Page 1
Package Contents
Product Detail
Wireless Speaker with USB Transmitter
Quick Start Guide
by Aluratek
AUWS01F
aluratek.com
Product Operation
Step 1: Charging the Speaker
The Built-in Li-Ion Polymer battery is not fully charged and must be fully charged
before first use. It is recommended to charge the battery for a minimum of 3 hrs.
1. Connect the mini-B end of the provided USB cable to the USB port on AUWS01F
2. Connect the type-A end of the same cable to a computer or power adapter*
(optional accessory)
3. The LED indicator will shown Red during charging and will go off when the
battery is fully charged
qsg Q10178 Copyright © 2010 Aluratek, Inc. All Rights Reserved.
Your order has been carefully packaged and inspected. The following should be included in your package.
Please inspect the contents of the package to ensure that you have received all items and that nothing has
been damaged. If you discover a problem, please contact us immediately for assistance.
Wireless Speaker USB Transmitter
Auxillary Cable
Quick Start Guide Warranty / Registration
USB 2.0 Cable
Card
Step 2: Connect the speaker to an audio source:
From a computer:
1. Press the power button on the speaker until the blue color LED indicator is on
2. Connect the USB transmitter to the computer and make sure the LED indicator
is on. The USB transmitter is connected to the speaker wirelessly automatically
3. You can start streaming music from your computer now using any media player
such as Windows media player, iTune, and etc
4. You can adjust the volume by pressing the volume buttons on top of the speakers
5. To turn of the speaker, press and release the “Power” button. LED indicator will
fade off
From a MP3 player:
1. Press the power button on the speaker until the blue color LED indicator is on.
2. Connect the music player Line out/headset out to the Line In port of the
speaker using included audio cable
3. You can now stream music from the MP3 player.
4. You can adjust the volume by pressing the volume buttons on top of the speaker
5. To turn of the speaker, press and release the “Power” button, LED indicator
will fade off
1
4
2
7
3
6
8
5
ITEM
Power
1
Volume -
2
Volume +
3
LED Indicator
4
USB port
5
Audio port
6
Channel key
7
LED Indicator
8
Technical Support Warranty
If you need further assistance, please contact the Aluratek support department for
troubleshooting prior to returning this device.
E-mail: support@aluratek.com
Web: www.aluratek.com/support
Local (Tustin, CA): 714-586-8730
Toll free: 1-866-580-1978
Radio and TV Interference Statement
WARNING!!! This equipment has been tested and found to comply with the limits of a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by whatever measures may be required to correct the interference.
Aluratek warrants this product against defect in material or workmanship for 1 Year
from the date of purchase.
This warranty becomes invalid if the factory-supplied serial number or "warranty void" sticker
has been removed or altered on the product.
This warranty does not cover:
A) Cosmetic damage or damage due to acts of God
B) Accident, misuse, abuse, negligence or modification of any part of the product.
C) Damage due to improper operation or maintenance, connection to improper equipment,
or attempted repair by anyone other than Aluratek.
D) Products sold AS IS or WITH FAULTS.
IN NO EVENT SHALL ALURATEK'S LIABILITY EXCEED THE PRICE PAID FOR THE
PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THE PRODUCT, IT'S ACCOMPANYING
SOFTWARE, OR IT'S DOCUMENTATION.
Aluratek makes no warranty or representation, expressed, implied, or statutory, with respect
to it's products, contents or use of this documentation and all accompanying software, and
specifically disclaims it's quality, performance, merchantability, or fitness for any particular
purpose. Aluratek reserves the right to revise or update it's product, software or documentation
without obligation to notify any individual or entity.
DESCRIPTION
To turn on/off speaker
To lower the volume
To increase the volume
Status indicator
To power / charge speaker using USB cable
Line in for other audio source
To switch transmission channel
Status indicator
