Alcatel 5005R User Guide

User Guide

Some of the contents in this manual may differ from your phone depending on the software of the phone. Actual color may vary. Your phone is designed to make it easy for you to access a wide variety of content. For your protection, we want you to be aware that some applications that you enable may involve the location of your phone being shared. For applications available through Cricket, we offer privacy controls that let you decide how an application may use the location of your phone and other phones on your account. However, the Cricket privacy tools do not apply to applications available outside of Cricket. Please review the terms and conditions and the associated privacy policy for each location-based service to learn how location information will be used and protected. In addition, your Cricket phone may be used to access the internet and to download, and/or purchase goods, applications, and services from Cricket or elsewhere from third parties. Cricket provides tools for you to control access to the Internet and certain Internet content. These controls may not be available for certain devices which bypass Cricket controls. © 2019 Cricket Wireless LLC. All rights reserved. Cricket and the Cricket logo are registered trademarks under license to Cricket Wireless LLC. Other marks are the property of their respective owners. microSD logo is a trademark of SD-3C, LLC. Alcatel is a trademark of Nokia used under license by TCL Communication Technology Holdings Limited. INSIGHT is a trademark of TCL Communication Technology Holdings Limited. © 2019 TCT Mobile Limited. All rights reserved. TCL Communication Technology Holdings Limited reserves the right to alter material or technical specification without prior notice. All "Signature" ringtones embedded in this phone have been composed, arranged and mixed by NU TROPIC (Amar Kabouche).

This device meets applicable national SAR limits of

1.6 W/kg. When carrying the device or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 15 mm from the body to ensure compliance with RF

www.sar-tick.com

exposure requirements. Note that the product may be transmitting even if you are not using it.

Table of contents

Getting started ................................................................................................5

Phone setup ............................................................................................................. 5

Extending the battery life.........................................................................................8

Powering your phone on/off ................................................................................... 8

Getting around ...................................................................................................... 10

Getting to know your phone ................................................................................. 11

Key functions .......................................................................................................... 12

Phone calls ...................................................................................................22

Making calls ........................................................................................................... 22

Receiving calls ....................................................................................................... 24

Adjusting your phone settings .............................................................................. 27

Contacts........................................................................................................30

Importing and exporting contacts ....................................................................... 30

Sharing contact information ................................................................................. 30

Creating a contact ................................................................................................ 31

Adding a contact to Favorites .............................................................................. 31

Searching for a contact ........................................................................................ 31

Linking contacts ..................................................................................................... 32

Unlinking contacts ................................................................................................. 32

Messaging .....................................................................................................33

Opening the messaging screen ........................................................................... 33

Sending a message .............................................................................................. 33

Replying to a message.......................................................................................... 34

Forwarding a message ..........................................................................................34

Changing message settings ................................................................................. 34

Email ..............................................................................................................35

Setting up the first email account ........................................................................ 35

Checking your emails ............................................................................................ 35

Responding to an email ........................................................................................ 36

Writing and sending an email .............................................................................. 37

Adding and editing email accounts ................................................................... 37

Changing general email settings ......................................................................... 38

Connecting to the Internet ...........................................................................39

Connecting to a Wi-Fi network .............................................................................. 39

Adding a Wi-Fi network .......................................................................................... 40

Checking the Wi-Fi network status ........................................................................ 40

Connecting to virtual private networks ................................................................ 41

Browsing the Internet ....................................................................................43

Opening a webpage or searching the web ....................................................... 43

Using multiple browser tabs .................................................................................. 43

Switching between tabs ........................................................................................ 44

Setting the home page ......................................................................................... 44

Downloading files .................................................................................................. 44

Changing browser settings ................................................................................... 45

Mobile Hotspot & Tethering .......................................................................... 46

Share your phone's data connection via USB ..................................................... 46

Share your phone's data connection as a portable Wi-Fi hotspot .................... 46

Rename or secure your portable Wi-Fi hotspot ................................................... 46

Using Wi-Fi Direct ...........................................................................................47

Connecting to another device via Wi-Fi Direct .................................................... 47

Bluetooth .......................................................................................................48

Turning Bluetooth on/off ........................................................................................ 48

Changing the device name ................................................................................. 48

Pairing with another Bluetooth device ................................................................. 49

Unpairing from a Bluetooth device ...................................................................... 49

Sending data via Bluetooth .................................................................................. 50

Receiving data via Bluetooth ................................................................................ 50

Entertainment ................................................................................................51

Capturing a photo ................................................................................................ 51

Adjusting camera settings .................................................................................... 52

Recording a video ................................................................................................. 53

Using your photos .................................................................................................. 54

Applications ..................................................................................................56

Google Apps .......................................................................................................... 56

Calculator ............................................................................................................... 57

Clock ....................................................................................................................... 57

Downloads ............................................................................................................. 58

Phone settings ..............................................................................................59

Network & internet ................................................................................................. 59

Connected devices ............................................................................................... 60

Apps & Notifications .............................................................................................. 60

Battery ..................................................................................................................... 61

Display .................................................................................................................... 61

Sound ..................................................................................................................... 62

Storage ...................................................................................................................62

Security & location ................................................................................................. 63

System ..................................................................................................................... 65

Troubleshooting ............................................................................................69

For your safety ...............................................................................................72

General safety ........................................................................................................ 72

FCC RF Exposure Information (SAR) .....................................................................73

FCC compliance ................................................................................................... 74

Hearing Aid Compatibility (HAC) regulations for mobile phones ...................... 76

CTIA ........................................................................................................................ 78

Distraction ............................................................................................................... 79

Product handling ................................................................................................... 79

Electrical safety ...................................................................................................... 82

Interference ............................................................................................................ 83

Explosive environments.......................................................................................... 85

Specifications ...............................................................................................86

12 month limited warranty ...........................................................................87

Electronic Recycling .....................................................................................90

Battery Recycling (USA & Canada) ..................................................................... 90

Getting started

Phone setup

Installing the NANO SIM card

You must insert your SIM card to make phone calls. You do not need to power off your phone before inserting or removing the SIM card since this phone supports hot swap.

1. Remove the back cover by gently pulling up on the indentation on the bottom left of the cover.

2. Insert the SIM card and microSDTM card as shown in the illustration below.

Micr o SD

SIM

3. Ensure that SIM and microSDTM cards have been properly secured.

Micro SD

SIM

Note: microSDTM card sold separately.

WARNING: To avoid damage to the phone, only use a standard NANO SIM

card provided by your service provider.

Some applications may require a microSDTM card to work normally or to store data. Therefore, it is recommended that you keep a microSDTM card installed.

Charging the battery

Your phone’s battery should have enough power for the phone to power on, acquire a signal, and place several calls. You should fully charge the battery as soon as possible.

When the battery is low, a low-battery warning icon will appear on the screen.

If the battery is extremely low, you may be unable to power on the phone even when it is being charged. In this case, try again after charging the phone for at least 10 minutes.

1. Insert the charger’s connector into the charging port. Be sure to insert the connector in the correct orientation. Do not force the connector into the port.

2. Plug the charger into a standard AC wall outlet.

3. When the battery is fully charged, unplug the charger and disconnect it from the phone.

WARNING: Only use Alcatel-approved chargers and cables. The use of unapproved accessories could damage your phone.

Extending the battery life

Active applications, screen brightness levels, Bluetooth and Wi-Fi usage, and GPS functionality can drain your battery. Follow the helpful tips below to conserve your battery power:

• Reduce the time before the Sleep Mode function is activated.

• Lower the screen brightness.

• Turn auto-sync, Wi-Fi, and Bluetooth off when not in use.

• Disable the GPS function when not in use. Most applications using this

function will periodically locate the GPS satellites for your current location.

Powering your phone on/off

Ensure that the NANO SIM card is in your phone and the battery is charged.

• Press and hold the Power key to power on your phone.

• To power it off, press and hold the Power key to open the options menu.

Tap Power off.

Setting up your phone for the first time

Follow the steps below to set up your phone for the first time or after a factory reset:

1. Tap the language field to select the language you want to use and then tap START.

2. Connect to a secure and trusted Wi-Fi network, enter the password, and tap CONNECT. To skip, tap SKIP and tap CONTINUE on the pop-up message.

3. You will be prompted to agree to or decline Google Services, such as location and device maintenance, and to read Google's Terms of Service. Make your allowances and tap ACCEPT to continue.

4. Choose a screen lock type Pattern, PIN or Password to prevent others from using your phone.

Switching to Sleep Mode

To save battery power, Sleep Mode suspends your phone in a low-powerconsumption state while the display is off. Your phone also goes into Sleep Mode by itself when the display is automatically turned off after a certain period of time, which you can set by tapping Settings > Display > Sleep from the home screen.

Press the Power key to switch to Sleep Mode.

Waking up your phone

Press the Power key to activate your screen display.

Note: If you have set an unlock pattern, PIN, or password for your phone (see

Settings > Security & location > Screen lock) you’ll need to draw the pattern or enter the PIN/password to unlock your screen.

Getting around

Touch control

Your phone’s touch screen allows you to control actions through a variety of touch gestures.

• Tap: Tap the buttons, icons, or applications to select items or to open

applications.

• Press and hold: To open the available options for an item (such as a

message or link in a web page), press and hold the item.

• Swipe or slide: To scroll or toggle, quickly drag your finger vertically or

horizontally across the screen.

• Drag: To drag, press and hold before you start to move your finger. While

dragging, do not release your finger until you have reached the target position.

• Pinch: In some apps (such as Maps Go, Browser, and Photos), you can

zoom in and out by placing two fingers on the screen and pinching them together (to zoom out) or spreading them apart (to zoom in).

• Rotate the screen: In certain applications, you can automatically change

the screen orientation from portrait to landscape by turning the phone sideways.

Getting to know your phone

Headset port

Light and proximity sensor

Back

Speaker

Camera

Home

Microphone

LED Indicator

Volume keys

Power key

Touch screen

Recent apps

Charging port

Camera

Camera flash/Flashlight

Volume keys

Power key

Key functions

Recent apps key

• Touch to switch between apps and files you've recently opened.

Home key

• From any application or screen, tap to return to the Home screen.

• Press and hold to activate your Google Assistant.

Back key

• Tap to go back to the previous screen, or to close a dialog box, options menu, the Notifications panel, etc.

Power key

• Press: Lock the screen/Light up the screen.

• Press and hold: Show the popup menu to select from Power off/ Restart/Screenshot.

• Press and hold the Power key and Volume down key to capture a screenshot.

• Press and hold the Power key for at least 10 seconds to force restart.

Volume Keys

• Adjust the earpiece or headset volume during a phone call

• Adjusts the media volume while listening to music or a video, or streaming content

• Adjust the ringtone volume.

• Mute the ringtone of an incoming call.

• While using the Camera app, press Volume up or down key to take a photo or press and hold to take several photos.

Customize your Home screen by adding application shortcuts, widgets, folders, and using wallpapers.

Status and notifications bar

Voice search

Google Apps

Favorite apps

Extended home screen

In addition to the main home screen, your phone has extended home screens to provide more space for adding apps, widgets, and more. Once an app or widget is added to the extended home screen, simply swipe your finger to the left or right to access the extended home screen panels.

Choosing your wallpaper

1. Press and hold an empty place on the home screen and tap WALLPAPERS.

2. Tap a wallpaper and tap Set wallpaper. You can also tap My photos to use

a photo as your wallpaper.

3. A popup menu will appear to set the selected wallpaper as image for the Home screen, Lock screen, or both.

Adding items to your home screen

• To add an app to your home screen, swipe up on the home screen to

access all the applications on the phone. Press and hold the desired app, and drag it to the home screen.

• To add a widget to your home screen, press and hold an empty place on

the home screen, then tap SHORTCUTS.

Adjusting widget size

1. Press and hold a widget on the home screen and then release it.

2. When an outline appears around the widget, drag the lines to adjust the size.

Note: Not all widgets can be resized.

Organizing apps with a folder

1. Hold and drag an application over another to create folders.

2. To add more shortcuts into the folder, press and hold each shortcut and drag them over the folder before releasing them.

Removing items from your home screen

1. Press and hold the item you want to delete until X Remove appears at the top of the screen.

2. Drag the item to X Remove and release your finger when the item turns red.

Viewing your apps

Swipe up on the home screen to access all the applications on the phone. You can add apps to your home screen and uninstall or disable them.

Uninstall or disable an application

1. Swipe up on the home screen.

2. Press and hold an application.

3. To uninstall an app, drag it to X Remove and release it.

4. To enable the disabled applications, swipe up on the home screen > Settings > Apps & notifications. Tap the application and tap ENABLE to enable it.

Note: Not all applications can be uninstalled or disabled.

Status and notification icons

Your phone will tell you exactly what’s going on by showing you simple icons. Here’s what they mean.

Status icons

4G connected Speakerphone is on

4G in use Phone microphone is mute

LTE connected No SIM card installed

LTE in use Vibrate mode

Connected to a Wi-Fi network Battery is very low

Airplane mode Battery is low

Signal strength Battery is partially decreased

No signal Battery is full

Alarm is set Battery is charging

Connected to a Bluetooth device

GPS is on

Notification icons

New email message Portable Wi-Fi hotspot is on

New text or multimedia message

Problem with SMS or MMS delivery

Carrier data use threshold approaching or exceeded

New voicemail Select input method

Upcoming event

Screenshot captured

Both USB tethering and portable hotspot are on

USB tethering is on

Missed call

Uploading data

Download finished

An open Wi-Fi network is available

Phone is connected via USB cable

More notifications are hidden

Using the Notifications panel

Touch and drag the Status bar down to open the Notifications panel. Drag down once again to enter the Quick settings panel. When there are notifications, you can tap them to access notifications directly.

Notifications panel

When there are notifications, touch and drag down the Status bar to open the Notifications panel to read more detailed information.

Clear new notifications (ongoing notifications, such as New Voicemail, will remain)

Quick settings panel

Touch and drag the Notifications panel down to open the Quick settings panel. This will allow you to access frequently used settings like Wi-Fi, screen brightness, airplane mode, and others. You can open this panel from anywhere on your device, including your lock screen.

Tap to access Settings, where you can set more items.

Tap EDIT to customize your Quick settings panel.

Protecting your phone with a screen lock, pin, or pattern

You can protect your phone by creating a screen lock. When enabled, you can swipe the screen, draw a pattern, or enter a numeric PIN or password to unlock the phone.

1. From the home screen, swipe up on the home screen > Settings > Security

& location > Screen lock.

2. Tap Screen lock.

3. Tap Swipe, Pattern, PIN, or Password.

• Tap None to disable screen lock.

• Tap Swipe to enable screen lock. Note: you will not need a pattern, PIN, or

password to access the phone

• Tap Pattern to create a pattern you must draw to unlock the screen.

• Tap PIN or Password to set a numeric PIN or a password that you must

enter to unlock your screen.

Phone calls

Making calls

Calling from the dial pad

1. From the home screen, tap .

2. Tap to open the dial pad.

3. Enter the phone number with the on-screen keypad. Tap to delete incorrect digits.

Note: As you enter digits, your phone searches for contacts that match.

If you see the number you want to dial, tap it to place the call immediately without entering the rest of the number.

4. Tap to place the call.

Tip: To make an international call, press and hold the 0 key to enter the plus (+) symbol. Next, enter the country code, followed by the area code, and then the phone number.

Dial a Recent Number

1. From the home screen, tap > .

2. Swipe the screen up or down and tap the contact you want to call.

Tip: You can search for a contact by tapping the search field above the contacts list.

3. Tap the icon before the number then tap to call, or tap the number to call.

Calling from Contacts

1. Swipe up on the home screen, tap .

2. Swipe your finger up or down to scroll through the contacts list, tap the contact you want to call, then tap to call.

Tip: You can search for a contact by tapping the search field above the Contact lists.

Calling from Messaging

1. From Messaging , tap the conversation with the contact you wish to call.

2. Tap at the top of the screen to call that number.

Receiving calls

When the screen is locked

• Press and swipe up to answer an incoming phone

call.

• Press and swipe up to reject an incoming phone

call.

• Tap to set a reminder to call the number back in 5

or 10 minutes.

• Tap to reject the call and select a preset test

message to send to the caller.

When the screen is unlocked

• Tap to answer an incoming phone call.

• Tap to reject an incoming phone call.

Note: To silence the ringtone on an incoming call, press the

volume down key.

Using options during a call

During a call, you will see a number of on-screen options. Tap an option to select it.

• Tap to turn the speaker on or off.

• Tap to mute or unmute your microphone.

• Tap to open the dial pad.

• Tap to put the call on hold.

• Tap to make another call separately from the first call, which is put on

hold.

• Tap to end the current call.

WARNING: Do not place the phone near your ear while the speakerphone is in use.

Managing multi-party calls

When call waiting and three-way calling features are available, you can switch between two calls or set up a conference call.

Note: Call waiting and three-way call features require network support and

may result in additional charges. Please contact your service provider for more information.

Switching between current calls

When you’re on a call, your phone screen informs you that another call is coming in and displays the caller ID.

To respond to an incoming call while you’re on a call:

Press and swipe up to answer the call. This puts the first call on hold and answers the second call. Press and swipe up to reject the second call.

Note: Tap to reject the second call and select a preset text message to

the caller.

To switch between two calls:

Tap or On hold on the screen.

Setting up a conference call

You can make another call while a call is in progress.

1. In the dial pad, enter a number and tap .

2. Once you have established the connection, tap > and dial the second number. This puts the first caller on hold and dials the second number.

3. When you’re connected to the second party, tap .

If one of the individuals on the line hangs up during your call, you and the remaining caller stay connected. If you initiated the call and are the first to hang up, all callers are disconnected.

To end the conference call, tap .

Adjusting your phone settings

From the home screen, tap > > Settings to configure the phone options.

PHONE SETTINGS

Quick responses: Edit quick responses which will be used when you reject a

call with messages.

Dial pad tones: Turn on the switch to enable playing tones when using the dial pad.

Call settings

• Voicemail

Access voicemail service and number settings.

• Fixed Dialing Numbers

Fixed dialing number (FDN) is a SIM service mode, which restricts outgoing calls to a set list of phone numbers. These numbers are added to the FDN list. The most common practical application of FDN is for parents to restrict the phone numbers to which their children can dial. For security reasons, you’ll be prompted to enable FDN by entering SIM PIN2 which is usually acquired from your service provider or SIM maker.

• Wi-Fi calling

Turn on/off Wi-Fi calling to allow your device to make calls over a Wi-Fi network.

• Call forwarding

Configure how your calls are forwarded when unanswered.

• Call barring

Select calls to be barred, cancel call barring, or change barring password.

• Additional settings

Use default carrier settings to display your number in outgoing calls.

Accessibility

• Real Time Text (RTT) Call Button

RTT assists callers who are deaf, hard of hearing, have a speech

disability, or need more than voice alone. Incoming/outgoing speech can be converted to a real-time text messaging when RTT call has been established.

• Hearing aids

Enable hearing aid compatibility.

• Noise reduction

Enable your background noise during calls.

Quick dial: Assign specific numbers to numbers on your dial pad for quick dialing.

CONTACTS SETTINGS

Import/Export: Import or export contacts between phone, SIM card, microSD

card and phone storage.

Merge contacts: Select duplicate contacts to merge.

Manage account: Manage the synchronization settings for different

accounts.

Display options

• Sort by

Set the contacts display by First name or Last name.

• Name format

Set the name format by First name first or Last name first.

Contacts

Add contacts on your phone and synchronize them with the contacts in your Google account or other accounts that support contact syncing.

To see your contacts, swipe up on the home screen, tap . From there, tap the tabs on the top to quickly switch to FAVORITES or ALL CONTACTS.

Importing and exporting contacts

Import/export contacts from/to your NANO SIM card, phone storage, Gmail account, or microSD card. This is especially useful when you need to transfer contacts between different devices. You can also quickly share your contacts using Bluetooth, Gmail, Messaging, and other applications.

1. Swipe up on the home screen, tap .

2. Tap > Settings > Import/Export, then tap to choose copying contacts from Phone, SIM card, Phone storage, Gmail account or microSD card and tap NEXT to choose where the contacts are copied.

To import/export a single contact from/to your SIM card, select the contact you want to import/export and tap the icon to confirm.

To import/export all contacts from/to your SIM card, tap the icon and then the icon to confirm.

Sharing contact information

Share a single contact or contacts with others by sending the contact's vCard to them via Bluetooth, Gmail, etc.

1. From the Contacts screen, tap the contact you want to share, tap > Share.

2. This menu allows you to choose how you would like to share the contacts. Available options will depend on the applications and services installed.

Creating a contact

1. From the Contacts screen, tap to add a new contact.

2. Tap the account field near the top of the screen to choose where to save the contact. If a sync account is selected, the contacts will be synced automatically with your account online.

3. Enter the contact name, phone numbers, email addresses, and other information.

4. Tap to save the contact.

Adding a contact to Favorites

Add the contacts you use frequently to Favorites so that you can find them quickly.

1. From the Contacts screen, tap the contact you want to add to Favorites.

2. Tap .

Searching for a contact

1. Tap above the contacts list.

2. Enter the contact name, phone number or email address you want to find. Matching contacts will be listed.

Linking contacts

As your phone synchronizes with multiple online accounts, you may see duplicate entries for the same contact. You can merge all the separate information of a contact into one entry in the Contacts list.

1. Swipe up on the home screen, tap .

2. Tap a contact to display the contact’s details.

3. Tap > Link.

4. Tap the contact whose information you want to join with the first entry.

The information from the second contact is added to the first, and the second contact is no longer displayed in the contacts list.

Repeat these steps to join another contact to the main contact.

Unlinking contacts

If contact information from different sources was joined in error, separate the information back into individual contacts on your phone.

1. Swipe up on the home screen, tap .

2. Tap a contact you have merged and want to separate.

3. Tap > View linked contacts > SEPARATE

Messaging

Use Messaging to exchange text messages (SMS) and multimedia messages (MMS).

Opening the messaging screen

From the home screen, tap .

The Messaging screen opens, where you can create a new message, search for messages, or open an ongoing message thread.

• Tap to write a new text or multimedia message.

• Tap to search for keywords within a message.

• Tap an existing message thread to open the conversation with a contact,

phone number, or email address.

Sending a message

1. From the Messaging screen, tap at the bottom of the screen.

2. Add recipients by one of the following ways:

• Tap the To field and type the recipient's name, number, or email address. If

the recipient is saved in Contacts, their contact information will appear.

• Select recipients from Contacts by tapping .

3. Tap the Type message field and enter the content of your text message.

4. If you want to send a multimedia message, tap the paper clip icon to

attach a file to the message.

5. Tap to send your message.

Note: Messages sent to email addresses are multimedia messages.

Replying to a message

Messages you receive are added to existing conversation threads with the same recipient. If the new message comes from a new number, a new thread is created.

1. From the Messaging screen, tap the thread that has the message you

want to reply to.

2. Type your reply in the text box at the bottom. You can tap if you want

to reply with an MMS.

3. Tap to send your message.

Forwarding a message

1. From the thread screen, press and hold a message you want to forward.

2. Tap .

3. Enter a recipient for the message and edit the content if you want.

4. Tap to send your message.

Changing message settings

The phone’s message settings are pre-configured for you to use immediately. To change them, tap > Settings from the Messaging screen.

Swipe up on the home screen, tap Gmail. Receive and send emails from your webmail or other accounts using POP3 or IMAP, or access your Exchange ActiveSync account for your corporate email needs.

Setting up the first email account

1. From the Home screen, tap Google, then tap Gmail.

2. Select Take Me to Gmail to setup a Gmail account, or select Add an email address to setup a different email account.

3. Enter your account credentials, such as email address and password. Tap NEXT to continue.

4. Confirm email account settings, tap NEXT.

5. Enter your name which will be displayed on outgoing emails, tap FINISH.

Note: You can also enter these details manually by tapping MANUAL SETUP.

Checking your emails

Your phone can automatically check for new emails at the interval you set when setting up the account.

When you are in an email account, swipe down on the screen to download new emails.

Responding to an email

Reply to or forward a message that you recieve. You can also delete messages and manage them in other ways.

Replying to or forwarding an email

1. Open the email you want to reply to or forward.

2. Choose from the following:

• To reply to the sender, tap .

• To reply to the sender and all recipients of the original email, tap >

Reply all or tap the Reply all button on the keyboard.

• To forward the email to someone else, tap .

3. Edit your message and tap to send.

Marking an email as unread

Return a read email to the unread state—for example, to remind yourself to read it again later. You can also mark a batch of emails as unread.

• While in an email list (for instance, the Inbox), tap the checkboxes next to

the messages and then tap > Mark unread from here.

Deleting an email

You can delete a single email or several emails at once.

• With an email message open, tap .

• While in an email list (such as inbox), tap the checkboxes next to the

messages and then tap .

Writing and sending an email

1. Open your email Inbox and tap .

Note: If you have more than one email account added on the phone, tap

the sender line to select the account you want to use for sending the message.

2. Enter a contact name or email address in the To field. Separate each

recipient with a comma.

Note: Tap > Cc/Bcc to Cc or Bcc other recipients.

3. Enter the email subject and compose the email text.

4. Tap to add audio files, images, videos, and other types of files as an

attachment.

5. Tap to send the message.

Adding and editing email accounts

Adding an email account

After setting up your first email account (see Email – Setting up the first email account), you can add more email accounts and manage them separately.

1. Open Gmail to get to the Inbox screen.

2. Tap > Settings and tap Add account.

3. Follow the prompts to set up your second account.

Editing an email account

Change a number of settings for an account, including how often you check for email, how you’re notified of new emails, your email signature, and details about the servers the account uses to send and receive email.

1. Open Gmail to access your inbox.

2. Tap > Settings and tap the account you want to change.

3. Make the changes and tap when you’re finished.

Changing general email settings

1. General settings apply to all email accounts you add.

2. Open Gmail to get the Inbox screen.

3. Tap > Settings > General settings.

4. Make the changes and tap when you’re finished.

Connecting to the Internet

Your phone’s impressive networking capabilities allow you to access the Internet or your corporate network with ease. You can use default connection settings to connect to the Web via your cellular network or Wi-Fi. The mobile data connection can be enabled/disabled manually. Swipe up on the home screen, tap Settings > Network & internet > Cellular network and enable/disable Mobile data.

Turning on Wi-Fi

Wi-Fi is a wireless networking technology that can provide internet access at distances of up to 100 meters, depending on the Wi-Fi router and your surroundings.

1. Swipe up on the home screen, tap Settings > Network & internet > Wi-Fi.

2. Slide the Wi-Fi switch to the position to turn on Wi-Fi.

Connecting to a Wi-Fi network

1. Swipe up on the home screen, tap Settings > Network & internet > Wi-Fi.

Available Wi-Fi networks and hotspots are displayed with network names and security settings.

2. Tap an access point to connect to it. If security features are implemented,

you’ll need to enter a password.

Note: Your phone automatically connects to previously used Wi-Fi networks

when that network is in range.

Adding a Wi-Fi network

Add a Wi-Fi network if the network does not broadcast its name (SSID), or to add a Wi-Fi network when you are out of range.

To connect to a secure network, you first need to get the security details from the network’s administrator.

1. Swipe up on the home screen, tap Settings > Network & internet > Wi-Fi.

2. Slide the Wi-Fi switch to the position.

3. Tap Add network.

4. Enter the network SSID (name). If necessary, enter security or other network

configuration details.

5. Tap CONNECT.

Checking the Wi-Fi network status

Check the Wi-Fi network by looking at the icon in the status bar. Or tap the access point that the phone is currently connected to in the Wi-Fi screen. You can then check the network status from the pop-up window.

Note: A shortcut to the Wi-Fi status and settings is available in the Quick

Settings Menu. From the home screen, swipe down twice to access the Quick Settings menu. Tap to turn Wi-Fi on/off. Press and hold to open the Wi-Fi menu.

Connecting to virtual private networks

Virtual private networks (VPNs) allow you to connect to the resources inside a secured local network. VPNs are commonly deployed by corporations, schools, and other institutions to let people access local network resources when not on campus, or when connected to a wireless network.

Depending on the type of VPN you are using, you may be required to enter your login credentials or install security certificates before you can connect to your VPN. You can get this information from your network administrator.

Adding a VPN

1. Swipe up on the home screen, tap Settings > Network & internet >

Advanced > VPN.

2. Tap and fill in the information provided by your network administrator.

Note: You need to set a lock screen pattern, PIN, or password before you

can use credential storage.

3. Tap SAVE.

The VPN is added to the list on the VPN screen.

Connecting to a VPN

1. Swipe up on the home screen, tap Settings > Network & internet >

Advanced > VPN.

2. Tap the VPN that you want to connect.

3. When prompted, enter any requested credentials, and then tap CONNECT.

When you are connected, the VPN connected icon appears in the Status bar.

Modifying a VPN

1. Swipe up on the home screen, tap Settings > Network & internet >

Advanced > VPN.

2. Press and hold the VPN that you want to modify.

3. Tap Edit profile and edit the VPN settings you want.

4. Tap SAVE.

Browsing the Internet

Use Chrome to view web pages and search for information.

Opening a webpage or searching the web

1. Open the Chrome app.

2. Tap the address box at the top of the web page. If the address box isn’t

visible, scroll to the top of the webpage.

3. Enter the address (URL) of a webpage, or enter terms to conduct a Google

Search.

4. Tap a URL to open the web page, or tap the search suggestion to open the

search results.

5. To go back a page, tap . To go forward, tap > .

Tips:

• Tap > if you want to stop opening the page.

• Tap > if you want to refresh the page.

• To bookmark a web page, open it and tap to add a bookmark.

Using multiple browser tabs

Open several web pages at the same time (one page in each tab) and switch between them freely.

Opening a new browser tab

Tap > . A new browser window opens and the homepage is loaded.

Switching between tabs

Tap > tap the tabs to switch between tabs.

Tip: Tap on a tab to close the tab.

Setting the home page

Your home page opens whenever you launch your browser or open a new browser tab.

1. Open the page you want to set as your home page.

2. Tap > Settings > Home page.

3. Tap Open this page, enter the address (URL) and tap Save.

Downloading files

1. Press and hold an image or a link to a file or to another web page.

2. In the menu that opens, tap Download image or Download link.

The downloaded files are saved to your phone or the microSDTM card. You can view or open the downloaded files by swiping up on the home screen > Downloads.

Changing browser settings

Configure a number of browser settings to customize the way you browse the web, including several you can use to control your privacy.

To open the browser settings screen, tap > Settings in the web page screen.

Mobile Hotspot & Tethering

Share your phone's mobile data connection with a single computer via a USB cable (USB tethering) or with up to ten devices at once by turning your phone into a portable Wi-Fi hotspot.

Warning: The functions below may incur additional network charges from your network carrier. Extra fees may also be charged in roaming areas.

Share your phone's data connection via USB

Use the USB cable that came with your phone to connect the phone to a USB port on your computer.

1. Tap Settings > Network & internet > Tethering & portable hotspot.

2. Toggle the USB tethering switch to activate/deactivate this function.

Share your phone's data connection as a portable Wi-Fi hotspot

1. Tap Settings > Network & internet > Tethering & portable hotspot.

2. Toggle the Mobile Hotspot tethering switch to enable/disable this function.

Rename or secure your portable Wi-Fi hotspot

When Mobile Hotspot is activated, you can change the name of your phone's Wi-Fi network (SSID) and secure its Wi-Fi network.

• Tap Settings > Network & internet > Tethering & portable hotspot > Mobile

hotspot to change the network SSID or set your network security.

Using Wi-Fi Direct

Wi-Fi Direct allows two devices to establish a direct, peer-to-peer Wi-Fi connection without requiring a wireless router.

Connecting to another device via Wi-Fi Direct

1. Swipe up on the home screen, tap Settings > Network & internet > Wi-Fi.

2. If Wi-Fi is off, slide the Wi-Fi switch to the position.

3. Tap Wi-Fi preferences > Advanced > Wi-Fi Direct. Your phone will search for

other devices enabled with Wi-Fi Direct connections.

4. Tap a device name under Peer Devices to connect with it. The other

device will receive a Wi-Fi Direct connection prompt and need to accept the request for connection. If prompted, tap ACCEPT.

5. Once connected, the device is displayed as “Connected”.

Bluetooth

Bluetooth is a short-range wireless communication technology. Phones or other devices with Bluetooth capabilities can exchange information wirelessly within a distance of about 32 feet (10 meters). The Bluetooth devices must be paired before the communication is performed.

Turning Bluetooth on/off

1. Swipe up on the home screen, tap Settings > Connected devices >

Connection preferences > Bluetooth.

2. Slide the Bluetooth switch to the or position.

Turning Bluetooth on will make your phone visible to nearby devices.

Note: A shortcut to the Bluetooth status and settings is available in the Quick

Settings Menu. From the home screen, swipe down twice to access the Quick Settings menu. Tap to turn Bluetooth on/off. Press and hold

to open the Bluetooth menu.

Changing the device name

1. Swipe up on the home screen, tap Settings > Connected devices >

Connection preferences > Bluetooth.

2. Slide the Bluetooth switch to the position if Bluetooth is off.

3. Tap Device name > Rename this device.

4. Edit the name and tap RENAME.

Pairing with another Bluetooth device

1. Swipe up on the home screen, tap Settings > Connected devices >

Connection preferences > Bluetooth.

2. Slide the Bluetooth switch to the position if Bluetooth is off. Tap Pair

new device to display a list of available devices.

3. Tap the name of the device to initiate pairing.

4. Confirm that the Bluetooth passkeys are the same between the two devices

and tap PAIR. Alternately, enter a Bluetooth passkey and tap PAIR. Pairing is successfully completed when the other device accepts the connection or the same passkey is entered.

Note: The Bluetooth passkey may be fixed for certain devices, such as

headsets and hands-free car kits. You can try entering 0000 or 1234 (the most common passkeys), or refer to the documents for that device.

Unpairing from a Bluetooth device

You can make your phone forget its pairing connection with another Bluetooth device. To connect to the device again, you may need to enter or confirm a passkey again.

1. Swipe up on the home screen, tap Settings > Connected devices >

Connection preferences > Bluetooth and make sure Bluetooth is turned on.

2. In the list of paired devices, tap beside the Bluetooth device you want

to unpair.

3. Tap FORGET.

Sending data via Bluetooth

1. Open the appropriate application and select the file or item you want to

share.

2. Select the option for sharing via Bluetooth. The method may vary by

application and data type.

3. Tap a Bluetooth device the phone has paired with or wait for it to search

for new devices and tap one of them.

Receiving data via Bluetooth

1. Turn Bluetooth on before trying to receive data via Bluetooth.

Note: If the phone has not been paired with the sending device, you may

need to tap your phone’s device name in the Bluetooth menu in Settings to keep the phone detectable through Bluetooth.

2. Swipe down on the status bar and tap .

3. Tap ACCEPT to start receiving the data.

Entertainment

You can use your phone to take photos and record videos. Photos and videos are stored to the phone's internal storage or microSDTM card (if applicable).

You can copy them to your computer or access them in Photos.

Capturing a photo

1. From the home screen, tap Camera.

2. Aim the camera at the subject and make any necessary adjustments.

Tap to select photo size.







Tip: You can pinch or spread on the screen to zoom in or zoom out.

WARNING: Keep a safe distance when using the flash. Do not point the flash

toward people’s or animals’ eyes.



Tap to set a timer.  Tap to turn camera flash on/off/auto.

 Tap to open Photos.  Tap to take a photo.  Tap to switch between front/back

camera.





Adjusting camera settings

Tap MORE > to access Camera settings:

• Photo size: Set the photo size.

• Video quality: Choose video quality.

• Video stabilization (EIS): Switch the toggle to enable/disable the Electronic

Image Stabilization (EIS) feature. It helps reduce blurring associated with the motion of a camera during exposure.

• Volume button function: Choose Capture, Zoom or Change volume.

• Grid: Switch the toggle to enable/disable grid view. It divides the screen

into equal parts and helps you take better photos by making it simple to align compositional elements to the grid, such as the horizon or buildings to the lines in the grid.

• Storage: Save photos to your phone or microSDTM card.

• Save location information: Switch the toggle to activate/deactivate the

function of tagging photos and videos with your location. This option is available when GPS location services and wireless network are switched on.

• Shutter sound: Switch the toggle to enable/disable shutter sound when

taking a photo.

• Reset settings: Tap and confirm to reset the camera settings.

Recording a video

1. Swipe up on the home screen, tap Camera.

2. Tap to the left to access VIDEO.

3. Aim the camera at the subject.

Tip: Pinch or spread on the screen to zoom in or zoom out.

4. Tap to start recording.

5. Tap to stop recording.

Tip: While the recording is in progress, you can tap to save the frame as a separate photo.

Using your photos

Opening your photos

From the home screen, tap Photos to view your pictures and videos.

Sharing pictures, or videos

1. Press and hold a picture or a video.

2. Tap and select how you want to share the items.

Working with pictures

Tap a picture in an album to view the picture in full screen. Tap the screen to view the following features.

Return to the album.





Tap to delete.  Share the photo.

 Tap to access more options.





Google Play Music

Tap a song in the music library to listen to it. The following playback screen appears.

Tap to enter Search Google Play Music.





Tap to access the song list where you

can change the play sequence.



 Tap to access more options.

 Tap the thumbs up key to like a song.  Tap to play the previous song.  Tap to play or pause.

 Tap to play the next song.

 Tap the thumbs down key to unlike a

song.







 

Applications

Google Apps

These Google apps are pre-installed on your phone. Some apps require a Google account -- visit google.com to learn more.

Chrome

Use Google Chrome to browse the Internet and bring your open tabs, bookmarks and address bar data from your computer to your tablet. Visit google.com/chrome/browser/mobile to learn more.

Gmail

Send and receive an email with Gmail, Google’s web-based email service. Visit gmail.com to learn more.

Google Go

Search not only the Internet, but also the apps and contents of your device.

Maps Go

Use Google Maps Go to find your current location, get directions, and other location-based information.

Note: You must enable location services to use Maps Go. For more

information, see Location Services. Visit google.com/maps to learn more.

Photos

This application automatically backs up your photos and videos to your Google+ account. Visit google.com/+/learn more/photos to learn more.

Play Music

With Google Play Music, you can play music and audio files on your device. Visit play.google.com/about/music to learn more.

Play Store

Find new apps, movies and TV shows, music, books, magazines, and games in Google Play store. Visit play.google.com/store to learn more.

YouTube

View and upload YouTube videos right from your device. Visit youtube.com to learn more.

Calculator

Swipe up on the home screen, tap Calculator to use the phone’s convenient built-in calculator for some basic as well as advanced mathematical equations.

Clock

Swipe up on the home screen, tap Clock to use a series of timing tools.

Setting a new alarm

1. Tap in the Clock app.

2. Tap an existing alarm to configure it, or tap at the bottom of the

screen to create a new alarm.

3. Set up the alarm options, such as time, repeat, and alarm sound.

Note: To enable or disable existing alarms directly, just slide the switch.

Checking World time

Tap in the Clock app to check local time for cities around the world.

Tap at the bottom to add a new city or country.

Using the Stopwatch and Timer

Tap or in the Clock app to use the stopwatch or the timer.

Stopwatch allows you to record lap times, while Timer allows you to set

a time and count down to zero.

Downloads

The Downloads app keeps a record of the files you have downloaded using apps such as Browser or Gmail.

Swipe up on the home screen, tap Downloads.

• Tap a file to open it with the appropriate application.

• Press and hold a file or check the box in front of it to delete or share it.

Phone settings

Swipe up on the home screen, tap Settings. The Settings app contains most of the tools for customizing and configuring your phone.

Network & internet

Wi-Fi

Turn Wi-Fi on or off and configure your Wi-Fi connections.

When Wi-Fi is on, tap Wi-Fi preferences > Advanced > Wi-Fi Direct in the Wi-Fi menu to share data between two devices via Wi-Fi Direct.

Cellular network

Enable or disable data service, allow data services when roaming, or set access point names for data access.

Important: Data roaming and always-on data may incur significant roaming charges.

Data usage

You can check how much data has been used during the time cycle you set, set a cellular data limit, see which apps have been using data, or restrict background data for individual apps.

Note: The data usage is measured by your phone, and your carrier’s data

usage accounting may differ.

Tethering & portable hotspot: Enable to share your phone's mobile data connection with a single computer via a USB cable (USB tethering) or with up to ten devices at once by turning your phone into a portable Wi-Fi hotspot.

Airplane mode

Swipe the On/Off switch to turn airplane mode on or off.

Wi-Fi calling

Turn on/off Wi-Fi calling to allow your device to make calls over a Wi-Fi network.

VPN

Set up and connect to virtual private networks.

Private DNS

Tap select private DNS mode.

Connected devices

Bluetooth

Turn Bluetooth on or off and configure your Bluetooth connections.

Apps & Notifications

Tap to view details about the applications installed on your phone, to manage their data usage and force them to stop.

In the Permissions menu of an application, you can grant permissions for the app, such as allowing the app to access your Camera, Contacts, Location, etc.

In the Notification menu, you can configure whether to allow notifications from this app even when Do not disturb mode is on, hide sensitive content, and more.

Battery

Check how much power remains for the battery and what has been using the battery.

You can set the mode in order to save battery life.

Display

• Brightness level: Set the brightness of the display.

• Night Light: Night light tints your screen amber. This makes it easier to look

at your screen or read in dim light, and may help you fall asleep more easily.

• Adaptive brightness: Optimize brightness level for available light.

• Wallpaper: Select a background image for the home screen.

• Sleep: Set the inactivity duration before the screen turns off automatically.

• Auto-rotate screen: Select whether the screen rotates automatically or

not.

• Font size: Set the font size of the text on the screen.

• Display size: Set the display size of the items on the screen.

• Device theme: Set the device theme.

Sound

Use the Sound settings to configure many aspects of call and notification ringtones, music, and other audio settings.

• Media volume: Set volume for media.

• Call volume: Set volume for call.

• Ring volume: Set volume for ring.

• Alarm volume: Set volume for alarm.

• Also vibrate for calls: Switch the toggle to enable vibration for incoming

calls.

• Do Not Disturb: Set the behavior of calls and notifications while Do Not

Disturb is turned on.

• Shortcut to prevent ringing: Create a shortcut to prevent the ringtone during

an incoming call.

• Phone ringtone: Set your incoming call ringtone.

• Default notification sound: Set the default sound for notifications.

• Default alarm sound: Set your alarm ringtone.

• Other sounds and vibrates: Set dial pad tones, screen locking sounds,

charging sounds, touch sounds and vibrate on touch.

• Sound enhancement: Set sound enhancement.

Storage

View details about storage used by apps, images, etc. and manage space on your phone.

Security & location

Security status

• Google Play Protect: Google Play Protect regularly checks your apps and

device for harmful behavior. You’ll be notified of any security risks found.

• Find My Device: Find My Device helps you locate this device remotely. It

also helps you keep your data safe if the device is lost.

• Security Update: Check for updates.

• Function shortcuts: Customize the application shortcuts displayed on your

lock screen.

• Screen lock: Set your screen unlock method. For example, you can

unlock your phone by sliding the screen, entering a password, or drawing a pattern. You can make pattern visible, select the duration to lock the phone after the screen is off, or input owner information which will display on the locked screen.

• Lock screen preferences: Choose how notification content is displayed on

your lock screen.

• Smart Lock: With a Screen lock method enabled, your phone will detect

when it's safe with you, such as is your pocket or at your home.

• Location: Tap the switch to enable the use of information from Wi-Fi and

cellular networks to determine your approximate location, for use in Google Maps Go, when you search, and so on. When you select this option, you’re asked whether you consent to share your location anonymously with Google’s location service.

• Make passwords visible: Switch the toggle to show passwords as you type.

• Auto device wipe: Activate auto device wipe.

• Device administrators: View, activate, or deactivate device administrators.

• Encryption & credentials

• Encrypt phone: You can encrypt your accounts, settings, download

apps and their data, media and other files by tapping Encrypt device.

• Storage type: Show storage type.

• Trusted credentials: Display trusted CA certificates.

• User credentials: Check and manage stored credentials.

• Install from SD card: Install encrypted certificates from microSDTM card.

• Clear credentials: Remove all credentials.

• Trust agents: Activate or deactivate trust agents.

• Screen pinning: When this function is enabled, you can always keep a

window in view by tapping the Recent apps key and then the pin icon. In this case, the user cannot go to any other window or open any other app. To stop pinning a window in view, press and hold both the Back key and Recent apps key together, then enter your screen unlock method.

Accounts

Manage your accounts and synchronization. Tap Accounts to sign in to or create accounts on your phone.

Tap an account to see what type of accounts you have added and adjust the accounts settings.

Accessibility

Configure the system accessibility options and accessibility plug-ins on your phone.

Google

Tap to modify Google settings.

System

Languages & input

• Languages: Tap to select the language and the region you want.

• Virtual keyboard

• Gboard: The Gboard settings apply to the on-screen keyboard that is

included with your phone. The correction and capitalization features affect only the English version of the keyboard.

• Google voice typing: Google voice typing is free speech-to-text

capabilities which can let you input words by talking instead of typing by hand. Tap the microphone icon on the on-screen keyboard to start Voice Typing.

• Physical keyboard

• Show virtual keyboard: Tap the switch to enable virtual keyboard on

screen while physical keyboard is active.

• Keyboard shortcuts helper: View the available keyboard shortcuts.

• Spell checker: Mark the checkbox to enable the system to show suggested

words.

• Autofill service: Select an app which uses what’s on your screen to

determine what can be autofilled.

• Personal dictionary: Open a list of the words you’ve added to the

dictionary. Tap a word to edit or delete it. Tap the add button (+) to add a word.

• Pointer speed: Select how fast the pointer/mouse should scroll when you

connect the phone to a trackpad or mouse accessory.

• Text-to-speech settings

• Preferred engine: Choose a preferred text-to-speech engine - tap the

settings icon to show more choices for each engine.

• Language: This will show status of your default language.

• Speech rate: Open a dialog where you can select how quickly you

want the synthesiser to speak.

• Pitch: Adjust the tone of the spoken text.

Gestures

• Jump to camera: Press the power button twice to open Camera.

• Prevent ringing: Press power & volume up together to prevent ringing.

Date & time

Set date, time, time zone, and how date and time are displayed. You can also use network-provided data.

Regulatory & Safety

View regulatory & safety information.

Backup

Turn on the switch to back up your device’s settings and other application data to Google Servers, with your Google account. If you replace your device, the settings and data you’ve backed up are restored onto the new device for the first time you sign in with your Google account. If you mark this option, a wide variety of settings and data are backed up, including your Wi-Fi passwords, bookmarks, a list of the applications you’ve installed, the words you’ve added to the dictionary used by the onscreen keyboard, and most of the settings that you configure with the Settings application. If you unmark this option, you stop backing up your settings, and any existing backups are deleted from Google Servers.

Reset options

• Reset Wi-Fi, cellular & Bluetooth: Reset all network settings including Wi-Fi,

Bluetooth and other network settings to factory defaults.

• Reset app preferences: Reset your personal settings; no data or media will

be deleted

• Erase all data (factory reset): Reset your phone to factory default settings.

All of your personal data from the phone’s internal storage will be erased.

Cricket Software Update

1. Swipe up on the home screen, tap Settings.

2. Tap Cricket Software Update > Check for Updates, and the phone will search for the latest software. Your phone will automatically download the update package. You can choose to install or ignore the updates.

Note: All personal information will be saved following the update process. We

recommend you back up your personal data using Smart Suite before updating.

About phone

View phone status, legal information, and other information.

Troubleshooting

If you encounter problems while using the phone, or if it performs abnormally, you can refer to the chart below. If your particular problem cannot be resolved using the information in the chart, contact the dealer where you purchased the phone.

Problem Possible causes Possible solution

Poor reception The network signal is too weak at

Echo or noise Poor network link quality on the part

Unable to select certain features

your current location, for example, in a basement or near a tall building, because wireless transmissions cannot effectively reach it.

The network is busy at the current time (for example, during peak times, there may be too much network traffic to handle additional calls).

You are too far away from a base station for your service provider.

of your service provider.

Poor local telephone line quality. End the call and dial again. You

Your service provider does not support these features, or you have not applied for services that provide these features.

Move to a location where the network signal can be properly received.

Avoid using the phone at such times, or try again after waiting a short time.

You can request a service area map from your service provider.

End the call and dial again. You may be switched to a betterquality network link or phone line.

may be switched to a betterquality network link or phone line.

Contact your service provider.

Problem Possible causes Possible solution

Battery not charging

Shortened standby time

Cannot turn your phone on

NANO SIM card error

The battery or battery charger is damaged.

The phone’s temperature is below 32°F or higher than 113°F.

Poor contact between the battery and charger.

The display brightness is high or Wi-Fi, Bluetooth, GPS, etc. are not disabled when they are not in use.

If you are not able to connect to the network, the phone will continue to send out signals as it attempts to locate a base station. Doing so consumes battery power and will consequently shorten standby time.

Battery power has been depleted. Recharge the phone’s battery.

The NANO SIM card has malfunctioned or is damaged.

The NANO SIM card is inserted improperly.

There is debris on the NANO SIM card contacts.

Contact the dealer.

Adjust the environment to avoid extremes of temperature.

Check all connectors to make sure all connections have been properly made.

Adjust the brightness of the screen as appropriate.

Exit background-running applications if they are not being used for a long time.

Disable Bluetooth, Wi-Fi, or GPS when not in use.

Change your location to one where the network is accessible, or temporarily turn off your phone.

Take the NANO SIM card to your service provider for testing.

Insert the NANO SIM card properly.

Use a soft, dry cloth to clean the NANO SIM card contacts.

Problem Possible causes Possible solution

Unable to connect to the network

Cannot make outgoing calls

PIN code blocked

Unable to enter information into the phonebook

Phone crashes, reboots, freezes, or cannot be powered on

Phone is slow or sluggish

Cannot receive new notifications while App running in the background

The NANO SIM card is invalid. Contact your service provider.

You are not within the network’s service area.

Poor signal. Move to an open space, or if you

You have activated Fixed Dialing Numbers.

You have entered an incorrect PIN code three consecutive times.

The phonebook’s memory is already full.

Some third-party software is not compatible with your phone.

Applications are running in the background.

Not activate your Apps under

DuraSpeed

Check the service area with your service provider.

are inside a building, move closer to a window.

Go to Fixed Dialing Numbers and disable it.

Contact your service provider. If the service provider provides the SIM card’s PUK code, use the PUK code to unlock the SIM card.

Delete unnecessary data from the contacts.

Uninstall the software that may cause the problem.

Upgrade the phone software.

Reset the phone to factory status by pressing Power key and Volume Up key at the same time when power off the phone.

Exit background-running applications if they are not being used.

Access into Settings > Apps &

notifications > Advanced > DuraSpeed, activate your desired

Apps.

For your safety

General safety

Don’t make or receive handheld calls while driving. And never text while driving.

Keep your phone at least half an inch (15 mm) away from your ear or body while making calls.

Small parts may cause choking.

Your phone can produce a loud sound.

Avoid contact with anything magnetic.

Keep away from pacemakers and other electronic medical devices.

Power off when asked to in hospitals and medical facilities.

Power off when told to in aircrafts and airports.

Power off when near explosive materials or liquids.

Don’t use at gas stations.

Your phone may produce a bright or flashing light.

Don’t dispose of your phone in a fire.

To prevent possible hearing damage, do not listen at high volume levels for long periods

Avoid extreme temperatures.

Avoid contact with liquids. Keep your phone dry.

Don’t take your phone apart.

Only use approved accessories.

Don’t rely on your phone as a primary device for emergency communications.

FCC RF Exposure Information (SAR)

This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the United States.

During SAR testing, this device was set to transmit at its highest certified power level in all tested frequency bands and placed in positions that simulate RF exposure in usage against the head with no separation, and near the body with the separation of 15 mm. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.

The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption Rate or SAR. The SAR limit set by the FCC is

1.6 W/kg.

Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: 2ACCJH103.

For this device, the highest reported SAR value for usage against the head is

0.98 W/kg, for usage near the body is 1.11 W/kg.

While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirements.

SAR compliance for body-worn operation is based on a separation distance of 15 mm between the unit and the human body. Carry this device at least 15 mm away from your body to ensure RF exposure level compliant or lower to the reported level. To support body-worn operation, choose the belt clips or holsters, which do not contain metallic components, to maintain a separation of 15 mm between this device and your body.

RF exposure compliance with any body-worn accessory, which contains metal, was not tested and certified, and use such body-worn accessory should be avoided.

FCC compliance

This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment.

Hearing Aid Compatibility (HAC) regulations for mobile phones

In 2003, the FCC adopted rules to make digital wireless telephones compatible with hearing aids and cochlear implants. Although analog wireless phones do not usually cause interference with hearing aids or cochlear implants, digital wireless phones sometimes do because of electromagnetic energy emitted by the phone’s antenna, backlight, or other components. Your phone is compliant with FCC HAC regulations (ANSI C63.19- 2011). While some wireless phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise and phones also vary in the amount of interference they generate. The wireless telephone industry has developed a rating system for wireless phones to assist hearing device users in finding phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label located on the box. The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.

This phone has been tested and rated for use with hearing aids for some of the wireless technologies that it uses. However, there may be some newer wireless technologies used in this phone that have not been tested yet for use with hearing aids. It is important to try the different features of this phone thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult your service provider or the manufacturer of this phone for more information on hearing aid compatibility. If you have questions about return or exchange policies, consult your service provider or phone retailer.

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the better/ higher of the two ratings. (Note that not all hearing devices have telecoils in them.)

Your phone meets the M4/T3 level rating.

Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may help you find this rating. For more information about FCC Hearing Aid Compatibility, please go to http://www.fcc.gov/cgb/dro.

CTIA

a) Do not disassemble or open crush, bend or deform, puncture or shred.

b) Do not modify or remanufacture, attempt to insert foreign objects into

the battery, immerse or expose to water or other liquids, expose to fire, explosion or other hazard.

c) Only use the battery for the system for which it is specified.

d) Only use the battery with a charging system that has been qualified

with the system per CTIA Certification Requirements for Battery System Compliance to IEEE 1725. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

e) Do not short circuit a battery or allow metallic conductive objects to

contact battery terminals.

f) Replace the battery only with another battery that has been qualified with

the system per this standard, IEEE-Std-1725. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard.

g) Promptly dispose of used batteries in accordance with local regulations.

h) Battery usage by children should be supervised.

i) Avoid dropping the phone or battery. If the phone or battery is dropped,

especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

j) Improper battery use may result in a fire, explosion or other hazard.

The phone shall only be connected to products that bear the USB-IF logo or have completed the USB-IF compliance program.

Distraction

Driving

Full attention must be given to driving at all times in order to reduce the risk of an accident. Using a phone while driving (even with a hands-free kit) can cause distraction and lead to an accident. You must comply with local laws and regulations restricting the use of wireless devices while driving.

Operating machinery

Full attention must be given to operating the machinery in order to reduce the risk of an accident.

Product handling

General statement on handling and use

You alone are responsible for how you use your phone and any consequences of its use.

You must always power off your phone wherever the use of a phone is prohibited. Use of your phone is subject to safety measures designed to protect users and their environment.

• Always treat your phone and its accessories with care and keep it in a

clean and dust-free place.

• Do not expose your phone or its accessories to open flames or lit tobacco

products.

• Do not expose your phone or its accessories to liquid, moisture, or high

humidity.

• Do not drop, throw, or try to bend your phone or its accessories.

• Do not use harsh chemicals, cleaning solvents, or aerosols to clean the

device or its accessories.

• Do not paint your phone or its accessories.

• Do not attempt to disassemble your phone or its accessories. Only

authorized personnel can do so.

• Do not expose your phone or its accessories to extreme temperatures,

minimum 32°F and maximum 122°F (minimum 0°C and maximum + 50°C).

• Please check local regulations for disposal of electronic products.

• Do not carry your phone in your back pocket as it could break when you

sit down.

Small children

Do not leave your phone and its accessories within the reach of small children or allow them to play with it. They could hurt themselves or others, or could accidentally damage the phone.

Your phone contains small parts with sharp edges that may cause an injury or may become detached and create a choking hazard.

Demagnetization

To avoid the risk of demagnetization, do not allow electronic devices or magnetic media close to your phone for a long time.

Electrostatic discharge (ESD)

Do not touch the NANO SIM card’s metal connectors.

Antenna

Do not touch the antenna unnecessarily.

Normal use position

When placing or receiving a phone call, hold your phone to your ear, with the bottom toward your mouth.

Air bags

Do not place a phone in the area over an air bag or in the air bag deployment area as an airbag inflates with great force and serious injury could result.

Store the phone safely before driving your vehicle.

Seizures/blackouts

The phone can produce a bright or flashing light. A small percentage of people may be susceptible to blackouts or seizures (even if they have never had one before) when exposed to flashing lights or light patterns such as when playing games or watching a video. If you have experienced seizures or blackouts or have a family history of such occurrences, please consult a physician.

Repetitive strain injuries

To minimize the risk of Repetitive Strain Injury (RSI) when texting or playing games with your phone:

• Do not grip the phone too tightly.

• Press the keys lightly.

• Use the special features that are designed to minimize the times of

pressing buttons, such as Message Templates and Predictive Text.

• Take lots of breaks to stretch and relax.

Emergency calls

This phone, like any wireless phone, operates using radio signals, which cannot guarantee connection in all conditions. Therefore, you must never rely solely on any wireless phone for emergency communications.

Loud noise

This phone is capable of producing loud noises, which may damage your hearing. Turn down the volume before using headphones, Bluetooth stereo headsets or other audio devices.

Phone heating

Your phone may become warm during charging and during normal use.

Electrical safety

Accessories

Use only approved accessories.

Do not connect with incompatible products or accessories.

Take care not to touch or allow metal objects, such as coins or key rings, to contact or short-circuit in the battery terminals.

Connection to a car

Seek professional advice when connecting a phone interface to the vehicle electrical system.

Faulty and damaged products

Do not attempt to disassemble the phone or its accessories.

Only qualified personnel can service or repair the phone or its accessories.

If your phone (or its accessories) has been submerged in water, punctured, or subjected to a severe fall, do not use it until you have taken it to be checked at an authorized service center.

Interference

General statement on interference

Care must be taken when using the phone in close proximity to personal medical devices, such as pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of

6 inches (15 cm) be maintained between a mobile phone and a pacemaker to avoid potential interference with the pacemaker. To achieve this, use the phone on the opposite ear to your pacemaker and do not carry it in a breast pocket.

Hearing aids

People with hearing aids or other cochlear implants may experience interference noise when using wireless devices or when one is nearby.

The level of interference will depend on the type of hearing device and the distance from the interference source, increasing the separation between them may reduce the interference. You may also consult your hearing aid manufacturer to discuss alternatives.

Medical devices

Please consult your doctor and the device manufacturer to determine if using your phone may interfere with the operation of your medical device.

Hospitals

Switch off your wireless device when requested to do so in hospitals, clinics, or healthcare facilities. These requests are designed to prevent possible interference with sensitive medical equipment.

Aircraft

Switch off your wireless device whenever you are instructed to do so by airport or airline staff.

Consult the airline staff about the use of wireless devices on board the aircraft. If your device offers a ‘flight mode’, this must be enabled prior to boarding an aircraft.

Interference in cars

Please note that because of possible interference to electronic equipment, some vehicle manufacturers forbid the use of mobile phones in their vehicles unless a hands-free kit with an external antenna is included in the installation.

Explosive environments

Gas stations and explosive atmospheres

In locations with potentially explosive atmospheres, obey all posted signs to turn off wireless devices such as your phone or other radio equipment.

Areas with potentially explosive atmospheres include fueling areas, below decks on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

Blasting caps and areas

Power off your mobile phone or wireless device when in a blasting area or in areas posted with power off “two-way radios” or “electronic devices” notices to avoid interfering with blasting operations.

Specifications

Handset specifications are shown in the following table.

Network frequency GSM: 850/900/1800/1900

Operating system Android P Go Display 5.0'' FWVGA

Processor MT6739WW Memory 1.5 GB RAM, up to 16 GB ROM

Wi-Fi 802.11b/g/n Camera Rear: 5MP with LED flash

Talk time 2G/3G: 10-12 hours; 4G: 7.5 hours Standby time 2G/3G: 316 hours; 4G: 220 hours Dimensions 136.6 X 65.1 X 9.95 mm Weight 145g Battery 2200 mAh HAC Rated for hearing aids: M4/T3 Audio jack

UMTS: B2/4/5 LTE: B2/4/5/12/14/30 (band12 by MFBI)

480x960 resolution

microSDTM support up to max 32GB

Front: 2MP with LCD software flash

3.5 mm audio jack

12 month limited warranty

TCL Communications Ltd. warrants to the original retail purchaser of this wireless device that should this product or part thereof during normal consumer usage and condition be proven to be defective in material or workmanship that results in product failure within the first twelve (12) months from the date of purchase as shown on your original sales receipt from an authorized sales agent. Such defect(s) will be repaired or replaced (with new or rebuilt parts) at the company’s option without charge for parts or labor directly related to the defect(s). Batteries, power adapters, and other accessories sold as in box items are also warranted against defects and workmanship that results in product failure within the first twelve (12) month period from the date of purchase. This warranty extends to products purchased and sold within the United States.

The limited warranty for your wireless device will be voided if any of the following conditions occur:

• Non-compliance with the instructions for use or installation, or with

technical and safety standards applicable in the geographical area where your phone is used;

• Connection to any equipment not supplied or not recommended by TCL

Communications Ltd.;

• Modification or repair performed by individuals not authorized by TCL

Communications Ltd. or its affiliates;

• Changes to the device operating system by the user or third party

applications;

• Acts of god such as inclement weather, lightning, power surges, fire,

humidity, infiltration of liquids or foods, chemical products, download of files, crash, high voltage, corrosion, oxidation;

• Removal or altering of the wireless device’s event labels or serial numbers

(IMEI);

• Damage from exposure to water or other liquids, moisture, humidity,

excessive temperatures or extreme environmental conditions, sand, excess dust and any condition outside the operating guidelines;

• Rooted devices;

• Damage as result of physical abuse regardless of cause.

There are no express warranties, whether written, oral or implied, other than this printed limited warranty or the mandatory warranty provided by your jurisdiction. In no event shall TCL Communications Ltd. or any of its affiliates be liable for incidental or consequential damages of any nature whatsoever, including but not limited to commercial loss, to the full extent those damages can be disclaimed by law. Some states do not allow the exclusion or limitation of incidental or consequential damages or limitation of the duration of implied warranties, so the preceding limitations or exclusions may not apply to you.

How to obtain Support: Contact the customer care center by calling (855368-0829) or going to (http://www.alcatelonetouch.us). We have placed many self-help tools that may help you to isolate the problem and eliminate the need to send your wireless device in for service. In the case that your wireless device is no longer covered by this limited warranty due to time or condition, you may utilize our out of warranty repair options.

How to obtain Hardware Service within the terms of this warranty: Create a user profile (alcatel.finetw.com) and then create an RMA for the defective device. Ship the device with a copy of the original proof of purchase (e.g.original copy of the dated bill of sale, invoice) with the owner's return address (No PO Boxes accepted), wireless carrier’s name, alternate daytime phone number, and email address with a complete problem description. Only ship the device. Do not ship the SIM card, memory cards, or any other accessories such as the power adapter. You must properly package and ship the wireless device to the repair center. TCL Communications Ltd. is not responsible for devices that do not arrive at the service center or are damaged in transit. Insurance is recommended with proof of delivery. Upon receipt, the service center will verify the warranty conditions, repair, and return your device to the address provided in the RMA.

Electronic Recycling

For more information on Electronic Recycling, please:

1) Visit Alcatel Electronic Recycling Program website at

https://us.alcatelmobile.com/electronic-recycling-program, or

2) Call Alcatel US Customer Support at 1-855-368-0829.

Battery Recycling (USA & Canada)

Alcatel partners with Call2Recycle® to offer a safe and convenient battery recycling program. For more information on our Battery Recycling Program, please visit the USA and Canada website at www.alcatelonetouch.us/ battery-recycling and https://ca.alcatelmobile.com/battery-recycling.

Alcatel 5005R User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
