AIRO MIRO 9 User Manual
MIRO, Marine Intelligence Robot
USER’S MANUAL for
http://www.airo.kr
Table of Content
1. Important Safety Information
2. MIRO & Accessories
3. MIRO Anatomy
4. Basic Operating Instructions
5. MIRO App
6. Product Specifications
7. Customer Care
• To reduce the risk of injury or damage, keep these safety precautions in mind when setting up, using
and maintaining your robot.
• Read all safety and operating instructions before operating your robot.
• Retain the safety and operating instructions for future reference.
• Follow all operating and use instructions.
http://www.airo.kr
1. Important Safety Information
1
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the robot. Cleaning and maintenance shall not be
performed by children.
• Do not drop your robot on the solid ground or do not place anything on top of your robot, which may cause a crack
inside product to lead to water leakage inside of it.
• Stop operating robot and contact your seller in case it is exposed to hazardous materials or liquids, or smokes.
• Be careful not to put your fingers or other materials between joints of robot in operation. Do not try to physically stop
robot’s wagging or reverse the direction of joint in operation.
• Do not handle the (metal) plug socket of a charging stand with wet hands.
• Do not heat or place the robot near any heat source, which can cause explosion of the battery inside, and/or
deformation or disorder of robot.
• Do not drill a hole or bore through the main body inside ornamental skins. It can seriously defect waterproof function of
robot.
• Do not place robot near magnet or magnetic field.
• MIRO is designed to operate in normal fresh water environment. To operate MIRO in salt water will immediately void the
warranty.
• Ornamental skins on the product are consumable. Under normal usage, they can be worn and torn, which does not
mean a defect of robot. You can contact your seller to purchase new skins.
http://www.airo.kr
2. MIRO & Accessories
MIRO (1ea)
Charging stand for MIRO (1ea)
Weight (1~2 ea)
Router and charger (1ea) L Wrench(2mm, 1 ea) User Manual
2http://www.airo.kr
3. MIRO Anatomy
Main Body
1stJoint
2ndJoint
Power
On/Off
Eyeball
(LED)
Pointer
(LED)
Sensors for
Obstacle
Detection
Electronic Air Bladder
Charging Port
* LED : Light Emitting Diode
Eyeball
(LED)
Pointer
(LED)
Sensor
(Middle)
Sensor
(right)
Sensor
(left)
Four Sensors for Obstacle Detection
Sensor
(bottom)
http://www.airo.kr 3
POWER ON (ㅡ)
POWER OFF (ㅣ)
1. Before turning power on, be sure to grip robot tightly, otherwise it might fall down onto ground.
2. Turn on power switch clockwise 90˚. When power is on, the robot will start operating in 3 seconds.
3. If the eyeball LEDs are on and off(flickering), then the robot is ready to use.
4http://www.airo.kr
4. Basic Operating Instructions
Power On/Off
Eyeball
(LED)
