Agilent E8361A Configuration Guide

Agilent PNA Series Microwave Network Analyzers

Configuration Guide

PNA-L N5230A 300 kHz to 6, 13.5, or 20 GHz PNA-L N5230A 10 MHz to 20, 40, or 50 GHz PNA-X N5242A 10 MHz to 26.5 GHz PNA E8362B 10 MHz to 20 GHz PNA E8363B 10 MHz to 40 GHz

PNA E8364B 10 MHz to 50 GHz PNA E8361A 10 MHz to 67 GHz PNA N5250A 10 MHz to 110 GHz

System configuration summary

This summary lists the main components required to form a basic measurement system. Options or peripherals may be added to provide enhanced measurement and data storage capability.

Full S-parameter measurements

• Agilent PNA Series microwave

network analyzers

• Test port cables, 50 ohms

• Calibration kit for applicable

connector type

This configuration guide describes standard configurations, options, accessories, upgrade kits and compatible peripherals for the PNA Series microwave network analyzers. This guide should be used with the Agilent PNA Series Microwave Network Analyzers Data Sheet for a complete description of these analyzers.

PNA-L (N5230A)

Step 1: Select N5230A model number

Step 2: Choose your frequency range and test set (Mandatory, choose only one) Description Ordering number

300 kHz to 6 GHz 2-port standard test set N52300-020 300 kHz to 6 GHz 2-port configurable test set N52300-025 and extended power range 300 kHz to 13.5 GHz 2-port standard test set N52300-120 300 kHz to 13.5 GHz 2-port configurable test set N52300-125 and extended power range 300 kHz to 13.5 GHz 4-port standard test set N52300-140 300 kHz to 13.5 GHz 4-port configurable test set N52300-145 and extended power range 300 kHz to 13.5 GHz 4-port configurable test set, N52300-146 extended power range and internal second source (Option 080 recommended) 10 MHz to 20 GHz 2-port standard test set N52300-220 10 MHz to 20 GHz 2-port configurable test set N52300-225 and extended power range 300 kHz to 20 GHz 4-port standard test set N52300-240 300 kHz to 20 GHz 4-port configurable test set N52300-245 and extended power range 300 kHz to 20 GHz 4-port configurable test set, N52300-246 extended power range and internal second source (Option 080 recommended) 10 MHz to 40 GHz 2-port standard test set N52300-420 10 MHz to 40 GHz 2-port configurable test set N52300-425 and extended power range 10 MHz to 50 GHz 2-port standard test set N52300-520

10 MHz to 50 GHz 2-port configurable test set N52300-525 and extended power range

Step 3: Choose additional software options (Optional) Description Ordering number

Time domain for 6 GHz model N52310-010 Time domain for 13.5, 20, 40 or 50 GHz model N52300-010 Frequency-offset measurements N52300-080 Scalar-calibrated converter measurements N52300-082 (Option 080 required) 4-port measurement application N52300-550 N-port capabilities for 6, 13.5 or 20 GHz model N52310-551 N-port capabilities for 40 or 50 GHz model N52300-551

Step 4: Choose an electronic or mechanical calibration kit (Optional) Description Ordering number

300 kHz to 9 GHz, 2-port, 3.5 mm 85093C 300 kHz to 13.5 GHz, 4-port, Type-N N4431B or 3.5 mm 300 kHz to 18 GHz, 4-port, Type-N N4432A 300 kHz to 20 GHz, 4-port, 3.5 mm N4433A 300 kHz to 26.5 GHz, 2-port, 3.5 mm N4691B 10 MHz to 50 GHz, 2-port, 2.4 mm N4693A

Note: For additional calibration kits refer to page 16

Step 5: Accessories (Optional) Description Ordering number

Rack mount kit without handles N5230A-1CM Rack mount kit with handles N5230A-1CP USB CD R/W drive N4688A USB Hub N4689A

Note: For additional accessories refer to page 16

Step 6: Calibration documentation (Optional) Description Ordering number

ISO 17025 compliant calibration N5230A-1A7 Commercial calibration certificate with test data N5230A-UK6 ANSI Z540 compliant calibration N5230A-A6J

Step 7: Choose your warranty and service (Optional) Description

1 year return-to Agilent warranty and service 3 year return-to Agilent warranty and service

Documentation

The PNA Series instruments are equipped with an Online Help system available within the instrument in the following languages: English, Japanese, Chinese, German, Spanish, and French. The PNA Service Guide and Online Help system are available on the Web: www.na.tm.agilent.com/pna

Connector type

Option 020, 025, 120, 125, 140, 145, 146, 220, 225, 240, 245, 246:

3.5 mm ruggedized male, 50 ohm Option 420, 425, 520, 525:

2.4 mm ruggedized male, 50 ohm

Additional product information

For additional PNA-L (N5230A) product information, refer to the PNA-L brochure available on our Web site:

www.agilent.com/find/pnal

PNA-L (N5230A)

This guide is intended to assist you in the ordering process. Additional information and products (such as calibration kits and cables) are described throughout this document.

4-port standard test set

Test set options

• Standard test set and power range (Option xx0) The 13.5 and 20 GHz versions are available in 2- or 4-ports.

• Configurable test set and extended power range (Option xx5) Adds front panel access loops and one or two 60 dB step

attenuators as shown in the figures below. This provides the capability to improve instrument sensitivity for measuring low-level signals, to reverse the directional couplers to achieve even more dynamic range or to add components and other peripheral instruments for a variety of measurement applications. The 13.5 and 20 GHz versions are available in 2- or 4-ports.

• Configurable test set, extended power range and internal second source (Option x46)

Available with 4-port models only, this option adds an internal second source, nine front panel access loops and two 60 dB step attenuators as shown in the figure below. This provides an additional signal (fixed or swept) for two-tone third-order-intercept (TOI) and intermodulation testing of amplifiers; or it can be used as a fast swept-LO signal for fixed-IF testing of mixers and converters. In either case, sweep speed is more than twenty times faster than using an external source (Option 080 recommended. Please note, Option 080 is needed in order to have independent control of the two internal sources.).

2-port standard test set

Source

Switch/splitter

receivers

Reference

receiver

Reference

receiver

R1 R2

A B

Measurement

Port 1 Port 2

2-port configurable test set and extended power range

PORT 4

PORT 3

PORT 2

PORT 1

Source

Reference receiver

Switch

4-port configurable test set and extended power range

Source out Coupler thru

PORT 4

Coupler arm Receiver D in

Source out Coupler thru

PORT 3

Coupler arm Receiver C in

Receiver B in Coupler arm

PORT 2 Coupler thru Source out

Receiver A in Coupler arm

PORT 1

Coupler thru Source out

Source out Receiver R in

Source

Reference receiver

60 dB

Switch

4-port configurable test set, extended power range and internal second source

Source 1

Source 2

Source

out

Source

Switch/splitter

receivers

Rcvr

Reference

B in

receiver

Cplr arm

60 dB

Rcvr

Cplr thru

Source

SRC

out

Reference

receiver

R1 R2

60 dB

Measurement

Rcvr

SRC

Cplr

out

thru

Cplr

Rcvr

Port 1 Port 2

arm

A in

60 dB 60 dB

A B C D

Test port 2Test port 1

Test port 3

Test port 4

PNA-L (N5230A)

Additional options

□ Time domain (Option 010)

This option enables the PNA Series to view reflection and transmission responses in both time or distance domain. Use time domain to tune filters, gate out the response of fixtures and cables, characterize the impedance of transmission line, and more.

□ Frequency offset (Option 080)

This option enables the PNA Series to set the source frequency independently from where the receivers are tuned. This ability is important for two general classes of devices: mixers (and converters) and amplifiers.

Certification options

□ Commercial calibration certification with test data (Option UK6)

Complete set of measurements which tests unit to manufacturer’s published specifications. Includes calibration label, calibration certificate, and data report. Conforms to ISO 9001.

□ ISO 17025 compliant calibration (Option 1A7)

Complete set of measurements which tests unit to manufacturer’s published specifications. Includes calibration label, ISO 17025 calibration certificate, and data report, measurement uncertainties and guardbands on all customer specifications. Conforms to ISO 17025 and ISO 9001.

□ Scalar-calibrated converter measurements (Option 082)

With a simple setup and calibration, this application provides the highest accuracy for conversion-loss (or gain) measurements by combining one-port and power-meter calibrations to remove mismatch errors. Option 080 required.

□ 4-port measurement application (Option 550)

Enables full 4-port error correction and differential measurements on a 2-port network analyzer with configurable test set (Option x25). External test set required. User installable.

□ N-port capabilities (Option 551)

Adds full N-port error correction and measurement capabilities to any PNA-L network analyzer with configurable test set (Option xx5 or x46). External test set required. User installable.

□ ANSI Z540 compliant calibration (Option A6J)

Complete set of measurements which tests unit to manufacturer’s published specifications. Includes pre- and post-adjustment data with measurement uncertainty information compliant to the ANSI/NCSL Z540 standard.

PNA-X Network Analyzers N5242A , 10 MHz to 26.5 GHz, 2 or 4 Ports

Options

To add options to a product, order the corresponding item number.

Description For N5242A Additional information

Test set

Option 200 2 ports, single source N5242A-200 Option 224 2 ports, add internal 2nd source, combiner and mechanical switches N5242A-224 Requires Options 200, 219 and 080 Option 400 4 ports, dual source N5242A-400 Recommends Option 080 Option 423 4 ports, add internal combiner and mechanical switches N5242A-423 Requires Options 400, 419, and 080

Power configuration

Option 219 2 ports, extended power range and bias-tees N5242A-219 Requires Option 200 Option 419 4 ports, extended power range and bias-tees N5242A-419 Requires Option 400 Option H85 High-power configuration N5242AH85 Requires Option 080 plus Option 224 or 423

Measurement applications

Option 010 Time-domain measurements N5242A-010 Option 029 Fully-corrected noise figure measurements N5242A-029 Requires Option 219, 224, 419 or 423 Option 080 Frequency offset N5242A-080 Option 0821 Scalar-calibrated converter measurements N5242A-082 Requires Option 080 Option 0831 Vector- and scalar-calibrated converter measurements N5242A-083 Requires Option 080 Option 084 Embedded LO measurements N5242A-084 Requires Options 080 and 083 Option 5512 N-port capabilities N5242A-551

Pulse, antenna, mm-wave

Option H08 Pulse measurements N5242A-H08 Requires Option 025 Option 020 Add IF inputs for antenna and mm-wave N5242A-020 Option 021 Add pulse modulator to internal 1st source N5242A-021 Option 022 Add pulse modulator to internal 2nd source N5242A-022 Requires Options 224 or 400 Option 025 Add four internal pulse generators N5242A-025

Accessories

Option 1CM Rack mount kit for use without handles N5242A-1CM Option 1CP Rack mount kit for use with handles N5242A-1CP N1966A Pulse I/O adapter N1966A N4688A USB CD R/W drive N4688A N4689A USB Hub N4689A

Calibration Software

Option 8973 Perpetual license for built-in performance test software for N5242A-897 Agilent inclusive calibration Option 8983 Perpetual license for built-in performance test software for N5242A-898 standards compliant calibration

Calibration documentation

Option 1A7 ISO 17025 compliant calibration N5242A-1A7 Option UK6 Commercial calibration certificate with test data N5242A-UK6 Option A6J ANSI Z540 compliant calibration N5242A-A6J

1. Option 082 is a subset of Option 083, and therefore, they can not be ordered together.

2. When configured as a multiport analyzer with Option 551, the combiner feature of Option 224 or 423 is not available. When configured as a standalone analyzer, the combiner feature is available.

3. Additional hardware required. Please refer to chapter 2 of the Service Guide for required service test equipment.

PNA-X Network Analyzer

The PNA-X is an integrated vector network analyzer featuring a built-in S-parameter test set, one or two synthesized sources used for device stimulus, a hard disk drive, USB interfaces, and a

10.4” LCD touch screen display. The N5242A analyzer has 50 ohm, ruggedized 3.5 mm (m) test ports. Included with each instrument is a mouse, keyboard (U.S. style), and a 1-year return-to-Agilent service warranty.

● N5242A network analyzer, 10 MHz to 26.5 GHz,

2 or 4 ports

Test set options

• 2-port standard test set and power range (Option 200) The standard 2-port test set comes with six front-panel access

loops. The loops provide access to the signal path between (a) the source output and the reference receiver, (b) the source output and directional coupler thru arm and (c) the coupled arm of the directional coupler and the port receiver. The standard test set also includes a solid-state internal RF transfer switch in the R1 reference-receiver path.

• 4-port standard test set, power range and an internal second source (Option 400)

The standard 4-port test set comes with 12 front-panel access loops and a built-in second source. The loops provide access to the signal path between (a) the source output and the reference receiver, (b) the source output and directional coupler thru arm and (c) the coupled arm of the directional coupler and the port receiver. The internal second source provides an additional signal (fixed or swept) for two-tone third-order-intercept (TOI) and intermodulation testing of amplifiers, or it can be used as a fast swept-LO signal for fixed-IF testing of mixers and converters. With two sources, source 1 is accessible through test ports 1 and 2, and source 2 is accessible through test ports 3 and 4. The standard test set also includes a solid-state internal RF transfer switch in the R1 reference-receiver path. Recommends Option 080.

• Extended power range and bias-tees (Option 219, 419)

Adds to the standard test set one 65 dB source attenuator (settable in 5 dB increments), one 35 dB receiver attenuator (settable in 5 dB increments), and one bias-tee to each test port. Option 219 requires Option 200, and Option 419 requires Option 400.

• Add an internal second source, a combiner and mechanical switches to 2-port analyzer (Option 224) Available with 2-port model only, this option adds an internal

second source, a combiner and mechanical switches. The internal second source provides an additional signal (fixed or swept) for two-tone third-order-intercept (TOI) and intermodulation testing of amplifiers, or it can be used as a fast swept-LO signal for fixed-IF testing of mixers and converters. The mechanical switches provide increased flexibility by having rear panel access to signal paths for advanced applications. Access to the second source is available through two output (SMA) connectors on the front panel. Requires Options 200, 219 and 080.

• Add an internal combiner and mechanical switches to 4-port analyzer (Option 423)

Available with 4-port model only, this option adds a combiner and mechanical switches. The mechanical switches provide increased flexibility by having rear panel access to signal paths for advanced applications. Requires Options 400, 419 and 080.

PNA-X Network Analyzer

2-port standard test set and power range (Option 200)

Source 1

OUT 1

OUT 2

Test port 1

2-port extended power range and bias-tees (Option 219, requires Option 200)

Source 1

OUT 1

OUT 2

Test port 2

65 dB

Test port 1

A B

35 dB

65 dB

Test port 2

35 dB

Add an internal second source, a combiner, and mechanical switches to 2-port analyzer (Option 224 requires Options 200, 219 and 080)

OUT 1

Source 1

OUT 2

OUT 1 OUT 2

Source 2

Rear

panel

A B

65 dB

Test port 1

4-port standard test set, power range, and an internal second source (Option 400, recommends Option 080)

35 dB

Source 2 Output 1

Source 2 Output 2

65 dB

Test port 2

35 dB

Source 1

Source 2

OUT 2

Test port 4

D B

Test port 2

Test port 1

OUT 1

OUT 1 OUT 2

Test port 3

4-port extended power range and bias-tees (Option 419, requires Option 400)

Source 1

OUT 1

OUT 1 OUT 2

OUT 2

Source 2

65 dB

Test port 1

35 dB

65 dB

Test port 3

35 dB

65 dB

Test port 4

Add an internal combiner and mechanical switches to 4-port analyzer (Option 423 requires Options 400, 419 and 080)

OUT 1

Source 1

OUT 2

OUT 1 OUT 2

Source 2

D B

35 dB

65 dB

Test port 2

Rear panel

35 dB

65 dB

Test port 1

35 dB

65 dB

Test port 3

35 dB

65 dB

Test port 4

D B

35 dB

65 dB

Test port 2

35 dB

2-port PNA-X with noise ﬁ gure hardware (shown with Options 200, 219, 224, and 029). On 4-port analyzers (Option 419 or 423) with Option 029, ports 1 and 2 are the same as shown here.

PNA-X Network Analyzer

Additional options

□ Pulse measurements (Option H08)

This option provides software to set up and control pulsed-RF measurements with point-in-pulse and pulse-profile capability. The software sets the coefficient of the PNA-X’s digital-IF filters to null out unwanted spectral components, enables the receiver IF gates on the rear panel, controls internal pulse generators (Option 025) or external Agilent pulse generators (the Agilent 81110A series), controls internal pulse modulators (Option 021 and/or 022) or external pulse modulators, and optimization for measurement sensitivity. The measurement software can run on the PNA-X or an external computer. A “.dll” file containing the IF-filter algorithms is included for automated pulsed-RF testing. The N1966A pulse I/O adapter is recommended if using external pulse generators and/or external pulse modulators.

□ Time domain (Option 010)

This option enables the PNA-X to view reflection and transmission responses in time or distance. Use time domain to tune filters, gate out the response of fixtures and cables, characterize the impedance of transmission lines and more.

□ Add IF inputs for antenna and millimeter-wave (Option 020)

This option enables external IF inputs on the rear panel of the PNA-X for applications such as antenna and millimeter-wave test.

□ Add pulse modulator to internal first source (Option 021)

This option enables the internal pulse modulator on source 1. Control of the modulator can also be done via pin 8 of the Pulse I/O D-sub connector on the rear panel of the PNA-X using an external pulse generator, or by using one of the internal pulse generators (Option 025). The N1966A pulse I/O adapter is recommended if using an external pulse generator. (See diagram below for details of the D-sub connector.)

□ Add pulse modulator to internal second source (Option 022)

This option enables the internal pulse modulator on source 2. Control of the modulator can also be done via pin 8 of the Pulse I/O D-sub connector on the rear panel of the PNA-X using an external pulse generator, or by using one of the internal pulse generators (Option 025). The N1966A pulse I/O adapter is recommended if using an external pulse generator. Option 224 or 400 required. (See diagram below for details of the D-sub connector.)

□ Add four internal pulse generators (Option 025)

This option enables four internal pulse generators. These pulse generators can be used to control the internal pulse modulators and internal receiver IF gates, and are also available on pins 10 through 13 of the Pulse I/O D-sub connector on the rear panel of the PNA-X to control external modulators and/or gates. The N1966A pulse I/O adapter is recommended if using external pulse modulators. (See diagram below for details of the D-sub connector.)

8 7 6 5 4 3 2 1

15 14 13 12 11 10 9

Pulse I/O D-sub connector (DB-15 female)

□ Fully-corrected noise figure measurements (Option 029)

This option adds hardware and firmware for high-accuracy noise figure measurements, utilizing Agilent’s unique source correction technique. Using the PNA-X and an Agilent ECal module configured as an impedance tuner, the effects of imperfect system source match are removed, greatly improving the accuracy of the cold-source technique. This approach surpasses the accuracy provided by the Y-factor method. This option requires an N4691B ECal module (m-f recommended) and a 346-series noise source (both must be ordered or supplied separately). During calibration of the analyzer, an additional ECal or mechanical calibration kit is required (also must be ordered or supplied separately). The noise source is only used during calibration of the analyzer. To use the ECal module as a tuner, Option 029 includes a cable (N5242-20137) and 3.5 mm m-f adapter (85052-60013) for use with m-f modules (N4691B-M0F). For use with f-f ECal modules (N4691B-00F), order a 3.5 mm m-m adapter (85052-60014).

□ Frequency offset (Option 080)

This option enables the PNA-X to set the source frequency independently from where the receivers are tuned. This ability is important for measuring amplifiers, mixers, and frequency converters.

□ Scalar-calibrated converter measurements (Option 082)

With a simple setup and calibration, this application delivers the highest accuracy for conversion-loss (or gain) magnitude measurements by combining one-port and power-meter calibrations to remove mismatch errors. This application provides an intuitive and easy-to-use user interface for setting up mixer and converter measurements, with single or dual conversion stages (up to two local oscillators, LO), along with control of up to two external signal generators for use as LO. External synthesizers supported include the Agilent ESG series and the PSG series of signal source families as well as other SCPI controlled signal generators. Option 082 requires Option 080, and can not be ordered with Option 083.

PNA-X Network Analyzer

□ Vector- and scalar-calibrated converter measurements

(Option 083) This converter measurement is a superset and includes not

only the Scalar-Calibrated Converter Measurement (SMC), but also the Vector-Mixer Calibration (VMC). The advanced and unique VMC delivers exceptional conversion loss amplitude and phase accuracy for mixer and converter measurements. This application provides an intuitive and easy-to-use user interface for setting up mixer and converter measurements, with single or dual conversion stages (up to two LO’s), along with control of up to two external signal generators for use as LO.External synthesizers supported include the Agilent ESG series and the PSG series of signal source families as well as other SCPI controlled signal generators. Option 083 requires Option 080, and cannot be ordered with Option 082.

□ Embedded LO Measurements (Option 084)

Advanced software tuning that provides absolute group delay of converters with embedded LOs without the need for access to a common reference signal. The measurement result is the same as locking the DUT LO to the reference mixer LO. (Option 080 and 083 required)

□ N-port capabilities (Option 551)

Adds full N-port error correction and measurement capabilities to the PNA-X network analyzer. External test set is required.

The PULSE IN connectors are for controlling the PNA-X's internal IF gates, which are enabled with Option H08 and used with narrowband detection. The PULSE OUT connectors are from the PNA-X's four internal pulse generators, which are enabled with Option 025. The PULSE SYNC IN connector is used to synchronize the internal pulse generators with an external timing pulse. The RF PULSE MOD IN connector controls the internal pulse modulator(s) which are enabled with Options 021 and 022.

□ High-power test set (Option H85)

With the standard test set conﬁ gurations that include source attenuators, the internal bias tees limit the maximum test port power to +30 dBm. Option H85 removes the bias tees between the source attenuators and the test port couplers. This extends the maximum port power that the analyzer can safely handle to +43 dBm. Option H85 requires Option 080, plus Option 224 or 423.

□ Rack mount kit without handles (Option 1CM)

Adds a rack mount (5063-9217) and rail kit (E3663AC) for use without handles.

□ Rack mount kit with handles (Option 1CP)

Adds a rack mount (5063-9237) with standard supplied handles.

and rail kit (E3663AC) for use

□ Pulse I/O adapter (N1966A)

An adapter for connecting between the Pulse I/O connector on the rear panel of the PNA-X and the coaxial inputs and outputs of external pulse generators and external pulse modulators. Coaxial connectors are SMB-male. (See diagram below for details of the Pulse I/O adapter.

1. When configured as a multiport analyzer with Option 551, the combiner feature of Option 224 or 423 is not available. When configured as a standalone analyzer, the combiner feature is available.

2. The 5063-9237 kit assumes you have the standard handles shipped with the instrument. If you do not have handles, order a 5063-9224 kit.

Pulse I/O adapter (N1966A) simplifies connections

PNA-X Network Analyzer

Certification options

□ Commercial calibration certificate with test data (Option UK6)

Complete set of measurements which tests unit to manufacturer’s published specifications. Includes calibration label, calibration certificate, and data report. Conforms to ISO 9001.

□ ISO 17025 compliant calibration (Option 1A7)

□ ANSI Z540 compliant calibration (Option A6J)

Warranty and service

1 and 3 year warranty and service plans are available at time of instrument purchase. Standard warranty is 1 year.

PNA Network Analyzers1 E8361A/62B/63B/64B, N5250A

PNA (highest performance series) PNA (highest performance series)

E8362B 10 MHz to 20 GHz E8361A 10 MHz to 67 GHz E8363B 10 MHz to 40 GHz N5250A E8364B 10 MHz to 50 GHz

Options

To add options to a product, order the corresponding item number.

Description For E8362B For E8363B For E8364B For E8361A For N5250A Additional system3 information Test set

Option 014 • Configurable test set E8362B-014 E8363B-014 E8364B-014 E8361A-014 Included

Power configuration

Option UNL • Extended power range E8362B-UNL E8364B-UNL E8364B-UNL E8361A-UNL Included Only E8361A and bias-tees requires 014

Option 016 • Add receiver attenuators E8362A-016 E8364A-016 E8364A-016 E8361A-016 E8361A-016 Requires UNL (only E8361A also

Option H85 • High-power configuration E8362B-H85 E8363B-H85 E8364B-H85 Contact Contact Includes 014, 016, Agilent Agilent UNL*4, 080, 081

Non-linear measurements

Option 080 • Frequency offset E8362A-080 E8364A-080 E8364A-080 E8361A-080 Included Requires 014 (E8361A only, 081 required if UNL is also purchased)

Option 081 • Reference receiver switch E8362A-081 E8364A-081 E8364A-081 (only E8361A also requires UNL)

Option 082 • Scalar-calibrated E8362B-082 E8363B-082 E8364B-082 E8361A-082 E8361A-0825 Requires 014, 080 converter measurements

Option 083 • Vector- and scalar-calibrated E8362A-083 E8364A-083 E8364A-083 E8361A-083 E8361A-0835 Requires 014, 080, converter measurements 081(only E8361A also requires UNL)

Option 084 • Embedded LO Measurement E8362B-084 E8363B-083 E8364B-083 E8361A-083 Requires Option 083

Pulse, antenna, mm-wave

Option H08 • Pulsed-RF measurement E8362B-H08 E8363B-H08 E8364B-H08 E8361A-H08 E8361A-H085 Requires 014, 080 capability Option H11 • IF access (for antenna, E8362B-H11 E8363B-H11 E8364B-H11 E8361A-H11 Included Requires 014, UNL, pulsed-RF and mm-wave 080, and 081 measurements)

Measurement features

Option 010 • Time-domain capability E8362A-010 E8363A-010 E8364A-010 E8361A-010 E8361A-010 Options 550 and 551 Option 550 • Option 551 • N-port capabilities E8362B-551 E8363B-551 E8364B-551 E8361A-551 not compatible with N5250A systems

Accessories

Option 1CM • Rack mount kit for use E8362A-1CM E8363A-1CM E8364A-1CM E8361A-1CM E8361A-1CM without handles Option 1CP • Rack mount kit for use E8362A-1CP E8363A-1CP E8364A-1CP E8361A-1CP E8361A-1CP with handles N4688A • USB CD R/W drive N4688A N4688A N4688A N4688A N4688A N4689A • USB Hub N4689A N4689A N4689A N4689A N4689A

Calibration documentation

Option 1A7 • ISO 17025 compliant E8362B-1A7 E8363B-1A7 E8364B-1A7 E8361A-1A7 E8361A-1A7 calibration

Option UK6 • Commercial calibration E8362A-UK6 E8363A-UK6 E8364A-UK6 E8361A-UK6 E8361A-UK6 certificate with test data

Option A6J • ANSI Z540 compliant E8362B-A6J E8363B-A6J E8364B-A6J E8361A-A6J E8361A-A6J calibration

Note: Item numbers may not correspond to product model number. For example, to order the time-domain option on the E8362B, the correct item number to order is E8362A-010.

4-port measurement application

requires 014)

E8362B-550 E8363B-550 E8364B-550 E8361A-550 require 014, and are

Warranty and service One, and three year warranty service plans are available at time of instrument purchase.

The N5250A 110 GHz system carries a full one-year on-site warranty (where available).

Calibration Three year calibration plans are available at time of instrument purchase.

10 MHz to 110 GHz

E8361A-081

Included Requires 014, 080

1. All models are not available in all countries.

2. For more detailed information regarding the 110 GHz network analyzer system, refer to the Agilent Web site: www.agilent.com/find/pna and download the N5250A Technical Overview, literature number 5988-9620EN.

3. The N5250A 110 GHz system also includes an N5260A millimeter-wave test set controller, 1.0 mm combiner assembly, interconnecting cables, and installation and productivity assistance. See page 14 for more details.

4. UNL* does not include bias-tees. Only includes source attenuators.

5. Up to 67 GHz.

Agilent PNA Network Analyzers

The microwave PNA Series instruments are integrated vector network analyzers equipped with a built-in S-parameter test set, synthesized source, hard and floppy disk drives, and LCD display. The E8362B analyzer has two 50 ohm, 3.5 mm (m) test ports. The E8363B and E8364B analyzers have two 50 ohm, 2.4 mm (m) test ports. The E8361A analyzer has two 50 ohm, 1.85 mm (m) test ports. Included with each instrument is a mouse, keyboard (U.S.), and a 1-year return-to-Agilent service warranty.

● E8362B network analyzer, 10 MHz to 20 GHz

● E8363B network analyzer, 10 MHz to 40 GHz

● E8364B network analyzer, 10 MHz to 50 GHz

● E8361A network analyzer, 10 MHz to 67 GHz

● N5250A network analyzer system, 10 MHz to 110 GHz

Options

□ Time-domain capability (Option 010)

For viewing reflection and transmission responses in time or distance domain.

□ Configurable test set (Option 014)

Provides six front panel access loops. Three access loops are for port one and three for port two. The loops provide access to the signal path between (a) the source output and the reference receiver, (b) the source output and directional coupler thru arm and (c) the coupled arm of the directional coupler and the port receiver. This option provides the capability to improve instrument sensitivity for measuring low-level signals, to reverse the directional coupler to achieve even more dynamic range or to add components and other peripheral instruments for a variety of measurement applications. (see PNA Series Microwave Data Sheet literature number 5988-7988EN for a basic block diagram)

□ 4-port measurement application (Option 550)

Enables full 4-port error correction and differential measurements on a 2-port network analyzer with configurable test set. Option 014 required. External test set required.

□ N-port capabilities (Option 551)

Adds full N-port error correction and measurement capabilities to any PNA network analyzer with configurable test set. Option 014 required. External test set required.

□ Extended power range and bias-tees (Option UNL)

Adds two 60 dB step attenuators and two bias-tees to the E8362/3/4B. Adds two 50 dB step attenuators and two bias-tees to the E8361A. A step attenuator and bias-tee set is inserted between the source and test port one and another set between the source and test port two. (see PNA Series Microwave Data Sheet literature number 5988-7988EN for a basic block diagram)

□ Frequency offset (Option 080)

This option enables the PNA Series microwave network analyzers to set the source frequency independently from where the receivers are tuned. This ability is important for two general classes of devices: mixers (and converters) and amplifiers. Option 080 provides a very basic user interface.

□ Reference receiver switch (Option 081)

Option 081 adds a solid-state internal RF transfer switch in the R1 reference-receiver path (see PNA Series Microwave Data Sheet literature number 5988-7988EN for a block diagram). The switch allows the instrument to easily switch between standard S-parameter (non-frequency-offset) measurements and frequency offset measurements such as relative phase or absolute group delay that require an external reference mixer. The user can set the switch manually or remotely, but it is best used with the frequency-converter application (Option 083), where it is controlled automatically during the vector-mixer calibration procedure and subsequent measurements.

□ Scalar-calibrated converter measurements (Option 082)

□ Vector- and scalar-calibrated converter measurements

(Option 083)

This converter measurement adds an intuitive and easy-to-use user interface, advanced calibration choices that provide exceptional amplitude and phase accuracy, and control of external signal sources for use as local oscillators. Mixer calibration techniques include scalar-mixer calibration and vector-mixer calibration (requires Option 081). Finally, the frequency-converter application supports all of Agilent’s major signal source families.

□ Embedded LO Measurements (Option 084)

1. The E8361A can be extended to 110 GHz with IF access (Option H11).

2. Up to 67 GHz.

□ Add receiver attenuators (Option 016)

An attenuator is added between each test port and its corresponding receiver. Two 35 dB step attenuators are added to the E8362/3/4B. Two 50 dB step attenuators are added to the E8361A (see PNA Series Microwave Data Sheet literature number 5988-7988EN for a basic block diagram).

□ Pulsed-RF measurement capability (Option H08)

Provides software to set up and control pulsed-RF measurements with point-in-pulse capability. The software sets the coefficient of the PNA’s digital-IF filter to null out unwanted spectral components, enables the IF gates provided with IF access (Option H11), and controls selected Agilent pulse generators. It can be run on the PNA or an external computer. A “.dll” file containing the IF-filter algorithms is included for automated pulsed-RF testing. The pulsed application is configured to work with the Agilent 81110A series pulse generator.

For more detailed information regarding pulsed measurement capabilities with the microwave PNA refer to the Agilent Web site www.agilent.com/find/pna and download the PNA Series

MW Network Analyzers Configuration Guide for Pulsed Measurements, literature number 5988-9833EN.

□ IF access (Option H11)

Provides hardware to enable antenna, point-in pulse, and broadband millimeter-wave measurements to 110 GHz. For each of the MW PNA’s measurement receivers, IF gates (enabled with pulsed measurement capability, Option H08) and external IF inputs are added. In addition, access to the PNA’s internal RF and LO source is provided for remote mixing applications. For basic antenna measurements, only Option H11 is necessary. Pulsed antenna applications also require the pulsed measurement capability (Option H08). Broadband measurements to 110 GHz, also requires an N5260A millimeter-wave test set controller.

□ High-power test set (Option H85)

This configuration combines options that are often necessary for high power measurements (UNL* only difference between ordering Option H85 versus a combination of the options listed above is the source attenuator option UNL. Standard UNL includes two source attenuators and two bias-tees. Option H85 includes the two source attenuators, but not the bias-tees, as the bias-tees are the power-limiting factor in the network analyzer test set. The maximum power at the test port is +43 dBm (<20 GHz), and +40 dBm (>20 GHz).

Option 080, frequency-offset mode, is included in Option H85 because it manages the phase-locking internally (instead of depending on the R1 receiver). So if you need to use external components in the path of the R1 receiver, it makes the measurements simpler and more robust.

, 014, 016, 080, 081). The

□ Rack mount kit without handles (Option 1CM)

Adds a rack mount (5063-9217) and rail kit (E3663AC) for use without handles.

□ Rack mount kit with handles (Option 1CP)

Adds a rack mount (5063-9237) with standard supplied handles.

Documentation

PNA Online Help system is available within PNA instruments in the following languages: English, German, Spanish, French, Japanese, and Chinese.

The PNA Service Guide and Online Help are available on the Web: http://na.tm.agilent.com/pna

and rail kit (E3663AC) for use

Note: Use external IF access for up to 20 dB more sensitivity when making antenna measurements with a remote mixing configuration. Add Option H08 (Pulsed-RF Measurement Capability) to enable advanced pulsed measurements. Or upgrade to a broadband (10 MHz to 110 GHz) VNA system simply by purchasing an N5260A controller test set with test heads (Option 110, 120, or 130).

1. UNL* does not include bias-tees. Only includes source attenuators.

2. Up to 67 GHz.

3. The 5063-9237 kit assumes you have the standard handles shipped with the instrument. If you do not have handles, order a 5063-9224 kit.

Certification options

□ Commercial calibration certificate with test data (Option UK6)

Complete set of measurements which tests unit to manufacturer’s published specifications. Includes calibration label, calibration certificate, and data report. Conforms to ISO 9001.

□ ISO 17025 compliant calibration (Option 1A7)

□ ANSI Z540 compliant calibration (Option A6J)

Warranty and service

1 and 3 year warranty and service plans are available at time of instrument purchase. Standard warranty is 1 year.

E8361A/62B/63B/64B Configuration Details

Selecting the correct mixer-test configuration:

Most mixer or converter test applications require Options 014, 080, and 082 for conversion loss/gain, or Options 014, 080, 081 and 083 for conversion loss/gain and phase/delay measurements. If you want to create and automate your own custom frequencyoffset measurements (for example, intermodulation distortion), you may only need Options 014 and 080. For converters that require input power below -27 dBm, or for devices that have a large amount of LO feedthrough (like an unfiltered mixer), Option UNL, which adds source attenuators, is highly recommended. Besides allowing lower input power levels, these attenuators improve the isolation between the PNA’s internal source and LO leakage signals, helping to prevent source-unleveled errors. For devices that put out signals near or above the receiver’s compression levels (which varies between –3 and +5 dBm, depending on the model and frequency), Option 016 is recommended, which adds receiver attenuators. Finally, Option 010, which adds time-domain analysis, is very useful for gating out unwanted, time-delayed responses which often occur when measuring mixers.

Calibration

3 year calibration plans are available at time of instrument purchase. Contact your local Agilent sales office for details.

Product services

Agilent product services provide tailored assistance related to a specific need or application. Product services enable you to quickly learn how Agilent instruments operate, their capabilities, and how to apply that knowledge to achieve your specific measurement goals. PNA series services available include:

• Remote scheduled productivity assistance

• 1 Day of start-up assistance

• Daily productivity assistance

• PNA operator training for 8 students at your business site

• PNA operator web classes for 1 student

• Custom services to be qualified by an Agilent technical consultant

Microwave PNA Network Analyzer

Simplified test set block diagrams

Standard power range

Source

Switch/splitter

Reference

receiver

R1 R2

A B

Measurement

receivers

Port 1 Port 2

Extended power range and bias-tees (Option UNL)

Source

Switch

Reference

receiver

Reference

receiver

R1 R2

Source attenuator

Port 1 Port 2

1. Source attenuator for E8362/3/4B is 60 dB in 10 dB steps. Source attenuator for E8361A is 50 dB in 10 dB steps.

Measurement

receivers

Reference

receiver

Source attenuator

Bias-teeBias-tee

Microwave PNA Network Analyzer

Simplified test set block diagrams – continued

Configurable test set (Option 014)

Source

Switch

Reference

receiver

R1 R2

Measurement

receivers

Port 1 Port 2

Configurable test set with extended power range and bias-tees (Option UNL and 014)

Reference

receiver

Source

Switch

Reference

receiver

R1 R2

Source attenuator

Bias-tee

1. Source attenuator for E8362/3/4B is 60 dB in 10 dB steps. Source attenuator for E8361A is 50 dB in 10 dB steps.

Port 1 Port 2

Measurement

receivers

Reference

receiver

Source attenuator

Bias-tee

Microwave PNA Network Analyzer

Simplified test set block diagrams – continued

Fully optioned, active device or mixer/converter test configuration (Options 014, UNL, 016, 080,

081)

Source

Switch/splitter/leveler

Option 081

Source

out

Rcvr R1

Source attenuator

10 dB steps

Bias-tee

SRC

out

Cplr thru

Rcvr B

Reference

receiver

Source attenuator

10 dB steps

Bias-tee

Cplr arm

Reference

receiver

R1 R2

Measurement

receivers

Receiver

attenuator

Cplr

arm

Rcvr A

Cplr thru

SRC

out

Rcvr R2

Source

out

1. Source attenuator for E8362/3/4B is 60 dB in 10 dB steps. Source attenuator for E8361A is 50 dB in 10 dB steps.

2. Receiver attenuator for E8362/3/4B is 35 dB in 5 dB steps. Receiver attenuator for E8361A is 50 dB in 10 dB steps.

Microwave PNA Network Analyzer

Simplified test set block diagrams – continued

High-power configuration (Option H85)

Source

Switch/splitter/leveler

+30

dBm

Reference

Source attenuator

+15

dBm

Option 081

Source attenuator

10 dB steps

Reference

+15

receiver

R1 R2

dBm

+30

dBm

Measurement

receivers

+15

dBm

receiver

+15 dBm

+30

dBm

10 dB steps

Source

out

Rcvr R1

SRC

out

Cplr thru

+40 dBm

Cplr

arm

+30 dBm

Rcvr A

Receiver

attenuator

D U T

Rcvr B

+30

dBm

Cplr arm

+40

dBm

Cplr thru

SRC

out

Rcvr R2

Source

out

preamp

Power levels shown on the diagram are damage levels. At a minimum, keep power levels 6 dB below damage level. For optimal performance, keep the power level incident upon the receivers -20 dBm or less. This will keep the receivers out of compression.

1. Source attenuator for E8362/3/4B is 60 dB in 10 dB steps. Source attenuator for E8361A is 50 dB in 10 dB steps.

2. Receiver attenuator for E8362/3/4B is 35 dB in 5 dB steps. Receiver attenuator for E8361A is 50 dB in 10 dB steps.

Microwave PNA Network Analyzer

Simplified test set block diagrams – continued

Fully optioned, pulse-RF, antenna, or mm-wave configuration (Options 014, UNL, 016, 080, 081, H11)

Aux RF out

(2 to 20 GHz)

Aux LO out

(2 to 20 GHz)

Rear

8.33 MHz reference

Phase-locked loop

Offset receiver

Offset

Option 081

Option 080

ADC

Option UNL

ADC

Option UNL

Option H11

IF gate

External

IF in

External

IF in

IF gate

Option H11

YIG source

Multipliers

(1, 2)

tune

Multipliers (1, 2, 4)

Option H11

IF gate

External

Option UNL

External

IF in

IF gate

Option H11

Option UNL

Option H11

ADC

IF in

ADC

Option 016

Receiver

Front

Port 1 Port 2

1. Option H11: IF-gate controls and external-IF inputs are accessed on rear panel. IF gates are enabled with Option H08. External-IF input frequency is 8.33 MHz.

attenuators

Option 014

Option 014Option 014

N5250A Configuration Details

□ N5250A MM PNA system

E8361A MW PNA with the following options:

• Configurable test set – Option 014 (required)

• Extended power range and bias-tees – Option UNL (required)

• Frequency-offset mode – Option 080 (required)

• Reference channel switch – Option 081 (required)

• IF access – Option H11 N5260A millimeter-wave test set controller with test heads

• 67 to 110 GHz test heads

• 1.0 mm combiner assembly

• Interconnecting cables

• Installation and productivity assistance

Additional options available:

• Millimeter-wave modules with bias-tees N5250A Option 017

• Millimeter-wave modules with bias-tees and port 2 attenuator - N5250A Option 018

• Receiver attenuator – Option 016

• Time-domain capability – Option 010

• Pulsed-RF measurement capability – Option H08

• Scalar-calibrated converter measurements – Option 082

• Frequency converter application – Option 083 Factory integration of the N5250A system integrates the E8361A with Option H11 and the N5260A millimeter-wave controller with test heads. On-site installation is included, and the entire system carries a full one-year, on-site warranty (where available).

, 10 MHz to 110 GHz, includes:

Banded waveguide solution

In order to assemble a banded waveguide solution, the following components are needed:

• Microwave PNA network analyzer (E8361A or E8362/3/4B) with the following options:

• IF access - Option H11

• Configurable test set - Option 014

• Extended power range and bias-tees - Option UNL

• Frequency-offset mode - Option 080

• Reference channel switch - Option 081

• Millimeter-wave test set controller (N5260A) with no options

• A set of waveguide modules:

• N5260AW15, 50 to 75 GHz

• N5260AW12, 60 to 90 GHz

• N5260AW10, 75 to 110 GHz

• N5260AW08, 90 to 140 GHz

• N5260AW06, 110 to 170 GHz

• N5260AW05, 140 to 220 GHz

• N5260AW03, 220 to 325 GHz

NOTE: To significantly improve system dynamic range above 220 GHz, Agilent strongly recommends adding two external synthesizers such as Agilent’s PSG Series signal generators; one for the RF signal, and one for the LO signal.

For more detailed information, see PNA Millimeter-wave Technical Overview, literature number 5988-9620EN.

Option Descriptions

□ Millimeter-wave modules with bias-tees (N5250A Option 017)

Adds 67 GHz bias-tees to the combiner assembly between the input to the combiner and the 67 GHz coupler. The bias-tees have tri-axial connectors for force, sense, and ground. Positioning the bias-tees close to the DUT greatly improves stability for on-wafer and in-fixture devices. The bias-tees added for this option have a voltage rating of 40 volts and a maximum of 0.5 amps.

□ Millimeter-wave modules with bias-tees and port 2

attenuator (N5250A Option 018)

1. For more detailed information regarding the 110 GHz network analyzer system, refer to the Agilent Web site: www.agilent.com/find/pna and download the N5250A Technical Overview, literature number 5988-9620EN.

2. Up to 67 GHz.

3. Cascade Microtech is an Agilent Channel Partner.

On-wafer applications

For on-wafer applications, Cascade Microtech3 provides complete probing systems using the N5250A. These include both new probing systems and upgrades to existing Cascade Microtech products. Cascade can also provide on-wafer verification and probing system training. Once the N5250A system is verified in coax, Cascade Microtech will verify the system through its wafer probes.

N5250A Millimeter-Wave PNA Block Diagram

With Option 017, the signal is routed out of the PNA from the front panel jumpers rather than the ports. Without Option 017, the signal is routed from the front panel ports to the combiner assembly, allowing access to the PNA’s internal bias-tees.

Receiver A

30 in.

76.2 cm

48 in.

121.9 cm

N5260A

with

test heads

67 to 110 GHz

waveguide head

with Option H11

Port 1

LO RF

IF1 IF2 IF3 IF4

Test set controller

(Option 017)

Te st

port 1

Combiner assembly

E8361A

Optional bias-tees

Port 2

Te st

port 2

Combiner assembly

Test set I/O

Receiver B

67 to 110 GHz

waveguide head

30 in.

76.2 cm

48 in.

121.9 cm

PNA test set block diagram

Simplified receiver block diagram

IF multiplexer

(from LO distribution.

See test set

block diagram)

External IF input

IF gating

A/D

SMA

connectors

LO: 2 to 20 GHz

LO distribution to

each receiver

BNC

connectors

R1 IF

50 dB

Bias-tee

To IF multiplexer

(see Figure 5)

Reference

receiver

Port 1 Port 2

connectors

RF: 2 to 20 GHz

50 dB 50 dB

Option 016

receiver

attenuators

SMA

Reference

receiver

BNC

connectors

gate

To IF multiplexer

(see Figure 5)

gate

50 dB

Bias-tee

Measurement Accessories

A complete list of RF and microwave test accessories is available on our Web site:

www.agilent.com/find/accessories

Accessories are available in these connector types: 50 ohm Type-N, 3.5 mm, 7 mm, 2.4 mm, 2.92 mm, 1.85 mm, 1.0 mm, and waveguide. Test port cables and a calibration kit should be added for a complete measurement system. A verification kit is used to verify corrected system performance.

Cables and adapter sets

Agilent offers cables in the following types:

• single cables in semi-rigid and flexible

• cable sets in semi-rigid and flexible

There are also adapter sets available that protect the test port and convert the port to the desired connector interface. These kits contain:

• one male adapter

• one female adapter

To attain the best mechanical rigidity for device connection, use a single cable and the appropriate special adapter set. To attain the greatest flexibility for device connection, use a cable set.

Network analyzer

test set

Network analyzer

test set

Calibration kits

Coaxial measurements

Mechanical calibration kits include standards, such as opens, shorts and loads, which are measured by the network analyzer for increased measurement accuracy.

Electronic calibration (ECal) kits replace mechanical calibration standards with one solid-state calibration module that is controlled by the network analyzer via USB, to present many different impedances to the test ports. A full two-port calibration can be performed quickly with a single connection. This technique reduces operator errors and connector wear and abrasion.

Choose a calibration kit for each connector type to be used.

Economy, includes:

• open standards (male and female)

• short standards (male and female)

• fixed-termination standards (male and female)

Standard, includes the devices in the economy kit and adds:

• sliding load standards (male and female) or a series of offset shorts

Precision, includes the devices in the economy kit and adds:

• 50 ohm airline(s) for TRL calibration

• TRL adapters

Device

under

test

Test port

adapter

Single cable

Cable set

Device

under

test

Waveguide measurements

For waveguide measurements, Agilent offers mechanical calibration kits that include:

• waveguide-to-coax adapters (X, P, K, R, Q, U, V)

• precision waveguide section

• flush short circuit

• fixed terminations

• straight section

For devices with 1.0 mm connectors

For devices with 1.85 mm connectors

Mechanical calibration/verification kit

□ 85059A DC to 110 GHz precision calibration/verification

kit. Includes: 85059-60003 1.00 mm (m) short 2.450 mm 85059-60007 1.00 mm (f) short 2.450 mm 85059-60004 1.00 mm (m) short 3.000 mm 85059-60008 1.00 mm (f) short 3.000 mm 85059-60002 1.00 mm (m) short 1.825 mm 85059-60006 1.00 mm (f) short 1.825 mm 85059-60001 1.00 mm (m) short 1.300 mm 85059-60005 1.00 mm (f) short 1.300 mm 85059-60009 1.00 mm male open 85059-60010 1.00 mm female open 85059-60019 1.00 mm male load 85059-60020 1.00 mm female load 85059-60021 1.00 mm lossy delay line 11920-60001 1.00 mm (m) to 1.00 mm (m) adapter 11920-60002 1.00 mm (f) to 1.00 mm (f) adapter 11920-60003 1.00 mm (m) to 1.00 mm (f) adapter 11500-60001 1.00 mm (f) to 1.00 mm (f) 8.8 cm cable 85059-60016 1.00 mm mismatch thru adapter for verification 85059-60017 1.00 mm matched thru adapter for verification 8710-2079 6 mm, 4 in-lb torque wrench 8710-2156 6 mm open end wrench

Cables

□ 11500I 1.0 mm (f-f) test port cable (8.8 cm) □ 11500J 1.0 mm (m-f) test port cable (16.0 cm) □ 11500K 1.0 mm (m-f) test port cable (20.0 cm) □ 11500L 1.0 mm (m-f) test port cable (24.0 cm)

Adapter set

□ V281C 1.0 mm(f) to V-band waveguide adapter □ V281D 1.0 mm (m) to V-band waveguide adapter □ W281C 1.0 mm (f) to W-band waveguide adapter □ W281D 1.0 mm (m) to W-band waveguide adapter □ 11920A 1.0 mm (m) to 1.0 mm (m) adapter □ 11920B 1.0 mm (f) to 1.0 mm (f) adapter □ 11920C 1.0 mm (m) to 1.0 mm (f) adapter □ 11921A 1.0 mm (m) to 1.85 mm (m) adapter □ 11921B 1.0 mm (f) to 1.85 mm (f) adapter □ 11921C 1.0 mm (m) to 1.85 mm (f) adapter □ 11921D 1.0 mm (f) to 1.85 mm (m) adapter □ 11922A 1.0 mm (m) to 2.4 mm (m) adapter □ 11922B 1.0 mm (f) to 2.4 mm (f) adapter □ 11922C 1.0 mm (m) to 2.4 mm (f) adapter □ 11922D 1.0 mm (f) to 2.4 mm (m) adapter □ 11923A 1.0 mm (f) connector launch assembly

Mechanical calibration kits

□ 85058B standard: DC to 67 GHz.

Includes: 85058-60101 1.85 mm (m) short 5.4 mm 85058-60102 1.85 mm (m) short 6.3 mm 85058-60103 1.85 mm (m) short 7.12 mm 85058-60104 1.85 mm (m) short 7.6 mm 85058-60105 1.85 mm (f) short 5.4 mm 85058-60106 1.85 mm (f) short 6.3 mm 85058-60107 1.85 mm (f) short 7.12 mm 85058-60108 1.85 mm (f) short 7.6 mm 85058-60109 1.85 mm male open 85058-60110 1.85 mm female open 85058-60111 1.85 mm male load 85058-60112 1.85 mm female load 85058-60113 1.85 mm (m) to 1.85 mm (m) adapter 85058-60114 1.85 mm (f) to 1.85 mm (f) adapter 85058-60115 1.85 mm (m) to 1.85 mm (f) adapter

□ 85058E economy: DC to 67 GHz.

Includes: 85058-60101 1.85 mm (m) short 5.4 mm 85058-60105 1.85 mm (f) short 5.4 mm 85058-60109 1.85 mm male open 85058-60110 1.85 mm female open 85058-60123 1.85 mm male load 85058-60124 1.85 mm female load 85058-60113 1.85 mm (m) to 1.85 mm (m) adapter 85058-60114 1.85 mm (f) to 1.85 mm (f) adapter 85058-60115 1.85 mm (m) to 1.85 mm (f) adapter

Electronic calibration kits

□ N4694A Microwave ECal: 10 MHz to 67 GHz, 2 ports.

Includes: Option M0F module with: N4694-60001 1.85 mm (f) to 1.85 mm (m) ECal module Option 00M module with: N4694-60002 1.85 mm (m) to 1.85 mm (m) ECal module Option 00F module with: N4694-60003 1.85 mm (f) to 1.85 mm (f) ECal module Option 00A adds: 85058-60113 1.85 mm (m) to 1.85 mm (m) adapter 85058-60114 1.85 mm (f) to 1.85 mm (f) adapter

Cables

□ N4697E

96.5 cm, 38 inches

□ N4697F

One 1.85 mm (f) to 1.85 mm (f) cable, 62.2 cm,

24.5 inches, p/n N4697-60100 One 1.85 mm (f) to 1.85 mm (m) cable, 62.2 cm,

24.5 inches, p/n N4697-60200

□ N4697H

1.85 mm (m), 62.2 cm, 24.5 inches

Single, flexible: 1.85 mm (f) to 1.85 mm (f),

Set, flexible:

Single, flexible: 1.85 mm (f) to

□ N4421B-B67 Set of 4, flexible: 1.85 mm (f) to

1.85 mm (m), 91.4 cm, 36 inches

1. For on-wafer applications, two 11500J/K/L cables are required; one cable for each test port.

2. Special rugged female connector specifically for connecting to the network analyzer test port, but does not mate with a standard male connector.

Adapter set

□ 85130H 1.85 mm

to 1.85 mm

For devices with 2.4 mm connectors

Mechanical calibration kits

□ 85056A standard: DC to 50 GHz.

Includes: 00901-60003 2.4 mm (m) fixed broadband load 00902-60004 2.4 mm (f) fixed broadband load 00915-60003 2.4 mm (m) sliding load 00915-60004 2.4 mm (f) sliding load 85056-60005 2.4 mm (m) to 2.4 mm (m) adapter 85056-60006 2.4 mm (f) to 2.4 mm (f) adapter 85056-60007 2.4 mm (m) to 2.4 mm (f) adapter 85056-60020 2.4 mm (m) short 85056-60021 2.4 mm (f) short 85056-60022 2.4 mm (m) open 85056-60023 2.4 mm (f) open

□ 85056D economy: DC to 50 GHz.

Includes: 00901-60003 2.4 mm (m) fixed broadband load 00902-60004 2.4 mm (f) fixed broadband load 85056-60005 2.4 mm (m) to 2.4 mm (m) adapter 85056-60006 2.4 mm (f) to 2.4 mm (f) adapter 85056-60007 2.4 mm (m) to 2.4 mm (f) adapter 85056-60020 2.4 mm (m) short 85056-60021 2.4 mm (f) short 85056-60022 2.4 mm (m) open 85056-60023 2.4 mm (f) open

Electronic calibration kits

□ N4693A Microwave ECal: 10 MHz to 50 GHz, 2 ports.

Includes: Option M0F module with: N4693-60001 2.4 mm (f) to 2.4 mm (m) ECal module Option 00M module with: N4693-60002 2.4 mm (m) to 2.4 mm (m) ECal module Option 00F module with: N4693-60003 2.4 mm (f) to 2.4 mm (f) ECal module Option 00A adds: 85056-60005 2.4 mm (m) to 2.4 mm (m) adapter 85056-60007 2.4 mm (f) to 2.4 mm (f) adapter

Cables

□ 85133C

81 cm, 32 inches

□ 85133D

One 2.4 mm (f) to 2.4 mm (m), 53 cm, 21 inches, p/n 85133-60001 One 2.4 mm (f) to 2.4 mm (f), 53 cm, 21 inches, p/n 85133-60002

□ 85133E

97 cm, 38 inches

□ 85133F

One 2.4 mm (f) to 2.4 mm (f), 63 cm, 25 inches, p/n 85133-60016 One 2.4 mm (f) to 2.4 mm (m), 63 cm, 25 inches, p/n 85133-60017

single, semi-rigid: 2.4 mm (f) to PSC-2.4 mm (f),

set, semi-rigid:

single, flexible: 2.4 mm (f) to PSC-2.4 mm (f),

set, flexible:

□ 85133G

53 cm, 21 inches

□ 85133H

63 cm, 25 inches

Single, semi-rigid: 2.4 mm (f) to 2.4 mm (m),

Single, flexible: 2.4 mm (f) to 2.4 mm (m),

□ N4421A-B20 Set of 4, flexible: 2.4 mm (f) to 2.4 mm (m),

91.4 cm, 36 inches

Adapter set

□ 85130G 2.4 mm

to 2.4 mm

For devices with K connectors (2.92 mm)

Mechanical calibration kits

□ 85056K 2.92/2.4 economy: DC to 40/50 GHz.

Includes: 00901-60003 2.4 mm (m) fixed broadband load 00902-60004 2.4 mm (f) fixed broadband load 00915-60003 2.4 mm (m) sliding load (Option 001) 00915-60004 2.4 mm (f) sliding load (Option 001) 11904-60001 2.4 mm (m) to 2.92 mm (m) adapter 11904-60002 2.4 mm (f) to 2.92 mm (f) adapter 11904-60003 2.4 mm (m) to 2.92 mm (f) adapter 11904-60004 2.4 mm (f) to 2.92 mm (m) adapter 85056-60005 2.4 mm (m) to 2.4 mm (m) adapter 85056-60006 2.4 mm (f) to 2.4 mm (f) adapter 85056-60007 2.4 mm (m) to 2.4 mm (f) adapter 85056-60020 2.4 mm (m) short 85056-60021 2.4 mm (f) short 85056-60022 2.4 mm (m) open 85056-60023 2.4 mm (f) open

Electronic calibration kits

□ N4692A Microwave ECal: 10 MHz to 40 GHz, 2 ports.

Includes: Option M0F module with:

N4692-60001 2.92 mm (f) to 2.92 mm (m) ECal module Option 00M module with: N4692-60002 2.92 mm (m) to 2.92 mm (m) ECal module Option 00F module with: N4692-60003 2.92 mm (f) to 2.92 mm (f) ECal module Option 00A adds: N4692-60021 2.92 mm (m) to 2.92 mm (m) adapter

N4692-60022 2.92 mm (f) to 2.92 mm (f) adapter

Cables

□ 85133C

81 cm, 32 inches

□ 85133D

One 2.4 mm (f) to 2.4 mm (m), 53 cm, 21 inches, p/n 85133-60001 One 2.4 mm (f) to 2.4 mm (f), 53 cm, 21 inches, p/n 85133-60002

□ 85133E

97 cm, 38 inches

□ 85133F

One 2.4 mm (f) to 2.4 mm (f), 63 cm, 25 inches, p/n 85133-60016 One 2.4 mm (f) to 2.4 mm (m), 63 cm, 25 inches, p/n 85133-60017

single, semi-rigid: 2.4 mm (f) to PSC-2.4 mm (f),

set, semi-rigid:

single, flexible: 2.4 mm (f) to PSC-2.4 mm (f),

set, flexible:

1. Special rugged female connector specifically for connecting to the network analyzer test port, but does not mate with a standard male connector.

□ 85133G

53 cm, 21 inches

□ 85133H

63 cm, 25 inches

Single, semi-rigid: 2.4 mm (f) to 2.4 mm (m),

Single, flexible: 2.4 mm (f) to 2.4 mm (m),

□ N4421A-B20 Set of 4, flexible: 2.4 mm (f) to 2.4 mm (m),

91.4 cm, 36 inches

Adapters

□ 11904A 2.4 mm (m) to K (m) □ 11904B 2.4 mm (f) to K (f) □ 11904C 2.4 mm (m) to K (f) □ 11904D 2.4 mm (f) to K (m) □ 11904S 2.4 mm to K adapter set

For devices with 3.5 mm or SMA connectors

Mechanical calibration kits

□ 85052B standard: DC to 26.5 GHz.

Includes: 00902-60003 3.5 mm (m) fixed load 00902-60004 3.5 mm (f) fixed load 00911-60019 3.5 mm (m) sliding load 00911-60020 3.5 mm (f) sliding load 85052-60006 3.5 mm (m) short 85052-60007 3.5 mm (f) short 85052-60008 3.5 mm (m) open 85052-60009 3.5 mm (f) open 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter 85052-60013 3.5 mm (f) to 3.5 mm (m) adapter 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter

□ 85052C precision TRL: DC to 26.5 GHz.

Includes: 00902-60003 3.5 mm (m) fixed load 00902-60004 3.5 mm (f) fixed load 85052-60006 3.5 mm (m) short 85052-60007 3.5 mm (f) short 85052-60008 3.5 mm (m) open 85052-60009 3.5 mm (f) open 85052-60032 3.5 mm (f) to 3.5 mm (f) adapter 85052-60033 3.5 mm (m) to 3.5 mm (m) adapter 85052-60034 3.5 mm (f) to 3.5 mm (m) adapter 85052-60035 3.5 mm short TRL line 85052-60036 3.5 mm long TRL line

□ 85052D economy: DC to 26.5 GHz.

Includes: 00902-60003 3.5 mm (m) fixed load 00902-60004 3.5 mm (f) fixed load 85052-60006 3.5 mm (m) short 85052-60007 3.5 mm (f) short 85052-60008 3.5 mm (m) open 85052-60009 3.5 mm (f) open 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter 85052-60013 3.5 mm (f) to 3.5 mm (m) adapter 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter

Electronic calibration kits

□ 85093C RF ECal: 300 kHz to 9 GHz, 2 ports

Standard module includes Option M0F with: 85093-60008 3.5 mm (f) to 3.5 mm (m) ECal module Option 00F module with: 85093-60010 3.5 mm (f) to 3.5 mm (f) ECal module Option 00M module with: 85093-60009 3.5 mm (m) to 3.5 mm (m) ECal module Option 00A adds: 85052-60012 3.5 mm (m) to 3.5 mm (m) adapter 85052-60014 3.5 mm (f) to 3.5 mm (f) adapter

85093C-xxx mixed-connector options:

Port A option Port B option Type (f) (m) Type (f) (m) Type (f) (m)

3.5 mm 101 102 Type-N 203 204 7-16 205 206 50 ohm

□ N4431B Microwave ECal: 300 kHz to 13.5 GHz, 4 ports.

Includes: Option 010 module with: N4431-60006 4 x 3.5 mm (f) ECal module

N4431B-xxx mixed-connector options:

Connector Port A Port B Port C Port D type option option option option

3.5 mm (f) 101 201 301 401

3.5 mm (m) 102 202 302 402

Type-N 50 ohm (f) 103 203 303 403

Type-N 50 ohm (m) 104 204 304 404

7-16 (f) 105 205 305 405

7-16 (m) 106 206 306 406

□ N4433A Microwave ECal: 300 kHz to 20 GHz, 4 ports.

Includes:

□ Option 010 module with:

N4433-60003 4 x 3.5 mm (f) ECal module

N4433A-xxx mixed-connector options:

Connector Port A Port B Port C Port D type option option option option

3.5 mm (f) 101 201 301 401

3.5 mm (m) 102 202 302 402

□ N4691B Microwave ECal: 300 kHz to 26.5 GHz, 2 ports.

Includes: Option M0F module with: N4691-60001 3.5 mm (f) to 3.5 mm (m) ECal module Option 00M module with: N4691-60002 3.5 mm (m) to 3.5 mm (m) ECal module Option 00F module with: N4691-60003 3.5 mm (f) to 3.5 mm (f) ECal module Option 00A adds: 85052-60012 3.5 mm (m) to 3.5 mm (m) adapter 85052-60014 3.5 mm (f) to 3.5 mm (f) adapter

Cables

□ 85131C

81 cm, 32 inches

□ 85131D

One 3.5 mm (f) to 3.5 mm (m), 53 cm, 21 inches, p/n 85131-60009 One 3.5 mm (f) to PSC-3.5 mm (f), 53 cm, 21 inches, p/n 85131-60010

□ 85131E

96.5 cm, 38 inches

□ 85131F

One 3.5 mm (f) to 3.5 mm (m), 62.2 cm, 24.5 inches, p/n 85131-60012 One 3.5 mm (f) to PSC-3.5 mm (f), 62.2 cm, 24.5 inches, p/n 85131-60013

□ 85131G

53 cm, 21 inches

□ 85131H

62.2 cm, 24.5 inches

□ 85134C

81 cm, 32 inches

□ 85134D

One 2.4 mm (f) to PSC-3.5 mm (f), 53 cm, 21 inches, p/n 85134-60002 One 2.4 mm (f) to PSC-3.5 mm (m), 53 cm, 21 inches, p/n 85134-60001

□ 85134E

96 cm, 38 inches

□ 85134F

One 2.4 mm (f) to PSC-3.5 mm (f), 53 cm, 21 inches, p/n 85134-60004 One 2.4 mm (f) to PSC-3.5 mm (m), 53 cm, 21 inches, p/n 85134-60003

□ 85134G

53 cm, 21 inches

□ 85134H

53 cm, 21 inches

single, semi-rigid: 3.5 mm (f) to PSC-3.5 mm (f),

set, semi-rigid:

single, flexible: 3.5 mm (f) to PSC-3.5 mm (f),

set, flexible:

single, semi-rigid: 3.5 mm (f) to 3.5 mm (m),

single, flexible: 3.5 mm (f) to 3.5 mm (m),

single, semi-rigid: PSC-3.5 mm (f) to 2.4 mm (f),

set, semi-rigid:

single, flexible: PSC-3.5 mm (f) to 2.4 mm (f),

set, flexible:

single, semi-rigid: 2.4 mm (f) to PSC-3.5 mm (m),

single, flexible: 2.4 mm (f) to PSC-3.5 mm (m),

□ N4419A-B20 set of 4, flexible: 3.5 mm (m) to 3.5 mm (f),

91.4 cm, 36 inches

□ Z5623A-B20 set of 4, flexible: 3.5 mm (m) to 3.5 mm (m),

91.4 cm, 36 inches (phase-matched)

Adapter sets

□ 85130C 3.5 mm □ 85130D 3.5 mm □ 85130F 2.4 mm

to Type-N

to 3.5 mm

1. Special rugged female connector specifically for connecting to the network analyzer test port, but does not mate with a standard male connector.

2. For use with E8362A or B.

For devices with Type-N connectors

Electronic calibration kits

Mechanical calibration kits

□ 85054B standard: DC to 18 GHz.

Includes: 00909-60011 Type-N (m) fixed lowband load 00909-60012 Type-N (f) fixed lowband load 85054-60025 Type-N (m) short 85054-60026 Type-N (f) short 85054-60027 Type-N (m) open 85054-60028 Type-N (f) open 85054-60031 Type-N (f) to 7mm adapter 85054-60032 Type-N (m) to 7mm adapter 85054-60037 Type-N (f) to Type-N (f) adapter 85054-60038 Type-N (m) to Type-N (m) adapter 85054-80010 Type-N (f) sliding load 85054-80009 Type-N (m) sliding load 85054-60050 Type-N (f) connector gage 85054-60052 Type-N (f) gage master 85054-60051 Type-N (m) connector gage 85054-60053 Type-N (m) gage master

□ 85054D economy: DC to 18 GHz.

Includes: 85054-60025 Type-N (m) short 85054-60026 Type-N (f) short 85054-60027 Type-N (m) open 85054-60028 Type-N (f) open 85054-60031 Type-N (f) to 7mm adapter 85054-60032 Type-N (m) to 7mm adapter 85054-60037 Type-N (f) to Type-N (f) adapter 85054-60038 Type-N (m) to Type-N (m) adapter 85054-60046 Type-N (m) fixed load 85054-60047 Type-N (f) fixed load

□ N4431B Microwave ECal: 300 kHz to 13.5 GHz, 4 ports.

Includes: Option 020 module with: N4431-60007 4 x Type-N (f) ECal module

N4431B-xxx mixed-connector options:

Connector Port A Port B Port C Port D type option option option option

3.5 mm (f) 101 201 301 401

3.5 mm (m) 102 202 302 402

Type-N 50 ohm (f) 103 203 303 403

Type-N 50 ohm (m) 104 204 304 404

7-16 (f)1 105 205 305 405

7-16 (m)1 106 206 306 406

□ N4432A Microwave ECal: 300 kHz to 18 GHz, 4 ports.

Includes: Option 020 module with: N4432-60003 4 x Type-N (f) ECal module

N4432A-xxx mixed-connector options:

Connector Port A Port B Port C Port D type option option option option

3.5 mm (f) 101 201 301 401

3.5 mm (m) 102 202 302 402

Type-N 50 ohm (f) 103 203 303 403

Type-N 50 ohm (m) 104 204 304 404

□ N4690B Microwave ECal: 300 kHz to 18 GHz, 2 ports.

Includes: Option M0F module with: N4690-60001 Type-N (f) to Type-N (m) ECal module Option 00M module with: N4690-60002 Type-N (m) to Type-N (m) ECal module Option 00F module with: N4690-60003 Type-N (f) to Type-N (f) ECal module Option 00A adds: 85054-60037 Type-N (f) to Type-N (f) adapter 85054-60038 Type-N (m) to Type-N (m) adapter

1. Limits ECal module high frequency to 7.5 GHz.

2. Special rugged female connector specifically for connecting to the network analyzer test port, but does not mate with a standard male connector.

Cables

Use the test port cables recommended for devices with 7 mm connectors, and 7 mm to Type-N adapters that are from the 85054B/D Type-N calibration kit (see 7 mm connector section).

For devices with 7 mm connectors

For devices with waveguide

Mechanical calibration kits

□ 85050B standard: DC to 18 GHz.

Includes: 00909-60008 7 mm coax termination 85050-60006 7 mm fixed broadband load 85050-80007 7 mm short 85050-80010 7 mm open 85050-80011 7 mm sliding load

□ 85050C precision TRL: DC to 18 GHz.

Includes: 00909-60008 7 mm coax termination 85050-60003 7 mm to 7 mm airline 85050-60005 7 mm to 7 mm TRL adapter 85050-60006 7 mm fixed broadband load 85050-80008 7 mm short 85050-80009 7 mm short collet 85050-80010 7 mm open

□ 85050D economy: DC to 18 GHz.

Includes: 85050-60006 7 mm fixed broadband load 85050-80007 7 mm short 85050-80010 7 mm open

Electronic calibration kits

□ N4696B Microwave ECal: 300 kHz to 18 GHz, 2 ports,

7mm to 7mm Microwave module

Cables

□ 85132C single, semi-rigid: 7 mm to 3.5 mm (f),

81 cm, 32 inches

□ 85132D set, semi-rigid: two 3.5 mm (f) to 7 mm cables,

53 cm each, 21 inches each

, p/n 85132-60003

□ 85132E single, flexible: 7 mm to 3.5 mm (f),

97.2 cm, 38.25 inches

□ 85132F set, flexible: two 3.5 mm (f) to 7 mm cables,

62.9 cm each, 24.75 inches each

, p/n 85132-60004

□ 85135C single, semi-rigid: 7 mm to 2.4 mm (f),

81 cm, 32 inches

□ 85135D set, semi-rigid: two 2.4 mm (f) to 7 mm cables,

53 cm each, 21 inches each, p/n 85135-60001

□ 85135E single, flexible: 7 mm to 2.4 mm (f),

96 cm, 38 inches

□ 85135F set, flexible: two 2.4 mm (f) to 7 mm cables,

53 cm each, 21 inches each, p/n 85135-60002

Mechanical calibration kits

X Band

□ X11644A standard, WR-90: 8.2 to 12.4 GHz.

Includes: 00896-60008 X-band standard section 00910-60003 X-band termination 11644-20018 X-band short 11644-20021 X-band shim

□ 85132F cable set (set, flexible 7 mm to 3.5 mm,

62.9 cm each, 24.75 inches each

)

□ 85135F cable set (set, flexible,

7 mm to 2.4 mm, 53 cm each, 21 inches each)

□ X281C adapter (included in calibration kit):

WR-90 to 7 mm

P Band

□ P11644A standard, WR-62: 12.4 to 18 GHz.

Includes: 00896-60007 P-band standard section 00910-60002 P-band termination 11644-20017 P-band short 11644-20020 P-band shim

□ 85132F cable set (set, flexible, 7 mm to 3.5 mm,

62.9 cm each, 24.75 inches each

)

□ 85135F cable set (set, flexible, 7 mm to 2.4 mm,

53 cm each, 21 inches each)

□ P281C adapter (included in calibration kit):

WR-62 to 7 mm

K Band

□ K11644A standard, WR-42: 18 to 26.5 GHz.

Includes: 00896-60006 K-band standard section 00910-60001 K-band termination 11644-20016 K-band short 11644-20019 K-band shim

□ 85134F cable set (set, flexible, 3.5 mm to 2.4 mm,

53 cm each, 21 inches each)

□ K281C adapter (included in calibration kit):

WR-42 to 3.5 mm (f) Option 012 WR-42 to 3.5 mm (m)

Adapter sets

□ 85130E 2.4 mm

1. Special rugged female connector specifically for connecting to the network analyzer test port, but does not mate with a standard male connector.

2. For use with E8362A or B.

to 7 mm

R Band

□ R11644A standard, WR-28: 26.5 to 40 GHz.

Includes: 00914-20028 R-band termination 11644-20005 R-band short 11644-20003 R-band shim 11644-60001 R-band 10 cm straight waveguide 11644-60016 R-band 5 cm straight waveguide

□ 85133F cable set (set, flexible, 2.4 mm, 53 cm each,

21 inches each)

□ R281A adapter (2.4 mm (f) to WR-28 waveguide

adapter)

□ R281B adapter (2.4 mm (m) to WR-28 waveguide

adapter)

Q Band

□ Q11644A standard, WR-22: 33 to 50 GHz.

Includes: 11644-60005 Q-band termination 11644-20004 Q-band short 11644-20001 Q-band shim 11644-60002 Q-band 10 cm straight waveguide 11644-60017 Q-band 5 cm straight waveguide

□ 85133F cable set (set, flexible, 2.4 mm, 53 cm each,

21 inches each)

□ Q281A adapter (2.4 mm (f) to WR-22 waveguide adapter) □ Q281B adapter (2.4 mm (m) to WR-22 waveguide adapter)

U Band

□ U11644A standard, WR-19: 40 to 60 GHz.

Includes: 11644-60006 U-band termination 11644-20004 U-band short 11644-20002 U-band shim 11644-60003 U-band 10 cm straight waveguide 11644-60018 U-band 5 cm straight waveguide

Verification kits

All Agilent verification kits include:

• precision Z

• mismatched airline or mismatch thru

• fixed attenuators

• traceable measured data and uncertainties

□ 85053B 300 kHz to 26.5 GHz 3.5 mm kit

Includes attenuators, airline and mismatch airline with data on a 3.5-inch disk for use in confirming accuracy enhanced system measurement performance, traceable to national standards. Test procedure is provided in the service manual.

□ 85055A 300 kHz to 18 GHz Type-N kit

□ 85057B 45 MHz to 50 GHz 2.4 mm kit

□ 85058V 45 MHz to 67 GHz 1.85 mm kit

Includes attenuators, match thru and mismatch thru with data on a 3.5-inch disk for use in confirming accuracy enhanced system measurement performance, traceable to national standards. Test procedure is provided in the service manual.

airline or match thru

V Band

□ V11644A standard, WR-15: 50 to 75 GHz.

Includes: 11644-60025 V-band termination 11644-20015 V-band short 11644-20013 V-band shim 11644-60012 V-band standard section

General Accessories

Amplifiers

USB

□ N4688A CD-ROM drive

Provides an external read/write CD-ROM drive with a USB cable.

□ N4689A USB hub

Provides a USB hub for connecting additional USB peripherals.

Hard drive

□ N8980A spare hard drive

For use with 500 MHz Pentium III CPU board1 Recommended for use in secure environments.

□ N8981A spare hard drive

For use with 1.1 GHz Pentium M CPU board1 Recommended for use in secure environments.

Probe

□ 85024A high-frequency probe

Provides high-impedance in-circuit test capability from 300 kHz to 3 GHz.

Power meters and sensors

Recommended for self support, adjustments and performance tests to verify proper instrument operation.

□ E4418B single-channel power meter □ E4419B dual-channel power meter □ 8481B power sensor, 10 MHz to 18 GHz, Type-N (m), 25 W □ 8481A power sensor, 10 MHz to 18 GHz, Type-N (m), 100 mW □ 8485A power sensor, 50 MHz to 26.5 GHz, APC-3.5 mm (m),

100 mW

□ 8487A power sensor, 50 MHz to 50 GHz, 2.4 mm, 300 mW □ 8487D power sensor, 50 MHz to 50 GHz, 2.4 mm, 100 mW □ R8486A power sensor, 26 GHz to 40 GHz, waveguide flange

UG-599/U, 100 mW

□ Q8486A power sensor, 33 GHz to 50 GHz, waveguide flange

UG-383/U, 100 mW

□ U8486A power sensor, 50 GHz to 75 GHz, waveguide flange

UG-385/U, 200 mW avg

□ E4412A CW power sensor, 10 MHz to 18 GHz, Type-N (m), 200 mW □ E4413A CW power sensor, 50 MHz to 26.5 GHz, 3.5 mm, 200 mW

□ 83006A power amplifier, 10 MHz to 26.5 GHz, 20 dB gain,

power out: +18 dBm to 10 GHz or +16 dBm to 20 GHz or +14 dBm to 26.5 GHz

□ 83017A power amplifier, 50 MHz to 26.5 GHz, 25 dB gain,

power out: +20 dBm to 20 GHz, or +15 dBm to 26.5 GHz

□ 83018A power amplifier, 2 to 26.5 GHz, 27 dB gain to 20 GHz

or 23 dB to 26.5 GHz, power out: +24 dBm to 20 GHz or +21 dBm to 26.5 GHz

□ 83020A power amplifier, 2 to 26.5 GHz, 30 dB gain to 20 GHz

or 27 dB to 26.5 GHz, power out: +30 dBm to 20 GHz or +26 dBm to 26.5 GHz

□ 83050A power amplifier, 2 to 50 GHz, 23 dB gain, power out:

+20 dBm to 40 GHz or +17 dBm to 50 GHz

□ 83051A power amplifier, 45 MHz to 50 GHz, 23 dB gain power out:

+12 dBm to 45 GHz or +10 dBm to 50 GHz

Couplers

□ 87300B coaxial coupler, 1 to 20 GHz, SMA (f), 10 dB coupling □ 87300C coaxial coupler, 1 to 26.5 GHz, 3.5 mm (f), 10 dB coupling □ 87301B coaxial coupler, 10 to 46 GHz, 2.92 mm (f), 10 dB coupling □ 87301D coaxial coupler, 1 to 40 GHz, 2.4 mm (f) or optional

2.92 mm (f), 13 dB coupling

□ 87301E coaxial coupler, 2 to 50 GHz, 2.4 mm (f), 10 dB coupling □ 87310B 90

coaxial coupler, 1 to 18 GHz, SMA (f), 3 dB coupling

Equipment rack accessories

□ E3663AC Rail kit □ 5063-9205 Front handle kit □ 5063-9217 Rack mount kit, for use without handles

(included with Option 1CM)

□ 5063-9224 Rack mount kit with handles □ 5063-9237 Rack mount kit, for use with standard supplied

handles (included with Option 1CP)

1. The 500 MHz CPU board has one USB port oriented vertically and a single GPIB port. The 1.1 GHz CPU board has four USB ports and two GPIB ports. For more information on this subject, refer to na.tm.agilent.com/pna/hdnumbers.html.

2. For the latest guide to power meters and power sensors, refer to the Agilent web site: www.agilent.com/find/powermeters

Applications

Material measurements

□ 85070E High-Temperature Dielectric Probe Kit

The 85070E enables measurements of the dielectric properties of materials quickly and conveniently. Measurements made with this probe are nondestructive and require no sample preparation. The dielectric probe is well suited for measurements of liquid, semisolid and flat solid materials. Measurement results can be viewed in a variety of formats (ε’ or Cole-Cole). The supplied software can be run in the PNA analyzer or on a PC.

, ε”r, tan δ

□ 85071E Materials Measurement Software

The 85071E materials measurement software calculates the permittivity and permeability of material samples placed in a coaxial airline or a rectangular waveguide. The measurement technique works well for solid materials that can be machined to fit precisely inside a transmission line. Measurement results can be viewed in a variety of formats (ε’ or Cole-Cole µ). The software can be run in the PNA analyzer or on a PC.

Pulsed measurements

The pulsed RF measurement capability (Option H08) and IF access (Option H11), are recommended for pulsed measurements with the PNA Series.

, εr, µ’r, µ”r, tan δ,

Pulse/pattern generators

Recommended to provide pulse signals and timing to the pulsed S-parameter text set and MW PNA

□ 81104A Pulse/pattern generator, 80 MHz, single-/dual-channel

with one or two Agilent 81105A output modules.

□ 81110A Pulse/pattern generator, 165 MHz, single-/dual-channel

with one or two Agilent 81111A output modules.

Note: Each pulse/pattern generator must be ordered with its associated output modules depending on the measurement configuration.

Pulsed S-Parameter test sets

□ Z5623AH81 Pulsed S-parameter test set, 2 to 20 GHz

Includes a pin-diode switch to modulate the analyzer’s internal source, an amplifier, and directional coupler to provide a pulsed reference to the analyzer.

□ Z5623AH83 Pulsed S-parameter test set, 2 to 20 GHz

Includes two pin switches for bi-directional (forward and reverse) pulsed-RF stimulus, and two directional couplers for the reference channels. It does not include internal amplifiers, but has front panel access loops for switching in external amplifiers to boost port power in both directions.

1. For more details regarding pulsed measurement configurations with the PNA Series, refer to Agilent’s Web site (www.agilent.com/find/pna) to download a copy of the Microwave PNA Series Network Analyzer Configuration Guide for Pulsed Measurements, literature number 5988-9833EN.

□ Z5623AH84 Pulsed S-parameter test set, 2 to 40 GHz

□ Z5623AH86 Pulsed S-parameter test set, 2 to 40 GHz

Includes one pin switch to modulate the analyzer’s internal source in the forward direction, and one directional coupler for the reference channel. It does not include internal amplifiers, but has front panel access loops for switching in an external amplifier to boost port power.

□ Z5623AH87 Pulsed S-parameter test set, 1 to 50 GHz

Includes two pin switches for bi-directional (forward and reverse) pulsed-RF stimulus. It does not include internal amplifiers, but has front panel access loops for switching in external amplifiers to boost port power in both directions.

□ Z5623AH89 Pulsed S-parameter test set, 10 MHz to 5 GHz

Includes one pin switch to modulate the analyzer’s internal source in the forward direction. This test set has no internal amplifier, no reference channel variable attenuator, and no GPIB control (manual control only).

□ Z5623AH90 Pulsed S-parameter test set, 1 to 50 GHz

Same as Z5623AH87, but adds 50 GHz couplers to the front panel to allow DUT connection on the test set instead of using the PNA test ports.

Note: Pulse biasing can be achieved with or without the use of a pulsed S-parameter test set. A proper pulse-bias driver must be used. Contact your local Agilent Sales Representative for additional pulsed S-parameter test set configurations and details.

Peripherals

The following peripherals may be used with the Microwave PNA Series. Other peripherals not listed here may also be compatible with these instruments.

Monitors

VGA-compatible monitor

Printers

USB, LAN, parallel or serial printers with Microsoft® Windows® printer driver

Interface cables

Choose the appropriate cables to connect each peripheral to the network analyzer.

□ 10833A GPIB cable, 1.0 m (3.3 ft) □ 10833B GPIB cable, 2.0 m (6.6 ft) □ 10833D GPIB cable, 0.5 m (1.6 ft) □ 82357B GPIB to USB interface

Upgrade Kits

Upgrade kits for the PNA Series E8362A, E8363A, E8364A, E8362B, E8363B, E8364B, E8361A, N5250A

Upgrade kits are available to add options after initial purchase. To order an upgrade kit for the PNA series, order the analyzer’s model number followed by a “U”, then indicate the option to be added (for example, E8362BU-010). The serial number of the instrument to be retrofitted is required as part of the order.

□ Time-domain (Option 010)

User installable.

□ Configurable test set (Option 014)

Provides six front-panel RF access loops. Includes installation at an Agilent service center.

□ Receiver attenuators (Option 016)

(Not available for the E8362A/63A/64A) Includes installation at an Agilent service center.

□ Extended memory (Option 022)

(Not available for the E8362A/63A/64A) Applies only to E8362B/63B/64B/61A with 256 MB of RAM. Includes installation at an Agilent service center.

□ Frequency range upgrade to an E8363A/B (40 GHz) PNA (Option 040)

Available only for the E8362A/B. Includes installation at an Agilent service center.

□ Frequency range upgrade to an E8364A/B (50 GHz) PNA (Option 050)

Available only for the E8362A/B and E8363A/B. Includes installation at an Agilent service center.

□ Frequency range upgrade to an E8361A (67 GHz) PNA (Option 067)

Available only for the E8363B and E8364B. Includes installation at an Agilent service center.

□ Frequency-offset (Option 080)

(Not available for the E8362A/63A/64A) Includes installation at an Agilent service center.

□ External reference switch (Option 081)

(Not available for the E8362A/63A/64A) Includes installation at an Agilent service center.

□ Scalar-calibrated converter measurements (Option 082)

(Not available for the E8362A/63A/64A) User installable. Option 080 required.

□ Frequency converter measurement application (Option 083)

(Not available for the E8362A/63A/64A) User installable. Option 080 and 081 required.

□ Extended hardware capability (Option 097)

(Available for the E8362A/63A/64A only) This option will upgrade your E836xA model to an E836xB model; adding a 10 MHz start frequency and the ability to add the options needed to test mixers (080, 081, and 083).

□ 4-Port measurement application (Option 550)

(Available for E8361A, E8362B/3B/4B) Enables full 4-port error correction and differential measurements. Option 014 and external test set required. User installable.

□ N-port capabilities (Option 551)

(Available for E8361A, E8362B/3B/4B) Adds full N-port error correction and measurement capabilities. Option 014 and external test set required. User installable.

□ Extended power range (Option UNL)

Adds a step attenuator and a bias-tee between source and each test port. Includes installation at an Agilent service center.

□ Pulsed-RF measurement capability (Option H08)

(Not available for E8362A/63A/64A) Provides software to set up and control pulsed-RF measurements using narrowband detection, with point-in-pulse and pulse-profile capability. User installable.

□ IF access (Option H11)

(Not available for E8362A/63A/64A) Provides hardware for antenna, point-in-pulse, and millimeter wave measurements. Adds rear-panel RF and LO outputs, external IF inputs, and IF gates (gates enabled with Option H08). Includes installation at an Agilent service center.

□ High-power test set (Option H85)

Removes bias tees for higher test port power-handling capability. Options UNL, 014, 016, 080, and 081 are required. Includes installation at an Agilent Service Center.

Upgrade kits for the PNA-L Series N5230A

Upgrade kits are available to add options after initial purchase. To order an upgrade kit for the PNA-L series, order the analyzer’s model number followed by a “U”, then indicate the option to be added (example: N5230AU-010). The serial number of the instrument to be retrofitted is required as part of the order.

□ Time-domain upgrade kit (Option 010)

The serial number of the instrument to be retrofitted must be specified when ordering this kit. User installable.

□ Frequency-offset upgrade kit (Option 080)

The serial number of the instrument to be retrofitted must be specified when ordering this kit. User installable.

□ Scalar-calibrated converter measurements (Option 082)

User installable. Option 080 required.

□ 4-port measurement application (Option 550)

Enables full 4-port error correction and differential measurements on a 2-port network analyzer with configurable test set (Option x25). External test set required. User installable.

□ N-port capabilities (Option 551)

Adds full N-port error correction and measurement capabilities to PNA-L with configurable test set (Option xx5 or x46). External test set required. User installable.

□ 6 or 13.5 GHz configurable test set & extended power range

upgrade kit (Option 901) Applicable to 6 or 13.5 GHz PNA-L (N52300-020, N52300-120). Upgrade to configurable test set and extended power range. Includes installation at an Agilent service center.

□ 20 GHz 2-port configurable test set & extended power range

upgrade kit (Option 921) Applicable to 20 GHz PNA-L (N52300-220 with serial prefix MY4500A and below). Upgrade to configurable test set and extended power range. Includes installation at an Agilent service center.

□ 20 GHz 2-port configurable test set & extended power range

upgrade kit (Option 922) Applicable to 20 GHz PNA-L (N52300-220 with serial prefix MY4640A and above). Upgrade to configurable test set and extended power range. Includes installation at an Agilent service center.

□ 13.5 or 20 GHz 4-port configurable test set & extended power

range upgrade kit (Option 926) Applicable to 20 GHz 4-port PNA-L (N52300-140, N52300-240). Upgrade to configurable test set and extended power range. Includes installation at an Agilent service center.

□ 13.5 GHz 4-port configurable test set, extended power range &

internal second source upgrade kit (Option 928) Applicable to 13.5 GHz 4-port PNA-L (N52300-145). Upgrade to configurable test set, extended power range and internal second source. Includes installation at an Agilent service center. (Option 080 recommended. Please note, Option 080 is needed in order to have independent control of the two internal sources.)

□ 20 GHz 4-port configurable test set, extended power range &

internal second source upgrade kit (Option 927) Applicable to 20 GHz 4-port PNA-L (N52300-245). Upgrade to configurable test set, extended power range and internal second source. Includes installation at an Agilent service center. Option 080 recommended.

□ 40 or 50 GHz configurable test set & extended power range

upgrade kit (Option 941) Applicable to 40 or 50 GHz PNA-L (N52300-420, N52300-520). Upgrade to configurable test set and extended power range. Includes installation at an Agilent service center.

□ Frequency range upgrade from 6 to 13.5 GHz (Option 960)

Applicable to the 6 GHz PNA-L (N52300-020, N52300-025). Includes installation at an Agilent service center.

□ Frequency range upgrade from 13.5 to 20 GHz (Option 966)

Applicable to the 13.5 GHz 4-port PNA-L (N52300-140, N52300-145, N52300-146). Includes installation at an Agilent service center.

□ Frequency range upgrade from 20 to 40 GHz (Option 971)

Applicable to the 20 GHz PNA-L (N52300-220). Includes installation at an Agilent service center.

□ Frequency range upgrade from 20 to 40 GHz (Option 973)

Applicable to the 20 GHz PNA-L (N52300-225 with serial prefix MY4500A and below). Includes installation at an Agilent service center.

□ Frequency range upgrade from 40 to 50 GHz (Option 990)

Applicable to the 40 GHz PNA-L (N52300-420, N52300-425). Includes installation at an Agilent service center.

For additional upgrade paths, contact your Agilent field office.

x20 x25 x40 x45 x46

901

020

6 GHz

025

960

13.5 GHz

20 GHz

40 GHz

50 GHz

960

120 140

125 145

146

921/

220 240

941

973

990

225 245

971

246

420

425

990

520

525

966

927

PNA-L upgrade path examples.

Upgrade kits for the PNA-X N5242A

Upgrade kits are available to add options after initial purchase. To order an upgrade kit for the PNA-X, order the analyzer’s model number followed by a “U”, then indicate the option to be added (example: N5242AU-010). The model and serial numbers of the instrument to be retrofitted are required as part of the order.

□ Pulse measurements (Option H08)

User installable.

□ Time-domain (Option 010)

User installable.

□ Add IF inputs for antenna and millimeter-wave (Option 020)

User installable.

□ Add pulse modulator to internal 1

User installable.

□ Add pulse modulator to internal 2

User installable. Option 224 or 400 required.

source (Option 021)

source (Option 022)

□ Add four internal pulse generators (Option 025)

User installable.

□ Fully-corrected noise figure measurements (Option 029)

Includes installation at an Agilent Service Center. Option 219, 224, 419 or 423 required.

□ Frequency offset (Option 080)

User installable.

□ Scalar-calibrated converter measurements (Option 082)

User installable. Option 080 required, and can not be ordered with Option 083.

□ Frequency converter measurements (Option 083)

User installable. Option 080 required, and can not be ordered with Option 082.

□ Embedded LO measurements (Option 084)

User installable. Options 080 and 083 required.

□ N-port capabilities (Option 551)

User installable.

□ Perpetual license for built-in performance test software for

Agilent inclusive calibration (Option 897) User installable. Additional hardware required.

□ Perpetual license for built-in performance test software for

standards compliant calibration (Option 898) User installable. Additional hardware required.

□ 2 ports, extended power range and bias-tees (Option 921)

Applicable to 2-port model only (N5242A-200). This upgrade adds one 65 dB source attenuator, one 35 dB receiver attenuator, and one bias-tee to each test port. Includes installation at an Agilent service center. Option 200 required.

□ 2 ports, add an internal 2

switches (Option 922) Applicable to 2-port models only (N5242A-200, N5242A-219). This upgrade adds an internal second source, a combiner and mechanical switches. Access to the second source is available through two output (SMA) connectors on the front panel. Includes installation at an Agilent service center. Options 200, 219 and 080 required.

source, a combiner & mechanical

□ Fully corrected noise figure measurements, 2-port

(Option 924) Adds fully-corrected noise figure measurements to 2-port analyzer. Includes installation at an Agilent Service Center. Option 219 or 224 required.

□ 4 ports, extended power range and bias-tees (Option 926)

Applicable to 4-port model only (N5242A-400). This upgrade adds one 65 dB source attenuator, one 35 dB receiver attenuator, and one bias-tee to each test port. Includes installation at an Agilent service center. Option 400 required.

□ 4 ports, add an internal combiner & mechanical switches

(Option 927) Applicable to 4-port models only (N5242A-400, N5242A-419). This upgrade adds a combiner and mechanical switches. Includes installation at an Agilent service center. Options 400, 419 and 080 required.

□ Fully corrected noise figure measurements, 4-port

(Option 929) Adds fully-corrected noise figure measurements to 4-port analyzer. Includes installation at an Agilent Service Center. Option 419 or 423 required.

□ High-power test set (Option H85)

Removes bias tees for higher test port power-handling capability. Includes installation at an Agilent Service Center. Option 080 plus 224 or 423 required.

N5242A PNA-X upgrade path

2-port 4-port 200 219 224 400 419 423

921 922 926 927 200 219 224 400 419 423

Key Web Resources

Visit our Web sites for additional product information and literature:

www.agilent.com/find/pna

Electronic calibration (ECal) visit:

www.agilent.com/find/ecal

Material test equipment:

www.agilent.com/find/materials

Test and measurement accessories:

www.agilent.com/find/accessories

Antenna and radar cross-section products visit:

www.agilent.com/find/antenna

Multiport test sets visit:

www.agilent.com/find/multiport

Pulsed-RF products visit:

www.agilent.com/find/pulsedRF

On-wafer and in-fixture measuring products visit:

www.agilent.com/find/probingRF

Agilent’s service and support products visit:

www.agilent.com/find/tm_services

Expand your measurement capabilities with Agilent qualified channel partners

Remove all doubt

Our repair and calibration services will get your equipment back to you, performing like new, when promised. You will get full value out of your Agilent equipment throughout its lifetime. Your equipment will be serviced by Agilent-trained technicians using the latest factory calibration procedures, automated repair diagnostics and genuine parts. You will always have the utmost confidence in your measurements.

Agilent offers a wide range of additional expert test and measurement services for your equipment, including initial start-up assistance design, system integration, and project management.

For more information on repair and calibration services, go to

, onsite education and training, as well as

www.agilent.com/find/removealldoubt

www.agilent.com

For more information on Agilent Technologies’ products, applications or services, please contact your local Agilent office. The complete list is available at:

www.agilent.com/find/contactus

Our channel partners offer accessories and measurement solutions that extend your network analysis capabilities.

For more information about probing equipment and accessories, contact:

Cascade Microtech, Inc

2430 NW 206th Avenue Beaverton, Oregon 97006, USA Toll free telephone: 1-800-550-3279 Telephone: (503) 601-1000 Fax: (503) 601-1002 Web site: www.cascademicrotech.com E-mail: sales@cmicro.com

www.agilent.com/find/emailupdates

Get the latest information on the products and applications you select.

www.agilent.com/find/quick

Quickly choose and use your test equipment solutions with confidence.

Product specifications and descriptions in this document subject to change without notice.

Pentium® is a U.S. registered trademark of Intel Corporation. Microsoft® and Windows® are registered trademarks of Microsoft Corporation.

Agilent E8361A Configuration Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
