Product Specification Sheet APS815 - Rev. 10/2013

1210/AL 10-Button Color Video Door Entry Station (Golmar)1210/AL 10-Button Color Video Door Entry Station (Golmar)

387 CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone] CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone]

Web: www.canalalarm.comWeb: www.canalalarm.com

Copyright © 1998-2 017 Alpha Communication s® - All Righ ts Reserved.

Due to c ontinuo us product i mprovement, all col ors, sizes, materials, finishes and sp ecifications are subject to change witho ut not ice.

1210/AL 10-Button Entry Video Station (Flush)1210/AL 10-Button Entry Video Station (Flush)

Architects' And Engineers' SpecificationsArchitects' And Engineers' Specifications

The 10-Button Entry Video stat ion(s) shall be
Alpha Communicat ions® / Golmar 1210/AL, or approved equal.
Stat ion(s) shall be flush mounted (or surfac e mount using optional
model 805/AL surfac e bac k box).

Stat ion(s) shall include 10- heavy-duty metal call butt ons with
assoc iated nameholder assembly. When used with t he EL531
module station(s) shall include a built- in hi-resolution color camera
with elec tronic iris and built-in infrared illuminators (for night
vision).

Stat ion(s) shall be made of 1.8mm thick anodized aluminum, and
shall feature a built- in information window for insertion of building
name, address or other information.

Contractor shall observe all local and national electrical and
building codes.

1210/AL 10-Button Entry Video Station1210/AL 10-Button Entry Video Station

The Alpha Communications® / Golmar 1210/AL 10 Button Entry
Video Stat ion is a c ompact, att ract ive lobby/entry stat ion to be
used with C OLOR or B&W type Platea, T ekna and/or Szena
apartment video Station units.

Made of 1.8mm thick anodized aluminum, the 1210/AL (when used
with the EL531 module) feat ures a built-in hi-resolution c olor
camera with electronic iris, infrared illuminators (for night vision).
The 1210/AL includes 10- heavy- duty met al c all pushbutton
switc hes and built-in nameholder display assemblies.

The 1210/AL can be used with the CE615 flush back box and
requires the EL531 (Color) or EL530 (B&W) camera and sound
module.

FeaturesFeatures

1 Heavy-duty metal call button with nameholder assembly
Rugged 1.8mm thick anodized aluminum
Built-in hi-resolution color camera with elect ronic iris
Built-in infrared illuminators (for night vision)
Can be Flush or Surface mounted - depending on t he
housing being used

SpecificationsSpecifications

Dimensions:

5.30"W (135mm)

9.00"H (229mm)

Flush Wall Opening:

4.92"W (125mm)

8.66"H (220mm)

2.25"D (58mm)

Surface Housing:

Model 805/AL. Use in addition to the

CE615 flush bac k box. OPTIONAL.

Rain Hood:

Model 705/AL. Use in addition to the

805/AL surfac e bac k box. OPTIONAL.
