These specifications apply to the Agilent Technologies E7401A,
E7402A, E7403A, E7404A and E7405A EMC analyzers.
Specifications
All specifications apply over 0° C to +55° C unless otherwise
noted and are covered by the product warranty. The analyzer will
meet its specifications when: it’s within the one year calibration
cycle, AUTO ALIGN [ALL] is selected, stored a minimum 2 hours
within the operating temperature range, turned on for at least 5
minutes, and Align Now RF has been run once every 24 hour period.
Typical performance describes the level at which 80% of the units will
meet or exceed with a 95% confidence level over 20 to 30° C, but is
not covered in the product warranty. Characteristics describe
expected product performance levels that are not covered in the
product warranty.
Frequency specifications
Frequency range
E7401A
50 Ω 9 kHz to 1.5 GHz
E7402A 9 kHz to 3.0 GHz
dc coupled (Option UKB) 30 Hz
1
to 3.0 GHz
ac coupled 100 kHz1to 3.0 GHz
E7403A
dc coupled 9 kHz to 6.7 GHz
dc coupled (Option UKB) 30 Hz1to 6.7 GHz
ac coupled 100 kHz to 6.7 GHz
Band
0 9 kHz to 3.0 GHz
1 2.85 GHz to 6.7 GHz
E7404A
dc coupled 9 kHz to 13.2 GHz
dc coupled (Option UKB) 30 Hz1to 13.2 GHz
ac coupled 100 kHz to 13.2 GHz
Band LO harmonic = N
0 1- 9 kHz to 3.0 GHz
(Option UKB) 30 Hz1to 3.0 GHz
1 1- 2.85 GHz to 6.7 GHz
2 2- 6.2 GHz to 13.2 GHz
E7405A 9 kHz to 26.5 GHz
Band LO harmonic = N
0 1- 9 kHz to 3.0 GHz
0 (Option UKB) 30 Hz1to 3.6 GHz
1 1- 2.85 GHz to 6.7 GHz
2 2- 6.2 GHz to 13.2 GHz
3 4- 12.8 GHz to 19.2 GHz
4 4- 18.7 GHz to 26.5 GHz
Frequency reference (Option 1D5)
Aging ±2 x 10-6/year ±1 x 10-7/year
Temperature stability ±5 x 10
-6
±1 x 10
-8
Settability ±5 x 10
-7
±1 x 10
-8
Frequency readout accuracy
(start, stop, center, marker) ±(frequency indication
x frequency reference error
2
+ span accuracy + 15% of RBW
+ 10 Hz) + 1 Hz x N
3
Agilent
E7400 A-series EMC Analyzers
Data Sheet
1. Characteristic
2. Frequency reference error = (aging rate x period of time since adjustment +
settability + temperature stability
3. N = LO harmonic mixing mode
2
Marker frequency counter
1
Accuracy
2
±(marker frequency x frequency
reference error3+ counter resolution)
Counter Resolution Selectable from 1 Hz to 100 kHz
Frequency span
Range 0 Hz (zero span), 100 Hz x N4to
the range of the spectrum analyzer
Resolution 2 Hz x N
4
Accuracy (> 2000 sweep points)
Sweep type linear ±0.5% of span
Sweep type log ±2% of span (characteristic)
Sweep time
Range
Span > 0 Hz 1 ms to 4000 s
Span = 0 Hz 10 µs5to 4000 s
(Option AYX) 50 ns5to 4000 s
Accuracy ±1%
Sweep trigger Free run, single, line, video,
external, delay, offset, and gate
(Option 1D6)
Delay trigger range 1 µs to 400 s
Sweep (trace) point range 101 to 8192
Span = 0 Hz 2 to 8192
Resolution bandwidth 10 Hz to 3 MHz (-3 dB) in
1-3-10 sequence
6
5 MHz (-3 dB) bandwidth
200 Hz6, 9 kHz, 120 kHz, 1 MHz
(-6 dB) EMI bandwidths
1 MHz (impulse) EMI bandwidth
Option 1D5 Adds 1 Hz and 3 Hz
Accuracy
10 Hz to 300 MHz (-3 dB) ±10%
1Hz and 3 Hz (Option 1D5) ±10%
1 kHz to 3 MHz (-3 dB) ±15%
5 MHz (-3 dB) ±30%
200 Hz (-6 dB) ±10%
9 kHz to 120 kHz (-6 dB) ±20%
1 MHz (-6 dB) ±10%
1 MHz (impulse) ±15%
Selectivity (characteristic)
10 Hz to 300 Hz (-3 dB) < 5:1 (-60 dB/-3 dB)
(Digital, approximately Gaussian-shaped)
1 kHz to 3 MHz (-3 dB) < 5:1 (-60 dB/-3 dB)
(approximately Gaussian-shaped)
200 Hz (-6 dB) < 3:1 (-40 dB/-6 dB)
(Digital, Kaizer Windows)
9 kHz, 120 kHz,
1 MHz (-6 dB) < 10:1 (-60 dB/-6 dB)
(approximately Gaussian-shaped)
1 MHz (impulse) < 10:1 (-60 dB/-6 dB)
(approximately Gaussian-shaped)
Video bandwidth range 30 Hz to 3 MHz7in 1-3-10
sequence
1, 3, 10 Hz for RBW’s < 1 kHz
Stability
Noise sidebands (1 kHz RBW, 30 Hz VBW and sample detector)
E7401A
≥ 1 kHz na ≤ 79 dBc/Hz
(Option 1D5)
≥ 10 kHz ≤ -93 dBc/Hz ≤ -95 dBc/Hz
> 20 kHz ≤ -100 dBc/Hz ≤ -102 dBc/Hz
> 30 kHz ≤ -104 dBc/Hz ≤ -106 dBc/Hz
> 100 kHz ≤ -113 dBc/Hz ≤ -116 dBc/Hz
E7402/03/04/05A
≥ 1 kHz na ≤ 78 dBc/Hz
(Option 1D5)
≥ 10 kHz ≤ -90 dBc/Hz
8
≤ -94 dBc/Hz
8
> 20 kHz ≤ -100 dBc/Hz
8
≤ -105 dBc/Hz
8
> 30 kHz ≤ -106 dBc/Hz
8
≤ -112 dBc/Hz
8
> 100 kHz ≤ -118 dBc/Hz
8
≤ -122 dBc/Hz
8
> 1 MHz ≤ -125 dBc/Hz
8
≤ -127 dBc/Hz
8
> 5 MHz ≤ -127 dBc/Hz
8
≤ -129 dBc/Hz
8
> 10 MHz ≤ -131 dBc/Hz
8
≤ -136 dBc/Hz
8
Residual FM
1 kHz RBW, 1 kHz VBW ≤ 150 x N4Hz pk-pk in 100 ms
Option 1D5 ≤ 100 x N4Hz pk-pk in 100 ms
10 Hz RBW, 10 Hz VBW ≤ 2 x N4Hz pk-pk in 20 ms
System-related sidebands
≥ 30 kHz offset from CW signal ≤ -65 dBc + 20 Log N
4
1. Not available in RBW < 1kHz
2.
Marker level to DANL > 25 dB, Span ≤ 1.5 GHz, RBW/Span ≥ 0.002
3. Frequency reference error = (aging rate x period of time since adjustment +
settability + temperature stability
4. N = LO harmonic mixing mode
5. RBW ≥1 kHz, 2 sweep points
6. 10 Hz to 300 Hz are only available in spans of ≤ 5 MHz and are not usable with
tracking generator Option 1DN.
7. Characteristic
8. Add 20 log(N) for frequencies > 6.7 GHz.
-70
Typical performance
Spec
-90
dBc/Hz
-110
-130
1k 10k 100k 1M
Offset (Hz)
3
Amplitude specifications
Amplitude range
Measurement range Displayed average noise level (DANL)
to maximum safe input level
Input attenuator range
E7401A 0 to 60 dB, in 5 dB steps
E7402A, 03A, 04A 0 to 65 dB (75 dB1), in 5 dB steps
E7405A 0 to 65 dB, in 5 dB steps
Maximum safe input level
Average continuous power
E7401A (input attenuator ≥ 15 dB)
+30 dBm (1 Ω)
(input attenuator ≥ 5 dB)
E7402A/03A/04A/05A +30 dBm (1 Ω)
Peak pulse power (input attenuator ≥ 30 dB)
E7402A/03A/04A/05A +50 dBm (100 Ω)
E7401A +30 dBm (1 Ω)
dc
E7401A, E7402A 100 Vdc
E7402A (Option UKB) 0 Vdc (dc coupled)
50 V (ac coupled)
E7403A, E7404A 0 Vdc (dc coupled)
50 V (ac coupled)
E7405A 0 Vdc
(Option UKB) 0 Vdc (dc coupled)
50 V (ac coupled)
1 dB gain compression (total power at input mixer2)
≥ 50 MHz 0 dB
≥ 6.7 GHz -3 dB
≥ 13.2 GHz -5 dB
Displayed average noise level (dBm)
(Input terminated, 0 dB attenuation, sample-detector)
1 kHz RBW; 30 Hz VBW
10 Hz RBW; 1 Hz VBW
1 Hz RBW; 1 Hz VBW (Option 1D5)
1 kHz 10 Hz 1 kHz 10 Hz 1 Hz
RBW RBW w/preamp w/preamp Option 1D5
on on, typical w/preamp
on, typical
E7401A
400 kHz to 10 MHz ≤ -115 ≤ -134 ≤ -150 ≤ -155 ≤ -165
10 MHz to 500 MHz ≤ -119 ≤ -138 ≤ -154 ≤ -156 ≤ -166
500 MHz to 1 GHz ≤ -117 ≤ -136 ≤ -152 ≤ -156 ≤ -166
1 GHz to 1.5 GHz ≤ -114 ≤ -133 ≤ -150 ≤ -155 ≤ -165
E7402A
30 Hz to 9 kHz
3
(Option UKB) na ≤-93 na na na
9 kHz to 100kHz3na ≤-109 na na na
100 kHz to 1 MHz3na ≤-135 na na na
1 MHz to 10 MHz3≤-117 ≤-136 na ≤-152 ≤-162
10 MHz to 1 GHz ≤-117 ≤-136 ≤-1524≤-156 ≤-166
1 GHz to 2 GHz ≤-116 ≤-135 ≤–1534≤-156 ≤-166
2 GHz to 3 GHz ≤-114 ≤-133 ≤–1514≤-154 ≤-164
E7403A, 04A, 05A
30 Hz to 9 kHz
3
(Option UKB) na ≤ -93 na na na
9 kHz to 100kHz3na ≤ -109 na na na
100 kHz to 1 MHz3na ≤ -135 na na na
1 MHz to 10 MHz3≤ -117 ≤ -137 na ≤ -155 ≤ -165
10 MHz to 1 GHz ≤ -116 ≤ -135 ≤ -1514≤ -157 ≤ -167
1 GHz to 2 GHz ≤ -116 ≤ -131 ≤ –1514≤ -155 ≤ -165
2 GHz to 3 GHz ≤ -112 ≤ -131 ≤ –1494≤ -152 ≤ -162
3 GHz to 6 GHz ≤ -112 ≤ -131 na ≤ -138 na
6 GHz to 12 GHz ≤ -111 ≤ -130 na ≤ -137 na
12 GHz to 22 GHz ≤ -107 ≤ -126 na ≤ -134 na
22 GHz to 26.5 GHz ≤ -106 ≤ -125 na ≤ -132 na
Display range
Log Scale 0.1, 0.2, 0.5 dB/division and 1 to 20 dB/division
in 1 dB steps; ten divisions displayed
RBW ≥ 1kHz 0 to -85 dB from reference level is calibrated
RBW ≤ 300 Hz 0 to -1205 dB from reference level is calibrated
Linear scale 10 divisions
Scale units dBm, dBmV, dBµV, dBµA, Amps, Volts and Watts
Marker readout resolution
Log scale
0 to -85 dB 0.04 dB
0 to -120 (RBW ≤ 300 Hz 0.04 dB
Linear scale 0.01% of reference level
Fast sweep times for zero span (Option AYX)
Log Scale
0 to -85 dB 0.3 dB
Linear 0.3 dB of reference level
1. Characteristic
2. Mixer power level (dBm) = input power (dBm) – input attenuator (dB)
3. Typical
4. 0 to 50 dB for RBWs ≤ 300 Hz and span = 0 Hz, or when auto ranging is off, or
0 to 30 dB for RBW = 200 Hz.
5.
0 to –70 dB range when span = 0 Hz, when RBW = 200 Hz, or when IF
gain is fixed.
4
Frequency response (10 dB input attenuation)
Absolute1Typical Relative
flatness
2
E7401A
9 kHz to 1.5 GHz ±0.5 dB na ±0.5 dB
E7402A/03A/04A/05A
30 Hz to 3 GHz
3
(Option UKB) ±0.5 dB na ±0.5 dB
9 kHz to 3 GHz ±0.46 dB ±0.14 dB ±0.5 dB
3.0 GHz to 6.7 GHz ±1.5 dB ±0.39 dB ±1.3 dB
6.7 GHz to 13.2 GHz ±2.0 dB ±0.68 dB ±1.8 dB
13.2 GHz to 26.5 GHz ±2.0 dB ±0.86 dB ±1.8 dB
Input attenuation switching uncertainty at 50 MHz
Attenuation setting
0 dB to 5 dB ±0.3 dB
10 dB Reference
15 dB ±0.3 dB
20 to 60 dB (E7401A) ±(0.1 dB + 0.01 x attenuator setting)
20 to 65 dB ±(0.1 dB + 0.01 x attenuator setting)
Absolute amplitude accuracy Typical
At reference settings
4
±0.34 dB ±0.13 dB
E7401A ±0.30 dB ±0.10 dB
Preamp on
5
±0.37 dB ±0.14 dB
Overall amplitude accuracy6±(0.54 dB + absolute
frequency response)
RF input VSWR3(at tuned frequency, 10 dB attenuation)
E7401A
1 MHz to 1.5 GHz 1.35:1
E7402A
100 Hz to 100 kHz 1.1:1 (Option UKB)
9 kHz to 100 kHz 2:1
100 kHz to 3 GHz 1.4:1
E7403A/04A
100 Hz to 100 kHz 1.1:1 (Option UKB)
9 kHz to 100 kHz 2:1
100 kHz to 6.7 GHz 1.3:1
6.7 kHz to13.2 GHz 1.5:1
E7405A
100 Hz to 100 kHz 1.1:1 (Option UKB)
9 kHz to 6.7 GHz 1.3:1
6.7 GHz to 13.2 GHz 1.5:1
13.2 GHz to 22 GHz 2:1
22 GHz to 26.5 GHz 2.2:1
Resolution bandwidth switching uncertainty
(Referenced to 1 kHz RBW, at reference level)
10 Hz to 3 MHz RBW ±0.3 dB
5 MHz RBW ±0.6 dB
10 Hz to 300 Hz RBW ±0.3 dB
Reference level
Range -149 dBm to maximum mixer level
+ attenuator setting
Resolution
Log scale ±0.1 dB
Linear scale ±0.12% of reference level
Accuracy (reference level ±0.3 dB (-10 dBm to –60 dBm)
-attenuator setting ±0.5 dB (-60 dBm to –85 dBm)
+ preamp gain) ±0.7 dB (-85 dBm to –90 dBm)
Display scale fidelity
Log maximum cumulative
RBW ≥ 1 kHz
dB below reference level Typical
0 dB (reference) ±0.00 dB ±0.00 dB
> 0 dB to 10 dB ±0.3 dB ±0.08 dB
> 10 dB to 20 dB ±0.4 dB ±0.09 dB
> 20 dB to 30 dB ±0.5 dB ±0.10 dB
> 30 dB to 40 dB ±0.6 dB ±0.23 dB
> 40 dB to 50 dB ±0.7 dB ±0.35 dB
> 50 dB to 60 dB ±0.7 dB ±0.35 dB
> 60 dB to 70 dB ±0.8 dB ±0.39 dB
> 70 dB to 80 dB ±0.8 dB ±0.46 dB
> 80 dB to 85 dB ±1.15 dB ±0.79 dB
RBW ≤ 300 Hz (Span >0 Hz)
0 dB to 98 dB ±(0.3 dB + 0.01 x dB from
reference level)
≥ 98 dB to 120 dB ±(2.0 dB from reference level)
3
Log incremental accuracy
0 dB to 80 dB
7
±0.4 dB/4 dB from reference level
Linear accuracy ± 2% of reference level
Linear to log switching ±0.15 dB at reference level
1. Referenced to 50 MHz amplitude reference (20 °C – 30 °C)
2. Reference to midpoint between highest and lowest frequency response deviations. (20
°C – 30 °C)
3. Characteristic
4. Reference level -25 dBm (E7401A) or -20 dBm (E7402A/03A/04A/05A); input attenuation 10 dB; center frequency 50 MHz; RBW 1 kHz; VBW 1 kHz; scale linear or log; span
2 kHz; sweep time coupled, sample director, signal at reference level.
5. 10 Hz to 300 Hz are only available in spans of ≤ 5 MHz and are not usable with tracking
generator Option 1DN.
6. For reference levels 0 to 50 dBm; input attenuation 10 dB; dc coupled; RFW 1 kHz;
VBW 1 kHz; scale loge range 0 to -50 dB from reference level; sweeptime coupled;
signal input 0 to 50 dB; spsn ≤ 20 kHz.
7. 0 to 50 dB for RBWs ≤ 300 Hz and span = 0 Hz, or when auto ranging is off, or 0 to 30
dB for RBW = 200 Hz.
5
Spurious responses
Second harmonic distortion
E7401A
2 MHz to 750 MHz < -75 dBc for -40 dBm tone at
input mixer
1
E7402A/03A/04A/05A
10 MHz to 500 MHz < -65 dBc for -30 dBm tone at
input mixer
1
500 MHz to 1.5 GHz < -75 dBc for -30 dBm tone at
input mixer
2
1.5 GHz to 2.0 GHz < -85 dBc for -10 dBm tone at
input mixer
2
> 2.0 GHz < -100 dBc for -10 dBm tone at
input mixer1(or below displayed
average noise level)
Third order intermodulation distortion
E7401A
100 MHz to 1.5 GHz < -87 dBc for two -30 dBm tones at
input mixer1and > 50 kHz separation
E7402A/03A/04A/05A
100 MHz to 6.7 GHz < -85 dBc for two -30 dBm tones at
input mixer1and > 50 kHz separation
> 6.7 GHz < -75 dBc for two -30 dBm tones at
input mixer1and > 50 kHz separation
Other input related spurious
< -65 dBc, for -20 dBm tone at
input mixer
1
Residual responses (input terminated and 0 dB attenuation)
150 kHz to 6.7 GHz < -90 dBm
Amplitude ref. output
E7402A,03A,04A,05A
Amplitude -20 dBm (nominal)
FM demodulation
3
Input level -60 dBm + attenuator setting
Signal level 0 to -30 dB below reference level
Quasi-peak detector specifications
The EMC analyzer displays the quasi-peak amplitude of a pulse
radio frequency on continuous wave signals. Amplitude response
conforms with Publication 16 of Comite International Special des
Perturbations Radioelectrique (CISPR) Section 1, Clause 2.
Relative quasi-peak response to a CISPR pulse (dB)
Pulse repetition 120 kHz EMI BW 9 kHz EMI BW 200 Hz EMI BW
frequency (Hz) .03 to 1 GHz 0.150 to 30 MHz 9 kHz to 150 kHz
1000 +8.0 ±1.0 +4.5 ±1.0 –––
100 0 dB reference40 dB reference4+4.0 ±1.0
60 ––– ––– +3.0 ±1.0
25 ––– ––– 0 dB reference
4
20 -9.0 ±1.0 -6.5 ±1.0 –––
10 -14 ±1.5 -10.0 ±1.5 -4.0 ±1.0
5 ––– ––– -7.5 ±1.5
2 -26 ±2.0 -20.5 ±2.0 -13.0 ±2.0
1 ––– -22.5 ±2.0 -17.0 ±2.0
Isolated Pulse ––– -23.5 ±2.0 -19.0 ±2.0
General specifications
Temperature range
Operating 0° C to +55° C
Storage -40° C to +75° C
EMI compatibility Conducted and radiated emissions is
in compliance with CISPR Pub.
11/1990 Group 1 Class B
5
Audible noise < 40 dBa pressure and < 4.6 Bels
power (ISODP7779)
Military specification Type tested to the environmental
specifications of MIL-PRF-28800F,
class 3
Power requirements
ON (line1) 90 to 132 V rms, 47 to 440 Hz
195 to 250 V rms, 47 to 66 Hz
Power consumption < 300 Ω
Standby (line 0) Power consumption < 5 Ω
DC operation
Voltage 12 to 20 Vdc
Power consumption < 200 Ω
Measurement speed
E7401A E7402A E7403A/04A/05A
Local measurement rate6≥ 50/sec ≥ 45/sec ≥ 40/sec
Remote measurement as
GPIB transfer rate
7
≥ 45/sec ≥ 45/sec ≥ 40/sec
RF center frequency
tuning time
8
≥ 75/ms ≥ 75/ms ≥ 75/ms
Data storage (nominal)
Internal 200 traces9or states
External (floppy) 200 traces9or states
1. Mixer power level (dBm) = input power (dBm) – input attenuator (dB)
2. Not available in RBW < 1kHz
3. Characteristic
4. Reference pulse amplitude accuracy relative a 66 µV CW signal < 1.5 dB as
specified in CISPR Pub 16 CISPR reference pulse: 0.44 µVs for 30 MHz to 1 GHz,
0.316 µVs for 150 kHz to 30 MHz, 13.5 µVs for 9 kHz to 150 kHz
5. Meets Class A performance during dc operation or serial number US41110000 or
lower.
6. Characteristic; factory preset, fixed center frequency, sweep points = 101 auto
align off, RBW = 1 MHz, stop frequency ≤ 3 GHz, span > 10 MHz and ≤ 600 MHz
(E4401, span > 102 MHz and ≤ 400 MHz).
7. Characteristic; factory preset, fixed center frequency, sweep points = 101 auto
align off, RBW = 1 MHz, stop frequency ≤ 3 GHz, span = 20 MHz, GPIB interface,
display and markers off, fixed center frequency, single sweep
8. Characteristic; includes center frequency tuning and measurement plus GPIB
transfer times, stop frequency ≤ 3 GHz, sweep points = 101, display and markers
off, single sweep
9. When storing a 401-point trace plus the instrument state
6
Weight (without options)
E7401A 12.6 kg (27.7 lbs.)
E7402A 14.9 kg (32.9 lbs.)
E7403A/04A/05A 17.1 kg (37.7 lbs.)
Dimensions
without handle 222 mm(H) x 409 mm(D)
x 373 mm(W)
with handle (max.) 222 mm(H) x 516 mm(D)
x 416 mm(W)
Inputs/outputs
Front panel connectors
Input 50 Ω type N (f)
Option BAB 50 Ω APC 3.5 (m)
RF Out 50 Ω type N (f)
Probe power +15 Vdc, -12.6 Vdc at 150 mA
max. characteristic
Ext. keyboard 6-pin mini-DIN, PC keyboards
(for entering screen titles and
file names)
Speaker front-panel knob controls volume
Headphone 3.5 mm (1/8
inch) miniature audio jack
Power output 0.2 Ω into 4 Ω
1
Amptd ref. output 50 Ω, BNC (f)
E7402A/03A/04A/05A
Rear panel connectors
10 MHz ref out 50 Ω, BNC (f), > 0 dBm
1
10 MHz ref in 50 Ω, BNC (f), -15 to +10 dBm
1
Gate trig/ext. trig in BNC (f), 5 V TTL
Gate hi swp out BNC (f), 5 V TTL
VGA output VGA compatible monitor, 15-pin
D-SUB, (31.5 kHz horizontal, 60 Hz
vertical sync rates, non-interlaced)
Analog RGB 640 x 480
Option A4J (IF and Sweep Ports) or Option AYX
Aux IF output BNC (f), 21.4 MHz, nominal -10 to
-70 dBm1(uncorrected)
Aux video out BNC (f), 0 to 1 V1(uncorrected)
Hi swp In BNC (f), low stops sweep
(5 V TTL)
Hi swp out BNC (f), (5 V TTL)
Swp out BNC (f), 0 to +10 V1ramp
GPIB interface
Standard (Option A4H) IEEE-488 bus connector
Serial interface
(Option 1AX) RS-232, 9-pin D-SUB (m)
Parallel interface
Standard 25-pin D-SUB (f), printer port only
Option specifications
Option 1DN tracking generator
Frequency range
E7401A
Option 1DN 9 kHz to 1.5 GHz
E7402A/03A/04A/05A
Option 1DN 9 kHz to 3.0 GHz
Output power level range
Range
E7401A
Option 1DN 0 to -70 dBm
E7402A/03A/04A/05A
Option 1DN -2 to -66 dBm
Resolution 0.1 dB
Absolute Accuracy (at 50 MHz)
Option 1DN ±0.75 dB
Output vernier range
E7401A 10 dB
E7402A/03A/04A/05A 8 dB
Output attenuator range
E7401A 0 to 60 dB, 10 dB steps
E7402A/03A/04A/05A 0 to 56 dB, 8 dB steps
Output flatness
E7401A
Option 1DN
9 kHz to 10 MHz ±2.0 dB
10 MHz to 1.5 GHz ±1.5 dB
E7402A/03A/04A/05A
Option 1DN
9 kHz to 10 MHz ±3.0 dB
10 MHz to 3.0 GHz ±2.0 dB
Effective source match (characteristic)
E7401A < 2.5:1
E7402A/03A/04A/05A < 2.0:1 (0 dB Atten.)
< 1.5:1 (≥ 8 dB Atten.)
1. Characteristic
7
Spurious output
Harmonic spurs
E7401A
(0 dBm output)
9 kHz to 20 MHz <-20 dBc
20 MHz to 1.5 GHz <-25 dBc
E7402A/03A/04A/05A
(-1 dBm output)
9 kHz to 3 GHz <-25 dBc
Non-harmonic spurs
E7401A <-35 dBc
E7402A/03A/04A/05A
9 kHz to 2 GHz <-27 dBc
2 GHz to 3 GHz <-23 dBc
Dynamic range
Maximum output power – displayed average noise level
Power sweep range
E7401A
Option 1DN (-15 dBm to 0 dBm) – (source atten-
uator setting)
E7402A/03A/04A/05A
Option 1DN (-10 dBm to -1 dBm) – (source
attenuator setting)
Preamplifier (standard)
E7401A 100 kHz to 1.5 GHz
E7402A/03A/04A/05A 1 MHz to 3 GHz
(nominal gain 20 dB)
Option Ordering Information
For information on ordering options, please refer to the
ESA/EMC Spectrum Analyzer Configuration Guide (literature
number 5968-3412E).
Agilent Technologies’ Test and Measurement Support, Services, and Assistance
Agilent Technologies aims to maximize the value you receive, while minimizing your
risk and problems. We strive to ensure that you get the test and measurement
capabilities you paid for and obtain the support you need. Our extensive support
resources and services can help you choose the right Agilent products for your
applications and apply them successfully. Every instrument and system we sell has
a global warranty. Support is available for at least five years beyond the production life
of the product. Two concepts underlie Agilent’s overall support policy: “Our Promise”
and “Your Advantage.”
Our Promise
Our Promise means your Agilent test and measurement equipment will meet its
advertised performance and functionality. When you are choosing new equipment, we
will help you with product information, including realistic performance specifications and practical recommendations from experienced test engineers. When
you use Agilent equipment, we can verify that it works properly, help with
product operation, and provide basic measurement assistance for the use of
specified capabilities, at no extra cost upon request. Many self-help tools are available.
Your Advantage
Your Advantage means that Agilent offers a wide range of additional expert test
and measurement services, which you can purchase according to your unique technical and business needs. Solve problems efficiently and gain a competitive edge
by contracting with us for calibration, extra-cost upgrades, out-of-warranty repairs,
and onsite education and training, as well as design, system integration, project
management, and other professional engineering services. Experienced Agilent
engineers and technicians worldwide can help you maximize your productivity, optimize the return on investment of your Agilent instruments and systems, and obtain
dependable measurement accuracy for the life of those products.
www.agilent.com/find/emailupdates
Get the latest information on the products and applications you select.
Agilent T&M Software and Connectivity
Agilent’s Test and Measurement software and connectivity products, solutions and
developer network allows you to take time out of connecting your instruments to
your computer with tools based on PC standards, so you can focus on your tasks,
not on your connections. Visit
www.agilent.com/find/
connectivity
for more information.
By internet, phone, or fax, get assistance with all your test & measurement needs
Online Assistance:
www.agilent.com/find/assist
Product specifications and descriptions in this document subject to change
without notice.
© Agilent Technologies, Inc. 2003, 2001
Printed in USA, April 15, 2003
5968-3662E
Phone or Fax
United States:
(tel) 800 452 4844
Canada:
(tel) 877 894 4414
(fax) 905 282 6495
China:
(tel) 800 810 0189
(fax) 800 820 2816
Europe:
(tel) (31 20) 547 2323
(fax) (31 20) 547 2390
Japan:
(tel) (81) 426 56 7832
(fax) (81) 426 56 7840
Korea:
(tel) (82 2) 2004 5004
(fax) (82 2) 2004 5115
Latin America:
(tel) (305) 269 7500
(fax) (305) 269 7599
Taiwan:
(tel) 0800 047 866
(fax) 0800 286 331
Other Asia Pacific Countries:
(tel) (65) 6375 8100
(fax) (65) 6836 0252
Email: tm_asia@agilent.com
Agilent Email Updates
Loading...
