The ME Personal Mixing System puts the musician in control of their own
monitor mix. Each performer can be given a tailored setup that works
perfectly for them, whether they crave maximum control over the fine
details of their mix or just want the minimum of keys to press. Operation
is intuitive and elegant, with simple controls and clear visual feedback for
instant familiarity. The system has earned respect for rugged reliability
on the road, and of course it lives up to Allen & Heath’s reputation for
ME personal mixers are used by touring bands, orchestras, houses of worship, recording studios, musical theatre shows, broadcasters
and more. With ME everyone benefits from quicker setups, slicker
soundchecks and lower sound levels on stage, while the audio engineer
is freed up to focus on the front of house sound or key performers. Both ME-500 and ME-1 personal mixers are plug ‘n’ play compatible with our
own digital mixers, and users of many other consoles can also enjoy the
benefits thanks to the ME-U hub.
ALLEN&HEATH
ME-1
40 Source Personal Mixer
ME-1 is probably the most sophisticated personal mixer on the market, giving precision control over up to 40 channels to satisfy the most demanding ears.
16 backlit keys
Each key is assignable to a single mono or stereo source (e.g. bass guitar) or to a group of sources (e.g. the whole drumkit).
16 user presets
Levels, pan, mutes and key assignments can all be stored and recalled at the touch of a button. Presets can also be stored to USB and recalled on any ME-1 unit.
Groups
Sources can be grouped within the ME-1, so each performer can use different groups without consuming buses on the main console.
Custom Naming
ME-1 can display custom names for all channels and groups. ME-1s connected to a dLive or SQ mixer automatically pick up names from the console.
Built-in ambient mic
The ambient mic keeps performers in touch with the stage sound and lets them hear the audience and communicate with each other without needing to pull out their ear pieces.
• 40 Inputs with level and pan control
• Dimmable OLED screen
• 16 Assignable keys
• 3.5mm and 1/4” headphone outputs
• Master 3 band EQ and Limiter
• Solo and Mute keys
• Aux Input for MP3 players, click tracks etc
• Built-in signal generator
• Mic stand bracket and headphone hanger included
• Mains or PoE powered
• Daisy chain or use standard PoE Ethernet hubs
ME-U
10 Port PoE Monitor Hub
ME-U is a touring grade, 10 port PoE hub providing power and audio to multiple ME-1 and/or ME-500 personal mixers. ME-U’s default input card allows seamless integration with Allen & Heath dLive, SQ and Qu mixers. Fitting a Dante or MADI option
• 10 ports with locking Ethercon connectors
• Each port provides power + audio to a ME-1 or ME-500
• Link 2 hubs for more ports
• Touring grade build quality
• 2U rack or desk mounting
• Connected ME-1s automatically pick up channel names from SQ or dLive mixers
• Connect PC/Mac for setup of unit name and IP address, and manual entry of channel names
card to the ME-U allows users of other pro digital mixer brands to feed up to 40 sources to ME-1s, or up to 16 sources to ME-500s.
When to use ME-U
If you’re using Allen & Heath digital consoles, ME-U gives you the option to take your ME system to the next level of professionalism, eliminating the clutter of separate power supplies for each directly connected ME-1 or ME-500 unit and providing a high quality, road-proven alternative to standard PoE hubs. If you’re using other console brands, ME-U is your gateway to the ME system, with MADI, Dante and Waves SG option cards allowing a digital feed of up to 40 sources from third party systems.
ME-500
16 Channel Personal Mixer
ME-500 is a powerful walk-up-and-mix solution that’s quick to set up and easy for just about anyone to learn in moments. The ME-500 personal mixer’s intuitive hands-on controls and crisp visual
Fast Setup
With ME-500 there’s no time­consuming configuration of individual units. The first 16 mono / stereo channels and / or mixes assigned from the mixer will be automatically mapped to ME­500’s 16 select keys, so it’s fast and simple to deploy personal mixers in pressured situations such as festivals.
8 user presets
Levels, pan, mutes and key assignments can all be stored and recalled at the touch of a button. Presets can be saved to USB and easily transferred to different ME-500s.
display make it easy for musicians to quickly build and control their own monitor mixes. With plug ‘n’ play setup and self-sufficient musicians, ME-500 is also a massive time-saver for the audio engineer.
Which ME is right for ME?
Although superficially similar, ME-1 and ME-500 are quite different solutions for different types of users and scenarios. For resident artists (such as a broadcast house band or church praise band), shows with high channel counts and plenty of rehearsal time, ME-1 allows the engineer to configure each unit to perfectly reflect each artist’s tastes and needs. For budget­conscious or low channel count applications, or for more impromptu scenarios where the engineer and artists have very limited soundcheck time (festivals being the typical example), ME-500 is a great solution for getting the show up and running with minimum fuss.
• 16 Mono / stereo inputs with level and pan control
• Master 2 band EQ and Limiter
• Automatic key assignment
• 8 User presets
• 3.5mm and 1/4” headphone outputs
• Solo and Mute keys
• Mains or PoE powered
• Daisy chain or use standard PoE Ethernet hubs
• Mic stand bracket + headphone hanger sold separately
System Examples
ME-1 and ME-500 mixers can be directly connected to any available ME, SLink, dSnake or Monitor port in an Allen & Heath digital mixing system.
Multiple ME-1 and ME-500 mixers can be daisy-chained with all mixers powered via external PSU.
The ME-U hub can be connected to any available ME, SLink, dSnake or Monitor port in an Allen & Heath digital mixing system.
ME-1 and ME-500 mixers connected directly to the ME-U are powered via PoE. Additional ME-1 and ME-500 mixers can be daisy-chained and powered via external PSU.
Multiple ME-U hubs can be daisy-chained together if more than 10 ports are required.
The ME-U hub can be fitted with a Dante or MADI option card enabling the connection of 3rd party digital mixing systems.
ME-1 and ME-500 mixers connected directly to the ME-U are powered via PoE. Additional ME-1 and ME-500 mixers can be daisy-chained and powered via external PSU.
Multiple ME-U hubs can be daisy-chained together if more than 10 ports are required.
ME 3rd Party Options
DiGiCo and ME
The DMI-ME option card enables selected DiGiCo consoles to send up to 40 channels to a ME system. See the DiGiCo website for more details.
ME + AVIOM® A-16ii
ME-1 and ME-500 can be used as drop-in replacements for older AVIOM® A-16ii units.
Technical Specifications
ME-1
Frequency Response AD/DA Conversion Residual Output Noise PoE Requirements Headphone Out
Mono Out Aux Input External PSU PoE Requirement
Dimensions and Weights ME-1 Boxed ME-1
ME-500
Frequency Response AD/DA Conversion Residual Output Noise PoE Requirements Headphone Out
External PSU PoE Requirement
10Hz to 20kHz (+0/-1dB) 24-bit Delta/Sigma, 48kHz
-95dBu
802.3af (15.4W at source) or 802.at (25.5W at source)
300mW + 300mW into 100Ω load
Max: +21dBu Nom 0dBu / Max +18dBu
Nom -8dBu / Max +10dBu / Impedance >10kΩ
IN: 100-240V AC , 50/60Hz / OUT: 12V DC, 1.25A 10W (requires 15W from PoE hub)
Width x Depth x Height x Weight 230 x 160 x 70 mm (9” x 6.3” x 2.7”) x 1.1kg (2.4lbs) 290 x 350 x 170 mm (11.4” x 13.8” x 6.7”) x 2.5kg (5.5lbs)
10Hz to 20kHz (+0/-1dB) 24-bit Delta/Sigma, 48kHz
-95dBu
802.3af (15.4W at source) or 802.at (25.5W at source)
300mW + 300mW into 100Ω load
Max: +21dBu IN: 100-240V AC , 50/60Hz / OUT: 12V DC , 1.25A 10W (requires 15W from PoE hub)
Dimensions and Weights ME-500 Boxed ME-500
Width x Depth x Height x Weight 230 x 160 x 70 mm (9” x 6.3” x 2.7”) x 1.1kg (2.4lbs) 290 x 350 x 170 mm (11.4” x 13.8” x 6.7”) x 2.5kg (5.5lbs)
ALLEN&HEATH
www.allen-heath.com
Allen & Heath reserves the right to alter any information supplied in this document or any other document supplied hereafter.
AP9085_2
