AJA OG-FIDO-2T Specifications

OG-FiDO-2T

The OG-FiDO-2T is a state of the art, openGear compatible, 2-channel 3G-SDI to Fiber converter,
enabling 3G-SDI signals to be extended up to 10 km (32,808 ft) over standard single mode fiber
optic cable. The two 3G-SDI inputs are completely independent allowing different 3G-SDI rates to
be carried on each channel.

Designed for use in high density openGear’s 2RU frames including AJA’s OG-X-FR frame, new
DashBoard Software support on Windows®, macOS® and Linux® offers remote control and
monitoring of the openGear architecture and provides convenient and industry standard
configuration, monitoring and control options over a PC or local network.

https://www.aja.com/products/og-fido-2t

Video Formats

150 Mbps - 3 Gbps, format agnostic

openGear standard form factor, front slot and rear card. Two slots
required for each card.

Weight

Video Input Digital

2-Channel independent 3G-SDI BNC Inputs, SMPTE-259/292/424

0.5 lb (0.3 kg)

Power

Video Output Digital

2-Channel independent Single Mode LC Fiber Outputs, SMPTE-297
Nominal Wavelength: 1310 nm
Optical Power: -5dBm (min), 0dBm (max)
Extinction Ratio: 7.5dB (Typ)

Reclocking

270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto
Select
All other rates are passed through and not reclocked

openGear frame compatible, 2.5 watts max per card

Environment

Safe Operating Temperature: 0 to 40 C (32 to 104 F)
Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
Operating Relative Humidity: 10-90% noncondensing
Operating Altitude: <3,000 meters (<10,000 feet)

$645 US MSRP

User Interface

openGear DashBoard network control software via Windows, macOS or
Linux

Size (w x d x h)

OG-FiDO-2T - Spec Sheet

07/26/2019 Page 1 of 1
