AJA RD5CE User Manual [en, de, es, fr, it]
www.aja.com
Installation and Operation
Guide
Because it matters.
RD5CE
Dual Universal
D/A Converter
R-series Card Module
Published: 6/30/10
2
Trademarks
Notice
Contacting Support
®
AJA
are trademarks of AJA Video, Inc. HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC. DVI is a registered trademark of DDWG.
All other trademarks are the property of their respective holders.
Copyright © 2010 AJA Video, Inc. All rights reserved. All information in this manual is subject to
change without notice. No part of the document may be reproduced or transmitted in any form, or by
any means, electronic or mechanical, including photocopying or recording, without the express
written permission of AJA Inc.
To contact AJA Video for sales or support, use any of the following methods:
180 Litton Drive, Grass Valley, CA. 95945 USA
Telephone: 800.251.4224 or 530.274.2048
Fax: 530.274.9442
Web: http://www.aja.com
Support Email: support@aja.com
Sales Email: sales@aja.com
When calling for support, have all information at hand prior to calling.
®
, KONA
, Ki Pro®, and XENA
®
are registered trademarks of AJA Video, Inc. FiDO™, Io HD
™
and Io
™
Limited Warranty
AJA Video warrants that this product will be free from defects in materials and workmanship for a
period of five years from the date of purchase. If a product proves to be defective during this warranty
period, AJA Video, at its option, will either repair the defective product without charge for parts and
labor, or will provide a replacement in exchange for the defective product.
In order to obtain service under this warranty, you the Customer, must notify AJA Video of the defect
before the expiration of the warranty period and make suitable arrangements for the performance of
service. The Customer shall be responsible for packaging and shipping the defective product to a
designated service center nominated by AJA Video, with shipping charges prepaid. AJA Video shall
pay for the return of the product to the Customer if the shipment is to a location within the country in
which the AJA Video service center is located. Customer shall be responsible for paying all shipping
charges, insurance, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or
inadequate maintenance and care. AJA Video shall not be obligated to furnish service under this
warranty a) to repair damage resulting from attempts by personnel other than AJA Video
representatives to install, repair or service the product, b) to repair damage resulting from improper
use or connection to incompatible equipment, c) to repair any damage or malfunction caused by the
use of non-AJA Video parts or supplies, or d) to service a product that has been modified or integrated
with other products when the effect of such a modification or integration increases the time or
difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY AJA VIDEO IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED.
AJA VIDEO AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. AJA VIDEO’S RESPONSIBILITY TO REPAIR OR REPLACE
DEFECTIVE PRODUCTS IS THE WHOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR
ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER AJA
VIDEO OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
•
•
•
•
•
Introduction
Features
AJA RD5CE Dual Universal D/A Converter User Manual
The AJA Video RD5CE is a low-cost, dual-channel, universal video D/A
converter. The RD5CE supports 2 completely separate channels of SDI to
analog conversion. Channel 1 can output component or composite analog
video including YPbPr (SMPTE, EBU-N10), Betacam, RGB, composite or YC (SVideo). Channel 2 can output composite or Y. Both SDI inputs have a reclocked
SDI loop-thru output. The RD5CE fits in AJA's R-Series Frames or other standard
industry rack mount frames.
1
3
RD5CE Card Module, Side View
Low Cost, Universal D/A Conversion
Two Separate Channels
SDI Inputs, Re-Clocked Loop-Thru SDI Outputs
CH 1 Outputs Component or Composite
CH 2 Outputs Composite or Y
4
Block Diagram
SD SDI Video 1
Rackframe
Backplane
I/O Connections
Component/Composite Analog
Composite Analog Video 2
Comp/C/
R/Pr 1
Comp/Y/
B/Pb 1
Video 1
SD SDI Video 2
No Connect
+6.5V Power
From Rackframe
Redundant Supplies
Comp/
-/G/Y 1
J8
J9
Comp Out 2
Digital to Analog Converter
And Composite Encoder
Digital to Analog Converter
And Composite Encoder
Power Regulation
SDI Out 1
J4
J6
J5
J7
SDI Out 2
SDI In 1
J2
J3
REF In
J1
SDI In 2
SDI In 1
SDI Out 1
Comp/-/G/Y 1
Comp/C/R/Pr 1
J2
J4
J6
J8
J1
J3
J5
J7
J9
UNUSED
SDI In 2
SDI Out 2
Comp Out 2
Comp/Y/B/Pb 1
Configuration
Switches
Configuration
Switches
FR1 Frame Layout
RD5CE Rear Panel
FR2 Frame Layout
RD5CE Rear Panel
FR1 and FR2 BNC Connector Assignments, RD5CE Card Module
When the RD5CE module is installed in an AJA FR1 or FR2 frame, a corresponding
group of 9 BNCs on the rear panel then provide I/O for the module. The
illustration above shows the connector assignments for both the FR1 and FR2
when used with the RD5CE.
User Controls and Indicators
The user interface for the RD5CE includes two dipswitches, a six position for control of
Channel 1 and a four position for control of Channel 2 and 2 LEDs.
LED FUNCTION
1 Video present on Channel 1
2 Video present on Channel 2
Channel 1 DIP
Switches
FUNCTION DESCRIPTION DETAILS
AJA RD5CE Dual Universal D/A Converter User Manual
1 Output Selection UP = Component
DOWN = Composite
2 Output Selection UP = YUV/YC if SW1=up Output = YUV, if
SW1=down Output = YC + 1 composite
DOWN = RGB is SW1=up, if SW1=down
Outputs all composite
3 Output Selection UP = BETACAM 525 levels
DOWN = SMPTE/EBU-N10 Levels
4 Blanking UP = Narrow: Vertical
(line numbers indicate where video starts)
line 13, field 1; line 12, field 2 (525 line)
line 10, field 1; line 322, field 2 (625 line)
Horizontal (active video line duration’s)
ITU-R.470 (720 pixels PAL/NTSC)
DOWN = Wide:
line 20, field 1; line 20, field 2 (525 line)
line 23, field 1; line 336, field 2 (625 line)
Horizontal (active video line duration)
ITU-R/SMPTE (710 pixels NTSC, 702 pixels PAL)
1
5
5 Pedestal UP = Add Pedestal
DOWN = No Pedestal
6 Test UP = Normal
DOWN = Color Bar Test Pattern
(Requires valid SDI input)
Channel 2 DIP
Switches
FUNCTION DESCRIPTION DETAILS
1 Output Selection UP = Component
DOWN = Composite
2 Blanking UP = Narrow: Vertical
3 Pedestal UP = Add Pedestal
4 Test UP = Normal
(line numbers indicate where video starts)
line 13, field 1; line 12, field 2 (525 line)
line 10, field 1; line 322, field 2 (625 line)
Horizontal (active video line duration’s)
ITU-R.470 (720 pixels PAL/NTSC)
DOWN = Wide:
line 20, field 1; line 20, field 2 (525 line)
line 23, field 1; line 336, field 2 (625 line)
Horizontal (active video line duration)
ITU-R/SMPTE (710 pixels NTSC, 702 pixels PAL)
DOWN = No Pedestal
DOWN = Color Bar Test Pattern
(Requires valid SDI input)
