Alamo 00761808C, FC-0015, A96B, FC-0016 User Manual
A96B
ROTARY MOWER
Published 03/06 Part No. 00761808C
OPERATOR’S MANUAL
This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ,
and Operation Instructions contained in this manual before operating the equipment. C01-
Cover
UNDERSTAND, and FOLLOW the Safety
ALAMO INDUSTRIAL®
1502 E. Walnut
Seguin, Texas 78155
830-372-3551
Email: parts@alamo-industrial.com
©2006 Alamo Group Inc.
$0.00
To the Owner/Operator/Dealer
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded
operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has
designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
BEFORE YOU START!!Read the safety messages on the implement and shown in your manual. Observe the
rules of safety and common sense!
In order to reduce accidents and enhance the safe operation of mowers, Alamo Industrial, in cooperation
with other industry manufacturers has developed the AEM/FEMA Industrial and Agricultural Mower
Safety Practices video and guide book.
The video will familiarize and instruct mower-tractor operators in safe practices when using industrial
and agricultural mowing equipment. It is important that Every Mower Operator be educated in the operation of their mowing equipment and be able to recognize the potential hazards that can occur while operating a mower. This video, along with the mower operator ’s manual and the warning messages on the
mower, will significantly assist in this important education.
Your Authorized Alamo Industrial Dealer may have shown this video and presented you a DVD Video
when you purchased your mower. If you or any mower operator have not seen this video, Watch the
Video, Read this Operator ’s Manual, and Complete the Video Guidebook before operating your new
mower. If you do not understand any of the instructions included in the video or operator’s manual or if
you have any questions concerning safety of operation, contact your supervisor, dealer or Alamo Indus-
trial.
If you would like a VHS video tape of the video, please email AEMVideo@alamo-group.com or Fax
AEM VHS Video at (830) 372-9529 or mail in a completed copy of the form on the back of this page to
AEM VHS Video 1502 E Walnut Street, Seguin, TX 78155. and request the VHS video version. Please
include your name, mailing address, mower model and serial number.
Every operator should be trained for each piece of equipment (Tractor and Mower), understand the
intended use, and the potential hazards before operating the equipment.
Alamo Industrial Division is willing to provide
one (1) AEM Mower Safety Practices Video
Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video
DVD Format – AEM/FEMA Mower Operator Safety Video
Mower Operator’s Manual
AEM Mower Operator’s Safety Manual
Requester Name Phone:
Requester Address:
City
State
Zip Code
Mower Model: Serial Number:
Date Purchased: Dealer Salesperson:
Dealership Name: Dealership Location:
Mail to:
AEM Video Services
1502 E Walnut street
Seguin, TX 78155
Or Fax to:
(830) 372-9529
Or Email to:
AEMVideo@alamo-group.com
Table of Contents
SAFETY SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
General Safety Instructions and Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Operator Safety Instructions and Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Equipment Operation Safety Instructions and Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Connecting or Disconnecting Implement Safety Instructions and Practices . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Transporting Safety Instructions and Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Maintenance and Service Safety Instructions and Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Concluding Safety Instructions and Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Decal Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Decal Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20
Federal Laws and Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-27
INTRODUCTION SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Attention Owner/Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
ASSEMBLY SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
DEALER SET-UP INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
A-FRAME ASSEMBLY-LIFT TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
A-FRAME ASSEMBLY - LIFT TYPE (CONT’D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
TAIL WHEEL ASSEMBLY - LIFT TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
TONGUE - PULL TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
AXLE ASSEMBLY - PULL TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
AXLE ASSEMBLY (Semi-Mount & Hydraulic Offset) (Figure ASM-R-0138) . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
CONTROL RODS - PULL TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
MOWER SUPPORT ROD (OFFSET PULL MODEL ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
HYDRAULIC OR MANUAL LIFT - PULL & OFFSET TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
HYDRAULIC OFFSET SEMI-MOUNT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
WHEELS - PULL TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
DRIVELINE ATTACHMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
SHIELD ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
JACKSHAFT BEARING SUPPORT ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
CHECK CHAINS (EXTRA EQUIPMENT) FOR LIFT-MODELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
DRIVELINE CLAMP CONE YOKE OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
FRONT AND REAR DEFLECTORS (Standard Equipment) and CHAIN GUARDS (Optional Equipment at additiona l
cost) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Rear Deflector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
CHAIN GUARD (EXTRA EQUIPMENT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Front Chain Guards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Rear Chain Guards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
JACKSHAFT BEARING SUPPORT ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
CV JACKSHAFT SUPPORT ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
OPERATION SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Standard Equipment and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
OPERATOR REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
ROPS and SEAT BELT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Tractor Safety Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Tractor Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
3-Point Hitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Drawbar-Pull Type Mower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Front End Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Power Take Off (PTO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
GETTING ON AND OFF THE TRACTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Boarding the Tractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Dismounting the Tractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
STARTING THE TRACTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
CONNECTING THE MOWER TO THE TRACTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Connecting the Mower-Lift Type and Semi-Mount Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Connecting the Mower-Pull Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
Safety Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
SETTING THE MOWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Setting Mower Height- Lift Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Setting Mowing Height-Pull Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
Setting Deck Pitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
DRIVELINE ATTACHMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Driveline Length Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
Constant Velocity (CV) Driveline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
PRE-OPERATION INSPECTION AND SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Tractor Pre-Operation Inspection/Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Mower Pre-Operation Inspection/Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Cutting Component Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
DRIVING THE TRACTOR AND IMPLEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
Starting the Tractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
Brake and Differential Lock Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Raising the Mower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Driving the Tractor and Mower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Crossing Ditches and Steep Inclines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
OPERATING THE TRACTOR AND IMPLEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Foreign Debris Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
Bystanders/Passersby Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
Engaging the Power Take Off (PTO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31
PTO RPM and Ground Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Operating the Mower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Shutting Down the Implement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
DISCONNECTING THE MOWER FROM THE TRACTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
MOWER STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
TRANSPORTING THE TRACTOR AND IMPLEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
Transporting on Public Roadways . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38
Hauling the Tractor and Implement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40
MAINTENANCE SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
GEARBOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
TAIL WHEEL ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
DRIVELINE LUBRICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
DRIVELINE SHIELD REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
MAIN CV DRIVELINE SAFETY SHIELD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
DRIVELINE CLAMP CONE YOKE OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
BLADE SERVICING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
BLADE SHARPENING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
BLADE REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
BLADE CARRIER REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
BLADE CARRIER INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
BLADE TIMING AND ROTATION (FIGURE Mnt-R-0102) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
BLADE TIMING PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
SLIP CLUTCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
SEASONAL CLUTCH MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
MOWER STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
TORQUE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
TOOLS NEEDED FOR DISASSEMBLY AND ASSEMBLY OF T GEARBOX . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Disassembly and Assembly Procedures for T-BOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
Assembly Procedure for T - BOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
Disassembly Instructions for Outer Gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
ASSEMBLY INSTRUCTIONS FOR GEARBOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
SAFETY SECTION
© 2006 Alamo Group Inc.
Safety Section 1-1
SAFETY
General Safety Instructions and Practices
A safe and careful operator is the best operator. Safety is of primary importance to the m anufacturer and
should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your
surroundings, and observing certain precautions. The first section of this manual includes a list of Safety
Messages that, if followed, will help protect the operator and bystanders from injury or death. Read and
understand these Safety Messages before assembling, operating or servicing this Implement. This
equipment should only be operated by those persons who have read the Manual, who are responsible and
trained, and who know how to do so safely and responsibly.
The Safety Alert Symbol combined with a Signal Word, as seen below, is used throughout this manual and on
decals which are attached to the equipment. The Safety Alert Symbol means: “ATTENTION! BECOME
ALERT! YOUR SAFETY IS INVOLVED!” The Symbol and Signal Word are intended to warn the owner/
operator of impending hazards and the degree of possible injury faced when operating this equipment.
SAFETY
READ, UNDERSTAND, and FOLLOW the following Safety Messages. Serious injury or
death may occur unless care is taken to follow the warnings and instructions stated in the
Safety Messages. Always use good common sense to avoid hazards.
Practice all usual and customary safe working precautions and above all---remember
safety is up to YOU
practices.
The lowest level of Safety Message; warns of possible injury. Decals located on the
Equipment with this Signal Word are Black and Yellow
Serious injury or possible death! Decals are Black and Orange.
Imminent death/critical injury. Decals are Red and White.
Si no lee ingles, pida ayuda a alguien que si lo lea para que le traduzca las
medidas de seguridad.
. Only YOU can prevent serious injury or death from unsafe
(SG-1)
(SG-2)
(SG-3)
Engine Exhaust, some of its constituents, and certain vehicle components contain or emit
chemicals known to the state of California to cause cancer and birth defects or other
reproductive harm.
A96B 03/06 Safety Section 1-2
© 2006 Alamo Group Inc.
(SG-30)
SAFETY
N
til
d
Battery posts, terminals and related accessories contain lead and lead compounds,
chemicals known to the state of California to cause cancer, birth defects or other
reproductive harm.
Operator Safety Instructions and Practices
PTO disengaged, the tractor turned off, and all evidence of rotation has ceased.
possible injury or death. Always securely block up the Implement before crawling underneath to perform
repairs and service.
(SG-31)
The rotating parts of this machine continue to rot ate even af ter the P T O has bee n turned off.
The operator should remain in his seat for 60 seconds after the brake has been set, the
(S3PT-10)
“Wait a minute...Save a life!”
Never crawl under a raised Implement supported solely by the Tractor 3-Point hitch.
Release of the control lever or mechanical failure will result in the Implement falling and
(S3PT-19)
SAFETY
ever operate the Tractor or Implement un
you have read an
completely understand this Manual, the Tractor Operator’s Manual, and
each of the Safety Messages found in the Manual or on the Tractor and Implement. Learn
how to stop the tractor engine suddenly in an emergency. Never allow inexperienced or
untrained personnel to operate the Tractor and Implement without supervision. Make sure
the operator has fully read and understood the manuals prior to operation.
(SG-4)
The operator and all support personnel should wear hard hats, safety
shoes, safety glasses, and proper hearing protection at all times for
protection from injury including injury from items thrown by the equipment.
(SG-16)
PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE
PERMANENT HEARING LOSS! Tractors with or without an Implement
attached can often be noisy enough to cause perman ent hear ing lo ss. We recommend that
you always wear hearing protection if the noise in the Operator’s position exceeds 80db.
Noise over 85db over an extended period of time will cause severe hearing loss. Noise
over 90db adjacent to the Operator over an extended pe riod of time will cause per manent or
total hearing loss. NOTE: Hearing loss from loud noise [f rom tractors, chain saws, radios ,
and other such sources close to the ear] is cu mulative over a lifetime withou t hope of natural
recovery.
(SG-I7)
A96B 03/06 Safety Section 1-3
© 2006 Alamo Group Inc.
SAFETY
Al
ith th
Prol
U
tti
d
ways read carefully and comply fully w
e manufacturer’s
instructions when handling oil, solvents, cleansers, and any other
chemical agent.
(SG-22)
KEEP AWAY FROM ROTATING ELEMENTS to prevent entanglement
and possible serious injury or death.
(SG-24)
Never allow children to play on or around Tractor or Implement. Children can slip or fall of f
the Equipment and be injured or killed. Children can cause the Implement to shift or fall
crushing themselves or others.
(SG-25)
SAFETY
NEVER use drugs or alcohol immediately before or while operating the
Tractor and Implement. Drugs and alcohol will affect an operator’s
alertness and coordination and therefore affect the operator’s ability to operate the
equipment safely. Before operating the Tractor or Implement, an operator on prescription
or over-the-counter medication must consult a medical professional regarding any side
effects of the medication that would hinder their ability to operate the Equipment safely.
NEVER knowingly allow anyone to operate this equipment when their alertness or
coordination is impaired.
operator is under the influence of drugs or alcohol.
Serious injury or death to the operator or others could result if the
(SG-27)
onged operation may cause operator boredom and fatigue affecting safe operation.
Take scheduled work breaks to help prevent these potentially impaired operating
conditions. Never operate the Implement and Tractor in a fatigued or bored mental state wh ich imp air s proper
and safe operation.
(SG-32)
se extreme caution when ge
ng onto the Implement to perform repairs, maintenance an
when removing accumulated material. Only stand on solid flat surfaces to ensure good
footing. Use a ladder or raised stand to access high spots which cannot be reached from gound level.
Slipping and falling can cause serious injury or death.
(SG-33)
Avoid contact with hot surfaces including hydraulic oil tanks, pumps, motors, valves and
hose connections. Relieve hydraulic pressure before performing maintenance or repairs.
Use gloves and eye protection when servicing hot components. Contact with a hot surface or fluid can cause
serious injury from burns or scalding.
A96B 03/06 Safety Section 1-4
(SG-34)
© 2006 Alamo Group Inc.
SAFETY
e
f
B
ill b
r
DO NOT operate this Implement on a Tractor that is not properly maintained. Should a
mechanical or Tractor control failure occur while operating, immediately shut down the
Tractor and perform repairs before resuming operation. Serious injury and possible death
could occur from not maintaining this Implement and Tractor in good operating condition.
Avoid contact with hot surfaces of the engine or muffler. Use gloves and eye protection
when servicing hot components. Contact with a hot surface or fluid can cause serious injury
from burns or scalding.
Do not put hands or feet under mower decks. Blade Contact can result
in serious injury or even death. Stay away until all motion has stopped
and the decks are securely blocked up.
Always keep a careful lookout and use extreme care when working around utility and
municipal obstructions. Never allow the Mower to contact any utility, municipal, or other
type structure. Clearly mark all mowing obstructions and consult local utility providers for a safe code of
operation.
(SPU-5)
(SG-38)
(SGM-9)
SAFETY
Do not operate the implement while wearing loose fitting clothing. Entanglement of th
clothing with the rotating elements can result in serious injury or even death. Stay clear o
all rotating elements at all times. (SSP-3)
Equipment Operation Safety Instructions and Practices
Never leave the Tractor and Implement unattended while the Implement is in the lifted
position. Accidental operation of lifting lever or a hydraulic failure may cause sudden drop
of unit with injury or death by crushing. To properly park the implement when disconnecting it from the tractor,
lower the stand and put the retaining pin se cure ly in place, or put a secure su pport un der the A-F ram e. Lower
the implement carefully to the ground. Do not put hands or feet under lifted components.
This Implement is wider than the Tractor. Be careful when operating or transporting this
equipment to prevent the Implement from running into or striking s ign posts, guard rails,
concrete abutments or other solid objects. Such an impact could cause the Implement and Tractor to pivot
violently resulting in loss of steering control, serious injury, or even death. Never allow the Implement to
contact obstacles.
cable could result in serious injury or death. (SBH-6)
(S3PT-12)
e sure you have adequate knowledge of the property you w
make yourself aware of any area underground lines or cables. Contact with buried lines o
(S3PT-1)
e working on. Take time to
A96B 03/06 Safety Section 1-5
© 2006 Alamo Group Inc.
SAFETY
Do not operate Mower if excessive vibration exists. Shut down PTO and the Tractor
engine. Inspect the Mower to determ ine the source of the vibration. If Mower blades are
missing or damaged replace them immediately. Do not operate the mower until the blades have been
replaced and the Mower operates smoothly. Operating the Mower with excessive vibration can result in
component failure and broken objects to be thrown outward at very high velocities. To reduce the possibility of
property damage, serious injury, or even death, never allow the Mower to be operated with blades missing.
(SFL-4)
Operate this Equipment only with a Tractor equipped with an approved roll-
over-protective system (ROPS). Always wear seat belts. Serious injury or
even death could result from falling off the tractor--particularly during a turnover when the operator
could be pinned under the ROPS.
(SG-7)
SAFETY
BEFORE leaving the tractor seat, always engage the brake and/or set
the tractor transmission in parking gear, disengage the PTO, stop the
engine, remove the key, and wait for all moving parts to stop. Place the tractor shift lever
into a low range or parking gear to prevent the tractor from rolling. Never dismount a
Tractor that is moving or while the engine is running. Operate the Tractor controls from the
tractor seat only .
(SG-9)
Never allow children or other persons to ride on the Tractor or Implement.
Falling off can result in serious injury or death.
(SG-10)
Never allow children to operate, ride on, or come close to the Tractor or
Implement. Usually, 16-17 year-old children who are mature and
responsible can operate the implement with adult supervision, if they have read and
understand the Operator’s Manuals, been trained in safe operation of the tractor and
Implement, and are physically large enough to reach and operate the controls easily.
(SG-11)
Do not mount the Tractor while the tractor is moving. Mount the Tractor
only when the Tractor and all movin g parts are completely stopped.
(SG-12)
A96B 03/06 Safety Section 1-6
© 2006 Alamo Group Inc.
SAFETY
I
difficulty duri
iti
Start tractor only when properly seated in the Tractor seat. Starting a
tractor in gear can result in injury or death. Read the Tractor operators
manual for proper starting instructions.
Do not operate this Equipment with hydraulic oil or fuel leaking. Oil and
fuel are explosive and their presence could present a hazard. Do not
check for leaks with your hand! High-pressure oil streams from breaks in the line could
penetrate the skin and cause tissue damage including gangrene. To check for a hose leak,
SHUT the tractor ENGINE OFF and remove all hydraulic pressure. Wear oil impenetrable
gloves, safety glasses and use Cardboard to check for evidence of oil leaks. If you suspect
a leak, REMOVE the HOSE and have it tested at a Dealer. If oil does penetrate the skin,
have the injury treated immediately by a physician knowledgeable and skilled in this
procedure.
(SG-15)
(SG-13)
SAFETY
Never run the Tractor engine in a closed building or without adequate ventilation. The
exhaust fumes can be hazardous to your health.
(SG-23)
Do not exceed the rated PTO speed for the Implement. Excessive PTO speeds can cause
Implement driveline or blade failures resulting in serious injury or death.
(SG-26)
Operate the Tractor and/or Implement control s only while properly seated in the Tractor seat
with the seat belt securely fastened around you. Inadvertent movement of the Tractor or
Implement may cause serious injury or death.
n case of mechincal
(SG-29)
ng operation, place the transmission in the park pos
on,
set the parking brake, shut down all power, including the PTO and the engine and remove
the key. Wait until all rotating motion has stop before dismounting. (SG-39)
Do Not operate this equipment in areas where insects such as bees may attack you and/or
cause you to lose control of the equipment. If you must enter in such areas, use a tractor
with an enclosed Cab and close the windows to prevent insects from entering. If a tractor cab is not
available, wear suitable clothing including head, face, and hand protection to shield you from the insects.
Attacking insects can cause you to lose control of the tractor, which can result in serious injury or death to you
or bystanders. Never dismount a moving tractor.
(SG-40)
A96B 03/06 Safety Section 1-7
© 2006 Alamo Group Inc.
SAFETY
E
h
M
M
Mow only in conditions where you have clear visibility in daylight or with adequate artificial
lighting. Never mow in darkness or foggy conditions where you cannot clearly see at least
100 yards in front and to the sides of the tractor and mower. Make sure that you can clearly see and identify
passersby, steep slopes, ditches, drop-offs, overhead obstructions, power lines, debris and foreign objects. If
you are unable to clearly see these type of items discontinue mowing.
There are obvious and hidden potential hazards in the operation of this
Mower. REMEMBER! This machine is often operated in heavy brush
and in heavy weeds. The Blades of this Mower can throw objects if shields are not
properly installed and maintained. Serious injury or even death may occur unless care is
taken to insure the safety of the operator, bystanders, or passersby in the area. Do not
operate this machine with anyone in the immediate area. Stop mowing if anyone is within
100 yards of mower.
(SGM-2)
(SGM-1)
SAFETY
The rotating parts of this machine have been designed and tested for rugged use.
However, the blades could fail upon impact with heavy, solid objects such as metal guard
rails and concrete structures. Such im pact could cau se the brok en ob jects to be thro wn ou tward a t very h igh
velocities. To reduce the possibility of property damage, serious injury, or even death, never allow the cutting
blades to contact such obstacles.
(SGM-4)
xtreme care should be taken when operating near loose objects suc
as gravel, rocks, wire, and other debris. Inspect the area before
mowing. Foreign objects should be removed from the site to prevent machine damage
and/or bodily injury or even death. Any objects that cannot be removed must be clearly
marked and carefully avoided by the operator. Stop mowing immediately if blades strike a
foreign object. Repair all damage and make certain rotor or blade carrier is balanced
before resuming mowing.
(SGM-5)
any varied objects, such as wire, cable, rope, or chains, can become entangled in the
operating parts of the mower head. These items could then swing outside the housing at
greater velocities than the b lades. Such a s ituation is extre mely hazardous and could res ult in serious injur y
or even death. Inspect the cutting area for such objects before mowing. Remove any like object from th e site.
Never allow the cutting blades to contact such items.
(SGM-6)
ow at the speed that you can safely operate and control the tractor and mower. Safe
mowing speed depends on terrain condition and grass type, density, and height of cut.
Normal ground speed range is from 0 to 5 mph. Use slow mowing speeds when operating on or near steep
slopes, ditches, drop-offs, overhead obstructions, power lines, or when debris and foreign objects are to be
avoided.
(SGM-7)
A96B 03/06 Safety Section 1-8
© 2006 Alamo Group Inc.
SAFETY
The M
ifi
Avoid mowing in reverse direction when possible. Check to make sure there are no
persons behind the mower and use extreme care when mowing in reverse. Mow only at a
slow ground speed where you can safely operate and control the tractor and mower. Never mow an area
that you have not inspected and removed debris or foreign material.
Do not mow with two machines in the same area except with Cab tractors with the windows
closed.
(SGM-11)
Follow these guidelines to reduce the risk of equipment and grass fires
while operating, servicing, and repairing the Mower and Tractor:
-Equip the Tractor with a fire extinguisher in an accesible location.
-Do Not operate the Mower on a Tractor with an underframe exhaust.
-Do Not smoke or have an open flame near the Mower and Tractor.
-Do Not drive into burning debris or freshly burnt areas.
-Ensure slip clutches are properly adjusted to prevent excessive slippage and plate heating.
(SGM-8)
SAFETY
-Never allow clippings or debris to collect near drivelines, slip clutches, and gearboxes.
Periodically shut down the Tra ctor an d Mo we r and cl ean clip pings an d collected debris fro m
the mower deck.
(SGM-12)
ower is designed for certain mowing applications and is rated to cut up to a spec
size vegetation (see Mower Standard Equipment and Specifications). DO NOT use this
mower to cut vegetation above the Mower’s rated capacity or to cut any type of non-vegetative material. Only
operate this Mower on a properly sized and equipped Tractor. Operating this Mower in an application for
which it is not designed and/or operating the Mower with the wrong size Tractor can cause M o we r c om p on en t
damage and equipment failure resulting in possible serious injury or death.
(SGM-14)
Do not operator or pull the mower into standing water. When uplift or fan type mowe r blades
contact water they can be severely deflected downward causing possible failure of blade
resulting in serious boldly injury to the operator or bystanders.
(SGM-15)
Use extreme caution when raising the Mower above ground level. Stop the Blades from
turning when the Mower is raised and passersby are within 100 yards. Raising the
Mower exposes the Cutting Blades which creates a potentially serious hazard and can cause serious injury
by objects thrown from the Blades or by contact with the Blades.
(SPU-1)
c
A96B 03/06 Safety Section 1-9
© 2006 Alamo Group Inc.
SAFETY
Rotary Mowers are capable under adverse conditions of throwing
objects for great distances (100 yards or more) and causing serious
injury or death. Follow safety messages carefully.
STOP MOWING IF PASSERSBY ARE WITHIN 100 YARDS UNLESS:
-Front and Rear Deflectors, Chain Guards, or Bands are installed and in good, workable
condition;
-Mower sections or Wings are running close to and parallel to the ground without exposed
Blades;
-Passersby are outside the existing thrown-object zone;
-All areas have been thoroughly inspected and all foreign material such as rocks, cans,
glass, and general debris has been removed.
NOTE: Where there are grass and weeds high enough to hide debris that could be struck
SAFETY
by the blades, the area should be: inspected and large debris removed, mowed at an
intermediate height, inspected, closely with any remaining debris being removed, and
mowed again at desired final height. (This will also reduce power required to mow, reduce
wear and tear on the Mower drivetrain, spread cut material better, eliminate streaking, and
make the final cut more uniform).
(SRM-1)
Do Not attempt to raise or lower the implement wing unless the Implement tongue is securely
attached to the Tractor drawbar. The Implement could tip over and cause equipment damage and
possible serious injury or death. Raise or Lower the mower wing only while seated in the Tractor operator’s seat with the
seat belt securely fastened.
(SRM-2)
Do not turn so sharp or lift mower so high to produce a severe "knocking" of the Driveline
which will cause accelerated wear and breakage of drive train components and could result
in possible injury from the separated Driveline sections.
(SRM-4)
Do not let the Blades turn when the Mower Deck is raised for any reason,
including clearance or for turning. Raising the Mower deck exposes the
Cutting Blades which creates a potentially serious hazard and could cause serious injury or
even death from objects thrown from the Blades.
(SRM-7)
DO NOT allow any person under a folded wing unless wing is securely
locked up or supported. DO NOT approach the Implement unless the
Tractor is turned off and all motion has ceased. Never work under the frame work, or any
lifted component unless the implement is securely supported or blocked up. A sudden or
inadvertent fall by any of these components could cause serious injury or even death.
(STI-3)
A96B 03/06 Safety Section 1-10
© 2006 Alamo Group Inc.
SAFETY
Wh
PTO, it is i
t
r
Connecting or Disconnecting Implement Safety Instructions and Practices
DO NOT use a PTO adapter to attach a non-matching Implement driveline to a Tractor
PTO. Use of an adapter can double the operating speed of the Mower resulting in
excessive vibration, thrown objects, and blade and mower failure. Adapter use will also change the working
length of the driveline exposing unshielded driveline areas. Serious bodily injury and/or equipment failure can
result from using a PTO adapter. Consult an authorized dealer for assistance if the Implement driveline does
not match the Tractor PTO.
(S3PT-14)
Always shut the Tractor completely down, place the transmission in park, and set the
parking brake before you or anyone else attempts to connect or disconnect the Implement
and Tractor hitches.
the momentum of the rotating Mower blades driving the Tractor transmission even though the Tractor clutch
has been disengaged. Install an over running clutch between the Tractor PTO and the Mower driveline to
prevent this potentially dangerous situation.
securely in the groove on the Tractor PTO shaft. A driveline not attached correctly to the Tractor PTO shaft
could come loose and result in personal injury and damage to the Implement.
the outer housing until the assembly becomes solid-it can shorten no more. Bottoming out can cause serious
damage to the Tractor PTO by pushing the PTO into the Tractor and through the support bearings or
downward onto the PTO shaft, breaking it off. A broken drive line can cause personal injury.
(S3PT-15)
Never operate the Tractor and Mower if the Im plement input driveline is directly connected
to the Tractor transmission. Tractor braking distances can be substantially increased by
(S3PT-16 )
en attaching the Implement input driveline to the Tractor
connecting yoke spring activated locking collar slides freely and the locking balls are seated
(S3PT-17)
Before operating the Implement, check to make sure the Implement input driveline will not
bottom out or become disengaged. Bottoming out occurs when the inner shaft penetrates
mportant that the
(S3PT-18 )
SAFETY
Transporting Safety Instructions and Practices
Be particularly careful when transporting the Implement with the Tractor. Turn curves or go
up hills only at a low speed and using a gradual steering angle. Rear mounted implements
move the center of gravity to the rear and remove weight from the front wheels. Make certain, by adding fron
ballast, that at least 20% of the tractor’s weight is on the front wheels to prevent rearing up, loss of steering
control or Tractor tip-over. Slow down on rough or uneven surfaces to prev ent loss of st eering co ntrol w hich
could result in property damage or possible injury. Do not transport unless 3-Point lift lever is fully raised and
in the latched transport position. Dropping implement in transport can cause serious damage to the tracto
and/or Implement and possibly cause the operator or others to be injured or killed. (S3PT-2)
A96B 03/06 Safety Section 1-11
© 2006 Alamo Group Inc.
SAFETY
B
Allow sufficient clearance for the Implement to swing outward while turning. Implements
carried behind the Tractor will swing outside the tire path when making turns. Co ntacting a
solid object while turning will cause equipment damage and possible injury.
Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in
such a way as to be clea rly visible and legible. When transporti ng the
Equipment use the Tractor flashing warnin g light s and follow a ll local traffic regulations.
Transport only at safe speeds. Serious accidents and injuries can result
from operating this equipment at unsafe speeds. Understand the Tractor
and Implement and how it handles before transporting on streets and highways. Make
sure the Tractor steering and brakes are in good condition and operate properly.
Before transporting the Tractor an d Implement, de termine th e safe transport speeds for yo u
SAFETY
and the equipment. Make sure you abide by the following rules:
• T est the tra ctor at a slow speed and incr ease the speed slowly. Apply the Brakes
smoothly to determine the stopping characteristics of the Tractor and Implement. As you increase the speed of the Tractor the stopping distance increases.
Determine the maximum safe transport speed for you and this Equipment.
• Test the equipment at a slow speed in turns. Increase the speed through the turn
only after you determine that it is safe to operate at a higher speed. Use extreme
care and reduce your speed when turning sharply to prevent the tractor and
implement from turning over. Determine the maximum safe turning speed for
you and this equipment before operating on roads or uneven ground.
• Only transport the Tractor and Implement at the speeds that you have deter-
mined are safe and which allow you to properly control the equipment.
(S3PT-20)
(SG-6)
Be aware of the operating conditions. Do not operate the Tractor with weak or faulty
brakes. When operating down a hill or on wet or rain slick roads, the braking distance
increases: use extreme care and reduce your speed. When operating in traffic always use
the Tractor’s flashing warning lights and r educe your speed. Be aware of traf fic around you
and watch out for the other guy.
e particularly careful when transporting the Implement using the tractor. Turn curves or
go up or down hills only at a low speed and at a gradual steering angle. Make certain that
at least 20% of the tractor’s weight is on the front wheels to maintain safe steerage. Slow down on rough or
uneven surfaces.
A96B 03/06 Safety Section 1-12
© 2006 Alamo Group Inc.
(STI-1)
(SG-19)
SAFETY
Only t
r
N
ith fact
librati
librati
ld
D
dif
this Impl
dif
thi
ow the Implement behind a properly sized and equipped Tractor
which exceeds the weight of the Implement by at least 20%. DO NOT
tow the Implement behind a truck or ot her type of vehicle. Never tow the Implement and
another Implement connected in tandem. Never tow the Implement at speeds over 20
MPH.
Maintenance and Service Safety Instructions and Practices
(STI-6)
Your driving vision may be reduced or impaired by the tractor, cab, or implement. Before
driving on public roadways identify any limited vision areas, and make adjustments to you
operating position, mirrors, and the implement transport position so that you can clearly see the area where
you will be traveling, and any traffic that may approach you. Failure to maintain adequate vision of the public
roadway and traffic can result in serious injury or even death.
(STI-10)
Make sure the PTO shield, integral driveline shields, and input shields are
is installed when using PTO-driven equipment. Always replace any
shield if it is damaged or missing.
(S3PT-8)
SAFETY
Relieve hydraulic pressure prior to doing any maintenance or repair work
on the Implement. Place the Implement on the ground or securely
blocked up, disengage the PTO, and turn off the tractor engine. Push and pull the Remote
Cylinder lever in and out several times prior to starting any maintenance or
repair work.
(S3PT-9)
Always disconnect the main PTO Driveline from the Tractor before performing service on
the Implement. Never work on the Implement with the tractor PT O d riveline connected a nd
running. Rotating Parts, Blades or Drivelines could turn without warning and cause immediate entanglement,
injury or death.
(S3PT-11)
ever interfere w
ory-set hydraulic ca
ons. Any change in ca
on cou
cause a failure of the equipment and may result in injur y. (SBH-13)
Always maintain the safety decals in good readable condition. If the decals are missing,
damaged, or unreadable, obtain and install replacement decals immediately.
o not mo
Implement, any of its components or any Implement function.
y or alter
ement. Do not permit anyone to mo
(SG-8)
(SG-5)
y or alter
s
A96B 03/06 Safety Section 1-13
© 2006 Alamo Group Inc.
SAFETY
N
lifted
U
dli
ever work under the Implement, the framework, or any
component unless the Implement is securely supported or blocked up
to prevent sudden or inadvertent falling which could cause serious
injury or even death.
Never attempt to lubricate, adjust, or remove material from the Implement while it is in
motion or while tractor engine is running. Make sure the tractor eng ine is off befo re working
on the Implement.
(SG-20)
Periodically inspect all moving parts for wear and replace when
necessary with authorized service parts. Look for loose fasteners, worn
or broken parts, and leaky or loose fittings. Make sure all pins have cotter pins and
washers. Serious injury may occur from not maintaining this machine in good working
SAFETY
order.
(SG-21)
(SG-14)
Do Not fill gasoline tank while engine is running. Refuel on ly af ter engine has coo led down .
If gasoline is spilled, move machine away from the area of the spill and avoid creating any
source of ignition until the gasoline has evaporated.
(SG-28)
Perform service, repairs and lubrication according to the maintenance section. Ensure the
unit is properly lubricated as specified in the lubrication schedule and all bolts and nuts are
properly torqued. Failure to properly service, repair and maintain this Implement in good operating condition
could cause component failure and possible serious injury or even death.
se caution and wear protective gloves when han
(SG-35)
ng sharp objects such as blades,
knives, and other cutting edges. Be alert to worn component surfaces which have sharp
edges. Sharp surfaces can inflict severe laceration injuries if proper hand protection is not worn.
(SG-37)
All Safety Shields, Guards and Safety devices including (but not
limited to) - the Deflectors, Chain Guards, Steel Guards, Gearbox
Shields, PTO integral shields, and Retractable Door Shields should be used and
maintained in good working condition. All safety devices should be inspected
carefully at least daily for missing or broken components. Missing, broken, or worn
items must be replaced at once to reduce the possibility of injury or death from thrown
objects, entanglement, or blade contact.
(SGM-3)
A96B 03/06 Safety Section 1-14
© 2006 Alamo Group Inc.
SAFETY
B
ill b
I
diti
likelihood of
dditi
this Impl
Replace bent or broken blades with new blades. NEVER ATTEMPT TO STRAIGHTEN OR
WELD ON BLADES SINCE THIS WILL LIKELY CRACK OR OTHERWISE DAMAGE THE
BLADE WITH SUBSEQUENT FAILURE AND POSSIBLE SERIOUS INJURY FROM THROWN BLADES.
(SGM-10)
DO NOT weld or repair rotating mower components. Welds and other repairs may cause
severe vibration and/or component failure resulting in part being thrown from the mower
causing serious bodily injury. See your Authorized Dealer for proper repairs.
(SGM-13)
PARTS INFORMATION
Alamo Industrial mowers use balanced and matched system components for blade carriers, blades,
cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and
tested to Alamo Industrial specifications. Non-genuine "will fit" parts do not consistently meet these
specifications. The use of “will fit” parts may reduce mower performance, void mower warranties, and present
a safety hazard. Use genuine Alamo Industrial mower parts for economy and safety.
(SPAM -1 )
SEE YOUR ALAMO DEALER
e sure you have adequate knowledge of the property you w
e working on. Take time to
make yourself aware of any area underground lines or cables. Contact with b uried lines or
cable could result in serious injury or death.
n wet con
ons where there is a
certain that this material is removed before travelling on public roadways.
(STL-1)
material collecting on the Implement, make
(STL-7)
Concluding Safety Instructions and Practices
In a
hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper
training of personnel involved in the operation, transport, maintenance, and storage of the machine. Refer
also to Safety Messages and operation instruction in each of the appropriate sections of the Tractor and
Equipment Manuals. Pay close attention to the Safety Signs affixed to the Tractor and Equipment.
on to the design and configuration of
ement, including Safety Signs and Safety Equipment,
(SG-18)
SAFETY
A96B 03/06 Safety Section 1-15
© 2006 Alamo Group Inc.
Decal Location
SAFETY
SAFETY
NOTE: Alamo supplies safety decals on this product to promote safe operatio n. Dama ge to the d ecals may occu r wh ile in
shipping, use, or reconditioning. Alamo cares about the safety of its customers, operators, and bystanders, and will replace
the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply). Contact your
Alamo dealer to order replacement decals.
A96B 03/06 Safety Section 1-16
© 2006 Alamo Group Inc.
SAFETY
ITEM PART NO. QTY LEVEL DESCRIPTION
1. 00725746 1 PELIGRO Translate Safety Material
2. 00749117 1 DANGER Multiple Hazard
3. 00756004 3 DANGER D/L Shield Missing. Do not operate
4. 00756005 3 DANGER Rotating D/L-Entanglement
5. 00756007 1 WARNING Use/Repair Shields & Guards
6. 00756059 1 DANGER Oil Leak Detection
7. 00756485 2 DANGER Cutting Blades/Thrown Objects
8. 00756494 1 DANGER Driveline Hazards
9. 02925100 1 IMPORTANT Alamo Genuine Parts, Rotary Mower
10. 00773723 1 PELIGRO! Rotating Driveline Translation
11. 03200347 * REFLECTOR SMV Sign
12. 1458392 2 REFLECTOR Red Reflectors
13. 00763977 INSTRUCT Notice to Owner
14. D114** 1 INSTRUCT 1000 RPM . D103** 1 INSTRUCT 540 RPM
15. D132 1 INSTRUCT Blade Timing
16. D137 1 INSTRUCT CCW Blade Rotation
17. D138 1 INSTRUCT CW Blade Rotation
18. 00763613 1 INSTRUCT Slip Clutch
19. 00757139 2 L. NAME Alamo Type ( 5 x15)
20. 02960766 2 LOGO Alamo Logo (4 x 5)
21. 00799875 4 NAME A96B
22. nfs 1 SER PLT A96B Serial No. Plate
23. 1458393 1 REFLECTOR Amber Reflector
24. 00776031 1 Canister, Operators Manual
25. 00761678C 1 Operators Manual
26. 10058000 3 Bolt
27. 00024100 6 Flatwasher
28. 02959924 3 Locknut * Provided by tractor manufacturer
SAFETY
** 540 or 1000 RPM units only. Select correct one.
A96B 03/06 Safety Section 1-17
© 2006 Alamo Group Inc.
SAFETY
SAFETY
NOTE: Alamo supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in
shipping, use, or reconditioning. Alamo cares about the safety of its customers, operators, and bystanders, and will
replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Contact your Alamo dealer to order replacement decals.
A96B 03/06 Safety Section 1-18
© 2006 Alamo Group Inc.
SAFETY
ITEM PART NO. QTY. LEVEL DESCRIPTION
1. 00725746 1 PELIGRO Translate Safety Material
2. 00749117 1 DANGER Multiple Hazard
3. 00756004 3 DANGER D/L Shield Missing. Do Not Operate.
4. 00756005 4 DANGER Rotating D/L - Entanglement
5. 00756007 1 WARNING Use/Repair Shields & Guards
6. 00756059 1 WARNING Oil Leak Detection
7. 00756485 2 DANGER Cutting Blades/Thrown Objects
8. 00756494 1 DANGER Driveline Hazards
9. 00760657 1 IMPORTANT Alamo Genuine Parts, Rotary Mower
10. 00773723 1 PELIGRO! Rotating Driveline Translation
11. 03200347 * REFLECTOR SMV Sign
12. 1458392 2 REFLECTOR Red Reflectors
13. 00763977 1 INSTRUCT Notice to Owner
14. D102 1 INSTRUCT Draw bar-to-PTO Adjustment
15. D114** 1 INSTRUCT 1000 RPM . D103** 1 INSTRUCT 540 RPM
16. D132 1 INSTRUCT Blade Timing
17. D137 1 INSTRUCT CCW Blade Rotation
18. D138 1 INSTRUCT CW Blade Rotation
19. 00763613 1 INSTRUCT Slip Clutch
20. 00757139 2 L. NAME Alamo Type ( 5 x 15)
21. 02960766 2 LOGO Alamo Logo (4 x 5)
22. 00769875 4 NAME A96B
23. nfs 1 SER PLT A96B Serial No. Plate
24. 1458393 1 REFLECTOR Amber Reflector
25. 00776031 1 Canister, Operators Manual
26. 00761678C 1 Operators Manual
27. 10058000 3 Bolt
28. 00024100 6 Flatwasher
29. 02959924 3 Locknut *Provided by tractor manufacturer
SAFETY
** 540 or 1000 RPM units only. Select correct one.
A96B 03/06 Safety Section 1-19
© 2006 Alamo Group Inc.
Decal Description
Peligro Translation, If you do not know how to read
English, please find someone who knows how to
read English.
P/N 00725746
DANGER! Multi-Hazard Decal
(Refer To Front Cover)
SAFETY
SAFETY
P/N 00749117
DANGER! Guard Missing, Do Not Operate. If you
see this decal, Do Not Operate the mower until the
shield has been replaced.
P/N 00756004
DANGER! Rotating Driveline Keep Away, Contact
can cause death.
P/N 00756005
A96B 03/06 Safety Section 1-20
© 2006 Alamo Group Inc.
SAFETY
WARNING! Keep all safety shielding installed,
repaired and replaced when damaged so that
machine stays in safe condition.
P/N 00756007
WARNING! Never use your hand to check for oil
leaks. Always use paper or cardboard.
P/N 00756059
DANGER! Keep Away - Rotating Blades
SAFETY
P/N 00756485
DANGER! Make certain that drivelines are correct
length and are securely attached.
P/N 00756494
A96B 03/06 Safety Section 1-21
© 2006 Alamo Group Inc.
IMPORTANT - Use only Genuine Ala mo Industrial
replacement parts.
P/N 02925100
PELIGRO! Spanish Translation for Driveline Safety
SAFETY
SAFETY
P/N 00773723
Slow Moving Vehicle Decal. Keep SMV reflector
clean and visible. DO NOT transport or operate
without the SMV.
P/N 03200347
Red Reflector. Keep reflectors clean and visible.
P/N 1458392
A96B 03/06 Safety Section 1-22
© 2006 Alamo Group Inc.
Loading...
