eBook Reader
Instructional Manual | AEBK07FS
mnl M10191 Copyright © 2010 Aluratek, Inc. All Rights Reserved. aluratek.com
Package Content
Getting Started
1 2 3
4 5 6
7 8 9
10
11
1
1. AEBK07FS Ebook Reader
2. USB cable
3. Power adapter
4. Carrying Pouch
5. QSG
6. Download Guide
7. Registration/Warranty Card
Parts and Controls
Power button – press and hold for 3 seconds to turn on/off,
press and hold 6 seconds to reset
Next pg button – press to turn to next page
Previous pg button – press to turn to previous page
OK / Enter Button
Zoom button – press to adjust the font size or to zoom in/out
Menu button – press to display Option Menu
Directional buttons – to move cursor
Music button – to enter into music menu
Return button – press once to return to previous menu, press
12
13
14
15
16
17
18
Getting Started
and hold to return to Home menu
Earphone jack
Mini USB jack – for data transfer and charging
SD cart slot – supports SD/SDHC/MMC card
DC jack – for charging
LED indicator
Speaker
Power On and Off AEBK07FS
Press and hold the [Power] button for 3 seconds to turn on
AEBK07FS.
When AEBK07FS is on, press and release the [Power] button for
standby mode, press and release the [Power] button again to
return to power on mode.
To turn off AEBK07FS, press and hold the [Power] button for 3
seconds.
Charging AEBK07FS
The battery is not fully charged and it is highly recommended that you
charge your LIBRE before you begin using it.
Note: Using the LIBRE “out of the box” will not harm the device. You
will experience reduced battery life as the unit will not be fully
charged.
Connect the power adapter to the LIBRE’s USB port and you will see
an animation of a battery charging on the LIBRE’s display. Please
charge the battery for a minimum of six (6) hours using the power
adapter. You may also charge the battery by connecting your LIBRE to
the USB port of your PC using the USB cable included with your LIBRE.
However, using this method will extend the charging time to
approximately twelve (12) hours.
When DC/USB power cable is connected to AEBK07FS for charging,
Getting Started
AEBK07FS will go into standby mode after it is idle for 60 seconds.
Press the [Power] button to start AEBK07FS.
The battery status is displayed at the bottom left corner. The
remaining battery playback time is displayed right next to the
battery icon.
Inserting Memory Card
AEBK07FS supports SD/SDHC/MMC card in both FAT and NTFS file
system. NTFS is needed to copy file with size larger than 4GB.
To insert a Memory card:
Open the SD cover.
Check that the SD card is in the correct position with the contact
pin facing upwards as illustrated below. You may damage the card
and AEBK07FS if SD card is not inserted in the right orientation.
Push the SD card into the card slot until it clicks.
To remove SD card, push the SD card once again until it clicks.
When a SD card is inserted in or ejected from AEBK07FS, it may
take few seconds for AEBK07FS to update the content.
Please avoid inserting or ejecting SD card when other operation is
running.
Do not remove the card if the content inside the card is being
played. This will halt the operation of AEBK07FS and cause
AEBK07FS to restart.
If the system is not responding, press and hold the <Power>
book. Press <OK> button to
open the last page read.
2. Library
-display the list of books
available. Move the cursor to the
desired title and press <OK> to
open it.
3. Battery Indicator
-displays battery status during
operation
4. Page Number
-displays current page number
and total available pages.
5. Time & Date
-display current time and date,
you can set this from the
[Settings]
6. File Directory
- indicates the location where the
file is stored. SD – SD card, INT –
internal memory
Getting Started
button for 6 seconds to reset.
Limitations with NTFS file system:
Books in the card are not recognized by ADE when connected to
PC.
Direct copy of files from internal memory to card is not supported.
Starting from Home Menu
When AEBK07FS is turn on, you will enter into the Home Menu.
Library
Battery Indicator
Page Number
Time & Date
Getting Started
Entering Option Menu
Press the [Menu] button to display the Option Menu as illustrated.
Press the directional key to move the
cursor to desired item. Selected item
will be highlighted.
Press <OK> to enter.
To exit from Option menu, move cursor
to and press <OK> to confirm.
Alternatively, press the <Return>
button to exit.
To sort books by different categories: Title, Author,
Category, Date, and Format
Jump to a specific page
Read from previously added bookmarks
Adjust brightness of the display screen
Enter into Video Player
Enter into Music Player
Enter into Photo Viewer
Enter into File Explorer for advance file management
Enter into System settings and to read user guide
Open your favorite book list.
Importing Content
Importing and Transferring Content
Importing Content
AEBK07FS supports USB Mass Storage Device function.
To import contents (ebooks, video, audio, photo etc) into
AEBK07FS, connect AEBK07FS to PC via the supplied USB cable.
Upon successful connection to PC, AEBK07FS will enter USB mode
and all operation will be halted.
Go to [My Computer]; double click on disk “AEBK07FS” to open.
Perform normal file management operation like other USB device.
Importing DRM Contents
Adobe Digital Editions (ADE) is required for downloading DRM content
into AEBK07FS.
Installing Adobe Digital Edition (ADE)
To download the latest Adobe Digital Edition software, please go to
http://www.adobe.com/products/digitaleditions/#fp .
For first time user, you will need to get a free adobe ID from
adobe’s website. Click on the [get an Adobe ID online] link as below:
Enter your email address and complete the online form as
instructed.
Authorizing PC and AEBK07FS
Upon registration, return to the ADE window. Enter the username
and password to activate your Adobe account.
After activation, connect AEBK07FS to PC. ADE will detect
AEBK07FS and you are prompted to authorize the device.
