ED 2- 7 2/ 2S
ED 2S Y S- 72 /2S
ED2-72/2S SERIES
ED2SYS-72/2S SERIES
MULTI-SH E L F H E AT E D DI S P L AY
●
HALO HEAT … a controlled, uniform heat source that gently
holds and surrounds food for better appearance, taste, and longer
holding life.
●
Holds and displays hot food fresh and moist for hours.
●
SELF-S ERVIC E H OT DI SPLAY C ASE
— Curved glass styling.
— Thermostatically controlled heat source radiates from the base of
each shelf in multiple heat zones.
— Top shelf incorporates thermal kinetic glass technology to provide an
evenly heated display surface.
— Bottom shelf is heated by an aluminum plate with a resistive heat pad.
— Overhead lighting on each shelf.
— Solar cool bronze sliding glass doors reflect heat back into the
products and mirror the display to enhance merchandising effect.
— Customer self-service opening is across the full width of case.
— Front-mounted heat guard on each shelf provides customer protection.
MULTI-SHELF HEATED DI SPLAY C ASE
The display case is constructed of 18 gauge, non-magnetic stainless steel. A curved, tempered glass top frames the
display case. Removable, sliding glass doors on the operator side are included. Sliding door tracks have a “clean
sweep” cutout allowing for easy cleaning and crumb removal. Each shelf is controlled by two (2) adjustable thermostats
with a range of 1 to 10, and includes one (1) heat-on indicator light. The two-shelf self-service display system includes a
low-profile, European style base with one (1) storage shelf. As an additional option, the base can be adapted to
accommodate two (2) 500-1D drawer warmers. Counter-top display cases include one set of 4" (102mm) legs.
Note: For use with pre-packaged foods only.
ED2-72/2 S - 72" (1829mm) length
■■
ED2SYS-7 2/ 2S - 72" (1829mm) length, with base
■■
FACTORY IN STAL LED OPTION S
● The system base is not sold as a separate
item. Order the full ED2SYS/2S model
to receive the base.
● Panel Color Choices
➥Specify color choice:
Black, standard
■■
Stainless Steel
■■
Custom Color
■■
#70 A - 05 /0 9
W164 N9221 Wat er S tr ee t • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PH ON E: 262.251.3800 800.558.8744 U .S .A ./CA NA DA FA X: 2 62 .2 51 .7 06 7 80 0. 32 9. 87 44 U .S.A . O NLY
www.alto-shaam.com
D UE T O O NG OI N G P RO D UC T I M PR O VE ME N T, S PE C IF I CA TI ON S A R E S UB J EC T T O C HA N GE W IT H OU T N O TI C E.
P RI NT E D I N U .S . A.
48" (1219mm)
26-1/8" (661mm)
23-11/16" (601mm)
18-15/16"
(482mm)
3
" (76mm)
ADJUSTABLE
PEGS IN EACH
CORNER
ELECTRICAL
PANEL
E
LECTRICAL
OUTLET
47-7/8" (1216mm)
3 ANGLE
SHELF
23-11/16" (601mm)
27-1/2" (699mm)
25-5/8" (650mm)
36-13/16" (934mm)
37-13/16" (959mm)
10-1/4"
(259mm)
47-7/8" (1216mm)
ELECTRICAL
PANEL
18-15/16"
(482mm)
3" (76mm)
ADJUSTABLE
P
EGS IN EACH
CORNER
ELECTRICAL
OUTLET
26-1/8" (661mm)
23-11/16" (601mm)
47-7/8" (1216mm)
72" (1829mm)
48" (1220mm)
8-3/4"
(
223mm)
8-9/16"
(216mm)
3-11/16"
(93mm)
1" (26mm)
36-3/4" (932mm)
2"
(52mm)
26-1/2" (673mm)
3 ANGLE
SHELF
4
8" (1220mm)
10-5/16"
(261mm)
ED2-72/2S SE RIE S
3 ANGLE
SHELF
23-11/16" (601mm)
27-1/2" (699mm)
25-5/8" (650mm)
36-13/16" (934mm)
37-13/16" (959mm)
10-1/4"
(259mm)
47-7/8" (1216mm)
48" (1220mm)
8-3/4"
(223mm)
8-9/16"
(216mm)
3-11/16"
(93mm)
1" (26mm)
36-3/4" (932mm)
2"
(52mm)
26-1/2" (673mm)
3 ANGLE
SHELF
48" (1220mm)
10-5/16"
(261mm)
8-3/4"
(223mm)
8-9/16"
(216mm)
3-11/16"
(93mm)
1" (26mm)
36-3/4" (932mm)
2"
(52mm)
26-1/2" (673mm)
3 ANGLE
SHELF
48" (1220mm)
10-5/16"
(261mm)
E L E C T R I C A L
VO LTAGE PH AS E C YC LE /H Z A MP S kW
208-240V (A
GC Y
)
1 50/60 17.9 4.5
at 208V 1 50/60 17.1 3.6
at 240V 1 50/60 19.6 4.7
NE MA L6-30P
30A, 2 50V P LU G
ED2SYS-72/2S SE RIE S
MULTI -S H E L F H E AT ED DISPLAY SY S T E M S
ED 2- 72 /2S P rof il e
W E I G H T (ES T.)
OD EL NE T SH IP
M
ED2-72/2S: CO NTA CT FAC TO RY CO NTA CT FAC TO RY
ED2SYS-72/2S: C ON TACT FACTORY CON TAC T FACTORY
CR ATE D DI MENSI ON S
: HXWXD
ED2-72/2S: CON TA CT FAC TO RY
ED2SYS-72/2S: C ONTACT FA CT ORY
P R O D U C T C A PA C I T Y
TO P S H EL F
Eighteen (18) chicken boats with dome cover
BO T TOM S HEL F
Twenty-one (21) chicken boats with dome cover
O P T I O N S & A C C E S S O R I E S
WORK SHE LF WITH GRAVY L AN E 5005639
■■
I N S TA L L A T I O N R E Q U I R E M E N T S
Display case must be installed level. The display case must not
be installed in any area where it may be affected by steam,
grease, dripping water, high temperatures, or any other
severely adverse conditions.
Do not install a heated display case near a cold air source such
as a freezer, air conditioning vents, or in any area where
outside air fluctuation can affect performance.
ED 2S YS -72 /2 S P ro fi le
ED 2S YS -72 /2 S B ac k V ie w
D I M E N S I O N S (HXWXD)
ED2-72 /2S
EX TE RI OR:
30-3/16" x 72" x 48" (766mm x 1829mm x 1220mm)
ED2SYS -72/2S
EX TE RI OR:
47-7/8" x 72" x 48" (1216mm x 1829mm x 1220mm)
TO P SHE LF D IMENS IO NS (WXD):
71-5/16" x 18-3/4" (1811mm x 475mm)
BO TT OM SH ELF D IM EN SIONS (WXD):
64-5/8" x 28-3/4" (1642mm x 730mm)
S P E C I F I C A T I O N S
●
Three (3) florescents are enclosed in the top interior
of the case. Three (3) florescents are enclosed and
centered under the top shelf. Each set is controlled
by one (1) ON/OFF light switch.
●
One (1) 10" x 60" (254mm x 1524mm) operator-side
work shelf.
