Aiwa NSX-D20, NSX-R20 Service Manual

NSX-D20

U

NSX-R20

LH

SERVICE MANUAL

CD STEREO SYSTEM

 Replace this Service manual with Revision Publishing when it is issued.

BASIC TAPE MECHANISM : CMAT6Z2(1+1)ALPS
BASIC CD MECHANISM : BZG-2 ZD9GNC1

S/M Code No. 09-01C-454-0T1

SIMPLE

DATA

ELECTRICAL PARTS LIST

! = ! SAFTY PARTS
C = Components marked

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
AC S D 0091 87-A40-269-080 C-DIODE,MC2836 a .
AC S D 0092 87-A40-270-080 C-DIODE,MC2838 a .
AC X JW 0076 88-100-000-010 PLATING-JW, 0.58 SN95 a .
AC X JW 0092 88-100-000-010 PLATING-JW, 0.58 SN95 a .
AC X JW 0093 88-100-000-010 PLATING-JW, 0.58 SN95 a .
AC X JW 0094 88-100-000-010 PLATING-JW, 0.58 SN95 a .
AC X PR 0003 88-100-000-010 PLATING-JW, 0.58 SN95 a .
AC ! O PT 0002 8B-MA6-671-010 PT,SUB BMA U (VRK) a .
AC O R 0090 87-A01-010-080 RES,SD 2.2M-1/2W J RCR50+ a .
AC ! O RY 0001 87-A91-418-010 RELAY,AC12V G5PA-1-M a .

AC O T 0001 87-A60-317-010 TERMINAL, 1P MSC a .
AC O T 0002 87-A60-317-010 TERMINAL, 1P MSC a .
AC ! O WH 0002 87-A90-510-010 HLDR,WIRE 2.5-9P a .
FUNC/TAPE/E.VR O C 0301 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0302 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0303 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0304 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0305 87-A10-039-080 C-CAP,U 470P-50 J CH a b
FUNC/TAPE/E.VR O C 0310 87-012-274-080 C-CAP,U 1000P-50 K B a b
FUNC/TAPE/E.VR O C 0363 87-010-759-080 C-CAP,U 0.1-25 Z F a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR O C 0451 87-010-759-080 C-CAP,U 0.1-25 Z F a b
FUNC/TAPE/E.VR O C 0452 87-010-406-080 CAP,E 22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0453 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0454 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0455 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0456 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR O C 0457 87-A12-361-080 CAP,M 5600P-100 J CP a b
FUNC/TAPE/E.VR O C 0458 87-012-278-080 C-CAP,U 2200P-50 K B a b
FUNC/TAPE/E.VR O C 0459 87-012-271-080 C-CAP,U 560P-50 K B a b
FUNC/TAPE/E.VR O C 0460 87-012-368-080 C-CAP,S 0.1-50 Z F a b

FUNC/TAPE/E.VR O C 0461 87-012-158-080 C-CAP,S 390P-50 J CH GRM a b
FUNC/TAPE/E.VR O C 0462 87-012-158-080 C-CAP,S 390P-50 J CH GRM a b
FUNC/TAPE/E.VR O C 0463 87-010-759-080 C-CAP,U 0.1-25 Z F a b
FUNC/TAPE/E.VR O C 0464 87-012-278-080 C-CAP,U 2200P-50 K B a b
FUNC/TAPE/E.VR O C 0601 87-012-188-080 C-CAP,U 47P-50 J CH a b
FUNC/TAPE/E.VR O C 0602 87-012-188-080 C-CAP,U 47P-50 J CH a b
FUNC/TAPE/E.VR O C 0603 87-010-263-080 CAP,E 100-10 M 11L SME a b
FUNC/TAPE/E.VR O C 0604 87-010-263-080 CAP,E 100-10 M 11L SME a b
FUNC/TAPE/E.VR O C 0605 87-A12-362-080 CAP,M 6800P-100 J CP a b
FUNC/TAPE/E.VR O C 0606 87-A12-362-080 CAP,M 6800P-100 J CP a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR O C 0607 87-A10-039-080 C-CAP,U 470P-50 J CH a b
FUNC/TAPE/E.VR O C 0608 87-A10-039-080 C-CAP,U 470P-50 J CH a b
FUNC/TAPE/E.VR O C 0609 87-010-401-080 CAP,E 1-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0610 87-010-401-080 CAP,E 1-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0611 87-A12-348-080 C-CAP,U 560P-25 J CH a b
FUNC/TAPE/E.VR O C 0612 87-A12-348-080 C-CAP,U 560P-25 J CH a b
FUNC/TAPE/E.VR O C 0613 87-012-280-080 C-CAP,U 3300P-50 K B a b
FUNC/TAPE/E.VR O C 0614 87-012-280-080 C-CAP,U 3300P-50 K B a b
FUNC/TAPE/E.VR O C 0615 87-010-545-080 CAP,E 0.22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0616 87-010-545-080 CAP,E 0.22-50 M 11L SME a b

FUNC/TAPE/E.VR O C 0617 87-010-545-080 CAP,E 0.22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0618 87-010-545-080 CAP,E 0.22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0625 87-012-198-080 C-CAP,U 180P-50 J CH a b
FUNC/TAPE/E.VR O C 0626 87-012-198-080 C-CAP,U 180P-50 J CH a b
FUNC/TAPE/E.VR O C 0627 87-012-284-080 C-CAP,U 6800P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0628 87-012-284-080 C-CAP,U 6800P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0629 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR O C 0630 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR O C 0631 87-012-278-080 C-CAP,U 2200P-50 K B a b
FUNC/TAPE/E.VR O C 0632 87-012-278-080 C-CAP,U 2200P-50 K B a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR O C 0641 87-010-401-080 CAP,E 1-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0642 87-010-401-080 CAP,E 1-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0651 87-010-248-080 CAP,E 220-10 M 11L SME a b
FUNC/TAPE/E.VR O C 0652 87-010-260-080 CAP,E 47-25 M 11L SME a b
FUNC/TAPE/E.VR O C 0655 87-010-404-080 CAP,E 4.7-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0656 87-010-784-080 C-CAP,U 0.012-25 K B a b
FUNC/TAPE/E.VR O C 0663 87-010-759-080 C-CAP,U 0.1-25 Z F a b
FUNC/TAPE/E.VR O C 0664 87-010-759-080 C-CAP,U 0.1-25 Z F a b
FUNC/TAPE/E.VR O C 0665 87-A10-504-080 C-CAP,U 0.047-16 K B a b
FUNC/TAPE/E.VR O C 0666 87-A10-504-080 C-CAP,U 0.047-16 K B a b

FUNC/TAPE/E.VR O C 0677 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR X CLP0301 87-A60-884-010 PIN,DIA1 COATING-SHS a b
FUNC/TAPE/E.VR X CLP0302 87-A60-884-010 PIN,DIA1 COATING-SHS a b
FUNC/TAPE/E.VR O CN 0301 87-A60-620-010 CONN,3P V 2MM JMT a b
FUNC/TAPE/E.VR O CN 0302 87-A60-625-010 CONN,8P V 2MM JMT a b
FUNC/TAPE/E.VR ! O CN 0601 87-099-719-010 CONN,30P H BLK TYK-B(X) a b
FUNC/TAPE/E.VR ! O CN 0602 87-099-194-010 CONN,6P V BLK 6216 a b
FUNC/TAPE/E.VR S D 0301 87-A40-269-080 C-DIODE,MC2836 a b
FUNC/TAPE/E.VR S D 0661 87-A40-438-080 ZENER,MTZJ4.7A a b
FUNC/TAPE/E.VR S D 0662 87-A40-438-080 ZENER,MTZJ4.7A a b

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

 2 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR X FB 0601 88-118-000-080 C-JUMPER,S a b
FUNC/TAPE/E.VR X FB 0602 88-118-000-080 C-JUMPER,S a b
FUNC/TAPE/E.VR X FB 0603 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR S IC 0601 87-A22-236-040 C-IC,BD3881FV a b
FUNC/TAPE/E.VR O J 0602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN a b
FUNC/TAPE/E.VR X JR 0301 88-108-000-080 C-JUMPER,U a b
FUNC/TAPE/E.VR X JR 0302 88-108-000-080 C-JUMPER,U a b
FUNC/TAPE/E.VR X JR 0303 88-108-000-080 C-JUMPER,U a b
FUNC/TAPE/E.VR X JR 0304 88-129-000-080 C-JUMPER, 3216 a b
FUNC/TAPE/E.VR X JR 0305 88-108-000-080 C-JUMPER,U a b

FUNC/TAPE/E.VR X JR 0306 88-129-000-080 C-JUMPER, 3216 a b
FUNC/TAPE/E.VR X JR 0401 88-129-000-080 C-JUMPER, 3216 a b
FUNC/TAPE/E.VR X JR 0402 88-129-000-080 C-JUMPER, 3216 a b
FUNC/TAPE/E.VR X JR 0403 88-108-000-080 C-JUMPER,U a b
FUNC/TAPE/E.VR X JR 0603 88-108-000-080 C-JUMPER,U a b
FUNC/TAPE/E.VR X JR 0604 88-129-000-080 C-JUMPER, 3216 a b
FUNC/TAPE/E.VR X JR 0605 88-108-000-080 C-JUMPER,U a b
FUNC/TAPE/E.VR X JR 0607 88-108-000-080 C-JUMPER,U a b
FUNC/TAPE/E.VR X JW 0401 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0402 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR X JW 0403 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0501 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0601 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0602 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0604 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0605 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0606 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0607 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0608 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0609 88-100-000-010 PLATING-JW, 0.58 SN95 a b

FUNC/TAPE/E.VR X JW 0610 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0611 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0612 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0614 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0615 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0616 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0617 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0618 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0619 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0620 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR X JW 0621 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0622 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0623 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0624 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0625 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0626 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0627 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR X JW 0641 88-100-000-010 PLATING-JW, 0.58 SN95 a b
FUNC/TAPE/E.VR O L 0451 87-007-342-010 COIL,OSC 85KHZ BIAS a b
FUNC/TAPE/E.VR S Q 0301 87-A30-091-080 FET,2SJ460 a b

FUNC/TAPE/E.VR S Q 0302 87-A30-091-080 FET,2SJ460 a b
FUNC/TAPE/E.VR S Q 0303 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0304 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0305 87-A30-091-080 FET,2SJ460 a b
FUNC/TAPE/E.VR S Q 0306 87-A30-091-080 FET,2SJ460 a b
FUNC/TAPE/E.VR S Q 0307 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0308 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0309 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0451 87-A30-630-080 TR,2SC5343GL a b
FUNC/TAPE/E.VR S Q 0452 87-A30-076-080 C-TR,2SC3052F a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR S Q 0453 89-333-317-880 TR,2SC3331(T/U) a b
FUNC/TAPE/E.VR S Q 0454 89-333-317-880 TR,2SC3331(T/U) a b
FUNC/TAPE/E.VR S Q 0601 87-A30-538-040 C-TR,SRA2202S a b
FUNC/TAPE/E.VR S Q 0651 87-A30-087-080 C-FET,2SK2158 a b
FUNC/TAPE/E.VR S Q 0652 87-A30-087-080 C-FET,2SK2158 a b
FUNC/TAPE/E.VR S Q 0653 87-A30-076-080 C-TR,2SC3052F a b
FUNC/TAPE/E.VR X R 0301 88-108-393-080 C-RES,U 39K-1/16W J a b
FUNC/TAPE/E.VR X R 0302 88-108-393-080 C-RES,U 39K-1/16W J a b
FUNC/TAPE/E.VR X R 0303 88-108-823-080 C-RES,U 82K-1/16W J a b
FUNC/TAPE/E.VR X R 0304 88-108-823-080 C-RES,U 82K-1/16W J a b

FUNC/TAPE/E.VR X R 0305 88-108-224-080 C-RES,U 220K-1/16W J a b
FUNC/TAPE/E.VR X R 0451 88-108-222-080 C-RES,U 2.2K-1/16W J a b
FUNC/TAPE/E.VR X R 0453 88-108-472-080 C-RES,U 4.7K-1/16W J a b
FUNC/TAPE/E.VR X R 0454 88-121-829-080 RES,8.2-1/8W J a b
FUNC/TAPE/E.VR X R 0455 88-108-183-080 C-RES,U 18K-1/16W J a b
FUNC/TAPE/E.VR X R 0456 88-108-183-080 C-RES,U 18K-1/16W J a b
FUNC/TAPE/E.VR X R 0457 88-108-104-080 C-RES,U 100K-1/16W J a b
FUNC/TAPE/E.VR X R 0458 88-108-563-080 C-RES,U 56K-1/16W J a b
FUNC/TAPE/E.VR X R 0459 88-108-472-080 C-RES,U 4.7K-1/16W J a b
FUNC/TAPE/E.VR X R 0469 88-108-150-080 C-RES,U 15-1/16W J a b

 3 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR X R 0601 88-108-680-080 C-RES,U 68-1/16W J a b
FUNC/TAPE/E.VR X R 0602 88-108-680-080 C-RES,U 68-1/16W J a b
FUNC/TAPE/E.VR X R 0603 88-108-394-080 C-RES,U 390K-1/16W J a b
FUNC/TAPE/E.VR X R 0604 88-108-394-080 C-RES,U 390K-1/16W J a b
FUNC/TAPE/E.VR X R 0605 88-108-122-080 C-RES,U 1.2K-1/16W J a b
FUNC/TAPE/E.VR X R 0606 88-108-122-080 C-RES,U 1.2K-1/16W J a b
FUNC/TAPE/E.VR X R 0607 88-108-183-080 C-RES,U 18K-1/16W J a b
FUNC/TAPE/E.VR X R 0608 88-108-183-080 C-RES,U 18K-1/16W J a b
FUNC/TAPE/E.VR X R 0609 88-108-472-080 C-RES,U 4.7K-1/16W J a b
FUNC/TAPE/E.VR X R 0610 88-108-472-080 C-RES,U 4.7K-1/16W J a b

FUNC/TAPE/E.VR X R 0611 88-108-223-080 C-RES,U 22K-1/16W J a .
FUNC/TAPE/E.VR X R 0612 88-108-223-080 C-RES,U 22K-1/16W J a .
FUNC/TAPE/E.VR X R 0613 88-108-273-080 C-RES,U 27K-1/16W J a b
FUNC/TAPE/E.VR X R 0614 88-108-273-080 C-RES,U 27K-1/16W J a b
FUNC/TAPE/E.VR X R 0615 88-108-153-080 C-RES,U 15K-1/16W J a b
FUNC/TAPE/E.VR X R 0616 88-108-153-080 C-RES,U 15K-1/16W J a b
FUNC/TAPE/E.VR X R 0617 88-108-153-080 C-RES,U 15K-1/16W J a b
FUNC/TAPE/E.VR X R 0619 88-108-153-080 C-RES,U 15K-1/16W J a b
FUNC/TAPE/E.VR X R 0621 88-108-332-080 C-RES,U 3.3K-1/16W J a b
FUNC/TAPE/E.VR X R 0622 88-108-332-080 C-RES,U 3.3K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR X R 0623 88-108-332-080 C-RES,U 3.3K-1/16W J a b
FUNC/TAPE/E.VR X R 0624 88-108-332-080 C-RES,U 3.3K-1/16W J a b
FUNC/TAPE/E.VR X R 0625 88-108-682-080 C-RES,U 6.8K-1/16W J a b
FUNC/TAPE/E.VR X R 0626 88-108-682-080 C-RES,U 6.8K-1/16W J a b
FUNC/TAPE/E.VR X R 0627 88-108-222-080 C-RES,U 2.2K-1/16W J a b
FUNC/TAPE/E.VR X R 0628 88-108-222-080 C-RES,U 2.2K-1/16W J a b
FUNC/TAPE/E.VR X R 0629 88-108-103-080 C-RES,U 10K-1/16W J a b
FUNC/TAPE/E.VR X R 0630 88-108-103-080 C-RES,U 10K-1/16W J a b
FUNC/TAPE/E.VR X R 0631 88-108-222-080 C-RES,U 2.2K-1/16W J a b
FUNC/TAPE/E.VR X R 0632 88-108-222-080 C-RES,U 2.2K-1/16W J a b

FUNC/TAPE/E.VR X R 0633 88-108-272-080 C-RES,U 2.7K-1/16W J a b
FUNC/TAPE/E.VR X R 0634 88-108-272-080 C-RES,U 2.7K-1/16W J a b
FUNC/TAPE/E.VR X R 0635 88-108-102-080 C-RES,U 1K-1/16W J a b
FUNC/TAPE/E.VR X R 0636 88-108-102-080 C-RES,U 1K-1/16W J a b
FUNC/TAPE/E.VR X R 0637 88-108-102-080 C-RES,U 1K-1/16W J a b
FUNC/TAPE/E.VR X R 0638 88-108-102-080 C-RES,U 1K-1/16W J a b
FUNC/TAPE/E.VR X R 0639 88-108-183-080 C-RES,U 18K-1/16W J a b
FUNC/TAPE/E.VR X R 0640 88-108-183-080 C-RES,U 18K-1/16W J a b
FUNC/TAPE/E.VR X R 0641 88-121-223-080 RES,22K-1/8W J a b
FUNC/TAPE/E.VR X R 0642 88-108-222-080 C-RES,U 2.2K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR X R 0643 88-108-104-080 C-RES,U 100K-1/16W J a b
FUNC/TAPE/E.VR X R 0644 88-108-104-080 C-RES,U 100K-1/16W J a b
FUNC/TAPE/E.VR X R 0649 88-108-332-080 C-RES,U 3.3K-1/16W J a b
FUNC/TAPE/E.VR X R 0650 88-108-332-080 C-RES,U 3.3K-1/16W J a b
FUNC/TAPE/E.VR X R 0651 88-108-101-080 C-RES,U 100-1/16W J a b
FUNC/TAPE/E.VR X R 0652 88-108-101-080 C-RES,U 100-1/16W J a b
FUNC/TAPE/E.VR X R 0656 88-121-394-080 RES,390K-1/8W J a b
FUNC/TAPE/E.VR X R 0657 88-108-274-080 C-RES,U 270K-1/16W J a b
FUNC/TAPE/E.VR X R 0658 88-108-274-080 C-RES,U 270K-1/16W J a b
FUNC/TAPE/E.VR X R 0659 88-108-394-080 C-RES,U 390K-1/16W J a b

FUNC/TAPE/E.VR X R 0660 88-108-274-080 C-RES,U 270K-1/16W J a b
FUNC/TAPE/E.VR X R 0661 88-108-392-080 C-RES,U 3.9K-1/16W J a b
FUNC/TAPE/E.VR X R 0662 88-108-392-080 C-RES,U 3.9K-1/16W J a b
FUNC/TAPE/E.VR X R 0669 88-108-223-080 C-RES,U 22K-1/16W J . b
FUNC/TAPE/E.VR X R 0670 88-108-223-080 C-RES,U 22K-1/16W J . b
FUNC/TAPE/E.VR X R 0672 88-108-223-080 C-RES,U 22K-1/16W J a b
FUNC/TAPE/E.VR X R 0673 88-108-392-080 C-RES,U 3.9K-1/16W J a b
FUNC/TAPE/E.VR X R 0674 88-108-273-080 C-RES,U 27K-1/16W J a b
FUNC/TAPE/E.VR X R 0676 88-108-563-080 C-RES,U 56K-1/16W J . b
FUNC/TAPE/E.VR X R 0677 88-108-223-080 C-RES,U 22K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
FUNC/TAPE/E.VR X R 0678 88-108-223-080 C-RES,U 22K-1/16W J a b
FUNC/TAPE/E.VR O SFR0451 87-024-435-080 SFR,33K H RH063MC a b
FUNC/TAPE/E.VR O SFR0452 87-024-435-080 SFR,33K H RH063MC a b
MIC O C 0401 87-012-282-080 C-CAP,U 4700P-50 K B . b
MIC O C 0402 87-010-112-040 CAP,E 100-16 M 11L SME . b
MIC O C 0403 87-010-545-040 CAP,E 0.22-50 M 11L SME . b
MIC O C 0404 87-012-191-080 C-CAP,U 68P-50 J CH . b
MIC O C 0405 87-010-545-040 CAP,E 0.22-50 M 11L SME . b
MIC O C 0406 87-010-545-040 CAP,E 0.22-50 M 11L SME . b
MIC O C 0407 87-010-405-040 CAP,E 10-50 M 11L SME . b

MIC O C 0408 87-012-195-080 C-CAP,U 100P-50 J CH . b
MIC O C 0409 87-010-265-040 CAP,E 33-16 M 11L SME . b
MIC O C 0410 87-010-829-080 C-CAP,U 0.047-16 Z F . b
MIC O C 0413 87-010-177-080 C-CAP,S 820P-50 J SL C2012 . b
MIC O FB 0401 87-008-372-080 FLTR,EMI BL01 RN1 . b
MIC O J 0401 87-A61-243-010 JACK,6.3 BLK MONO W/SW V MSC . b
MIC X JR 0402 88-108-000-080 C-JUMPER,U . b
MIC X JR 0403 88-108-000-080 C-JUMPER,U . b
MIC X JR 0404 88-108-000-080 C-JUMPER,U . b
MIC X JR 0405 88-108-000-080 C-JUMPER,U . b

 4 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
MIC X JW 0401 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0402 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0403 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0404 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0405 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0406 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0407 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0411 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0412 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC X JW 0414 88-100-000-010 PLATING-JW, 0.58 SN95 . b

MIC X JW 0415 88-100-000-010 PLATING-JW, 0.58 SN95 . b
MIC S Q 0401 87-A30-076-080 C-TR,2SC3052F . b
MIC S Q 0402 87-A30-075-080 C-TR,2SA1235F . b
MIC S Q 0403 87-A30-076-080 C-TR,2SC3052F . b
MIC S Q 0404 87-A30-075-080 C-TR,2SA1235F . b
MIC S Q 0405 87-A30-087-080 C-FET,2SK2158 . b
MIC S Q 0406 87-A30-076-080 C-TR,2SC3052F . b
MIC X R 0401 88-108-472-080 C-RES,U 4.7K-1/16W J . b
MIC X R 0402 88-108-104-080 C-RES,U 100K-1/16W J . b
MIC X R 0403 88-128-101-080 C-RES, 100-1/8W J . b

CX-SND20 CX-SNR20
USC1 LHSC1
MIC X R 0404 88-108-222-080 C-RES,U 2.2K-1/16W J . b
MIC X R 0405 88-108-102-080 C-RES,U 1K-1/16W J . b
MIC X R 0406 88-108-334-080 C-RES,U 330K-1/16W J . b
MIC X R 0407 88-108-333-080 C-RES,U 33K-1/16W J . b
MIC X R 0408 88-108-562-080 C-RES,U 5.6K-1/16W J . b
MIC X R 0409 88-108-101-080 C-RES,U 100-1/16W J . b
MIC X R 0410 88-108-153-080 C-RES,U 15K-1/16W J . b
MIC X R 0411 88-108-561-080 C-RES,U 560-1/16W J . b
MIC X R 0412 88-108-274-080 C-RES,U 270K-1/16W J . b
MIC X R 0413 88-108-223-080 C-RES,U 22K-1/16W J . b

MIC X R 0414 88-108-102-080 C-RES,U 1K-1/16W J . b
MIC X R 0415 88-108-000-080 C-JUMPER,U . b
MIC X R 0416 88-108-224-080 C-RES,U 220K-1/16W J . b
MIC X R 0417 88-108-334-080 C-RES,U 330K-1/16W J . b
MIC X R 0418 88-108-154-080 C-RES,U 150K-1/16W J . b
MIC X R 0720 88-108-101-080 C-RES,U 100-1/16W J . b
MIC O VR 0401 86-NFA-607-010 VR,RTRY 10K15AX1 1 V XV0121PVN . b
MICON X * 8C-NF9-620-010 PWB,COMB FRONT CNF-9 a b
MICON X * 8C-NF9-621-010 PWB,FRONT CNF-9 a b
MICON X * 8C-NF9-623-010 PWB,HLDR WIRE CNF-9 a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X * 8C-NF9-624-010 PWB,HLDR MIC CNF-9 . b
MICON X * 8C-NF9-622-010 PWB,MIC CNF-9 . b
MICON O C 0108 87-010-785-080 C-CAP,U 0.015-25 K B GRM a b
MICON O C 0153 87-010-787-080 C-CAP,U 0.022-25 K B a b
MICON O C 0154 87-010-246-040 CAP,E 47-35 M 11L SME a b
MICON O C 0155 87-010-404-040 CAP,E 4.7-50 M 11L SME a b
MICON O C 0156 87-010-404-040 CAP,E 4.7-50 M 11L SME a b
MICON O C 0301 87-012-278-080 C-CAP,U 2200P-50 K B a b
MICON O C 0351 87-A10-353-080 C-CAP,U 0.22-10 K B a b
MICON O C 0361 87-012-274-080 C-CAP,U 1000P-50 K B a b

MICON O C 0362 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0371 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0372 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0601 87-010-382-040 CAP,E 22-25 M 11L SME a b
MICON O C 0801 87-A10-353-080 C-CAP,U 0.22-10 K B a b
MICON O C 0803 87-012-280-080 C-CAP,U 3300P-50 K B a b
MICON O C 0804 87-A10-592-080 C-CAP,S 0.015-50 J B a b
MICON O C 0806 87-012-273-080 C-CAP,U 820P-50 K B a b
MICON O C 0808 87-010-544-040 CAP,E 0.1-50 M 11L SME a b
MICON O C 0809 87-010-404-040 CAP,E 4.7-50 M 11L SME a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON O C 0810 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0811 87-A12-052-080 C-CAP,S 0.033-25 J B a b
MICON O C 0812 87-012-285-080 C-CAP,U 8200P-50 K B GRM a b
MICON O C 0901 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0902 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0903 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0904 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0905 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0906 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0907 87-012-195-080 C-CAP,U 100P-50 J CH a b

MICON O C 0908 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0909 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0910 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0911 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0912 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0913 87-A10-189-040 CAP,E 220-10 M 5L a b
MICON O C 0915 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0916 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0917 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0919 87-012-286-080 C-CAP,U 0.01-25 K B a b

 5 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
MICON O C 0920 87-010-829-080 C-CAP,U 0.047-16 Z F a b
MICON O C 0921 87-012-282-080 C-CAP,U 4700P-50 K B a b
MICON O C 0922 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0923 87-016-116-080 C-CAP,U 0.015-25 J B CB a b
MICON O C 0924 87-016-116-080 C-CAP,U 0.015-25 J B CB a b
MICON O C 0925 87-016-116-080 C-CAP,U 0.015-25 J B CB a b
MICON O C 0931 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0932 87-012-195-080 C-CAP,U 100P-50 J CH a b
MICON O C 0951 87-012-172-080 C-CAP,U 10P-50 D CH a b
MICON O C 0952 87-010-854-080 C-CAP,S 560P-50 J CH a b

MICON O C 0953 87-012-349-080 C-CAP,S 1000P-50 J CH GRM a b
MICON O C 0961 87-010-391-040 CAP,E 10-35 M 11L SME a b
MICON O C 0962 87-012-336-080 C-CAP,U 330P-50 J SL a b
MICON O C 0963 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON ! O CN 0103 87-099-013-010 CONN,11P V BLK 6216 a b
MICON ! O CN 0701 87-099-720-010 CONN,30P BLK TYK-B(P) a b
MICON ! O CN 0731 87-099-196-010 CONN,8P V BLK 6216 a b
MICON S D 0103 87-020-465-080 DIODE,1SS133 a b
MICON S D 0104 87-020-465-080 DIODE,1SS133 a b
MICON S D 0301 87-A40-234-080 ZENER,MTZJ5.6A a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON S D 0302 87-020-465-080 DIODE,1SS133 a b
MICON S D 0601 87-A40-269-080 C-DIODE,MC2836 a b
MICON S D 0801 87-020-465-080 DIODE,1SS133 a b
MICON S D 0981 87-020-465-080 DIODE,1SS133 a b
MICON S D 0982 87-020-465-080 DIODE,1SS133 . b
MICON O FL 0201 8C-NF9-615-010 FL,HUA-13SS09T a b
MICON S IC 0901 8C-NF9-610-030 C-IC,UPD780226GF-033-3BA a b
MICON S IC 0961 87-A21-831-010 IC,SPS-442-1-F1 a b
MICON X JR 0101 88-108-000-080 C-JUMPER,U a b
MICON X JR 0621 88-108-000-080 C-JUMPER,U a b

MICON X JR 0901 88-108-000-080 C-JUMPER,U a b
MICON X JR 0902 88-108-000-080 C-JUMPER,U a b
MICON X JR 0903 88-108-000-080 C-JUMPER,U a b
MICON X JR 0904 88-108-000-080 C-JUMPER,U a b
MICON X JR 0905 88-108-000-080 C-JUMPER,U a b
MICON X JR 0965 88-108-000-080 C-JUMPER,U a b
MICON X JW 0101 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0103 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0104 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0105 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X JW 0106 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0107 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0108 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0109 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0110 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0151 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0152 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0201 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0209 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0301 88-100-000-010 PLATING-JW, 0.58 SN95 a b

MICON X JW 0302 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0303 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0304 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0305 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0306 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0307 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0308 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0309 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0310 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0311 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X JW 0312 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0313 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0314 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0315 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0316 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0317 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0318 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0319 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0320 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0321 88-100-000-010 PLATING-JW, 0.58 SN95 a b

MICON X JW 0322 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0323 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0324 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0325 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0326 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0327 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0328 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0329 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0330 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0331 88-100-000-010 PLATING-JW, 0.58 SN95 a b

 6 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X JW 0601 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0602 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0603 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0606 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0607 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0608 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0609 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0610 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0611 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0612 88-100-000-010 PLATING-JW, 0.58 SN95 a b

MICON X JW 0613 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0614 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0616 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0617 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0618 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0619 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0620 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0701 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0703 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0704 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X JW 0705 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0706 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0707 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0709 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0710 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0711 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0712 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0713 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0731 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0732 88-100-000-010 PLATING-JW, 0.58 SN95 a b

MICON X JW 0801 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0803 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0804 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0805 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0806 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0807 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0808 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0809 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0901 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0902 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X JW 0903 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0904 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0905 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0906 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0907 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0908 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0909 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0910 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0912 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0913 88-100-000-010 PLATING-JW, 0.58 SN95 a b

MICON X JW 0914 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0915 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0916 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0917 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0918 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0919 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0920 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0921 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0922 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0923 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X JW 0925 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0926 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0927 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0928 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0929 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0930 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0931 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0932 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0933 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0934 88-100-000-010 PLATING-JW, 0.58 SN95 a b

MICON X JW 0935 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0936 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0937 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0938 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0939 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0940 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0941 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0942 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0943 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0944 88-100-000-010 PLATING-JW, 0.58 SN95 a b

 7 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X JW 0945 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0946 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0947 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0948 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0950 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0951 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0952 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0953 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0954 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0956 88-100-000-010 PLATING-JW, 0.58 SN95 a b

MICON X JW 0957 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0958 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0959 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0960 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0961 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0962 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X JW 0963 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON O L 0951 87-A50-655-010 COIL,CLK 4.19MHZ (TOKO)7KLY a b
MICON O LED0201 87-A41-062-040 LED,LTL-1CHEE-012A RED a b
MICON S Q 0102 87-A30-076-080 C-TR,2SC3052F a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON S Q 0104 87-A30-538-040 C-TR,SRA2202S a b
MICON S Q 0301 87-A30-494-080 TR,2SA1980G a b
MICON S Q 0302 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0303 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0601 87-A30-495-080 TR,2SA1981Y a b
MICON S Q 0602 87-A30-495-080 TR,2SA1981Y a b
MICON S Q 0603 87-A30-200-080 TR,2SA1585SR a b
MICON S Q 0801 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0802 87-A30-075-080 C-TR,2SA1235F a b
MICON S Q 0803 87-A30-076-080 C-TR,2SC3052F a b

MICON S Q 0804 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0805 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0901 87-A30-538-040 C-TR,SRA2202S a b
MICON X R 0109 88-108-224-080 C-RES,U 220K-1/16W J a b
MICON X R 0110 88-108-153-080 C-RES,U 15K-1/16W J a b
MICON X R 0111 88-108-333-080 C-RES,U 33K-1/16W J a b
MICON X R 0112 88-108-224-080 C-RES,U 220K-1/16W J a b
MICON X R 0114 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0115 88-108-000-080 C-JUMPER,U a b
MICON X R 0116 88-108-124-080 C-RES,U 120K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0151 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X R 0152 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X R 0153 88-128-821-080 C-RES, 820-1/8W J a b
MICON X R 0154 88-128-821-080 C-RES, 820-1/8W J a b
MICON X R 0155 88-108-332-080 C-RES,U 3.3K-1/16W J a b
MICON X R 0156 88-108-332-080 C-RES,U 3.3K-1/16W J a b
MICON X R 0161 88-108-000-080 C-JUMPER,U a b
MICON X R 0162 88-108-000-080 C-JUMPER,U a b
MICON X R 0163 88-108-000-080 C-JUMPER,U a b
MICON X R 0164 88-108-000-080 C-JUMPER,U a b

MICON X R 0165 88-108-000-080 C-JUMPER,U a b
MICON X R 0166 88-108-000-080 C-JUMPER,U a b
MICON X R 0208 88-128-102-080 C-RES, 1K-1/8W J a b
MICON X R 0301 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0302 88-108-472-080 C-RES,U 4.7K-1/16W J a b
MICON X R 0303 88-108-153-080 C-RES,U 15K-1/16W J a b
MICON X R 0304 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0306 88-108-471-080 C-RES,U 470-1/16W J a b
MICON X R 0321 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0322 88-108-102-080 C-RES,U 1K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0323 88-108-821-080 C-RES,U 820-1/16W J a b
MICON X R 0324 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0325 88-108-122-080 C-RES,U 1.2K-1/16W J a b
MICON X R 0326 88-121-122-080 RES,1.2K-1/8W J a b
MICON X R 0327 88-108-182-080 C-RES,U 1.8K-1/16W J a b
MICON X R 0328 88-121-182-080 RES,1.8K-1/8W J a b
MICON X R 0329 88-108-272-080 C-RES,U 2.7K-1/16W J a b
MICON X R 0330 88-108-332-080 C-RES,U 3.3K-1/16W J a b
MICON X R 0331 88-121-472-080 RES,4.7K-1/8W J a b
MICON X R 0332 88-108-682-080 C-RES,U 6.8K-1/16W J a b

MICON X R 0333 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0334 88-108-183-080 C-RES,U 18K-1/16W J a b
MICON X R 0335 88-108-183-080 C-RES,U 18K-1/16W J a b
MICON X R 0341 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0342 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0343 88-108-821-080 C-RES,U 820-1/16W J a b
MICON X R 0344 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0345 88-108-122-080 C-RES,U 1.2K-1/16W J a b
MICON X R 0346 88-108-122-080 C-RES,U 1.2K-1/16W J a b
MICON X R 0347 88-108-182-080 C-RES,U 1.8K-1/16W J a b

 8 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0348 88-108-182-080 C-RES,U 1.8K-1/16W J a b
MICON X R 0361 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0362 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0363 88-108-100-080 C-RES,U 10-1/16W J a b
MICON X R 0364 88-108-100-080 C-RES,U 10-1/16W J a b
MICON X R 0371 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0372 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0373 88-108-100-080 C-RES,U 10-1/16W J a b
MICON X R 0374 88-108-100-080 C-RES,U 10-1/16W J a b
MICON X R 0601 88-108-103-080 C-RES,U 10K-1/16W J a b

MICON X R 0602 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MICON X R 0603 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0604 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MICON X R 0605 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0606 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0607 88-108-000-080 C-JUMPER,U a b
MICON X R 0611 88-108-473-080 C-RES,U 47K-1/16W J a b
MICON X R 0612 88-108-473-080 C-RES,U 47K-1/16W J a b
MICON X R 0613 88-108-473-080 C-RES,U 47K-1/16W J a b
MICON X R 0614 88-108-473-080 C-RES,U 47K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0615 88-108-473-080 C-RES,U 47K-1/16W J a b
MICON X R 0617 88-108-473-080 C-RES,U 47K-1/16W J a b
MICON X R 0618 88-108-473-080 C-RES,U 47K-1/16W J a b
MICON X R 0704 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0705 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0706 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0707 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0708 88-121-102-080 RES,1K-1/8W J a b
MICON X R 0709 88-108-101-080 C-RES,U 100-1/16W J a b
MICON X R 0710 88-128-101-080 C-RES, 100-1/8W J a b

MICON X R 0711 88-108-101-080 C-RES,U 100-1/16W J a b
MICON X R 0712 88-108-101-080 C-RES,U 100-1/16W J a b
MICON X R 0719 88-108-100-080 C-RES,U 10-1/16W J a b
MICON X R 0721 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0730 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0732 88-108-101-080 C-RES,U 100-1/16W J a b
MICON X R 0733 88-108-101-080 C-RES,U 100-1/16W J a b
MICON X R 0734 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0735 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0740 88-108-102-080 C-RES,U 1K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0741 88-108-101-080 C-RES,U 100-1/16W J a b
MICON X R 0742 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0743 88-108-474-080 C-RES,U 470K-1/16W J a b
MICON X R 0744 88-108-823-080 C-RES,U 82K-1/16W J a b
MICON X R 0745 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0749 88-108-474-080 C-RES,U 470K-1/16W J a b
MICON X R 0803 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0804 88-108-224-080 C-RES,U 220K-1/16W J a b
MICON X R 0805 88-108-273-080 C-RES,U 27K-1/16W J a b
MICON X R 0806 88-108-562-080 C-RES,U 5.6K-1/16W J a b

MICON X R 0807 88-108-000-080 C-JUMPER,U a b
MICON X R 0808 88-121-101-080 RES,100-1/8W J a b
MICON X R 0809 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0810 88-108-182-080 C-RES,U 1.8K-1/16W J a b
MICON X R 0811 88-108-224-080 C-RES,U 220K-1/16W J a b
MICON X R 0813 88-108-224-080 C-RES,U 220K-1/16W J a b
MICON X R 0815 88-108-272-080 C-RES,U 2.7K-1/16W J a b
MICON X R 0816 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0818 88-108-224-080 C-RES,U 220K-1/16W J a b
MICON X R 0819 88-108-222-080 C-RES,U 2.2K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0820 88-108-101-080 C-RES,U 100-1/16W J a b
MICON X R 0821 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0822 88-108-224-080 C-RES,U 220K-1/16W J a b
MICON X R 0823 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X R 0824 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X R 0825 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MICON X R 0826 88-108-000-080 C-JUMPER,U a b
MICON X R 0827 88-108-473-080 C-RES,U 47K-1/16W J a b
MICON X R 0901 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0902 88-108-104-080 C-RES,U 100K-1/16W J a b

MICON X R 0903 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0904 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0905 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0906 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0907 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0908 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0909 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0910 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0911 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0912 88-108-104-080 C-RES,U 100K-1/16W J a b

 9 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0913 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0914 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0915 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0916 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0917 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0918 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0919 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0920 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0921 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0922 88-108-104-080 C-RES,U 100K-1/16W J a b

MICON X R 0923 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0924 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0925 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0926 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0927 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0928 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0929 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0930 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0931 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0932 88-108-104-080 C-RES,U 100K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0933 88-121-104-080 RES,100K-1/8W J a b
MICON X R 0934 88-108-683-080 C-RES,U 68K-1/16W J a b
MICON X R 0935 88-108-683-080 C-RES,U 68K-1/16W J a b
MICON X R 0936 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0937 88-128-472-080 C-RES, 4.7K-1/8W J a b
MICON X R 0938 88-108-472-080 C-RES,U 4.7K-1/16W J a b
MICON X R 0939 88-108-472-080 C-RES,U 4.7K-1/16W J a b
MICON X R 0940 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0941 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0942 88-108-103-080 C-RES,U 10K-1/16W J a b

MICON X R 0943 88-121-472-080 RES,4.7K-1/8W J a b
MICON X R 0946 88-108-000-080 C-JUMPER,U a b
MICON X R 0947 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0948 88-121-104-080 RES,100K-1/8W J a b
MICON X R 0951 88-108-102-080 C-RES,U 1K-1/16W J a b
MICON X R 0955 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0956 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0957 88-108-104-080 C-RES,U 100K-1/16W J a b
MICON X R 0958 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0959 88-108-103-080 C-RES,U 10K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON X R 0961 88-121-181-080 RES,180-1/8W J a b
MICON X R 0963 88-108-563-080 C-RES,U 56K-1/16W J a b
MICON X R 0969 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0981 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0982 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0983 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0984 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0985 88-121-103-080 RES,10K-1/8W J a b
MICON X R 0986 88-121-103-080 RES,10K-1/8W J a b
MICON X R 0987 88-108-103-080 C-RES,U 10K-1/16W J a b

MICON X R 0988 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON X R 0989 88-108-103-080 C-RES,U 10K-1/16W J a b
MICON O S 0321 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0322 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0323 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0324 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0325 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0326 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0327 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0328 87-A90-164-080 SW,TACT SKQNAB(N) a b

CX-SND20 CX-SNR20
USC1 LHSC1
MICON O S 0329 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0330 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0331 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0332 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0333 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0334 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0335 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0341 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0342 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0343 87-A90-164-080 SW,TACT SKQNAB(N) a b

MICON O S 0344 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0345 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0346 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0347 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0348 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0361 87-A92-370-010 SW,RTRY RE012307PVB30F a b
MICON O S 0371 87-A92-371-010 SW,RTRY RE0123PVB30F a b
POWER AMP O C 0101 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
POWER AMP O C 0102 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
POWER AMP O C 0103 87-010-546-080 CAP,E 0.33-50 M 11L SME a b

 10 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP O C 0104 87-010-546-080 CAP,E 0.33-50 M 11L SME a b
POWER AMP O C 0107 87-010-405-080 CAP,E 10-50 M 11L SME a b
POWER AMP O C 0108 87-010-405-080 CAP,E 10-50 M 11L SME a b
POWER AMP O C 0111 87-010-407-080 CAP,E 33-50 M 11L SME a b
POWER AMP O C 0112 87-010-407-080 CAP,E 33-50 M 11L SME a b
POWER AMP O C 0113 87-012-195-080 C-CAP,U 100P-50 J CH a .
POWER AMP O C 0113 87-A10-596-080 C-CAP,S 100P-100 J CH . b
POWER AMP O C 0114 87-012-195-080 C-CAP,U 100P-50 J CH a .
POWER AMP O C 0114 87-A10-596-080 C-CAP,S 100P-100 J CH . b
POWER AMP O C 0117 87-012-368-080 C-CAP,S 0.1-50 Z F a b

POWER AMP O C 0118 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0119 87-012-286-080 C-CAP,U 0.01-25 K B a b
POWER AMP O C 0120 87-012-286-080 C-CAP,U 0.01-25 K B a b
POWER AMP O C 0121 87-010-401-080 CAP,E 1-50 M 11L SME a b
POWER AMP O C 0122 87-010-401-080 CAP,E 1-50 M 11L SME a b
POWER AMP O C 0123 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a b
POWER AMP O C 0124 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a b
POWER AMP O C 0125 87-012-195-080 C-CAP,U 100P-50 J CH a .
POWER AMP O C 0125 87-A10-596-080 C-CAP,S 100P-100 J CH . b
POWER AMP O C 0126 87-012-195-080 C-CAP,U 100P-50 J CH a .

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP O C 0126 87-A10-596-080 C-CAP,S 100P-100 J CH . b
POWER AMP O C 0133 87-012-282-080 C-CAP,U 4700P-50 K B a b
POWER AMP O C 0140 87-012-278-080 C-CAP,U 2200P-50 K B a b
POWER AMP O C 0145 87-010-971-080 C-CAP,S 4700P-50 J B a b
POWER AMP O C 0146 87-010-971-080 C-CAP,S 4700P-50 J B a b
POWER AMP O C 0186 87-010-759-080 C-CAP,U 0.1-25 Z F a b
POWER AMP O C 0187 87-A12-890-080 CAP,E 10-63 VR a b
POWER AMP O C 0188 87-A12-890-080 CAP,E 10-63 VR a b
POWER AMP O C 0190 87-012-188-080 C-CAP,U 47P-50 J CH a .
POWER AMP O C 0190 87-012-180-080 C-CAP,U 22P-50 J CH . b

POWER AMP O C 0201 87-A10-260-080 C-CAP,U 0.1-16 K B a b
POWER AMP O C 0225 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0226 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0227 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0228 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0241 87-010-759-080 C-CAP,U 0.1-25 Z F a b
POWER AMP X CLP0230 87-A60-884-010 PIN,DIA1 COATING-SHS . b
POWER AMP S D 0101 87-A40-269-080 C-DIODE,MC2836 a b
POWER AMP S D 0103 87-020-465-080 DIODE,1SS133 a b
POWER AMP S D 0104 87-020-465-080 DIODE,1SS133 a b

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP S D 0105 87-A40-269-080 C-DIODE,MC2836 a b
POWER AMP S D 0106 87-A40-269-080 C-DIODE,MC2836 a b
POWER AMP S D 0107 87-A40-270-080 C-DIODE,MC2838 a b
POWER AMP S D 0108 87-A40-270-080 C-DIODE,MC2838 a b
POWER AMP S D 0109 87-A40-488-080 DIODE,1SS244 a b
POWER AMP S D 0110 87-A40-488-080 DIODE,1SS244 a b
POWER AMP S D 0150 87-A40-270-080 C-DIODE,MC2838 a b
POWER AMP S D 0160 87-A40-270-080 C-DIODE,MC2838 a b
POWER AMP S D 0185 87-A40-393-090 DIODE,1N5402GW(F20) a b
POWER AMP S D 0186 87-A40-393-090 DIODE,1N5402GW(F20) a b

POWER AMP S D 0187 87-A40-871-080 ZENER,MTZJ5.6C a b
POWER AMP S D 0188 87-017-931-080 ZENER,MTZJ5.6B a b
POWER AMP S D 0189 87-A40-270-080 C-DIODE,MC2838 a b
POWER AMP S D 0190 87-A40-269-080 C-DIODE,MC2836 a b
POWER AMP S D 0191 87-A40-345-080 ZENER,MTZJ10C a b
POWER AMP S D 0192 87-020-465-080 DIODE,1SS133 a b
POWER AMP S D 0193 87-020-465-080 DIODE,1SS133 a b
POWER AMP S D 0280 87-A40-269-080 C-DIODE,MC2836 a b
POWER AMP S D 0281 87-A40-270-080 C-DIODE,MC2838 a b
POWER AMP O J 0201 87-A60-420-010 JACK,3.5 ST (MSC) a .

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP ! O J 0203 87-033-229-010 TERMINAL,SPKR 4P YKD21-0242 a .
POWER AMP ! O J 0203 87-A60-238-010 TERMINAL,SP 4P (MSC) . b
POWER AMP O J 0230 87-A60-420-010 JACK,3.5 ST (MSC) . b
POWER AMP X JR 0101 88-108-000-080 C-JUMPER,U a b
POWER AMP X JR 0102 88-108-000-080 C-JUMPER,U a b
POWER AMP X JR 0103 88-108-000-080 C-JUMPER,U a b
POWER AMP X JR 0104 88-108-000-080 C-JUMPER,U a b
POWER AMP X JR 0109 88-108-000-080 C-JUMPER,U a b
POWER AMP X JW 0101 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0102 88-100-000-010 PLATING-JW, 0.58 SN95 a b

POWER AMP X JW 0103 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0104 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0107 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0108 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0109 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0110 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0111 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0112 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0113 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0114 88-100-000-010 PLATING-JW, 0.58 SN95 a b

 11 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP X JW 0115 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0116 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0117 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0118 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0119 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0120 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0121 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0122 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0123 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0124 88-100-000-010 PLATING-JW, 0.58 SN95 a b

POWER AMP X JW 0125 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0126 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0127 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0128 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0129 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0130 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0131 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0132 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0133 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0134 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP X JW 0135 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0136 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0137 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0138 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0139 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0201 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0202 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0204 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0205 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0206 88-100-000-010 PLATING-JW, 0.58 SN95 a b

POWER AMP X JW 0207 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0211 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0212 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0213 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0214 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0215 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0216 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0217 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0218 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0219 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP X JW 0220 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0221 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0222 88-100-000-010 PLATING-JW, 0.58 SN95 a .
POWER AMP X JW 0223 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP X JW 0235 88-100-000-010 PLATING-JW, 0.58 SN95 . b
POWER AMP X JW 0236 88-100-000-010 PLATING-JW, 0.58 SN95 . b
POWER AMP X JW 0241 88-100-000-010 PLATING-JW, 0.58 SN95 . b
POWER AMP X JW 0242 88-100-000-010 PLATING-JW, 0.58 SN95 . b
POWER AMP X JW 0245 88-100-000-010 PLATING-JW, 0.58 SN95 a .
POWER AMP X JW 0246 88-100-000-010 PLATING-JW, 0.58 SN95 a .

POWER AMP X JW 0249 88-100-000-010 PLATING-JW, 0.58 SN95 a b
POWER AMP O L 0201 87-A50-611-010 COIL,1UH K(CS) a b
POWER AMP O L 0202 87-A50-611-010 COIL,1UH K(CS) a b
POWER AMP S Q 0101 87-A30-257-080 C-TR,2SD1306E a b
POWER AMP S Q 0102 87-A30-257-080 C-TR,2SD1306E a b
POWER AMP S Q 0103 87-A30-075-080 C-TR,2SA1235F a .
POWER AMP S Q 0103 87-A30-669-040 C-TR,SBT5401 . b
POWER AMP S Q 0104 87-A30-075-080 C-TR,2SA1235F a .
POWER AMP S Q 0104 87-A30-669-040 C-TR,SBT5401 . b
POWER AMP S Q 0105 87-A30-075-080 C-TR,2SA1235F a .

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP S Q 0105 87-A30-669-040 C-TR,SBT5401 . b
POWER AMP S Q 0106 87-A30-075-080 C-TR,2SA1235F a .
POWER AMP S Q 0106 87-A30-669-040 C-TR,SBT5401 . b
POWER AMP S Q 0107 87-A30-076-080 C-TR,2SC3052F a b
POWER AMP S Q 0108 87-A30-076-080 C-TR,2SC3052F a b
POWER AMP S Q 0109 87-A30-076-080 C-TR,2SC3052F a b
POWER AMP S Q 0110 87-A30-076-080 C-TR,2SC3052F a b
POWER AMP S Q 0111 87-A30-672-080 TR,2N5551C a b
POWER AMP S Q 0112 87-A30-672-080 TR,2N5551C a b
POWER AMP S Q 0113 87-A30-076-080 C-TR,2SC3052F a b

POWER AMP S Q 0114 87-A30-076-080 C-TR,2SC3052F a b
POWER AMP S Q 0115 87-A30-670-040 C-TR,SBT5551 a b
POWER AMP S Q 0116 87-A30-670-040 C-TR,SBT5551 a b
POWER AMP S Q 0117 87-A30-306-010 TR,2SB1677 a .
POWER AMP S Q 0117 87-A30-528-010 TR,2SB1686 . b
POWER AMP S Q 0118 87-A30-306-010 TR,2SB1677 a .
POWER AMP S Q 0118 87-A30-528-010 TR,2SB1686 . b
POWER AMP S Q 0119 87-A30-307-010 TR,2SD2619 a .
POWER AMP S Q 0119 87-A30-529-010 TR,2SD2642 . b
POWER AMP S Q 0120 87-A30-307-010 TR,2SD2619 a .

 12 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP S Q 0120 87-A30-529-010 TR,2SD2642 . b
POWER AMP S Q 0123 87-A30-669-040 C-TR,SBT5401 a b
POWER AMP S Q 0124 87-A30-669-040 C-TR,SBT5401 a b
POWER AMP S Q 0126 87-A30-669-040 C-TR,SBT5401 a b
POWER AMP S Q 0127 87-A30-076-080 C-TR,2SC3052F a b
POWER AMP S Q 0128 87-A30-076-080 C-TR,2SC3052F a b
POWER AMP S Q 0130 87-A30-670-040 C-TR,SBT5551 a b
POWER AMP S Q 0183 87-A30-186-010 FET,2SK3053 a b
POWER AMP S Q 0184 87-A30-186-010 FET,2SK3053 a b
POWER AMP S Q 0185 87-A30-076-080 C-TR,2SC3052F a b

POWER AMP S Q 0186 87-A30-075-080 C-TR,2SA1235F a b
POWER AMP S Q 0187 87-A30-075-080 C-TR,2SA1235F a b
POWER AMP S Q 0235 87-A30-075-080 C-TR,2SA1235F a b
POWER AMP S Q 0280 87-A30-538-040 C-TR,SRA2202S a b
POWER AMP S Q 0281 87-A30-669-040 C-TR,SBT5401 a b
POWER AMP X R 0103 88-108-393-080 C-RES,U 39K-1/16W J a b
POWER AMP X R 0104 88-108-393-080 C-RES,U 39K-1/16W J a b
POWER AMP X R 0105 88-108-273-080 C-RES,U 27K-1/16W J a b
POWER AMP X R 0106 88-108-273-080 C-RES,U 27K-1/16W J a b
POWER AMP X R 0107 88-108-101-080 C-RES,U 100-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP X R 0108 88-108-101-080 C-RES,U 100-1/16W J a b
POWER AMP X R 0111 88-118-122-080 C-RES,S 1.2K-1/10W J a .
POWER AMP X R 0111 88-118-102-080 C-RES,S 1K-1/10W J . b
POWER AMP X R 0112 88-118-122-080 C-RES,S 1.2K-1/10W J a .
POWER AMP X R 0112 88-118-102-080 C-RES,S 1K-1/10W J . b
POWER AMP X R 0113 88-118-273-080 C-RES,S 27K-1/10W J a b
POWER AMP X R 0114 88-118-273-080 C-RES,S 27K-1/10W J a b
POWER AMP X R 0115 88-128-222-080 C-RES, 2.2K-1/8W J a b
POWER AMP X R 0116 88-128-222-080 C-RES, 2.2K-1/8W J a b
POWER AMP X R 0117 88-108-103-080 C-RES,U 10K-1/16W J a b

POWER AMP X R 0118 88-108-103-080 C-RES,U 10K-1/16W J a b
POWER AMP X R 0119 88-118-101-080 C-RES,S 100-1/10W J a b
POWER AMP X R 0120 88-118-101-080 C-RES,S 100-1/10W J a b
POWER AMP X R 0121 88-118-101-080 C-RES,S 100-1/10W J a b
POWER AMP X R 0122 88-118-101-080 C-RES,S 100-1/10W J a b
POWER AMP X R 0123 88-128-222-080 C-RES, 2.2K-1/8W J a b
POWER AMP X R 0124 88-128-222-080 C-RES, 2.2K-1/8W J a b
POWER AMP X R 0125 88-128-102-080 C-RES, 1K-1/8W J a b
POWER AMP X R 0126 88-128-102-080 C-RES, 1K-1/8W J a b
POWER AMP X R 0127 88-118-390-080 C-RES,S 39-1/10W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP X R 0128 88-118-390-080 C-RES,S 39-1/10W J a b
POWER AMP O R 0129 87-A00-258-080 RES,M/F 0.22-1W J a .
POWER AMP O R 0129 87-A00-257-080 RES,M/F 0.15-1W J . b
POWER AMP O R 0130 87-A00-258-080 RES,M/F 0.22-1W J a .
POWER AMP O R 0130 87-A00-257-080 RES,M/F 0.15-1W J . b
POWER AMP O R 0131 87-A00-258-080 RES,M/F 0.22-1W J a .
POWER AMP O R 0131 87-A00-257-080 RES,M/F 0.15-1W J . b
POWER AMP O R 0132 87-A00-258-080 RES,M/F 0.22-1W J a .
POWER AMP O R 0132 87-A00-257-080 RES,M/F 0.15-1W J . b
POWER AMP X R 0133 88-108-332-080 C-RES,U 3.3K-1/16W J a .

POWER AMP X R 0133 88-108-222-080 C-RES,U 2.2K-1/16W J . b
POWER AMP X R 0134 88-108-332-080 C-RES,U 3.3K-1/16W J a .
POWER AMP X R 0134 88-108-222-080 C-RES,U 2.2K-1/16W J . b
POWER AMP X R 0135 88-108-152-080 C-RES,U 1.5K-1/16W J a b
POWER AMP X R 0136 88-108-152-080 C-RES,U 1.5K-1/16W J a b
POWER AMP X R 0137 88-108-101-080 C-RES,U 100-1/16W J a b
POWER AMP X R 0138 88-108-101-080 C-RES,U 100-1/16W J a b
POWER AMP X R 0141 88-118-102-080 C-RES,S 1K-1/10W J a b
POWER AMP X R 0142 88-118-102-080 C-RES,S 1K-1/10W J a b
POWER AMP X R 0143 88-108-392-080 C-RES,U 3.9K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP X R 0145 88-118-123-080 C-RES,S 12K-1/10W J a b
POWER AMP X R 0146 88-118-123-080 C-RES,S 12K-1/10W J a b
POWER AMP X R 0149 88-108-392-080 C-RES,U 3.9K-1/16W J a b
POWER AMP X R 0151 88-108-473-080 C-RES,U 47K-1/16W J a b
POWER AMP X R 0152 88-108-473-080 C-RES,U 47K-1/16W J a b
POWER AMP X R 0153 88-128-272-080 C-RES, 2.7K-1/8W J a b
POWER AMP X R 0155 88-108-682-080 C-RES,U 6.8K-1/16W J a b
POWER AMP X R 0156 88-108-682-080 C-RES,U 6.8K-1/16W J a b
POWER AMP X R 0157 88-108-472-080 C-RES,U 4.7K-1/16W J a b
POWER AMP X R 0158 88-108-472-080 C-RES,U 4.7K-1/16W J a b

POWER AMP X R 0159 88-108-103-080 C-RES,U 10K-1/16W J a b
POWER AMP X R 0160 88-121-103-080 RES,10K-1/8W J a b
POWER AMP X R 0161 88-108-472-080 C-RES,U 4.7K-1/16W J a b
POWER AMP X R 0162 88-108-472-080 C-RES,U 4.7K-1/16W J a b
POWER AMP X R 0163 88-108-472-080 C-RES,U 4.7K-1/16W J a b
POWER AMP X R 0164 88-108-472-080 C-RES,U 4.7K-1/16W J a b
POWER AMP X R 0165 88-118-152-080 C-RES,S 1.5K-1/10W J a b
POWER AMP X R 0166 88-118-152-080 C-RES,S 1.5K-1/10W J a b
POWER AMP X R 0167 88-108-103-080 C-RES,U 10K-1/16W J a b
POWER AMP X R 0168 88-118-473-080 C-RES,S 47K-1/10W J a b

 13 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP X R 0171 88-118-222-080 C-RES,S 2.2K-1/10W J a b
POWER AMP X R 0172 88-118-222-080 C-RES,S 2.2K-1/10W J a b
POWER AMP X R 0173 88-118-182-080 C-RES,S 1.8K-1/10W J a b
POWER AMP X R 0174 88-118-182-080 C-RES,S 1.8K-1/10W J a b
POWER AMP X R 0175 88-118-331-080 C-RES,S 330-1/10W J a b
POWER AMP X R 0176 88-118-331-080 C-RES,S 330-1/10W J a b
POWER AMP X R 0177 88-128-222-080 C-RES, 2.2K-1/8W J a b
POWER AMP X R 0178 88-118-103-080 C-RES,S 10K-1/10W J a b
POWER AMP X R 0179 88-108-102-080 C-RES,U 1K-1/16W J a b
POWER AMP X R 0180 88-108-102-080 C-RES,U 1K-1/16W J a b

POWER AMP X R 0181 88-108-222-080 C-RES,U 2.2K-1/16W J a b
POWER AMP X R 0182 88-108-222-080 C-RES,U 2.2K-1/16W J a b
POWER AMP X R 0184 88-118-102-080 C-RES,S 1K-1/10W J a b
POWER AMP X R 0185 88-108-222-080 C-RES,U 2.2K-1/16W J a .
POWER AMP X R 0185 88-108-332-080 C-RES,U 3.3K-1/16W J . b
POWER AMP X R 0186 88-118-102-080 C-RES,S 1K-1/10W J a b
POWER AMP X R 0187 88-118-562-080 C-RES,S 5.6K-1/10W J a .
POWER AMP X R 0187 88-118-103-080 C-RES,S 10K-1/10W J . b
POWER AMP X R 0188 88-118-102-080 C-RES,S 1K-1/10W J a .
POWER AMP X R 0188 88-118-222-080 C-RES,S 2.2K-1/10W J . b

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP X R 0189 88-128-272-080 C-RES, 2.7K-1/8W J a b
POWER AMP X R 0190 88-128-272-080 C-RES, 2.7K-1/8W J a b
POWER AMP X R 0192 88-128-222-080 C-RES, 2.2K-1/8W J a b
POWER AMP X R 0193 88-108-103-080 C-RES,U 10K-1/16W J a b
POWER AMP X R 0194 88-108-103-080 C-RES,U 10K-1/16W J a b
POWER AMP X R 0195 88-108-473-080 C-RES,U 47K-1/16W J a b
POWER AMP X R 0196 88-108-473-080 C-RES,U 47K-1/16W J a b
POWER AMP X R 0197 88-108-473-080 C-RES,U 47K-1/16W J a b
POWER AMP X R 0198 88-108-473-080 C-RES,U 47K-1/16W J a b
POWER AMP X R 0199 88-108-225-080 C-RES,U 2.2M-1/16W J a b

POWER AMP X R 0217 88-108-683-080 C-RES,U 68K-1/16W J a b
POWER AMP X R 0218 88-108-105-080 C-RES,U 1M-1/16W J a b
POWER AMP X R 0219 88-108-000-080 C-JUMPER,U a b
POWER AMP O R 0230 87-A00-439-050 RES,180-1/2W J RP . b
POWER AMP O R 0231 87-A00-439-050 RES,180-1/2W J RP . b
POWER AMP O R 0232 87-A00-439-050 RES,180-1/2W J RP . b
POWER AMP O R 0233 87-A00-439-050 RES,180-1/2W J RP . b
POWER AMP X R 0234 88-128-222-080 C-RES, 2.2K-1/8W J . b
POWER AMP X R 0235 88-128-222-080 C-RES, 2.2K-1/8W J . b
POWER AMP O R 0243 87-A00-439-050 RES,180-1/2W J RP a .

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP O R 0244 87-A00-439-050 RES,180-1/2W J RP a .
POWER AMP O R 0245 87-A00-439-050 RES,180-1/2W J RP a .
POWER AMP O R 0246 87-A00-439-050 RES,180-1/2W J RP a .
POWER AMP X R 0247 88-130-100-080 RES,10-1/4W J a b
POWER AMP X R 0248 88-130-100-080 RES,10-1/4W J a b
POWER AMP X R 0249 88-128-100-080 C-RES, 10-1/8W J a b
POWER AMP X R 0250 88-128-100-080 C-RES, 10-1/8W J a b
POWER AMP X R 0265 88-128-222-080 C-RES, 2.2K-1/8W J a .
POWER AMP X R 0266 88-128-222-080 C-RES, 2.2K-1/8W J a .
POWER AMP X R 0280 88-118-473-080 C-RES,S 47K-1/10W J a b

POWER AMP X R 0281 88-118-222-080 C-RES,S 2.2K-1/10W J a b
POWER AMP X R 0282 88-118-103-080 C-RES,S 10K-1/10W J a b
POWER AMP X R 0283 88-118-224-080 C-RES,S 220K-1/10W J a b
POWER AMP X R 0284 88-118-224-080 C-RES,S 220K-1/10W J a b
POWER AMP X R 0285 88-118-223-080 C-RES,S 22K-1/10W J a .
POWER AMP X R 0285 88-118-333-080 C-RES,S 33K-1/10W J . b
POWER AMP X R 0286 88-118-473-080 C-RES,S 47K-1/10W J a b
POWER AMP X R 0287 88-118-473-080 C-RES,S 47K-1/10W J a b
POWER AMP O TH 0101 87-A91-042-080 C-THMS,100K 55001 a b
POWER AMP O TH 0102 87-A91-042-080 C-THMS,100K 55001 a b

CX-SND20 CX-SNR20
USC1 LHSC1
POWER AMP O W 0101 8B-NF1-640-010 F-CABLE,5P 2.5 250MM a b
POWER AMP ! O WH 0101 87-A90-459-010 HLDR,WIRE 2.5-5P a b
POWER AMP ! O WH 0201 87-A90-459-010 HLDR,WIRE 2.5-5P a .
POWER AMP ! O WH 0230 87-A90-459-010 HLDR,WIRE 2.5-5P . b
P-SUPPLY/PWB/FAN X * 8C-NF9-630-010 PWB,COMB MAIN U/LH/HR/V/ HS a b
P-SUPPLY/PWB/FAN X * 8C-NF9-631-010 PWB,MAIN U/LH/HR/V/ HS a b
P-SUPPLY/PWB/FAN X * 8C-NF9-636-010 PWB,HP U/LH/HR/V/ HS a .
P-SUPPLY/PWB/FAN X * 8C-NF9-632-010 PWB,PT 66 U/LH/HR/V/ HS a .
P-SUPPLY/PWB/FAN X * 8C-NF9-638-010 PWB,HP(FOR MIC MODEL) U/LH/HR/ . b
P-SUPPLY/PWB/FAN O C 0003 87-012-368-080 C-CAP,S 0.1-50 Z F a b

P-SUPPLY/PWB/FAN O C 0004 87-012-368-080 C-CAP,S 0.1-50 Z F a b
P-SUPPLY/PWB/FAN O C 0005 87-012-368-080 C-CAP,S 0.1-50 Z F a b
P-SUPPLY/PWB/FAN O C 0006 87-012-368-080 C-CAP,S 0.1-50 Z F a b
P-SUPPLY/PWB/FAN O C 0009 87-010-759-080 C-CAP,U 0.1-25 Z F a b
P-SUPPLY/PWB/FAN O C 0010 87-010-759-080 C-CAP,U 0.1-25 Z F a b
P-SUPPLY/PWB/FAN O C 0011 87-010-759-080 C-CAP,U 0.1-25 Z F a b
P-SUPPLY/PWB/FAN O C 0012 87-010-759-080 C-CAP,U 0.1-25 Z F a b
P-SUPPLY/PWB/FAN O C 0013 87-012-282-080 C-CAP,U 4700P-50 K B a b
P-SUPPLY/PWB/FAN O C 0014 87-010-260-080 CAP,E 47-25 M 11L SME a b
P-SUPPLY/PWB/FAN O C 0015 87-010-263-080 CAP,E 100-10 M 11L SME a .

 14 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN O C 0016 87-012-286-080 C-CAP,U 0.01-25 K B a b
P-SUPPLY/PWB/FAN O C 0019 87-A12-432-000 CAP,E 3300-50 M 85 IV LELON a b
P-SUPPLY/PWB/FAN O C 0020 87-A12-432-000 CAP,E 3300-50 M 85 IV LELON a b
P-SUPPLY/PWB/FAN O C 0021 87-A12-755-000 CAP,E 4700-25 M 85 IV LELON a b
P-SUPPLY/PWB/FAN O C 0022 87-A12-755-000 CAP,E 4700-25 M 85 IV LELON a b
P-SUPPLY/PWB/FAN O C 0025 87-A12-079-080 CAP,E 100-35 SMG a b
P-SUPPLY/PWB/FAN O C 0026 87-010-393-080 CAP,E 100-35 M SME a b
P-SUPPLY/PWB/FAN O C 0027 87-010-393-080 CAP,E 100-35 M SME a b
P-SUPPLY/PWB/FAN O C 0028 87-010-393-080 CAP,E 100-35 M SME a b
P-SUPPLY/PWB/FAN O C 0030 87-010-247-080 CAP,E 100-50 M SME a b

P-SUPPLY/PWB/FAN O C 0031 87-010-263-080 CAP,E 100-10 M 11L SME a b
P-SUPPLY/PWB/FAN O C 0034 87-010-260-080 CAP,E 47-25 M 11L SME a b
P-SUPPLY/PWB/FAN O C 0035 87-010-405-080 CAP,E 10-50 M 11L SME a b
P-SUPPLY/PWB/FAN O C 0036 87-010-260-080 CAP,E 47-25 M 11L SME a b
P-SUPPLY/PWB/FAN O C 0060 87-010-403-080 CAP,E 3.3-50 M 11L SME a b
P-SUPPLY/PWB/FAN O C 0061 87-010-260-080 CAP,E 47-25 M 11L SME a b
P-SUPPLY/PWB/FAN O C 0083 87-010-387-080 CAP,E 470-25 M SME a b
P-SUPPLY/PWB/FAN O C 0097 87-010-759-080 C-CAP,U 0.1-25 Z F a b
P-SUPPLY/PWB/FAN ! O CNA0001 8A-NF8-653-010 CONN ASSY,9P TID-A(480) . b
P-SUPPLY/PWB/FAN S D 0001 87-A40-393-090 DIODE,1N5402GW(F20) a b

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN S D 0002 87-A40-393-090 DIODE,1N5402GW(F20) a b
P-SUPPLY/PWB/FAN S D 0003 87-A40-393-090 DIODE,1N5402GW(F20) a b
P-SUPPLY/PWB/FAN S D 0004 87-A40-393-090 DIODE,1N5402GW(F20) a b
P-SUPPLY/PWB/FAN S D 0005 87-A40-393-090 DIODE,1N5402GW(F20) a b
P-SUPPLY/PWB/FAN S D 0006 87-A40-393-090 DIODE,1N5402GW(F20) a b
P-SUPPLY/PWB/FAN S D 0007 87-A40-393-090 DIODE,1N5402GW(F20) a b
P-SUPPLY/PWB/FAN S D 0008 87-A40-393-090 DIODE,1N5402GW(F20) a b
P-SUPPLY/PWB/FAN S D 0011 87-A40-270-080 C-DIODE,MC2838 a b
P-SUPPLY/PWB/FAN S D 0021 87-A40-345-080 ZENER,MTZJ10C a b
P-SUPPLY/PWB/FAN S D 0025 87-A40-553-080 DIODE,1N4003 LES a b

P-SUPPLY/PWB/FAN S D 0026 87-A40-553-080 DIODE,1N4003 LES a b
P-SUPPLY/PWB/FAN S D 0027 87-A40-553-080 DIODE,1N4003 LES a b
P-SUPPLY/PWB/FAN S D 0028 87-A40-553-080 DIODE,1N4003 LES a b
P-SUPPLY/PWB/FAN S D 0029 87-A40-336-080 ZENER,MTZJ27D T-72 a b
P-SUPPLY/PWB/FAN S D 0030 87-020-465-080 DIODE,1SS133 a b
P-SUPPLY/PWB/FAN S D 0032 87-020-465-080 DIODE,1SS133 a b
P-SUPPLY/PWB/FAN S D 0041 87-A40-270-080 C-DIODE,MC2838 a b
P-SUPPLY/PWB/FAN S D 0042 87-A40-269-080 C-DIODE,MC2836 a b
P-SUPPLY/PWB/FAN S D 0060 87-020-465-080 DIODE,1SS133 a b
P-SUPPLY/PWB/FAN S D 0063 87-A40-270-080 C-DIODE,MC2838 a b

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN S D 0064 87-A40-269-080 C-DIODE,MC2836 a b
P-SUPPLY/PWB/FAN S D 0076 87-A40-269-080 C-DIODE,MC2836 a b
P-SUPPLY/PWB/FAN S D 0077 87-A40-270-080 C-DIODE,MC2838 a b
P-SUPPLY/PWB/FAN S IC 0001 87-A21-364-010 IC,NJM7806FA(A) a b
P-SUPPLY/PWB/FAN X JR 0001 88-108-000-080 C-JUMPER,U a b
P-SUPPLY/PWB/FAN X JR 0002 88-118-000-080 C-JUMPER,S a b
P-SUPPLY/PWB/FAN X JR 0003 88-118-000-080 C-JUMPER,S a b
P-SUPPLY/PWB/FAN X JW 0001 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0002 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0003 88-100-000-010 PLATING-JW, 0.58 SN95 a b

P-SUPPLY/PWB/FAN X JW 0006 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0007 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0008 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0009 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0010 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0011 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0012 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0013 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0014 88-100-000-010 PLATING-JW, 0.58 SN95 . b
P-SUPPLY/PWB/FAN X JW 0015 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN X JW 0016 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0017 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0018 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0019 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0020 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0021 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0022 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0024 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0025 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0026 88-100-000-010 PLATING-JW, 0.58 SN95 a b

P-SUPPLY/PWB/FAN X JW 0027 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0028 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0029 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0030 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0031 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0032 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0033 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0034 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0035 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0036 88-100-000-010 PLATING-JW, 0.58 SN95 a b

 15 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN X JW 0037 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0038 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0039 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0040 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0041 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0042 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0043 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0044 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0045 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0046 88-100-000-010 PLATING-JW, 0.58 SN95 a b

P-SUPPLY/PWB/FAN X JW 0047 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0048 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0049 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0051 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0052 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0053 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0055 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0056 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0057 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0058 88-100-000-010 PLATING-JW, 0.58 SN95 a b

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN X JW 0060 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0061 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0062 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0063 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0064 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0065 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0066 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0067 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0068 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0069 88-100-000-010 PLATING-JW, 0.58 SN95 a b

P-SUPPLY/PWB/FAN X JW 0079 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X JW 0085 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN S Q 0001 87-A30-494-080 TR,2SA1980G a b
P-SUPPLY/PWB/FAN S Q 0002 87-A30-494-080 TR,2SA1980G a b
P-SUPPLY/PWB/FAN S Q 0003 87-A30-076-080 C-TR,2SC3052F a b
P-SUPPLY/PWB/FAN S Q 0006 87-A30-076-080 C-TR,2SC3052F a b
P-SUPPLY/PWB/FAN S Q 0009 87-A30-494-080 TR,2SA1980G a b
P-SUPPLY/PWB/FAN S Q 0010 87-A30-076-080 C-TR,2SC3052F a b
P-SUPPLY/PWB/FAN S Q 0011 87-A30-614-010 TR,2SB1548 a b
P-SUPPLY/PWB/FAN S Q 0012 87-A30-630-080 TR,2SC5343GL a b

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN S Q 0015 87-A30-075-080 C-TR,2SA1235F a .
P-SUPPLY/PWB/FAN S Q 0060 87-A30-076-080 C-TR,2SC3052F a b
P-SUPPLY/PWB/FAN S Q 0061 87-A30-075-080 C-TR,2SA1235F a b
P-SUPPLY/PWB/FAN S Q 0062 87-A30-076-080 C-TR,2SC3052F a b
P-SUPPLY/PWB/FAN S Q 0063 87-A30-075-080 C-TR,2SA1235F a b
P-SUPPLY/PWB/FAN S Q 0064 87-A30-076-080 C-TR,2SC3052F a b
P-SUPPLY/PWB/FAN X R 0001 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X R 0005 88-100-000-010 PLATING-JW, 0.58 SN95 a b
P-SUPPLY/PWB/FAN X R 0009 88-108-223-080 C-RES,U 22K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0010 88-108-223-080 C-RES,U 22K-1/16W J a b

P-SUPPLY/PWB/FAN X R 0011 88-118-472-080 C-RES,S 4.7K-1/10W J a b
P-SUPPLY/PWB/FAN X R 0012 88-118-472-080 C-RES,S 4.7K-1/10W J a b
P-SUPPLY/PWB/FAN X R 0013 88-118-472-080 C-RES,S 4.7K-1/10W J a b
P-SUPPLY/PWB/FAN X R 0014 88-118-100-080 C-RES,S 10-1/10W J a b
P-SUPPLY/PWB/FAN X R 0015 88-121-104-080 RES,100K-1/8W J a b
P-SUPPLY/PWB/FAN X R 0016 88-108-104-080 C-RES,U 100K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0017 88-108-104-080 C-RES,U 100K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0018 88-108-104-080 C-RES,U 100K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0019 88-108-104-080 C-RES,U 100K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0020 88-128-129-080 C-RES, 1.2-1/8W J a .

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN X R 0021 88-128-129-080 C-RES, 1.2-1/8W J a .
P-SUPPLY/PWB/FAN X R 0022 88-108-103-080 C-RES,U 10K-1/16W J a .
P-SUPPLY/PWB/FAN X R 0023 88-118-101-080 C-RES,S 100-1/10W J a .
P-SUPPLY/PWB/FAN X R 0024 88-118-103-080 C-RES,S 10K-1/10W J a b
P-SUPPLY/PWB/FAN X R 0026 88-108-472-080 C-RES,U 4.7K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0027 88-118-000-080 C-JUMPER,S a b
P-SUPPLY/PWB/FAN X R 0028 88-108-221-080 C-RES,U 220-1/16W J a b
P-SUPPLY/PWB/FAN X R 0029 88-108-223-080 C-RES,U 22K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0031 88-121-154-080 RES,150K-1/8W J a b
P-SUPPLY/PWB/FAN X R 0032 88-108-472-080 C-RES,U 4.7K-1/16W J a b

P-SUPPLY/PWB/FAN X R 0035 88-118-123-080 C-RES,S 12K-1/10W J a b
P-SUPPLY/PWB/FAN X R 0037 88-118-102-080 C-RES,S 1K-1/10W J a b
P-SUPPLY/PWB/FAN X R 0038 88-118-102-080 C-RES,S 1K-1/10W J a b
P-SUPPLY/PWB/FAN X R 0042 88-121-331-080 RES,330-1/8W J a b
P-SUPPLY/PWB/FAN X R 0043 88-121-331-080 RES,330-1/8W J a b
P-SUPPLY/PWB/FAN X R 0044 88-121-331-080 RES,330-1/8W J a b
P-SUPPLY/PWB/FAN X R 0045 88-121-331-080 RES,330-1/8W J a b
P-SUPPLY/PWB/FAN X R 0046 88-121-471-080 RES,470-1/8W J a b
P-SUPPLY/PWB/FAN X R 0050 88-108-223-080 C-RES,U 22K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0051 88-108-102-080 C-RES,U 1K-1/16W J a b

 16 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN X R 0052 88-108-102-080 C-RES,U 1K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0053 88-118-393-080 C-RES,S 39K-1/10W J a b
P-SUPPLY/PWB/FAN X R 0054 88-118-682-080 C-RES,S 6.8K-1/10W J a .
P-SUPPLY/PWB/FAN X R 0054 88-118-562-080 C-RES,S 5.6K-1/10W J . b
P-SUPPLY/PWB/FAN X R 0055 88-121-152-080 RES,1.5K-1/8W J a b
P-SUPPLY/PWB/FAN X R 0056 88-118-680-080 C-RES,S 68-1/10W J a b
P-SUPPLY/PWB/FAN X R 0057 88-108-472-080 C-RES,U 4.7K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0058 88-108-103-080 C-RES,U 10K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0059 88-108-221-080 C-RES,U 220-1/16W J a b
P-SUPPLY/PWB/FAN X R 0060 88-108-471-080 C-RES,U 470-1/16W J a b

P-SUPPLY/PWB/FAN X R 0061 88-108-103-080 C-RES,U 10K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0062 88-108-223-080 C-RES,U 22K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0063 88-108-223-080 C-RES,U 22K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0064 88-108-822-080 C-RES,U 8.2K-1/16W J a .
P-SUPPLY/PWB/FAN X R 0064 88-108-103-080 C-RES,U 10K-1/16W J . b
P-SUPPLY/PWB/FAN X R 0065 88-108-123-080 C-RES,U 12K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0066 88-108-104-080 C-RES,U 100K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0067 88-108-103-080 C-RES,U 10K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0068 88-128-152-080 C-RES, 1.5K-1/8W J a b
P-SUPPLY/PWB/FAN X R 0076 88-108-103-080 C-RES,U 10K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
P-SUPPLY/PWB/FAN X R 0078 88-108-393-080 C-RES,U 39K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0079 88-108-123-080 C-RES,U 12K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0081 88-108-101-080 C-RES,U 100-1/16W J a b
P-SUPPLY/PWB/FAN X R 0085 88-108-103-080 C-RES,U 10K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0093 88-108-683-080 C-RES,U 68K-1/16W J a .
P-SUPPLY/PWB/FAN X R 0093 88-108-823-080 C-RES,U 82K-1/16W J . b
P-SUPPLY/PWB/FAN X R 0094 88-108-393-080 C-RES,U 39K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0095 88-108-123-080 C-RES,U 12K-1/16W J a b
P-SUPPLY/PWB/FAN X R 0096 88-108-683-080 C-RES,U 68K-1/16W J a .
P-SUPPLY/PWB/FAN X R 0096 88-108-823-080 C-RES,U 82K-1/16W J . b

P-SUPPLY/PWB/FAN O W 0099 8A-NF9-609-010 F-CABLE,9P 2.5 480MM a .
P-SUPPLY/PWB/FAN ! O WH 0001 87-A90-510-010 HLDR,WIRE 2.5-9P a b
PT X * 8C-NF9-670-010 PWB,PT 66 2M . b
PT ! O CN 0002 87-A61-110-010 CONN,9P V TID-A . b
PT S D 0091 87-020-465-080 DIODE,1SS133 . b
PT S D 0092 87-020-465-080 DIODE,1SS133 . b
PT S D 0093 87-020-465-080 DIODE,1SS133 . b
PT S D 0094 87-020-465-080 DIODE,1SS133 . b
PT X JW 0001 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0002 88-100-000-010 PLATING-JW, 0.58 SN95 . b

CX-SND20 CX-SNR20
USC1 LHSC1
PT X JW 0003 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0004 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0005 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0006 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0007 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0008 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0009 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0010 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0011 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0012 88-100-000-010 PLATING-JW, 0.58 SN95 . b

PT X JW 0013 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0014 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0015 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0016 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0017 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0018 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0019 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0020 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT X JW 0021 88-100-000-010 PLATING-JW, 0.58 SN95 . b
PT ! O PT 0002 8B-MA6-673-010 PT,SUB BMA H (VRK) . b

CX-SND20 CX-SNR20
USC1 LHSC1
PT ! O RY 0001 87-A91-339-010 RELAY,AC DC12V G5PA-2 . b
PT ! O S 0001 87-A90-165-010 SW,SL 1-2-3 SWS2301 . b
PT O T 0001 87-A60-317-010 TERMINAL, 1P MSC . b
PT O T 0002 87-A60-317-010 TERMINAL, 1P MSC . b
TUNER(FM FE) O C 0901 87-012-169-080 C-CAP,U 7P-50 D CH a b
TUNER(FM FE) X C 0906 88-108-000-080 C-JUMPER,U a b
TUNER(FM FE) O C 0909 87-A10-915-080 C-CAP,U 1000P-25 J CH a b
TUNER(FM FE) O C 0911 87-012-167-080 C-CAP,U 5P-50 C CH a b
TUNER(FM FE) O C 0912 87-012-195-080 C-CAP,U 100P-50 J CH a b
TUNER(FM FE) O C 0914 87-012-286-080 C-CAP,U 0.01-25 K B a b

TUNER(FM FE) O C 0915 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(FM FE) O C 0917 87-012-164-080 C-CAP,U 2P-50 C CH a b
TUNER(FM FE) O C 0920 87-012-180-080 C-CAP,U 22P-50 J CH a b
TUNER(FM FE) O C 0921 87-012-186-080 C-CAP,U 39P-50 J CH a b
TUNER(FM FE) O C 0922 87-012-174-080 C-CAP,U 12P-50 J CH a b
TUNER(FM FE) O C 0923 87-A10-039-080 C-CAP,U 470P-50 J CH a b
TUNER(FM FE) O C 0924 87-012-162-080 C-CAP,U 1P-50 C CH a b
TUNER(FM FE) O C 0926 87-012-195-080 C-CAP,U 100P-50 J CH a b
TUNER(FM FE) O C 0931 87-A12-319-080 C-CAP,U 0.1-25 K B a b
TUNER(FM FE) O D 0902 87-A40-916-040 C-VARI-CAP,HVC202A a b

 17 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(FM FE) O D 0903 87-A40-916-040 C-VARI-CAP,HVC202A a b
TUNER(FM FE) X JR 0902 88-108-000-080 C-JUMPER,U a b
TUNER(FM FE) X JR 0904 88-108-000-080 C-JUMPER,U a b
TUNER(FM FE) X JR 0906 88-129-000-080 C-JUMPER, 3216 a b
TUNER(FM FE) X JR 0907 88-108-000-080 C-JUMPER,U a b
TUNER(FM FE) O L 0901 87-A50-110-010 COIL,FM BPF EX a b
TUNER(FM FE) O L 0903 86-ZA1-624-010 COIL,FM RF-1 a b
TUNER(FM FE) O L 0904 86-ZA1-622-010 COIL,FM ANT/RF-U a b
TUNER(FM FE) O L 0906 87-005-847-080 COIL,2.2UH K CECS a b
TUNER(FM FE) O L 0907 86-ZA1-627-010 COIL,FM OSC-U a b

TUNER(FM FE) O L 0908 88-ZA1-624-010 COIL,FM IFT 7-6.2 (COILS) a b
TUNER(FM FE) S Q 0901 89-503-602-080 C-FET,2SK360E a b
TUNER(FM FE) S Q 0902 87-A30-664-080 C-TR,2SC2620B a b
TUNER(FM FE) S Q 0904 87-A30-664-080 C-TR,2SC2620B a b
TUNER(FM FE) X R 0903 88-108-221-080 C-RES,U 220-1/16W J a b
TUNER(FM FE) X R 0904 88-108-473-080 C-RES,U 47K-1/16W J a b
TUNER(FM FE) X R 0905 88-108-102-080 C-RES,U 1K-1/16W J a b
TUNER(FM FE) X R 0906 88-108-564-080 C-RES,U 560K-1/16W J a b
TUNER(FM FE) X R 0908 88-108-000-080 C-JUMPER,U a b
TUNER(FM FE) X R 0911 88-108-121-080 C-RES,U 120-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(FM FE) X R 0912 88-108-473-080 C-RES,U 47K-1/16W J a b
TUNER(FM FE) X R 0913 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER(FM FE) X R 0914 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER(FM FE) X R 0918 88-108-000-080 C-JUMPER,U a b
TUNER(FM FE) X SH 0901 8B-ZA3-619-010 SHLD-CASE,BZA-3 EZ a b
TUNER(IF) O C 0771 87-010-263-080 CAP,E 100-10 M 11L SME a b
TUNER(IF) O C 0772 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) X C 0781 88-108-000-080 C-JUMPER,U a b
TUNER(IF) O C 0782 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) O C 0783 87-012-286-080 C-CAP,U 0.01-25 K B a b

TUNER(IF) O C 0784 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) O C 0785 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) O C 0786 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) O C 0788 87-012-167-080 C-CAP,U 5P-50 C CH a b
TUNER(IF) O C 0789 87-A13-065-080 C-CAP,U 0.027-25 J B a b
TUNER(IF) O C 0790 87-A13-065-080 C-CAP,U 0.027-25 J B a b
TUNER(IF) O C 0791 87-010-759-080 C-CAP,U 0.1-25 Z F a b
TUNER(IF) O C 0792 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) O C 0793 87-010-404-080 CAP,E 4.7-50 M 11L SME a b
TUNER(IF) O C 0795 87-012-286-080 C-CAP,U 0.01-25 K B a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(IF) O C 0796 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) O C 0797 87-010-405-080 CAP,E 10-50 M 11L SME a b
TUNER(IF) O C 0798 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) O C 0799 87-010-265-080 CAP,E 33-16 M 11L SME a b
TUNER(IF) O C 0800 87-010-829-080 C-CAP,U 0.047-16 Z F a b
TUNER(IF) O C 0801 87-010-403-080 CAP,E 3.3-50 M 11L SME a b
TUNER(IF) O C 0802 87-010-829-080 C-CAP,U 0.047-16 Z F a b
TUNER(IF) O C 0803 87-010-787-080 C-CAP,U 0.022-25 K B a b
TUNER(IF) O C 0804 87-010-263-080 CAP,E 100-10 M 11L SME a b
TUNER(IF) O C 0807 87-010-400-080 CAP,E 0.47-50 M 11L SME a b

TUNER(IF) O C 0808 87-010-401-080 CAP,E 1-50 M 11L SME a b
TUNER(IF) O C 0809 87-010-401-080 CAP,E 1-50 M 11L SME a b
TUNER(IF) O C 0810 87-010-759-080 C-CAP,U 0.1-25 Z F a b
TUNER(IF) O C 0814 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(IF) O C 0815 87-010-400-080 CAP,E 0.47-50 M 11L SME a b
TUNER(IF) O C 0816 87-010-400-080 CAP,E 0.47-50 M 11L SME a b
TUNER(IF) O C 0821 87-010-405-080 CAP,E 10-50 M 11L SME a b
TUNER(IF) X C 0822 88-108-000-080 C-JUMPER,U a b
TUNER(IF) O C 0823 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a b
TUNER(IF) O C 0824 87-010-404-080 CAP,E 4.7-50 M 11L SME a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(IF) O C 0825 87-010-596-080 C-CAP,S 0.047-16 K R C2012 a b
TUNER(IF) X D 0801 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) S D 0803 87-020-465-080 DIODE,1SS133 a b
TUNER(IF) S IC 0801 87-A21-695-010 IC,LA1845L a b
TUNER(IF) X JR 0781 88-129-000-080 C-JUMPER, 3216 a b
TUNER(IF) X JR 0785 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X JR 0786 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X JR 0801 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X JR 0802 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X JR 0803 88-129-000-080 C-JUMPER, 3216 a b

TUNER(IF) X JR 0804 88-129-000-080 C-JUMPER, 3216 a b
TUNER(IF) X JW 0780 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0781 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0782 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0783 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0784 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0786 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0787 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0788 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0789 88-100-000-010 PLATING-JW, 0.58 SN95 a b

 18 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(IF) X JW 0790 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0791 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0793 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0794 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0795 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0796 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0797 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0798 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0799 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0801 88-100-000-010 PLATING-JW, 0.58 SN95 a b

TUNER(IF) X JW 0802 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0811 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0812 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0835 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) X JW 0864 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(IF) O L 0801 87-A50-608-010 COIL,FM DET-N(TOK) a b
TUNER(IF) O L 0802 87-A91-551-010 FLTR,PCFJZH-450 L(TOK) a b
TUNER(IF) O L 0811 87-005-847-080 COIL,2.2UH K CECS a b
TUNER(IF) X R 0789 88-108-333-080 C-RES,U 33K-1/16W J a b
TUNER(IF) O R 0790 87-012-286-080 C-CAP,U 0.01-25 K B a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(IF) X R 0791 88-108-102-080 C-RES,U 1K-1/16W J a b
TUNER(IF) X R 0793 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X R 0795 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X R 0801 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(IF) X R 0802 88-108-223-080 C-RES,U 22K-1/16W J a b
TUNER(IF) X R 0803 88-128-183-080 C-RES, 18K-1/8W J a b
TUNER(IF) X R 0804 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X R 0805 88-108-332-080 C-RES,U 3.3K-1/16W J a b
TUNER(IF) X R 0806 88-108-682-080 C-RES,U 6.8K-1/16W J a b
TUNER(IF) X R 0809 88-108-102-080 C-RES,U 1K-1/16W J a b

TUNER(IF) X R 0810 88-108-102-080 C-RES,U 1K-1/16W J a b
TUNER(IF) X R 0811 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X R 0812 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X R 0813 88-108-224-080 C-RES,U 220K-1/16W J a b
TUNER(IF) X R 0814 88-108-105-080 C-RES,U 1M-1/16W J a b
TUNER(IF) X R 0815 88-121-682-080 RES,6.8K-1/8W J a b
TUNER(IF) X R 0818 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(IF) X R 0821 88-108-000-080 C-JUMPER,U a b
TUNER(IF) X R 0823 88-108-333-080 C-RES,U 33K-1/16W J a b
TUNER(IF) X R 0826 88-108-223-080 C-RES,U 22K-1/16W J a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(PLL) O C 0971 87-010-381-080 CAP,E 330-16 M SME a b
TUNER(PLL) O C 0972 87-010-404-080 CAP,E 4.7-50 M 11L SME a b
TUNER(PLL) O C 0973 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(PLL) O C 0974 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(PLL) O C 0979 87-012-195-080 C-CAP,U 100P-50 J CH a b
TUNER(PLL) O C 0981 87-010-260-080 CAP,E 47-25 M 11L SME a b
TUNER(PLL) O C 0982 87-010-759-080 C-CAP,U 0.1-25 Z F a b
TUNER(PLL) O C 0983 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(PLL) O C 0984 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(PLL) O C 0987 87-012-286-080 C-CAP,U 0.01-25 K B a b

TUNER(PLL) O C 0988 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(PLL) O C 0991 87-012-176-080 C-CAP,U 15P-50 J CH a b
TUNER(PLL) O C 0992 87-012-176-080 C-CAP,U 15P-50 J CH a b
TUNER(PLL) O C 0993 87-012-274-080 C-CAP,U 1000P-50 K B a b
TUNER(PLL) O C 0995 87-012-274-080 C-CAP,U 1000P-50 K B a b
TUNER(PLL) O C 0997 87-010-759-080 C-CAP,U 0.1-25 Z F a b
TUNER(PLL) O C 0998 87-010-260-080 CAP,E 47-25 M 11L SME a b
TUNER(PLL) O C 0999 87-A11-155-080 CAP,TC U 0.01-16 Z F a b
TUNER(PLL) S D 0991 87-017-149-080 ZENER,HZS6A2L a b
TUNER(PLL) S D 0994 87-020-465-080 DIODE,1SS133 a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(PLL) S IC 0991 87-A21-928-010 IC,LC72131D-N a b
TUNER(PLL) X JR 0971 88-129-000-080 C-JUMPER, 3216 a b
TUNER(PLL) X JR 0972 88-108-000-080 C-JUMPER,U a b
TUNER(PLL) X JR 0973 88-129-000-080 C-JUMPER, 3216 a b
TUNER(PLL) X JR 0974 88-108-000-080 C-JUMPER,U a b
TUNER(PLL) X JR 0976 88-108-000-080 C-JUMPER,U a b
TUNER(PLL) X JR 0977 88-108-000-080 C-JUMPER,U a b
TUNER(PLL) X JR 0991 88-108-000-080 C-JUMPER,U a b
TUNER(PLL) X JW 0973 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0974 88-100-000-010 PLATING-JW, 0.58 SN95 a b

TUNER(PLL) X JW 0975 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0977 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0978 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0979 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0980 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0981 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0982 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0987 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) X JW 0989 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(PLL) S Q 0981 87-A30-494-080 TR,2SA1980G a b

 19 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(PLL) S Q 0982 87-A30-076-080 C-TR,2SC3052F a b
TUNER(PLL) S Q 0983 87-A30-076-080 C-TR,2SC3052F a b
TUNER(PLL) X R 0968 88-108-822-080 C-RES,U 8.2K-1/16W J a b
TUNER(PLL) X R 0975 88-108-562-080 C-RES,U 5.6K-1/16W J a b
TUNER(PLL) X R 0976 88-108-102-080 C-RES,U 1K-1/16W J a b
TUNER(PLL) X R 0977 88-108-102-080 C-RES,U 1K-1/16W J a b
TUNER(PLL) X R 0978 88-108-681-080 C-RES,U 680-1/16W J a b
TUNER(PLL) X R 0979 88-108-123-080 C-RES,U 12K-1/16W J a b
TUNER(PLL) X R 0980 88-108-684-080 C-RES,U 680K-1/16W J a b
TUNER(PLL) X R 0981 88-121-471-080 RES,470-1/8W J a b

TUNER(PLL) X R 0982 88-108-682-080 C-RES,U 6.8K-1/16W J a b
TUNER(PLL) X R 0983 88-108-392-080 C-RES,U 3.9K-1/16W J a b
TUNER(PLL) X R 0984 88-108-562-080 C-RES,U 5.6K-1/16W J a b
TUNER(PLL) X R 0985 88-121-471-080 RES,470-1/8W J a b
TUNER(PLL) X R 0986 88-121-221-080 RES,220-1/8W J a b
TUNER(PLL) X R 0987 88-121-472-080 RES,4.7K-1/8W J a b
TUNER(PLL) X R 0988 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(PLL) X R 0989 88-121-102-080 RES,1K-1/8W J a b
TUNER(PLL) X R 0990 88-108-563-080 C-RES,U 56K-1/16W J a b
TUNER(PLL) O R 0991 87-012-195-080 C-CAP,U 100P-50 J CH a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(PLL) X R 0992 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(PLL) O R 0993 87-012-195-080 C-CAP,U 100P-50 J CH a b
TUNER(PLL) X R 0994 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(PLL) O R 0995 87-012-195-080 C-CAP,U 100P-50 J CH a b
TUNER(PLL) X R 0996 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(PLL) X R 0997 88-108-154-080 C-RES,U 150K-1/16W J a b
TUNER(PLL) X R 0998 88-108-102-080 C-RES,U 1K-1/16W J a b
TUNER(PLL) X R 0999 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(PLL) O X 0992 87-A70-306-010 VIB,XTAL 4.500MHZ CSA-309ST a b
TUNER(RF) O C 0842 87-012-286-080 C-CAP,U 0.01-25 K B a b

TUNER(RF) X C 0843 88-108-000-080 C-JUMPER,U a b
TUNER(RF) O C 0844 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(RF) X C 0845 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X C 0846 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X C 0847 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X C 0848 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X C 0849 88-108-000-080 C-JUMPER,U a b
TUNER(RF) O C 0850 87-010-260-080 CAP,E 47-25 M 11L SME a b
TUNER(RF) O C 0851 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(RF) O C 0852 87-012-286-080 C-CAP,U 0.01-25 K B a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(RF) O C 0853 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(RF) O C 0860 87-012-286-080 C-CAP,U 0.01-25 K B a b
TUNER(RF) X C 0940 88-108-000-080 C-JUMPER,U a b
TUNER(RF) O C 0959 87-010-759-080 C-CAP,U 0.1-25 Z F a b
TUNER(RF) O C 0960 87-010-759-080 C-CAP,U 0.1-25 Z F a b
TUNER(RF) O C 0961 87-012-169-080 C-CAP,U 7P-50 D CH a b
TUNER(RF) O C 0962 87-010-401-080 CAP,E 1-50 M 11L SME a b
TUNER(RF) O C 0963 87-A12-319-080 C-CAP,U 0.1-25 K B a b
TUNER(RF) O CF 0831 87-008-261-010 FLTR,CF SFE10.7MA5 a b
TUNER(RF) O CF 0832 87-008-261-010 FLTR,CF SFE10.7MA5 a b

TUNER(RF) X D 0944 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) O D 0951 87-A40-799-040 C-VARI-CAP,KV1610S a b
TUNER(RF) ! O J 0831 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 a b
TUNER(RF) X JR 0834 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X JR 0835 88-108-561-080 C-RES,U 560-1/16W J a b
TUNER(RF) X JR 0943 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X JR 0946 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X JR 0950 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X JR 0951 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X JR 0952 88-129-000-080 C-JUMPER, 3216 a b

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(RF) X JR 0954 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X JR 0955 88-108-000-080 C-JUMPER,U a b
TUNER(RF) X JR 0964 88-129-000-080 C-JUMPER, 3216 a b
TUNER(RF) X JW 0831 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0834 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0851 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0903 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0909 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0942 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0952 88-100-000-010 PLATING-JW, 0.58 SN95 a b

TUNER(RF) X JW 0953 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0954 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0956 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0963 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) X JW 0965 88-100-000-010 PLATING-JW, 0.58 SN95 a b
TUNER(RF) O L 0832 87-005-847-080 COIL,2.2UH K CECS a b
TUNER(RF) O L 0952 87-A50-752-010 COIL,MW ANT(2B) a b
TUNER(RF) O L 0953 87-A50-753-010 COIL,MW OSC(2B) a b
TUNER(RF) S Q 0835 87-A30-521-080 C-TR,2SC5345SF/S(O) a b
TUNER(RF) S Q 0836 87-A30-677-040 C-TR,SRA2207S a b

 20 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
TUNER(RF) X R 0832 88-108-391-080 C-RES,U 390-1/16W J a b
TUNER(RF) X R 0840 88-108-221-080 C-RES,U 220-1/16W J a b
TUNER(RF) X R 0850 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(RF) X R 0851 88-118-000-080 C-JUMPER,S a b
TUNER(RF) X R 0852 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(RF) X R 0853 88-108-102-080 C-RES,U 1K-1/16W J a b
TUNER(RF) X R 0854 88-108-331-080 C-RES,U 330-1/16W J a b
TUNER(RF) X R 0855 88-108-183-080 C-RES,U 18K-1/16W J a b
TUNER(RF) X R 0856 88-108-103-080 C-RES,U 10K-1/16W J a b
TUNER(RF) X R 0857 88-108-181-080 C-RES,U 180-1/16W J a b

TUNER(RF) X R 0858 88-108-101-080 C-RES,U 100-1/16W J a b
TUNER(RF) X R 0860 88-108-101-080 C-RES,U 100-1/16W J a b
TUNER(RF) X R 0945 88-108-104-080 C-RES,U 100K-1/16W J a b
TUNER(RF) X R 0962 88-121-102-080 RES,1K-1/8W J a b
TUNER(RF) X R 0963 88-108-330-080 C-RES,U 33-1/16W J a b

 21 

MECHANICAL PARTS LIST

! = ! SAFTY PARTS
C = Components marked

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
APPEARANCE O 1 8C-NF9-003-010 CABI,FR U a .
APPEARANCE O 2 87-B00-002-010 BADGE,AIWA 30 ABS SIL a b
APPEARANCE O 3 8C-NF8-005-010 WINDOW,CASS 1 a b
APPEARANCE O 4 8C-NF8-006-010 WINDOW,CASS 2 a b
APPEARANCE O 5 8C-NF8-007-010 PANEL,FR a .
APPEARANCE O 6 8C-NF8-008-010 PANEL,TRAY a b
APPEARANCE O 7 8C-NF8-021-010 PANEL,LEFT . b
APPEARANCE O 8 8C-NF8-022-010 PANEL,RIGHT . b
APPEARANCE O 9 8C-NF8-023-010 PANEL,TOP . b
APPEARANCE O 10 8C-NF8-024-010 PANEL,LEFT V-2 a .

APPEARANCE O 11 8C-NF8-025-010 PANEL,RIGHT V-2 a .
APPEARANCE O 12 8C-NF8-026-010 PANEL,TOP V-2 a .
APPEARANCE O 13 8C-NF8-071-010 PANEL,FR HR . b
APPEARANCE O 14 8C-NF9-004-010 BOX,CASS 1 a b
APPEARANCE O 15 8C-NF9-005-010 BOX,CASS 2 a b
APPEARANCE O 16 8C-NF9-006-010 WINDOW,DISP U a .
APPEARANCE O 17 8C-NF9-010-010 WINDOW,DISP LH DINA . b
APPEARANCE O 18 8C-NF9-021-010 CABI,FR LH . b
APPEARANCE O 19 8C-NF9-011-010 CABI,REAR USC a .
APPEARANCE O 20 8C-NF9-012-010 CABI,REAR LHSC . b

CX-SND20 CX-SNR20
USC1 LHSC1
KNOB O 21 8C-NF8-009-010 KEY,POWER a b
KNOB O 22 8C-NF8-010-010 KEY,CD a b
KNOB O 23 8C-NF8-011-010 KEY,ENTER a b
KNOB O 24 8C-NF8-012-010 KEY,REC a b
KNOB O 25 8C-NF8-013-010 KEY,OPE a b
KNOB O 26 8C-NF8-015-010 KNOB,RTRY MIC . b
KNOB O 27 8C-NF8-027-010 KNOB,RTRY JOG a b
KNOB O 28 8C-NF9-001-010 KNOB,RTRY VOL a b
KNOB O 29 8C-NF5-031-010 PLATE,MIC . b
KNOB O 30 8C-NF8-014-010 REFLECTOR,ECO a b

PLATE X 31 84-711-909-010 LBL DATE CODE a .
PLATE X 32 87-057-961-010 LBL,CAUTION TRIANGLE . b
PLATE X 33 87-057-995-010 LBL,CAUTION EFSD . b
PLATE X 34 87-B40-281-010 LBL,BAR-CODE A 35X8 . b
PLATE X 35 87-B40-282-010 LBL,BAR-CODE AU 35X8 a .
PLATE X 36 8C-NF8-045-010 SH,FL a b
TAPE O 37 87-A90-193-010 HLDR,CV100 (B) a b
TAPE X 38 M8-CZK-292-070 CMAT6Z2(1+1)ALPS a b
TAPE O 39 8C-NF9-605-010 CONN ASSY,3P -PB a b
TAPE O 40 8C-NF9-606-010 CONN ASSY,8P -RPB a b

CX-SND20 CX-SNR20
USC1 LHSC1
CD X 41 M8-BZG-29J-070 BZG-2 ZD9GNC1 a b
OTHERS O 42 82-NF5-229-010 PLATE,LOCK(*) a b
OTHERS O 43 86-NF9-224-010 SPR-C,LOCK a b
OTHERS X 44 87-064-080-010 BINDER,WIRE a b
OTHERS O 45 87-NF4-216-010 HLDR,LOCK 1 a b
OTHERS O 46 87-NF4-217-110 HLDR,LOCK 2 a b
OTHERS O 47 8A-NF8-206-010 HLDR,PWB M a b
OTHERS O 48 8A-NF8-281-010 SPR-T,EJECT 1 a b
OTHERS O 49 8A-NF8-282-010 SPR-T,EJECT 2 a b
OTHERS X 50 8B-NF9-204-010 CUSH, 11-8.5-2 a b

OTHERS X 51 8C-NF7-207-010 HT-SINK,MAINC a b
OTHERS X 52 8C-NF8-213-010 HT-SINK,FIN C . b
OTHERS X 53 8C-NF9-203-010 HT-SINK,ASSAY1 C . b
OTHERS O 54 8Z-NF6-210-010 DMPR,150 N a b
OTHERS O 55 8A-NF9-211-010 HLDR,PWB PT HI a .
OTHERS O 56 8B-NF8-251-010 HLDR,PWB PT F8 . b
OTHERS X 57 8C-NF8-202-010 HLDR,TR a b
OTHERS X 58 8C-NF9-201-010 PLATE,EARTH MECHA a b
OTHERS X 59 8C-NF9-202-010 PLATE,EARTH MIC . b
SCREW O 60 87-067-689-010 BVTT+3-8 a b

CX-SND20 CX-SNR20
USC1 LHSC1
SCREW O 61 87-067-703-010 BVT2+3-10 W/0 SL0T a b
SCREW O 62 87-078-200-010 S-SCREW,ITC+4-8 R a b
SCREW O 63 87-721-096-410 QT2+3-10 W/O SLOT a b
SCREW O 64 87-B10-091-010 UTT2+3-10 W/O SLOT BLK a b
SCREW O 65 87-B10-315-010 BVIT3B+3-8 R W/O a b
SCREW O 66 87-NF4-224-010 S-SCREW,IT3B+3-8 CU a b
SCREW O 67 88-AR1-217-010 S-SCREW,BFT2+3-8 a b
FRCB MECHA O 68 8A-NFA-208-010 GUIDE,FL 100-25 ANFA a b
MECHANICAL X 69 8C-NF8-232-010 CHAS,MAIN CC 66-70 . b
MECHANICAL X 70 8C-NF8-233-010 CHAS,MAIN CC 66-45 a .

ELECTRICAL O 71 87-085-185-010 BUSHING,AC CORD(E) CM-22B . b
ELECTRICAL O 72 87-A90-193-010 HLDR,CV100 (B) a b
ELECTRICAL O 73 87-A91-422-010 BUSHING,AC CORD(U) a .
ELECTRICAL O 74 88-906-171-110 FF-CABLE, 6P 1.25 a .
ELECTRICAL O 75 88-906-251-110 FF-CABLE,6P 1.25 . b
ELECTRICAL O 76 88-908-291-110 FF-CABLE,8P 1.25 290MM a b
ELECTRICAL O 77 88-911-101-110 FF-CABLE,11P 1.25 100MM a b
ELECTRICAL O 78 8C-NF9-601-010 PT,CNF-9 U a .
ELECTRICAL O 79 8C-NF9-602-010 PT,CNF-9 LH . b
ELECTRICAL O 80 87-A80-110-010 AC CORD ASSY,U SPT-2W a .

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

 22 

! = ! SAFTY PARTS
C = Components marked

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
ELECTRICAL O 81 87-A80-188-010 AC CORD ASSY,BRAZ BLK SUN FAI . b

 23 

ACCESSORIES PARTS LIST

! = ! SAFTY PARTS
C = Components marked

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

CX-SND20 CX-SNR20
USC1 LHSC1
PACKING X 1 87-B40-098-010 BAG,PV 0.025-650-750 PL a b
PACKING X 2 8C-NF9-851-010 CUSHION,FRONT USC1 a .
PACKING X 3 8C-NF9-852-010 CUSHION,REAR USC1 a .
PACKING X 4 8C-NF9-853-010 CUSHION,FRONT LHSC1 . b
PACKING X 5 8C-NF9-854-010 CUSHION,REAR LHSC1 . b
PACKING X 6 92-370-716-010 SH,FOAMED-MAT 0.31-700-500 a b
PRINTED DU X 7 87-B40-085-010 BAG,PV 0.04-200-350 PL a b
PRINTED DU X 8 87-B50-053-010 WARR-CARD,USA CUST/AV,VISUAL a .
PRINTED DU X 9 87-B50-056-010 SH,CAUTION AC VOLTAGE . b
PRINTED DU X 10 87-B50-079-010 LIST,FACILITY(B)-0007 . b

PRINTED DU O 11 8C-NF9-902-010 IB,LH(ESP)S NSX-R20 . b
PRINTED DU O 12 8C-NF9-903-010 IB,U(ESF)S NSX-D20 a .
LBL,POP X 13 87-B40-034-010 LBL,USA 1-800 a .
LBL,POP X 14 8A-NF8-972-010 LBL,POP ENG a .
LBL,POP X 15 8C-NF8-971-010 LBL,POP UR a .
LBL,POP X 16 8C-NF9-970-010 LBL,POP UL a .
LBL,POP X 17 8C-NF9-972-010 LBL,POP LHL . b
LBL,POP X 18 8C-NF9-973-010 LBL,POP LHR . b
ACCESSORY O 19 87-A92-150-010 ANT,LOOP AM NO-CONT a b
ACCESSORY O 20 87-A92-262-010 PLUG,CONVERSION WT01011 . b

CX-SND20 CX-SNR20
USC1 LHSC1
ACCESSORY O 21 87-A92-345-010 ANT,WIRE FM(SEMI-ST) a b
ACCESSORY O 22 8C-NF8-702-010 RC UNIT,RC-CAS03(VS) a b

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

 24 

SCHEMATIC DIAGRAM – 1 (U : MAIN)

– 25 –

SCHEMATIC DIAGRAM – 2 (LH : MAIN)

– 26 –

SCHEMATIC DIAGRAM – 3 (U: FRONT)

– 27 –

SCHEMATIC DIAGRAM – 4 (LH : FRONT)

– 28 –

SCHEMATIC DIAGRAM – 5 (U : TUNER)

– 29 –

SCHEMATIC DIAGRAM – 6 (LH : TUNER)

– 30 –

SCHEMATIC DIAGRAM – 7 (PHONE)

– 31 –

SCHEMATIC DIAGRAM – 8 (PT)

– 32 –

211, IKENOHATA 1CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]

Printed in Singapore9301978
