Agilent N9010A Data Sheet

Agilent EXA

Signal Analyzer

N9010A

Data Sheet

Available frequency range

N9010A-503 9 kHz to 3.6 GHz

N9010A-507 9 kHz to 7.0 GHz

N9010A-513 9 kHz to 13.6 GHz

N9010A-526 9 kHz to 26.5 GHz

LXI class C certified

Table of Contents

Definitions and Conditions . . . . . . . . .3

Frequency and Time Specifications . .4

Frequency range . . . . . . . . . . . . . . . . . . .4

Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Frequency reference . . . . . . . . . . . . . . . . 4

Frequency readout accuracy . . . . . . . . . 4

Marker frequency counter . . . . . . . . . . .4

Frequency span . . . . . . . . . . . . . . . . . . . .5

Sweep time and triggering . . . . . . . . . . . 5

Time gating . . . . . . . . . . . . . . . . . . . . . . .5

Sweep (trace) point range . . . . . . . . . . . 5

Resolution bandwidth (RBW) . . . . . . . . 5

Analysis bandwidth . . . . . . . . . . . . . . . . 6

Video bandwidth (VBW) . . . . . . . . . . . . .6

Measurement speed . . . . . . . . . . . . . . . .6

Amplitude Accuracy and Range

Specifications . . . . . . . . . . . . . . . . . . .7

Amplitude range . . . . . . . . . . . . . . . . . . .7

Electronic attenuator . . . . . . . . . . . . . . . . 7

Maximum safe input level . . . . . . . . . . . 7

Display range . . . . . . . . . . . . . . . . . . . . . 7

Frequency response . . . . . . . . . . . . . . . .8

Input attenuation switching

uncertainty . . . . . . . . . . . . . . . . . . . . . . . 8

Total absolute amplitude accuracy . . . .8

Input voltage standing wave ratio

(VSWR) . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Resolution bandwidth switching

uncertainty . . . . . . . . . . . . . . . . . . . . . . . 9

Reference level . . . . . . . . . . . . . . . . . . . . 9

Display scale switching uncertainty . . . 9

Display scale fidelity . . . . . . . . . . . . . . . . 9

Trace detectors . . . . . . . . . . . . . . . . . . . .9

Preamplifier . . . . . . . . . . . . . . . . . . . . . . . 9

Dynamic Range Specifications . . . .10

1 dB gain compression (two tone) . . . 10
Displayed average noise level

(DANL) . . . . . . . . . . . . . . . . . . . . . . . . . .10

Spurious responses . . . . . . . . . . . . . . . 10

Second harmonic distortion (SHI) . . . .11

Third-order intermodulation

distortion (TOI) . . . . . . . . . . . . . . . . . . . 11

Phase noise . . . . . . . . . . . . . . . . . . . . . .12

Power Suite Measurement

Specifications . . . . . . . . . . . . . . . . . . 13

Channel power . . . . . . . . . . . . . . . . . . . 13

Occupied bandwidth . . . . . . . . . . . . . . . 13

Adjacent channel power . . . . . . . . . . . 13

Power statistics CCDF . . . . . . . . . . . . . 13

Burst power . . . . . . . . . . . . . . . . . . . . . 14

Spurious emission . . . . . . . . . . . . . . . . 14

Spectrum emission mask (SEM) . . . . . 14

General Specifications . . . . . . . . . . . 15

Temperature range . . . . . . . . . . . . . . . . 15

EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Audio noise . . . . . . . . . . . . . . . . . . . . . . 15

Environmental stress . . . . . . . . . . . . . . 15

Power requirements . . . . . . . . . . . . . . . 16

Data storage . . . . . . . . . . . . . . . . . . . . . 16

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Dimensions . . . . . . . . . . . . . . . . . . . . . . 16

Warranty . . . . . . . . . . . . . . . . . . . . . . . . 16

Calibration cycle . . . . . . . . . . . . . . . . . . 16

Inputs and Outputs . . . . . . . . . . . . . . 17

Front panel . . . . . . . . . . . . . . . . . . . . . . 17

Rear panel . . . . . . . . . . . . . . . . . . . . . . . 17

EXA Signal Analyzer Ordering

Information . . . . . . . . . . . . . . . . . . . . . 19

Hardware . . . . . . . . . . . . . . . . . . . . . . . . 19

Applications . . . . . . . . . . . . . . . . . . . . . 19

Accessories . . . . . . . . . . . . . . . . . . . . . . 19

Warranty and service . . . . . . . . . . . . . . 19

Calibration . . . . . . . . . . . . . . . . . . . . . . . 19

Related Literature . . . . . . . . . . . . . . . 20

Support, Services, and Assistance . 21

Eliminate the compromise
between speed and price

The Agilent EXA is the industry’s
fastest economy-class signal analyzer.
Its speed and accuracy, coupled
with its unprecedented performance
and application coverage, provides
development and manufacturing
engineers with the capabilities to cost­effectively troubleshoot new designs,
increase manufacturing throughput,
or analyze complex and time-varying
signals.

The EXA seamlessly integrates a
broad range of standards-based
measurements with Agilent’s industry­leading 89600 vector signal analysis
(VSA) software—all in a single
instrument. In addition to the use of
an open Windows® XP Professional
operating system, the EXA provides
an advanced signal analysis user
interface. All measurement features
and functions are intuitively grouped
and accessible from the front panel or
via a USB keyboard and mouse.

Optional measurement application
software provides preconfigured test
routines for 802.16e Mobile WiMAX™,
W-CDMA, HSDPA/HSUPA, GSM/EDGE,
and phase noise applications. Running
the Agilent 89600 VSA software
application in the EXA enables
advanced signal demodulation analysis
and troubleshooting of more than 50
demodulation formats including: 2G,
3G, 3.5G, WiMAX, WLAN, and Private
Mobile Radio.

2

Definitions and Conditions

Specifications describe the performance
of parameters covered by the product
warranty and apply over 5 to 50 °C unless
otherwise noted. 95th percentile values
indicate the breadth of the population
(≈2σ) of performance tolerances
expected to be met in 95 percent of the
cases with a 95 percent confidence,
for any ambient temperature in the
range of 20 to 30 °C. In addition to the
statistical observations of a sample
of instruments, these values include the
effects of the uncertainties of external
calibration references. These values
are not warranted. These values are
updated occasionally if a significant
change in the statistically observed
behavior of production instruments is
observed. Typical describes additional
product performance information that
is not covered by the product warranty.
It is performance beyond specifications
that 80 percent of the units exhibit
with a 95 percent confidence level over
the temperature range 20 to 30 °C.
Typical performance does not include
measurement uncertainty. Nominal
values indicate expected performance,
or describe product performance that
is useful in the application of the
product, but is not covered by the
product warranty.

The analyzer will meet its
specifications when:

• The analyzer is within its calibration
cycle.

• Under auto couple control, except
that Auto Sweep Time Rules = Accy.

• For signal frequencies <20-MHz,

DC coupling applied.

• The analyzer has been stored at
an ambient temperature within
the allowed operating range for at
least two hours before being turned
on, if it had previously been stored
at a temperature range inside the
allowed storage range but outside
the allowed operating range.

• The analyzer has been turned on at
least 30 minutes with Auto Align
set to normal, or if Auto Align is set
to off or partial, alignments must
have been run recently enough to
prevent an Alert message. If the
Alert condition is changed from
Time and Temperature to one of
the disabled duration choices,
the analyzer may fail to meet
specifications without informing
the user.

This EXA signal analyzer data sheet is a
summary of the complete specifications
and conditions, which are available in
the EXA Signal Analyzer Specification

Guide. The EXA Signal Analyzer
Specification Guide can be obtained

on the web at:

www.agilent.com/find/exa_manuals.

3

Frequency and Time Specifications

Frequency range DC Coupled AC Coupled

Option 503 9 kHz to 3.6 GHz 10 MHz to 3.6 GHz

Option 507 9 kHz to 7.0 GHz 10 MHz to 7.0 GHz

Option 513 9 kHz to 13.6 GHz 10 MHz to 13.6 GHz

Option 526 9 kHz to 26.5 GHz 10 MHz to 26.5 GHz

Band LO Multiple (N)

0 1 9 kHz to 3.6 GHz

1 1 3.5 to 7.0 GHz

2 2 6.9 to 13.6 GHz

3 2 13.5 to 17.1 GHz

4 4 17 to 26.5 GHz

Frequency reference

Accuracy ± [(time since last adjustment x aging rate) + temperature stability + calibration accuracy]

Aging rate Option PFR Standard
±1 x 10
±1.5 x 10

Temperature stability Option PFR Standard
20 to 30 °C ±1.5 x 10–8 ±2 x 10
5 to 50 °C ±5 x 10–8 ±2 x 10

Achievable initial calibration accuracy Option PFR Standard
±4 x 10

Example frequency reference accuracy = ±(1 x 1 x 10–7 + 5 x 10–8 + 4 x 10–8)
(with Option PFR) 1 year after = ±1.9 x 10
last adjustment

Residual FM
Option PFR ≤ (0.25 Hz x N) p-p in 20 ms nominal
Standard ≤ (10 Hz x N) p-p in 20 ms nominal
See band table above for N (LO Multiple)

–7

/ year ±1 x 10–6 / year

–7

/ 2 years

–6

–6

–8

±1.4 x 10

–7

–6

Frequency readout accuracy (start, stop, center, marker)

± (marker frequency x frequency reference accuracy + 0.25% x span + 5% x RBW + 2 Hz + 0.5 x horizontal resolution

1. Horizontal resolution is span/(sweep points – 1)

Marker frequency counter

Accuracy ± (marker frequency x frequency reference accuracy + 0.100 Hz)

Delta counter accuracy ± (delta frequency x frequency reference accuracy + 0.141 Hz)

Counter resolution 0.001 Hz

4

1

)

Frequency and Time Specifications (continued)

Frequency span (FFT and swept mode)

Range 0 Hz (zero span), 10 Hz to maximum frequency of instrument

Resolution 2 Hz

Accuracy
Swept ±(0.25% x span + horizontal resolution)
FFT ±(0.10% x span + horizontal resolution)

Sweep time and triggering

Range Span = 0 Hz 1 µs to 6000 s
Span ≥ 10 Hz 1 ms to 4000 s

Accuracy Span ≥ 10 Hz, swept ±0.01% nominal
Span ≥ 10 Hz, FFT ±40% nominal
Span = 0 Hz ±0.01% nominal

Trigger Free run, line, video, external 1, external 2, RF burst, periodic timer

Trigger delay Span = 0 Hz or FFT –150 to +500 ms
Span ≥ 10 Hz, swept 1 µs to 500 ms
Resolution 0.1 µs

Time gating

Gate methods: Gated LO; Gated video; Gated FFT
Gate length range (except method = FFT): 100.0 ns to 5.0 s
Gate delay range: 0 to 100.0 s
Gate delay jitter: 33.3 ns p-p nominal

Sweep (trace) point range

All spans 1 to 20001

Resolution bandwidth (RBW)

Range (–3.01 dB bandwidth) 1 Hz to 3 MHz (10% steps), 4, 5, 6, 8 MHz

Bandwidth accuracy (power) 1 Hz to 750 kHz ±1.0% (±0.044 dB)
RBW range 820 kHz to 1.2 MHz (< 3.6 GHz CF) ±2.0% (±0.088 dB)

1.3 to 2.0 MHz (< 3.6 GHz CF) ±0.07 dB nominal

2.2 to 3 MHz (< 3.6 GHz CF) ±0.15 dB nominal
4 to 8 MHz (< 3.6 GHz CF) ±0.25 dB nominal

Bandwidth accuracy (–3.01 dB) 1 Hz to 1.3 MHz ±2% nominal
RBW range

Selectivity (–60 dB/–3 dB) 4.1:1 nominal

5

Frequency and Time Specifications (continued)

Analysis bandwidth

2

Maximum bandwidth 10 MHz, Standard

2. Analysis bandwidth is the instantaneous bandwidth available around a center frequency over which the input signal can be digitized for further analysis or processing in the
time, frequency, or modulation domain.

Video bandwidth (VBW)

Range 1 Hz to 3 MHz (10% steps), 4, 5, 6, 8 MHz and wide open (labeled 50 MHz)

Accuracy ±6% nominal

Measurement speed

Local measurement and display 11 ms (90/s) nominal Sweep points = 1001
update rate

Remote measurement and LAN 4 ms (250/s) nominal Sweep points = 1001
transfer rate

Marker peak search 5 ms nominal

Center frequency tune and transfer (RF) 51 ms nominal

Center frequency tune and transfer (µW) 86 ms nominal

Measurement/mode switching 75 ms nominal

6

Amplitude Accuracy and Range Specifications

Amplitude range

Measurement range Displayed average noise level (DANL) to +23 dBm

Input attenuator range
(9 kHz to 26.5 GHz)
Standard 0 to 60 dB in 10 dB steps
Option FSA 0 to 60 dB in 2 dB steps

Electronic attenuator (Option EA3)

Frequency range 9 kHz to 3.6 GHz

Attenuation range
Electronic attenuator range 0 to 24 dB, 1 dB steps
Full attenuation range 0 to 84 dB, 1 dB steps
(mechanical + electronic)

Maximum safe input level

Average total power +30 dBm (1 W)
(with and without preamp)

Peak pulse power < 10 µs pulse width, < 1% duty cycle +50 dBm (100 W)
and input attenuation ≥30 dB

DC volts
DC coupled ±0.2 Vdc
AC coupled ±70 Vdc

Display range

Log scale 0.1 to 1 dB/division in 0.1 dB steps
1 to 20 dB/division in 1 dB steps
(10 display divisions)

Linear scale 10 divisions

Scale units dBm, dBmV, dBµV, dBmA, dBµA, V, W, A

7

Amplitude Accuracy and Range Specifications (continued)

Frequency response (10 dB input attenuation, 20 to 30 °C, preselector centering applied, σ = nominal standard deviation)

th

Specification 95

9 kHz to 10 MHz ±0.8 dB ±0.4 dB
10 MHz to 3.6 GHz ±0.6 dB ±0.3 dB

3.5 to 7.0 GHz ±2.0 dB

6.9 to 13.6 GHz ±2.5 dB

13.5 to 22.0 GHz ±3.0 dB

22.0 to 26.5 GHz ±3.2 dB

Preamp on (Option P03) 100 kHz to 3.6 GHz ±0.28 dB
attenuation 0 dB

Input attenuation switching uncertainty

50 MHz (reference frequency) ±0.20 dB ±0.08 dB typical
attenuation > 2 dB , preamp off
9 kHz to 3.6 GHz ±0.3 dB nominal

3.5 to 7.0 GHz ±0.5 dB nominal

6.9 to 13.6 GHz ±0.7 dB nominal

13.5 to 26.5 GHz ±0.7 dB nominal

Percentile (≈ 2σ)

Total absolute amplitude accuracy (10 dB attenuation, 20 to 30 °C, 1 Hz ≤ RBW ≤ 1 MHz, input signal –10 to –50 dBm, all settings
auto-coupled except Auto Swp Time = Accy, any reference level, any scale, σ = nominal standard deviation)

At 50 MHz ±0.40 dB
At all frequencies ±(0.40 dB + frequency response)
9 kHz to 3.6 GHz ±0.30 dB (95th Percentile ≈ 2σ)

Preamp on (Option P03) 100 kHz to 3.6 GHz ±(0.39 dB + frequency response)

Input voltage standing wave ratio (VSWR) (≥10 dB input attenuation)

10 MHz to 3.6 GHz < 1.2:1 nominal

3.6 to 7.0 GHz < 1.5:1 nominal

7.0 to 13.6 GHz < 1.6:1 nominal

13.6 to 26.5 GHz < 1.9:1 nominal

Preamp on (Option P03) 10 MHz to 3.6 GHz < 1.7:1 nominal
(0 dB attenuation)

8

Amplitude Accuracy and Range Specifications (continued)

Resolution bandwidth switching uncertainty (referenced to 30 kHz RBW)

1 Hz to 1.5 MHz RBW ±0.08 dB

1.6 MHz to 3 MHz RBW ±0.10 dB

4, 5, 6, 8 MHz RBW ±1.0 dB

Reference level

Range
Log scale –170 to +23 dBm in 0.01 dB steps
Linear scale Same as Log (707 pV to 3.16 V)

Accuracy 0 dB

Display scale switching uncertainty

Switching between linear and log 0 dB

Log scale/div switching 0 dB

Display scale fidelity

Between –10 dBm and –80 dBm input ±0.15 dB total
mixer level

Trace detectors

Normal, peak, sample, negative peak, log power average, RMS average, and voltage average

Preamplifier

Frequency range Option P03 100 kHz to 3.6 GHz

Gain 100 kHz to 3.6 GHz +20 dB nominal

Noise figure 100 kHz to 3.6 GHz 11 dB nominal

9

Dynamic Range Specifications

1 dB gain compression (two-tone)

Total power at input mixer

20 MHz to 26.5 GHz +9 dBm nominal

Preamp on (Option P03) 10 MHz to 3.6 GHz –10 dBm nominal

Displayed average noise level (DANL)
(Input terminated, sample or average detector, averaging type = Log, 0 dB input attenuation, IF Gain = High, 20 to 30 °C)

Specification Typical

Preamp off 1 to 10 MHz –145 dBm –149 dBm
10 MHz to 2.1 GHz –146 dBm –150 dBm

2.1 to 3.6 GHz –144 dBm –148 dBm

3.6 to 7.0 GHz –144 dBm –149 dBm

7.0 to 13.6 GHz –143 dBm –147 dBm

13.6 to 17.1 GHz –137 dBm –142 dBm

17.1 to 20.0 GHz –137 dBm –142 dBm

20.0 to 26.5 GHz –134 dBm –140 dBm

Preamp on (Option P03) 10 MHz to 2.1 GHz –160 dBm –162 dBm

2.1 to 3.6 GHz –159 dBm –160 dBm

Spurious responses

Residual responses (Input 200 kHz to 8.4 GHz (swept) –100 dBm
terminated and 0 dB attenuation) Zero span or FFT or other frequencies –100 dBm nominal

Image responses 10 MHz to 3.6 GHz –80 dBc (–103 dBc typical)

3.6 to 13.6 GHz –75 dBc (–87 dBc typical)

13.6 to 17.1 GHz –71 dBc (–85 dBc typical)

17.1 to 22 GHz –68 dBc (–82 dBc typical)

22 to 26.5 GHz –66 dBc (–78 dBc typical)

LO related spurious 10 MHz to 3.6 GHz –90 dBc typical
(f > 600 MHz from carrier)

Other spurious
First RF order
f ≥ 10 MHz from carrier –68 dBc
Higher RF order
f ≥ 10 MHz from carrier –80 dBc

10

Dynamic Range Specifications (continued)

relative

to

mixer

level

(dB)

Nominal Dynamic Range Bands 1-4

-130

-120

-110

-100

-90

-80

-70

-60

-80 -70 -60 -50 -40 -30 -20 -10

Mixer Level (dBm)

DANL and distortion

relative to mixer level (dB)

DANL
(1 Hz RBW)

2nd Harmonic
Distortion

3rd Order

Intermodulation

22–26.5 GHz3.6–26.5 GHz

1

3

.6

–

2

6

.5

G

H

z

3.6–13.6 GHz

13.6–22 GHz

3.6–13.6 GHz

Second harmonic distortion (SHI)

Mixer level SHI
10 MHz to 1.8 GHz –15 dBm +45 dBm

1.8 to 7.0 GHz –15 dBm +65 dBm

7.0 to 11.0 GHz –15 dBm +55 dBm

11.0 to 13.25 GHz –15 dBm +50 dBm

Third-order intermodulation distortion (TOI) (two -30 dBm tones at input mixer with tone separation > 5 times IF prefilter bandwidth,
20 to 30 degC, see Specifications Guide for IF prefilter bandwidths)

Distortion TOI Typical
100 to 400 MHz –80 dBc +10 dBm +14 dBm
400 MHz to 1.7 GHz –82 dBc +11 dBm +15 dBm

1.7 to 3.6 GHz –86 dBc +13 dBm +17 dBm

3.6 to 7.0 GHz –82 dBc +11 dBm +15 dBm

7.0 to 13.6 GHz –82 dBc +11 dBm +15 dBm

13.6 to 26.5 GHz –78 dBc + 9 dBm +14 dBm

Preamp on (Option P03) 30 MHz to 3.6 GHz 0 dBm nominal (two –45 dBm tones at preamp input)

-60

-70

-80

-90

-100

-110

-120

-130

Figure 1. Nominal dynamic range – Band 0, for second and third
order distortion, 9 kHz to 3.6 GHz

Nominal Range at 1 GHz

DANL
(1 Hz RBW)

2nd Harmonic
Distortion

3rd Order

Intermodulation

-80 -70 -60 -50 -40 -30 -20 -10

Mixer Level (dBm)

Figure 2. Nominal dynamic range – Bands 1 to 4, second and
third order distortion, 3.6 GHz to 26.5 GHz

11

Dynamic Range Specifications (continued)

Phase noise

Noise sidebands Offset Specification Typical
(20 to 30 °C, CF = 1 GHz) 100 Hz –84 dBc/Hz – 88 dBc/Hz
1 kHz – 97 dBc/Hz nominal
10 kHz –99 dBc/Hz –103 dBc/Hz
100 kHz –111 dBc/Hz –114 dBc/Hz
1 MHz –130 dBc/Hz –134 dBc/Hz
10 MHz –143 dBc/Hz nominal

3. For nominal values, refer to Figure 3.

3

Nominal phase noise at different center frequencies with RBW selectivity curves

Optimized phase noise, versus offset frequency

–20

–30

–40

–50

RBW = 100 Hz

RBW = 1 kHz

–60

–70

–80

–90

–100

–110

CF = 600 MHz

CF = 10.2 GHz

–120

SSB phase noise (dBc/Hz)

–130

–140

–150

–160

–170

0.01 0.1 1 10 100 1000 10000

RBW = 1 kHz

RBW = 100 kHz

CF = 25.2 GHz

Freq (kHz)

Figure 3. Nominal phase noise at different center frequencies (with Option PFR)

12

Power Suite Measurement Specifications

Channel power

Amplitude accuracy, W-CDMA or IS95 ±0.94 dB (±0.30 dB 95th percentile)
(20 to 30 °C, attenuation = 10 dB)

Occupied bandwidth

Frequency accuracy ± [span/1000] nominal

Adjacent channel power

Accuracy, W-CDMA (ACLR) (at specific
mixer levels and ACLR ranges) Adjacent Alternate
MS ±0.22 dB ±0.34 dB
BTS ±1.07 dB ±1.00 dB

Dynamic range (typical)
Without noise correction –68 dB –74 dB
With noise correction –73 dB –76 dB

Offset channel pairs measured 1 to 6

ACP speed (fast method). Data 14 ms nominal (σ = 0.2 dB)
measurement and transfer time

Multiple number of carriers measured Up to 12

Power statistics CCDF

Histogram resolution 0.01 dB

13

Power Suite Measurement Specifications (continued)

Burst power

Methods Power above threshold, power within burst width

Results Single burst output power, average output power, maximum power, minimum power within
burst, burst width

Spurious emission

W-CDMA (1 to 3.6 GHz)
Table driven spurious signals; search
across regions.
Dynamic range 91.9 dB (97.1 dB typical)
Absolute sensitivity –79.4 dBm (–85.4 dBm typical)

Spectrum emission mask (SEM)

cdma2000® (750 kHz offset)
Relative dynamic range (30 kHz RBW) 74.0 dB (81.0 dB typical)
Absolute sensitivity –94.7 dBm (–100.7 dBm typical)
Relative accuracy ±0.11 dB

3GPP W-CDMA (2.515 MHz offset)
Relative dynamic range (30 kHz RBW) 76.5 dB (83.9 dB typical)
Absolute sensitivity –94.7 dBm (–100.7 dBm typical)
Relative accuracy ±0.12 dB

14

General Specifications

Temperature range

Operating 5 to +50 °C

Storage –40 to +65 °C

EMC

Complies with European EMC Directive 89/336/EEC, amended by 93/68/EEC

• IEC/EN 61326

• CISPR Pub 11 Group 1, class A

• AS/NZS CISPR 11:2002

• ICES/NMB-001

Safety

Complies with European Low Voltage Directive 73/23/EEC, amended by 93/68/EEC

• IEC/EN 61010-1

• Canada: CSA C22.2 No. 61010-1

• USA: UL 61010-1

Audio noise

Acoustic noise emission Geraeuschemission

LpA <70 dB LpA <70 dB

Operator position Am Arbeitsplatz

Normal position Normaler Betrieb

Per ISO 7779 Nach DIN 45635 t.19

Environmental stress

Samples of this product have been type tested in accordance with the Agilent Environmental Test Manual and verified to be robust against
the environmental stresses of storage, transportation and end-use; those stresses include but are not limited to temperature, humidity, shock,
vibration, altitude and power line conditions. Test methods are aligned with IEC 60068-2 and levels are similar to MIL-PRF-28800F Class 3.

15

General Specifications (continued)

Power requirements

Voltage and frequency (nominal) 100/120 V, 50/60 Hz
220/240 V, 50/60 Hz

Power consumption
On < 260 watts
Standby < 20 watts

Data storage

Internal 40 GB nominal

External Supports USB 2.0 compatible memory devices

Weight (without options)

Net 16 kg (35 lbs) nominal
Shipping 28 kg (62 lbs) nominal

Dimensions

Height 177 mm (7.0 in)

Width 426 mm (16.8 in)

Length 368 mm (14.5 in)

Warranty

The EXA signal analyzer is supplied with a one-year warranty.

Calibration cycle

The recommended calibration cycle is one year. Calibration services are available through Agilent service centers.

16

Inputs and Outputs

Front panel

RF input
Connector Type-N female, 50 Ω nominal

Probe power
Voltage/current +15 Vdc, ±7% at 150 mA max nominal
–12.6 Vdc, ±10% at 150 mA max nominal

USB 2.0 ports
Master (2 ports)
Standard Compatible with USB 2.0
Connector USB Type-A female
Output current 0.5 A nominal

Rear panel

10 MHz out
Connector BNC female, 50 Ω nominal
Output amplitude ≥ 0 dBm nominal
Frequency 10 MHz ± (10 MHz x frequency reference accuracy)

Ext Ref In
Connector BNC female, 50 Ω nominal
Input amplitude range –5 to +10 dBm nominal
Input frequency 10 MHz nominal
Frequency lock range ± 5 x 10

Trigger 1 and trigger 2 inputs
Connector BNC female
Impedance > 10 kΩ nominal
Trigger level range –5 to +5 V

Trigger 1 and trigger 2 outputs
Connector BNC female
Impedance 50 Ω nominal
Level 5 V TTL nominal

–6

of specified external reference input frequency

17

Inputs and Outputs (continued)

Rear panel (continued)

Sync (reserved for future use)
Connector BNC female

Monitor output
Connector VGA compatible, 15-pin mini D-SUB
Format XGA (60 Hz vertical sync rates, non-interlaced) Analog RGB
Resolution 1024 x 768

Noise source drive +28 V (pulsed)
(reserved for future use)
Connector BNC female

SNS series noise source (reserved for future use)

Digital bus (reserved for future use)
Connector MDR-80

Anolog out (reserved for future use)
Connector BNC female

USB 2.0 ports
Master (4 ports)
Standard Compatible with USB 2.0
Connector USB Type-A female
Output current 0.5 A nominal
Slave (1 port)
Standard Compatible with USB 2.0
Connector USB Type-B female
Output current 0.5 A nominal

GPIB interface
Connector IEEE-488 bus connector
GPIB codes SH1, AH1, T6, SR1, RL1, PP0, DC1, C1, C2, C3, C28, DT1, L4, C0

LAN TCP/IP interface
Standard 100BaseT
Connector RJ45 Ethertwist

18

EXA Signal Analyzer Ordering Information

For further information, refer to EXA Signal Analyzer Configuration Guide (5989-6531EN)

Hardware

N9010A EXA signal analyzer

N9010A-503 Frequency range, 9 kHz to 3.6 GHz

N9010A-507 Frequency range, 9 kHz to 7.0 GHz

N9010A-513 Frequency range, 9 kHz to 13.6 GHz

N9010A-526 Frequency range, 9 kHz to 26.5 GHz

N9010A-FSA Fine step attenuator

N9010A-PFR Precision frequency reference

N9010A-EA3 Electronic attenuator, 3.6 GHz

N9010A-P03 Preamplifier, 3.6 GHz

Applications

N9063A Analog demodulation measurement application (Orderable December 2007)

Phase noise measurement application

N9068A

GSM/EDGE measurement application

N9071A

N9073A-1FP

N9073A-2FP

N9075A 802.16 OFDMA measurement application

N9069A

N9072A

N9079A-1FP

N9079A-2FP HSDPA/8PSK measurement application (requires N9079A-1FP) (Orderable December 2007)

89601A

89601X

W-CDMA measurement application

HSDPA/HSUPA measurement application (requires N9073A-1FP)

Noise fi gure measurement application (Orderable December 2007)

cdma2000 measurement application (Orderable December 2007)

TD-SCDMA measurement application (Orderable December 2007)

Vector signal analysis software

Modulation analysis measurement application for X-Series (Orderable early 2008)

Accessories

N9010A-CPU Instrument security, additional CPU/HDD

N9010A-MSE Mouse

N9010A-KYB Keyboard

N9010A-EFM USB flash drive, 512 MB

N9010A-DVR USB DVD-ROM/CD-R/RW drive

N9010A-CPU Instrument security, additional CPU/HDD

N9010A-MLP Minimum loss pad, 50 to 75 Ω

N9010A-PRC Portable configuration

N9010AK-CVR Front panel cover

N9010A-1CP Rack mount and handle kit

N9010A-1CM Rack mount kit

N9010A-1CN Front handle kit

N9010A-1CR Rack slide kit

N9010A-HTC Hard transit case

Warranty and service

Standard warranty is one year.

R-51B-001-3C 1 year return-to-Agilent warranty extended to 3 years

Calibration

R-50C-011-3 Inclusive calibration plan, 3 year coverage

R-50C-013-3 Inclusive calibration plan and cal data, 3 year coverage

4. Options not available in all countries

4

19

Literature Resources

Publication title Publication number

Agilent MXA Signal Analyzer

Agilent MXA Signal Analyzer, Brochure 5989-5047EN

Agilent MXA Signal Analyzer, Data Sheet 5989-4942EN

Agilent MXA Signal Analyzer, Configuration Guide 5989-4943EN

Agilent EXA Signal Analyzer

Agilent EXA Signal Analyzer, Brochure 5989-6527EN

Agilent EXA Signal Analyzer, Data Sheet 5989-6529EN

Agilent EXA Signal Analyzer, Configuration Guide

Agilent X-Series Signal Analyzers

Agilent X-Series Signal Analyzer (MXA/EXA), Demonstration Guide 5989-6126EN

Agilent X-Series Signal Analyzers (MXA/EXA) W-CDMA, HSDPA/HSUPA, Technical Overview 5989-5352EN

Agilent X-Series Signal Analyzers (MXA/EXA) 802.16 OFDMA, Technical Overview 5989-5353EN

Agilent X-Series Signal Analyzers (MXA/EXA) Phase Noise, Technical Overview 5989-5354EN

Agilent X-Series Signal Analyzers (MXA/EXA) GSM/EDGE, Technical Overview

Using Agilent X-Series Signal Analyzers (MXA/EXA) for Measuring and Troubleshooting 5989-4944EN
Digitally Modulated Signals, Application Note

Using Agilent X-Series Signal Analyzers (MXA/EXA) Preselector Tuning for Amplitude
in Microwave Spectrum Analysis

Maximizing Measurement Speed with Agilent X-Series Signal Analyzers (MXA/EXA), Application

, Application Note

Accuracy 5989-4946EN

Note 5989-4947EN

5989-6531EN

5989-6532EN

20

www.agilent.com/fi nd/emailupdates

Get the latest information on the
products and applications you select.

www.agilent.com/fi nd/agilentdirect

Quickly choose and use your test
equipment solutions with confi dence.

www.agilent.com/fi nd/open

Agilent Open simplifi es the process
of connecting and programming
test systems to help engineers
design, validate and manufacture
electronic products. Agilent offers
open connectivity for a broad range
of system-ready instruments, open
industry software, PC-standard I/O
and global support, which are
combined to more easily integrate
test system development.

www.lxistandard.org
LXI is the LAN-based successor to
GPIB, providing faster, more effi cient
connectivity. Agilent is a founding
member of the LXI consortium.

Microsoft® and Windows® are U.S. registered
trademarks of Microsoft Corporation.

®

Pentium
Intel Corporation.

cdma2000 is a registered certifi cation mark of
the Telecommunications Industry Association.
Used under license.

WiMax, Mobile WiMax, or WiMax Forum are
trademarks of the WiMax Forum.

is a U.S. registered trademark of

Remove all doubt

Our repair and calibration services
will get your equipment back to you,
performing like new, when prom­ised. You will get full value out of
your Agilent equipment through­out its lifetime. Your equipment
will be serviced by Agilent-trained
technicians using the latest factory
calibration procedures, automated
repair diagnostics and genuine parts.
You will always have the utmost
confi dence in your measurements.

Agilent offers a wide range of addi­tional expert test and measurement
services for your equipment, includ­ing initial start-up assistance onsite
education and training, as well as
design, system integration, and
project management.

For more information on repair and
calibration services, go to:

www.agilent.com/fi nd/removealldoubt

www.agilent.com

For more information on Agilent Technologies’
products, applications or services, please
contact your local Agilent offi ce. The
complete list is available at:

www.agilent.com/fi nd/contactus

Americas

Canada [phone]
Latin America 305 269 7500
United States [phone]

Asia Pacifi c

Australia 1 800 629 485
China 800 810 0189
Hong Kong 800 938 693
India 1 800 112 929
Japan 81 426 56 7832
Korea 080 769 0800
Malaysia 1 800 888 848
Singapore 1 800 375 8100
Taiwan 0800 047 866
Thailand 1 800 226 008

Europe

Austria 0820 87 44 11
Belgium 32 (0) 2 404 93 40
Denmark 45 70 13 15 15
Finland 358 (0) 10 855 2100
France 0825 010 700
Germany 01805 24 6333*
*0.14€/minute
Ireland 1890 924 204
Italy 39 02 92 60 8484
Netherlands 31 (0) 20 547 2111
Spain 34 (91) 631 3300
Sweden 0200-88 22 55
Switzerland (French) 41 (21) 8113811(Opt 2)
Switzerland (German) 0800 80 53 53 (Opt 1)
United Kingdom 44 (0) 118 9276201
Other European Countries:
www.agilent.com/fi nd/contactus

Revised: May 7, 2007

Product specifi cations and descriptions
in this document subject to change
without notice.

© Agilent Technologies, Inc. 2007
Printed in USA, August 29, 2007
5989-6529EN
