Dok./Rev.-Nr. 37182 EN Aldi UK MSN 50065190-1 Cover Final REV1
Overview · Use · Scope of delivery/Device parts
A
10
9
1
234
Min
Max
A
B
C
7
568
3
Use
B
C
FP
FPFP
4
Use
D
5
Device parts
Device parts
1
Fan
2
LED lamp
3
Temperature control
4
Door handle (not shown)
5
Door compartment
6
Glass shelf
7
Drip tray for condensation
8
Condensate drain
9
Mains cable with plug (on the back, not shown)
10
Air fi lter (on rear, not shown)
The appliance is suitable for the storage of particular foodstuffs at a temperature warmer than
+14°C and for the storage of red wine, white wine, sparkling wine etc.
For example:
A
Suitable for fresh fruits
B
Suitable for beverage cans
C
Suitable for beverage bottles
6
About these operating instructions
About these operating instructions
Thank you for choosing our product. We hope you enjoy using it.
Read the safety instructions carefully before using the device for the fi rst
time. Note the warnings on the device and in the operating instructions.
Always keep the operating instructions close to hand. If you sell the device
or give it away, please ensure that you also pass on these operating instructions. They
are an essential component of the product.
Explanation of symbols
If a block of text is marked with one of the warning symbols listed below, the hazard
described in that text must be avoided to prevent the potential consequences
described there from occurring.
DANGER!
This signal word indicates a hazard with a high level of risk which, if not avoided, will
result in death or serious injury.
WARNING!
This signal word indicates a hazard with a medium level of risk which, if not avoided,
could result in death or serious injury.
CAUTION!
This signal word indicates a hazard with a low level of risk which, if not avoided, could
result in minor or moderate injury.
NOTICE!
This signal word warns of possible damage to property.
Warning: danger due to combustible and/or highly fl ammable
substances!
7
Proper use
Read the user manual and observe its instructions.
This symbol gives you useful additional information on assembly or
operation.
Declaration of conformity (see section „Declaration of conformity“):
Products labelled with this symbol comply with all the applicable
Community rules of the European Economic Area.
Symbol for AC current
Proper use
This appliance is used for cooling drinks and food. This appliance is
intended to be used in household or in similar applications such as:
− staff kitchen areas in shops, offi ces and other working
environments;
− farm houses and by clients in hotels, motels and other
residential type environments;
− bed & breakfast type environments;
− catering and similar non-retail applications.
Please note that we shall not be liable in cases of improper use:
− Do not modify the appliance without our consent and do not
use any auxiliary equipment that we have not approved or
supplied.
− Use only spare parts and accessories that we have supplied or
approved.
− Heed all the information in these operating instructions,
especially the safety information. Any other use is deemed
improper and can cause personal injury or property damage.
8
Safety information
Safety information
WARNING!
Risk of injury!
There is a risk of injury in case of improper use.
− Store the appliance and its accessories out of the reach of
children.
− This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
− Children shall not play with the appliance.
− Cleaning and user maintenance shall not be made by children
without supervision.
− Children between the ages of 3 and 8 are allowed to load and
unload refrigerators.
− Children younger than 8 should be kept away from the mains
cable.
DANGER!
Risk of suffocation.
There is a risk of suffocation if plastic packaging or small parts are
inhaled or swallowed.
− Do not store any of the packaging material used (bags,
polystyrene, etc.) within the reach of children.
− Keep children away from the inside of the appliance. If the door
shuts, there is a risk of suffocation!
9
Safety information
General safety instructions
− Do not operate the appliance if it has been visibly damaged or
the mains cable or plug is defective.
WARNING!
Risk of explosion!
There is a RISK OF EXPLOSION AND FIRE due to the resulting fumes!
− Do not store or use any explosive substances such as aerosol
cans with a fl ammable propellant or other fl ammable materials
in this appliance or near to the appliance.
CAUTION!
Risk of injury!
Burns caused by low temperatures are possible.
− Do not touch the cold inner walls of the refrigerator
compartment with your hands.
Setting up the appliance
− Never place the appliance with the front edge along the edge
of a table top or shelf, because there is a risk of the appliance
tipping forwards and falling if the door compartment is
overloaded. Take care to ensure that there is suffi cient space in
front of the appliance so that when opening the door, the door
lies on the storage surface when the appliance is tipped.
− Connect the appliance to a properly installed safety socket
which is easily accessible and close to the place of installation.
The local mains voltage must correspond to the technical data
for the appliance.
− The socket must be freely accessible so that you can unplug the
appliance from the mains quickly if necessary.
− Do not use an extension cable.
10
Safety information
− WARNING! When positioning the appliance, ensure the supply
cord is not trapped or damaged.
− WARNING! Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
− Ensure the mains cable is out of harm’s way and will not trip
people up.
− To ensure adequate ventilation, maintain a minimum distance of
10cm to the ceiling and rear wall and 5cm to the walls, otherwise
internal electronics could be damaged (see fi g. B).
− WARNING! Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
− Set up the appliance in a dry and ventilated room. Do not
expose the appliance to direct sunlight because this can
damage the surfaces of the appliance and increase energy
consumption.
− Protect the appliance from moisture and splashes.
− Never immerse the appliance in water.
− Do not set up the appliance near to heat sources such as ovens,
radiators, underfl oor heating, etc.
− Set up the appliance on a stable, fl at surface.
− Set up the appliance horizontally; compensate for any
unevenness of the worktop by adjusting the front screw foot.
The rear feet and the other front foot are fi xed and can’t be
adjusted.
− Do not place any other household appliances (such as a
microwave, food processor, etc.) on top of the refrigerator.
− Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
11
Safety information
− The appliance is suitable for climate classes SN and N (see
type plate). A fl awless cooling performance of the appliance
is guaranteed at ambient temperatures of between 10°C and
32°C. The performance of the appliance may diminish at other
temperatures.
Handling the appliance
WARNING!
Risk of injury/health hazard!
Incorrect use of the appliance can result in injuries.
− Do not use the base, drawers, doors, etc. as steps or for support.
− Never place the appliance with the front edge along the edge
of a table top or shelf, because there is a risk of the appliance
tipping forwards and falling if the door compartment is
overloaded. Take care to ensure that there is suffi cient space
in front of the appliance so that when opening the door, the
door lies on the storage surface when the appliance is tipped.
Always load the cooling compartment fi rst and then the door
compartment.
The appliance may not function perfectly (increased temperature)
if it is exposed for a long period of time to temperatures that are
colder than the lower limit of the temperature range for which it
was designed (below 10 °C).
Food can perish if there is a power cut or if the appliance is switched
off. There is then a risk of food poisoning.
− If there has been a power cut, check that the food which is
stored in the appliance still looks and smells safe to eat.
− Do not store any medicines, laboratory preparations or other
temperature-sensitive products subject to Directive 2007/47/EC
in the refrigerator.
− Pay attention to cleanliness and the correct storage of the food.
12
Safety information
Cleaning and maintenance
WARNING!
Risk of electric shock!
There is a risk of electric shock due to live parts.
− Before starting any maintenance work, always ensure that
the plug has been removed from the wall socket (do not pull
on the cable, but on the plug). If the plug is not accessible,
the corresponding mains supply from your distribution board
needs to be switched off.
− Never pull out the plug with wet or moist hands.
WARNING!
Risk of explosion!
There is a RISK OF EXPLOSION AND FIRE due to the resulting fumes!
− Do not use any fl ammable liquids to clean the appliance or any
parts of the appliance.
Faults
WARNING!
Risk of electric shock!
There is a risk of electric shock due to live parts.
− Never try to open and/or repair an appliance component
yourself. There is a risk of electric shock.
− To prevent risks, damaged mains cables may only be replaced
by our Service Centre or by a qualifi ed specialist workshop.
− In the event of a fault, contact our Service Centre or another
suitable specialist workshop.
13
Information on the appliance
Disposal
WARNING!
Risk of injury!
There is a risk of suffocation if the door slams shut.
− Remove the door before disposing of the appliance and
leave the storage shelves in the appliance to prevent children
climbing into it.
− Before disposal, cut off the mains cable.
Information on the appliance
• Energy effi ciency class A+
• Climate class SN/N
Refrigerating appliances conforming to this standard are classifi ed into four climate
classes or into a range of classes:
ClassSymbol
Extended temperateSN+ 10 to + 32
TemperateN+ 16 to + 32
SubtropicalST+ 16 to + 38
TropicalT + 16 to + 43
Ambient temperature
range °C
Package contents
WARNING!
Risk of suffocation.
There is a risk of suffocation if plastic packaging or small parts are
inhaled or swallowed.
− Do not store any of the packaging material used (bags,
polystyrene, etc.) within the reach of children.
14
Changing the door hinge
When unpacking, ensure that the following parts are included:
• Upright fridge
• Glass shelf
• Operating instructions, warranty documents
Changing the door hinge
The refrigerator is supplied with a right-hinged door. If you want to change the opening
direction, proceed as follows:
Tools required:
• No. 8 spanner (metric)
• Small fl at-head screwdriver
• or Phillips screwdriver
1. Unplug the appliance from the mains socket.
2. Empty the refrigerator, including the shelf and all food, etc.
Place all parts safely to one side. They will all be needed to reinstall the door.
3. Remove the top hinge cover on the right side and the cover on the left side, for
example with a fl at-head screwdriver (see fi g. C) and remove the dummy plugs
from the door.
4. Undo the three screws on the upper hinge using the spanner.
5. Remove the upper hinge and put it on the left side and tighten the screws hand
tight.
6. Tilt the appliance slightly backwards.
7. Undo the three screws on the lower hinge with a spanner and remove it.
8. Fit the lower hinge on the left side and tighten the screws.
9. Align the door so that the seal is applied evenly. Now tighten the screws on the
upper hinge (see fi g. D).
10. Replace the hinge cover on the hinge; place the cover on the now exposed holes
and press down fi rmly. Push the dummy plugs into the holes on the door.
Please note: The door seal adapts to the new door hinge after a few hours.
15
Using the refrigerator
Using the refrigerator
− Unpack the appliance and remove the adhesive tape.
Remove any possible adhesive residue using a mild cleaning agent.
− Dispose of the protective polystyrene foam packaging separately.
− Clean all parts of the appliance thoroughly before switching it on for the fi rst time
(see section „Cleaning the appliance“ on page 18).
− After cleaning, dry the appliance thoroughly before switching it on for the fi rst
time.
− Set up the appliance in a suitable location (see Fig. B).
− Connect the appliance to a wall socket.
− Set the temperature control
About 1–2 hours after connection to the mains, the appliance will have reached
operating temperature and you can load the appliance.
Notes on using the refrigerator
The appliance works correctly in ambient temperatures from +10°C to + 32°C.
The appliance is suitable for the storage of particular foodstuffs at a temperature
warmer than +14°C and for the storage of red wine, white wine, sparkling wine etc.
To avoid contamination of food, please respect the following instructions
− Clean regularly surfaces that can come in contact with food and accessible
drainage systems.
− Store raw meat and fi sh in suitable containers in the refrigerator, so that it is not
in contact with or drip onto other food.
− Distribute the food/beverages evenly in the appliance. Ensure that the food does
not touch the rear wall of the refrigerator compartment because it could become
overripe or damp as a result.
Please store different foods according to the compartments or target storage
temperature of your purchased products.
3
to Min and close the door.
− If the refrigerating appliance is left empty for long periods, switch off, clean, dry,
and leave the door open to prevent mould developing within the appliance.
16
Using the refrigerator
Tips on saving energy
− Place only food or drinks that are already cooled or at room temperature into the
refrigerator. Do not place hot food or drinks into the refrigerator.
− Do not position the appliance near a heat source (radiator or cooker, etc.).
− Ensure adequate ventilation to prevent increased energy consumption and any
possible damage to the internal electronics.
− Opening the door for long periods can cause a signifi cant increase of the
temperature in the compartments of the appliance. Open the door for a short
time only when putting food/beverages in the fridge and taking food/beverages
out. Do not open the door too often and do not leave the door open for extended
periods.
− Select the setting of the temperature control according to how full the appliance
is.
− If you leave the shelve in the appliance during operation, the energy
consumption will be the lowest.
Setting the temperature
The temperature of the refrigerator compartment is controlled via the temperature
control 3.
The cooling temperature can be set from 4.5°C (setting Min) to 15°C (setting Max).
Check the temperature in the refrigerator compartment with a thermometer. If the
desired temperature has been reached, food can be inserted into the appliance.
The internal temperatures can be infl uenced by factors such as the
installation location, ambient temperature and frequency at which the door
is opened. Take these factors into account when setting the thermostat.
Do not load the refrigerator compartment until the appliance has cooled
down.
Before adding fresh foods, bring the temperature of the refrigerator
compartment down to the coldest level Min.
Switching off the appliance
− In order to de-energise the appliance completely, pull the mains plug 8 out of
the socket.
− Wait around 3–5 minutes before switching the appliance back on.
17
Cleaning the appliance
Cleaning the appliance
WARNING!
Risk of electric shock.
There is a risk of electric shock from electrifi ed parts.
− Before starting any cleaning, pull the mains plug out of
the socket (pull on the plug, not the cable). If the plug is
not accessible, the corresponding mains supply from your
distribution board needs to be switched off.
NOTICE!
Risk of damage.
Equipment damage due to improper handling of the sensitive
surfaces of the appliance.
− Sensitive surfaces: Do not allow oil and grease to come into
contact with the plastic parts and the door seal as the surface
can become porous and brittle.
− Never use acidic, abrasive or granular, acetic-acid soda- or
solvent-based cleaning agents. These may damage the
surfaces of your appliance.
1. Empty the refrigerator.
2. Pull out the plug 8.
3. Remove the shelf 6 from the refrigerator compartment.
4. Wash out the refrigerator compartment with a mild detergent (such as
washing-up liquid or a soda solution of 3 tablespoons of soda to one litre of
water) and dry thoroughly.
5. Clean all of the fi ttings carefully and dry them.
6. Clean the appliance surfaces, except the door seal, with a mild cleaning agent. If
necessary, the appliance surface can be treated with silicone wax.
7. Clean the door seal with clean water; wipe it off and allow it to dry.
8. Put the mains plug back into the wall socket.
9. As soon as the appliance has reached operating temperature, you can fi ll it again
with food.
18
Cleaning the appliance
Cleaning the fan fi lter
To protect the fan 1 on the rear of the appliance from dust, there is a dust fi lter fi tted
in front of the fan. To ensure proper operation, make sure that the air fi lter does not
get clogged. It must be cleaned if necessary.
1. Unplug the refrigerator from the wall socket.
2. Push the two clips on top of the fan fi lter
remove the fi lter from the rear of the appliance.
3. Rinse the air fi lter under running water and then leave it to dry completely.
4. Place the fan fi lter so that the three tabs fi t into the matching recesses on the rear of
the appliance and push the clips into the two upper slots until they lock into place.
9
together at the same time to
Emptying the drip tray for condensation
Condensation from inside the refrigerator will collect in the drip tray 7 below the
refrigerator. The condensation evaporates in the drip tray and it is not generally
necessary to empty it manually. However, if additional liquid (e.g. from a leaking
water bottle) should enter the inside of the refrigerator, it will also collect in the
drip tray. The volume of liquid that accumulates in the drip tray may under certain
circumstances be too large to evaporate or it may contaminate the drip tray.
The drip tray is permanently screwed to the base of the device and thus
cannot be readily removed.
Proceed as follows to empty the drip tray:
− Absorb the excess liquid little by little from the drip tray using an absorbent cloth.
− If necessary, wipe the drip tray afterwards using a damp cloth to remove any
contaminants.
Replacing the interior light
CAUTION!
Risk of injury/device damage!
The replacement of the interior LED light is reserved for the
manufacturer, his customer service or a similarly qualifi ed person.
− If the interior light does not work, contact customer service.
19
Transport
Transport
1. Unplug the appliance from the wall socket.
6
2. Remove all items and the glass shelf
3. Screw in the adjustable foot.
4. Tape the door in place using adhesive tape.
from the interior of the appliance.
Troubleshooting
Faults may occur during operation. Please use the following table to check whether
you can resolve the problem yourself. All other repairs are prohibited and will
invalidate the warranty cover. In the event of a fault, contact our Service Centre or
another suitable professional repair workshop.
MalfunctionCauseRectifi cation
The appliance is
not working.
The electrical circuit has been
interrupted.
− Check whether the
mains plug is plugged
in.
− Check whether the
connection cable has
been damaged.
− Check fuse in plug and
replace if necessary.
The temperature
is not low
enough.
20
The door will not shut tight,
or is opened too often.
The appliance is dirty. − Clean the appliance.
− Arrange the contents
of the fridge so that
nothing can prevent the
door from closing.
− Avoid opening the fridge
door unnecessarily.
− Check the door seal.
Steps to take in the event of a power cut
MalfunctionCauseRectifi cation
The appliance has been
set up in a location that is
exposed to direct sunlight or
next to a heat source.
The air fi lter is clogged. − Check the air fi lter.
− Set up the appliance in
another location.
− Set the appliance to a
colder setting.
The appliance
is operating
too loudly or
vibrating.
Temperature
control does not
work.
The interior
lighting is not
working.
The feet on the appliance
have not been properly
adjusted.
The air fi lter is clogged. − Check the air fi lter.
The temperature sensor is
defective.
The LED is defective. − Contact the customer
− Adjust.
− Contact the customer
service department.
service department.
Steps to take in the event of a power cut
− In the event of a power cut, check the condition of the food before consuming it
(also see „Handling the appliance“ on page 12).
End of operation/Storage
If you do not intend to use the appliance for a long period of time, it is necessary to
perform the following tasks:
− Remove the plug from the wall socket.
− Empty the appliance.
− Wipe out the cooling area and allow it to dry.
− Carefully wash all fi ttings.
− Leave the door open to avoid unpleasant odours and mould formation.
21
Disposal
Disposal
PACKAGING
The product has been packaged to protect it from damage in transit. The packaging is
made of materials that can be recycled in an environmentally friendly manner.
DEVICE
Old devices may not be disposed of with normal household waste. If you
can no longer use your electrical device, dispose of it in accordance with
the legal provisions applicable in your area. This involves separating the
materials in the device for the purpose of recycling and minimising the
environmental impact.
− Take old devices to a collection point for electrical scrap or a recycling centre.
− Contact your local waste disposal company or your local authority for more
information on this subject.
− Before disposal cut off the cable.
− The appliance/insulation must be disposed of correctly.
− During disposal, please note that the appliance/insulation contains cyclopentane
(a fl ammable expanded gas for insulation).
22
Technical data
Technical data
Brand:Ambiano
Model:MD 37182
Power supply:220-240 V ~ 50/60Hz
Power consumption:50W
Cooling temperature range:+4.5°C to +15°C
Energy effi ciency class:A+
Energy consumption:82 kWh/year*
0.225 kWh/24 hours
Category10
Storage capacity:17l
Climate class:SN/N
Noise emissions:38 dB
Dimensions (W x H x D):38,5 x 34,1 x 42,5 cm
Weight:approx. 7.3 kg
Propellent gascyclopentane
Interior light, LED0.6W
* kWh / year energy consumption calculated on the basis of conformity testing
results over 24 hours. The actual consumption will depend on the use and location
of the appliance.
Declaration of conformity
Medion AG hereby declares that the product MD 37182 complies with
the requirements set out in the following European standards:
• EMC Directive 2014/30/EU
• Low Voltage Directive 2014/35/EU
• Regulation (EC) No 1935/2004
23
Service information
Service information
Please contact our Customer Service team if your device ever stops working the way
you want or expect it to. There are several ways for you to contact us:
• In our Service Community, you can meet other users, as well as our staff, and
you can exchange your experiences and pass on your knowledge there.
You will fi nd our Service Community at http://community.medion.com.
• Alternatively, use our contact form at www.medion.com/contact.
• You can also contact our Service team via our hotline or by post.
Opening timesHotline number UK
Mon – Fri: 08.00 – 20.00
Sat – Sun: 10.00 – 16.00
You can download this and many other sets of operating
instructions from our service portal at
www.medion.com/gb/service/start/.
You will also fi nd drivers and other software for a wide range of
devices there.
You can also scan the QR code on the side of the screen, to
download the operating instructions onto your mobile device from
the service portal.
0333 3213106
Hotline number Ireland
1 800 992508
Service address
MEDION Electronics Ltd.
120 Faraday Park, Faraday Road, Dorcan
Swindon SN3 5JF, Wiltshire
United Kingdom
24
Privacy statement
Privacy statement
Dear customer,
We wish to inform you that we, MEDION AG, Am Zehnthof 77, 45307 Essen, Germany
process your personal data as a data controller.
For matters regarding data protection, we are supported by our company data
protection offi cer who can be contacted at MEDION AG, Datenschutz, Am Zehnthof 77,
D – 45307 Essen; datenschutz@medion.com. We process your data for the purpose
of warranty processing and associated processes (e.g. repairs) and therefore rely on
processing your data for the sales contract concluded with us.
Your data will be provided to repairers contracted to us for the purpose of warranty
processing and associated processes. We generally store your personal data for a
period of three years in order to fulfi l your legal warranty rights.
You have the right to be informed of the personal data concerned as well as the right
to rectifi cation, deletion, restriction of processing, the right to object to processing, as
well as the right to data portability.
In case of access and cancellation rights, restrictions apply according to S 34 and S
35 of BDSG (Federal Data Protection Act) (Art. 23 GDPR). In addition, there is a right
of appeal to a competent data protection supervisory authority (Article 77 GDPR in
conjunction with S 19 BDSG). The state offi cial for data protection and freedom of
information for MEDION AG is Nordrhein Westfalen, P box 200444, 40212 Düsseldorf,
Germany. www.ldi.nrw.de.
The processing of your data is necessary for warranty processing: it is not possible to
process the warranty without the provision of the required data.
These operating instructions are protected by copyright.
Mechanical, electronic and any other forms of reproduction are prohibited without the
written permission of the manufacturer.
Copyright is owned by the company:
MEDION AG
Am Zehnthof 77
45307 Essen
Germany
Please note that you cannot use the address above for returns. Please always contact
our Customer Service team fi rst.
26
Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly. In
the event of product failure within its intended use over the course of the
fi rst 3 years after date of purchase, we will remedy the problem as quickly
as possible once it has been brought to our attention. In the unlikely event
of such an occurrence, or if you require any information about the product,
please contact us via our helpline support services, details of which are to be
found both in this manual and on the product itself.
GBIE
PRODUCED IN CHINA FOR:
ALDI STORES LTD. PO BOX 26, ATHERSTONE
WARWICKSHIRE, CV9 2SH.
ALDI STORES (IRELAND) LTD.
PO BOX 726, NAAS, CO. KILDARE.
VISIT US AT WWW.ALDI.COM
AFTER SALES SUPPORT
GBIE
0333 32131061 800 992508
Standard local landline call rate
www.medion.co.uk
MODEL:
MD 37182
705123/705124
Free hotline
09/2020
3
YEAR
WARRANTY
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
