USER GUIDE
Aleratec
RoboShredder™
®
Part No. 240201
Copyright/Model Identification
The content of this manual is for informational purposes only and is subject
to change without notice.
This manual is copyright with all rights reserved. Under copyright laws, this
manual and the software described within may not be copied, except in the
normal use of the product(s) described within or to make a backup copy.
Copyright© 2012
Aleratec, Inc.
9851 Owensmouth Avenue
Chatsworth, CA 91311 U.S.A.
Aleratec® is a registered trademark, and RoboShredder™ is a trademark of
Aleratec, Inc
Check out Aleratec Online!
• Blog.Aleratec.com
• Facebook.com/Aleratec
• Twitter.com/Aleratec
• YouTube.com/Aleratec
Please record the following information to help expedite any warranty
claim:
Model No. _____________________ Serial No. _____________________
Date Purchased ________________________________________________
Place of Purchase ______________________________________________
www.aleratec.com
Introduction
Thank you for purchasing the Aleratec RoboShredder. Please read this User
Guide thoroughly before using this product.
Precautions
Before operating your RoboShredder, please read the following.
Warning:
• When shredding DVDs, CDs, or Blu-ray discs keep eyes and
ngers away from the feed opening to avoid possible injury.
• Always unplug the shredder prior to moving, cleaning, or emptying
the wastebasket.
• Continuous shredding of form-fed computer paper should not
exceed 60 minutes.
• Do not add or remove paper from the auto-feed tray once shredding
has begun.
• Do not attempt to repair the shredder yourself.
• Keep the shredder power switch in the OFF position when it is not
in use for an extended period of time.
• Product is not intended for use by children (product is not a toy).
Keep shredder out of the reach of children.
• Avoid touching the document feed opening, disc feed opening or
feed opening on the auto-feed tray with hands. Do not place hands
or ngers into any shredder opening to avoid serious injury.
• Keep all loose articles of clothing and jewelry, and other small
items away from the feed opening to prevent injury.
• Avoid hair touching the document feed opening, disc feed opening
or feed opening on the auto-feed tray.
• Keep aerosol products away.
www.aleratec.com
1
Introduction
Key Items
Entry slot for paper
and credit cards
Auto-Feed Tray
Entry slot for Blu-ray,
DVD and CD discs
Control Panel
Power
Switch
Waste
Receptacle
Auto-Feed
Load Button
Feed Cover
Reverse
Button
LED Display
Note: Choose a Good Location
1. Allow adequate clearance for moving parts.
2. Do not place near heat sources such as radiators or air ducts, or in a place
subject to direct sunlight, excessive dust, mechanical vibration or shock.
3. Good care will help assure maximum product life. Improper operating
environment and misuse may void the warranty.
2
www.aleratec.com
On/Off
Forward/Auto
Introduction
Unpacking your Shredder
1. Place the shredder on a at level surface.
2. Remove all packing materials from the shredder.
Powering Up your Shredder
1. Plug the shredder into a 120V electrical outlet.
2. Press the power switch to the ON position
3. The power LED will illuminate and the shredder is now ready for
operation.
( – )
.
www.aleratec.com
3
Shredder Operation
This shredder is equipped with an Auto Start/Stop smart sensor, which
allows the unit to automatically start when an item is placed into the feed
opening or paper is placed in the auto-feed tray and to stop as soon as the
item travels completely through the feed opening.
Shredder Capacity
• The shredder will shred up to six letter size sheets of 20 lb. bond paper
at one time when inserted in the entry slot for paper. The auto-feed tray
will hold up to 80 sheets of paper. When shredding Blu-ray, DVD or CD
discs or credit cards, only insert one piece at a time.
Using the Auto-Feed Tray
1. Make sure the power switch is in the ON position ( – ). (The power LED
will be lit.)
2. Slide no more than 80 sheets of paper into the Auto-Feed Tray, sliding
them under the Feed Cover until you meet some resistance.
3. Holding the papers in place, press the Auto-Feed Load Button. This will
allow you to slide the papers a bit further under the Feed Cover. When
you again meet resistance, release the papers and the Auto-Feed Load
Button.
4. The Auto Start/Stop smart sensor will signal the shredder to start. Paper in
the Auto-Load Tray will be fed in batches to the shredder until the AutoLoad Tray is empty, at which point the shredder will stop.
5. Once you conrm that batches of paper are feeding into the shredder from
the Auto-Load Tray, you can leave the RoboShredder to complete the task.
No further intervention is required.
4
www.aleratec.com
Problems and Solutions
When a minor jam occurs, your RoboShredder will automatically reverse and
then resume shredding. This will clear most jams. In case of a stall, follow the
directions below.
Basic Paper Jam
The shredder should automatically eject any minor excess material from the
feed openings. Manually remove any unshredded material from the top of the
feed openings. If the jam occurs in the auto-feed slot, gently raise the feed
cover and remove excess material from the opening.
Minor Paper Jam
Press the REVERSE button on the control panel. The shredder will reverse
momentarily, then resume shredding. If shredding does not resume, remove
unshredded portion of paper from the entry slot or auto-feed slot (by lifting the
feed cover) and clear any excess paper shreds.
Major Paper Jam (Overload lit on LED panel)
1. Turn the power switch to the OFFposition ( ○ ) and wait at least 10
minutes for the thermal overload protection to reset.
2. Turn the power switch ON ( – ). If paper was left inside any feed opening
prior to the overload, press the REVERSE button. Be careful to not place
your ngers near the feed opening or serious harm could result. Clear any
excess paper shreds from the feed opening. You are now ready to resume
normal shredding.
Paper Jams and Motor Overload Situations
The shredder is equipped with an automatic motor overload protection
circuit. The duty cycle for the shredder is rated for continuous shredding.
Recommended running time at maximum capacity is 60 minutes on and 45
minutes off when using the auto feed tray, 15 minutes off when feeding the
shredder normally. The shredder will automatically terminate power if any of
the following abnormal situations occur:
1. Operating the shredder at the maximum six-sheet capacity continuously
for a prolonged period of time, e.g., more than 60 minutes without
stopping.
www.aleratec.com
5
Problems and Solutions
2. Exceeding the shedding capacity, e.g., inserting more than six sheets of 20
lb paper in one pass through the paper entry slot, or more than 80 sheets of
20 lb paper in the auto feed tray, or if the paper is not fed squarely into the
feed opening.
Both abnormal operations may result in the activation of the automatic thermal
motor overload protection circuit, which terminates power to the shredder. A
paper jam could cause the thermal motor overload protection to terminate AC
power to the motor. Never allow the shredder to remain in a jammed condition
with the AC power turned on.
6
www.aleratec.com
Specifications
Shredding Capacity • 1 Blu-ray disc, 1 DVD, 1 CD, 1 Credit Card, or 6
sheets of paper per pass in the entry slot. 80 sheets
of paper in the auto-feed tray.
Shred Type • Blu-ray/DVD/CD/: Strip Cut
• Paper/Credit Card: Cross Cut
Shred Size • Strip Cut: 40 mm
• Cross Cut: 3 x 9 mm
Feed Opening • Paper/Credit Card: 220 mm (8.66 in.)
• Blu-ray/DVD/CD: 123 mm (4.8 in.)
• Auto feed: 224 mm (8.8 in.)
Weight • 12.9 kg (28.4 lb)
Dimensions
(depth x width x height)
Power Requirements • 120V, 60 Hz
• 305 mm x 356 mm x 533 mm
• 12 in. x 14 in. x 21 in.
www.aleratec.com
7
Technical Support
After reading this User Guide, if you need additional assistance with this
product, please contact Aleratec Technical Support. Our technical staff will
be happy to assist you, but they may need your help to better assist you.
• Troubles - your questions about the RoboShredder. Please provide
enough information about your problems so our technical staff can
recreate and diagnose it.
Technical Support Addresses and Phone Numbers
X By e-mail: support@aleratec.com – Skype: support.aleratec.com
X By Telephone: 1-818-678-0484
Technical Support Group can be reached 8:00 AM to 5:00 PM, Pacic
Time, Monday through Friday, excluding U.S. holidays.
Please try to call from a phone near your computer system.
X Access is available 24 hours a day, 365 days a year, via:
The World Wide Web at: www.aleratec.com
FAX at: 1-818-678-0483
8
www.aleratec.com
Technical Support FAX Back Form
Aleratec, Inc.
Technical Support Fax Back Form
To:TechnicalSupportGroupFAX:1-818-678-0483
FROM: _____________________FAX: ___________________________
E-MAIL ____________________________________________________
RE: ________________________TEL: ___________________________
DATE: _______________# OF PAGES: ___________________________
I am experiencing the following problems with my RoboShredder:
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
By answering these questions, your problem will be solved more rapidly.
Make copies as necessary. You can reach us electronically at: www.aleratec.
com on the internet.
