8000mAh Dual USB 2.1A Power Bank with 32 LED Lantern
Quick Start Guide
model APBQ08F
aluratek.com
qsg Q10449 Copyright © 2017 Aluratek, Inc. All Rights Reserved.
Package Contents Product Highlights
Your order has been carefully packaged and inspected. The following accessories should
be included in your package. Please inspect the contents of the package to ensure that
you have received all items and that nothing has been damaged. If you discover a problem,
please contact us immediately for assistance.
USB Charging Cable Registration Card
Carabiner
Solar Panels
Power Button
USB Output Port A
5V / 2.1A*
LED Indicators
USB Output Port B
5V / 2.1A*
32 LED Lights
Micro USB Input
DC 5V / 2A
*Max output 5V / 2.1A combined
Operation Operation
Charging The Battery
The battery is not fully charged and it is highly recommended that you charge
Checking The Capacity
The power status LEDs will light up according to available power capacity
APBQ08F before you begin using it.
Note: Using APBQ08F “out of the box” will not harm the device. You will experience
reduced battery life as the unit will not be fully charged.
To charge the device, connect the larger end of the USB cable provided to your PC
or a USB power adapter (not provided) and the Micro USB end to APBQ08F. Once
it is fully charged, all 4 blue LEDs will be on. The charge time is about 5 hours.
<25% capacity 25 - 50% capacity 50 - 75% capacity >75% capacity
Note: LED indicators will remain on and stop flashing when the power bank is fully charged.
When the battery is low, the first indicator will start to flash. Please charge the power bank.
The power bank will shut off in 30 seconds when no device is connected.
Charging Your Device
Use the original cable that came with your device. Connect the USB-A end to one of
the USB Output ports on the battery pack. Charging will start automatically once the
cable is connected.
Radio and TV Interference Statement
WARNING!!! This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by whatever measures may be
required to correct the interference.
Warranty
Aluratek warrants this product against defect in material or workmanship for 1 YEAR
from the date of purchase.
This warranty becomes invalid if the factory-supplied serial number or "warranty void" sticker has
been removed or altered on the product.
This warranty does not cover:
A) Cosmetic damage or damage due to acts of God
B) Accident, misuse, abuse, negligence or modification of any part of the product.
C) Damage due to improper operation or maintenance, connection to improper equipment,
or attempted repair by anyone other than Aluratek.
D) Products sold AS IS or WITH FAULTS.
IN NO EVENT SHALL ALURATEK'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT
FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THE PRODUCT, IT'S ACCOMPANYING SOFTWARE, OR
IT'S DOCUMENTATION.
Aluratek makes no warranty or representation, expressed, implied, or statutory, with respect to it's
products, contents or use of this documentation and all accompanying software, and specifically
disclaims it's quality, performance, merchantability, or fitness for any particular purpose. Aluratek
reserves the right to revise or update it's product, software or documentation without obligation to
notify any individual or entity.
Operation
Solar Panel Charging
Place the solar panel side directly under the sun to start charge, the green LED
indicator will turn on indicating charging.
Note:The solar panel is designed for emergency charging. It should not be the
primary source of charging. Prolonged exposure under the sun will cause damage
to the internal battery.
Operating The LED Lamp
- To turn ON, press the Power Button once for 100% brightness
- Once ON at 100%, press the Power Button once for 25% brightness
- Once ON at 25%, press the Power Button once for strobe light
- Press the power button once to turn the lamp OFF
Note:The LED lamp will last up to 50 hours with 25% brightness when the battery
charger is fully charged.
Technical Support
If you need further assistance, please contact the Aluratek support department for
troubleshooting prior to returning this device.
E-mail: support@aluratek.com
Web: www.aluratek.com/helpdesk
Local (Irvine, CA): 714-586-8730
Toll free: 1-866-580-1978
