TOP AND CONSOLE PARTS
For Models: NGD4500VQ0
(White)
29" GAS DRYER
9−08 Litho in U.S.A.(LT)(bay)
1
Part No. W10217482 Rev.A.
TOP AND CONSOLE PARTS
For Models: NGD4500VQ0
(White)
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10150630
W10150620
8576796 Wiring Diagram
W10089178
W10203571
2
3 694419 Buzzer, Mini
4 8271365 Cap, End (L.H.)
5 717252 Plug, 2−Way
6 8274261 Panel, Rear
7 3405152 Switch,
8 8271359 Cap, End (R.H.)
9 693995 Screw, Hex
Instructions,
Installation
Use & Care Guide
Sheet,
Cycle Feature
Jumper,
Auxillary Switch
Terminal
Console
Wrinkle Gaurd
Washer Head
Illus. Part
No. No. DESCRIPTION
10 Screen, Lint
8558463 White
11 8536939 Clip, Spring
12 8533971 Screw, 8−18 x 5/16
13 688983 Screw, 8−18 x 5/8
14 8533951 Screw, Grounding
15 3395683 Connector
(Motor)
16 8557930 Top
W10196504
17
W10196503
18
19 3394427 Clip−Harness
20 388326 Screw, Console
21 3977678 Timer Assembly
22 3397269 Connector−Timer
23 3401144 Connector,
Knob,
Push−To−Start
Knob, Control
(60 Hz.)
(PTS Relay)
Illus. Part
No. No. DESCRIPTION
24 3403499 Connector,
2−Position
(Gas Valve)
25 3403498 Connector,
3−Position
(Gas Valve)
W10196507
26
W10086734
27
28 3936144 Connector
29 8271418 Bracket, Control
30 357213 Nut, Push−In (2)
31 8299876 Harness, Wiring
32 3401695 Jumper, Buzzer
33 3347243 Connector
34 94614 Terminal, Female
35 3977456 Switch,
Timer Knob
Assembly
Panel, Control
(On/Off)
6−Circuit
Push−To−Start
2
W10217482
CABINET PARTS
For Models: NGD4500VQ0
(White)
W10217482
3
CABINET PARTS
For Models: NGD4500VQ0
(White)
Illus. Part
No. No. DESCRIPTION
1 697776 Screw, 10−32 x 5/8
(External Ground)
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, Hex Head
4 8541400 Bracket, Cabinet
5 3396795 Cover, Block
6 3404162 Clamp, Motor
(W/Shield)
7 3396805 Panel, Rear
8 3403630 Plug−Strike
9 3980175 Clamp−Elbow
10 3406109 Door Switch
Assembly
11 697773 Screw, 6−20 x 7/8
12 341029 Clamp−Pipe
13 8318272 Burner Assembly
60 HZ
(See Pages 7 &
8 For Further
Burner Breakdown)
14 3404413 Plug−Hole
Illus. Part
No. No. DESCRIPTION
W10121316
15
16 3392100 Foot, Dryer
279810 Foot−Optional
W10194250
17
18 Cabinet
8530603 White
19 98234 Clip, Ground (2)
20 690363 Lock, Front Top (2)
21 Panel Front
3403447 White
22 8066184 Pulley, 60 HZ.
23 685203 Clip, Felt Pad (2)
24 3389441 Catch, Door
25 3405246 Seal, Door
Clamp−Motor
(Extended Length)
(Package of 2)
(Not Included.)
Motor Assembly
60 HZ.
(Includes
Illus. 4)
Assembly
Illus. Part
No. No. DESCRIPTION
26 3400500 Bolt,
5/16 − 18 x 3/4
27 342055 Screw, 8−18 x 1/2
28 3405514 Hinge, R.H.
29 348780 Base, Motor
W10131364
30
31 691366 Idler & Pulley
32 8066217 Hinge, Top (2)
33 3403431 Strike, Panel
34 3394083 Clip, Front Panel
35 3402341 Door, Rear
36 Door, Front
3402335 White
37 Handle, Door
3405184 White
38 3406129 Seal & Bearing
39 Plug, Front Panel
3394975 White
40 344020 Cord, Power
Belt, Drive
Assembly
Assembly
4
W10217482
BULKHEAD PARTS
For Models: NGD4500VQ0
(White)
W10217482
5
BULKHEAD PARTS
For Models: NGD4500VQ0
(White)
Illus. Part
No. No. DESCRIPTION
1 348368 Lint Chute
Assembly
2 489463 Screw, 8−18 x 5/8
3 3388703 Washer−Support
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
7 3392519 Fuse, Thermal
8 8066086 Drum Hole
Plug
9 3387134 Thermostat,
Internal−Bias
10 694089 Wheel, Blower
11 8577230 Housing, Blower
12 8066155 Clip
13 343641 Screw, 10−16 x 1/2
14 8530285 Box, Heater
15 3403140 Thermostat, 205
C)
(96
16 280010 Kit,
Thermal Cut−Off
(Includes
Illus. 15)
17 3390647 Screw, 8−18 x 1/2
18 8066049 Funnel, Burner
19 348197 Washer, Support
20 3359452 Nut, 3/8−16
21 696302 Shield, Exhaust
22 3403491 Bulkhead
23 3406022 Bracket, Bulkhead
24 3401707 Wire, Jumper
25 339956 Seal
26 3403636 Baffle, Drum (1)
27 90296 Clip
28 3976434 Bracket, Support
29 692490 Baffle, Drum (2)
30 695587 Drum Assembly
31 3406130 Seal, Rear Drum
W10109200
32
33 692526 Ring, Bearing
34 690997 Ring, Tri
35 3399506 Shaft, L.H.
36 3399507 Shaft, R.H.
37 3397590 Roller, Support
38 338906 Sensor, Radiant
Screw, 11−16 x 3/4
F
6
W10217482
8318272 BURNER ASSEMBLY
For Models: NGD4500VQ0
(White)
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
W10217482
BA−150
7
8318272 BURNER ASSEMBLY
For Models: NGD4500VQ0
(White)
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
Illus. Part
No. No. DESCRIPTION
1 8318272 Burner Assembly
60 Hz.
(Type 1)
(White Rodgers)
2 688617 Tube, Burner
3 694298 Bracket, Ignitor
4 686590 Ignitor
5 3393909 Screw & Washer
(8−32 x 5/8)
6 343641 Screw, 10−16 x 1/2
7 693986 Base, Burner
8 3387057 Screw, 8−18 x 3/8
9 Orifice, Burner
234826 Type 1
229742 Type 4 (Butane)
234868 Type 4 (Propane)
10 8318277 Valve, 60 Hz.
(Includes Pipe &
Illus. #7)
11 694421 Screw,
8−32 x 1/2 (2)
12 694538 Bracket, Coil
13 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
14 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
15 694424 Leak Limiter
16 694423 Screw, Regulator
Adjustment
17 694422 Spring, Regulator
20 239822 Plug, Pipe
25 341029 Clamp, Pipe
Following Parts Not Illustrated
694572 Conversion Kit
(Type 1)
to Type (4) L.P.G.
8
BA−150
W10217482
OPTIONAL PARTS (NOT INCLUDED)
For Models: NGD4500VQ0
(White)
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
279948 Kit,
Dryer Repair
346764 Kit, Hold−Down
(Gas Dryer Mobile
Home Installation)
8522199 Kit, Dryer
Vent Testing
3406839 Dry Rack
PAINT, TOUCH−UP (1/2oz.)
72017 White
4392899 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
4392901 Biscuit
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
4392900 Biscuit (Uncut)
W10217482
9
