SPECIFICATIONS
FAS
by
FRESH AIR SUPPLY FAN
120 CFM @ 0.20" SP., 30.1 Watts
110 CFM @ 0.20" SP., 27.5 Watts
100 CFM @ 0.20" SP., 26.3 Watts
90 CFM @ 0.20" SP., 21.8 Watts
80 CFM @ 0.20" SP., 19.5 Watts
• Blower Wheel
Balanced polymeric dual inlet blower wheel secured in place using a hex nut.
• Adjustable Capacity Motor
9 capacity settings allow the fan to be set to the required intake. Set
points include: 40 50 60 70 80 90 100 110 120 CFM
4 Pole motor, permanently lubricated, thermally protected
115/120V 60 Hz., 0.30 amps.
• Fan Housing
Insulated 26 gauge baked epoxy housing. Overall dimensions:
7
14
/8"H x 111/2"D x 101/8"W.
• Duct Collars
6" round, zinc plated metal collar adapters.
• Electrical Connections
0.5" electrical access. Easy wiring access via external wiring
compartment cover or internal access plate.
• Unit Mounting
Designed to surface mount to a wall or ceiling with the included mounting
brackets. Can be mounted onto joists, studs or the housing mounting
brackets can be adapted for overhead mounting (hardware not provided).
11
70 CFM @ 0.20" SP., 17.1 Watts
60 CFM @ 0.20" SP., 15.1 Watts
50 CFM @ 0.20" SP., 14.5 Watts
40 CFM @ 0.20" SP., 12.9 Watts
7
/
14
"
1
/
10
"
8
1
/
"
2
6"
1
/
9
2
8
"
6"
• Single Pack Shipping Info
Box Dim: 23" x 157/8" x 123/4"
Shipping Weight: 18.0 lbs.
• Optional Air Filter
An optional 10" x 10" x 2" air filter can be added to the unit (not included).
12"
• Test Port
Allows easy air flow measurement with Pitot tube or similar device.
SEE REVERSE SIDE FOR STATIC PRESSURE RANGES
