Alco Electronics W1166 Users Manual
W1166
Windows 10
2-in-1 Tablet with detachable keyboard
User Manual
Need Help? Visit support.rcatablets.com
Safety Precautions
Equipment tested for
compliance as a
W1166
complete unit
FCC Information
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: The grantee is not responsible for any changes
or modifications not expressly approved by the party
responsible for compliance. Such modifications could void
the user’s authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
EN-1
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Warning: Changes or modifications not expressly
approved by the party responsible for compliance (MLB
International Inc., PO Box 1214, Lockport, NY, 14095, Tel:
716-240-0902) could void the user’s authority to operate
the equipment.
CAN ICES-3(B) / NMB-3(B)
This device complies with Industry Canada License-exempt
RSS Standard(s). Operation is subject to the following two
conditions: (1) This device may not cause interference,
and (2) this device must accept any interference, including
interference that may cause undesired operation of the
device.
RF exposure information (SAR)
this device is designed and manufactured not to exceed
the emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission of
the United States. During SAR testing, this device was set
to transmit at its highest certified power level in all tested
frequency bands, and placed in positions that simulate RF
EN-2
exposure in usage against the head with no separation,
and near the body with the separation of 0 mm. Although
the SAR is determined at the highest certified power level,
the actual SAR level of the device while operating can be
well below the maximum value. This is because the phone
is designed to operate at multiple power levels so as to use
only the power required to reach the network. In general,
the closer you are to a wireless base station antenna, the
lower the power output.
The exposure standard for wireless devices employing a
unit of measurement is known as the Specific Absorption
Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.
This device is complied with SAR for general population /
uncontrolled exposure limits in ANSI/IEEE C95.1-1992
and had been tested in accordance with the measurement
methods and procedures specified in IEEE1528. This
device has been tested and meets the FCC RF exposure
guidelines when tested with the device directly contacted
to the body.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and
can be found under the Display Grant section of www.fcc.
gov/oet/ea/fccid after searching on FCC ID: A2HW1166.
For this device, the highest reported SAR value for usage
against the body is 0.599 W/kg. While there may be
differences between the SAR levels of various phones
EN-3
and at various positions, they all meet the government
requirements. SAR compliance for body-worn operation
is based on a separation distance of 0 mm between the
unit and the human body. Carry this device at least 0
mm away from your body to ensure RF exposure level
compliant or lower to the reported level. To support bodyworn operation, choose the belt clips or holsters, which do
not contain metallic components, to maintain a separation
of 0 mm between this device and your body. RF exposure
compliance with any body-worn accessory, which contains
metal, was not tested and certified, and use such bodyworn accessory should be avoided.
Warning: the AC adapter is used as disconnect device
and it should remain readily operable during intended
use. In order to disconnect the mains plug from mains
completely, the AC adapter should be disconnected from
the mains socket outlet completely.
Caution: Use of controls or adjustments or performance
of procedures other than those specified may result in
hazardous radiation exposure.
Service Information
This product should be serviced only by those specially
trained in appropriate servicing techniques. For instructions
on how to obtain service, refer to the warranty included in
this guide.
EN-4
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND
SAVE THIS FOR FUTURE REFERENCE
Some of the following information may not apply to your
particular product; however, as with any electronic product,
precautions should be observed during handling and use.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
•
Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
• Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
• Only use attachments / accessories specified by the
manufacturer.
• Unplug this apparatus during lightning storms or
when unused for long periods of time.
EN-5
• Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INFORMATION
• The AC adapter and apparatus shall not be exposed
to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the
apparatus.
• Always leave sufficient space around the product for
ventilation. Do not place product in or on a bed, rug,
in a bookcase or cabinet that may prevent air flow
through vent openings.
• Do not place lighted candles, cigarettes, cigars, etc.
on the product.
• Care should be taken so that objects do not fall into the
product.
• Do not attempt to disassemble the cabinet. This product
does not contain customer serviceable components.
• To prevent the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
• Do not play your headset at high volume. Hearing
experts warn against extended high-volume play.
EN-6
Contents
Safety Precautions .....................................................1
Important Safety Instructions ................................... 5
Startup ..................................................................... 8
Overview of Controls ........................................................ 6
Keyboard ................................................................ 10
Accessory ................................................................... 11
Connections ............................................................. 12
Battery Management and Charging ............................... 12
USB ..............................................................................14
Micro SD ........................................................................14
HDMI .............................................................................. 15
Headphone ..................................................................... 15
Using your Tablet ....................................................... 16
Turning your Tablet on ....................................................... 16
Turning your Tablet off ...................................................... 17
Using the Touchscreen...................................................... 19
Windows Start Screen ............................................... 21
Action Center .................................................................. 24
Tablet Mode Screen .......................................................... 27
Customizing Apps ............................................................ 29
Connecting to a Wi-Fi Network ............................... 30
Bluetooth ............................................................ 31
Synchronizing your Tablet .......................................... 31
Recovery your Tablet ......................................................... 32
Additional Information ............................................ 33
Trouble Shooting .................................................... 33
Copyright and Trademark Notices .................................. 34
Specifications .................................................................. 35
Limited Warranty ..................................................... 36
EN-7
Startup
Overview of Controls
MIC (microphone)
HDMI port
DC 5V
Micro-USB / Charging*
Headphone jack
Power button
/ Standby
USB port
Windows button
Press to open/close
the Windows Start
screen.
Connector
Volume adjustment bar
EN-8
Micro SD card slot
Rear camera
Volume+/- button
Item Description
Microphone For voice input.
HDMI port Connect to a TV or a display device.
DC jack Connect with 5V DC charger.
Micro-USB port Use to charge the tablet's battery.
For charging at either OFF mode or
Standby mode.
Headphone jack Headphone connection for personal
listening.
Power button Press to enter standby/wake up mode,
press and hold to switch On/Off the unit.
USB port Connect to a USB storage device or a
mouse or a wired keyboard.
Connector Use to connect the keyboard.
Micro SD card slot Accepts micro SD card (up to 128GB).
Volume +/- button Press to increase/decrease the volume.
Windows
button Press to open/close the Windows Start
screen.
EN-9
Keyboard
Overview
Connector
Use to connect the tablet
to keyboard.
Keys
Windows key
Press to open/close
Remove tablet from keyboard
the Windows Start
screen.
Touch pad
EN-10
Tablet docking
There are two ways to dock the tablet onto the keyboard.
or
NOTE
The keyboard connects to the tablet via the Connector. When
the connection is successful:
• If the tablet is in PC mode, it will automatically adjust its
settings to use the keyboard.
• If the tablet is in Tablet mode, the message box "Do you
want to exit tablet mode?" will display on the bottom of
the screen. Choose "Yes" or "No" to proceed.
Accessory
The following accessory is included.
AC Adapter ....................................................................................................x1
EN-11
Loading...
