VHF FM Transceiver
UHF FM Transceiver
Instruction Manual
Thank you for purchasing your new Alinco transceiver. Please read this manual
care fully befo re using the prod uct to ensur e ful l performa nce, and keep thi s
manual for future reference as it contains information on after-sales service.
In case addendum or errata sheets are included with this product, please read
those materials and keep them together with this instruction manual for future
reference.
Introduction
Thank you very much for purchasing this excellent Alinco transceiver. Our products are ranked among the
nest in the world. This radio has been manufactured with state of the art technology and it has been tested
carefully at our factory. It is designed to operate to your satisfaction for many years under normal use.
Please read this manual completely from the rst page to the last, to learn all the functions the
product offers. It is important to note that some of the operations may be explained in relation
to information in previous chapters. By reading just one part of the manual, you may risk not
understanding the complete explanation of the function.
Before transmitting
There are many radio stations operating in the frequency ranges this product covers. Be careful not to
cause interference when transmitting around such radio stations.
■
Lightning
Any person is not safe outdoor during thunderstorm and lightning. This condition is getting worse if
somebody keeps a hand-held radio; chances of being hit by lightning are doubled since lightning may
hit a radio antenna as well. At this time, there is no hand-held radio having any kind of protection against
lightning current (which is higher than10 kA.). Note also that no car provides adequate protection of its
passengers or drivers against lightning as well. Therefore, Alinco will not take responsibility for any danger
associated with using its hand-held radios outdoor or inside the car during lightning.
■
About IP54 rating / Dust and splash resistant
About IP54 rating
5: Dust protected /Ingress of dust is not entirely prevented, but it must not enter in sufcient quantity to
interfere with the satisfactory operation of the equipment; complete protection against contact.
4: Splashing water / Water splashing against the enclosure from any direction shall have no harmful effect.
Test duration: 5 minutes / Water volume: 10 litters per minute /Pressure: 80~100 kN/m²
The IP54 designation provides for limited dust and splash proong of the radio per specied above. This
compatibility is factory guaranteed for a period of one year provided all the jack covers are securely in
place, any accessories connected must be specied genuine Alinco accessories and the radio has not
been disassembled by the customer. The factory has tested and made the equipment compatible to IP54
certication during engineering. However, please understand that this equipment is NOT certied IP54
compliant but is designed to remain operational when used in hard conditions and is in no way stating
that you should attempt to wash the radio for cleaning. Warranty will not cover radios that are water/dust
damage due to negligence or misuse of the product.
The warranty period of dust and splash resistance is the same as the period of the product warranty.
■
Covering ranges
You may expect a range of approx.3km/2 miles or more at high-power when located on a at, noise-free
place like on a beach.However,it may vary drastically depending on how to wear and carry the radios,
surrounding locations/conditions and static noise levels (below or near power transmission lines), etc. In
urban areas with many buildings or inside a building, such covering range will become drastically short
even to several tens of meters.
Features
■ Output power selectable 5W/2W/0.5W
■ 128 PC-programmable channels (16ch x 8groups)
■ Li-Ion battery pack and stand-charger as standard accessories
■ Voice Compander (Reduce Noise & enhance audio clarity)
■ Inversion Scramble(Analog encryption)
■ Sub-tone (CTCSS/DCS) Encode/Decode and DTMF
■ VOX built-in
Conformity Symbols
Tested to comply MIL-STD-810G
-Shock: Method 514.6/I,IV -Vibration: Method 516.6/I
SAFETY TRAINING INFORMATION
Warning: Please Read Carefully
DO NOT operate the transceiver without a proper antenna attached, as it may damage the transceiver
•
and may also cause you to exceed FCC RF exposure limits. A proper antenna is the genuine antenna
supplied with this transceiver by Alinco or ones specically authorized by the antenna manufacturer for
use with this transceiver.
ALWAYS keep the antenna at least 3 cm (1 inch) away from your body when transmitting and only use
•
the original belt clips when attaching the transceiver to your body (Unauthorized attachment devices may
help radiating more electromagnetic energy). To obtain the best sound quality during communications,
hold the antenna at least 6 cm (2 inches) from your mouth, and slightly off to one side.
Use only the genuine Alinco accessories listed in this instruction manual for RF safety. Third party
•
accessories are not guaranteed for RF safety by Alinco.
Electromagnetic Interference/Compatibility
•
During transmissions, a transceiver generates RF energy that can possibly cause interference with other
devices and/or systems.
To avoid such interference, turn off the transceiver in areas where signs are posted to do so. NEVER
operate transceivers in areas that are sensitive to electromagnetic radiation such as hospitals, blasting
sites, aboard aircraft and similar advanced vehicles etc. Do not expose magnetic cards such as credit
cards in a very close vicinity to a transceiver; it may erase the magnetic data. A person using medical
devices such as a pacemaker MUST NOT use this transceiver, as interference may cause malfunction to
such medical devices.
Occupational/Controlled Use
•
This product is used in situations that users are exposed to RF as consequence of their employment
provided those users are fully aware of the potential RF hazards and can exercise control over their
exposure.
This transceiver is NOT ATEX approved and NOT intended for the use in hazardous explosive
•
atmospheres.
Alert
Environment and condition of use
Use of this product may be prohibited or illegal outside of your country. Be informed in advance when you
travel.
It is recommended that you check local trafc regulations regarding the use of a radio equipment while
driving. Some countries prohibit or apply restrictions for the operation of radios and mobile- phones while
driving.
Do not use this product in close proximity to other electronic devices, especially medical ones. It may
cause interference to those devices.
Keep the radio out of the reach of children.
In case a liquid leaks from the product, do not touch it. It may damage your skin. Rinse with plenty of cold
water if the liquid contacted your skin.
Never operate this product in facilities where radio products are prohibited for use such as aboard aircraft,
in airports, in ports, within or near the operating area of business wireless stations or their relay stations.
The manufacturer declines any responsibilities against loss of life and/or a property due to a failure of this
product when used to perform important tasks like life-guarding, surveillance, and rescue.
Do not use multiple radios in very close proximity. It may cause interference and/or damage to the
product(s).
Risk of explosion if battery is replaced with an incorrect type. Dispose of, or recycle used batteries
according to your local regulations.
The manufacturer declines any responsibilities against loss of life and property due to a failure of this product
when used with or as a part of a device made by third parties.
Use of third party accessory may result in damage to this product. It will void our warranty for repair.
Handling this product
Be sure to reduce the audio output level to minimum before using an earphone or a headset. Excessive
audio may damage hearing.
Do not open the unit without permission or instruction from the manufacturer. Unauthorized modication or
repair may result in electric shock, re and/or malfunction and voids warranty.
Do not operate this product in a wet place such as in a shower room. It may result in electric shock, re and/
or malfunction, This product is splash-proof but not a complete water-proof.
Do not place the product in a container carrying conductive materials, such as water or metal in close
proximity. A short-circuit to the product may result in electric shock, re and/or malfunction.
About chargers
Do not use adapters other than having the specified voltage. It may result in electric shock, fire and/or
malfunction,Never turn on the radio while charging.
Do not plug multiple devices using an adapter into a single wall outlet. It may result in overheating and/or re.
Do not handle adapter with a wet hand. It may result in electric shock.
Securely plug the adapter into the wall outlet. Insecure installation may result in short-circuit, electronic shock
and/or re.
Do not use the adapter if the plug or socket contacts are dirty. Overheating and/or short-circuiting may result
in re, electric shock and/or damage to the product.
In case of emergency
In case of the following situation(s), please turn off the product, switch off the source of power,
then remove or unplug the power-cord. Please contact your local dealer of this product for service
and assistance. Do not use the product until the trouble is resolved. Do not try to troubleshoot the
problem by yourself.
When a strange sound, smoke and/or strange odor comes out of the product. ●
When the product is dropped or the case is broken or cracked. ●
When a liquid penetrated inside. ●
When a power cord (including DC cables, AC cables and adapters) is damaged ●
For your safety, turn off then remove all related AC lines to the product and its accessories from the wall outlet
if a thunderstorm is likely.
Maintenance
Do not open the unit and its accessories. Please consult with your local dealer of this product for service and
assistance
Alert
Environment and condition of use
Do not use the product in proximity to a TV or a radio. It may cause interference or receive interference.
Do not install in a humid, dusty or insufciently ventilated place. It may result in electric shock, re and/or
malfunction.
Do not install in an unstable or vibrating position. It may result in electric shock, re and/or malfunction when/
if the product falls to the ground.
Do not install the product in proximity to a source of heat and humidity such as a heater or a stove. Avoid
placing the unit in direct sunlight.
Be cautious of a dew formation. Please completely dry the product before use when it happens.
About transceiver
Be cautious of the whip antenna when carried in your shirt-pocket etc. It may make contact with your eye and
cause injury.
Do not connect devices other than specified ones to the jacks and ports on the product. It may result in
damage to the devices.
Turn off and remove the power source (AC cable, DC cable, battery, cigar cable, charger adapter etc.) from
the product when the product is not in use for extended period of time or in case of maintenance.
Never pull the cord alone when you unplug AC cable form the wall outlet.
Use a clean, dry cloth to wipe off dirt and condensation from the surface of the product. Never use thinner or
benzene for cleaning.
Check with your local waste ofcials for details on recycling or proper disposal of the electronics product,
battery-packs and accessories in your area.
PC PROGRAMMING
NOTE: The utility software may be available to distributors/dealers only. USB programming cable is required. The
manufacturer will not release the software to unauthorized party so please contact your dealer for details.
CONTENTS
STANDARD ACCESSORIES/OPTIONAL ACCESSORIES ............................................... 1
Standard Accessories .........................................................................................................................1
BATTERY INFORMATION .................................................................................................. 2
Charging Operation .............................................................................................................................2
Battery Charger Type ..........................................................................................................................2
Notice for Charging Battery .................................................................................................................2
How to Charge .................................................................................................................................... 4
How to Store the Battery .....................................................................................................................6
PREPARATION ................................................................................................................... 7
Installing / Removing the Battery ........................................................................................................7
Installing / Removing the Antenna ......................................................................................................7
Installing / Removing the Belt Clip ......................................................................................................8
Accessories ........................................................................................................................................8
Installing/ Removing the Hand Strap ..................................................................................................9
GETTING ACQUAINTED ....................................................................................................10
Indicator Status and Beep ..................................................................................................................12
[PF1] & [PF2] Key Default ...................................................................................................................12
BASIC OPERATIONS .........................................................................................................13
Professional
FM Transceiver
I
CONTENTS
Switch on / off Transceiver ..................................................................................................................13
Adjusting Volume ................................................................................................................................ 13
Channel Selection ...............................................................................................................................13
Group Selection ..................................................................................................................................14
Receiving ............................................................................................................................................14
Transmitting ........................................................................................................................................14
Emergency Alarm Function .................................................................................................................15
ADVANCED OPERATIONS ................................................................................................ 16
Call 1/Call 2 DTMF ..............................................................................................................................16
Monitor ................................................................................................................................................ 16
Momentary Monitor ............................................................................................................................. 16
Temporary Deletion of the Interfering Channel from scanning ............................................................17
Squelch Levels Enquiry ......................................................................................................................17
Squelch Levels Setup .........................................................................................................................17
Scan ....................................................................................................................................................17
Scramble Setup (Encryption) .............................................................................................................. 18
Squelch off .......................................................................................................................................... 18
Temporary Squelch off ....................................................................................................................... 18
Talk Around ......................................................................................................................................... 18
Professional
II
FM Transceiver
CONTENTS
Frequency Reverse .............................................................................................................................19
Current Channel Power Enquiry .........................................................................................................19
TX Power Switch .................................................................................................................................19
Whisper ...............................................................................................................................................20
Voice Compander (Reduce Noise & Enhance Audio Clarity) ..............................................................20
Battery Capacity Enquiry ....................................................................................................................20
Current Channel Enquiry ....................................................................................................................20
Channel Selector Knob Lockout ........................................................................................................21
PRESET OPERATIONS ...................................................................................................... 22
CTCSS / DCS Encode / Decode .........................................................................................................22
Optional Signaling ..............................................................................................................................22
Wide / Narrow Band Setup .................................................................................................................23
Busy Channel Lockout ........................................................................................................................ 23
Signaling Relations Setup ...................................................................................................................24
Channel Scan Skip .............................................................................................................................24
TX OFF ...............................................................................................................................................24
Battery Save Setup ............................................................................................................................. 24
Time-out Timer .................................................................................................................................... 25
Time-Out Timer Pre-Alarm .................................................................................................................. 25
Professional
FM Transceiver
III
CONTENTS
TOT Re-transmitting Time Setup ........................................................................................................25
VOX Function ......................................................................................................................................25
Priority Scan Setup .............................................................................................................................26
Resume Factory Default .....................................................................................................................26
OPTIONAL ACCESSORIES ............................................................................................... 27
RECOMMENDED INSTALLATION OF EARPHONE MICROPHONE ................................. 28
TECHNICAL SPECIFICATIONS ......................................................................................... 29
DJ-A11 TECHNICAL SPECIFICATIONS ............................................................................................29
DJ-A41 TECHNICAL SPECIFICATIONS ............................................................................................ 30
TROUBLE SHOOTING GUIDE ........................................................................................... 31
ATTACHED CHARTS ......................................................................................................... 33
CTCSS Frequency Chart .................................................................................................................... 33
DCS Chart ...........................................................................................................................................34
Professional
IV
FM Transceiver
STANDARD ACCESSORIES
Standard Accessories
Antenna Li-ion Battery Pack
Belt Clip
Instruction
Manual
Charger
Hand Strap
AC Adaptor
NOTE: Accessories may differ depending on the version you have purchased. Please contact your local
dealer for details of standard accessories and the warranty-policy before purchase.
Professional
FM Transceiver
1
BATTERY INFORMATION
Charging Operation
The battery is not charged at the factory, so please charge it before use.
Charge the battery for the rst time after purchase or extended storage (more than 2 months) may
not bring the battery to its normal operating capacity. After repeating fully charge/ discharge cycle,
the operating capacity will reach the best performance.The battery life is over when its operating
time decreases even though it is fully and correctly charged and it must be replace to new one.
Battery Charger Type
Please use Alinco's designated charger, other models may cause explosion.After installing the
battery pack, if the radio displays low battery with red ashing lamp or voice prompt, please charge
the battery.
Notice for Charging Battery
Do not shortcircuit the charger. Never attempt to remove the casing from the battery, otherwise ▼
Professional
2
FM Transceiver
the warranty is void and you risk serious damage to yourself and properties.
The ambient temperature should be between 5 ▼
range may not charge the battery.
Always switch OFF the transceiver before charging.Otherwise, it may not charge correctly. ▼
To avoid interfering the charging procedure, please do not cut off the power or take out the ▼
battery during charging.
Do not recharge the battery if it is already fully charged.This may shorten the life of the battery ▼
or damage the battery.
Do not charge the battery or transceiver when wet. Dry it before charging to avoid danger. ▼
℃
and 40℃while charging.Charging outside this
BATTERY INFORMATION
Caution:
Risk of explosion, generation of heat or leak of chemicals inside if the battery is replaced by an ▼
incorrect type or reverse polarity. Use always the recommended types of batteries in this manual
only.
The battery pack isn't fully charged when shipped. It must be charged before use. ▼
Charging should be conducted in a temperature range of +5ºC to +40ºC (+41ºF to +104ºF). ▼
Don't modify, dismantle, incinerate or immerse the battery pack in the water as this can be ▼
dangerous.
Never short-circuit the battery pack terminals, as this can cause damage to the equipment or lead ▼
to heating of the battery which may cause burns.
Unnecessary prolonged charging (overcharging) can deteriorate battery performance. ▼
The battery pack should be stored in a dry place where temperature is in -10ºC to +45ºC (-14ºF to ▼
+113ºF) range. Temperatures outside this range can cause the battery liquid to leak.Exposure to
prolonged high humidity can cause corrosion of metal components.
Battery-packs are a consuming part. When its operating time becomes considerably short after a ▼
normal charge, please consider that the pack is exhausted and replace it with a new one.
The battery pack is recyclable.Check with your local waste ofcials for details on recycling options ▼
or proper disposal in your area.
Use specied genuine chargers only to charge battery packs.Use of other chargers may cause ▼
damage to products, you and your property.
Never carry battery packs together with conductive articles such as metals in a same bag to ▼
prevent from short-circuiting. Put the packs only in nylon bags to carry them safely.
Professional
FM Transceiver
3
BATTERY INFORMATION
Even if you do not use the battery pack for a long time, charge it at least once every three ▼
months to prevent deterioration.
How to Charge
Plug the AC adaptor into the AC outlet, and then plug the 1.
cable of the AC adaptor into the DC jack located on the
back of the Charger. The Indicator lights orange (1s) and
then goes out----waits to charge.
Plug the battery or transceiver into the charger. Make 2.
su re that the b atter y ter mi nal s are in conta ct with
charging terminals well. The Indicator turns into twinkling
red-----Pre-charging begins.
After pre-charging for about 5 minutes, the 3. indicator will
stop twinkling----charging begins.
It takes approximately 4 hours to fully charge the battery. When the lamp lights green, the charging 4.
is nished. Remove the battery or the transceiver equipped with battery from the stand.
NOTE: when charging a power-on transceiver equipped with battery, the indicating lamp will not
turn into green to show the fully charged status.Only when the transceiver is switched off, can the
lamp indicate normally. The transceiver consumes energy when it is power-on, and the charger can
not detect the voltage when the battery has been fully charged. So the charger will charge battery in
constant voltage and fail to indicate correctly whether the battery has been charged fully.
Professional
4
FM Transceiver
Ac Input
BATTERY INFORMATION
LED Indicator:5.
STATUS
LED
Self-Examine
When Power on
Orange
(for 1 second)
No Battery Pre-charging
None
Red Light
Twinkles
for 5 Minutes
NOTE:
Trouble means battery heating, short-circuit or charger malfunction.Remove the battery pack ▼
from the charger immediately and contact to your local dealer for services.
The max trickle pre-charging time is 30 minutes. In case the red indicator continues to blink ▼
longer, please stop charging and consult with your local dealer for services.
It is known that Li-Ion battery packs heat up over 400 ▼
of over 80℃ for extended period of time. Although the packs are protected against overheating
with a protective circuit, never leave the battery packs in a car or similar locations in hot
seasons.
Charge
Normally
Red Green
℃
by itself when kept in a temperature
Fully
Charged
for a long time
Trouble
Red twinkles
Professional
FM Transceiver
5
BATTERY INFORMATION
▼ Li-ion packs may deteriorate by over 30% regardless of conditions after 3 years.This is a nature
of Li-ion pack and not a defect of the product.
The charger is to charge the battery pack only. It is not an AC adapter to operate the radio. ▼
Never attempt to transmit the radio with using the charger as it will cause the damage to the
charger and a repair/replace may become necessary.
The charge should be conducted in an ambient temperature with a minimum proper air- ▼
conditioning in an extremely hot or cold seasons.
Try charging the battery pack only when having trouble charging with the radio.In case the radio ▼
may have troubles,the charge can't be conducted properly.If the battery pack can be charged
alone, please take the radio to your local dealer for services.
Battery pack discharges faster when it is attached to the radio.Please always remove it from the ▼
radio when not in use.
How to Store the Battery
The battery should be kept in the status of 50% discharge when storing.1.
Remove the battery pack from the radio and keep it in a cool, dry place.2.
Keep away from source of heat and direct sunlight.3.
NOTE: Incorrect storage will damage both the battery pack and the radio. Please always remove the
battery pack from the radio when not in use.
Professional
6
FM Transceiver
PREPARATION
Installing / Removing the Battery
Match the three grooves of the battery pack with the 1.
corresponding guides on the back of the transceiver,
and then push it.
Press the battery pack until the release latch on the 2.
top of the transceiver locks. After hearing a “click”
sounds, the battery has been locked.
To remove the battery pack, slide up the release latch 3.
and remove the pack away from the transceiver.
Installing / Removing the Antenna
Installing the Antenna
1. Hold the antenna by its base.
2. Align the grooves at the base of the antenna with the
protrusions on the antenna connector.
3. Slide the antenna down and turn it clockwise until it stops.
4. Confirm that the antenna is securely connected.Check
and secure the connection from time to time.
Removing the Antenna:
Turn the antenna counter-clockwise to disconnect the antenna.
NOTE: Do not use third-party antenna as it may radiate more
RF that exceeds SAR limit guidances.
Professional
FM Transceiver
7
PREPARATION
Installing / Removing the Belt Clip
Installing the Belt Clip:
■
1. Put the belt clip on the back of the unit, and the screw
clockwise until it stops.
2. Conrm that the belt clip is securely attached.
* Tighten up the screw occasionally.
Removing the Belt Clip:
■
Turn the screw counter-clockwise to remove the belt clip.
Caution: Use the screws of specied size only. Others
may cause damage to the product. (screws size PM
Φ 2.5mm x 3mm)
Accessories
Remove the jack cover and insert the accessory plug
into the jack,as shown.
When the accessory is not used, please be sure to
put on cover with 3x6mm screw securely.
Note:
1.To keep the radio dust and splash resistant, the cover must
be closed properly with the original supplied cover.
2.The radio is not dust and splash resistant while using the
optional accessory risking that the water may penetrate
inside through the plug.
Professional
8
FM Transceiver
PREPARATION
Installing/ Removing the Hand Strap
Attach the hand strap as shown.
Professional
FM Transceiver
9
GETTING ACQUAINTED
1
8
2
3
4
11
1
Professional
10
FM Transceiver
5
6
7
9
GETTING ACQUAINTED
1
Antenna
2
POWER / VOLUME Switch: To turn on/off the power and adjust the audio level.
3
Jacklight: White is lit when the alarm key is pressed.
4
Emergency Alarm Key
(1)Under the standby conditions, press this key for 1 second to enable alarm function. Press this
key again to exit the alarm status.This is optional and PC preprogramming is required.
(2)Under the standby conditions, press this key to start jacklight, press this key again to turn it off.
5
PTT Key: Press and hold this key to transmit. Release the key to receive.
6
PF1 Key: Function key 1
7
PF2 Key: Function key 2
8
Channel Selector Knob: Turn the selector knob to select desired channel.
9
Optional accessory port
10
Battery Lock
11
Indicator : Green is lit while receiving a signal, Red while transmitting.
Professional
FM Transceiver
11
GETTING ACQUAINTED
Indicator Status and Beep
Low battery voltage warning
Transceiver emits a low voltage beep at intervals of 60 seconds,
and red light blinks.
TX/Reading data Red is lit while transmitting or reading the data while programming.
RX/Writing data Green is lit whilereceiving or writing the data while programming.
Scan Green blinks every second while scanning.
DTMF Successfully Decoded Green and red alternatively blinks.
Key Operation
A beep sounds when activating a fun ction. Beeps twice whe n
exiting from a function.
[PF1] & [PF2] Key Default
Press [PF1] Battery Capacity Enquiry
Press [PF2] Squelch off
Press and hold [PF1] Whisper
Press and hold [PF2] TX Power Switch
Professional
12
FM Transceiver
BASIC OPERATIONS
Switch on / off Transceiver
Turn【POWER】/【VOLUME】dial clockwise to power on.
Turn it counterclockwise to power off.
Adjusting Audio output level
Press and release PF2 key to monitor white noise to refer to the current audio level.
Turn【POWER】/【VOLUME】clockwise to increase the audio level, counterclockwise to decrease.
CAUTION:
Never use earphone while adjusting audio level. The max audio output is loud enough to hurt your
eardrums. You may feel a static shock when wearing an earphone in a dry atomosphere but it's not a
defect of product but a cause of nature.It is the same shock you feel typically when opening a door of a
car in certain conditions.
Channels Selection
Under the standby conditions, turn channel selector knob to choose the desired channel, and the
transceiver will announce the selected channel number. Turn clockwise to increase the channel
number, counterclockwise to decrease.
NOTE: The empty channel will be announced as blank.
Professional
FM Transceiver
13
BASIC OPERATIONS
Group Selection
By PC-preprogramming, 128 channels can be assigned in total which are divided into 8 groups
with 16 channels in each group. If different groups are being programmed, press and hold [PF2] to
turn on. Still holding [PF2] for another 2 seconds, it will announce the current group number. Turn
the selector knob to choose the desired group. The voice announce will tell you the selected group
number.
NOTE: You can enable or disable the group selection function by programming software.
Receiving
When the channel you are operating is called, LED GREEN lights, then you hear the voice from
transmitting party.
NOTE: If your transceiver has set higher squelch level or being programmed with signaling features, it
may fail to hear the calling.
Transmitting
Press and release the [PF2] key to monitor for a while to conrm the channel desired is not busy.
Press and hold [PTT] key to speak into microphone (MIC). Keep the distance of about 2.5~5cm
between your lips and MIC, and speak at normal voice level.
NOTE: Press [PTT] key, red is lit indicating it is transmitting. Release PTT to receive.
Professional
14
FM Transceiver
BASIC OPERATIONS
Emergency Alarm Function
(PC pre-programming required)
Press the emergency alarm key for over 1 second to start the Emergency Alarm Function.Once
activated, it will generate alarm sound, start transmitting to send alarm beeps. Turn off then turn on
again or pressing Emergency Alarm key again to exit the function.
Professional
FM Transceiver
15
ADVANCED OPERATIONS
The [PF1] and [PF2] keys are programmable by dealer to assign following features by using
programming software.
NOTE: When programming the following functions, you need to press the [PF1] / [PF2] key for one
second till the transceiver beeps and then release the key to operate the programmed function.
Call 1/Call 2 DTMF
Under the standby conditions, press the programmed key to transmit the prestored and selected
DTMF signaling.
Monitor
Under the standby conditions, pressing and releasing the programmed key, it beeps and enters the
monitor state. While in Monitor, it ignores CTCSS / DCS decode and enables monitoring all incoming
signals. Press this key again, it beeps twice and exits the monitor state.
Momentary Monitor
Under the standby conditions, pressing and holding the programmed key, it beeps and enters the
monitor state. While in Monitor, it ignores CTCSS / DCS decode and enables monitoring all incoming
signals. Press this key again, it beeps twice and exits the monitor state.
Professional
16
FM Transceiver
ADVANCED OPERATIONS
Temporary Deletion of the Interfering Channel from scanning
This function can temporarily skip the interfering channel or occupied channel from scan list.
When scan stops on one channel, pressing the programmed key ; it beeps and temporarily deletes
this channel from the scan list. If only one or two channels are in the scan list, this operation is not
available. Restart the transceiver to restore the temporarily deleted channels into the list again.
Squelch Levels Enquiry
Under the standby conditions, pressing and holding the programmed key, it will announce current
squelch level by voice.
Squelch Levels Setup
Under the standby conditions, pressing and holding the programmed key, it will set the squelch and
announces the level by voice.
Scan
Scan function is to automatically search the busy channels.
Under the standby conditions, pressing and holding the programmed key, a beep sounds and starts
scanning. It scans channels in scan list one by one. When one channel receives a matching signal,
the transceiver will temporarily stay in this channel till the signal disappears. Pressing the key again,
it beeps twice, and stops scanning and returns to the channel pre-programmed as "return-channel".
Professional
FM Transceiver
17
ADVANCED OPERATIONS
Scramble Setup (Encryption)
This special audio process can offer a more condential communications.
Under the standby conditions, pressing and holding the programmed key, it beeps and enables
Scramble function. Repeat the same operation,it beeps twice and disables.
NOTE: This is a simple analog scrambling (inversion scrambling) and the security level is low.
Squelch off
Pressing the programmed key, squelch opens and the background noise is heard. Press this key
again, it beeps twice, and the squelch closes. By using this function you can monitor weaker signals.
Temporary Squelch off
Pressing and holding the programmed key, squelch opens and the background noise is heard.
Release this key again, it beeps twice, and the squelch closes. By using this function you can
monitor weaker signals.
Talk Around
Under the standby conditions, pressing and holding the programmed key, it beeps and activates Talk
Around. In case of semi-duplex channels, it will transmit on receiving frequency and CTCSS / DCS
Professional
18
FM Transceiver
ADVANCED OPERATIONS
encode/decode setting will be reversed. This ables the user to talk to other users without using the
repeater. Press the key again, it beeps twice and Talk-around is deactivated.
Note:Under the talk around state, the transceiver can not communicate with other transceivers through
repeaters.
Frequency Reverse
Under the standby conditions, pressing and holding the programmed key, it beeps and activates
Frequency Reverse. In this condition, the current receiving frequnecy is switched to the transmitting
channel's, and the CTCSS or DCS encode/decode setting will be interchanged.
Pressing this key again, it beeps twice and exits reverse function. This is to monitor other stations
without using repeaters.
Current Channel Power Enquiry
Under the standby conditions, pressing the programmed key, it will announce the current output
setting of the selected channel.
TX Power Switch
Under the standby conditions, pressing the programmed key, it beeps and will change the output
power setting of the selected channel.
Professional
FM Transceiver
19
ADVANCED OPERATIONS
Whisper
Under the standby conditions, pressing the programmed key, it beeps and activates whisper function.
This feature is handy in quiet place, you can talk in lower voice than usual. Pressing this key again, it
beeps twice and exits whisper function.
Voice Compander (Reduce Noise & Enhance Audio Clarity)
Under the standby conditions, pressing the programmed key, it beeps and activates the function.
This feature reduces the back-ground noise and enhances audio clarity. Pressing this key again, it
beeps twice and exits the function.
Note: All users must have the compander-compatible radios to enjoy the feature. Use this function only
to communicate with non-compander radios.
Battery Capacity Enquiry
Under the standby conditions, pressing the programmed key, it will announce the current battery
level.
Current Channel Enquiry
Under the standby conditions, pressing the programmed key, it will announce the current channel
number.
Professional
20
FM Transceiver
ADVANCED OPERATIONS
Channel Selector Knob Lockout
Under the standby conditions,pressing the programmed key, it will announce the current channel
number.En ab le t hi s functio n to preven t normal communication failure cau se d by chan nel
misadjustment.
Under the standby conditions, pressing the programmed key, it beeps and locks the channel selector
knob. Press the key again, it beeps twice and unlocks the knob.
Professional
FM Transceiver
21
PRESET OPERATIONS
Following features can be set by using dealer-programming
software.
CTCSS / DCS Encode / Decode
It enables the CTCSS/DCS encode/decode setting.Pre-programming is necessary and usually not
recommended for general users.
Optional Signaling
Users can enable or disable the Optional Signaling in every channel by programming software. This
Signaling function is similar to CTCSS/DCS which embodies functions as Selective Call, Group Call,
All Call, PTT ID, and Remotely stun and Waken.
PTT ID:1. If current channel is edited with PTT ID, the transceiver will send transmitting ID when pressing
or releasing PTT key.
You can set group call wildcard for each group2. by programming software. (DTMF character A. B.C.D.***
or “#”).
The caller can call different groups by sending different group call codes.When the receiving party
receives a valid ID code, one or all of the characters would be replaced by wildcard characters
and the receiving part can realize all call, group call or selective call. It is much easy and exible to
realize all call, group call and etc by using group call code.
For example:
Group code –"C"
Radio A Radio B Radio C Radio D
ID code of the receiving party is 123
If the calling party uses "C23" to call, Radio A and Radio B will receive the call.
If the calling party uses"CC5" to call, Radio C and Radio D will receive the call.
If the calling party uses "CCC" to call, All Radios would receive the call..
Professional
22
FM Transceiver
223
235
355.
PRESET OPERATIONS
3.This transceiver is set with 16 groups of DTMF code, users can program and use them exibly.
Wide / Narrow Band Setup
The bandwidth can be set from either one of 25KHz(wide) /20KHz (normal) or 12.5KHz(narrow). Set
the proper channel-spacing value allocated to the radio services in your area. This is not a Channelstep setting, but to determine the deviation width of the modulation.
Busy Channel Lockout
BCLO is to restrict transmitting while RX signal is received. When Busy Channel Lockout is set to
on, transmission is possible only in the specic conditions (and isn't possible otherwise).The alarm
beep sounds if the PTT key is pressed when transmission is prohibited.Busy Channel Lockout mode
available by programming software are as follows.
BCL:1. Enable BCL, carrier wave lockout, transmitting is prohibited when receives any carrier.
BTL: 2. Enable BTL, transmitting is prohibited when current channel receives a carrier signal that
CTCSS/DCS tones are different from your group's.
OFF:3. Busy channel lockout is disabled. Default is OFF.
Professional
FM Transceiver
23
PRESET OPERATIONS
Signaling Relations Setup
Users can set relations between CTCSS/DCS signal and DTMF signal by programming software.
AND: Only when a matching CTCSS/DCS signal and a DTMF signal are received, can calling of other
party be heard.
OR: As long as a matching CTCSS/DCS signal or a DTMF signal is received, calling of the other party
can be heard.
Channel Scan Skip
Users can choose whether to set current channel as Scan Skip by programmi ng software.
Transceiver will skip current channel during scan when it is set as Scan Skip.
TX OFF
Once this function is enabled, [PTT] key becomes invalid and it works only as a receiver.
Battery Save Setup
This function prevents useless battery consumption by switching the power ON/OFF at a xed ratio
if there is no key operation or receiving signal for a continuous period of 5 seconds or more. Higher
OFF time (1:4 setting) saves more amount of battery but may cause slight delay on receiving. The
Battery Save function is temporarily suspended when a key is operated or a signal is received.
Professional
24
FM Transceiver
PRESET OPERATIONS
Time-out Timer
This function stops the transmission automatically when the continuous transmission time exceeds
the set time and alerts it with a voice.
Time-Out Timer Pre-Alarm
This is the alarm that warns the user before TOT stops the transmission.
TOT Re-transmitting Time Setup
This is the penalty time before resuming the normal operation condition, once TOT stopped the
transmission.
VOX Function
After enabling this function, you can directly start transmitting by voice instead of pressing [PTT] key.
(An optional earphone-microphone is necessary)
Professional
FM Transceiver
25
BACKGROUND OPERATIONS
Priority Scan Setup
This transceiver can be set with two priority channels at the same time.Users can set the desired
priority scan by programming software. If transceiver set priority scan, under scanning and receiving
no signal state, it will scan every channel and also test priority channel at a time. When the non-
priority channel receives signal, it will test priority channel according to yback time A and yback
time B setup by users.
Resume Factory Default
You can make all the settings of transceiver return to the factory default settings when it has troubles,
can't work properly or simply you wish to change settings.
Press [PTT] and [PF1] key together while turning on. Keep holding the two keys for more than 1
second. It will resume Factory Default after announcing current channel number.
Note: This function may be prohibited by dealer programming.
Professional
26
FM Transceiver
OPTIONAL ACCESSORIES
EA-211 VHF & FM radio Antenna
EA-212 UHF & FM radio Antenna
EBC-34 Belt Clip
EBP-87 Li-ion Battery Pack (DC 7.4V 1500mAh)
EBP-88 Li-ion Battery Pack (DC 7.4V 1700mAh)
EDC-189 Li-ion Battery Charger
EDC-190E AC Adaptor (220V Linear type)
EDC-191E AC Adaptor (220V)
EDC-191T AC Adaptor (120V)
EME-56A Earphone Microphone
EMS-76 Speaker microphone
Professional
FM Transceiver
27
RECOMMENDED INSTALLATION OF EARPHONE MICROPHONE
Earphone
Use a clip to fix with collar.
Clip the PTT unit closer to your mouth.
Carry the radio on the side or the back of your body,
and the cable should go around the back as shown.
Clamp the excessive length of cable at your waist.
Professional
28
FM Transceiver
TECHNICAL SPECIFICATIONS
DJ-A11 TECHNICAL SPECIFICATIONS
General
Frequency Range VHF: 136-174MHz
Channel Capacity 128 channels
Channel Spacing
Phase-locked Step 5KHvvz, 6.25KHz
Operating Voltage 7.4V DC ±20%
Battery Life
Frequency Stability ±2.5ppm
Operating Temperature -20℃~ +55
Size
Weight 208 g (with battery pack, antenna)
Receiving Part(ETSI EN 300 086 Standard Test)
Sensitivity(12dB
SINAD)
25KHz (Wide Band)
20KHz(Middle Band)
12.5KHz (Narrow Band)
More than 14 Hours (1500mAh),
by 5-5-90 work cycle
℃
260×60×35mm (with battery pack,
antenna)
Wide band Narrow band
≤0.25μV ≤0.35μV
Adjacent Channel
Selectivity
Intermodulation ≥65dB ≥60dB
Spurious Rejection ≥70dB ≥70dB
Audio Response
Hum & Noise ≥45dB
Audio Distortion ≤5%
Audio Power Output 1000mW/10%
Transmitting Part(ETSI EN 300 086 Standard Test)
Power Output 5W/2W/0.5W
Modulation 16KΦF3E 11KΦF3E
Adjacent Channel
Power
Hum & Noise ≥40dB ≥36dB
Spurious Emission ≤-36dB ≤-36dB
Audio Response
Audio Distortion ≤5%
≥70dB ≥60dB
+1~-3dB
(0.3~3KHz)
Wide band Narrow band
≥70dB ≥65B
+1~-3dB
(0.3~3KHz)
+1~-3dB
(0.3~2.55KHz)
40dB
≥
+1~-3dB
(0.3~2.25KHz)
FM Transceiver
Professional
29
TECHNICAL SPECIFICATIONS
DJ-A41 TECHNICAL SPECIFICATIONS
General
Frequency Range UHF: 400-470MHz
Channel Capacity 128 channels
Channel Spacing
Phase-locked Step 5KHvvz, 6.25KHz
Operating Voltage 7.4V DC ±20%
Battery Life
Frequency Stability ±2.5ppm
Operating Temperature -20℃~ +55
Size
Weight 208 g (with battery pack, antenna)
Receiving Part(ETSI EN 300 086 Standard Test)
Sensitivity(12dB
SINAD)
Professional
30
FM Transceiver
25KHz (Wide Band)
20KHz(Middle Band)
12.5KHz (Narrow Band)
More than 14 Hours (1500mAh),
by 5-5-90 work cycle
℃
260×60×35mm (with battery pack,
antenna)
Wide band Narrow band
≤0.25μV ≤0.35μV
Adjacent Channel
Selectivity
Intermodulation ≥65dB ≥60dB
Spurious Rejection ≥70dB ≥70dB
Audio Response
Hum & Noise ≥40dB
Audio Distortion ≤5%
Audio Power Output 1000mW/10%
Transmitting Part(ETSI EN 300 086 Standard Test)
Power Output 5W/2W/0.5W
Modulation 16KΦF3E 11KΦF3E
Adjacent Channel
Power
Hum & Noise ≥40dB ≥36dB
Spurious Emission ≤-36dB ≤-36dB
Audio Response
Audio Distortion ≤5%
≥70dB ≥60dB
+1~-3dB
(0.3~3KHz)
Wide band Narrow band
≥70dB ≥65B
+1~-3dB
(0.3~3KHz)
+1~-3dB
(0.3~2.55KHz)
36dB
≥
+1~-3dB
(0.3~2.25KHz)
TROUBLE SHOOTING GUIDE
Problem Corrective Action
A.The battery may be exhausting. Recharge or replace the battery.
No power
Battery power dies shortly after
charging.
Transceiver cannot scan Squelch is open. Adjust the level.
All band is noisy Adjust squelch level.
No sound when using earphone.
Communication distance
becomes short, and Low
sensitivity
Cannot talk or hear other
members in your group
Can not power on or frequent
power off
B.The battery may not be installed correctly. Remove the battery
and install it again.
C.The power switch is broken; send it to local dealers to repair.
D.Battery life is end; contact to local dealers to replace.
The battery is exhausted. Replace the battery pack with a new one.
Earphone or the jack is broken. Please contact with local dealers for
inspection.
A.Check whether the antenna is in good conduction and the antenna
base do not come adrift.
B.Antenna may be broken. Consult your local dealer for services.
A.Different frequency or channel, please change it.
B.Different CTCSS / DCS /DTMF, please reset it.
C.Out of communication range.
Check if the battery pack is securely attached.
Professional
FM Transceiver
31
TROUBLE SHOOTING GUIDE
The receiving sound level is low
or intermittent
Consult with local dealers for inspection.
A.Out of communication range or obstruct by walls, buildings etc.
Receiving signal is intermittent.
Change position to transmit.
B.4Internal components may be in trouble, please contact with local
dealers to repair.
Loudspeaker sounds lower or
with dry noise after certain time of
usage.(Speaker magnet attracts
Check whether the loudspeaker is broken, Iron powder or dusts is in
the loudspeaker. Please contact with local dealers to repair.
iron powders)
Receive voice from the other
parties and can not transmit
Interference is being received. BCLO activated.
A.Low volume, increase the audio level.
Receiving indicator with green
light but no sound
B.Volume switch or loudspeaker is broken, please contact with local
dealers to repair.
C.Earphone jack is broken, please contact with local dealers to
repair.
NOTE: Alinco guarantees the supply of minimum-necessary spare parts such as battery-packs, components
and mechanical parts for at least 5 years after the production of this product is terminated except in case of
accidents beyond control.
Professional
32
FM Transceiver
ATTACHED CHART
CTCSS Frequency Chart
1 67.0 12 97.4 23 141.3 34 179.9 45 225.7
2 69.3 13 100.0 24 146.2 35 183.5 46 229.1
3 71.9 14 103.5 25 151.4 36 186.2 47 233.6
4 74.4 15 107.2 26 156.7 37 189.9 48 241.8
5 77.0 16 110.9 27 159.8 38 192.8 49 250.3
6 79.7 17 114.8 28 162.2 39 196.6 50 254.1
7 82.5 18 118.8 29 165.5 40 199.5
8 85.4 19 123.0 30 167.9 41 203.5
9 88.5 20 127.3 31 171.3 42 206.5
10 91.5 21 131.8 32 173.8 43 210.7
11 94.8 22 136.5 33 177.3 44 218.1
Professional
FM Transceiver
33
ATTACHED CHART
DCS Chart
1 017 18 073 35 165 52 261 69 356 86 464 103 632
2 023 19 074 36 172 53 263 70 364 87 465 104 645
3 025 20 114 37 174 54 265 71 365 88 466 105 654
4 026 21 115 38 205 55 266 72 371 89 503 106 662
5 031 22 116 39 212 56 271 73 411 90 506 107 664
6 032 23 122 40 217 57 274 74 412 91 516 108 703
7 036 24 125 41 223 58 305 75 413 92 523 109 712
8 043 25 131 42 225 59 306 76 423 93 526 110 723
9 047 26 132 43 226 60 311 77 425 94 532 111 731
10 050 27 134 44 243 61 315 78 431 95 534 112 732
11 051 28 135 45 244 62 325 79 432 96 546 113 734
12 053 29 143 46 245 63 331 80 445 97 565 114 743
13 054 30 145 47 246 64 332 81 446 98 606 115 754
14 055 31 152 48 251 65 343 82 452 99 612 116 765
15 065 32 155 49 252 66 345 83 454 100 624
16 071 33 156 50 254 67 346 84 455 101 627
17 072 34 162 51 255 68 351 85 462 102 631
Professional
34
FM Transceiver
Loading...
