Agilent N9360A Technical Overview

Agilent N9360A Mobile Station Tester
Technical Overview
Go/No go multi-format cellular device tester for mobile station service and repair with built-in PC
When your cellular phone repair, manufacturing, or R&D testing needs require cost-effective mobile device parametric and call processing measurements, use the Agilent N9360A mobile station tester.
This low-cost, go/no-go tester provides “just enough” capability to make it easy to evaluate protocol as well as RF transmitter and receiver performance. User-friendly, automated test operations enable phone test by operators with little or no technical expertise. The N9360A is an ideal solution for “quick check” call testing in R&D and basic calibration testing in manufacturing
The lightweight N9360A has an internal PC controller with LAN and GPIB connectivity. Test measurements display on the N9360A screen and can be stored as .csv files in a thumb drive, or printed on an Epson PM-G800 printer. Upgradeable hardware and firmware facilitates adding new wireless technologies to support next generation networks.
The N9360A is designed to help you meet your time-to-market goals, keep production costs low, and provide a platform that can change with the market.
Key Features
Multi-format test
o GSM/GPRS/EGPRS o W-CDMA o HSDPA o Cdma2000® o 1xEV-DO
Quad-band GSM/GPRS/EGPRS
SMS test
W-CDMA Bands I to VI
Twelve traffic-channel test in automatic mode
ACLR and SEM measurement capability
FM (frequency modulation) capability
Receiver sensitivity support in GPRS ETSI A and ETSI B mode
Support for EGPRS SRB loopback BLER
1
1
Avoid testing interference from real networks with a fully automated test system
The Agilent GS-8210 system is a pre-configured test system which combines the N9360A mobile station tester with the N9360A-S01 shield box and Agilent N9360A-W36 GS-8210 multi-format test software - offering a cost effective functional test system designed for cellular phone inspection and repair.
Figure 1. GS-8210 test system with N9360A, shield box, and test software
2
1
Requires N9360AU-100 hardware installed in unit
Technical Specifications
Specifications describe the test set’s warranted performance and are valid over the entire operation and environmental ranges unless otherwise noted.
Supplemental characteristics are intended to provide additional information useful in applying the instrument by giving typical, but non-warranted performance parameters. These characteristics are shown in italics and labeled as typical, or supplemental.
GSM/GPRS/EGPRS
Frequency (MHz) Band Uplink Downlink
GSM850 824 ~ 849 869 ~ 894
( 867 ~ 896)1
GSM900 876 ~ 915 921 ~ 960
(921 ~ 962)1
DCS1800 1710 ~1785 1805 ~ 1880
(1802 ~ 1884)
PCS1900 1850 ~1910 1930 ~ 1990
(1927 ~ 1994)1
W-CDMA/HSDPA
Frequency (MHz) Band Uplink Downlink
Band I 1920 ~ 1980 2110 ~ 2170 Band II 1850 ~ 1910 1930 ~ 1990 Band III 1710 ~ 1785 1805 ~ 1880 Band IV 1710 ~ 1770 2110 ~ 2170 Band V 824 ~ 849 869 ~ 894 Band VI 830 ~ 840 875 ~ 885 Band VIII 880 ~ 915 925 ~ 960 Band IX (Japan) 1749.9 ~ 1784.9 1844.9 ~ 1879.9
cdma2000/1xEV-DO
Frequency (MHz) Band Reverse Forward
Band 0 (Cell US) 815 ~ 849 869 ~ 894 AWS-1 1710 ~ 1755 2110 ~ 2155 Band 1 (PCS US) 1850 ~1910 1930 ~ 1990
887 ~ 889
Band 3 (Cell Japan)
Band 4 (PCS Korea) 1750 ~ 1780 1840 ~ 1870 Band 6 (IMT-2000) 1920 ~ 1980 2110 ~ 2170
893 ~ 901 915 ~ 925
GSM/GPRS/EGPRS
Peak Tx Power Measurement
Range: 20 to +39 dBm Resolution: 0.1 dB Accuracy: ±1.0 dB (25 ±5 °C), typical =
±1.5 dB (0 to 50 °C)
±
832 ~ 834 838 ~ 846 860 ~ 870
0.5
Power Ramp
Range: 20 to +39 dBm Resolution: 0.1 dB Accuracy: ±1.0 dB (25 ±5 °C), ≤ ±1.5 dB (0 to 50 °C) Range for display:
Vertical: 80 dB Horizontal: zoom off 9.25 to +156.25 bits, zoom on 8.00 to
+2.00 bits, +145.00 to +155.00 bits
Frequency Error Measurement
Range: 0 to ±60 kHz Resolution: 1 Hz Accuracy: ± (10 + reference signal) Hz Input level: 5 to +39 dBm
Burst Timing
Range: 20 to +20 deg Resolution: 0.1 deg Accuracy:
1
GSM850, GSM900: ±1.0 deg rms DCS1800, PCS1900: ±1.5 deg rms GSM850, GSM900: ±4.0 deg peak DCS1800, PCS1900: ±6.0 deg peak
Input level: 5 to +39 dBm
Rx Quality
Range: 0 to +7 Resolution: 1
Actual Timing Advance
Range: 0 to +63 bits Resolution: 1 bit
EVM Measurement (EGPRS 8PSK)
Range: 0 to 10% Resolution: 0.01% Residual EVM: 3.8% Input level: 5 to +39 dBm
Origin Offset Measurement (EGPRS 8PSK)
Range: 20 dB Resolution: 0.01 dB Residual EVM: 40 dB Input level: 5 to +39 dBm
Spectrum Monitor
Range: 11 to +39 dBm Span: fc to fc+400 kHz, fc±100 kHz RBW: 10 kHz, 30 kHz Range for display:
Span fc to fc+400 kHz ,level 80; fc±100 kHz, level 80
Accuracy: ±2 dB Resolution: 0.1 dB Noise level: 35 dB (Pin = ±29 dBm)
1
Requires N9360AU-100 hardware installed in unit
3
W-CDMA/HSDPA
Modulated Power Measurement
Range: 0 to +36 dBm; (-30 to +36 dBm)1 Resolution: 0.1 dB
±
±
±
0.4
0.5
0.8
1
1
)1
1
Accuracy: ≤ ±0.7 dB (25 ±5 °C), typical =
±1.0 dB (0 to 50 °C)
Range: 53 to 0.01 dBm; (-60 to -30.01dBm) Resolution: 0.1 dB Accuracy: ±1.0 dB (25 ±5 °C), typical =
±1.5 dB (0 to 50 °C)
Range: 60 to 53.01 dBm; (-70 to -60.01dBm)1 Resolution: 0.1 dB Accuracy: ±1.5 dB (25 ±5 °C), typical =
±2.0 dB (0 to 50 °C)
Frequency Error Measurement
Range: 0 to ±500 Hz Resolution: 0.1 Hz Accuracy: ± (10 + reference signal) Hz Input level: 20 to +36 dBm (30 to +36 dBm)
EVM Measurement
Range: 0 to 20% Resolution: 0.01% Residual EVM: 3.8% Input level: 20 to +36 dBm; ( 30 to +36 dBm
ACLR Measurement
Input level: 5 to +36 dBm Range: 0 to 40 dB (at ±5 MHz), 0 to 48 dB (at ±10 MHz)
(43 dB (at ±5 MHz) and 53 dB (at ±10 MHz))
Resolution: 0.01 dB
SEM Measurement 1
Range: 5 to +36 dBm Margin: > 7.7 dB
OBW Measurement
Input level: 5 to +36 dBm Accuracy: < ±100 kHz Range: 0.00 to 9.99 MHz Resolution: 0.01 MHz
Sensitivity/BER
Input level: 20 to +36 dBm Range:
PN9: 0.00 to 25.00% PN15: 0.00 to 33.33%
Origin Offset Measurement
Range: 10% Resolution: 0.01% Residual EVM: 50% Input level: 20 to +36 dBm
1
Requires N9360AU-100 hardware installed in unit
4
cdma2000/1xEV-DO
Modulated Power Measurement
Range: 53 to +36 dBm; (60 to +36 dBm)1 Resolution: 0.1 dB Accuracy: ±1.0 dB (25 ±5 °C), ≤ ±1.5 dB (0 to 50 °C)
Range: 60 to 53.01 dBm; (70 to 60.01 dBm) Resolution: 0.1 dB Accuracy: ±1.5 dB (25 ±5 °C), ≤ ±2.0 dB (0 to 50 °C)
Frequency Error Measurement
Range: 10 to +10 kHz Resolution: 0.1 Hz Accuracy: ± (30 + reference signal) Hz, Input level: 20 to +36 dBm;
(30 to +36 dBm)1
Origin Offset Measurement
Range: 20% Resolution: 0.01% Input level: 20 to +36 dBm
Time Offset Measurement
Range: 10 to +10 µSec Resolution: 1/8 chip Input level: 20 to +36 dBm
Access Probe Power Measurement
Resolution: 0.01% Input level: 40 to +36 dBm
Code Power Measurement
Accuracy: ±2.0 (0 to 36 dBm), ±4.0 (20 to 0.01 dBm) Resolution: 0.1 dB Input level: 20 to +36 dBm
1
RF Signal Generator for GSM/GPRS/EGPRS
Frequency step (MODEM): 0.1 kHz (Range: carrier < ±200 kHz) Modulation:
GMSK (B.T=0.3), 8PSK, OFF (CW)
Output power accuracy
±1 110.0 to 50.0 dBm (25 ±5 °C) ≤ ±1.5 dB 50.0 to 20.0 dBm (25 ±5 °C) ≤ ±1.5 110.0 to 50.0 dBm (0 to 50 °C) ≤ ±2.0 dB 50.0 to 20.0 dBm (0 to 50 °C)
Output power accuracy
±1 120.0 to 50.0 (25 ±5 °C) ≤ ±1.5 dB 50.0 to 10.0 dBm (25 ±5 °C) ≤ ±1.5 120.0 to 50.0 dBm (0 to 50 °C) ≤ ±2.0 dB 50.0 to 10.0 dBm (0 to 50 °C)
Phase error (GMSK: 5 deg. RMS, 15 deg. Peak
( 3 deg. RMS, 9 deg. Peak)
Modulation accuracy (8PSK): 12.5 % RMS; ( 7.0 % RMS) Power level step: 0.1 dB
Power level range
Auto/Man: 110.0 to 50.0 dBm in 0.1 dB steps
(120.0 to 50.0 dBm in 0.1 dB steps)1
Tx analyzer: 110.0 to 50.0 dBm in 0.1 dB steps
(120.0 to 50.0 dBm in 0.1 dB steps)1
SG: −110.0 to 20.0 dBm in 0.1 dB steps
(120.0 to 10.0 dBm in 0.1 dB steps)1
Off: < −120 dBm; (130 dBm)1
1
1
1
1
Requires N9360AU-100 hardware installed in unit
5
RF Signal Generator for W-CDMA/HSDPA
Modulation: W-CDMA: QPSK, Off: CW, FM FM Modulation1: Rate = 50kHz, Deviation = 500kHz Modulation accuracy: QPSK 12.5% rms; (QPSK 10.0% RMS) Output power accuracy:
±1 115.0 to 50.0 dBm (25 ±5 °C) ≤ ± 1.5 50.0 to 18.0 dBm (25 ±5 °C)
± 1.5 115.0 to 50 dBm (0 to 50 °C) ≤ ± 2.0 50.0 to 18.0 dBm(0 to 50 °C)
1
Output power accuracy:
±1 120.0 to 50.0 dBm (25 ±5 °C) ≤ ± 1.5 50.0 to 15.0 dBm (25 ±5 °C) ≤ ± 2.0 15.0 to 10.0 dBm (25 ±5 °C)
± 1.5 120.0 to 50 dBm (0 to 50 °C) ≤ ± 2.0 50.0 to 15.0 dBm (0 to 50 °C) ≤ ±2.5 15.0 to 10.0 dBm (0 to 50 °C)
Frequency:
Band I: 2110 to 2170 MHz Band II: 1930 to 1990 MHz
(1932.5, 1937.5, 1942.5, 1947.5, 1952.5, 1957.5, 1962.5,
1967.5, 1972.5, 1977.5, 1982.5, 1987.5)
Band III: 1805 to 1880 MHz Band IV: 2110 to 2170 MHz Band V: 869 to 894 MHz
(871.5, 872.5, 876.5, 877.5, 882.5, 887.5)
Band VI: 875 to 885 MHz, (877.5, 882.5) Power level step: 0.1 dB Power level range:
Mod: 115.0 to 18.0 dBm in 0.1 dB steps
(120.0 to 15.0 dBm in 0.1 dB steps)
CW: 115.0 to 18.0 dBm in 0.1 dB steps
(115.0 to 15.0 dBm in 0.1 dB steps)1
Off: 120.0 dBm; (130.0 dBm)1
1
1
RF Signal Generator for cdma2000
Modulation: CDMA, Off: CW Modulation accuracy: > 0.990
1
Output power accuracy
±1 115.0 to 53.0 dBm (25 ±5 °C) ≤ ± 1.5 52.9 to 18.0 dBm (25 ±5 °C)
± 1.5 115.0 to 53 dBm (0 to 50 °C) ≤ ± 2.0 52.9 to 18.0 dBm (0 to 50 °C)
Output power accuracy:
±1 120.0 to 50.0 dBm (25 ±5 °C) ≤ ± 1.5 49.9 to 15.0 dBm (25 ±5 °C)
± 1.5 120.0 to 50 dBm (0 to 50 °C) ≤ ± 2.0 49.9 to 15.0 dBm (0 to 50 °C) ≤ ±2.5 14.9 to 10.0 dBm (0 to 50 °C)
Frequency:
Band 0: 860 to 894 MHz Band 1: 1930 to 1990 MHz Band 3: 832 to 834 MHz, 838 to 846 MHz
860 to 870 MHz
Band 4: 1840 to 1870 MHz
Band 6: 2110 to 2170 MHz Power level step: 0.1 dB Power level range:
Mod: 115.0 to 18.0 dBm in 0.1 dB steps
(120.0 to 10.0 dBm in 0.1 dB steps)
CW: 115.0 to 18.0 dBm in 0.1 dB steps
(120.0 to 10.0 dBm in 0.1 dB steps)
Off: 120.0 dBm; (130.0 dBm)1
1
1
1
1
Requires N9360AU-100 hardware installed in unit
6
GSM/GPRS/EGPRS Test Coverage
GSM Transmitter Tests
Phase and frequency error
Tx output power (normal burst)
Monotonic power sequence
Power vs time (burst timing) (normal burst)
ORFS (output RF spectrum) due to modulation
ORFS due to switching
GPRS Transmitter Tests
Phase and frequency error in GPRS multislot configuration
Tx output power in GPRS multislot configuration (normal burst)
Monotonic power sequence in GPRS configuration
Power vs time (burst timing) in GPRS configuration (normal
burst)
ORFS (output RF spectrum) due to modulation in GPRS
multislot configuration
ORFS due to switching in GPRS multislot configuration
EGPRS Transmitter Tests
Frequency error in EGPRS configuration
Modulation accuracy in EGPRS configuration
EGPRS transmitter output power
ORFS (output RF spectrum) due to modulation in EGPRS
configuration
ORFS due to switching in EGPRS configuration
GSM Receiver Tests
Reference sensitivity, TCH/FS
Signal strength
GPRS Receiver Tests
Minimum input level for reference performance for GPRS
operation
EGPRS Receiver Tests
Minimum input level for reference performance for EGPRS
operation
Receiver Signal Reporting
Signal strength
Signal quality under static conditions TCH/FS no DTX
Short Message Service (SMS)
SMS mobile terminated
SMS mobile originated
SMS cell broadcast
7
HSDPA Test Coverage
HSDPA
Through R
Median CQI
CQI variance
BLER
W-CDMA FDD Test Coverage
W-CDMA Transmitter Characteristics
Maximum output power (Tx power)
Frequency error
Open loop power control in the uplink
Inner loop power control in the uplink
Minimum output power
1
Occupied bandwidth (OBW)
Adjacent channel leakage power ratio DSB (ACLR)
1, 2
Adjacent channel leakage power ratio (ACLR)
2
Spectrum emission mask
Error vector magnitude
W-CDMA Receiver Characteristics
Reference sensitivity level
Maximum input level
Short Message Service (SMS)
SMS mobile terminated
SMS mobile originated
1
Manual mode only
2
Requires N9360AU-100 hardware installed in unit
1
GSM/GPRS/EGPRS/W-CDMA Test Features
GSM
Location update
MS call
BS call
MS release
BS release
TCH loop
Voice loopback
Emergency call
Handover
Short message service
GPRS
Attach
Detach
Handover
EGPRS
Attach
Detach
Handover
W-CDMA
Registration
UE origination call
UE termination call
BS call (RMC)
BS call (AMR)
BS release
Voice (AMR) loopback
RMC test loopback
Handover
cdma2000 Test Coverage
Protocol Test
Location update
MS call
MS release
BS call (talk)
BS call (RF test)
BS release
Talk (loopback voice)
Softer handoff
Hard handoff
Band handoff
RF Test (Automatic Test)
Access probe power
ILP
Max Tx power
Min Tx power
Frequency error
Multi code rho
Time offset
Sensitivity/FER
RF Test (Manual Test)
Tx power
Frequency error
Rho/multi code rho
Origin offset
Time offset
FER
Max Tx power
Min Tx power
Code power pilot
Code power traffic (fundamental)
Pilot strength
Access probe power
8
1xEV-DO Test Features
Protocol Test
UATI assignment
Session opened
BS call
RF test
Softer handoff
Connection close
Session close
RF Test (Automatic Test)
Access probe power
ILP
Max Tx power
Min Tx power
Frequency error
Multi code rho
Time offset
Sensitivity/PER1
Sensitivity/PER2
Sensitivity/PER3
RF Test (Manual Test)
Tx power
Frequency error
Multi code rho
Origin offset
Time offset
PER
Max Tx power
Min Tx power
Code power
Physical Specifications
Dimension: 145 x 330 x 373 mm (H x W x D) Weight: 9 kg Voltage: 80 to 240 Vac, 1 Ф Power line frequency: 50/60 Hz Power: 160 W
Internal Timebase
Output frequency: 10 MHz Output Impedance: 50 ohm (typically) Reference accuracy: 0.06 ppm/2 year
Ordering Information
N9360A Mobile Station Tester
N9360A Options
Option 010 Support GSM/GPRS Option 011 Support GSM/GPRS/EGPRS Option 020 Support cdma2000 Option 022 Support cdma2000/1xEV-DO Option 023 Support GSM/GPRS/cdma2000 Option 030 Support W-CDMA Option 032 Support W-CDMA/cdma2000 Option 033 Support W-CDMA/cdma2000/1xEV-DO Option 0341 Support GSM/GPRS/EGPRS/W-CDMA Option 035 Support GSM/GPRS/EGPRS/W-CDMA/
cdma2000/1xEV-DO
Option 036 Support GSM/GPRS/EGPRS/W-
CDMA/cdma2000 Option 051 Support GSM/GPRS/W-CDMA/HSDPA Option 052 Support GSM/GPRS/EGPRS/W-CDMA/HSDPA Option 053 Support GSM/GPRS/EGPRS/W-CDMA/HSDPA/
cdma2000/1xEV-DO Option W36 Test software to support GSM/GPRS/EGPRS/
W-CDMA/HSDPA/cdma2000/1xEV-DO Option S01 RF shielded test chamber with 2 x N-type
connector Option S02 RF shielded test chamber with 2 x N-type
connector and USB connector Option S03 RF shielded test chamber with 2 x N-type
connector and D-SUB 25 connector Option S04 RF shielded test chamber with 2 x N-type, USB
and D-SUB 25 connector Option C012 RF cable option (1 meter) Option C02 GPIB cable option (1 meter) Option C03 USB/GPIB interface to control GPIB instruments
over USB Option C04 RS232 serial cable Option C05 LAN crossover cable Option C062 EF400 RF cable (1 meter) Option A01 Additional test USIM Option A02 Additional antenna coupler Option U0103GSM/GPRS upgrade kit Option U0204cdma2000 upgrade kit Option U02131xEV-DO upgrade kit Option U0234cdma2000/1xEV-DO upgrade kit Option U0303W-CDMA upgrade kit (for N9360A-02x) Option U0313W-CDMA upgrade kit (for N9360A-01x) Option U0323HSDPA upgrade kit Option U1004N9360A B version upgrade kit
9
1
Include 1 x Test USIM and 1 x antenna coupler
2
Recommended to pick with RF shielded test chamber
3
Field upgradeable
4
Return to factory for upgrade
cdma2000 is a registered certification mark of the Telecommunications Industry Association. Used under license.
www.agilent.com www.agilent.com/find/N9360A
For more information on Agilent Technologies’ products, applications or services, please contact your local Agilent office. The complete list is available at:
www.agilent.com/find/contactus
Americas
Canada Latin America United States
(877) 894-4414 305 269 7500
(800) 829-4444 Asia Pacific Australia China Hong Kong India Japan Korea Malaysia Singapore Taiwan Thailand
1 800 629 485
800 810 0189
800 938 693
1 800 112 929
0120 (421) 345
080 769 0800
1 800 888 848
1 800 375 8100
0800 047 866
1 800 226 008
Europe & Middle East
Austria Belgium Denmark Finland France
Germany
Ireland Israel Italy Netherlands Spain Sweden Switzerland United Kingdom
01 36027 71571
32 (0) 2 404 93 40
45 70 13 15 15
358 (0) 10 855 2100
0825 010 700*
*0.125 €/minute
07031 464 6333**
**0.14 €/minute
1890 924 204
972-3-9288-504/544
39 02 92 60 8484
31 (0) 20 547 2111
34 (91) 631 3300
0200-88 22 55
0800 80 53 53
44 (0) 118 9276201 Other European Countries: www.agilent.com/find/contactus
Revised: July 17, 2008
Product specification and descriptions in this document subject to change without notice.
© Agilent Technologies, Inc. 2008 Printed in USA, October 1, 2008 5989-9559EN
10
Loading...
