Alco Electronics RS3697BL User Manual

CD6697BL

USER MANUAL

MANUEL DE L’UTILISATEUR

MANUAL DE USUARIO

English (EN)

Español (E)

Français (F)

Scan for more user manual details
Lea para obtener más detalles sobre el manual del usuario
Scanner pour détails supplémentaires indiqués dans le manuel d’utilisation

CAUTION

INVISIBLE LASER RADIATION

WHEN OPEN AND INTERLOCKS DEFEATED.

AVOID EXPOSURE TO BEAM.

RADIACIÓN LÁSER INVISIBLE EN CASO DE

APERTURA Y DESBLOQUEO DE CIERRE.

EVITE CUALQUIER EXPOSICIÓN AL RAYO.

RADIATION LASER INVISIBLE, SI L’APPAREIL

VERROUILLAGE EST NEUTRALISÉ.ÉVITER

PRECAUCIÓN

MISE EN GARDE

EST OUVERT ET SI LE DISPOSITIF DE

L’EXPOSITION AU FAISCEAU LASER.

CLASS 1 LASER PRODUCT

PRODUCTO LÁSER CLASE 1

APPAREIL À LASER DE CLASSE 1

This product contains a low
power laser device.

Este producto contiene un
dispositivo láser de baja potencia.

Cet appareil contient un dispositif
à laser de faible puissance.

Double insulation when

servicing use only identical

replacement parts.

Doble aislamiento. Al reparar

sólo use piezas idénticas de

repuesto.

Double isolation; en cas de

réparation, utilisez seulement

des pièces de rechange

identiques

Es importante leer este manual antes de usar por vez primera su equipo.
Il est important de lire ce manuel d’utilisation avant l’utilisation initiale de ce nouveau produit.

RS3697BL_IB_r.indd 1 2014/4/23 17:20:11

EN

SAFETY PRECAUTIONS

* SEE MARK ING ON REAR OF PRODUCT *

WARNING:

• TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE

UNIT TO RAI N OR MOISTURE.

• TO AVOID ELECTRICAL SHOCK, DO NOT OPEN THE CABINET.

REFER SERVICI NG TO QUALIFIED PERSONNEL ON LY.

• THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR

SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUID,
SUCH AS VASES, SHALL B E PLACED ON THE APPARATUS.

FCC STATEMENTS

This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) This device must
accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician
for help.

WARNING: Changes or modifications not expressly
approved by th e party respo nsible for complianc e could void
the user’s authority to operate the equipment.

For Customers in Canada

This device complies with Industry Canada License-exempt
RSS-210. Operation is su bject to the foll owing two conditi ons:
(1) this device may not cause interference, and (2) this device
must accept any interference, including interference that
may cause undesired operation of the device.
This appar atus complies with the Cl ass B limits for radio n oise
emission set out in radio interference regulations.
FCC RF Radiation Ex posure Statement
Caution: To maintain compliance with the FCC’s RF exposure
guidelines, place the CD Audio System at least 20cm from
nearby persons.

CAN ICES-3 (B) / NMB-3 (B)

Warnings:

• The AC power plug is used as disconnect device and it

should remain readily operable during intended used.
In order to disconnect the apparatus from the mains
completely, the AC power plug should be disconnected
from the mains socket outlet completely.

• The mains plug of apparatus should not be obstructed OR

should be easily accessed during intended use.

• Minimum 10 cm (4 inches) distances around the apparatus

for sufficient ventilations.

• The ventilation should not be impeded by covering the

EN - 2

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to aler t the user to the

presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient magnitude to
constitute a risk of ele ctric shock to per sons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accomp anying the appliance .

ventilation openings with items such as newspaper, table­cloths, curtains, etc.

• No naked flame sources such as lighted candles should be

placed on the apparatus.

On Safety

As the laser beam used in this compact disc player could
be harmful to the eyes, do not attempt to disassemble the
casing. Refer servicing to qualified personnel only.

• Do not put any foreign objects in the disc compartment.

If you do so, the laser beam interlock may be defeated
allowing the laser to remain on when the lid is opened.

• Should any objects or liquids fall into the unit, disconnect

the power supply and have the unit checked by qualified
personnel before any further operation.

On Operation

Since the CD system offers a wide dynamic range, the peaks
of the high level inputs are recorded with high fidelity, and
the noise level is very low. Do not turn up the volume while
listening to a part of the disc with no audio signals or very
low level inputs. If you do so, the speakers may be damaged
when the peak level of the sound is played. The lens of the
laser should be kept clean. Do not touch the lens. If you do
so, the lens may be damaged and the unit will not operate
correctly.

On Use

Never use the unit where it would be subject to:

- Heat sources such as radiators or air ducts.

- Direct sunlight.

- Excessive dust.

- Moisture or rain.

- Mechanical vibration or shock .

- Uneven surface.

• Do not place any heavy objects on top of the unit.

• When the unit is used with an AC power plug, do not wrap

the unit in a clo th, blanket, etc. I f you do so, the temper ature
inside and outside the unit may rise considerably, resulting
in malfunctioning of the unit.

• If the unit is brought directly from a cold to a warm

location, or is placed in a very damp room, the moisture
may condense o n the lens inside the uni t. Should this occur,
the unit will not operate. In this case, remove the disc and
leave the unit in a warm place for several hours until the
moisture evaporates.

• For the unit to operate at its best, it should not be subject to

temperatures below 41°F (5°C) or above 95°F (35°C).

Additional safety information

• Apparatus shall not be exposed to dripping or splashing

and no objects filled with liquids, such as vases, shall be
placed on the apparatus.

• Always leave suf ficient space around the product for

ventilation. Do not place product in or on a bed, rug, in a
bookcas e or cabinet that may pre vent air flow throug h vent
openings.

• Do not place lighted candles, cigarettes, cigars, etc. on the

product.

• Connect power plug only to AC power source as marked on

the product.

• Care should be taken so that objects do not fall into the product.

• Do not attempt to disassemble the cabinet. This product

does not contain customer serviceable components.

RS3697BL_IB_R.indd 2 2014/5/26 12:03:13

EN

EN

7
8
9

10
11

12

13

1
2
3
4
5

6

IMPORTANT SAFETY

LOCATION OF CONTROLS

INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.

8. Do not install n ear any heat sources such as ra diators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

10. Protect the power plug from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.

11. Only use attachments/accessories specified by the
manufacturer.

12. Use only with a cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injur y from tip-over.

13. Unplug this apparatus during lightening storms or when
unused for a long period of time.

14. Refer all servicing to qualified service personnel. Servicing

is required when the apparatus has been damaged in any
way, such as the power-supply cord or plug is damaged,
liquid has sp illed or objects h ave fallen into the appara tus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.

Portable

Cart

Warning

1

2

3

4

5

1. CD Door

2. / TUNE – button
/ TUNE + button

PLAY/PAIR button

STOP button

OPEN / CLOSE button

3. LCD DISPLAY

4. USB port
(for charging only)

5. VOLUME control

6. Bluetooth® indicator

7. Remote sensor
STANDBY/ON button

8.

/ PRESET EQ button
/ MEM.UP button

PROG/MEM button

SOURCE button

9. Line in jack

6
7
8

9

REMOTE CONTROL

1. STANDBY/ON button

2. SLEEP button

3.

/ PROG/MEM button

4. RANDOM button

5.

/MEM.UP button

6.

STOP button

7.

/ PRESET EQ button

8. TIMER button

9. SOURCE button

10. PAIR button

11.

/ / TUNE – / + button

12. VOLUME +/– buttons

13.

PLAY/PAUSE button

WARNING
DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD.

The remote control supplied with this product contains a coin/button cell battery. If the coin/button cell battery is
swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the
product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.

RS3697BL_IB_R.indd 3 2014/5/26 12:03:13

BATTERY REPLACEMENT

When the battery becomes weak, the operating distance
of the remote control is greatly reduced and you will
need to replace it.

Remove the plastic sheet before
operating
the remote
control.

NOTE : If the remote control is not going to be used for
a long time, remove the battery to avoid damage caused
by battery leakage corrosion.
WARNING : Do not dispose of battery in fire; battery may
explode or leak.
Batteries should not be exposed to excessive heat such
as sunshine, f ire or the like.
CAUTION : Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.

EN - 3

1.

2.

EN

SYSTEM CONNECTIONS

SPEAKER CONNECTIONS

Connect the speakers to the R terminal and the L terminal.

NOTE : Connecting speakers other than the speakers supplied with the unit may damage the unit.

CAUTIONS:

• Ensure that the power supply in your house complies with that indicated on the identification sticker located

on the back of your unit. (AC 120V ~ 60Hz).

• If you are not going to use the unit for a long time, disconnect the AC power plug from the wall outlet.

• This unit is designed for continuous use. Switching off the unit to standby mode does not disconnect it

from the power supply. To completely isolate the equipment, remove the plug from the wall outlet as some
components remain connected to the electrical supply.

• Topreventelectricalshock,matchwidebladeofplugtowideslotofwalloutlet,thenfullyinsert.

CHARGE YOUR SMARTPHONE/TABLET

You can charge your smartphone/tablet through the USB socket with a USB cable (not supplied).
Connect a USB cable (not supplied) to the USB socket on the front of the unit and the dock connector on your
smartphone/tablet.

LINE IN CONNECTION

You can connect audio devices such as your CD player or MP3 player to the unit via the LINE IN jack. To do this,
connect an audio cable from the line out or headphone out jack of the other audio device to the LINE IN jack on
the front of unit. Press the SOURCE button to switch to AUX mode.

Note : We recommend you unplug the device from the LINE IN jack when not in use.

CLOCK SETTING

Setting the clock can only be done in STANDBY mode.

• If the unit is plugged in with the supplied AC adapter and the unit is in standby mode.

1. Press and hold the /PROG/MEM button until the hour digits blink.

2. Press the or button to adjust the desired hours and press the /PROG/MEM button once to confirm,

then the minute digits blink.

3. Press the or button to adjust the desired minutes and press the /PROG/MEM button once to start

clock.

LISTENING TO THE RADIO

Press the SOURCE button to switch to TUNER mode.

Searching for a Station Automatically

• Press and hold the or button until the tuner starts searching for a station, then release. After tuning in
a station, the search stops.

Presetting Stations

1. Tune in to a desired station. Press the /PROG/MEM button.

2. The preset number will blink and the “MEM” indicator will be shown on the display.

3. Press the /MEM.UP button to select the preset number.

4. Press the /PROG/MEM button again to store it in memory.

Tuning in to a Preset Station

Press the /MEM.UP button to select a preset number.
Note : Do not connect the FM antenna to an outside antenna.

When the reception is good, the “

RS3697BL_IB_R.indd 4 2014/5/26 12:03:13

” icon will appear on the display.

EN - 4
