SAFETY PRECAUTIONS SAFETY PRECAUTIONS

REMOTE CONTROL

37” 2.1-CHANNEL

SOUNDBAR

Model: BWA18SB001

PRODUCT GUIDE

FCC Information

This device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions:

(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference

that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the

TM

limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING:

• Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment.

• The AC adapter is used as disconnect device and it should remain
readily operable during intended used. In order to disconnect the unit
from the mains completely, the AC adapter should be disconnected
from the mains socket outlet completely.

• The AC adapter of unit should not be obstructed OR should be easily
accessed during intended use.

• Minimum 10 cm (4 inches) distances around the unit for sufficient
ventilations.

• The ventilation should not be impeded by covering the ventilation
openings with items such as newspaper, table-cloths, curtains, etc.

• No naked flame sources such as lighted candles should be placed on
the unit.

On Safety

• Should any objects or liquids fall into the unit, disconnect the power
supply and have the unit checked by qualified personnel before any
further operation.

• The unit shall not be exposed to dripping or splashing and that no
objects filled with liquid, such as vases, shall be placed on the unit.

On Use

Never use the unit where it would be subject to:

- Heat sources such as radiators or air ducts.

- Direct sunlight.

WARNING - DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD.

• The remote control supplied with this product contains a coin/button
cell battery. If the coin/button cell battery is swallowed, it can cause
severe internal burns in just 2 hours and can lead to death.

• Keep new and used batteries away from children. If the battery
compartment does not close securely, stop using the product and keep
it away from children.

• If you think batteries might have been swallowed or placed inside any
part of the body, seek immediate medical attention.

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated

with minimum distance 20cm between the radiator & your body

Using the Remote Control

• Point the remote control at the
REMOTE SENSOR located on the
unit.

• When using this unit in very bright
light, the infrared REMOTE SENSOR
may not work properly.

Remove the plastic sheet
before operating the
remote control.

To Change Remote Battery

1. Open the battery door.

2. Insert one CR2025 (3V) size
battery.

Battery Replacement

When the battery becomes weak, the operating distance of the remote
control will be greatly reduced and you will need to replace the battery.
Note: If the remote control is not going to be used for a long time, remove
the battery.

WARNING:

• Do not dispose of the battery in a fire or it may leak and/or explode.

• Batteries should not be exposed to excessive heat such as sunshine,
fire or the like.

CAUTION:

• Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type.

Ver.00 Rev.02/05/18 Ver.00 Rev.02/05/18 Ver.00 Rev.02/05/18 Ver.00 Rev.02/05/18

USING OF AC ADAPTER

Connect the included AC adapter to the Soundbar and the wall outlet.
Using an AC adapter other than the one supplied with the unit may
damage the unit.

AC adapter

Caution:

• Before use, ensure the rated voltage of the adapter matches your local
voltage.

• The included AC adapter is for use with this unit only. Do not use it with
other equipment.

• If you are not going to use the unit for a long time, disconnect the AC
adapter from the wall outlet.

• Whenever the AC adapter is plugged in to a wall outlet, the AC adapter
will draw some power, even when the Sound Bar is turned off.

ACCESSORIES

Please locate the included accessories.

Remote control with battery ............................ x 1

AC power adapter ............................................x 1

LOCATION OF CONTROLS LOCATION OF CONTROLS

Soundbar

1. Standby/ON button

2. SOURCE

3.

VOLUME button

4.

VOLUME button

5. OPTICAL IN Jack

6. LINE IN 3.5mm Jack

7. AUX IN R / L Jack

8. COAXIAL IN Jack

9. DC IN Jack

button

- 1 -

10. BLUETOOTH LED Indicator

AUX IN LED Indicator

DIGITAL IN

1. OPTICAL IN LED indicator
will illuminate when selected

2. COAXIAL IN LED indicator
will flash slowly when selected

LINE IN LED Indicator

11. Remote Sensor

- 5 -- 4 -

Remote Control

button

1.

2. AUX button

3. LINE IN button

4.

/ / button

5. PRESET EQ buttons

- STANDARD

- TALKS

- MOVIE

- MUSIC

- 2 -

6. OPTICAL button

7.

MUTE button

8. BLUETOOTH (BT)

9. COAXIAL button

10.

SOURCE button

11. VOL

- 6 -

/ button

- 3 -

BASIC OPERATION

1. Press button on the Soundbar or button on the remote to turn on
the unit.

2. Press SOURCE button on the Soundbar or remote to select AUX IN,
OPTICAL IN, COAXIAL IN, LINE IN or Bluetooth source (input). The
LEDs located on top of Soundbar will indicate the currently-selected

source, for COAXIAL IN, the LED indicator will flash slowly when
selected.

3. Press the preset EQ buttons on the remote control (STANDARD, TALKS,
MOVIE and MUSIC) to obtain your desired sound effect.

Note: When mute is enabled, the 4 LED indicators will flash. Press the
MUTE button on the remote control to disable the mute function and LED
flashing stop.

button

- 1 -

SYSTEM CONNECTIONS SYSTEM CONNECTIONS SYSTEM CONNECTIONS SYSTEM CONNECTIONS

Hear Audio from a TV/Blu-ray Player/DVD Player or Set Top
Box

A. Connect an Audio Cable (not included) from the AUX IN jacks to the

AUDIO OUT jacks of your TV, Set-Top Box or Blu-ray/DVD Player.

Then press AUX button on the remote or SOURCE button on the

Soundbar to select AUX IN mode.

B. Connect an Optical Cable (not included) from the OPTICAL IN jack to

the OPTICAL OUT jack of your TV, Set-Top Box or Blu-ray/DVD Player.

Then press DIGITAL button once on the remote or SOURCE button on

the Soundbar to select DIGITAL IN mode.

C. Connect a COAXIAL Cable (not included) from the COAXIAL IN jack to

the COAXIAL OUT jack of your TV, Set-Top Box or Blu-ray/DVD Player.

Then press DIGITAL button twice on the remote or SOURCE button on

the Soundbar to select DIGITAL IN mode.

Play other devices

D. Plug one end of a 3.5mm Audio Cable (not included) into the LINE IN

jack and other end into your MP3 or other audio sources.

Then press LINE IN button once on the remote or SOURCE button on

the Soundbar to select LINE IN mode.

The AUX IN LED indicator located on top of Soundbar will illuminate. The OPTICAL IN / COAXIAL IN LED indicator located on top of Soundbar

will illuminate.

Note: OPTICAL IN only supports PCM signal. You may need to activate
PCM (Downmix) on your source device, e.g. TV, Set-Top Box or Blu-ray/
DVD Player.

- 8 -

Ver.00 Rev.02/05/18

PLAYBACK VIA BLUETOOTH® ENABLED DEVICES

Before Bluetooth pairing, you should turn on the Bluetooth function of
your Bluetooth® enabled device (such as, mobile phone with Bluetooth
function).

1. Press SOURCE button on the unit or
to select BT (Bluetooth) mode. The Bluetooth indicator light on the
soundbar will blink.

2. On your device (mobile phone, MP3 player, etc.), select “ON70
Soundbar” from the list of available Bluetooth connections.

Note: If your Bluetooth device (such as, mobile phone) requires a password
while pairing, please enter 4-digit number: 0000.

• If the Bluetooth pairing is successful, the Bluetooth indicator will
illuminate.

• If the Bluetooth pairing is unsuccessful, the Bluetooth indicator will blink
at slow speed. Please try again.

To disconnect the currently paired device

1. On your currently paired and connected device, select “ON70 Soundbar”
from the list and disconnect it. Or

2. Turn off the connected device.

button on the remote control

TROUBLESHOOTING

The unit does not switch on.

• Make sure it is plugged in.

• Press STANDBY/ON button to turn on the Soundbar.

I have no sound.

• Press the VOLUME / button on the top of the Soundbar or VOL
/ button on the remote.

• Ensure the source you’ve selected is outputting audio. If you’re using
“audio out” from your TV, ensure your TV is configured to output audio
(see TV’s menu settings).

• Ensure your AV connections are properly made (ensure you don’t have
any loose connections).

• Ensure you’ve selected the correct source (input) - the LEDs located
on the top of the Soundbar will indicate the currently-selected source
(input).

• Mute is activated (the 4 LEDs on top of the Soundbar flashes). Press the
mute button on the remote control.

• Ensure the input source is selected PCM output on the setup menu of
the input device.

Cannot setup Bluetooth pairing

• Reset the bluetooth connection by turning off and on your connecting
device, or this Soundbar, or select other SOURCE on this Soundbar

- 9 -

Ver.00 Rev.02/05/18

then back to BT mode again.

The remote control doesn’t work

• If battery is weak, please replace the battery and ensure the new battery
is installed correctly.

• Please ensure there is nothing blocking the remote sensor on the front
of the Soundbar.

As concerns grow about the environmental impact of outdated
electronic products, Venturer Electronics is committed to being a
part of the solution. Free of charge, Venturer Electronics customers
can return qualifying units to us for recycling. For more details,
please visit our website at www.venturer.com/recycle.

Specifications and external appearance are subject to change without notice.

- 12 -

Ver.00 Rev.02/05/18

- 13 -

Ver.00 Rev.02/05/18

The OPTICAL IN / COAXIAL IN LED indicator located on top of Soundbar
will flash slowly.

- 10 -

Ver.00 Rev.02/05/18

LIMITED WARRANTY LIMITED WARRANTY

VENTURER ELECTRONICS (“VENTURER”) makes the following limited warranty.
This limited warranty extend to the original consumer purchaser and is limited to
non-commercial use of the product.

Ninety (90) Day Parts & Labor Warranty

Venturer products purchased in the United States are warranted to be free from defects
in materials or workmanship for a period of ninety (90) days from the date of their
original retail purchase. If the unit fails to conform to this warranty, we will service the
product using new or refurbished parts and products, at VENTURER’s sole discretion.
During a period of ninety (90) days from the effective warranty date, VENTURER
will provide, when needed, service labor to repair a manufacturing defect at its
designated Service Center. To obtain warranty service in the United States, you
must first contact our Customer Support Center at www. venturer.com. The
determination of service will be made by VENTURER Customer Support. PLEASE
DO NOT RETURN YOUR UNIT TO VENTURER WITHOUT PRIOR AUTHORIZATION.
New or remanufactured replacements for defective parts or products will be
used for repairs by VENTURER at its designated Service Center for ninety (90)
days from the effective warranty date. Such replacement parts or products are
warranted for an additional ninety (90) days from the date of repair or replacement.
The Customer will be required to ship the unit to the Service Center indicated at the
time Customer Support is contacted to make the necessary repairs. The customer
is responsible for all transportation charges to the service facility.

Packaging and Shipping Instruction

When you send the product to the VENTURER service facility you must use
the original carton box and packing material or an equivalent as designated by
VENTURER.
Your Responsibility
(1) You must retain the original sale receipt to provide proof of purchase.
(2) These warranties are effective only if the product is purchased and operated in

the U.S.A. or Canada.

(3) Warranties extend only to defects in material or workmanship, and do not extend

to any product or parts which have been lost or discarded, or damage to product
or parts caused by misuse, accident, improper operation or maintenance, or use
in violation of instructions provided with the product, or to product which has
been altered or modified without authorization of VENTURER, or to products or
parts thereof which have had the serial number removed or changed.

- 14 -

Ver.00 Rev.02/05/18

The LINE IN LED indicator located on top of Soundbar will illuminate.

- 11 -

Out of Warranty

In the event your product requires repair after the limited warranty period has
expired, please contact our Customer Support Center at www.venturer.com
Important: You are responsible for any transportation, shipping or insurance
relative to the return of product to our Product Returns Center.

All warranties implied by state law, including the implied warranties of
merchantability and fitness for a particular purpose, are expressly limited to
the duration of the limited warranties set forth above. With the exception of any
warranties implied by state law as hereby limited, the foregoing warranty is exclusive
and in lieu of all other warranties, guarantees, agreements and similar obligations
of manufacturer or seller with respect to the repair or replacement of any parts.
In no event shall VENTURER be liable for consequential or incidental damages.
No person, agent, distributor, dealer or company is authorized to change,
modify or extend the terms of these warranties in any manner whatsoever. The
time within action must be commenced to enforce any obligation of VENTURER
arising under the warranty or under any statute, or law of the United States or
any state thereof, is hereby limited to ninety (90) days from the date of purchase.
This limitation does not apply to implied warranties arising under state law.
This warranty gives you specific legal rights and you may also have other rights, which
may vary from state to state.Some states do not allow limitations on how long an
implied warranty lasts, when an action may be brought, or the exclusion or limitation of
incidental or consequential damages, so the above provisions may not apply to you.

For more information on other products and services, please visit our website
www.venturer.com or email address [e-mail]
Important: Also keep your “Bill of Sale” as proof of purchase.

Model no. ............................................ Product name .............................................

Type of set. .......................................... Serial no ......................................................

Invoice no. ........................................... Date purchased .........................................

Dealer name .............................................................................................................

FOR SERVICE AND REPAIR, PLEASE VISIT
Email address: [e-mail]
Website: www.venturer.com

Printed in China

- 15 -

Ver.00 Rev.02/05/18

Ver.00 Rev.02/05/18
