Aiphone GTW-LC User Manual

GTW-LC

SERVICE MANUAL

GT System Lift control adaptor

0311 A OI

GTW-LC

INSTALLATION & OPERATION MANUAL

PRECAUTIONS

General Prohibitions

Prohibition on Subjecting the Unit to Water

(Negligence could result in death or serious injury.)

1. Do not dismantle or alter the unit. Fire or electric shock could result.

2. The unit must be installed and wired by a qualiﬁed technician.

3. Do not connect any non-speciﬁed power source to the +, - terminals, and do not install two power supplies in parallel to a single input. Fire, damage to the unit, or system malfunction could result.

4. Keep the unit away from water or any other liquid. Fire or electric shock could result.

5. Do not connect any terminal on the unit to AC power lines. Fire or electric shock could result.

6. Do not put any metal or ﬂammable material into the unit through the openings. Fire, electric shock, or unit trouble could result.

7. Do not install or make any wire terminations while the lift or any other systems are powered on. It can cause electrical shock, damage, or malfunction to the other systems.

8. When checking the operation of the lift or other systems, ensure the safety of others in the surrounding area before starting. Failure to do so could cause an accident.

(Negligence could result in injury to people or damage to

1. Do not install or make any wire terminations while power supply is plugged in. It can cause electrical shock or damage to the unit.

2. Before turning on power, make sure wires are not crossed or shorted. Fire or electric shock could result.

3. Do not put anything on or cover the unit with cloth, etc. Fire or unit trouble could result.

4. For DC powered systems, use Aiphone power supply model speciﬁed with system. If non-speciﬁed product is used, ﬁre or malfunction could result.

5. Do not install the unit in any of the following locations. Fire, electric shock, or unit trouble could result.

* Places under direct sunlight, or near heating equipment that varies in temperature. * Places subject to dust, oil, chemicals, hydrogen sulﬁde (hot spring). * Places subject to moisture and humidity extremes, such as bathroom, cellar, green-

house, etc.

* Places where the temperature is qu

of air-conditioner.

* Places subject to steam or smoke (near heating or cooking surfaces). * Where noise generating devices such as dimmer switches, invertor electrical appli-

ances, are closeby.

6. When mounting the unit on wall, install the unit in a convenient location, but not where it could be jarred or bumped. Injury could result.

7. Do not place (install) the unit in locations subject to frequent vibration or impact. Injury or damage could result if the unit falls.

Prohibition to Dismantle the Unit

General Precautions

WARNING

CAUTION

property.)

ite low, such as inside a refrigerated area or in front

CONTENTS

1 SYSTEMCONFIGURATION

System Conguration �� 3 Wiring Distance �� 3

2 CONTENTS

Contents �� 4

3 NAMES

Names�� 4

4 MOUNTING

Mounting �� 5

5 WIRING

Wiring �� 6

6 SETTINGUP

Setup tool �� 8 Lift Control 1 �� 9 Lift Control 2 �� 9 Data transfer �� 9 Combine Data�� 10

7 OPERATIONS

Residential Station or Security Guard Station Door Release �� 10 Automatic Entry (Doctor Call) Option �� 10

8 TECHNICALPRECAUTIONS

Technical precautions �� 11

9 SPECIFICATIONS

Specications �� 11

GENERAL PRECAUTIONS

1. This unit is for indoor use only. Do not use outdoors.

2. As to other systems used with this device, such as the lift, comply with the Manufacturer’s Speciﬁcations and Warranty conditions.

3. The unit turns inoperative during power failure.

. Keep the intercom wires more than 30 cm (12 inches) away from AC 100-240 V lines,

particularly AC lines for invertor electrical appliances. Noise and malfunction could result.

- 2 -

1-1

SYSTEM CONFIGURATION

#16

GTW-LC

[3]

GTW-LC[3]

Max. 8

[6]

[7]

1-1

System Conﬁguration

a. GT expanded system (For details, see the GT Series Installation & Op-

eration Manual.)

Make sure to use GT-BCX, GT-DA(-L), GT-NS(-V), GT-DM(V). [1] Expanded Bus control unit GT-BCX [2] Distribution terminal (junction): Not included [3] Lift control adaptor GTW-LC Relay contacts: 20 [4] Bus control unit GT-BC [5] Power supply PS-2420DIN etc. [6] Lift controller (made by other manufacturer) [7] Lift (made by other manufacturer) [8] Entrance station (digital name scrolling type): Audio only o

video

Do not use direct selection GT-SW.

Capacity

Lift control adaptor Maximum 16 adaptors (up to 8 adaptors per trunk)

* Capacity of other units conform to the expanded system.

r Audio/

1-2

Wiring Distance

* DP = Distribution Point

0.65 mm

Diameter of wires

(22 AWG)

GT-BCX ~ GTW-LC -

0.8 mm

(20 AWG)

300 m

’

)

(980

1.0 mm

(18 AWG)

[8]

Max. 8

GTW-LC[3]

[4]

[2]

Entrance Station (Unit Type)

GT-BC

Common trunk

PS24

Sub trunk

[5]

[1]

GT-BCX

PS24

GT-BCX ~ GT-BC -

DP ~ GTW-LC -

GT-BC ~ DP -

GT-BC ~ power supply -

Total wiring distance GT-BCX ~ GTW-LC

300 m

’

)

(980

300 m

’

)

(980

5 m

’

)

(16

5 m

’

)

(16

2500 m (8200

’

)

5 m

(16’)

* For other Wiring Distances, see the GT Series Installation & Operation

Manual.

Entrance Station (Integrated Type)

GT Expanded System

- 3 -

Contents

Lift control adaptor GTW-LC (mounting bracket is included)

CONTENTS

GTW-LC

NAMES

[3]

[1]

Names

[1] Bus line terminal [2] ID setting switch [3] Relay output terminal [4] Lock release lever

[2]

[3]

[4]

- 4 -
