Altec Lansing VS2121 User Manual
User’s guide Guía del usuario
Mode d’emploi Guia do Usuário
V
S•2121
1
The lightning flash with arrowhead, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
Caution: To prevent the risk of electric shock, do not
remove cover (or back). No user-serviceable parts
inside. Refer servicing to qualified service personnel.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
IMPORTANT Safety Instructions
1. Read Instructions — All the safety and operating instructions should be read
before the appliance is operated.
2. Retain Instructions — The operating instructions should be retained for
future reference.
3. Heed Warning — All warnings on the appliance and in the operating
instructions should be adhered to.
4. Follow Instructions — All operating and use instructions should
be followed.
5. Water and Moisture — The appliance should not be used near water — for
example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, etc.
6. Outdoor Use — Warning: To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
7. Location — The appliance should be installed in a stable location.
8. Ventilation — The appliance should be situated so that its location or
position does not interfere with its proper ventilation. For example, the
appliance should not be situated on a bed, sofa, rug, or similar surface that
may block the ventilation openings; or placed in a built-in installation, such
as a closed bookcase or cabinet that may impede the flow of air through the
ventilation openings.
9. Heat — The appliance should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances (including amplifiers)
that produce heat.
10. Power Sources — The appliance should be connected to a power supply only
of the type described in the operating instructions or as marked on the
appliance.
11. Power-Cord Protection — Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them. Pay particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.
12. Grounding or Polarization — The precautions that should be taken
so that the grounding or polarization means of an appliance is
not defeated.
13. Cleaning — The appliance should be cleaned only with a polishing cloth or a
soft dry cloth. Never clean with furniture wax, benzene, insecticides or other
volatile liquids since they may corrode the cabinet.
14. Non-Use Periods — The power cord of the appliance should be unplugged
from the outlet when left unused for a long period of time.
15. Lightning Storms — Unplug the apparatus during lightining storms.
16. Object and Liquid Entry — Care should be taken so that objects do not fall
and liquids are not spilled into the enclosure through openings.
17. Accessories — Only use attachment acessories specified by Altec Lansing
Technolgies, Inc.
18. Damage Requiring Service — The appliance should be serviced by qualified
service personnel when:
• The power-supply cord or the plug has been damaged.
• Objects have fallen, or liquid has been spilled into the appliance.
• The appliance has been exposed to rain.
• The appliance does not appear to operate normally or exhibits a marked
change in performance.
• The appliance has been dropped or the enclosure damaged.
19. Servicing — The user should not attempt to service the appliance. Servicing
should be referred to qualified service personnel or returned to the dealer
or call the Altec Lansing service line for assistance.
One-Year Limited Warranty
Altec Lansing Technologies, Inc. warrants to the end user that all of its
powered audio, PC audio, portable audio, TV or gaming speaker systems
are free from defects in material and workmanship in the course of normal
and reasonable use for a term of one year from the date of purchase.
This warranty is the exclusive and only warranty in effect relative to Altec
Lansing powered audio, PC audio, portable audio, TV or gaming speaker
systems and any other warranties, either expressed or implied, are invalid.
Neither Altec Lansing Technologies, Inc. nor any authorized Altec Lansing
Technologies, Inc. reseller is responsible for any incidental damages incurred
in the use of the speakers. (This limitation of incidental or consequential
damage is not applicable where prohibited.)
Altec Lansing Technologies, Inc.’s obligation under this warranty does not
apply to any defect, malfunction or failure as a result of misuse, abuse,
improper installation, use with faulty or improper equipment or the use of
the speaker systems with any equipment for which they were not intended.
The terms of this warranty apply only to powered audio, PC audio, portable
audio, TV or gaming speaker systems when such speakers are returned to
the respective authorized Altec Lansing Technologies, Inc. reseller where
they were purchased.
Customer Service
The answers to most setup and performance questions can be found in
the Troubleshooting guide. You can also consult the FAQs in the customer
support section of our Web site at www.alteclansing.com. If you still can’t
find the information you need, please call our customer service team for
assistance before returning the speakers to your retailer under their
return policy.
1-800-ALTEC-88 (1-800-258-3288)
Email: csupport@alteclansing.com
For the most up-to-date information, be sure to check our Web site at
www.alteclansing.com.
International Distribution
International customers: For information regarding the distribution of Altec
Lansing products in your country, please visit www.alteclansing.com and
click on “International.”
CAUTION
To prevent electric shock do not use this (polarized) plug with an
extension cord, receptacle or other outlet unless the blades can be
fully inserted to prevent blade exposure.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
Connecting the Power Cord (AC Wall Socket)
Long slot is neutral
(ground) side.
Insert the wide blade
into the ground side slot.
2
Thank you for purchasing this Altec Lansing product. For generations, Altec
Lansing has been first in audio innovation. Today, our line of powered
speakers has received more performance awards than any other brand. In
all kinds of desktop environments, in every price range, Altec Lansing offers
sound of distinction — giving even the most demanding customers the
audio enjoyment they seek. Just listen to this!
Box Contents
• 2 Speakers
• Subwoofer
• User’s Guide
• Quick Connect Card (may be located on internal box flaps)
Placing Speakers
Subwoofer
All stereo-encoded information is heard through the satellite speakers. The
subwoofer contains no stereo imaging, and its sound is non-directional. As a
result, the subwoofer doesn’t have to be placed in any particular relationship
to the satellites. However, placing the subwoofer on the floor close to a wall
or room corner provides better bass efficiency and optimum sound.
Warning: The subwoofer is not magnetically shielded. As such, it SHOULD
be placed at least 2 feet (0.6m) from TVs, computer monitors, computer
hard drives or any other magnetic media (e.g. floppy disks, Zip disks,
computer or audio tapes, etc.).
Satellite Speakers
Arrange the satellite speakers to suit your listening tastes — from right next
to the monitor to as far apart as the speaker cords allow. Use the key hole
on the back of each speaker if you choose to mount them on the wall.
For optimum sound, satellite speakers should be placed at or slightly above
ear level, and in an arrangement that offers the most satisfying results.
Note: The satellite speakers ARE magnetically shielded and can be placed
close to video displays such as TVs and computer monitors without
distorting the image.
Making Connections
Warning: Do not insert the speaker system’s power plug into a wall outlet
until all connections are made. Also, turn off audio source (i.e., your PC,
MP3 player, Sony PlayStation, etc.) before connecting the outputs to the
speaker system’s inputs.
To ensure first-time operation as expected, please carefully follow the
connection sequences described below in the order indicated.
Speaker System
The satellites are connected together. To set-up the speaker system, insert
the orange DIN connector (hardwired into the right satellite) into the input
marked RIGHT SPEAKER on the rear of the subwoofer.
Notice that the DIN plug has an arrow. For easy insertion of the DIN
connector, the arrow on the connector must face up.
Inputs
Various connection schemes between your audio source and the speaker
system are available. Determine if you’ll be setting up the speaker system
for PC audio/PC gaming, DVD playback, console gaming or with portable
audio devices (such as MP3 or portable CD players), then skip to the
appropriate section.
PC Audio/PC Gaming/DVD Playback
All PC sound cards have audio outputs. Typically, the outputs will be marked
as “front output” and “rear output.” In some cases, slightly different
terminology may be used. The sound card’s documentation should help you
determine which outputs to use with your speaker system.
Connect the lime green 3.5mm stereo cable (hardwired into the right
satellite) to the lime green input labeled “FRONT” on your sound card.
Console Gaming
(Requires the Console Gaming Y-Adapter, which is not included but can be
purchased on our Web site at www.alteclansing.com)
Most console game systems feature dual-RCA outputs. To connect your
speakers, follow the steps below:
1. Make sure the power to your console gaming system is turned off.
2. The Console Gaming Y-Adapter has a lime green 3.5 mm stereo jack on
one end and two RCA jacks on the otheræone red and one white.
3. Connect the red and white RCA cable that came with your console gaming
system to the matching red and white RCA jacks on the Console Gaming
Y-Adapter.
4. Connect the lime green 3.5mm stereo cable (hardwired into the right
satellite) to the lime green input on the Console Gaming Y-Adapter.
Portable Audio Devices (MP3, Portable CD Players, etc.)
Connect the lime green 3.5mm stereo cable (hardwired into the right
satellite) to the headphone jack on your portable audio device.
Powering On
1. After all other connections are made, plug the AC power cord (on the
back of subwoofer) into a wall outlet. The speaker system is now ready to
operate.
2. Turn on the audio source.
3. Turn on the speaker system by turning the VOLUME knob on the right
satellite until you hear a click sound. An LED will light on the front of the
right satellite when the power is ON.
Note: To avoid hearing a popping sound when you turn on your Altec
Lansing speaker system, always turn on your audio source first.
Volume
The VOLUME knob on the right satellite controls the master volume. Turn
the knob clockwise to increase the volume and counterclockwise to
decrease the volume.
SFX Technology™
Sound Field Xpander™ technology allows your speaker system to deliver a
wider stereo image for bigger sound at the touch of a button. Press the SFX
button on the right satellite to turn it on. Press it again to turn it off.
Note: This feature does not work when using headphones.
Headphones
To use headphones with the system, plug them into the labeled jack
on the right satellite. When headphones are connected, the speaker system
is muted.
Three-Piece Powered
Audio System
VS2121
3
Sound Pressure Level (SPL): 97 dB
Total Continuous Power: 28 Watts RMS
• Front Speakers: 6 Watts/channel @ 4 ohms
@ 10% THD @ 180 – 18000 Hz
2 Channels Loaded
• Subwoofer: 16 Watts @ 8 ohms @ 10% THD
@ 50 – 180 Hz
Single Channel Loaded
System Response: 40 Hz – 20 kHz (-10 dB)
Signal to Noise Ratio
@ 1 kHz input: > 75 dB
Drivers (per satellite): One 2" full-range driver
Subwoofer: One 4" woofer
POWER REQUIREMENTS
USA, Canada and applicable
Latin American countries: 120 V AC @ 60 Hz
Europe, United Kingdom,
applicable Asian countries,
Argentina, Chile and Uruguay: 230 V AC @ 50 Hz
ETL/cETL/CE/NOM Approved
System Specifications*
No LEDs are lit.
No sound from
one or more
speakers.
Crackling sound
from speakers.
Power isn’t turned on.
AC power cord isn’t connected to the wall outlet.
Surge protector (if used) isn’t powered on.
Wall outlet not functioning.
Power isn’t turned on.
Volume is set too low.
3.5mm stereo cable isn’t connected to audio source.
3.5mm stereo cable is connected to wrong output on
audio source.
Problem with audio source device.
Bad connection.
Volume level in computer operating system is set
too high.
A problem with your audio source device.
Turn the VOLUME knob on the right speaker until you hear a click sound.
An LED will light next to the knob when the power is ON.
Check to see if the “Power On” LED is illuminated on the right satellite. If not,
connect AC power.
If the AC power cord is plugged into a surge protector, make sure the surge
protector is switched on.
Plug another device into the wall outlet (same jack) to verify the wall outlet
is working.
Verify the AC power cord is plugged into the wall outlet.
Turn the VOLUME knob on the right speaker until you hear a click sound.
An LED will light next to the knob when the power is ON.
Turn the VOLUME knob clockwise to raise the volume.
Check volume level on the computer sound card or alternate audio source
device, and set at mid-level.
Check plug connections on the audio source. Make sure the signal cables are
inserted firmly into the correct jacks.
Make sure the 3.5mm stereo cable is connected and fully inserted into the
“line-out,” “audio-out,” or the headphone jack of the audio source.
Test the speakers on another audio device. Remove the 3.5mm stereo cable
from the audio source device and connect it to “line-out,” “audio-out,” or the
headphone jack of another audio source.
Check all cables. Make sure they are connected to “line-out” or “audio-out”
jack on your sound card or other audio source — NOT “speaker-out.”
Check the computer operating system volume level and decrease it if necessary.
Unplug the stereo cable from the audio source. Then plug it into the
headphone jack of an alternate audio source (e.g., Walkman, Discman or
FM radio).
Troubleshooting
Symptom Possible Problem Solution
Altec Lansing’s superior sound comes from our patented Dynamic EQ technology,
which utilizes custom-built, high-fidelity drivers, state-of-the-art equalization circuitry,
and a harmonious mix of the following specifications:
*Power rating conforms to FTC Amplifier Rule #16 C.F.R. Part 432.
4
Sound is
distorted.
Radio
interference.
No sound from
subwoofer.
Low hum from
subwoofer.
Loud hum from
subwoofer.
Distorted monitor.
Volume level set too high.
Computer operating system volume level is set too high.
Sound source is distorted.
Too close to a radio tower.
Bad connection.
Sound source has little low-frequency content.
The AC in your house is at 60 cycles per second, which is
within the audio frequency of the subwoofer.
Bad connection.
Volume on your audio source device is set too high.
Subwoofer too close to monitor.
Turn the VOLUME knob counterclockwise to lower the volume.
Adjust the computer operating system volume and balance levels to the
center as a starting point, then adjust the level on the speaker using the
volume control.
WAV files are often of poor quality. So distortion and noise are easily noticed
with high-powered speakers. Try a different sound source such as a music CD.
Move your speakers until the interference goes away.
Check to make sure that all cables are connected properly and are making a
clear connection.
Many .WAV and .MID files often have little low-frequency content and sound
flat when you listen to them on a computer. Try a song with more bass —
something from your CD collection.
Some low hum may be detected when your speaker system is powered on
without an audio source playing, or when the volume is set at an extremely
low level.
Unplug the AC power cord from the surge protector (if used), and plug directly
into an AC wall outlet.
Move your cables. Check to ensure they are making a clear connection.
Disconnect your 3.5mm stereo cable from the audio source. If the loud hum
goes away, lower the volume on the audio source.
Lower the volume or bass level on your computer, portable device, etc.
Because the subwoofer is not magnetically shielded, it can cause distortion if
it’s too close to your monitor. Move the subwoofer so it’s at least 2 feet from
your monitor.
Symptom Possible Problem Solution
5
Le symbole figurant un éclair dans un triangle
équilatéral est destiné à attirer l’attention de l’utilisateur
sur la présence d’une “tension dangereuse” non isolée
pouvant être d’amplitude suffisante pour constituer un
risque d’électrocution.
Attention : Pour prévenir tout risque d’électrocution,
ne retirez pas le couvercle (ou le dos) de l’appareil. Il
ne se trouve à l’intérieur aucune pièce susceptible
d’être réparée par l’utilisateur. Confiez la réparation et
l’entretien à un personnel qualifié.
Le point d’exclamation à l’intérieur d’un triangle
équilatéral est destiné à prévenir l’utilisateur qu’il
trouvera d’importantes instructions concernant
l’utilisation et la maintenance (entretien) dans la
documentation jointe à l’appareil.
Consignes de sécurité importantes
1. Lisez les Instructions — Vous devez lire toutes les consignes de sécurité et le
manuel d’utilisation avant de faire fonctionner l’appareil.
2. Conservez les Instructions — Conservez le manuel d’utilisation pour pouvoir
vous y référer ultérieurement.
3. Tenez compte des Avertissements — Tous les avertissements figurant sur
l’appareil et dans les consignes d’utilisation doivent être respectés.
4. Suivez les Instructions — Le manuel d’utilisation et toutes les consignes
d’utilisation doivent être suivis.
5. Eau et Humidité — N’utilisez pas l’appareil près d’une source d’eau — par
exemple, près d’une baignoire, d’un lavabo, d’un évier, d’un bac
à laver, dans un sous-sol humide ou près d’une piscine, etc.
6. Utilisation à l’extérieur — Avertissement : Afin de limiter le risque d’incendie
ou d’électrocution, n’exposez pas cet appareil à la pluie ou
à l’humidité.
7. Emplacement — L’appareil doit être installé sur une surface stable.
8. Aération — L’appareil doit être placé de manière à ce que son emplacement
ou sa position n’entrave pas son aération correcte. Par exemple, l’appareil ne
doit pas être placé sur un lit, un canapé, un tapis ni sur une surface de type
similaire, qui pourrait bloquer les orifices d’aération ; ou placé dans une
installation encastrée, notamment dans une bibliothèque fermée ou une
armoire risquant d’empêcher la circulation de l’air à travers les orifices
d’aération.
9. Chaleur — L’appareil doit être tenu éloigné de toute source de chaleur et
notamment des radiateurs, des bouches d’air chaud, des réchauds ou des
autres appareils (y compris les amplificateurs) produisant de la chaleur.
10. Sources d’Alimentation — Brancher l’appareil uniquement à une source
d’alimentation du type mentionné dans le manuel d’utilisation ou indiqué
sur l’appareil lui-même.
11. Protection des Câbles d’alimentation — Veillez à ce que les câbles
d’alimentation ne se trouvent pas dans un lieu de passage ni bloqués par
d’autres objets. Veuillez prêter une attention toute particulière aux câbles
au niveau des fiches, des prises de courants et de l’endroit duquel ils sortent
de l’appareil.
12. Mise à la terre ou polarisation — Les précautions devant être prises pour que
les moyens de mise à la terre ou de polarisation d’un
appareil fonctionnent.
13. Nettoyage — L’appareil ne doit être nettoyé qu’à l’aide d’un chiffon à lustrer
ou d’un chiffon doux et sec. Ne le nettoyez jamais avec de la cire pour
meubles, du benzène, des insecticides ou d’autres liquides volatiles qui
pourraient attaquer le boîtier.
14. Périodes de non-utilisation — Le cordon d’alimentation de l’appareil doit
être débranché de la prise lorsque celui-ci n’est pas utilisé pendant une
longue période.
15. Orages — Débranchez l’appareil en cas d’orage.
16. Chutes d’objets et de liquide — Vous devez prendre garde à ne pas faire
tomber d’objets ou verser de liquide dans l’enveloppe de protection par les
ouvertures.
17. Accessoires — N’utilisez que les équipements/accessoires indiqués par Altec
Technologies, Inc.
18. Dommages nécessitant réparation — L’appareil doit être réparé par le
personnel qualifié lorsque :
• Le cordon d’alimentation ou la prise ont été endommagés.
• Des objets sont tombés ou du liquide a été renversé dans l’appareil.
• L’appareil a été exposé à la pluie.
• L’appareil ne semble pas fonctionner normalement ou donne des signes de
modification notoire de ses performances.
• L’appareil est tombé ou son boîtier a été endommagé.
19. Réparation — L’utilisateur ne doit pas tenter de réparer l’appareil. Les
réparations doivent être effectuées par le personnel qualifié, l’appareil doit
être retourné au distributeur ou vous devez appeler la ligne téléphonique
d’assistance Altec Lansing pour obtenir de l’aide.
Garantie limitée à un an
Altec Lansing Technologies, Inc. garantit à l’utilisateur final que tous ses systèmes
d’enceintes audio amplifiés, pour ordinateur, systèmes audio portables, pour TV
ou consoles de jeux sont exempts de défauts matériels ou de fabrication dans le
cadre d’une utilisation normale et raisonnable, et cela pour une durée d’un an à
compter de la date d’achat.
Cette garantie est exclusive et tient lieu de seule garantie en vigueur sur les
systèmes d’enceintes audio Altec Lansing amplifiés, pour PC, systèmes audio
portables, pour TV ou jeux. Aucune autre garantie, explicite ou implicite, n’est
valide. Ni Altec Lansing Technologies, Inc. ni aucun revendeur Altec agréé Lansing
Technologies, Inc. ne pourra être tenu responsable de dommages accidentels
provoqués par l’utilisation des enceintes. (Cette limitation des dommages
accidentels ou consécutifs n’est pas applicable là où la loi l’interdit).
Les obligations de Altec Lansing Technologies, Inc. liées à cette garantie ne
s’appliquent pas aux défauts, dysfonctionnements ou pannes résultant d’une
mauvaise utilisation, d’une utilisation abusive, d’une installation incorrecte, d’une
utilisation avec du matériel défectueux ou inapproprié ou d’une utilisation des
systèmes d’enceintes avec des équipements pour lesquels ils ne sont pas prévus.
Les conditions de la présente garantie s’appliquent uniquement si les systèmes
d’enceintes audio amplifiés, pour ordinateur, systèmes audio portables, pour TV
ou jeux sont retournés aux revendeurs Altec Lansing Technologies, Inc. agréés
auprès desquels ils ont été achetés.
Service clientèle
Vous trouverez les réponses à la plupart des questions concernant l’installation et
les performances dans le guide des Conseils de dépannage. Vous pouvez
également consulter les FAQ dans la section assistance clientèle de notre site
Internet à l’adresse www.alteclansing.com. Si vous ne trouvez toujours pas les
informations dont vous avez besoin, veuillez appeler par téléphone notre équipe
d’assistance clientèle pour obtenir de l’aide avant de retourner les enceintes à
votre détaillant, conformément aux conditions de retour.
1-800-ALTEC-88 (1-800-258-3288)
Email: csupport@alteclansing.com
Pour obtenir les informations les plus récentes, veuillez consulter notre site
Internet à l’adresse suivante www.alteclansing.com.
Distribution internationale
Clients internationaux : pour obtenir des informations concernant la vente de
produits Altec Lansing dans votre pays, veuillez visiter le site Internet
www.alteclansing.com et cliquer sur « International ».
ATTENTION
Pour éviter tout risque d’électrocution, n’utilisez pas cette fiche
(polarisée) avec une rallonge électrique, une prise de courant ou une
autre sortie, si les lames ne peuvent pas être insérées complètement,
afin d’éviter qu’elles ne soient exposées.
AVERTISSEMENT
AFIN DE LIMITER LE RISQUE D’INCENDIE OU D’ÉLECTROCUTION,
N’EXPOSEZ PAS CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ.
Connexion du câble d’alimentation (prise murale CA)
La fente longue
correspond au côté
neutre (terre).
Insérez la lame la plus
large dans la borne
côté terre.
Loading...
