Alphacool Mining Cube 300 User Manual

Version: 17.02.2020

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

What is it?

Alphacool Mining Cube 300

Highlights

When developing the Alphacool Mining Cube 300, the goal was to create a housing that is optimized to
cool as many graphics cards as possible with water. Thanks to the 7 mounting places for 420 mm radia­tors an outstanding cooling performance is guaranteed. Up to 9 graphics cards can be installed with optio­nally available riser boards or individual riser cards in the lower area.

- 3 x 420 mm Radiators pre-assembled

- 2 x Alphacool Eisfach pre-assembled reservoirs

- Up to 7 x 420 mm radiators possible

- 23 x 140 mm fan mountable

Version: 17.02.2020

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Technical Case

W x D x H 57,3 x 53,2 x 52,7 mm

Net weight 13,9 kg

Material case metal sheet

Mounting options fans 23 x 140 mm

Mounting options radiators 7 x 420 mm

Threads 2 x G1/4“ (Fill Ports)

Certificates CE, FC, ROHS

Scope of delivery

1pcs Cube 300 housing

3pcs 420 mm NexXxoS ST30 copper radiator

2pcs Eisfach reservoir with integrated DDC pump top

11pcs times 140 mm fan

Version: 17.02.2020

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Technical data radiators

W x D x H 458,5 x 144 x 30 mm

Max working temperature 60 °C

cooling fins copper

Material cooling channels copper

Material prechambers copper

Material outer housing steel

Fins per Inch 15

Threads 2 x G1/4“

Thread size Fan mounting M3

Fan size 140 mm

Fan slots 3 one sided / 6 both sided

Fan threads M3

Pressure tested 1,5 Bar

Certificates CE, FC, RoHS

Technical data fans

W x D x H 140 x 140 x 25 mm

Max. RPM 1300 rpm

Bearing Sleeve bearing

Connection 4-Pin WPM

Voltage range 5-12V

Power input 4,8 W

Version: 17.02.2020

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Other data

Article number Alphacool 18618

EAN Code 425019786186

PU Box 1

Dimensions PU B x T x H 61 x 58,5 x 57 cm,

Weight 13,9 kg

Customs code 84195080900

Product pics download

https://www.alphacool.com/
download/1015856_Alphacool_Mining_Cube_300.zip

Article text

The Alphacool Mining Cube offers a wide range of options for setting up a powerful water cooled system.
Whether as a workstation, render master or mining system, the Alphacool Mining Cube is very versatile
thanks to the extensive mounting options.

What fits into the Cube?

In addition to a mini or micro ATX motherboard, up to three ATX power supplies can be installed. The
mainboard is mounted on the upper level, while a drawer for mounting graphics cards can be found in the
lower area. On the bottom of the drawer there are extensive mounting holes for riser boards with PCIe
slots. Alternatively, up to 9 individual riser cards can be screwed together. A retaining bracket fixes the
graphic cards in the appropriate position so that nothing can slip during transport. For transport, grab
handles are attached to the top of the case.

Water Cooling?

Altogether there is the possibility to install up to seven 420 mm radiators. Alternatively, a total of up to
23 fans with a size of 140 mm can be mounted. Two fans sit on the front of the drawer and blow directly
onto the graphic cards. Inside, there are special mounting brackets for the Alphacool Eisfach. To facilitate
the filling of the water cooling, there is a filling nozzle on the top of the case. So that the air can escape
more easily during filling, a vent was inserted directly next to it. Both can be easily connected to the radi-

ators mounted in the lid.

Parts of the Water Cooling System Are Pre-Assembled!

The Mining Cube 300 has already pre-assembled individual components. Among them are three 420 mm
radiators with 9 pre-assembled 140 mm fans. Two more fans are mounted in the lower part at the rear.
The 140 mm fans can all be controlled by PWM with a maximum speed of 1300 rpm. There are also two
Eisfach reservoirs pre-mounted, each of which is prepared for the installation of a DDC pump. This gives
you a good basis for equipping the system with an extensive water-cooling system.

Manual PDF

None

Version: 17.02.2020

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

The Alphacool Mining Cube 300 is a unique product, which has not been available on the market in this
form before. The many mounting options for extremely powerful water cooling coupled with space for up

to 9 graphics cards is unique.
