Aiwa NSXAJ-310, NSXSZ-310, NSXSZ-315, NSXSZ-510 Service manual

Download

NSX-AJ310

NSX-SZ310 NSX-SZ315 NSX-SZ510

K,EZ,LH EZ LH

SERVICE MANUAL

COMPACT DISC

STEREO SYSTEM

SYSTEM

NSX-AJ310

TYPE : U

NSX-SZ310

TYPE : K,EZ,LH

NSX-SZ315

TYPE : EZ

NSX-SZ510

TYPE : LH

• This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-011-442-0T1).

CASSEIVER

CX-NAJ310

CX-NSZ310

CX-NSZ315

CX-NSZ510

SPEAKERS

SX-NAJ312

SX-NSZ312

SX-NSZ702

BASIC TAPE MECHANISM : ZZM-3 PR1NM/PR1NF BASIC CD MECHANISM : BZG-5 ZD3NM/YKZD3NF

MAIN

TAPE

MECHANISM

ZZM-3

PR1NM

ZZM-3

PR1NF

ZZM-3

PR1NF

ZZM-3

PR1NF

MECHANISM

BZG-5

ZD3NM

BZG-5

YKZD3NF

BZG-5

YKZD3NF

BZG-5

YKZD3NF

REMOTE

CONTROLLER

RC-ZAS02

• If requiring information about the CD mechanism, see Service Manual of

BZG-5, (S/M Code No. 09-00C-353-3N2).

S/M Code No. 09-012-442-0R1

REVISION

DATA

SPECIFICATIONS <U,LH>

<FM tuner section> Tuning range 87.5 MHz to 108 MHz Usable sensitivity (IHF) 13.2 dBf Antenna terminals 75 ohms (unbalanced)

<AM tuner section> Tuning range 530 kHz to 1710 kHz (10 kHz step)

Usable sensitivity 350 µV/m Antenna Loop antenna

<Amplifier section> CX-NAJ310: Power output 60 W + 60 W (50 Hz - 20 kHz,

Total harmonic distortion 0.08 % (30 W, 1 kHz, 6 ohms, DIN

CX-NSZ310: Power output Rated : 62 W + 62 W

Total harmonic distortion 0.08 % (40 W, 1 kHz, 6 ohms, DIN

CX-NSZ510: Power output Rated : 85 W + 85 W

Total harmonic distortion 0.08 % (40 W, 1 kHz, 6 ohms, DIN

Inputs VIDEO / AUX : 500 mV Outputs SPEAKERS : 6 ohms or more

<Cassette deck section> Track format 4 tracks, 2 channels stereo Frequency response 50 Hz - 15 kHz Recording system AC bias Heads Deck 1 : Playback head x 1

<Compact disc player section> Laser Semiconductor laser (λ = 780 nm) D-A converter 1 bit dual Signal-to-noise ratio 85 dB (1 kHz, 0 dB) Harmonic distortion 0.05 % (1 kHz, 0 dB)

<General> CX-NAJ310 Power requirements 120 V AC, 60 Hz Power consumption 70 W Power consumption With ECO mode on : 0.6 W in standby mode With ECO mode off : 20 W Dimensions of main unit 260 x 324 x 339 mm (W x H x D) (10 Weight 6.3 kg (13 lbs 14 oz)

531 kHz to 1602 kHz (9 kHz step)

T.H.D. less than 1 %, 6 ohms) 75 W + 75 W (1 kHz, T.H.D. less than 10 %, 6 ohms)

AUDIO)

(6 ohms, T.H.D. 1 %,1 kHz) Reference : 80 W + 80 W (6 ohms, T.H.D. 10 %, 1 kHz)

AUDIO)

(6 ohms, T.H.D. 1 %, 1 kHz) Reference : 100 W + 100 W (6 ohms, T.H.D. 10 %, 1 kHz)

AUDIO)

PHONES : 32 ohms or more

Deck 2 : Recording / Playback x 1, erase head x 1

/4 x 127/8 x 133/8 in.)

CX-NSZ310 Power requirements 120 V/220 - 230 V/240 V AC,

(Switchable), 50 Hz/60 Hz

Power consumption 90 W Power consumption With ECO mode on : 0.6 W in standby mode With ECO mode off : 19 W Dimensions of main unit 260 x 324 x 339 mm (W x H x D) Weight 6.8 kg

CX-NSZ510 Power requirements 120 V/220 - 230 V/240 V AC,

(Switchable), 50 Hz/60 Hz

Power consumption 105 W Power consumption With ECO mode on : 0.6 W in standby mode With ECO mode off : 20 W Dimensions of main unit 260 x 324 x 339 mm (W x H x D) Weight 7.2 kg

<Speaker system SX-NAJ312 (for NSX-AJ310)> Speaker system 3 way, bass reflex (magnetic shielded) Speaker units Woofer : 140 mm (55/8 in.) cone

Tweeter : 60 mm (23/8 in.) cone Super tweeter : 20 mm (13/16 in.) ceramic

Impedance 6 ohms Dimensions (W x H x D) 220 x 324 x 225 mm

(83/4 x 127/8 x 87/8 in.)

Weight 4.3 kg (9 lbs 8 oz)

<Speaker system SX-NSZ312 (for NSX-SZ310)> Speaker system 3 way, bass reflex (magnetic shielded) Speaker units Woofer : 140 mm cone

Tweeter : 60 mm cone Super tweeter : 20 mm ceramic

Impedance 6 ohms Dimensions (W x H x D) 220 x 324 x 225 mm Weight 4.3 kg

<Speaker system SX-NSZ702 (for NSX-SZ510)> Speaker system 2 way, bass reflex (magnetic shielded) Speaker units Woofer : 160 mm cone

Tweeter : 60 mm cone

Impedance 6 ohms Dimensions (W x H x D) 230 x 324 x 223 mm Weight 4.6 kg

• Design and specifications are subject to change without notice.

• The word "BBE"and the "BBE symbol" are trademarks of BBE

Sound, Inc.

Under license from BBE Sound,Inc.

– 2 –

SPECIFICATIONS <EZ,K>

<FM tuner section> Tuning range 87.5 MHz to 108 MHz Usable sensitivity (IHF) 16.8 dBf Antenna terminals 75 ohms (unbalanced)

<MW tuner section> Tuning range 530 kHz to 1710 kHz (10 kHz step)

531 kHz to 1602 kHz (9 kHz step)

Usable sensitivity 350 µV/m Antenna Loop antenna

<LW tuner section> Tuning range 144 kHz to 290 kHz Usable sensitivity 1400 µV/m Antenna Loop antenna

<Amplifier section> Power output Rated : 32 W + 32 W (6 ohms, T.H.D.

1 %, 1 kHz / DIN 45500) Reference : 40 W + 40 W (6 ohms, T.H.D. 10 %, 1 kHz / DIN 45324) EZ only : DIN MUSIC POWER : 120 W + 120 W

Total harmonic distortion 0.08 % (20 W, 1 kHz, 6 ohms, DIN

AUDIO)

Inputs VIDEO / AUX : 500 mV Outputs SPEAKERS : 6 ohms or more

PHONES : 32 ohms or more

<Cassette deck section> Track format 4 tracks, 2 channels stereo Frequency response 50 Hz - 15 kHz Recording system AC bias Heads Deck 1 : Playback head x 1

Deck 2 : Recording / Playback x 1, erase head x 1

<General> Power requirements 230 V AC, 50 Hz Power consumption 75 W Power consumption With ECO mode on : 0.6 W in standby mode With ECO mode off : 17 W Dimensions of main unit 260 x 324 x 339 mm (W x H x D) Weight 5.8 kg

<Speaker system SX-NSZ312> Speaker systm 3 way, bass reflex (magnetic shielded) Speaker unites Woofer : 140 mm cone

Tweeter : 60 mm cone Super tweeter : 20 mm ceramic

Impedance 6 ohms Dimensions (W x H x D) 220 x 324 x 225 mm Weight 4.3 kg

• Design and specifications are subject to change without notice.

• The word "BBE"and the "BBE symbol" are trademarks of BBE

Sound, Inc.

Under license from BBE Sound,Inc.

<Compact disc player section> Laser Semiconductor laser (λ = 780 nm) D-A converter 1 bit dual Signal-to-noise ratio 85 dB (1 kHz, 0 dB) Harmonic distortion 0.05 % (1 kHz, 0 dB)

– 3 –

PROTECTION OF EYES FROM LASER BEAM DURING SERVICING

This set employs laser. Therefore, be sure to follow carefully the instructions below when servicing.

WARNING!!

WHEN SERVICING, DO NOT APPROACH THE LASER EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE FROM A DISTANCE OF MORE THAN 30cm FROM THE SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL PICK-UP BLOCK.

s Caution: Invisible laser radiation when

open and interlocks defeated avoid exposure to beam.

s Advarsel: Usynlig laserståling ved åbning,

når sikkerhedsafbrydere er ude af funktion. Undgå udsættelse for stråling.

VAROITUS!

Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla saataa altistaa käyt-täjän turvallisuusluokan 1 ylittävälle näkymättömälle lasersäteilylle.

VARNING!

Om apparaten används på annat sätt än vad som specificeras i denna bruksanvising, kan användaren utsättas för osynling laserstrålning, som överskrider gränsen för laserklass 1.

CAUTION

Use of controls or adjustments or performance of procedures other than those specified herin may result in hazardous radiation exposure.

ATTENTION

L’utillisation de commandes, réglages ou procédures autres que ceux spécifiés peut entraîner une dangereuse exposition aux radiations.

ADVARSEL

Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude af funktion. Undgå udsættelse for stråling.

This Compact Disc player is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT label is located on the rear exterior.

CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT

Precaution to replace Optical block

(KSS-213F)

Body or clothes electrostatic potential could ruin laser diode in the optical block. Be sure ground body and workbench, and use care the clothes do not touch the diode.

1) After the connection, remove solder shown in right figure.

PICK-UP Assy PWB

Solder

– 4 –

NOTE ON BEFORE STARTING REPAIR

1. Forced discharge of electrolytic capacitor of power supply block

When repair is going to be attempted in the set that uses relay circuit in the power supply block, electric potential is kept charged across the electrolytic capacitors (C101, 102) even though AC power cord is removed. If repair is attempted in this condition, secondary defect can occur. In order to prevent the secondary trouble, perform the following measures before starting repair work.

Discharge procedure

1 Remove the AC power cord.

11 22

2 Connect a discharging resistor at an end of lead wire that

has clips at both ends. Connect the other end of the lead wire to metal chassis.

3 Contact the other end of the discharging resistor to the

positive (+) side (+VH) of C101. (For two seconds)

4 Contact the same end of the discharging resistor as step

3 to the negative (-) side (-VH) of C102 in the same way.

(For two seconds)

5 Check that voltage across C101 and C102 has decreased

to 1 V or less using a multimeter or an oscilloscope.

Select a discharging resistor referring to the following table.

Charging voltage (V) Discharging

(C101, 102) resistor (Ω)

25-48 100 3 87-A00-247-090

49-140 220 5 87-A00-232-090

Note: The reference numbers (C101, C102) of the electrolytic capacitors can change depending on the models. Be sure to check the

reference numbers of the charging capacitors on schematic diagram before starting the discharging work.

Rated power (W) Parts number

MAIN C.B

D101

C101 C102

Fig-1

2. Check items before exchanging the MICROCOMPUTER

Be sure to check the following items before exchanging the MICROCOMPUTER. Exchange the MICROCOMPUTER after confirming that the MICROCOMPUTER is surely defective.

2-1. Regarding the HOLD terminal of the MICROCOMPUTER

When the HOLD terminal (INPUT) of the MICROCOMPUTER is “H”, the MICROCOMPUTER is judged to be operating correctly. When this terminal is “L”, the main power cannot be turned on. Therefore, be sure to check the terminal voltage of the HOLD terminal before exchange. When the MICROCOMPUTER is not defective, the HOLD terminal can also go “L” when the POWER AMPLIFIER has any abnormalities that triggers the abnormality detection circuit on the MAIN C. B. that sets the HOLD terminal to “L”.

• Good or no good judgement of the MICROCOMPUTER

1 Turn on the AC main power.

11 22

2 Confirm that the main power is turned on and the HOLD terminal of the MICROCOMPUTER keeps the “H” level or not.

22 33

3 When the HOLD terminal is “L” level, the abnormality detection circuit is judged to be working correctly and the

MICROCOMPUTER is judged to be good.

– 5 –

In such a case, check also if the POWER AMPLIFIER circuit or power supply circuit has any abnormalities or not.

2-2. Regarding reset

There are cases that the machine does not work correctly because the MICROCOMPUTER is not reset even though the AC power cord is re-inserted, or the software reset (pressing the STOP key + POWER key) is performed. When the above described phenomenon occurs, it can lead to wrong judgement as if the MICROCOMPUTER is defective and to exchange the MICROCOMPUTER. In such a case, perform the forced-reset by the following procedure and check good or no good of the MICROCOMPUTER.

1 Remove the AC power cord.

FRONT C.B

MICROCOMPUTER

FRONT C.B

2 Short both ends of the electrolytic capacitor C113 that is connected to VDD of the MICROCOMPUTER with tweezers.

22 33

3 Connect the AC power cord again. If the MICROCOMPUTER returns to the normal operation, the MICROCOMPUTER is

good.

Note: The reference number or MICROCOMPUTER pin number of transistor (Q110) and electrolytic capacitor (C113) can change depending

on the models. Be sure to check the reference numbers on schematic diagram before starting the discharging work.

C113

Short with tweezers.

Fig-2-2

C113

VSS

VDD

MICROCOMPUTER

2-3. Confirmation of soldering state of MICROCOMPUTER

Check the soldering state of the MICROCOMPUTER in addition to the above described procedures. Be sure to exchange the MICROCOMPUTER after surely confirming that the trouble is not caused by poor soldering but the MICROCOMPUTER itself.

– 6 –

ELECTRICAL MAIN PARTS LIST

REF. NO.

87-A21-269-010 IC,EW732 87-A21-419-040 C-IC,NJM14558MD-TE2 87-A21-893-040 C-IC,NJM14558V-TE2 87-A21-401-040 C-IC,M61503FP 87-A21-695-010 IC,LA1845L

87-A20-440-040 C-IC,BU1920FS<5EZ> 8B-NF9-601-030 C-IC,UPD780226GF-021-3BA<EXCEPT 5EZ> 8B-NF9-602-030 C-IC,UPD780228GF-078-3BA<5EZ> 87-A21-218-110 IC,NJL64H380A 87-A21-928-010 IC,LC72131D-N

TRANSISTOR

87-A30-494-080 TR,2SA1980G 87-A30-559-010 TR,CSB1370EF 87-A30-492-080 TR,2SC5343G 87-A30-076-080 C-TR,2SC3052F 87-A30-075-080 C-TR,2SA1235F

87-A30-107-070 C-TR,CMBT5401 87-A30-484-080 C-TR,KRA102S 87-A30-468-080 C-TR,KRC102S-RTK 87-A30-190-080 TR,CC5551 87-A30-106-040 C-TR,CMBT5551

87-A30-528-010 TR,2SB1686 87-A30-529-010 TR,2SD2642 87-A30-162-010 FET,2SK2937 87-A30-091-080 FET,2SJ460 87-A30-090-080 FET,2SK2541

87-A30-062-080 C-TR,KRC104S 87-A30-495-080 TR,2SA1981Y 87-A30-087-080 C-FET,2SK2158 87-A30-582-080 TR,CDA1585BC 87-A30-288-040 C-TR,DTC114YKA

87-A30-490-080 C-TR,KRC107S<EXCEPT U> 89-327-143-080 C-TR,2SC2714O 87-A30-489-080 C-TR,KRA107S 89-503-602-080 C-FET,2SK360E 87-A30-086-040 C-TR,CSD1306E<K,EZ,5EZ>

87-A30-234-080 TR,CSC4115BC

DIODE

87-A40-393-090 DIODE,1N5402GW(F20) 87-A40-291-080 DIODE,1N4148M (CPT) 87-A40-454-090 DIODE,1N5393 GW 12.5<K,EZ,5EZ,U> 87-A40-455-090 DIODE,RL203 GW<LH,U> 87-A40-553-080 DIODE,1N4003 LES

87-A40-776-080 ZENER,UZ27BSD 87-A40-764-080 ZENER,UZ10BSC 87-A40-270-080 C-DIODE,MC2838 87-A40-269-080 C-DIODE,MC2836 87-A40-747-080 ZENER,UZ5.1BSB

87-A40-749-080 ZENER,UZ5.6BSB 87-A40-748-080 ZENER,UZ5.6BSA 87-A40-739-080 ZENER,UZ2.7BSA 87-017-149-080 ZENER,HZS6A2L

MAIN C.B

C3 87-012-368-080 C-CAP,S 0.1-50 F C4 87-012-368-080 C-CAP,S 0.1-50 F C5 87-012-368-080 C-CAP,S 0.1-50 F C6 87-012-368-080 C-CAP,S 0.1-50 F C9 87-010-759-080 C-CAP,U, 0.1-25F

C10 87-010-759-080 C-CAP,U, 0.1-25F C11 87-010-759-080 C-CAP,U, 0.1-25F C12 87-010-759-080 C-CAP,U, 0.1-25F C19 87-A12-776-090 CAP,E 2200-50<K,EZ,5EZ> C19 87-A12-036-000 CAP,E 2200-63<LH,U>

PART NO. DESCRIPTIONREF. NO. KANRI

KANRI NO.

DESCRIPTION

C19 87-016-520-000 CAP,E 3300-65<5LH> C20 87-A12-776-090 CAP,E 2200-50<K,EZ,5EZ> C20 87-A12-036-000 CAP,E 2200-63<LH,U> C20 87-016-520-000 CAP,E 3300-65<5LH> C21 87-A12-777-090 CAP,E 3300-25<EXCEPT 5LH>

C21 87-A12-780-090 CAP,E 4700-35<5LH> C22 87-A12-777-090 CAP,E 3300-25<EXCEPT 5LH> C22 87-A12-780-090 CAP,E 4700-35<5LH> C25 87-A12-072-080 CAP,E 100-25 SMG C26 87-A12-072-080 CAP,E 100-25 SMG

C27 87-A12-072-080 CAP,E 100-25 SMG C28 87-A12-072-080 CAP,E 100-25 SMG C30 87-010-430-080 CAP,E 100-63<5LH> C30 87-A12-095-080 CAP,E 100-50<EXCEPT 5LH> C31 87-A12-062-080 CAP,E 100-10 SMG

C32 87-012-286-080 CAP, U 0.01-25 C33 87-A12-062-080 CAP,E 100-10 C34 87-A12-072-080 CAP,E 100-25 SMG C35 87-A12-071-080 CAP,E 47-25 SMG C36 87-A12-067-080 CAP,E 330-16 SMG

C38 87-012-286-080 CAP, U 0.01-25 C60 87-A12-089-080 CAP,E 3.3-50 SMG C61 87-A12-071-080 CAP,E 47-25 SMG C83 87-A12-068-080 CAP,E 470-16<K,EZ,5EZ> C83 87-A12-074-080 CAP,E 470-25<LH,5LH,U>

C97 87-010-831-080 C-CAP,U,0.1-16F C101 87-012-278-080 C-CAP,U 2200P-50<K,EZ,5EZ> C101 87-012-279-080 C-CAP,U 2700P-50<LH,5LH,U> C102 87-012-278-080 C-CAP,U 2200P-50<K,EZ,5EZ> C102 87-012-279-080 C-CAP,U 2700P-50<LH,5LH,U>

C103 87-A12-084-080 CAP,E 0.22-50 SMG C104 87-A12-084-080 CAP,E 0.22-50 SMG C105 87-012-277-080 C-CAP, U 1800P-50 B C106 87-012-277-080 C-CAP, U 1800P-50 B C107 87-A12-089-080 CAP,E 3.3-50 SMG

C108 87-A12-089-080 CAP,E 3.3-50 SMG C109 87-012-195-080 C-CAP,U 100P-50<K,EZ,5EZ> C110 87-012-195-080 C-CAP,U 100P-50<K,EZ,5EZ> C111 87-A12-077-080 CAP,E 33-35 SMG C112 87-A12-077-080 CAP,E 33-35 SMG

C113 87-A10-596-080 C-CAP,S 100P-100<LH,5LH> C113 87-012-195-080 C-CAP,U 100P-50<K,EZ,5EZ,U> C114 87-A10-596-080 C-CAP,S 100P-100<LH,5LH> C114 87-012-195-080 C-CAP,U 100P-50<K,EZ,5EZ,U> C117 87-012-368-080 C-CAP,S 0.1-50 F

C118 87-012-368-080 C-CAP,S 0.1-50 F C119 87-012-286-080 CAP, U 0.01-25 C120 87-012-286-080 CAP, U 0.01-25 C123 87-010-177-080 C-CAP,S 820P-50 SL C124 87-010-177-080 C-CAP,S 820P-50 SL

C133 87-012-282-080 CAP, U 4700P-50 C140 87-012-278-080 C-CAP,U 2200P-50 B C186 87-010-759-080 C-CAP,U, 0.1-25F C187 87-010-866-080 CAP,E 10-63<LH,5LH,U> C187 87-A12-091-080 CAP,E 10-50<K,EZ,5EZ>

C188 87-010-866-080 CAP,E 10-63<LH,5LH,U> C188 87-A12-091-080 CAP,E 10-50<K,EZ,5EZ> C223 87-010-176-080 C-CAP,S 680P-50<K,EZ,5EZ> C224 87-010-176-080 C-CAP,S 680P-50<K,EZ,5EZ> C225 87-012-368-080 C-CAP,S 0.1-50 F

C226 87-012-368-080 C-CAP,S 0.1-50 F C227 87-012-368-080 C-CAP,S 0.1-50 F C228 87-012-368-080 C-CAP,S 0.1-50 F C229 87-010-191-080 C-CAP,S 0.015-50<K,EZ,5EZ> C230 87-010-191-080 C-CAP,S 0.015-50<K,EZ,5EZ>

C231 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ> C232 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ> C241 87-010-831-080 C-CAP,U,0.1-16F C301 87-012-275-080 C-CAP,U 1200P-50 B C302 87-012-275-080 C-CAP,U 1200P-50 B

PART NO.

NO.

– 7 –

PART NO.

NO.

C303 87-012-275-080 C-CAP,U 1200P-50 B C304 87-012-275-080 C-CAP,U 1200P-50 B C307 87-A12-062-080 CAP,E 100-10 SMG C308 87-A12-062-080 CAP,E 100-10 SMG C309 87-012-188-080 C-CAP,U 47P-50 CH

C310 87-012-188-080 C-CAP,U 47P-50 CH C313 87-012-284-080 CAP, U 6800P-50 C314 87-012-284-080 CAP, U 6800P-50 C315 87-A12-062-080 CAP,E 100-10 SMG C317 87-A12-085-080 CAP,E 0.33-50 SMG

C318 87-A12-085-080 CAP,E 0.33-50 SMG C326 87-010-787-080 CAP, U 0.022-25 C327 87-010-831-080 C-CAP,U,0.1-16F C350 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ> C360 87-A12-087-080 CAP,E 1-50 SMG

C399 87-A10-039-080 C-CAP,U 470P-50 J CH C401 87-A12-083-080 CAP,E 0.1-50 SMG C402 87-A12-083-080 CAP,E 0.1-50 SMG C403 87-012-193-080 C-CAP,U 82P-50 CH C404 87-012-193-080 C-CAP,U 82P-50 CH

C405 87-012-286-080 CAP, U 0.01-25 C406 87-012-286-080 CAP, U 0.01-25 C407 87-012-286-080 CAP, U 0.01-25 C408 87-012-286-080 CAP, U 0.01-25 C409 87-012-278-080 C-CAP,U 2200P-50 B

C410 87-012-278-080 C-CAP,U 2200P-50 B C411 87-A12-091-080 CAP,E 10-50 SMG C412 87-A12-091-080 CAP,E 10-50 SMG C452 87-A12-069-080 CAP,E 22-25 SMG C453 87-012-279-080 C-CAP,U 2700P-50 B

C454 87-012-279-080 C-CAP,U 2700P-50 B C455 87-012-279-080 C-CAP,U 2700P-50 B C456 87-012-286-080 CAP, U 0.01-25 C457 87-A12-361-080 CAP,M 5600P-100 J CP C458 87-012-274-080 CHIP CAP,U 1000P-50B

C459 87-012-271-080 CAP, U 560P-50 C460 87-010-831-080 C-CAP,U,0.1-16F C461 87-012-158-080 C-CAP,S 390P-50 CH C462 87-012-158-080 C-CAP,S 390P-50 CH C470 87-018-127-080 CAP, CER 470P-50V

C605 87-012-280-080 CAP, U 3300P-50 C606 87-012-280-080 CAP, U 3300P-50 C609 87-010-785-080 C-CAP,U0.015-25BK C610 87-010-785-080 C-CAP,U0.015-25BK C611 87-A12-084-080 CAP,E 0.22-50 SMG

C612 87-A12-084-080 CAP,E 0.22-50 SMG C613 87-A12-084-080 CAP,E 0.22-50 SMG C614 87-A12-084-080 CAP,E 0.22-50 SMG C615 87-012-172-080 CAPACITOR CHIP U 10P CH C616 87-016-459-080 CAP,E 470-10 SMG

C617 87-016-459-080 CAP,E 470-10 SMG C618 87-A12-091-080 CAP,E 10-50 SMG C620 87-010-263-080 CAP, ELECT 100-10V C623 87-A12-372-080 CAP,M 0.047-100 J CP C624 87-A12-372-080 CAP,M 0.047-100 J CP

C630 87-016-669-080 C-CAP,S 0.1-25<EXCEPT 5LH> C630 87-A10-260-080 C-CAP,U 0.1-16<5LH> C631 87-012-281-080 C-CAP,U 3900P-50 B C632 87-012-281-080 C-CAP,U 3900P-50 B C633 87-A11-070-080 C-CAP,U 0.033-16 K B

C634 87-A11-070-080 C-CAP,U 0.033-16 K B C661 87-012-336-080 CAP, CHIP U 330P SL C662 87-012-336-080 CAP, CHIP U 330P SL C669 87-012-274-080 C-CAP,U 1000P-50<K,EZ,5EZ> C670 87-012-274-080 C-CAP,U 1000P-50<K,EZ,5EZ>

C677 87-012-286-080 CAP, U 0.01-25 C771 87-A12-062-080 CAP,E 100-10 SMG C772 87-012-286-080 CAP, U 0.01-25 C779 87-010-949-080 C-CAP,S 0.01-50<K,EZ,5EZ> C780 87-010-949-080 C-CAP,S 0.01-50<K,EZ,5EZ>

DESCRIPTIONREF. NO. KANRI

PART NO.

NO.

C782 87-012-286-080 CAP, U 0.01-25 C783 87-012-286-080 CAP, U 0.01-25 C784 87-012-286-080 CAP, U 0.01-25 C785 87-012-286-080 CAP, U 0.01-25 C786 87-012-286-080 CAP, U 0.01-25

C788 87-012-167-080 C-CAP,U 5P-50 CH C789 87-A12-052-080 C-CAP,S 0.033-25<LH,5LH,U> C789 87-016-118-080 C-CAP,U0.022-25<K,EZ,5EZ> C790 87-A12-052-080 C-CAP,S 0.033-25<LH,5LH,U> C790 87-016-118-080 C-CAP,U0.022-25<K,EZ,5EZ>

C791 87-010-831-080 C-CAP,U,0.1-16F C792 87-012-286-080 CAP, U 0.01-25 C793 87-A12-090-080 CAP,E 4.7-50 SMG C795 87-012-286-080 CAP, U 0.01-25 C796 87-012-286-080 CAP, U 0.01-25

C797 87-A12-091-080 CAP,E 10-50 SMG C798 87-012-286-080 CAP, U 0.01-25 C799 87-A12-093-080 CAP,E 33-50 SMG C800 87-010-829-080 CAP, U 0.047-16 C801 87-A12-089-080 CAP,E 3.3-50 SMG

C802 87-010-829-080 CAP, U 0.047-16 C803 87-010-787-080 CAP, U 0.022-25 C804 87-A12-062-080 CAP,E 100-10 SMG C807 87-A12-086-080 CAP,E 0.47-50 SMG C808 87-A12-087-080 CAP,E 1-50 SMG

C809 87-A12-087-080 CAP,E 1-50 SMG C810 87-010-831-080 C-CAP,U,0.1-16F C814 87-012-286-080 CAP, U 0.01-25 C815 87-A12-086-080 CAP,E 0.47-50 SMG C816 87-A12-086-080 CAP,E 0.47-50 SMG

C818 87-012-276-080 C-CAP SS 1500<K,EZ,5EZ> C821 87-A12-091-080 CAP,E 10-50 SMG C823 87-012-349-080 C-CAP,S 1000P-50<K,EZ,5EZ> C823 87-010-177-080 C-CAP,S 820P-50<LH,5LH,U> C824 87-A12-090-080 CAP,E 4.7-50 SMG

C825 87-010-596-080 CAP, S 0.047-16 C831 87-A12-092-080 CAP,E 22-50<K,EZ,5EZ> C842 87-012-286-080 CAP, U 0.01-25 C844 87-012-286-080 CAP, U 0.01-25 C850 87-A12-071-080 CAP,E 47-25 SMG

C851 87-012-286-080 CAP, U 0.01-25 C852 87-012-286-080 CAP, U 0.01-25 C853 87-012-286-080 CAP, U 0.01-25 C858 87-010-831-080 C-CAP,U,0.1-16F C859 87-010-831-080 C-CAP,U,0.1-16<K,EZ,5EZ>

C860 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ> C869 87-012-286-080 CAP, U 0.01-25<5EZ> C870 87-012-274-080 CHIP CAP,U 1000P-50<5EZ> C871 87-012-199-080 CAP 220P<5EZ> C872 87-012-199-080 CAP 220P<5EZ>

C873 87-A10-039-080 C-CAP,U 470P-50<5EZ> C874 87-A12-091-080 CAP,E 10-50<5EZ> C875 87-010-759-080 C-CAP,U, 0.1-25<5EZ> C876 87-A12-091-080 CAP,E 10-50<5EZ> C877 87-012-286-080 CAP, U 0.01-25<5EZ>

C878 87-012-184-080 C-CAP,U 33P-50<5EZ> C879 87-012-180-080 C-CAP,U 22P-50<5EZ> C901 87-018-145-080 CAP,TC-U 6.8P-50<LH,5LH,U> C904 87-012-286-080 CAP, U 0.01-25<LH,5LH,U> C905 87-012-286-080 CAP, U 0.01-25<LH,5LH,U>

C907 87-012-286-080 CAP, U 0.01-25<LH,5LH,U> C908 87-A10-915-080 C-CAP,U 1000P-25<LH,5LH,U> C909 87-012-286-080 CAP, U 0.01-25<LH,5LH,U> C910 87-012-174-080 CAP CHIP U 12P-50<LH,5LH,U> C911 87-012-170-080 C-CAP,U 8P-50<LH,5LH,U>

C912 87-012-195-080 C-CAP,U 100P-50<LH,5LH,U> C913 87-012-286-080 CAP, U 0.01-25<LH,5LH,U> C914 87-012-166-080 C-CAP,U 4P-50<LH,5LH,U> C915 87-012-174-080 CAP CHIP CERA SS 12P<LH,5LH,U> C916 87-012-180-080 C-CAP,U 22P-50<LH,5LH,U>

DESCRIPTIONREF. NO. KANRI

– 8 –

C917 87-012-186-080 C-CAP,U 39P-50<LH,5LH,U>

NO.

C918 87-A10-039-080 C-CAP,U 470P-50<LH,5LH,U> C921 87-012-195-080 C-CAP,U 100P-50<LH,5LH,U> C922 87-012-174-080 CAP CHIP CERA SS 12P<LH,5LH,U> C940 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ>

C942 87-012-165-080 CAP 3P<K,EZ,5EZ> C947 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ> C948 87-A10-039-080 C-CAP,U 470P-50<K,EZ,5EZ> C952 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ> C957 87-012-174-080 CAP CHIP CERA SS 12P<K,EZ,5EZ>

C958 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ> C959 87-010-831-080 C-CAP,U,0.1-16F C960 87-010-831-080 C-CAP,U,0.1-16F C961 87-012-167-080 C-CAP,U 5P-50<LH,5LH,U> C962 87-A12-087-080 CAP,E 1-50<K,EZ,5EZ>

C963 87-015-785-080 CHIP CAPACITOR, 0.1-25 Z F C971 87-A12-067-080 CAP,E 330-16 SMG C972 87-A12-090-080 CAP,E 4.7-50 SMG C973 87-012-286-080 CAP, U 0.01-25 C974 87-012-286-080 CAP, U 0.01-25

C979 87-012-195-080 C-CAP,U 100P-50CH C981 87-A12-071-080 CAP,E 47-25 SMG C982 87-010-831-080 C-CAP,U,0.1-16F C983 87-012-286-080 CAP, U 0.01-25 C984 87-012-286-080 CAP, U 0.01-25

C985 87-012-195-080 C-CAP,U 100P-50<K,EZ,5EZ> C987 87-012-286-080 CAP, U 0.01-25 C989 87-012-286-080 CAP, U 0.01-25<K,EZ,5EZ> C991 87-012-176-080 CAP 15P C992 87-012-176-080 CAP 15P

C993 87-012-274-080 CHIP CAP,U 1000P-50B C995 87-012-274-080 CHIP CAP,U 1000P-50B C997 87-010-831-080 C-CAP,U,0.1-16F C998 87-A12-071-080 CAP,E 47-25 SMG C999 87-A11-155-080 CAP,TC U 0.01-16 Z F

CF831 87-008-261-010 FILTER,CF SFE10.7MA5<LH,5LH,U> CF831 87-008-423-010 FILTER,CF SFE10.7MS3GA<K,EZ,5EZ> CF832 82-785-747-010 CF MS2 GHY R<K,EZ,5EZ> CF832 87-008-261-010 FILTER, SFE10.7MA5-A<LH,5LH,U> CN301 87-A60-620-010 CONN,3P V 2MM JMT

CN351 87-A60-625-010 CONN,8P V 2MM JMT CN601 87-099-719-010 CONN,30P H BLK TYK-B(X) CN602 87-A60-131-010 CONN,6P V FE CNA1 8A-NF8-653-010 CONN ASSY,9P TID-A(480)<LH,5LH> CNA301 86-ZM3-604-210 CONN ASSY,3P-PB

CNA351 86-ZM3-605-110 CONN ASSY,8P-RPB D902 87-A40-128-080 C-VARI-CAP,HVU202A<LH,5LH,U> D903 87-A40-128-080 C-VARI-CAP,HVU202A<LH,5LH,U> FC602 88-906-251-110 FF-CABLE,6P 1.25 FFE831 A8-6ZA-19M-030 6ZA-1 YFEMENM<K,EZ,5EZ>

J202 87-A61-480-010 JACK,DIA6.3 BLK ST W/SW MSC16A J203 87-A60-238-010 TERMINAL,SP 4P (MSC) J602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN J831 87-A60-202-010 TERMINAL,ANT 4P MSP-154V<LH,5LH,U> J832 87-A60-403-010 TERMINAL,ANT PAL 2P HSP<K,EZ,5EZ>

JR123 87-A10-596-080 C-CAP,S 100P-100<LH,5LH> JR123 87-012-195-080 C-CAP,U 100P-50<K,EZ,5EZ,U> JR124 87-A10-596-080 C-CAP,S 100P-100<LH,5LH> JR124 87-012-195-080 C-CAP,U 100P-50<K,EZ,5EZ,U> L201 87-A50-610-010 COIL,1UH K(MDEC)

L202 87-A50-610-010 COIL,1UH K(MDEC) L451 87-007-342-010 COIL,OSC 85KHZ BIAS L801 87-A50-608-010 COIL,FM DET-N(TOK) L802 87-A91-551-010 FLTR,PCFJZH-450 L(TOK) L811 87-005-847-080 COIL,2.2UH(CECS)

L832 87-005-847-080 COIL,2.2UH(CECS) L861 87-005-847-080 COIL,2.2UH(CECS)<5EZ> L902 88-ZA1-602-110 COIL,FM-RF-U2 2G<LH,5LH,U> L903 88-ZA1-601-010 COIL,FM-RF-U1 2G<LH,5LH,U> L904 87-005-847-080 COIL,2.2UH(CECS)<LH,5LH,U>

DESCRIPTIONREF. NO. PART NO.

L905 88-ZA1-624-010 COIL,FM IFT 7-6.2 (COILS)<LH,5LH,U> L906 88-ZA1-603-010 COIL,FM-OSC-U 2G<LH,5LH,U> L941 87-A50-020-010 COIL,ANT LW(COI)<K,EZ,5EZ> L942 87-A50-019-010 COIL,OSC LW(COI)<K,EZ,5EZ> L951 8A-NF8-668-010 COIL,AM PACK 2(TOK)<K,EZ,5EZ>

L951 8A-NF8-667-010 COIL,AM PACK 4(TOK)<LH,5LH,U> R129 87-A00-257-080 RES,M/F 0.15-1W J R129 87-A00-262-080 RES,M/F 0.15-2W J<LH,5LH> R129 87-A00-258-080 RES,M/F 0.22-1W J<K,EZ,5EZ> R130 87-A00-257-080 RES,M/F 0.15-1W J

R130 87-A00-262-080 RES,M/F 0.15-2W J<LH,5LH> R130 87-A00-258-080 RES,M/F 0.22-1W J<K,EZ,5EZ> R131 87-A00-257-080 RES,M/F 0.15-1W J R131 87-A00-262-080 RES,M/F 0.15-2W J<LH,5LH> R131 87-A00-258-080 RES,M/F 0.22-1W J<K,EZ,5EZ>

R132 87-A00-257-080 RES,M/F 0.15-1W J R132 87-A00-262-080 RES,M/F 0.15-2W J<LH,5LH> R132 87-A00-258-080 RES,M/F 0.22-1W J<K,EZ,5EZ> R243 87-A00-439-050 RES,180-1/2W J RP<EXCEPT LH,U> R243 87-A00-440-050 RES,220-1/2W J RP<LH,U>

R244 87-A00-439-050 RES,180-1/2W J RP<EXCEPT LH,U> R244 87-A00-440-050 RES,220-1/2W J RP<LH,U> R245 87-A00-439-050 RES,180-1/2W J RP<EXCEPT LH,U> R245 87-A00-440-050 RES,220-1/2W J RP R245 87-A00-441-050 RES,270-1/2W J RP<LH>

R246 87-A00-439-050 RES,180-1/2W J RP<EXCEPT LH,U> R246 87-A00-440-050 RES,220-1/2W J RP R246 87-A00-441-050 RES,270-1/2W J RP<LH> R790 87-012-286-080 CAP, U 0.01-25 R991 87-012-195-080 C-CAP,U 100P-50CH

R993 87-012-195-080 C-CAP,U 100P-50CH R995 87-012-195-080 C-CAP,U 100P-50CH SFR451 87-024-435-080 SFR 33K H RH063EC SFR452 87-024-435-080 SFR 33K H RH063EC TC942 87-A91-774-080 TRIMMER,PLY 30P 6.8X5.4<K,EZ,5EZ>

TH101 87-A91-042-080 C-THMS,100K 55001 TH102 87-A91-042-080 C-THMS,100K 55001 W99 8A-NF9-609-010 F-CABLE,9P 2.5 480MM<K,EZ,5EZ,U> WH1 87-A90-510-010 HLDR,WIRE 2.5-9P X862 87-A70-307-010 VIB,XTAL 4.332MHZ CSA-309ST<5EZ>

X992 87-A70-306-010 VIB,XTAL 4.500MHZ CSA-309ST

FRONT C.B

C108 87-010-785-080 C-CAP,U 0.015-25BK C153 87-010-787-080 CAP, U 0.022-25 C154 87-010-246-040 CAP,E 47-35 SME C155 87-010-404-040 CAP,E 4.7-50 SME C156 87-010-404-040 CAP,E 4.7-50 SME

C301 87-012-278-080 C-CAP,U 2200P-50 B C351 87-A10-353-080 C-CAP,U 0.22-10KB C361 87-012-274-080 CHIP CAP,U 1000P-50B C362 87-012-274-080 CHIP CAP,U 1000P-50B C371 87-012-274-080 CHIP CAP,U 1000P-50B

C372 87-012-274-080 CHIP CAP,U 1000P-50B C601 87-010-382-040 CAP,E 22-25 SME C702 87-012-286-080 CAP, U 0.01-25 C801 87-A10-804-080 C-CAP,S 0.1-25 J B C803 87-012-280-080 CAP, U 3300P-50

C804 87-A10-592-080 C-CAP,S 0.015-50 J B C805 87-012-184-080 C-CAP,U 33P-50 CH C806 87-012-274-080 CHIP CAP,U 1000P-50B C807 87-012-274-080 CHIP CAP,U 1000P-50B C808 87-010-544-040 CAP,E 0.1-50 SME

C809 87-010-404-040 CAP,E 4.7-50 SME C810 87-016-114-080 C-CAP,U 0.01-25B C811 87-A12-052-080 C-CAP,S 0.033-25 J B C901 87-012-195-080 C-CAP,U 100P-50CH C902 87-012-195-080 C-CAP,U 100P-50CH

KANRI NO.

DESCRIPTIONREF. NO. PART NO.KANRI

– 9 –

KANRI

DESCRIPTIONREF. NO. PART NO.

NO.

C903 87-012-195-080 C-CAP,U 100P-50CH C904 87-012-195-080 C-CAP,U 100P-50CH C905 87-012-195-080 C-CAP,U 100P-50CH C906 87-012-195-080 C-CAP,U 100P-50CH C907 87-012-195-080 C-CAP,U 100P-50CH

C908 87-012-195-080 C-CAP,U 100P-50CH C909 87-012-195-080 C-CAP,U 100P-50CH C910 87-012-195-080 C-CAP,U 100P-50CH C911 87-012-274-080 CHIP CAP,U 1000P-50B C912 87-010-831-080 C-CAP,U,0.1-16F

C913 87-A10-189-040 CAP,E 220-10 C914 87-A10-189-040 CAP,E 220-10 C915 87-010-831-080 C-CAP,U,0.1-16F C916 87-010-831-080 C-CAP,U,0.1-16F C917 87-010-831-080 C-CAP,U,0.1-16F

C919 87-012-286-080 CAP, U 0.01-25 C920 87-010-829-080 CAP, U 0.047-16 C921 87-012-282-080 CAP, U 4700P-50 C951 87-012-172-080 CAPACITOR CHIP U 10P CH C952 87-010-854-080 C-CAP,S 560PCH

C953 87-012-349-080 C-CAP,S 1000P-50 CH C961 87-010-378-040 CAP,E 10-16 C962 87-012-336-080 CAP, CHIP U 330P SL C963 87-010-831-080 C-CAP,U,0.1-16F CN104 87-A60-057-010 CONN,11P V 9604S-11C

CN701 87-099-720-010 CONN,30P TYK-B(P) CN731 87-099-196-010 CONN,8P 6216 V FC731 88-908-301-110 FF-CABLE,8P 1.25 FFC104 88-911-101-110 FF-CABLE,11P 1.25 FL901 8B-NFY-605-010 FL,HNA-08LS02

L951 87-A50-655-010 COIL,CLK 4.19MHZ (TOKO)7KLY LED209 87-A40-317-080 LED,SLR-342VCT31 RED S321 87-A90-164-080 SW,TACT SKQAB(N) S322 87-A90-164-080 SW,TACT SKQAB(N) S323 87-A90-164-080 SW,TACT SKQAB(N)

S324 87-A90-164-080 SW,TACT SKQAB(N) S325 87-A90-164-080 SW,TACT SKQAB(N) S326 87-A90-164-080 SW,TACT SKQAB(N) S327 87-A90-164-080 SW,TACT SKQAB(N) S328 87-A90-164-080 SW,TACT SKQAB(N)

S329 87-A90-164-080 SW,TACT SKQAB(N) S330 87-A90-164-080 SW,TACT SKQAB(N) S331 87-A90-164-080 SW,TACT SKQAB(N) S332 87-A90-164-080 SW,TACT SKQAB(N) S333 87-A90-164-080 SW,TACT SKQAB(N)

S334 87-A90-164-080 SW,TACT SKQAB(N) S341 87-A90-164-080 SW,TACT SKQAB(N) S342 87-A90-164-080 SW,TACT SKQAB(N) S343 87-A90-164-080 SW,TACT SKQAB(N) S344 87-A90-164-080 SW,TACT SKQAB(N)

S345 87-A90-164-080 SW,TACT SKQAB(N) S346 87-A90-164-080 SW,TACT SKQAB(N) S347 87-A90-164-080 SW,TACT SKQAB(N) S348 87-A90-164-080 SW,TACT SKQAB(N) S349 87-A90-164-080 SW,TACT SKQAB(N)

S350 87-A90-095-080 SW,TACT EVQ11G04M<5EZ> S351 87-A90-095-080 SW,TACT EVQ11G04M<5EZ> S352 87-A90-095-080 SW,TACT EVQ11G04M<5EZ> S361 87-A91-633-010 SW,RTRY XRE012103PVB25FINA 1-2 S371 87-A91-632-010 SW,RTRY XRE012103PVB25FINB 1-2

NO.

DESCRIPTIONREF. NO. PART NO. KANRI

PT C.B

C85 87-010-831-080 C-CAP,U,0.1-16<K,EZ,5EZ> CN1 87-A61-110-010 CONN,9P V TID-A<LH,5LH> PT1 8B-NF9-615-010 PT,BNF-9 LH<LH>

PT1 8B-NFY-694-010 PT,BNF-Y EZ<K,EZ,5EZ>

PT1 8B-NFY-693-010 PT,BNF-Y LH<5LH>

PT1 8B-NFY-690-010 PT,BNF-Y U

PT2 8B-MA6-673-010 PT,SUB BMA H (VRK)<LH,5LH>

PT81 8B-MA6-675-010 PT,SUB BMA E (VRK)<K,EZ,5EZ>

PT81 8B-MA3-671-010 PT,SUB BMA U (VRK)

RY1 87-A91-339-010 RELAY,AC DC12V G5PA-2<LH,5LH>

RY81 87-A92-072-010 RELAY,AC DC12V HRM3H-S-1POLE

RY81 87-A91-418-010 RELAY,AC12V G5PA-1-M<K,EZ,5EZ>

S1 87-A90-165-010 SW,SL 1-2-3 SWS2301<LH,5LH>

T1 87-A60-317-010 TERMINAL, 1P MSC<LH,5LH>

T2 87-A60-317-010 TERMINAL, 1P MSC<LH,5LH>

T81 87-A60-317-010 TERMINAL, 1P MSC<K,EZ,5EZ,U>

T82 87-A60-317-010 TERMINAL, 1P MSC<K,EZ,5EZ,U> WH81 87-A90-510-010 HLDR,WIRE 2.5-9P<K,EZ,5EZ,U>

DECK C.B

CN1 87-099-753-010 CONN,11P H 9604 SFR1 87-024-581-010 SFR,3.3K H KVSF637A SOL1 82-ZM3-627-010 SOL ASSY,27 SO SOL1 82-ZM3-634-110 SOL ASSY,27 OM<EXCEPT U> SOL2 82-ZM3-627-010 SOL ASSY,27 SO

SOL2 82-ZM3-634-110 SOL ASSY,27 OM<EXCEPT U> SW1 87-A90-673-010 SW,MICRO ESE11SH1C SW2 87-A90-673-010 SW,MICRO ESE11SH1C SW3 87-A90-673-010 SW,MICRO ESE11SH1C SW4 87-A90-673-010 SW,MICRO ESE11SH1C

SW5 87-A90-673-010 SW,MICRO ESE11SH1C W1 82-ZM3-601-010 RBN-CORD,4P-75

NOTE:

310U = U 310K = K 310EZ = EZ 310LH = LH 315EZ = 5EZ 510LH = 5LH

– 10 –

CHIP RESISTOR PART CODE

Chip Resistor Part Coding

Resistor Code

Chip resistor

Wattage Type Tolerance

1/16W 1005 5% CJ

1/16W

1/10W

1/8W

1608

2125

3216

TRANSISTOR ILLUSTRATION

E C B

CSC4115 CDA1585

CC5551 2SA1981 2SC5343 2SA1980

E C B

Symbol

Figure

Value of resistor

Form

B C E

CSB1370

Dimensions (mm)

0.55

B C E

Resistor Code

108

118

128

LW t

1.0 0.5 0.35 104

1.6 0.8 0.45

2 1.25 0.45

3.2

1.6

2SD2642 2SB1686

: A : A

S D G

2SJ460 2SK2541

2SK360E

G D S

2SK2937

2SA1235 2SC2714 2SC3052

CMBT5401 CMBT5551 CSD1306

DTC114YKA KRA102S KRA107S KRC102S KRC104S KRC107S

2SK2158

– 11 –

WIRING  1 (U, LH : MAIN)

32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 1 1 10 9 8 7 6 5 4 3 2 1

 12 

SCHEMATIC DIAGRAM – 1 (U, LH : MAIN 1 / 2 )

– 13 –

SCHEMATIC DIAGRAM – 2 (U, LH : MAIN 2 / 2 : TUNER)

– 14 –

WIRING  2 (K, EZ : MAIN)

32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 1 1 10 9 8 7 6 5 4 3 2 1

 15 

SCHEMATIC DIAGRAM – 3 (K, EZ : MAIN 1 / 2 )

– 16 –

SCHEMATIC DIAGRAM – 4 (K, EZ : MAIN 2 / 2 : TUNER)

– 17 –

WIRING – 3 (FRONT)

32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1

– 18 –

SCHEMATIC DIAGRAM – 5 (FRONT / DECK)

– 19 –

WIRING  4 (U, K, EZ : PT)

151413121110987654321

 20 

SCHEMATIC DIAGRAM – 6 (U, K, EZ : PT)

– 21 –

WIRING  5 (310LH : PT)

151413121110987654321

 22 

SCHEMATIC DIAGRAM – 7 (310 LH : PT)

– 23 –

WIRING  6 (510LH : PT)

151413121110987654321

 24 

SCHEMATIC DIAGRAM – 8 (510 LH : PT)

– 25 –

WIRING  7 (DECK)

32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1

D DECK C.B

SW5

(CAM2)

SW4

(CST2)

TO FRONT C.B CN104

(FFC104)

11 9 7 5 3 1

10 8 6 4 2

CN1

SW3

(REA)

SW2

(CST1)

SW1

(CAM1)

IC2

SFR1

SOL2

IC1

SOL1

TAPE

MOTOR

 26 

IC BLOCK DIAGRAM

– 27 –

FL (HNA-08LS02) GRID ASSIGNMENT / ANODE CONNECTION

GRID ASSIGNMENT

– 28 –

ANODE CONNECTION

– 29 –

IC DESCRIPTION

IC, µPD780226GF-021-3BA <EXCEPT 315EZ>, IC, µPD780228GF-078-3BA <315EZ>

Pin No.

1 O-MOTOR O DECK MOTOR ON/OFF output. 2 O-SOL1 O DECK1 solenoid ON/OFF output. 3 O-SOL2 O DECK2 solenoid ON/OFF output. 4 O-STBY O STANDBY LED (Echo mode) output (ON/OFF). 5 NC – Not connected. 6 O-PB1 O DECK1 playback switch output (ON/OFF). 7 NC – Not connected. 8 NC – Not connected.

9 NC – Not connected. 10 NC – Not connected. 11 O-TU_ON O TUNER ON/OFF switch output. 12 O-MUTE O System MUTE ON/OFF output. 13 O-KSCAN O Switch SCAN timing output. 14 O-BIAS O DECK2 BIAS ON/OFF output. 15 O-RMT/STB(M) O DECK2 REC MUTE ON/OFF output. 16 NC – Not connected. 17 IC – Internal connection (connected to GND). 18 VSS0 – GND. 19 VDD0 – Power supply. 20 O-POWER O System power supply ON/OFF output. 21 NC – Not connected. 22 NC – Not connected. 23 NC – Not connected. 24 I-SUBQ I CD SUBQ data input. 25 I-WRQ I CD interrupt signal input. 26 I-DRF I CD focus ON detect data input. 27 I-REA I DECK2 sideA record OK switch data input. 28 I-RDS_CLK I Tuner RDS clock input <315EZ only>. 29 I-RDS_DATA I Tuner RDS data input <315EZ only>. 30 RESET – System reset input (ON/OFF). 31 O-DSC/O-DATA O Function IC/Tuner IC, DATA output. 32 O-CLK_SFT O MICON clock shift output. 33 I-IFC I Tune IF count serial data input. 34 I-RMC I System remote control signal input. 35 I-DISH I CD turntable photo sensor input A/D converter input. 36 I-STEREO I Tuner STEREO detect input. 37 VDD1 – Power supply. 38 X2 – 4.19MHz oscillator circuit. 39 X1 – 4.19MHz oscillator circuit. 40 VSS1 – GND. 41 AVDD – Power supply. 42 I-HOLD I Power failure detected input. 43 I-CDSW I CD mecha switch A/D converter input.

Pin Name I/O Description

– 30 –

Pin No.

44 I-SPEANA_1 I A/D input for spectrum analyser level display. 45 I-SPEANA_2 I A/D input for spectrum analyser level display. 46 I-KEY1 I Key A/D input 1. 47 I-KEY2 I Key A/D input 2. 48 I-SPEANA_3 I A/D input for spectrum analyser level display. 49 I-TU_SIG I Tuner signal input <315EZ only>. 50 AVSS – GND. 51 O-PLL_CLK O PLL IC clock enable output. 52 O-PLL_CE O PLL IC chip enable output.

53, 54 P1, P2 O FL segment P1, P2 output.

55 O-CD_CLK O CD clock output. 56 O-CD_DATA/O-SD O CD data output. 57 O-CD_CE O CD chip enable output. 58 P3 O FL segment P3 output. 59 I-JOG_B I Dial jog rotary encoder input B. 60 I-JOG_A I Dial jog rotary encoder input A. 61 I-VOL_B I Volume rotary encoder input B. 62 I-VOL_A I Volume rotary encoder input A. 63 P4 O FL segment P4 output. 64 I-TM_BASE I Base input for clock. 65 P5/I-CAM2 O/I FL segment P5 output / DECK2 CAM switch data input. 66 P6/I-CAM1 O/I FL segment P6 output / DECK1 CAM switch data input. 67 P7/I-AUTO2 O/I FL segment P7 output / DECK2 AUTO STOP switch data input. 68 P8/I-AUTO1 O/I FL segment P8 output / DECK1 AUTO STOP switch data input. 69 P9/I-CST2 O/I FL segment P9 output / DECK2 cassette detect switch data input. 70 P10/I-CST1 O/I FL segment P10 output / DECK1 cassette detect switch data input. 71 P11/AM10K O/I FL segment P11 output / AM10K input to diode <LH, U only>. 72 P12 O FL segment P12 output. 73 P13/LW O/I FL segment P13 output / LW input to diode <K, EZ only>.

74, 75 P14, P15 O FL segment P14, P15 output.

76 P16/RDS O/I FL segment P16 output / RDS input to diode <315EZ only>.

77, 78 P17, P18 O FL segment P17, P18 output.

79 VDD2 – Power supply. 80 VLOAD – Power supply for FL display. 81 P19/C-JACK O/I FL segment P19 output / C-JACK data input <LH only>. 82 P20/ECO-OFF O/I FL segment P20 output / ECO-OFF data input <LH only>.

83 ~ 92 P21 ~ P30 O FL segment P21 ~ P30 output.

93 ~ 100 G1 ~ G8 O FL grid G1 ~ G8 output.

Pin Name I/O Description

– 31 –

ADJUSTMENT (TUNER / DECK / FRONT)

< TUNER SECTION > <U, LH>

1. Clock Frequency Check Settings : • Test point : TP2 (CLK) Method : Set to AM 1710kHz and check that the test point is

2160kHz ± 45Hz.

2. AM VT Check Settings : • Test point : TP1 (VT) Method : Set to AM 1710kHz and check that the test point is

less than 8.5V. Then set to AM 530kHz and check that the test point is more than 0.6V.

3. AM Tracking Adjustment Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Adjustment location : L951 (1/3)

Method : Set to AM 1000kHz and adjust L951 (1/3) so that the

test point becomes maximum.

7. DC Balance / Mono Distortion Adjustment Settings : • Test point : TP3, TP4 (DC balance)

TP8 (Lch), TP9 (Rch) (Mono Distortion)

• Adjustment location :L801

• Input level : 60dBµV

Method : Set to FM 98.0MHz and adjust L801 so that the

distortion is less than 1.2%. Then check the voltage between TP3 and TP4 is 0V ± 500mV.

8. Output Level Check <AM> Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Input level : 74dBµV

Method : Set to AM 1000kHz and check that the test point is

40mV ± 3dB.

4. AM IF Adjustment Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Adjustment location :

L802 ........................... 450kHz

5. FM VT Adjustment. Settings : • Test point : TP1 (VT)

• Adjustment location : L906

Method : Set to FM 108.0MHz and adjust L906 so that the

test point bcomes 7.0V ± 0.1V. Then set to FM

87.5MHz and check that the test point is more than

0.4V.

6. FM Tracking Adjustment Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Adjustment location : L903

Method : Set to FM 87.5MHz and adjust L903 so that the

test point is less than 9dBµV.

<FM> Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Input level : 60dBµV

Method : Set to FM 98.0MHz and check that the test point is

200mV ± 3dB.

9. FM Separation Check Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Input level : 60dBµV

Method : Set to FM 98.0MHz and check that the test point is

more than 25dB.

– 32 –

< TUNER SECTION > <EZ, K>

1. Clock Frequency Check Settings : • Test point : TP2 (CLK) Method : Set to MW 1602kHz and check that the test point is

2052kHz ± 45Hz.

8. FM Tracking Check Settings : • Test point : TP8 (Lch), TP9 (Rch) Method : Set to FM 98.0MHz and check that the test point is

less than 13dBµV.

2. MW VT Check Settings : • Test point : TP1 (VT) Method : Set to MW 1602kHz and check that the test point is

less than 8.0V. Then set to MW 531kHz and check that the test point is more than 0.6V.

3. MW Tracking Adjustment Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Adjustment location : L951 (1/3)

Method : Set to MW 999kHz and adjust L951 (1/3) so that the

test point becomes maximum.

4. LW VT Adjustment Settings : • Test point : TP1 (VT)

• Adjustment location : L942

Method : Set to LW 144kHz and adjust L942 so that the test

point becomes 1.3V ± 0.05V. Then set to LW 290kHz and check that the test point is less than 8.0V.

5. LW Tracking Adjustment Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Adjustment location :

L941 ........................... 144kHz

TC942......................... 290kHz

Method : Set up TC942 to center before adjustment. The level at

144kHz is adjusted to MAX by L941. Then the level at 290kHz is adjusted to MAX by TC942.

9. DC Balance / Mono Distortion Adjustment Settings : • Test point : TP3, TP4 (DC balance)

TP8 (Lch), TP9 (Rch) (Mono Distortion)

• Adjustment location :L801

• Input level : 60dBµV

Method : Set to FM 98.0MHz and adjust L801 so that the

distortion is less than 1.2%. Then check the voltage between TP3 and TP4 is 0V ± 500mV.

10. Output Level Check <MW> Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Input level : 74dBµV

Method : Set to MW 999kHz and check that the test point is

40mV ± 3dB.

<FM> Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Input level : 60dBµV

Method : Set to FM 98.0MHz and check that the test point is

140mV ± 3dB.

11. FM Separation Check Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Input level : 60dBµV

Method : Set to FM 98.0MHz and check that the test point is

more than 12dB.

6. AM IF Adjustment Settings : • Test point : TP8 (Lch), TP9 (Rch)

• Adjustment location :

L802 ........................... 450kHz

7. FM VT Check Settings : • Test point : TP1 (VT) Method : Set to FM 108.0MHz and check that the test

point is less than 8.0V. Then set to FM

87.5MHz and check that the test point is more than

0.5V.

– 33 –

< DECK SECTION >

1. Tape Speed Adjustment (DECK 2) Settings : • Test tape : TTA–100

• Test point : TP8(Lch), TP9(Rch)

• Adjustment location : SFR1

Method : Play back the test tape and adjust SFR1 so that the

frequency counter reads 3000 Hz ± 5 Hz (FWD) and FWD speed ± 45 Hz (REV) with respect to forward speed.

2. Head Azimuth Adjustment (DECK 1, DECK 2) Settings : • Test tape : TTA–330

• Test point : TP8(Lch), TP9(Rch)

• Adjustment location : Head azimuth adjustment screw

Method : Play back (FWD) the 8 kHz signal of the test tape and

adjust screw so that the output becomes maximum. Next, perform on REV PLAY mode.

3. PB Frequency Response Check (DECK 1, DECK 2) Settings : • Test tape : TTA–330

• Test point : TP8(Lch), TP9(Rch)

Method : Play back the 315 Hz and 8 kHz signals of the test tape

and check that the output ratio of the 8 kHz signal with respect to that of the 315 Hz signal is 0 dB ± 5 dB.

4. PB Sensitivity Check (DECK 1, DECK 2) Settings : • Test tape : TTA–200

• Test point : TP8(Lch), TP9(Rch)

Method : Play back the test tape and check that the output level

of the test point is 110 mV ± 3 dB.

6. REC/PB Sensitivity Check (DECK 2) Settings : • Test tape : TTA–602

• Test point : TP8(Lch), TP9(Rch)

• Input signal : 1 kHz (LINE IN) (0VU)

Method : Apply a 1 kHz signal and REC mode. Then adjust

OSC attenuator so that the output level at TP8, TP9 becomes 0 dB (100 mV). Record and play back the 1 kHz signals and check that the output is

-1 dB ± 3.5 dB.

< FRONT SECTION >

7. µ-CON OSC Adjustment Settings : • Test point : TP10 (K-SCAN)

TP11 (GND)

• Adjustment location : L951

Method : Insert AC plug while pressing POWER key and TUNER

BAND key. Connect a frequency counter across TP10 and TP11. Then adjust L951 so that the frequency at the test point is 112.88 Hz ± 0.11 Hz.

5. REC/PB Frequency Response Adjustment (DECK 2) Settings : • Test tape : TTA–602

• Test point : TP8(Lch), TP9(Rch)

• Input signal : 1 kHz / 8 kHz (LINE IN) (-20VU)

• Adjustment location : SFR451 (Lch) SFR452 (Rch)

Method : Apply a 1 kHz signal and REC mode. Then adjust

OSC attenuator so that the output level at the TP8, TP9 becomes 0 dB (10 mV). Record and play back the 1 kHz and 8 kHz signals and adjust SFRs so that the output of the 8 kHz signals becomes 0 dB ± 1 dB with respect to that of the 1 kHz signal.

– 34 –

CD TEST MODE

1. How to Start the CD Test Mode

While pressing the FUNCTION button, insert the AC plug to the power outlet. When the test mode is started, the message [CD TEST] is displayed.

2. How to Exit the CD Test Mode

Press the POWER button or disconnect the AC plug.

* When any key other than PLAY is pressed during play mode, the machine exits the test mode.

3. Function Descriptions and Application of the CD Test Mode

Mode

Start mode

mode

Play mode

Traverse

mode

Sled mode

Spindle

mode

Operation

STOP

button

Play button

PAUSE

button

FF button

RWD button

REC/REC

MUTE button

Display

All indicators light

READING

Normal

CD TEST

All indicators light

Function

• All FL indicators light

• LD illuminates all the time

• Focus search continuous operations *1

• Spindle motor continuous kick

• Normal playback

• If TOC cannot be read, focus search is continued

• Tracking servo OFF/ON

• Each time PAUSE button is pressed, the tracking servo repeats turning OFF/ON

• Pickup moves to the inner circumference *2 At the same time, lens kicks to the inner circumference

• Pickup moves to the outer circumference *2 At the same time, lens kicks to the outer circumference

• The spindle motor rotates forward (rough speed) by pressing the button and rotates backward by pressing one more time and stops by pressing again

Checking item

• FL check

• Microprocessor check

• APC circuit check

• Laser current measurement

• Focus search waveform check

• Focus error waveform check (DRF in the search mode is ignored)

• Each servo circuit is checked

• DRF check

• Tracking balance check

• Sled circuit check

• Tracking circuit check

• Mechanism operation check

• Pickup check

• Spindle circuit

• Spindle motor

*1: The driver IC heats up and the protection circuit starts working when the focus search is continued for 10 minutes or longer.

There can be a case that operations cannot be performed correctly. In such a case, turn off the main power. After cooling down the machine, restart the machine.

*2: Be careful not to damage the gear because the sled motor rotates while the FF or RWD button is being pressed even if the

pick-up is located in the innermost track or the outermost track.

– 35 –

MECHANICAL EXPLODED VIEW 1 / 1

BZG-5

PWB

HT-SINK ASSY S

315 EZ

PLATE,EARTH MECHA

310 K, 310 EZ, 315 EZ

HT-SINK MAIN 60S

CHAS,MAIN

EXCEPT

510 LH

WIRE, BINDER

ZZM-3

– 36 –

MECHANICAL PARTS LIST 1 / 1

PART NO. DESCRIPTIONREF. NO. KANRI

NO.

1 8B-NFY-008-010 WINDOW,CASS 2 2 8B-NFY-007-010 WINDOW,CASS 1 3 8B-NFY-004-010 BOX,CASS 2 4 8B-NFY-003-010 BOX,CASS 1 5 8A-NF8-281-010 SPR-T,EJECT 1

6 8A-NF8-282-010 SPR-T,EJECT 2 7 8B-NFY-005-010 WINDOW,DISP U 8 8B-NFY-006-010 PANEL,FR<310U> 8 8B-NFY-038-010 PANEL,FR 510<510LH> 8 8B-NFY-021-010 PANEL,FR E RDS<315EZ>

8 8B-NFY-023-010 PANEL,FR HR<310LH,310K,310EZ> 9 8B-NFY-014-010 KNOB,RTRY JOG 10 8B-NFY-015-010 KNOB,RTRY VOL 11 8Z-NF6-210-010 DMPR,150 N 12 8B-NFY-022-010 CABI,FR EZ RDS<315EZ>

12 8B-NFY-019-010 CABI,FR LH<EXCEPT 315EZ,310U> 12 8B-NFY-001-010 CABI,FR U<310U> 13 8B-NFY-012-010 KEY,FUN 14 8B-NFY-036-010 REFLECTOR,ECO 15 8B-NFY-010-010 KEY,OPE 1W

16 8B-NFY-013-010 KEY,GEQ 17 8B-NF9-026-010 PANEL,LEFT 18 8B-NF9-027-010 PANEL,TOP 19 8B-NFY-201-010 GUIDE,FL 100-40 BNFY 20 88-911-101-110 FF-CABLE,11P 1.25

21 88-908-301-110 FF-CABLE,8P 1.25 22 8A-NF8-206-010 HLDR,PWB M 23 87-NF4-216-010 HLDR,LOCK 1 24 86-NF9-224-010 SPR-C,LOCK 25 82-NF5-229-010 PLATE,LOCK

DESCRIPTIONREF. NO. KANRI

PART NO.

26 87-NF4-217-110 HLDR,LOCK 2 27 8B-NFY-002-010 PANEL,TRAY 28 8B-NFY-017-110 PANEL,CD 29 87-CE3-023-010 BADGE,AIWA 30N SILV 30 87-NF4-221-010 HLDR,CABLE

31 8A-NF9-211-010 HLDR,PWB PT HI<EXCEPT 510LH> 31 8A-NF7-225-010 HLDR,PWB PT 85S<510LH>

32 87-A80-157-010 AC CORD ASSY,E BLK CC<EXCEPT 310U>

32 87-A80-149-010 AC CORD ASSY,U BLK<310U> 33 87-085-185-010 BUSHING, AC CORD (E)<EXCEPT 310U>

33 87-A91-422-010 BUSHING,AC CORD(U)<310U> 34 8B-NF9-025-010 PANEL,RIGHT 35 8B-NFY-059-010 CABI,REAR EZSFD<310EZ> 35 8B-NFY-061-010 CABI,REAR EZSFD RDS<315EZ> 35 8B-NFY-058-010 CABI,REAR KSFD<310K>

35 8B-NFY-057-010 CABI,REAR LHSFD<310LH> 35 8B-NFY-060-010 CABI,REAR LHSFD 510<510LH> 35 8B-NFY-048-010 CABI,REAR USM<310U> 36 88-906-251-110 FF-CABLE,6P 1.25(RVS-FACE) 37 8B-NF9-211-010 HLDR,TR S

38 8B-NFY-018-010 KEY,RDS<315EZ> A 87-067-703-010 TAPPING SCREW, BVT2+3-10 B 87-NF4-224-010 S-SCREW,IT3B+3-8 CU C 87-078-200-010 S-SCREW,ITC+4-8 R D 87-067-689-010 TAPPING SCREW, BVTT+3-8

E 87-723-096-410 QT2+3-10W/O SLOT BL F 87-721-097-410 QT2+3-12 GLD G 87-067-641-010 UTT2+3-8(W/O SLOT)BL H 87-721-096-410 QT2+3-10 GLD I 87-067-584-010 BVT2+3-6 W/O SLOT<EXCEPT 510LH>

NO.

COLOR NAME TABLE

Basic color symbol Color Basic color symbol Color Basic color symbol Color

B Black C Cream D Orange

G Green H Gray L Blue

LT Transparent Blue N Gold P Pink

R Red S Silver ST Titan Silver T Brown V Violet W White

WT Transparent White Y Yellow YT Transparent Yellow

LM Metallic Blue LL Light Blue GT Transparent Green LD Dark Blue DT Transparent Orange GM Metallic Green

YM Metallic Yellow DM Metallic Orange PT Transparent Pink

LA Aqua Blue GL Light Green HT Transparent Gray

– 37 –

TAPE MECHANISM EXPLODED VIEW 1 / 1

TERMINAL, LB1

30 21

25 24

43 42

46 47

TERMINAL,LB1

IC, EW732

PWB

IC, EW732

– 38 –

TAPE MECHANISM PARTS LIST 1 / 1

PART NO. DESCRIPTIONREF. NO. KANRI

NO.

1 8Z-ZM3-227-010 BELT,MAIN M3 2 8Z-ZM3-235-010 BELT,MAIN L 3 8Z-ZM1-235-010 PULLEY,MOT 4 87-045-347-010 MOT,SHU2L 70 5 8Z-ZM1-232-010 GEAR,IDL FF/REW

6 8Z-ZM3-244-010 GEAR,CAM TD20 7 8Z-ZM3-256-010 FLY-WHL ASSY,M3 R 8 8Z-ZM3-255-010 FLY-WHL ASSY,M3 L 9 8Z-ZM3-231-010 SPR-T,TRIG 10 8Z-ZM3-213-010 CLR,MG

11 82-ZM3-616-010 RING MAGNET 4 12 8Z-ZM3-243-010 LEVER ASSY,HD UP 13 8Z-ZM3-238-010 SPR-T,HD UP 14 8Z-ZM3-219-010 GEAR,CAM M3 15 8Z-ZM3-206-010 LEVER,TRIG

16 8Z-ZM3-209-010 LEVER,CAM FR 17 8Z-ZM3-203-010 CHAS ASSY,M3 18 8Z-ZM1-228-010 GEAR,SLIP T-UP B 19 8Z-ZM1-265-010 FELT,T-UP 20 8Z-ZM1-227-010 GEAR,SLIP T-UP A

21 8Z-ZM1-251-110 SPR-C,T-UP SLIP 22 8Z-ZM1-275-010 W-L,1,47-4-0.25 23 8Z-ZM1-257-010 SPR-C,F/R 24 8Z-ZM1-236-010 CLR,SLIP FF/REW 25 8Z-ZM3-226-010 SPR-C,FR M3

26 8Z-ZM3-250-010 GEAR,SLIP F/R A M3 27 8Z-ZM1-269-010 FELT,FF/REW 2 28 8Z-ZM1-238-110 GEAR,SLIP FF/REW B 2 29 8Z-ZM3-220-010 LEVER,FR M3 30 8Z-ZM3-205-010 LEVER,PLAY M3

DESCRIPTIONREF. NO. KANRI

PART NO.

NO.

31 8Z-ZM3-233-010 SPR-T,BRG M3 32 84-ZM2-227-310 SPR-C,AZIMUTH 33 87-A90-403-110 HEAD,RPH MS15R 34 87-A90-404-010 HEAD,EH LE15B 35 8Z-ZM3-239-010 SPR-E,FR

36 8Z-ZM3-211-010 LEVER,EJECT R 37 8Z-ZM3-225-010 LEVER,STOP 38 8Z-ZM3-221-010 LEVER,CAS 39 8Z-ZM3-234-010 SPR-T,LVR CAS 40 8Z-ZM3-223-010 SPR-C,REEL R M3

41 8Z-ZM1-225-110 GEAR,REEL R 42 8Z-ZM3-240-010 SPR-T,T-UP M3 43 8Z-ZM3-237-010 SPR-T,PINCH M3 44 8Z-ZM3-215-010 LEVER,PINCH M3 45 8Z-ZM1-261-110 ROLLER ASSY,PINCH

46 8Z-ZM1-226-010 GEAR,REEL L 47 8Z-ZM3-222-010 SPR-C,REEL L M3 48 8Z-ZM3-251-010 GEAR,IDL REW M3 49 8Z-ZM3-236-010 SPR-T,PLAY M3 50 82-ZM1-240-110 LVR,REC(*)

51 8Z-ZM3-216-010 LEVER,T-UP M3 52 87-B10-301-010 W-L,1.63-3.2-05 SLIT 53 8Z-ZM3-212-010 LEVER,EJECT L 54 8Z-ZM3-214-010 HLDR,IC 55 86-ZM3-605-110 CONN ASSY,8P -RPB

A 84-ZM2-242-010 S-SCREW,AZ1-2-6.4 B 8Z-ZM2-220-110 V+2.6 ZZM-2

– 39 –

GENERAL SPEAKER DISASSEMBLY INSTRUCTIONS (FOR REFERENCE)

Type.1

Insert a flat-bladed screwdriver into the position indicated by the arrows and remove the panel. Remove the screws of each speaker unit and then remove the speaker units.

Type.2

Remove the grill frame and four pieces of rubber caps by pulling out with a flat-bladed screwdriver. Remove the screws from hole where installed rubber caps. Insert a flat-bladed screwdriver into the position indicated by the arrows and remove the panel. Remove the screws of each speaker unit and then remove the speaker units.

Type.4

TOOLS

1 Plastic head hammer 2 (() flat head screwdriver 3 Cut chisel

12 3

How to Remove the PANEL, FR

1. Insert the (() flat head screwdriver tip into the gap

between the PANEL, FR and the PANEL, SPKR. Tap the head of the (() flat head screwdriver with the plastic hammer head, and create the clearance as shown in Fig-1.

2. Insert the cut chisel in the clearance, and tap the head of the cut chisel with plastic hammer as shown in Fig-2, to remove the PANEL, FR.

Type.3

Insert a flat-bladed screwdriver into the position indicated by the arrows and remove the panel. Turn the speaker unit to counterclockwise direction while inserting a flat-bladed screwdriver into one of the hollows around speaker unit, and then remove the speaker unit. After replacing the speaker unit, install it turning to clockwise direction until "click" sound comes out.

3. Place the speaker horizontally. Tap head of the cut chisel with plastic hammer as shown in Fig-3, and remove the PANEL, FR completely.

Fig-1 Fig-2

How to Attach the PANEL, FR

Attach the PANEL, FR to the PANEL, SPKR. Tap the four corners of the PANEL, FR with the plastic hammer to fit the PANEL, FR into the PANEL, SPKR completely.

– 40 –

Fig-3

SPEAKER PARTS LIST <SX-NAJ312 (YUS1N, YUSN) / SX-NSZ312 (YLSC, YSC)>

PART NO.

NO.

1 8B-NSY-001-010 PANEL,FR 2 8B-NSY-003-010 PANEL,TW 3 8B-NSY-009-010 PROTECTOR,TW 4 8B-NSY-010-010 SPKR,CERAMIC ASSY 5 8B-NSY-005-010 GRILLE,FRAME ASSY

6 8B-NSY-602-010 SPKR,W 140/30<YLSC,YUS1N,YUSN> 6 8B-NSY-604-010 SPKR,W 140/25<YSC> 7 8B-NSK-604-010 SPKR,T 60<YLSC,YUS1N,YUSN> 7 8B-NSY-606-010 SPKR,TW 60L<YSC> 8 8B-NSY-610-010 CORD,SPKR

DESCRIPTIONREF. NO. KANRI

SPEAKER PARTS LIST <SX-NSZ702 (YLSC)>

PART NO.

NO.

1 8B-NSJ-001-010 PANEL,FR 2 8B-NSJ-003-010 PANEL,DUCT 3 8B-NSJ-004-010 PROTECTOR 4 8A-NSJ-006-010 BADGE,AIWA S35 5 8B-NSJ-606-010 SPKR,W 160 35/4

6 8B-NSJ-604-010 SPKR,TW 60 7 8B-NSJ-612-010 CORD,SPKR

DESCRIPTIONREF. NO. KANRI

ACCESSORIES / PACKAGE LIST

PART NO.

1 8B-NFY-913-010 IB,U (ESF) M<310U> 1 8B-NFY-922-010 IB,LH (ESP) IN<310LH,510LH> 1 8B-NFY-925-010 IB,K (E) IN<310K> 1 8B-NFY-936-010 IB,EZ (9L) IN-SZ315(RDS)<315EZ> 1 8B-NFY-937-010 IB,EZ (9L) IN<310EZ>

2 87-A90-118-010 ANT,WIRE FM(Z)<310K,310EZ,315EZ> 2 87-043-115-010 FEEDER-ANT,FM<310U,310LH,510LH> 3 87-A92-150-010 ANT,LOOP AM NO-CONT 4 8Z-NF9-702-010 RC UNIT,ZAS02 5 87-A91-017-010 PLUG,CONVERSION JT-0476<310LH,510LH>

6 87-099-811-010 PLUG,ADPTR CONV (K)<310K>

NO.

DESCRIPTIONREF. NO. KANRI

– 41 –

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111

Printed in Singapore9301978 2000041 0251431

Aiwa NSXAJ-310, NSXSZ-310, NSXSZ-315, NSXSZ-510 Service manual

Specifications and Main Features

Frequently Asked Questions

User Manual
