Allview L5 Duo, L5 Easy User Guide

1

L5 Easy

User manual……….…………...2
Manual de utilizare.…………..20

Priručnik za korisnike….….….35

2

Allview L5 Easy
User Manual

FOR YOUR SAFETY

Read these simple guidelines. Not following them may be dangerous or illegal.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the device off near medical equipment. Do not use the device where

blasting is in progress.

Please keep this cell phone away from children, as they could mistake it for a toy, and hurt themselves

with it.

Don’t try to modify the phone except by the professional.
Warning!
Only use the authorized spare parts, otherwise it may damage the phone and the warranty will not work.

And it may be dangerous.

SWITCH OFF WHEN REFUELING

Don’t use the phone at a refueling point. Don’t use near fuel or chemicals.

SIM CARD AND T-FLASH CARD ARE PORTABLE

Pay attention to these small things to avoid children eating them.

3

Notice: The T-Flash Card can be used as a Memory Disk, the USB cable is necessary.

BATTERY

Please do not destroy or damage the battery, it can be dangerous and cause fire.
Please do not throw battery in fire, it will be dangerous
When battery cannot be used, put it in the special container.
Do not open the Battery.
If the battery or the charger is broken or old, please stop using them.

USE QUALITY EQUIPMENT

Use our authorized equipment or it will cause dangers

ROAD SAFETY COMES FIRST

Give full attention while driving; Pull off the road or park before using your phone if driving conditions so

require.

INTERFERENCE

All wireless devices may be susceptible to cause interference, which could affect performance.

SWITCH OFF IN AIRCRAFT

Wireless devices can cause interference in aircraft. It’s not only dangerous but also illegal to use mobile

phone in an aircraft.

Warning: We take no responsibility for situations where the phone is used other than as provided in the

manual.

Our company reserves the right to make changes in the content of the manual without making this public.

These changes will be posted on the company website to the product it amends.

4

The contents of this manual may be different from that in the product. In this last case will be considered.

GETTING STARTED

Battery Install Notice

Before you install or change battery, please ensure you already turn off the phone.

Install or change SIM card Notice

1. Before you change SIM card, please make sure you already turn off the phone and dispose battery.

2. Insert the SIM card and make the golden contact area face down and the nick face out.

Charge the battery

1. Before charging the battery, please make sure that the battery is installed properly in the phone.

2. Connect the charger lead to the phone socket, and then connect the charger to the AC socket.

3. If the phone is off when it’s charging, charging indicator is displayed on the screen. If the phone is on

when it’s charging, user can use it while charging. When the battery is fully charged, the charging indicator

on the screen is full and stops twinkling. While using the handset for the first time, please completely
discharge and then completely charge the battery. Repeat the process for three times to achieve the full
performance of the battery.

4. Long period unused or some other reasons may cause low battery pressure, so at the beginning of

charging the screen is black and it may take a while before the charging indicator appears.

5

Warning: When charging, in order to avoid serious damage to phone circuitry, do not remove or dispose

the battery.

CALLS

Key Explanation

Lock Keypad: Press End key then select “Yes”

Unlock Keypad: Press Navigation key then there are 3 choices, press Up key just unlock keypad, press
Left key unlock keypad and enter dialer function, press Right key unlock keypad and enter messaging
function.

* Key # Key:

Functions vary in different situations or function menus:

- In inputting status, “*” for symbols.

- In inputting status, “#” to switch inputting methods.

- In standby mode, hold “#” to switch the phone in silent mode.

- In standby and dial mode, press and hold “*”, you can input +, P and W.

- In standby mode, input “+” for an international call; in dial status, input “P” for calling number with

extension phone.

Main Menu Explanation

When you press Menu key, you will enter main menu. Press up, down, left and right keys to select
different functions.

6

Make a Call

Making a call by dialing numbers:

1. In standby mode, enter the phone number. If you want to change the numbers, press left and right
direction key to move the cursor and press〈Clear〉to delete a number. Press and hold 〈Clear〉to delete
all characters.

2. Press the call key to call the number.

Making a call using the Phonebook:
You can enter the phonebook list from functional menu, choose or input the needed letter (phonetic) to

search. Choose the number; press the call key to dial out.

Call the Dialled calls, Received calls, Missed calls:

1. In standby mode, press the call key to view the call log list.

2. Choose a number and press the call key to dial.

Making a call using the menu:

1. In standby mode, enter the menu, choose Call logs;

2. Choose from missed calls, dialled calls, and received calls.

3. Choose the needed number and press the call key to make a call.

Answer an Incoming Call

Press the Call key to answer an incoming call.

Call Options

Offer numerous in call functions (some of these functions need a subscription with the service provider).

During the call, press->Option and choose between the following options :

Hold: Pause the call.
End single call: End the present call.

7

New call: To make a new call.
Phonebook: Same as phonebook list in the function menu.
Call history: Same as call history in the function menu.
Messaging: To explore the Messaging Menu.
Sound recorder: Record the sound.
Mute: Enable the mic of phone not work.
DTMF (Dual-tone Multi-frequency): You can choose on/off, which is to send dual-tone multi-frequency

sound, this can offer dialing to the telephone numbers with extensions.

Volume: To adjust the volume of the call.

INPUT METHOD

Overview
Your phone offers input methods as followings: Smart abc, es, ro.
Keypad Definition
The definition of keypad is as follow:
Left key: Enter and OK
Right key: Back and Cancel
Navigate Keys: Cursor move or choose word.
# Key: Switch input methods and a sign will be display in left side.
2-9 key: Input the letter on the keys when input.
* Key: Input punctuation

8

FUNCTION LIST

Phonebook

You can save the contacts in the mobile phone and SIM card; it depends on the SIM card memory

capacity. When you select a contact, you can do the following operations:

View: To view the contact
Send text message: Send text message to the current number.
Send multimedia message: Send multimedia message to the current number.
Call: To Call the current number.
Edit: To edit the current contact.
Delete: To delete the current contact.
Copy: To copy the contact from phone to SIM card /phone or from SIM card to SIM card /phone or copy

to file.

Move: To move the contact from phone to SIM card /phone or from SIM card to SIM card /phone or copy

to file.

Send business card: You can send contact by different methods.
Add to Blacklist: Add the current number to the blacklist.
Add to Whitelist: Add the current number to the white list.
Mark several: You can mark several contacts.
Backup and Restore: To backup or restore PHB and Vcard.
Phonebook settings: To set the Phonebook.

9

Call logs

In this function menu, you can check the All calls, Dialled calls, Received calls, Missed calls, and You

can perform the following operations:

View: To check the call history.
Call: To call the Dialled calls, Received calls or Missed calls.
Send text message: Send SMS to the Dialled calls, Received calls or Missed calls.
Send multimedia message: Send MMS to the Dialled calls, Received calls or Missed calls.
Save to Phonebook: You can add the number to the phonebook or replace existing contacts.
Add to Blacklist: Add the number of the Dialled calls, Received calls or Missed calls to the Blacklist.
Add to Whitelist: Add the number of the Dialled calls, Received calls or Missed calls to the Whitelist.
Edit before call: Edit the number before you call
Delete: Delete the current call history.
Delete all: Delete all the call history.
Mark several: You can mark several call history.
Advanced: Including three options: Call timers/Call cost/GPRS counter.

File manager

Press left key option to enter functional menu, the following options are available:

- Open: See the files in the different folders of your phone

- Format: To format the folder.

- Details: To view the Memory status of the Memory card.

Camcorder

The built-in camera allows you to take photos and adjust the camera settings. The options menu

10

contains the following choices:

 EV: Set EV value.
 Switch to: Switch phone to photo album or video recorder.
 Capture mode: Set capture mode.
 Scene mode: To set the scenario mode of the camera.
 Image size: Set the image size.
 Self-timer: Set self-timer value.
 White balance: To adjust the white balance (E.g. Daylight, Auto etc.).
 Effects: Select the effect kind.
 Adv. Settings: Select to open many advantage setting items.

Image Viewer
The options for image viewer are as follows:

 View: To view a photo.
 Image information: You can view the image information.
 Browse style: To select the mode for browsing photos.
 Send: Transform the photos by different ways, such as multimedia message or via Bluetooth.
 Use as: This photo can be used as wallpaper.
 Rename: To rename the selected image or photo.
 Delete: To delete the selected photo.
 Sort by: To sort photos by the desired method.
 Storage: Allows you to set the location of the photos.

Audio Player

This phone comes with an inbuilt audio player that plays all your favorite songs. It gives you a host of

11

setting options to make your listening experience interesting.

1. Play: To start playing the audio file.

2. Details: To show the details of the selected file.

3. Refresh list: To refresh the audio file list.

4. Settings: To set parameters for audio playing.

Video Player
The Video Player plays all your video files stored in the phone (Phone Memory or on the Memory Card).

The video player gives you the following options:

1. Play: To start playing the video file.

2. Send: Send the video via Bluetooth or MMS.

3. Rename: To rename the video.

4. Delete: To delete the video.

5. Sort by: To sort videos by the desired method.

6. Storage: Allow you to set the location of the videos.

Sound Recorder
You can record sound/voice on your phone. Just select sound recorder, go to options and press “New

record”. Select Stop to save it. Select pause to ‘pause’ the recording and ‘continue’ to resume the recording.

FM Radio

 Channel list: List out all the current channels. You can enter channel list, edit it and display the

searched channel list.

 Manual input : Input the desired broadcasting channel manually
 Auto Search: Search and create the channel’s list automatically.
 Settings: To set some parameters of FM.

12

 Record: To record the current program being played on the radio.
 File list: To view the list of recorded files.

Messaging

Your phone supports various messaging services. You can create, send, receive, edit and organize

text/multimedia messages.

Messages contain the following folders:
 Write Message: On selecting Write Message, you can input the contents of the message using

different input methods.

 Conversations: All the received and sent messages stored in conversations.
 Drafts: You can save a message you edit in the drafts.
 Broadcast messages: Broadcast message is a service provided by the network operator to send

messages such as weather forecast, traffic status, etc. to all GSM subscribers in a specific area.

 Templates: Templates stores 10 preloaded/pre-written text messages for ready usage.
 Message Settings: Message settings store all the different settings responsible for sending and

receiving messages.

Browser

The following options are available in the Browser menu:

a. Homepage: Start a connection to the selected URL set.
b. Bookmarks: Access or edit a bookmark.
c. Search or input URL: Enter the address.
d. Recent pages: Browse a saved URL.
e. Settings: Set parameters of WAP browser. Please consult your network operator for details of the

parameters

13

Bluetooth

The following options are available in the Bluetooth menu:

1. Power: On/Off

2. Visibility: On/Off

3. My device: Inquiry new device or display paired devices and take the options.

4. Search audio device: Search for audio devices.

5. My name :You can change the name of the Bluetooth.

6. Advanced :Configure the settings of Bluetooth, For example, Audio path, storage etc.

Calendar

You can use the calendar to keep track of important meetings. After entering the calendar function menu

you can select year, month and date using direction keys. On a selected date you can select to view:

 View :To view and set the schedule of a day.
 View all: To view the schedule of all day.
 Add event: You can add several events to the date.
 Delete event: You can delete All /overdue/Specific period event.
 Jump to date: To input the date to enter the calendar, then move the cursor to the specified date.
 Go to today: Go to check today.
 Go to weekly view: Go to view the calendar events in weekly style.
 Start of week: You can select from Sunday or Monday.

Alarm

The Alarm can be set to ring at a specific time on several days. There are five different default alarms.

You can set these alarms to alarm you at different time in specific day(s) of a week.

14

To set an alarm:

1. Press edit to enter alarm settings menu.

2. Select edit option using up and down direction keys

o ON/OFF: Select alarm on or off using left and right direction key
o Alarm time: Input alarm time
o Repeat Setting: Press navigation keys to select alarm types which consists of one time, everyday

and custom.

o Alarm tone: You can select the alarm tone.
o Alert Type: To select between Ring only/Vib and ring, Vib only.

Settings

Under settings, the phone gives you the option to change the settings for various features of the phone.
The following list is available in Settings:

Phone Settings

You have following options listed under phone setup:

Time and date: Let you set the Time and date on the phone.
Schedule power on/off: Set scheduled power on/off time.
Language: To select language for the phone.
International keyboards: This enables you to set international keyboards.
Font Size: Set title and list font size.
Widget manager: Manager your widgets.
Shortcut manager: Manager your shortcuts.
Encoding: Select encoding kind.

15

Display: Under Display setup, you can set wallpaper, menu page transition, lock screen image,

screen auto lock and google search hint.

Auto update time: You can select off / first confirm / on.
Flight mode: You can select normal mode or flight mode.
UART settings: You can select UART 1 or UART 2.
Misc. settings: Set LCD backlight.
Network Settings

Network setup gives the user the ability to select a desired network and addition of a new network to the

network list. The network setup gives you the follow options:

SIM1/2 network settings:

1. Network Selection (Automatic)

2. Preferences: Will list down all the network IDs (depending on the SIM card used)

GPRS transfer pref.:

Including two options: Data prefer and Call prefer.

Security Settings

Under Security Setup, you can change the security settings of SIM1 or SIM2.

SIM1/2 Security Settings:

o PIN Lock: PIN Lock protects illegal usage of the SIM card.
o Change PIN: You can change the PIN password.
o Change PIN2: You can change the PIN2 password

Phone security: Enables you to lock/unlock your phone with a password.
Connectivity

Choose the phone networks.

16

Notification settings

Set notification service on / off. You can also set notification of messaging, call logs and downloads.

Call Settings

Include SIM1 call settings, SIM2 call settings and advanced settings.

Restore Factory Settings

Selecting this option will ask you to enter the password to restore the phone to factory settings. The

default password is ‘1122’.

WARNINGS AND NOTES

Operational Warnings

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. Read this information before

using your phone. For the safe and efficient operation of your phone, observe these guidelines:

Potentially explosive at atmospheres: Turn off your phone when you are in any areas with a
potentially explosive atmosphere, such as fueling areas (gas or petrol stations, below deck on boats),
storage facilities for fuel or chemicals, blasting areas and areas near electrical blasting caps, and areas
where there are chemicals or particles (Such as metal powders, grains, and dust) in the air.

Interference to medical and personal Electronic Devices: Most but not all electronic equipment is
shielded from RF signals and certain electronic equipment may not be shielded against the RF signals from
your phone.

Audio Safety: This phone is capable of producing loud noises which may damage your hearing. When
using the speaker phone feature, it is recommended that you place your phone at a safe distance from your
ear.

17

Other Media Devices, hospitals: If you use any other personal medical device, consult the
manufacture of your device to determine if it is adequately shielded from external RF energy. Your physician
may be able to assist you in obtaining this information. Turn your phone OFF in health care facilities when
any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using
equipment that could be sensitive to external RF energy.

Product statement on handling and use: You alone are responsible for how you use your phone and
any consequences of its use.

You must always switch off your phone wherever the use of a phone is prohibited. Use of your phone is
subject to safety measures designed to protect users and their environment.

Always treat your phone and its accessories with care and keep it in a clean and dust-free place

Do not expose your phone or its accessories to open flames or lit tobacco products.

Do not expose your phone or its accessories to liquid, moisture, or high humidity.

Do not drop, throw, or try to bend your phone or its accessories

Do not use harsh chemicals, cleaning solvents, or aerosols to clean the device or its accessories.

Do not attempt to disassemble your phone or its accessories; only authorized personnel must do so.

Do not expose your phone or its accessories to extreme temperatures, minimum 32 and maximum 113
F degrees (0 to 45 C degrees).

Battery: Your phone includes an internal lithium-ion or lithium-ion polymer battery. Please note that use
of certain data applications can result in heavy battery use and may require frequent battery charging. Any
disposal of the phone or battery must comply with laws and regulations pertaining to lithium-ion or lithium­ion polymer batteries.

Faulty and damaged products: Do not attempt to disassemble the phone or its accessory. Only
qualified personnel must service or repair the phone or its accessory. If your phone or its accessory has

18

been submerged in water, Punctured, or subjected to a severe fall, do not use it until you have taken it to be
checked at an authorized service center.

DECLARATION OF CONFORMITY

NO.1337-25.11.2014
We, SC VISUAL FAN SRL, importer located in Brasov, 61 Brazilor STR., registered at the Commerce
Chamber Brasov no. J08/818/2002, CUI 14724950, assures, guarantee and declare on our own
responsibility, in accordance with art.4 from HG nr. 1.022/2002 regarding the statute of the products and
services that can jeopardize life, health, work security and environmental protection, that: The product L5
Easy– mobile phone ALLVIEW brand - and the accessories that came with the product: 220V charger,

headphones and battery don’t jeopardize life, health, work security and environmental protection and they

are according to:

-Directive. 2011/65/EU regarding the restriction of use of certain substances
in electrical and electronic equipment.

- The Stipulations of HG nr.982/2007 witch transpose the essential requirements specified in Direction
2004/108/CE, regarding electromagnetically compatibility;

- The Direction regarding the low voltage equipment users assurance 73/32/CEE, modified by Direction
93/68/CEE (HG 457/2003) and tests EN 55013:2001+A1:2003+A2:2006, EN 55020:2007, EN 610000-3­2:2006, EN 61000-3-3:1995+A1:2001+A2:2005;

- The Direction regarding the radio and telecommunication equipments R&TTE 1999/5/CE (HG 88/303).
