Installation Guide
Rev. 011615
Pace1PRD
IP and Hi-PoE Receiver over extended distance CAT5e
Overview:
Pace1PRD is a long range Ethernet receiver which transmits data at 100mbps full duplex and power
via a Cat5e or higher cable. The Pace1PRD receiver is powered via Altronix NetWay1D midspan
injector. The receiver passes the Hi-PoE (60W) power over the cable to the eBridge200WPM
transceiver which in turn passes this power to an enabled IP camera/device. These plug and play
units facilitate cost effective solutions for IP devices that need to be installed at distances greater
than 100m.
Features:
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
Input:
• Powered by NetWay1D (60W).
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or 1 pair UTP
structured cable.
• Distance: up to 500m (1,500 ft.).
• Speed: 10/100BaseT, half/full duplex,
auto negotiation.
• Throughput is rated to pass 100mbps of
data at distances up to 1,500 ft. With
proper headend equipment this supports
Megapixel, HD720, HD1080.
CAT5e or Higher:
• Distance: up to 1,500 ft. @ 100mbps (see
Cable Type, Total Device Power, Data and
Power Distance, pg. 3).
LED Indicators:
• Green - PoE ON (by respective RJ45 jack).
• Yellow and Green LED IP Link status,
10/100Base-T/active.
Environmental:
• Operating Temperature Pace1PRM:
-- 4ºF to 120.2ºF (-- 20ºC to +49ºC).
• Storage Temperature:
-- 22º to 158ºF (-- 30º to +70ºC) Storage.
• Humidity: 20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Extend Network link distance in an
industrial environment (see note, pg. 2).
• Works with Megapixel, HD720, HD1080
and VGA (SD) cameras (see note, pg. 2).
Mechanical:
• Dimensions (W x L x H approx.):
3.5” x 3.5” x 1”
(88.89mm x 88.89mm x 25.4mm)
I.T.E. 43KC
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and
with all local codes and authorities having jurisdiction. Wiring should be UL Listed and/or
Recognized wire suitable for the application.. Pace1PRD is intended for indoor use only.
1. Pace1PRD installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the unit’s
mounting hole (Fig. 2a, pg. 3). Unit should be mounted in proximity to ethernet
switch/network, NVR or video server.
b. Connect structured cable from NetWay1D to RJ45 jack marked [PoE Input] (Fig. 2, pg. 3).
c. CAT5e or higher: Connect CAT5e or higher cable to connector marked [RJ45 OUT]
(Fig. 2, pg. 3).
2. eBridge200WPM connections:
a. Connect Cat5e from Pace1PRD (60W) to connector marked [CAT INPUT] (Fig. 2, pg. 3)
b. Select input power SW3 on switch marked [60W CAT, 30W CAT or 60W COAX] (Fig. 2, pg. 3).
c. Connect structured cable from one (1) 60W camera/device to RJ45 jack marked [Port 1] or
connect two (2) individual structured cables from two (2) 30W cameras/devices to RJ45
jacks marked [Port 1 & Port 2] (Fig. 2, pg. 3).
Pace1PRD - 1 -
Technical Specifications:
Parameter Description
Connections RJ45 for ethernet link or single pair UTP.
Input power
requirements
Indicators
Environmental
Conditions
Regulatory
Compliance
Weights (approx.) Product: 3.88 oz. (0.11 kg.); Shipping: 6.70 oz. (0.19 kg.)
Fig. 1 Pace1PRD
Midspan or endspan port connected.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W)
Yellow (RJ45 connector): On - Link, Off - No Link, Blinking - Activity.
Green (RJ45 connector): On - 100Base-TX, Off - 10Base-T.
Yellow: PoE Active.
Operating Ambient Temperature: UL60950-1
-- 4ºF to 120.2ºF (-- 20ºC to +49ºC).
Relative humidity: 20 to 85%, non-condensing.
Storage Temperature: -- 22º to 158ºF (-- 30º to +70ºC).
Operating Altitude: -- 1000 to 6,561.679 ft. (-- 304.8 to 2000m).
UL/CUL Listed for Information Technology Equipment (UL 60950-1).
CE approved.
Yellow LED
indicates
Hi-PoE Present
from Midspan/
Endspan
Single
UTP N/A
CAT5e or
higher from
eBridge200WPM
Yellow LED
indicates
Hi-PoE being
transmitted to
eBridge200WPM
Structured
Cable to
NetWay1D
Midspan
Injector
*Note: Caution: once Hi-PoE connection is established between Pace1PRD and eBridge200WPM,
disconnection from eBridge200WPM will not disable the Hi-PoE output voltage on the Pace1PRD,
although the eBridge200WPM can be reconnected, caution should be taken not to connect the
CAT5e wiring from Pace1PRD to any non-PoE device.
- 2 - Pace1PRD
PoE+ Camera/Device
60W CAT
PoE+ Camera/Device
SW3
or
30W CAT
60W COAX
SPEED
SW3
60W CAT
ACTIVITY
Cat5e - 100m
PORT 1 PORT 2
SPEED
ACTIVITY
Single PoE Camera Connection:
Cat5e - 100m Cat5e - 100m
or
30W CAT
60W COAX
COAX INPUT
ACTIVITY
1
SPEED
DATA
PoE
PoE
SPR
DATA
PoE
PoE
SPR
CAT INPUT
Option 1 Option 2
60W Camera/Device
ON
PoE
Aux.
+ ---
INOUT
Cat5e - 500m
NetWay1D
PoE
LED
Input
PoE
Input
www.altronix.com
PoE
LED
Output
IP- Receiver
Passes Hi-PoE
Z1409
Link
RJ45
Pace1PRD - Receiver
I.T.E. 43KC
RJ45 LEDs Yellow - Activity
Green - Speed
Fig. 2
Pace1PRD
Pace1PRD - 3 -
Green LED Power and PoE
Cable Type, Total Device Power, Data and Power Distance:
Cable Type
Total Power
Consumption
Max. Data
Distance
Max. Power
Distance
Cat-5e 15W 500m 846m
Cat-5e 30W 500m 423m
Cat-5e 60W 500m 211m
Note: Higher gauge wiring will allow for longer distances.
Notes:
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
