E-Series Power Sensors
High Frequency, High Power Specials
Agilent Technologies
E4413A H33
Frequency Range Maximum SWR Cal Factor Uncertainty
% at 1 mW (0.0 dBm)
50 MHz to 33 GHz 1.34 (26 GHz to 3.2%
33 GHz)
E9300A H24
All specifications for the E9300A option H24
are identical to the E9300A with the following
exceptions:
Frequency Range Connector Type
50 MHz to 24 GHz 3.5 mm
Maximum SWR Maximum SWR
(25 ± 10°C) (0 to 55°C)
50 MHz to 2 GHz: 1.13 50 MHz to 2 GHz: 1.15
2 GHz to 14 GHz: 1.19 2 GHz to 14 GHz: 1.20
14 GHz to 16 GHz: 1.22 14 GHz to 16 GHz: 1.23
16 GHz to 18 GHz: 1.26 16 GHz to 18 GHz: 1.27
18 GHz to 24 GHz: 1.30118 GHz to 24 GHz: 1.30
1
Maximum DC Volts: 10 volts
Cal Factor uncertainty
(Low Power Path, -60 to –10 dBm):
Frequency Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
50 MHz to 500 MHz ± 1.6% ± 2.0%
500 MHz to 1.2 GHz ± 1.8% ± 2.5%
1.2 GHz to 6 GHz ± 1.7% ± 2.0%
6 GHz to 14 GHz ± 1.8% ± 2.0%
14 GHz to 18 GHz ± 2.0% ± 2.2%
18 GHz to 24 GHz ± 3.0% ± 3.5%
Cal Factor uncertainty
(High Power Path, -10 to +20 dBm):
Frequency Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
50 MHz to 500 MHz ± 2.3% ± 3.0%
500 MHz to 1.2 GHz ± 2.8% ± 4.0%
1.2 GHz to 6 GHz ± 2.3% ± 2.1%
6 GHz to 14 GHz ± 2.4% ± 2.3%
14 GHz to 18 GHz ± 2.7% ± 3.3%
18 GHz to 24 GHz ± 3.5% ± 4.0%
1
A supplemental characteristic
E9300A H25
Option H25 adds an external 8493C option 010
10 dB attenuator, which shifts the power range
of the standard E9300A to –50 to +30 dBm. All
specifications for the E9300A option H25 are
identical to the E9300H with the following
exceptions:
Frequency Range Connector Type
50 MHz to 24 GHz 3.5 mm
Maximum SWR Maximum SWR
(25 ± 10°C) (0 to 55°C)
50 MHz to 2 GHz: 1.13 50 MHz to 2 GHz: 1.15
2 GHz to 14 GHz: 1.19 2 GHz to 14 GHz: 1.20
14 GHz to 16 GHz: 1.25 14 GHz to 16 GHz: 1.25
16 GHz to 18 GHz: 1.26 16 GHz to 18 GHz: 1.27
18 GHz to 24 GHz: 1.30 18 GHz to 24 GHz: 1.30
1
Maximum DC Volts: 10 volts
Cal Factor uncertainty
(Low Power Path, -50 to 0 dBm):
Frequency Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
50 MHz to 500 MHz ± 1.6% ± 2.0%
500 MHz to 1.2 GHz ± 1.8% ± 2.5%
1.2 GHz to 6 GHz ± 1.7% ± 2.0%
6 GHz to 14 GHz ± 1.8% ± 2.0%
14 GHz to 18 GHz ± 2.0% ± 2.2%
18 GHz to 24 GHz ± 3.0%
2
± 3.5%
2
Cal Factor uncertainty
(High Power Path, 0 to +30 dBm):
Frequency Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
50 MHz to 500 MHz ± 2.3% ± 3.5%
500 MHz to 1.2 GHz ± 2.8% ± 4.5%
1.2 GHz to 6 GHz ± 2.3% ± 2.6%
6 GHz to 14 GHz ± 2.4% ± 2.8%
14 GHz to 18 GHz ± 2.7% ± 3.8%
18 GHz to 24 GHz ± 3.5% ± 4.5%
1
A supplemental characteristic
2
Supplemental characteristic except ± 5°C in the 25 ± 10°C specification
E9304A H18
All specifications for the E9304A option H18
are identical to the E9304A with the following
exceptions:
Frequency Range
9 kHz to 18 GHz
Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
9 kHz to 2 GHz: 1.13 50 MHz to 2 GHz: 1.15
2 GHz to 14 GHz: 1.19 2 GHz to 14 GHz: 1.20
14 GHz to 16 GHz: 1.22 14 GHz to 16 GHz: 1.23
16 GHz to 18 GHz: 1.26 16 GHz to 18 GHz: 1.27
Cal Factor uncertainty
(Low Power Path, -60 to –10 dBm):
Frequency Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
9 kHz to 6 GHz ± 1.7% ± 2.0%
6 GHz to 14 GHz ± 1.8% ± 2.0%
14 GHz to 18 GHz ± 2.0% ± 2.2%
2
Cal Factor uncertainty
(High Power Path, -10 to +20 dBm):
Frequency Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
9 kHz to 500 MHz ± 2.0% ± 3.4%
500 MHz to 1.2 GHz ± 2.2% ± 3.4%
1.2 GHz to 6 GHz ± 1.8% ± 2.1%
6 GHz to 14 GHz ± 1.9% ± 2.3%
14 GHz to 18 GHz ± 2.2% ± 3.3%
E9304A H19
Option H19 modifies the standard E9304A
power sensor by adding a 10 dB attenuator,
which shifts the power range to –50 to +30 dBm
and extends the upper frequency range to 18 GHz.
All specifications for the E9304A option H19
are identical to the E9304A with the following
exceptions:
Frequency Range Power Range
9 kHz to 18 GHz -50 to +30 dBm
Maximum SWR Maximum SWR
(25 ± 10°C) (0 to 55°C)
9 kHz to 8 GHz: 1.15 9 kHz to 8 GHz: 1.17
8 GHz to 12.4 GHz: 1.25 8 GHz to 12.4 GHz: 1.26
12.4 GHz to 18 GHz: 1.28 12.4 GHz to 18 GHz: 1.29
Cal Factor uncertainty
(Low Power Path, -50 to 0 dBm):
Frequency Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
9 kHz to 6 GHz ± 1.7% ± 2.0%
6 GHz to 14 GHz ± 1.8% ± 2.0%
14 GHz to 18 GHz ± 2.0% ± 2.2%
Cal Factor uncertainty
(High Power Path, 0 to +30 dBm):
Frequency Uncertainty Uncertainty
(25 ± 10°C) (0 to 55°C)
9 kHz to 500 MHz ± 2.3% ± 3.5%
500 MHz to 1.2 GHz ± 2.8% ± 4.5%
1.2 GHz to 6 GHz ± 2.3% ± 2.6%
6 GHz to 14 GHz ± 2.4% ± 2.8%
14 GHz to 18 GHz ± 2.7% ± 3.8%
3
