Amazon Kindle (7th Generation) User Guide

Kindle User’s Guide, 5th Edition
Contents
2
Contents
Kindle User’s Guide, 5th Edition
Contents
3
Kindle User’s Guide, 5th Edition
Contents
4
Kindle User’s Guide, 5th Edition
Chapter 1 Getting Started
5
Chapter 1 Getting Started
Welcome to your new Kindle. This short guide will familiarize you with all of the features and
functionality of your Kindle. Some Kindle features may not be available based on your
country of residence or location. Please visit www.amazon.com/devicesupport for more
information about specific features.
Setting up your Kindle
Setting up your Kindle takes a few simple steps:
Select the device language. Connect to a wireless network. Register your Kindle to your Amazon account. Link your Kindle to your social network accounts. (Optional)
If you haven't done these steps yet, go to the Home screen now, select Set Up Your Kindle, and
follow the onscreen prompts. If you bought your Kindle online using your Amazon account, it
is already registered to you. To verify, tap the Home icon and look for your Amazon user
name in the upper left corner of the Home screen. If it says My Kindle or shows the name of a
previous owner instead of your own Amazon account name, you'll need to register it.
To register a Kindle that has been previously registered, tap the Quick Actions icon on the
toolbar, then tap All Settings. On the Settings page, tap My Account, then Register/Deregister
Device. If you have enabled Sign in Approval, you will need to enter your passcode followed
by the security code sent to your phone when you register the device.
If you have difficulty connecting to your wireless network or need more information, see
Network Connectivity. Once you have completed the setup process, Set Up Your Kindle will no
longer appear on your Home screen.
Kindle User’s Guide, 5th Edition
Chapter 1 Getting Started
6
Kindle controls
You need to learn only a few controls to use your Kindle.
Power button: To turn your Kindle on, press the Power button located on the bottom edge. If
you need to turn off your Kindle screen, press and hold the Power button for 7 seconds until
the Power dialog box displays and then tap Screen Off.
Your Kindle will automatically go into sleep mode after a few minutes of inactivity and a
screensaver displays. This static screensaver uses no battery power. To put your Kindle in
sleep mode, press and release the Power button. To wake up your Kindle, press and release
the Power button.
If your Kindle does not power on or is unresponsive during use and you need to restart it,
press and hold the Power button for 7 seconds until the Power dialog box displays and then
tap Restart. If the Power dialog box does not display, press and hold the Power button for 40
seconds or until the LED light stops blinking.
Micro-USB/power port: You can use the supplied USB cable to connect your Kindle to a
computer for charging the battery and transferring files. To charge your Kindle from a power
outlet, you will need a compatible AC adapter (sold separately) for the USB cable.
When your Kindle is charging, a lightning bolt appears on the battery status indicator at the
top of the Home screen. The indicator light on the bottom edge will turn amber while the
battery is charging and green when it is fully charged. Charging should take less than four
hours using a Kindle AC adapter. Charging using third-party adapters or via USB should take
less than four hours, but may take longer depending on the capability of the hardware.
You can still use your Kindle while it is connected to your computer and charging via USB. To
do so, unmount or eject it so that your Kindle exits USB drive mode.
Kindle User’s Guide, 5th Edition
Chapter 1 Getting Started
7
Windows: Right-click on the "Safely remove hardware" icon in the task bar and follow the
onscreen instructions to remove your Kindle.
Mac OS X: Click the Eject button next to the Kindle in any Finder window, or drag it from the
Desktop to the Trash.
Your Kindle will then exit USB drive mode, but will continue to charge. If the charge indicator
light on the bottom edge of the Kindle does not come on, make sure that the USB cable is fully
inserted into your Kindle and into the USB port of the computer. If your Kindle is still not
charging, try another USB port or power outlet.
Note that if your Kindle is plugged into a low-powered USB port—such as those found on
some keyboards and older computers—it will not receive enough power to charge.
Status indicators
At the top of the Home screen, you'll see indicators that inform you about the status of your
Kindle. To view these indicators within a book or document, tap the top of the screen to
display the toolbars.
Wireless status indicators
The Amazon Whispernet service wirelessly delivers content to your Kindle whenever and
wherever you want it. Your Kindle can connect to Whispernet via its built-in Wi-Fi capability.
The more bars on the Wi-Fi status indicator that are filled, the stronger the signal.
Your Kindle is connected to Whispernet using Wi-Fi.
Your Kindle is in Airplane Mode and you have no wireless connectivity.
Battery status indicator
The Kindle battery indicator shows the various states of the battery as it discharges. When
your Kindle is charging, a lightning bolt appears on the battery icon. Note that a weak wireless
signal can increase power consumption.
Activity indicator
This indicator appears in the top left corner of your Kindle screen when it is scanning or
connecting to a network, busy downloading new content, syncing and checking for new items,
searching for an item, opening a large PDF file, or loading a web page.
Kindle User’s Guide, 5th Edition
Chapter 1 Getting Started
8
Parental Controls indicator
This indicator appears when Parental Controls are enabled, either because you have turned
on specific restrictions or because a Kindle FreeTime (known as Kindle for Kids in the UK)
profile is active. For more information, see Parental Controls.
Keyboard
Your Kindle has an onscreen keyboard. When you tap within the Search field or begin other
actions that require you to type in information, the keyboard automatically displays at the
bottom of the screen. Tap the keys to enter your selection and use the appropriate buttons to
continue on to the next action. As you type, word suggestions based upon your entries display
above the keyboard. Tap the word you want to select.
Tips:
Tap the Number and Symbol key to enter numbers or symbols. Tap the Letter key to return to the regular keyboard.
Tap the Shift key to enter uppercase characters. Tap the Shift key twice to
enter all-cap mode, and tap it once to exit the mode.
To select a keyboard for a different language, tap the Quick Actions icon, then tap All Settings.
On the Settings page, tap Language & Dictionaries, then Keyboards.
To enter diacritics and special characters using the keyboard, press and hold the base letter’s
key. For example, press and hold the "n" to display ǹ, ñ, or ň.
A Globe key is added to your keyboard when you have selected multiple languages.
To select a different keyboard, tap the Globe key.
Network connectivity
Books, magazines, and other materials are delivered directly to your Kindle via its built-in
network connectivity. Your Kindle can connect to your home Wi-Fi network or to hotspots
located around the world, including libraries, coffee shops, and airports.
You can connect your Kindle to a wireless network manually or via a WPS-compatible router.
Please select the appropriate instructions below.
Connecting manually:
1. Tap the Quick Actions icon on the toolbar, then tap All Settings.
2. On the Settings page, tap Wireless. A list of the available Wi-Fi networks will display. If you
don't see the network you are looking for, tap the Rescan button to recheck for available Wi-
Fi networks.
3. Tap the name of the network that you want to use.
4. Enter the network password if required. A lock symbol next to the network name indicates
that it is password protected.
Kindle User’s Guide, 5th Edition
Chapter 1 Getting Started
9
5. Optionally, you can save your Wi-Fi password to Amazon for use later when setting up other
compatible devices. To opt out of this feature, verify that the Save password to Amazon
option is not selected when you enter your network password. For more information, see
Managing your saved Wi-Fi passwords.
6. Tap the Connect button. Once you have successfully connected to a network, the Wi-Fi status
indicator will display the network's signal strength.
Connecting via WPS:
1. Tap the Quick Actions icon on the toolbar, then tap All Settings.
2. On the Settings page, tap Wireless. A list of the available Wi-Fi networks will display. If you
don't see the network you are looking for, tap the Rescan button to recheck for available Wi-
Fi networks.
3. Tap the name of the network that you want to use.
4. Press the WPS button on your router.
5. Enter the network password if required. A lock symbol next to the network name indicates
that it is password protected.
6. Optionally, you can save your Wi-Fi password to Amazon for use later when setting up other
compatible devices. To opt out of this feature, verify that the Save password to Amazon
option is not selected when you enter your network password. For more information, see
Managing your saved Wi-Fi passwords.
7. Tap the WPS button. Once you have successfully connected to a network, the Wi-Fi status
indicator will display the network's signal strength.
Tips:
If you don't remember your network password, check your router and there may be a sticker
displaying the default password.
For information on deleting your saved Wi-Fi passwords, see Managing your saved Wi-Fi
passwords.
Please note that your Kindle does not support connecting to ad hoc (or peer-to-peer) Wi-Fi
networks.
If you are still having difficulties, please contact your Network Administrator, the individual
responsible for maintaining the network you are trying to access, or your Internet Service
Provider (ISP).
Managing your saved Wi-Fi passwords
When connecting to a Wi-Fi network, you can optionally choose to save your Wi-Fi password
to Amazon. Once saved, we can configure your compatible devices so that you will not need to
re-enter your Wi-Fi passwords for each device. Your Wi-Fi passwords are sent over a secured
connection and are stored in an encrypted file on an Amazon server. Amazon may use your
Wi-Fi passwords to connect your compatible devices but will not share them with any third
party without your permission. Amazon handles any information it receives, including your
Wi-Fi passwords, in accordance with the Amazon.com Privacy Notice.
To opt out of this feature, verify that the Save password to Amazon option is not selected
when you enter your network password.
Kindle User’s Guide, 5th Edition
Chapter 1 Getting Started
10
To change your Wi-Fi password in the future, perform the Wi-Fi setup process again from
your Kindle. Once reconnected to your Wi-Fi network, your updated Wi-Fi password will be
automatically saved to Amazon (if you have not opted out of this feature).
To delete any Wi-Fi passwords that you have saved from this device:
1. Tap the Quick Actions icon on the toolbar, then tap All Settings.
2. On the Settings page, tap Device Options, Advanced Options, then Delete Saved Wi-Fi
Passwords.
3. Tap Delete to confirm.
Airplane Mode
To turn wireless off and enter Airplane Mode, tap the Quick Actions icon on the toolbar, then
tap Airplane Mode. Any periodical downloads or other pending updates that require a
wireless connection will occur the next time you turn it back on. Turning on Airplane Mode
disables both 3G and Wi-Fi connections.
Special Offers and Sponsored Screensavers
For Kindle with Special Offers devices, you will receive Special Offers and Sponsored
Screensavers that display only on the Home screen or screensaver—not within a book. Note
that Special Offers and Sponsored Screensavers are not available in all countries.
Screensaver
When your device is sleeping, a Special Offer will be displayed on your screensaver. To see
more details on the offer, wake up your Kindle, then tap the Tap for Details area. To unlock
your Kindle without viewing offer details, swipe your finger to unlock. Special Offers and
Sponsored Screensavers are updated regularly when your Kindle is connected to a network.
Special Offer banners
Special Offer banners are displayed at the bottom of the Home screen. To view additional
details, tap the banner.
To view all available Special Offers:
1. Tap the Home icon, then tap the Menu icon.
2. Tap View Special Offers.
3. Tap on any available offer to view details about it.
Note that if you buy a Special Offer when your Kindle is offline, your order will not be
processed immediately. The purchase will be queued and the transaction will be
automatically completed the next time you connect to a network. To manage Special Offers,
tap the Quick Actions icon on the toolbar, then tap All Settings. On the Settings page, tap My
Account then Special Offers.
Kindle User’s Guide, 5th Edition
Chapter 2 Navigating Your Kindle
11
Chapter 2 Navigating Your Kindle
Your Kindle features a touchscreen interface that enables you to perform many tasks with
just a tap or swipe of a finger. To select an item, simply tap it. For example, tap a book cover
or title to open the book, or tap the Menu icon on the item's cover to view available options.
The Kindle Home screen
Your Kindle Home screen is organized into three sections: Recently Accessed Items, My
Reading Lists, and Recommended for You.
Recently Accessed Items: The left side of the Home screen shows your three most recently
accessed items. The percentage on the cover of the book indicates how far you have read. Tap
the My Library link on the Home screen to view more of your library.
My Reading Lists: The right side of the Home screen lists books that you have added to your
Amazon Wish List, Goodreads Want to Read shelf, and book samples that are available in the
Cloud.
Recommended for You: The bottom of the Home screen shows book recommendations,
such as Editors’ Picks, and books that your friends on Goodreads have read, are reading, or
want to read. For more information, see Recommended for You.
To access your library, tap My Library in the top left of the Home screen. For information on
managing your library, see Managing your Kindle Library.
Toolbars
EasyReach also lets you tap the top of the screen to display a toolbar. Toolbar options vary
depending on what you are viewing.
Kindle User’s Guide, 5th Edition
Chapter 2 Navigating Your Kindle
12
Standard toolbar
Home: Tap to return to the Home screen, where you'll find a list of books and other content
stored on your Kindle.
Back: Tap to retrace your steps. For example, you can follow a link from a book, then tap the
Back icon to return to your place in the book.
Quick Actions: Tap to access Airplane Mode, Sync My Kindle, and All Settings.
Airplane Mode: When selected, your Kindle will be placed in Airplane Mode and you
will have no wireless connectivity.
Sync My Kindle: Tap to synchronize your Kindle with other supported devices you own
and Kindle reading applications.
All Settings: Tap to access settings that will enable you to further customize your Kindle
experience. You can also access Settings by tapping the Menu icon, then selecting
Settings.
Goodreads: Tap to access Goodreads on Kindle. You will be prompted to sign in to Goodreads
or create a new account if you did not do so when setting up your Kindle.
Store: Tap to go to the Kindle Store. Your Kindle must have an active Wi-Fi connection to use
this feature.
Search: Tap to initiate a search. To exit search, tap outside of the Search box.
Menu: Tap to display a list of helpful options, including My Library, My Reading Lists, Kindle
Store, Goodreads, Kindle FreeTime (Kindle for Kids in the UK), Vocabulary Builder,
Experimental Browser, Settings, View Special Offers (Kindle with Special Offers devices only),
and Create New Collection.
Kindle User’s Guide, 5th Edition
Chapter 2 Navigating Your Kindle
13
When you're reading a book, menu options may include Shop Kindle Store, Vocabulary
Builder, Settings, Notes, About This Book, About the Author, Sync to Furthest Page Read,
Reading Progress, and Word Wise. Note that About the Author is only available for books that
support an author profile.
Reading toolbar
A secondary toolbar displays when you're reading a book and tap the top of the screen.
Go To: The Contents tab displays the book’s contents, including Beginning and chapter titles.
Use the Page or Location option to further navigate your book. The options displayed will
vary depending on the content you're reading. Tap the Notes tab to access your notes and
highlights. You can also view Popular highlights and Public notes by selecting the
corresponding options under the Notes tab.
X-Ray: The X-Ray feature lets you explore the "Bones of the Book" with a single tap. For
example, you can see all of the passages in a book that mention specific ideas, fictional
characters, historical figures, places, topics, and terms. You can also view notable clips and
images from a book in a stack of cards organized on a timeline, enabling you to quickly skim
through the clips and view all of the images in one place. If X-Ray is not available for a book,
the option will not appear. For more information, see X-Ray.
Display Settings (Aa): Tap to display font and text options for your Kindle books, including
font size, typeface, publisher font, line spacing, margins, and orientation. You can also select
your preferred Reading Progress tracking option.
Share: Tap to share your thoughts with friends using Goodreads on Kindle and other social
networks.
Bookmarks: Tap to add or delete a bookmark on the current page, and view previously
added bookmarks. The Bookmark icon on the toolbar changes from white to black on
bookmarked pages. A preview pane displays when you tap a bookmark in the list. To go to the
selected location, tap the preview pane. To exit the bookmark feature, tap outside of the
bookmark dropdown.
Kindle User’s Guide, 5th Edition
Chapter 2 Navigating Your Kindle
14
Reading Navigation toolbars
When reading, tap the top of the screen to display the Reading Navigation toolbar. This
toolbar displays the chapter name (if available), reading progress, and options to help you
explore your book. For more information, see Navigating a book.
Periodical toolbar
When you're reading a periodical, the toolbars are configured specifically for periodicals. To
display the toolbar, tap the top of the screen.
Periodical Home: Tap to display highlights of this issue.
Sections and Articles: Tap to go to the hierarchical list of sections and articles in a
newspaper or magazine. This option is not available in blogs.
A secondary toolbar is available when you're reading a periodical and are on the article detail
page. Options include:
Display Settings (Aa): Tap to display font and text options for your periodicals, including
font size, typeface, line spacing, and margins.
Clip This Article: Tap to clip an entire periodical article to the My Clippings file. The My
Clippings file is located in your library and stores your notes, bookmarks, highlights, and
clipped articles.
Kindle User’s Guide, 5th Edition
Chapter 2 Navigating Your Kindle
15
Tap zones
The EasyReach feature of your Kindle lets you effortlessly turn pages in a book or periodical
while holding the device with just one hand. Tapping almost anywhere in the display area will
take you to the next page; the area is large enough to be tapped whether you hold the device
with your left or right hand. Tap the left side of the screen to go to the previous page. The
EasyReach tap zones differ depending on whether your Kindle is in portrait or landscape
mode. When reading, you can change the screen orientation by tapping the Menu icon and
selecting Portrait or Landscape Mode. Note that the option displayed depends upon the
current orientation of your Kindle.
Portrait Mode
Kindle User’s Guide, 5th Edition
Chapter 2 Navigating Your Kindle
16
Landscape Mode
If you prefer, you can change pages by swiping the screen with your finger. To go to the next
page, swipe your finger from the right to the left across the screen. To go to the previous page,
swipe your finger from the left to the right across the screen.
Loading...
+ 37 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
