Agilent 8960 Reference Guide

Download

Agilent Technologies 8960 Series 10 Wireless Communications Test Set

Agilent Technologies E1962B cdma2000/IS-95/AMPS Mobile Test Application

Reference Guide

cdma2000 Test Application Revision B.03

1000-1748 (not orderable)

www.agilent.com/find/8960support/

Notice

except as allowed under the copyright laws. This material may be reproduced by or for the U.S. Government pursuant to the Copyright License under the

clause at DFARS 52.227-7013 (APR 1988).

Agilent Technologies, Inc. Learning Products Department 24001 E. Mission Liberty Lake, WA 99019-9599 U.S.A.

Edition/Print Date

All Editions and Updates of this manual and their creat ion dates are listed below. March 2001 E1962B cdma2000 Test Application Revision B.01 September 2001 E1962B cdma2000 Test Application Revision B.02 November 2001 E1962B cdma2000/IS-95/AMPS Test Application Revision B.03

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

Safety Summary

The following general safety precautions must be observed during all phases of operation of this instrument. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture , and intended use of the instrument. Agilent Tec hnologies Inc. assumes no liability for the customer’s failure to comply with these requirements.

GENERAL

This product is a Safety Cl a ss 1 in st r u m e n t (provided wi th a pro tective eart h te rminal). The pr o tective features of this product may be impaired if it is used in a manner not specified in the operation instructions.

All Light Emitting Diodes (LEDs) used in this product are Class 1 LEDs as per IEC 60825-1. This product has been designed and tested in accordance with IEC Publication 1010, "Safety Requirements f or

Electronic Measuring Apparatus," and has been supplied in a safe condition. This instruction documentation contains information and warnings which must be followed by the user to ensure safe operation and to maintain th e product in a safe condition.

ENVIRONMENTAL CONDITIONS

This instrument is intended for indoor use in an installation category II, pollution degree 2 environment. It is designed to operate at a maximum relative humidity of 95% and at altitudes of up to 2000 meters . Refer to the specifications tables for the ac mains voltage requirements and ambient operating temperature range.

V ent ilation Requireme nts: When inst alling the pro duct in a cabinet, the convection int o and out of t he product must not be restricted. The ambient temp erature (outside the cabinet) must be less than the maximum

operating temperature of the product by 4° C for every 100 watts dissipated in the cabinet. If the total power dissipated in the cabinet is greater than 800 watts, then forced convection must be used.

BEFORE APPLYIN G POWER

Verify that the product is set to match the available line voltage, the correct fuse is installed, and all safety precautions are taken. Note the in strument's external markings described under Safety Symbols.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

GROUND THE INSTRUMENT

To m inimize shock hazard, the instrument chassis and cover must be connected to an electrical protective earth ground. The instrument must be connected to the ac power mains through a grounded power cable , with the ground wire firmly connected to an electric al ground (safet y ground) at the power out let. Any inter rupt ion of the protective (grounding) conductor or disconne ctio n of the protec tive ear th terminal will cause a pote ntial shock hazard that could result in personal injury.

FUSES

Only fuses with the required rated cur rent, voltage , and speci fied type (norma l blow, time delay, etc.) should be used. Do not use repaired fuses or short-circuited fuse holders. To do so could cause a shock or fire hazard.

DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE

Do not operate the instrument in the presence of flammable gases or fumes.

DO NOT REMOVE THE INSTRUMENT COVER

Operating personnel must not remove instrument covers. Component replacement and internal adjustments must be made only by qualified service personnel.

Instruments that appear damaged or defective should be made inoperative and secured against unintended operation until they can be repaired by qualified service personnel.

WARNING The W ARNIN G sign denotes a h azard. It calls attention to a pr ocedure, prac tice, or th e

like, which, if not correctly performed or adhered to, could result in personal injury. Do not proceed beyond a WARNING sign until the indicated conditions are fully understood and met.

CAUTION The CAUTION sign denotes a hazard. It calls attention to an operating procedure, or the lik e,

which, if not corre ctly per formed o r adhered t o , could re sult in damage t o or dest ruction of part or all of the product. Do not proceed beyond a C A UTION sign until the indicat ed conditions are full y understood and met.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

Safety Symbols

Caution, refer to accompanying documents Warning, risk of electric shock Earth (ground) terminal Alternating current Frame or chassis terminal Standby (supply). Units with this symbol are not completely disconnected from ac mains

when this switch is off.

Product Markings

CE - the CE mark is a registered trademark of the European Community. A CE mark accompanied by a year indicated the year the design was proven.

CSA - the CSA mark is a registered trademark of the Canadian Standards Association.

CERTIFICATION

Agilent Technologies cer ti fies th at this pro duct m et it s publis hed sp ecif ica tion s at the ti me of shi pment from the factory. Agilent Technologies further certifies that its calibration measurements are traceable to the United States National Institute of Standards and Technology, to the extent allowed by the Institute’s calibration facility, and to the calibration faci lities of other International Stan d ar d s O r ga nization members

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

Agilent Technologies Wa rranty Statement for Commercial Products

Agilent Technologies 8960 Series 10 Wireless Communications Test Set Agilent Technologies E1962B cdma2000/IS-95/AMPS Mobile Test Application

Duration of Warranty: 1 year

1. Agilent Technologies warrants Agilent Technologies hardware, acces sor ies and supplies against defects in materials and workmanship for the period specified above. If Agilent Technologies receives notice of such defects during the warranty period, Agilent Technologies will, at its option, either repair or replace products which prove to be defective. Replacement products may be either new or like-new.

2. Agilent Technologies warrants that Agilent Technologies software will not fail to execute its programming instructions, for the period specified above, due to defects in material and workmanship when properly installed and used. If Agilent Technologies receives notice of such defects during the warranty period, Agilent Technologies will replace software media which does not execute its programming instructions due to such defects.

3. Agilent Technologies does not warrant that the operation of Agilent Technologies products will be uninterrupted or err or fre e . I f Agilent Technologies is unable , with in a reas onabl e time , to re pair or replace any product to a condition as warra nted, customer will be entitled to a refund of the purchase price upon prompt retu rn of the product .

4. Agilent T echnologies p roducts may contai n remanufactured pa rts equivale nt to new in performance or may have been subject to incidental use.

5. The warranty period begins on the date of delivery or on the date of installation if installed by Agilent Technologies. If customer schedules or delays Agilent Technologies installation more than 30 days after delivery, warranty begins on the 31st day from delivery.

6. Warranty does not apply to defects resulting from (a) improper or inadequate maintenance or calibration, (b) software, interfacing, parts or supplie s not supplied by Agilent Technologies, (c) unauthorized modification or misuse , (d) operation outside of the published en vironmental specifications for the product, or (e) improper site preparation or maintenance.

7. TO THE EXTENT ALLOWED BY LOCAL LA W, THE ABOVE WARRANTIES ARE EXCLUSIVE AND NO OTHER WARRANTYOR CONDITION, WHETHER WRITTEN OR ORAL IS EXPRESSED OR IMPLIED AND AGILENT TECHNOLOGIES SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTIES OR CONDITIONS OR MERCHANTABILITY, SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE.

8. Agilent Technologies will be liable for damage to tangible property per incident up to the greater of $300,000 or the actual amount paid for the product that is the subject of the claim, and for damages for bodily injury or death, to the extent that all such damages are determined by a court of competent jurisdiction to have been direct ly caused by a defective Agilent Technologi es product.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

9. TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS WARRANTY STATEMENT ARE CUSTOMER’S SOLE AND EXCLUSIVE REMEDIES. EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL AGILENT TECHNOLOGIES OR ITS SUPPLIERS BE LIABLE FOR LOSS OF DATA OR FOR DIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA), OR OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE.

FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND: THE WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE RESTRICT OR MODIFY AND ARE IN ADDITION TO THE MANDATORY STATUTORY RIGHTS APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.

SHOULD AGILENT HAVE A NEGOTIATED CONTRACT WITH THE USER AND SHOULD ANY OF THE CONTRACT TERMS CONFLICT WITH THESE TERMS, THE CONTRACT TERMS SHALL CONTROL.

ASSISTANCE

Product maintenance agreements and other customer assistance agreements are available for Agilent Technologies products. F o r any assistance, contact your nearest Agilent Technologies Sales and Service Office.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

Service and Support

Any adjustment, maintenance, or repair of this product must be performed by qualified personnel. Contact your customer engineer through your local Agilent Technologies Service Center. You can find a list of local service representatives on the Web at:

http://www.agilent-tech.com/services/English/index.html If you do not have access to the Internet, one of these centers can direct you to your nearest representative:

United States Test and Measurement Call Center

(Toll free in US) (800) 452-4844

Europe

(31 20) 547 9900

Canada

(905) 206-4725

Japan Measurement Assistance Center

(81) 426 56 7832 (81) 426 56 7840 (F AX)

Latin America

(305) 267 4288 (F AX) Australia/New Zealand 1 800 629 485 (Australia)

0800 738 378 (New Zealand) Asia-Pacific (852) 2599 7777

(852) 2506 9285 (F AX)

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

Regional Sales Offices

United States of America:

Agilent Technologies(tel) 1 800 452 4844 Test and Measurement Call Center P.O. Box 4026

Englewood, CO 80155-4026

Canada:

Agilent Technologies Canada Inc.(tel) 1 877 894 4414 2660 Matheson Blvd. E Mississauga, Ontario L4W 5M2

Europe:

Agilent Technologies(tel) (3120) 547 9999 European Marketing Organization P.O. Box 999 1180 AZ Amstelveen The Netherlands

Japan:

Agilent Technologies Japan Ltd.(tel) (81) 456-56-7832 Measurement Assistance Center(fax) (81) 426-56-7840 9-1 Takakura-Cho, Hachioji-Shi, Tokyo 192- 8510, Japan

Latin America:

Agilent Technologies(tel) (305) 267 4245 Latin America Region Headquarters(fax) (305) 267 4286 5200 Blue Lagoon Drive, Suite #950 Miami, Florida 33126 U.S. A.

Australia/New Zealand:

Agilent Technologies Australia Pty Ltd.AustraliaNew Zealand 347 Burwood Highway(tel) 1 800 629 485 (tel) 0 800 738 378 Forest Hill, Victoria 3131(fax) (61 3) 9272 0749(fax) (64 4) 802 6881

Asia Pacific:

Agilent Technologies(tel) (852) 3197 7777 24/F, Cityplaza One,(fax) (852) 2506 9233 111 Kings Road, Taikoo Shing, Hong Kong

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

DECLARATION OF CONFORMITY

According to ISO/IEC Guide 22 and CEN/CENELEC EN45014

Manufacturer’s Name: Agilent Technologies UK Ltd. Agilent Technologies, Inc. Manufacturer’s Address:

Electronic Products & Solutions Group - Queensferry South Queensferry West Lothian, EH30 9TG Scotland, United Kingdom

24001 E. Mission Avenue Liberty Lake Washington 99019-9599 USA

Declares, that the product Product Name:

8960 Series 10 Wireless Communications Test Set

Model Number: E5515B Product Options: This declaration covers all options of the above product.

Conforms with the following European Directives:

The product herewith compiles with the requirements of the Low Voltage Directive 72/23/EEC and the EMC Directive 89/336/EFC (including 93/68/EFC) and carries the CE Marking accordingly.

EMC Standard

IEC 61326-1:1997+A1:1998/EN 61326-1:1997+A1:1998 CISPR 11:1990 / EN 55011:1991 IEC 61000-4-2:1995+A1:1998 / EN 61000-4-2:1995 IEC 61000-4-3:1995 / EN 61000-4-3:1995 IEC 61000-4-4:1995 / EN 61000-4-4:1995 IEC 61000-4-5:1995 / EN 61000-4-5:1995 IEC 61000-4-6:1996 / EN 61000-4-6:1996 IEC 61000-4-11:1994 / EN 61000-4-11:1994

Limit

Group 1 Class A 4kV CD, 8kV AD

3 V/m, 80-1000 MHz

0.5V signal lines, 1kV power lines

0.5 kV line-line, 1 kV line-ground 3V, 0.15-80 MHz 1 cycle, 100%

[1]

Safety:

IEC 61010-1:1990+A1:1992+A2:1995 / EN 61010-1:1993+A2:1995

Canada CSA C22.2 No. 1010.1:1992

Supplemental Information:

[1]

The product was tested in a typical configuration with Agilent Technologies test systems

14 December 2000

R.M. Evans / Quality Manager

14 December 2000

W.V.Roland / Reliability & Regulatory Engineering Manager

For further information, please contact your local Agilent Technologies sales office, agent, or distributor.

Authorized EU-representative: Agilent Technologies Deutschland GmbH, Herrenberger StraBe 130, D71034 Boblingen, Germany

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

DECLARATION OF CONFORMITY

According to ISO/IEC Guide 22 and CEN/CENELEC EN45014

Manufacturer’s Name: Agilent Technologies UK Ltd. Agilent Technologies, Inc. Manufacturer’s Address:

Electronic Products & Solutions Group - Queensferry South Queensferry West Lothian, EH30 9TG Scotland, United Kingdom

24001 E. Mission Avenue Liberty Lake Washington 99019-9599 USA

Declares, that the product Product Name:

8960 Series 10 Wireless Communications Test Set

Model Number: E5515C Product Options: This declaration covers all options of the above product.

Conforms with the following European Directives:

The product herewith compiles with the requirements of the Low Voltage Directive 72/23/EEC and the EMC Directive 89/336/EFC (including 93/68/EFC) and carries the CE Marking accordingly.

EMC Standard

IEC 61326-1:1997+A1:1998/EN 61326:1997/A1:1998 CISPR 11:1990 / EN 55011:1991 IEC 61000-4-2:1995+A1:1998 / EN 61000-4-2:1995 IEC 61000-4-3:1995 / EN 61000-4-3:1995 IEC 61000-4-4:1995 / EN 61000-4-4:1995 IEC 61000-4-5:1995 / EN 61000-4-5:1995 IEC 61000-4-6:1996 / EN 61000-4-6:1996 IEC 61000-4-11:1994 / EN 61000-4-11:1994

Limit

Group 1 Class A 4kV CD, 8kV AD

3 V/m, 80-1000 MHz

0.5kV signal lines, 1kV power lines

0.5 kV line-line, 1 kV line-ground 3V, 0.15-80 MHz

1 cycle, 100%

[1]

Safety:

IEC 61010-1:1990+A1:1992+A2:1995 / EN 61010-1:1993+A2:1995

Canada: CSA C22.2 No. 1010.1:1992

Supplemental Information:

[1]

The product was tested in a typical configuration with Agilent Technologies test systems

01 May 2001

R.M. Evans / Quality Manager

01 May 2001

W.V.Roland / Reliability & Regulatory Engineering Manager

For further information, please contact your local Agilent Technologies sales office, agent, or distributor.

Authorized EU-representative: Agilent Technologies Deutschland GmbH, Herrenberger StraBe 130, D71034 Boblingen, Germany

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

DECLARATION OF CONFORMITY

According to ISO/IEC Guide 22 and CEN/CENELEC EN45014

Manufacturer’s Name: Agilent Technologies, Inc. Manufacturer’s Address:

24001 E. Mission Avenue Liberty Lake Washington 99019-9599 USA

Declares, that the product Product Name:

8960 Series 10 Wireless Communications Test Set

Model Number: E5515T Product Options: This declaration covers all options of the above product.

Conforms with the following European Directives:

The product herewith compiles with the requirements of the Low Voltage Directive 72/23/EEC and the EMC Directive 89/336/EFC (including 93/68/EFC) and carries the CE Marking accordingly.

EMC Standard

Limit

Group 1 Class A 4kV CD, 8kV AD

3 V/m, 80-1000 MHz

0.5V signal lines, 1kV power lines

0.5 kV line-line, 1 kV line-ground 3V, 0.15-80 MHz 1 cycle, 100%

[1]

Safety:

IEC 61010-1:1990+A1:1992+A2:1995 / EN 61010-1:1993+A2:1995

Canada CSA C22.2 No. 1010.1:1992

Supplemental Information:

[1]

The product was tested in a typical configuration with Agilent Technologies test systems

14 December 2000

W.V.Roland / Reliability & Regulatory Engineering Manager

For further information, please contact your local Agilent Technologies sales office, agent, or distributor.

Authorized EU-representative: Agilent Technologies Deutschland GmbH, Herrenberger StraBe 130, D71034 Boblingen, Germany

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

Manufacturer’s Declaration

This statement is provided to comply with the requir ements of t he German Sound Emiss ion Direct ive , from 18 January 1991.

This product has a sound pressure emiss ion (at the operator position) < 70 dB(A).

• Sound Pressure Lp < 70 dB(A).

• At Operator Position .

• Normal Operation.

• According to ISO 7779:1988/EN 27779:1991 (Type Test).

Herstellerbescheinigung

Diese Information steht im Zusammenhang mit den Anforderungen der Maschinenlärminformationsverordnung vom 18 Januar 1991.

• Schalldruckpegel Lp < 70 dB(A).

• Am Arbeitsplatz.

• Normaler Betrieb.

• Nach ISO 7779:1988/EN 27779:1991 (Typprüfung).

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\cdma2000_titlepage.fm

Contents

Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Instrument Configuration Measurement Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Access Probe Power Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

How is an Access Probe Power measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Considerations when making Access Probe Power measurements . . . . . . . . . . . . . . . . . . . . . . 37

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Analog Transmit Power Measurement Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

How is an Analo g T ra n smit Power measu rement made ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Consideratio n s W he n Maki n g Man u a l Ana l o g Tr a n smit Power Measur ements . . . . . . . . . . . 3 9

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Audio Analyzer Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

How is an analog audio measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

De-Emphasis State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Expandor Reference Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Trigger Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Audio Analyzer Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Audio Frequency Measurement Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Consideratio n s When Making Manua l Aud i o F re q u e n cy M easurements . . . . . . . . . . . . . . . . . 44

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Audio Level Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

How is an Audio Level measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Channel Power Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

How is a Chann e l P ower measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 6

Channel Pow e r Me a su r ement Calibra ti o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Channel Pow e r Me a su r ement Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Code Channel Timing and Phase Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . 48

How is a Code Channel Timing and Phase measurement made? . . . . . . . . . . . . . . . . . . . . . . . 48

Code Channel Time/PhaseMeasurement Graphical Display . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Measurement Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Digital Average Power Measurement Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

How is a Digital Average Power measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Contents

Digital Averag e P o w e r me a su rement chara ct e ri stics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Distortion Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

How is a Distortion measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Consideratio n s W he n Ma ki n g Ma n u a l Distortion Meas u re ments . . . . . . . . . . . . . . . . . . . . . . . 54

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Frame Error Rate Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

How is an FER (frame error rate) measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Confidence Level Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Frequency Modulation (FM) Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

How is a frequency modulation measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Distortion Sta t e a n d D i st o rt i o n Fu n da mental Frequ ency Operation . . . . . . . . . . . . . . . . . . . . 57

Modulation Frequency State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Filter Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Detector Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

De-emphasis State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Expandor State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Frequency Stability Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

How is a frequency stability measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Worst Case Frequency Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Gated Power Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

What is a Gated Power Measurement? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

How is a Gated Power Measurement Made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Gated Power Measurement Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Measurement Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Handoff Waveform Quality Measurement Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

How is a Handoff Waveform Quality measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Measurement Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Measurement Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

SINAD Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

How is a SINAD measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Contents

Consideratio n s W he n Ma ki n g Ma n u a l SI N A D Me a su r ements . . . . . . . . . . . . . . . . . . . . . . . . . 66

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Swept Audio Measurements Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

TDSO Frame Error Rate Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

What is a TDS O (Test Data Service Option) FER (Frame Error Rate ) measuremen t ? . . . . . . 70

How is a TDSO FER Measurement Made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Tx Spurious Emissions Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

How is a Tx Spurious Emissions measurement made? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Tx Spurious Emissions measurement characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Waveform Quality/Code Domain Measurement Description . . . . . . . . . . . . . . . . . . . . . . . . . 76

How is a Wavefor m Quality/Code D o ma i n Po we r measurement m ad e ? . . . . . . . . . . . . . . . . . . 76

Code Domain Power Graphical Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Input Signal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Test Adherence to Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Standards Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 9

Amplitude Offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Call Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Active Cell Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Active Cell Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

AVC Test Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

AVC Test Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

IS-2000 Test Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Forward CDMA channels available in test mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

CW Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

CW Test Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Contents

Selecting a Cellular System Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

Available System Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Setting the Cell Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Cell Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Setting the Radio Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Radio Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Setting the Cell Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Cell Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Setting Cell Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

IS-2000/IS-95 Cell Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Setting Cell Power and AWGN Power Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

RF Power Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Setting Access Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

IS-2000/IS-95 Access Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Setting Registration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

IS-2000/IS-95 Registration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Configuring the F-FCH/Traffic Channel (For ward Fundamental/Traffic Channel). . . . 106

Settable F-FCH Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

GPIB Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Configuring the F-Paging Channel (F-PCH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Settable F-Paging Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Fixed F-Paging Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

GPIB Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Configuring the F-SCH (Forward Supplemental Channel) . . . . . . . . . . . . . . . . . . . . . . . . . 109

Settable F-SCH Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Fixed F-SCH Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

GPIB Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Configuring the F-Pilot Channel (Forward PICH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Settable F-Pilot Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Fixed F-Pilot Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

GPIB Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Contents

Configuring the F-OCNS (Forward Orthogonal Channel Noise Simulator). . . . . . . . . . . 112

Settable F-OCNS Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Fixed F-OCNS Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

GPIB Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Configuring the F-QPCH (Forward Quick Paging Channel) . . . . . . . . . . . . . . . . . . . . . . . . 113

Settable F-QPCH Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Fixed F-QPCH Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

GPIB Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Configuring the F-Sync Channel (Forward SYNC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Settable F-Sync Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Fixed F-Sync Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

GPIB Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Configuring the R-SCH (Reverse Supplemental Channel). . . . . . . . . . . . . . . . . . . . . . . . . . 116

Settable R-SCH Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

GPIB Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Setting the Paging IMSI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Paging IMSI Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Setting Handoff Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118

Handoff Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Establishing an Active Link with the Mobile Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Making a Mobile Station Originated Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Making a Base St a t io n O r iginated Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Performing a Handoff. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Making a Handoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Performing a Registration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Registering a Mobile Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Programming: Getting Started Guide for cdma2000 Mobile Test . . . . . . . . . . . . 124

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Contents

Conventions used in this Getting Started Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

How to use this Getting Started Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Useful on-line links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

About the Programming Examples Presented in this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . 125

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Step 1: Set up the Test Set127

Fully Preset the Test Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Declare Vari ab le s, Set Path Losses an d Ti me o u ts, Activate GPIB De b u gge r . . . . . . . . . . . . . 128

Step 2: Configure Test Set and Mobile Station Parameters. . . . . . . . . . . . . . . . . . . . . . . . . 129

Configure the Test Set Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Configure the Mobile Station Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Step 3: Set Measurement Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Step 4: Make a connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Select an example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Test Set initiated connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Mobile Station initiated connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Step 5: INITiate and FETCh Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

INITiate measurements and FETCh results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Step 6: Reconfigure Test Set and Mobile Station Connection Parameters. . . . . . . . . . . . 137

Reconfigure the Test Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Reconfigure the MS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Step 7: End the Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

End the Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Control Program Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139

HP BASIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Step 1: Set Up the Test Set. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Step 2: Configure Test Set and Mobile Station Parameters. . . . . . . . . . . . . . . . . . . . . . . . . 142

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Step 3: Set Measurement Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Step 4: Make Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Step 5: INITiate and FETCh Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Step 6: Reconfigure Test Set and Mobile Station Connection Parameters. . . . . . . . . . . . 161

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

Step 7: End Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Contents

Programming an Access Probe Power Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 9

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

Programming an Analog Transmit Power Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 0

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Programming an Audio Level Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 2

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

Programming an Audio Frequency Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Programming a Channel Power Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 7

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Programming a Code Channel Time/Phase Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

Programming a Digital Average Power Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 3

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Programming a Distortion Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 5

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Programming an FER (Frame Error Rate) Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Programming a Frequency Modulation (FM) Measurement . . . . . . . . . . . . . . . . . . . . . . . . 189

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 0

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

Programming a Frequency Stability Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 1

Contents

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Programming a Gated Power Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

Programming a Handoff Waveform Quality Measurement . . . . . . . . . . . . . . . . . . . . . . . . . 196

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

Programming a SINAD Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Programming a Swept Audio Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

Programming a TDSO Frame Error Rate Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

Programming a Tx Spurious Emissions Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

Returned Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206

Programming a Waveform Quality/Code Domain Measurement . . . . . . . . . . . . . . . . . . . . 207

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209

Preset Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212

Receiver Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

Manual Receiver Control Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

Manual vs. Automatic Receiver Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

Manual Receiver Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

Automatic Receiver Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214

Effects on Recei v e r Co n t ro l Wh e n Cha n gi n g O pe r a ti n g Mo d e . . . . . . . . . . . . . . . . . . . . . . . . . 215

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215

Status Subsystem Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .216

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237

Statistical Measurement Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238

Contents

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238

Timeouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

Timeout Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

Triggering of Measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .240

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243

Integrity Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

Example Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Measurement Progress Report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

Concurrent Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .249

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

Invalid Measurement Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .250

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250

Dealing With Semicolon Separated Response Data Lists. . . . . . . . . . . . . . . . . . . . . . . . . . . 251

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251

Measurement Event Synchronization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

INITiate:DONE? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

Programming Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

Operating Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254

Call Processing State Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

Call Processing State Query . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258

Call Processing Event Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

Call Processing Subsystem Overlapped Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

Test System Synchronization Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263

Commands used for synchronization: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266

Contents

Diagram Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268

ABORt Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270

Syntax Diagram and Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270

ABORt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271

AFGenerator Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274

AFGenerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275

CALibration Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279

Calibration Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279

Recommended Calibration Intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280

Syntax Diagram and Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280

CALibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281

CALL Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 285

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 285

Syntax Diagrams and Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 285

CALL:ACC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287

CALL[:CELL]:APARameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288

CALL:AVCTest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292

CALL:AWGNoise:POWer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .293

CALL:BAND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296

CALL:CHANnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297

CALL[:CELL]:CLPControl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .299

CALL:CONNected[:STATe] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .300

CALL[:CELL]:CONTrol:DOWNlink:FREQuency:AUTO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304

CALL:D2KTest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 305

CALL:END. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307

CALL[:CELL]:ESCape[:MODE]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308

CALL:FCHannel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309

CALL:FM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312

CALL:HANDoff. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 316

CALL[:CELL]:MCCode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 317

CALL[:CELL]:MNCode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 318

Contents

CALL:MS:ANALog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 319

CALL:MS:REPorted:<BCL,BWT> . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 320

CALL:MS:REPorted:CAPability:CCHannel:DEDicated. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321

CALL:MS:REPorted:CAPability:FCHannel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323

CALL:MS:REPorted:CAPability:QUERy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325

CALL:MS:REPorted:CAPabiltiy:SCHannel:FORWard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 326

CALL:MS:REPorted:CAPability:SCHannel:REVerse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330

CALL:MS:REPorted:CLEar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .334

CALL:MS:REPorted:CPCLass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335

CALL:MS:REPorted:CTXType. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .336

CALL:MS:REPorted:DUAL[:MODE]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 337

CALL:MS:REPorted:<EIRP,ESN>. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 338

CALL:MS:REPorted:<MCC,MIN1,MIN2,MNC,MSIN>. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 340

CALL:MS:REPorted:<ONUM, . . . . . . . . . . . . . . . OPER,PCL,PCON,PNUM,PREV,QPCH>343

CALL:MS:REPorted:<RCON,REG,REV,SCIN,SCL,TXT>. . . . . . . . . . . . . . . . . . . . . . . . . . . . 347

CALL[:CELL]:NIDentity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .350

CALL:OCNSource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 351

CALL[:CELL]:OPERating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .353

CALL:ORIGinate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354

CALL:PAGing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 356

CALL:PILot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 361

CALL[:CELL]:PNOFfset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 363

CALL[:CELL]:POWer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 364

CALL[:CELL]:PROTocol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .368

CALL:QPCHannel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .370

CALL[:CELL]:RCONfig. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .373

CALL:REGister. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374

CALL[:CELL]:RFGenerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .377

CALL:[:CELL]:RLGain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 378

CALL:SCHannel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 379

CALL:SETup:AVC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 388

CALL:SETup:BAND. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .390

CALL:SETup:CHANnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 391

Contents

CALL:SETup:HANDoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 393

CALL:SETup:MS:ANALog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .394

CALL:SETup:SYSTem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 396

CALL[:CELL]:SIDentity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397

CALL[:CELL]:SOPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 398

CALL:STATus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 401

CALL:SYNC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 421

CALL[:CELL]:SYSTem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 423

CALL:TOTal:POWer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 424

CALL:TRAFfic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 426

CALL:TRIGger:TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 429

DISPlay Subsystem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 430

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 430

Syntax Diagram and Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 430

DISPlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 431

FETCh? Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 434

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 434

Syntax Diagrams and Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 434

FETCh:AFANalyzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 435

FETCh:ATXPower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 444

FETCh:CAPPower. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 447

FETCh:CCTPhase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 448

FETCh:CFERror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 452

FETCh:CPOWer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 454

FETCh:CTXSpurious . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 456

FETCh:DAPower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 459

FETCh:FM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 461

FETCh:FSTability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 467

FETCh:GPOWer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 472

FETCh:HWQuality. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 475

FETCh:SAUDio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 477

FETCh:TFERror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 482

FETCh:WQUality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 484

INITiate Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 492

Contents

Syntax Diagra ms and Comman d Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 492

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 492

INITiate Programming Examples (how INIT commands are used) . . . . . . . . . . . . . . . . . . . . . 492

INITiate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 494

READ? Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 499

Syntax Diagra m and Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 499

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 499

Program Example - READ:DAPower? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500

READ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 501

RFANalyzer Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 513

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 513

RFANalyzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 514

RFGenerator Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 521

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 521

Syntax Diagra ms and Comman d Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 521

RFGenerator: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OUTPut522

SETup Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 523

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 523

Syntax Diagra ms and Comman d Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 524

SETup:AFANalyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 525

SETup[:ALL]:CONTinuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .533

SETup:ATXPower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 534

SETup:CAPPower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 538

SETup:CCTPhase. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 541

SETup:CFERror. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 545

SETup:CPOWer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 549

SETup:CTXSpurious . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 553

SETup:DAPower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 557

SETup:FM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 561

SETup:FSTability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 567

SETup:GPOWer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 571

SETup:HWQuality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 575

SETup:SAUDio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 577

SETup:TFERror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 586

SETup:WQUality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 589

Contents

STATus Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 593

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 593

Syntax Diagrams and Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 593

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 593

STATus:OPERation: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 594

STATus:PRESet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 614

STATus:QUEStionable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 615

Status Byte Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 640

Standard Event Status Register. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 641

SYSTem Subsystem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 644

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 644

Syntax Diagrams and Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 644

SYSTem:APPLication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 645

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 651

SYSTem:BEEPer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 652

SYSTem:CONFigure:INFormation:HARDware:VERBose? . . . . . . . . . . . . . . . . . . . . . . . . . . 653

SYSTem:COMMunicate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 654

SYSTem:CORRection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 658

SYSTem:CURRent:TA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 664

SYSTem:DATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 665

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 665

SYSTem:ERRor? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 666

SYSTem:MEASurement:RESet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 667

SYSTem:PRESet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 668

SYSTem:ROSCillator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 670

SYSTem:SYNChronized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 671

SYSTem:TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 672

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 672

SYSTem:TZONe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 673

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 673

SYSTem:UTC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 674

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 675

IEEE 488.2 Common Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 676

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 676

See also . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 677

How Do I Make Measurements on a Mobile Station? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 680

Contents

A. Establish a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 680

B. Select measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 680

How Do I Change the Measurement Setup? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 681

A. Select a measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 1

B. Set up the measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 681

How Do I Turn Off a Measurement? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 682

How Do I Set Up a Call? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 683

How Do I Set Up an IS-2000 Call? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 683

How Do I Set Up an IS-95 Call? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 684

Repeat Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 685

How Do I Change Call Parameters? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 686

How Do I Change Cell Information? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 687

A. Set cell parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 687

B. Set access parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 688

C. Set registration parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 8 9

How Do I Change Code Channel Levels? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 690

How Do I Perform a Handoff?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .691

How Do I Configure the Test Set for My Test System? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 692

A. Configure instrument information and setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 692

B. Set amplitude offsets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 692

C. Check message log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 3

How Do I End a Call? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 694

cdma2000/IS-95/AMPS Measurement Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 695

Measuring Waveform Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 695

Measuring Handoff Waveform Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 696

Measuring Digital Average Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 698

Measuring Channel Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 699

Measuring Access Probe Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 699

Measuring Fra me E rr o r R a te (F E R ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 700

Measuring TD SO (T e st Data Servic e O p ti o n ) F ra me Error Rate (F E R ) . . . . . . . . . . . . . . . . . 700

Measuring Code Domain Power and Code Domain Power + Noise . . . . . . . . . . . . . . . . . . . . . 701

Measuring Cod e Ch a n n e l T i me /P h a se Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 703

Measuring Gated Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 704

Measuring TX Spurious Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 706

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 706

Front Panel Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 707

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 707

Rear Panel Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 709

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 709

Contents

Remote/Local Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 714

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 714

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 714

Printing Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 715

Printing and Saving Screen Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 715

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 720

Instrument Status Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 721

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 721

Access Probe Power Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 724

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 724

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 724

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 724

Analog Transmit Power Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 725

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 725

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 725

AFANalyzer Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 726

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 726

Interpreting Integrity Indicator Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 726

Code Channel Time/Phase Error Measurement Troubleshooting . . . . . . . . . . . . . . . . . . . 727

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 727

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 727

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 727

Channel Power Measurement Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 728

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 728

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 728

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 729

Digital Average Power Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 730

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 730

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 730

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 730

Frame Error Rate Measurement Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 731

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 731

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 731

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 731

Frequency Modulation (FM) Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 732

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 732

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 733

Frequency Stability Measurement Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 734

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 734

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 734

Contents

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 734

Gated Power Measurement Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 735

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 735

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 735

Handoff Waveform Quality Measurement Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 736

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 736

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 736

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 736

Swept Audio Measurement Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 737

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 737

Interpreting Integrity Indicator Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 737

TDSO FER (Frame Error Rate) Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 738

TDSO FER Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 738

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 738

Tx Spurious Emissions Measurement Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 739

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 739

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 739

Waveform Quality Measurement Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 740

Possible Setup Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 740

Interpreting Integrity Indicator values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 740

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 740

Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 741

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 741

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 742

Error Message Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 743

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 743

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 743

Fixed Timer Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 744

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 744

Manual User Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .747

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 747

Device Specific MUI Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 748

-400 through -499 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 752

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 752

-300 through -399 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 753

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 753

-200 through -299 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 755

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 755

-100 through -199 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 758

Contents

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 758

+100 through +199 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 762

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 762

Device Specific Gene ral Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 765

+200 through +299 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 767

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 767

+300 through +399 Link Control Device-Specific Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . 770

+400 through +499 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 771

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 771

+500 through +599 Test Application Hardware Device-Specific Error . . . . . . . . . . . . . . . 774

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 774

+600 through +699 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 775

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 775

+700 through +799 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 776

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 776

+800 through +899 Error Message Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 778

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 778

Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 779

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 779

Forward Channel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 784

Test Mode Forward Channel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 784

Active Cell Forward Channel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 784

Data Patterns/Rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 785

Closed Loop Power Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 786

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .787

Obtaining Identification Information (*IDN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 788

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 788

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 788

Hardware Configuration Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 789

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 789

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 790

cdma2000/IS-95/AMPS Revision Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 791

B.03 release - November 2001 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 791

B.02 release - September 2001 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 793

B.01 release - March 2001 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 797

Display Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 799

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 799

Contents

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 799

Display Mode (Track/Fast) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800

Writing Messages to the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 801

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 801

Test Set Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 802

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 802

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 802

Timebase Description/Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 803

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 803

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 803

Configuring the Test Set’s LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 804

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 804

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 805

Configuring the Test Set’s GPIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 806

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 806

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 806

Configuring System Time and Date. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 807

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 807

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 807

Test Application Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 808

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 808

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 809

Test Application Revisions and Licenses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 810

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 810

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 811

Test Application Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 812

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 812

Related Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 812

Contents

Measurements

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\ch_measurements.fm

Instrument Configuration Measurement Matrix

The following table shows which measurements are available for the various instrument configurations.

Table 1.

IS-2000 Test

RC3, RC4,

RC5

RC1,

RC2

AVC Test

Mode

Cell

Off

IS-2000

RC3, RC4,

RC5

Active Cell

RC1,

RC2

IS-95 AMPS

Digital Average Power XX XX Channel Power XX XX Wavefo rm Qu ality, Code Dom ain X

Access Probe Power XX Frame Error Rate XX TDSO Frame Error Rate X Handoff Waveform Quality X Gated Power XX Time Response of Open Loop Power XX XX Code Channel Time and Phase XX TX Spurious Emissions XX XX Analog TX Power XXX Frequency Stability XXX FM: deviation, distortion, frequency XXX

Audiob: level, SINAD, frequency,

XX XXXXXX

distortion, swept audio

a. Code domain is not available in RC1, RC2, or IS-95, but it is displayed on the instrument’s display for these

configurations.

b. These are instrument selection measurements. They are supported in all states.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_matrix.fm

Access Probe Power Measurement Description

How is an Access Probe Power measurement made?

The access probe power measurement is a channel power measurement (see “Channel Power Measurement

Description” ) triggered by a rise in RF power detected on the test set’s RF input. The pow er threshold is

approximately -55 dBm/BW. Access probe sequences are transmitte d by the mobile station during registrations or mobile station originated

calls. Access prob e sequences con si st of a series of RF po w e r “steps” which increase in power according to the step size setting until the maximum number of steps is reached or the call processing event completes, for example when the call connects.

When the test set is making access probe power measurements in the continuous trigger arm state, it will display the power level of the most recent access probe power measurement.

Considerations when making Access Probe Power measurements

IMPORTANT Access probe power measurements must not be left in Continuous Trigger Ar m mode. Attempt ing

any other measurements while in this state will result in 4 dashes (----) .

The access probe measurement setup menu provides control over the following access probe parameters:

• Number of Steps in the access probe sequence (NUM_STEP in the standards).

• Power Step (PWR_S TEP in the standards). This parameter specifies the step increase in transmit power

between each access probe within an access probe sequence.

• Maximum Request Sequence (MAX_REQ_SEQ in the standards). This parameter specifies the maximum number of acce ss probe sequence s fo r an ac c e ss ch a n n el request.

Changing the number of steps and s tep s ize wil l affec t the p ower l evel disp la yed if more t han on e acces s prob e is transmitted by the mobile station. However, the number of access probes transmitted depends on whether or not the test set responds by acknowledging the access request, thereby ending the access attempt. To prevent the test set from responding to the access probe request, turn the Call Limit Mode feature On (key F10 in Call Parms , 2 of 3 screen). For the GPIB command syntax, see “CALL:CONNected:LIMit[:STATe]” .

To measur e o nly the f irst acc ess p robe and p revent t riggering on subs eque nt acces s p robes, set Trigger Arm in the Access Probe P ower Setup menu to Single and press the START SINGLE hardkey.

When the mobile station performs any type of registration, an access probe power measurement will likely be triggered. Registrations can occur on mobile sta tion power-up, which is a function of the mobi le station’s programming. Registrations may be requested by the test set at pre-determined time intervals, which will periodically cause the access pro be power measurement to update . To control timer based registrations , access the Registration Parameters menu (see “C. Set registration parameters.” ). For GPIB syntax information on timer-based registrations, see “CALL:REGister” .

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_accprobe_desc.fm

Access Probe Power Measurement Description

Input Signal Requirements

See “Input Signal Requirements”

Analog Transmit Power Measurement Description

How is an Analog Transmit Power measurement made?

Analog Transmit Power measures the mean power from the mobile at the test set’s RF IN/OUT port when transmitting an analog carrier. The test set correctly measures the level with or without frequency modula tion (FM) present to make AMPS power measurements. Tests can be made with the mobile in the analog test mode or when connected on an active voice channel. See IS-137A, section 3.2.1.1, Analog RF Power.

The trigger source for this measurement i s always immediate.

Input Signal Requirements

The Analog Transmit Power measurement meets or exceeds specifications when the following requirements are met:

• The frequency of the signal being measured must be in the range of 800 MHz to 960 MHz or 1.7 GHz to

2.0 GHz, and within 100 kHz of the expected frequency.

• The signal level into the test set’s RF IN/OUT connector must be in the range of - 25 dBm to +43 dBm peak, and within 3 dBm of the expected input power to meet specifications. Results are provided for signals within +5 dB to -10 dB of the expected power, but performance is not warranted.

See “Active Cell Operating Mode” on page 90, and “Receiver Control” on page 213 for information on setting the expected input frequency and power level.

Considerations When Making Manual Analog Transmit Power Measurements

When manually controlling the test set from the front panel, all measurement s def ault to using continuous triggering. If you make digital measurements on a DTC using RF Rise or Protocol triggering, and then hand off to an AVC and select an analog measurement, the analog measurement may not trigger and display a result. This is because the digital measurement is still waiting for a burst transmission to trigger it (which it won’t get from an analog signal) and therefore the measurements “freeze”. To prevent this from happening when making analog measurements, either turn off the digital measurements or set their tri gger source to Immediate.

Audio Analyzer Measurement Description

How is an analog audio measurement made?

The Audio Analyzer can measure Audio Level (V), SINAD (dB), Distortion (%), and Audio Frequency. Measurements are made through the test set’s front panel AUDIO IN connectors. When measuring a mobile’s audio output, the audio signal may come from either an acoustic coupler or from a test interface connection to the mobile’s audio circuitry.

See “Audio Analyzer Block Diagram” on page 43. The AUDIO IN connectors feed the inputs to a floating-input differential amplifier, with each input having an

impedance of about 100,000 ohms to c hass is ground. For best noise immunity, connect the audio signal and its ground reference to the two input ports throug h shielded coaxial cables, or input the signal to the AUDIO IN HI connector and ground the AUDIO IN LO connector’s center contact.

None of the analog audio measurement results are affected by the Amplitude Offset setting.

SINAD/Distortion State

Select On or Off to enable or disable the SINAD and Distorti on measure ments. When On, these measurement results are displayed belo w the Audio Level measurement and the SINAD/Distortio n Fundamental F requency must be entered to specify the audio fre quency for t he measurement (range: 100 Hz to 10 kHz). Whe n Off , four dashes are displayed in place of the measurement results.

Audio Frequency State

Select On or Off to enable or disable the Audio Frequency measurement.

Filt er Type

• None - no filtering is provided (default).

• 100 Hz BW Band Pass Filter (Tunable) - The 100 Hz BW BPF Center Frequency setting is available when

this filter is selected, and can be set in the range of 300 Hz to 15 kHz.

• C-Message

• 50 Hz to 15 kHz

• 300 Hz to 15 kHz

Detector Type

Select either Peak or RMS (default) for making and displaying an Audio Level measurement (does not affect other measurements). The type of detector s elected is displ aye d next to the Au dio Level measurement re sul ts. A 1-volt rms sinewave input signal would measure 1.414 V

input signal would measure 0.707 V

when the RMS detector is used.

RMS

when the Peak detector is used. A 1-volt peak

Peak

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_afan_desc.fm

Audio Analyzer Measurement Description

Expected Peak Voltage

The Expected Amplitude sets the analog audio clipping level and must be set. This voltage is always the absolute peak audio input signal voltage expected at the AUDIO IN connectors, and must be in the range of

7.07 mV

1.414 V

(5 mV

peak

expected voltage value to avoid clipping (over-driving) the input.

peak

) to 20 V

rms

. Remember, measuring a 1-volt rms sinewave input signal would require a

peak

De-Emphasis State

Set to On or Off (default) to enable or disable 750 microsecond de-emphasis.

Expandor Reference Level

Set value from 10 mV/kHz to 10 V/kHz, or Off (default). Entering a numeric value automatically turns the state to On. Entering Off disables the expandor (s tate = off).

Trigger Source

Audio Analyzer measurements use immediate triggering and are continuously re-triggered by the analyzer any time the Trigger Arm parameter is set to Continuous. Trigger timing is independent of any mobile protocol signaling.

Considerations When Making Manual Audio Analyzer Measurements

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_afan_desc.fm

Audio Analyzer Measurement Description

Audio Analyzer Block Diagram

UDIO IN

Expected Peak

Voltage

Measurement

Receiver and

Sampler

100 Hz BW BPF

Center Freq.

100 Hz BW BPF

None

C-Message

50 Hz - 15 kHz

Expandor Reference

De-Emphasis State

750 µs De-emphasis Expandor

SINAD/Distortion

Fundamental

Freq.

SINAD/Distortion

Off

SINAD/Distortion State

RMS

Level

SINAD &

Distortion

Results

Audio

Level

Result

300 Hz - 15 kHz

Filter Type

Audio Frequency Measurement Description

Considerations When Making Manual Audio Frequency Measurements

Audio Level Measurement Description

How is an Audio Level measurement made?

Audio Level measures the AC voltage of the si gnal applied to t he front-panel AUDIO IN connectors, and is one of the Audio Analyzer measurements. Audio Level can be measur ed for signals in the frequency range of 100 Hz to 20 kHz, at l evels from 1 mV

peak

to 20V

and can be made using an rms or peak detector. The type of detector being used for the measurement is displayed next to th e measurement value.

When measuring very low voltages, it may be helpful to use the Audio Analyzer’s adjustable bandpass filter and the rms detector to reduce noi se components.

For information on using the Audio Analyzer, see “Audio Analyzer Measurement Description” on page 40. This measurement is not affected by the Amplitude Offset setting.

Considerations When Making Manual Audio Level Measurements

. The measurement is made after any filtering is applied,

peak

Channel Power Measurement Description

How is a Channel Power measurement made?

Channel power measurements are made by analyzing a digitized version of the input signal’s downconverted IF using the test set’s DSP (see “Block Diagram” ). Triggering occurs on the test set’s internal 20 ms frame clock. The measurement is cross-calibrated with the detected average power to determine the absolute power level.

Channel power measurements are limited to a 1.23 MHz bandwidth, and can be made on either power-gated or non-power-gated input signals.

Channel Power Measurement Calibration

Channel power measurements are calibrated using the “CALibration:CPOWer?” command. Refer to

“CALibration Subsystem” for a description of channel power calibration.

Channel Power Measurement Speed

There are two channel power measurement speeds, fast and normal. See “SETup:CPOWer:MSPeed” for GPIB command syntax.

Normal channel power measurements, like average power measurements, analyze a 10 millisecond sample of the input signal, which is one-half of a CDMA frame. Since there is always at least one “on” power control group in each half-frame the test set is able to “search” for and measure power during at leas t one “on” period . Therefore, normal channel power measurements can be made when the mobile station is transmitting less than full data rate, or is in one of the echo service options (mobile station is gating its output power according to speech act i vi ty ).

Fast channel power measurements do not perform the search for “on” power control groups. Fast channel power measurements only sample the input signal for 1.25 milliseconds, and are applicable only when the input signal power is not power-gated. An example of a condition which would result in the mobile station transmitting a non power-gated signal would be when the mobile station is in a loopback service option (on a call or not) and is transmitting full-rate data.

Input Signal Requirements

The channel power measurement meets or exceeds specifications when the following input signal requirem en ts are met:

• The frequency of the signal being measured must be within the range of 412 MHz to 483 MHz, 800 MHz to 960 MHz, or 1.7 GHz to 2.0 GHz, and be within 100 kHz of the expected frequency.

• The average power level of the signal at the RF IN/OUT connector must be between -61 dBm to +37 dBm. The test set can autorange to a signal that is bet we en +8 dBm to -20 dBm of the exp ected level (see

“RFANalyzer:AUTO:POWer[:SELected]?” ).

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_cpower_desc.fm

Code Channel Timing and Phase Measurement Description

How is a Code Channel Timing and Phase measurement made?

This measurement is designed to analyze signals that contain a rever se pilot channel. A call must be connected with one of the following radio configurations selected:

• Fwd3, Rvs3

• Fwd4, Rvs3

• Fwd 5, Rvs4

Each code channel timing and phase measurement tests the time and phase alignment of each code channel relative to the reverse channel pilot signal. The time erro r returns any offset, in nanoseconds, that is detected between the coding of each Walsh channel and the reverse channel pilot. The phas e error measurement determines whether there is any phas e difference , as sh own in Figure 1., that would cause a rotation in the I/Q constellation away from the decision points.

Figure 1. I/Q Constellation Showing Phase Error

Code channel time/phase error measurements are made by sampling the down- converted input signal, then applying DSP (Digital Signal Processing) techniq ues to determine the original data input to the mobile station transmitter’s Walsh spreading function for each channel. The DSP then generates a representation of what the “ideal” signal would be given the coding and data in use at the time of transmi ssion. The ide al wa veform is then compared with the wavef orm being measured to determine code channel time error and phase error.

A Code Channel Time/Phase Error display is shown below.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_codechan_desc.fm

Figure 2. Code Channel Time/Phase Error

Code Channel Timing and Phase Measurement Description

NOTE If the amount of timing or phase error is negligible, the red error bars may momentarily

disappear.

Table 2. on page 49 lists the code channel time and phase measurement results:

Table 2. Code Channel Time/ Phase Error Measurement Results

Code Channel Time/Phase Error

Code Channel Time Code Channel Phase

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_codechan_desc.fm

Code Channel Timing and Phase Measurement Description

Code Channel Time/PhaseMeasurement Graphical Display

The Code Channel measurement displa ys up to 16 bins1 of timing error information and 16 bins of phase e rror information. Each bin represents one active code channel.

The IS-2000 system achieves high data rates by combining multiple code channels. To facilitate the display of high data rate channels in contiguous blocks, the Walsh code sequence along the graph’s x-axis is displayed in “bit reversed” order. See Table 3. “Walsh Numbering on Code Channel Timing and Phase Graphs”

The code channel sequence along the graph’s x-axis is displayed in “bit reve r s e d” order. See Table 3. “Walsh

Numbering on Code Channel Timing and Phase Graphs”

Table 3. Walsh Numbering on Code Channel Timing and Phase Graphs

Bin Number (with spreading factors = 16)

Walsh Code Channel

0123456789101112131415

0841221061419513311715

The timing and phase graphs, because of the bit-reversed order, can display channels with a spreading factor less than 16, such as the R-SCH (Reverse Supplemental CHannel), using one bin.

For example, Figure 3. shows four active code channels displa yed in four bins . In b in four, Walsh code cha nnels 1, 3, 5, 7, 9, 1 1, 13, and 15 are a ll i ncl uded in a single c hannel. If t he Walsh numbering on the test set’s dis pla y were sequential, the this channel would have to be displayed as eight bars, each separated by one Walsh code.

1. Bins are the bars that appear on the graph. When high data rate channels such as the F-SCH channel are transmitted from the

mobile station, wider bins are displayed. The wider bins represent code channels that occupy multiple orthogonal channels.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_codechan_desc.fm

Figure 3. Code Channel Timing Graph With R-SCH

Bin 2 - Walsh code 4

Spread Factor 16

Bin 3 - Walsh code 2

Spread Factor 4

Bin 1 - Walsh code 8

Spread Factor 16

Code Channel Timing and Phase Measurement Description

Bin 4 - Walsh code 1

Spread Factor 2

An example of bit reversal is shown in Figure 4. Bin 13 has a binary coded decimal value of 1101. If you reverse that sequence, the result is 1011. When 1011 is converted back to a decimal value, the result is Walsh code 11.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_codechan_desc.fm

Code Channel Timing and Phase Measurement Description

Figure 4. Walsh Channel Bit Reversal

Bin 13

Walsh 11

Measurement Behavior

Bin 0 corresponds with Walsh will always return zero for Time Error zero and phase error because all other measurments are relative to the pilot channel, which is located at Walsh 0, bin 0.

Input Signal Requirements

The Code Channel Timing and Phase measurement meets or exceeds specifications when the following requirem en ts are met:

• The frequency of the signal being measured must be in the range of 412 MHz to 483 MHz, 800 MHz to 960 MHz, or 1.7 GHz to 2.0 GHz, and within 100 kHz of the expected frequency.

• The signal level into the test set’s RF IN/OUT connector must be in the range of -25 dBm to +37 dBm, and within 9 dBm of the expected input power (see “RFANalyzer:AUTO:POWer[:SELected]?” ) to meet specifications.

Digital Average Power Measurement Description

How is a Digital Average Power measurement made?

Digital average power measurements are broadband power measurements made on the RF input before frequency downconversion (see “Block Diagram” ). Digital average power measurements return the true rms power level of the input signal. Triggering is handled by internal mechanisms and autoranging is us ed. No external triggering is available.

The input waveform is det ected by a peak detector with sufficient AM bandwidth to track the instan taneous power changes of a CDMA signal. Each measurement is made by analyzing a 10 milliseco nd period (one-h alf of a frame) of the detected waveform.

The test set’s digital signal processo r (DSP) determines the true rms value of the si g n al. If the input signal is power-gated, only the active power control groups will be measuremed.

This measurement uses autor anging based on the open loop p ower control resp onse of the mobile station t o set up the receiver signal path attenuation.

Digital Average Power measurement characteristics

The digital average power measurement has greater than 2 GHZ bandwidth. For this reason, significant signal energy outside the IS-2000 SR1 (1.25 MHz) signal bandwidth will incre ase the measured value.

This measurement can be made on signals that are power-gated or signals that are not power-gated. It is not necessary to specify whether the input signal is power-gated.

Input Signal Requirements

The digital average power measurement meets or exceeds specifications when the following requirements are met:

• The frequency of the signal being measured must be in the range of 412 MHz to 483 MHz, 800 MHz to 960 MHz, or 1.7 GHz to 2.0 GHz.

• The signal level into the test set’s RF IN/OUT connector must be between +37 dBm and -30 dBm. The test set can autorange to a signal that is between +8 dBm to -20 dBm of the expected level (see

“RFANalyzer:AUTO:POWer[:SELected]?” ).

Distortion Measurement Description

How is a Distortion measurement made?

Distortion is an audio quality measurement that compare s the audio signal level fro m the mobile at a specifi ed (desired) frequency to the level of signals present at other frequencies. The audio signals from the mobile are typically demodulated tones sent over an analog voice channel (AVC).

The test set makes two measurements to determine distortion. First, the test set meas ures the total audio signal level into the Audio Analyzer. Next, a precise notch filter is then used to remove the signal at the specified frequency. The remaining signal level indicates the level of unwanted signals (distortion). Distortion is expressed as a percentage of the total audio signal.

Distortion can be measured in the range of 100 Hz to 10 kHz. F or infor mation on using the Audio Analyzer, see

“Audio Analyzer Measurement Description” on page 40.

The distortion measurement can be us ed to perf orm the audi o harmonic di st orti on test. In this tes t, tw o audio signals are used: a 1004 Hz tone and the 6000 Hz SAT. The 1004 Hz tone is notched out to make the measurement. See IS-137A, section 2.2.2.5 for more information.

Considerations When Making Manual Distortion Measurements

Frame Error Rate Measurement Description

How is an FER (frame error rate) measurement made?

FER measurements are used to test the performance of a mob ile station receiver. During each FER measurement the test set sends a sequence of bits to the mobile station and the mobile

station attempts to demodulate and re-transmit the same bits back to the test set. The test set keeps a running count of the measured frames and the number of frames that contained bit errors.

A call must be connected with a loopback service option selected (see “CALL[:CELL]:SOPTION” ) to perform frame error rate measurements.

Intermediate measurement results are periodically available on the front panel display, but are not available programmatically through the GPIB interface.

Confidence Level Description

Confidence level testing is a feature of FER measurements that applies s tatistical analysis to FER measurements so that pass/fail test re su l t s ca n be ob tained in the sh or test possibl e ti me. When confid e n ce level is on, the FER measurement will keep track of the number of frames measured, the number of frame errors, and perform a statistical analysis of the probability that the value entered in the FER requirement field will (or will not) be exceeded.

The confidence level parameter is typically set at 95 p ercent. Each FER measurem ent will return a P ass result before the maximum frame count is reached if statistically there is a 95 percent probability that the percentage of frame errors would not exceed the FER requirement value if the measureme nt were allowed to reach the maximum frame count. The FER measurement will return a Fail result before the maximum frame count is reached if statistically there is a 95 percent probability that the percentage of frame errors counted would exceed the FER requirement if the measurement were allowed to reach the maximum frame count. If confidence level is off, or the number of frame errors counted did not result in a pass or a fail result, max frames will be returned and the measurement result will be the FER percentage.

Several hundred frames of data must be measured before confidence limit checking can begin. A speed-up feature, which is always active, allows the test s et to end an FER measurement before reaching the minimum number of frames required to apply confidence limit chec k ing. The speed-up feature calculates a maximum value of frame errors allowed before confidence limit c hecking begins, and ends the FER measurement with a fail indication if this limit is exceeded.

Input Signal Requirements

The FER measurement meets or exceeds specifications when the following requirements are met:

• The frequency of the signal being measured must be in the range of 412 MHz to 483 MHz, 800 MHz to 960 MHz, or 1.7 GHz to 2.0 GHz, and within 100 kHz of the expected frequency.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_fer_desc.fm

Frame Error Rate Measurement Description

Frequency Modulation (FM) Measurement Description

How is a frequency modulation measurement made?

The Analog Frequency Modulation measurement measures the frequency deviation and, if enabled, the total harmonic distortion and modulation frequency, for frequency modulated analog signals (such as AMPS transmitters). Measurements are performed after any filtering, de-emphasis, and expansion are performed (selected by the user in the setup parame ters).

The distortion value is not returned if the Distortion State is set to OFF. The modulation frequency value is not returned if the Modulation Frequency State is set to OFF.

The FM deviation and distortion measurements are not affec ted by a static (constant) frequency error on the input signal as long as the input signal is within 2.5 kHz of the expected frequency.

This measurement is not used for digital signals . Refer to IS-137, 3.3.1, for more information on measuring analog modulation characteristics.

Triggering

Triggering is always immed iate for this measurement. Trigger Delay and other trigger sources are not use d.

Considerations When Making Manual FM Measurements

Distortion State and Distortion Fundamental Frequency Operation

The Distortion Fundamental Frequency value specifi es the demod ulated audio freq uency to use when making a distortion measurement, and must be entered to make a valid measurement. However, specifying the fundamental frequency does not affect the measur ement state. The Distortion State must be turned On

separately to make the measurement.

Modulation Frequency State

The modulation frequency measurement is enabled and disabled using the Mod Freq State setting. The modulation frequency measurement is made after any filtering is applied, and can be used to make measurements such as SAT frequency.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_fm_desc.fm

Frequency Modulation (FM) Measurement Description

Filter Type

The following filters are available to make measurements on the demodulat ed FM (baseband) signal.

• None - no filtering is provided (default).

• 100 Hz BW Band Pass Filter (Tunable) - The 100 Hz BW BPF Center Frequency setting is available when

this filter is selected, and can be set in the range of 300 Hz to 15 kHz.

• C-Message

• 50 Hz to 15 kHz

• 300 Hz to 15 kHz

Detector Type

Select the type of detector to use when making FM deviation measurements: RMS, Peak+, Peak-. The Peak+ and Peak- det ect ors me asure th e gre atest po sit ive o r n egative fr equenc y excur sion i n carrie r f req uency during the sample. The RMS detector measures the root mean squared value. This setting does not affect the distortion measurement.

De-emphasis State

Select On or Off to enable or disable (respectively) 750 µs de-emphasis.

Expandor State

Select On to compensate for signal compression on the mobile’s transmitted signal.

Frequency Stability Measurement Description

How is a frequency stability measurement made?

The Frequency Stability measurement measures the transmitter frequency and frequency error of analog signals (including AMPS) with a 1 Hz resolution. Frequency Error is determined by comparing the frequency of the measured signal to the expected frequency. These parameters are determined by the receiver control settings (see “Manual Receiver Control Parameters” on page 213).

Operating Considerations

This measurement is performed with the test set’s CW operating mode (see “CALL[:CELL]:OPERating” ). This measurement is not used for digital signals . For the bes t accuracy, connect the timebas e of the sig nal so urce with t he test set’s timebase. See “10 MHZ REF

IN” on page 713 and “10 MHZ REF OUT” on page 713.

Input Signal Requirements

The received signal’s freque ncy must be within the interval 293 MHz to 2.7 GHz and be within 200 kHz of the expected frequency. See “Measurement receiver frequency” on page 214.

The power level of the signal source must be between -30 to +43 dBM and be within 3 dB of the expe cted power. See “CW receiver power” on page 213.

If the received signal has FM, the modulation index must be no greater than three and the modulation frequency must be between 100 Hz and 15 kHz.

Worst Case Frequency Error

Frequency and Frequency Error measurement results are returned over GPIB in units of Hz. Worst Case Frequency Error, the greatest error measured during the total sample( s), is retu rned in units of ppm (parts pe r million). Worst Case Frequency error is only displayed on the test set’s display when multi-measurements are used, but is always available via GPIB (regardless of the multi-measurement state).

Triggering

Triggering is always immed iate for this measurement. Trigger Delay and other trigger sources are not use d.

Gated Power Measurement Description

What is a Gated Power Measurement?

Gated power measurements provide a graphical representation of the time response of the mobile station average transmitter power during periods when the power is gated on. During power gated transmission, power from the mobile station is deliv ered in burs ts. A measurement mask delineates the boundaries th at the signal’s amplitude trace must conform to.

Four views of the power versus time graph are available after the test set analyzes measurement data. The resolution of the traces has been designed to provid e detail at the most critical points in the trace. There are four views available:

• Rise

• Fall

• Full

• Zoomed

The Rise (part of Rise/Fall) trace details the rising edge of the burst, from -15 uS to +10 uS relative to the beginning of the burst. The beginning of the burst corresponds with the gated-on power control group clock

edge The F all (part of Rise/Fall) trace details the falling edge of the burst, from 1237 to 1262 uS after th e beginning

of the burst. The Full (part of Full/Zoomed) trace encompas ses t he enti re burst with decr eased re sol ution. This trace spans

the time perio d from -15 uS to 1 26 2 u S re l a tive the the beg i n n i n g of th e b u rst. The Zoomed (part of Full/Zoomed) trace details the area highlighte d by a vertical bar displayed on the Full

trace. This vertical bar can be positioned in any one of 14 locations alo ng the entire length of the zoomed burst. (The extreme left and right vertical bar positions encompass the Rise/Fall time periods.)

A marker displaying the power level (from +10 to -45 dB) at each time increment is provided for all traces except for Full. If a gated power measurement fails , the marker will be automatically positioned at the first fail point.

A measurement progress report, showing the number of mea sur eme n ts in a multi-measurement, is displayed on the test set’s screen in an “n/m” format. The number of measurements completed, n, increases from zero to the total number of measurements which need to be made, m.

1. Traffic channel frames are subdivided into 16 1.25 mS segmen ts, called power control groups . When the traffic data rate is set to half, quarter, or eighth, the mobile station transmits only during randomly se lected powe r co n trol groups. These are referred to as “gated-on” power control groups.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_gpow_desc.fm

Gated Power Measurement Description

How is a Gated Power Measurement Made?

Each gated power measurement is triggered internally by the test set. During the gated power measurement, a DSP (Digital Signal Processor) samples the signal and returns 5,625 amplitude versus time data points. Data points return power levels, relative to the average power during the mid dle of the burs t, that co rre spond with time intervals before, during, and after the burst.

The gated power measurement analyzes the rising and falling edges of the burst to determine where the -3 dB points are. Using the -3 d B points t o det ermine t he center of t he burst, the test s et posi tions the measur ement mask (green lines on the display) to align in time with the center of the burst.

Since the middle portion of the burst is compres sed in time, the scaling is different when compared to the rising or falling portions. The following formulas can be used to calculate the time associated with each data point from 0 to 5,264 as returned by the “FETCh:GPOWer:TRACe?” command:

Equation 1. Time Association For Data Points 0 through 370

t1 p 222–()×

where t1 is the sampling period for each data point, and p is the data point of interest (from 0 to 5,264).

t1 1 12 1.2288 106××()⁄ 67.82nS≈=

Equation 2. Time Association For Data Points 371 throu gh 4893

4 t1 p 2667–()8÷()××

where t1 is the sampling period for each data point, and p is the data point of interest (from 0 to 5,264).

t1 1 12 1.2288 106××()⁄ 67.82nS≈=

Equation 3. Time Association For Data Points 4894 through 5264

t1 p 13347+()×

where t1 is the sampling period for each data point, and p is the data point of interest (from 0 to 5,264).

t1 1 12 1.2288 106××()⁄ 67.82nS≈=

NOTE Data point 222 corresponds with time 0 on the gated power graph.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_gpow_desc.fm

Gated Power Measurement Description

On the test set’s display, data points are graphed as follows:

• For the rising trace, data points 0 through 370 (the first 371) are displayed with each data point occupying

one display pixel.

• For the falling trace, data points 4894 through 5264 (the last 371) are displayed with each data point occupying one display pixel .

• For th e Full/Zoomed tr ace sp anning t he entir e 1277 uS measureme nt peri od, a veragi ng over groups of data points will be performed to include all 5,264 data points using the display’s 371 pixels.

• For the Full/Zo omed tr ace that zoo ms in on the area highlighted by the ver tical bar, the correlation between data points an d pi xe l s is as follows:

— For the first or last zoomed segment the correlation between data points and display pixels will be

identical to the Rise/Fall traces, with the first or last 371 data points displayed on 371 pixels.

— For all of the middle 12 zoomed segments, the time period (when compared with rise/ fall graphs) will be

compressed in time. Each data point will span a time period four times longer than the rise/fall data points. This will result in about one fourth the dis play resolution when compared with the rise/fall traces.

Table 4. Graticule Line Labeling for all Zoomed Traces

Zoom

Position

0 0-370 371 -15 -10 -5 0 5 10 1 371 to 747 377 10 31 51 71 92 112 2 748 to 1124 377 112 133 153 174 19 4 214 3 1125 to 1501 377 215 235 255 276 296 317 4 1502 to 1878 377 317 337 358 378 399 419 5 1879 to 2255 377 419 440 460 480 501 521 6 2256 to 2632 377 521 542 562 583 603 623 7 2633 to 3008 376 624 644 664 685 705 726 8 3009 to 3385 377 726 746 767 787 808 828

9 3386 to 3762 377 828 849 869 889 910 930 10 3763 to 4139 377 930 951 971 992 1012 1032 11 4140 to 4516 377 1033 1053 1073 1094 1114 1135

DSP Output

Range (points)

Count of

Data

Points

µ s

Graticule

Line 0

µ s

Graticule

Line 2

µ s

Graticule

Line 4

µ s

Graticule

Line 6

µ s

Graticule

Line 8

µ s

Graticule

Line 10

12 4517 to 4893 377 1135 1155 1176 1196 1216 1237 13 4894 to 5264 371 1237 1242 1247 1252 1257 1262

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_gpow_desc.fm

Gated Power Measurement Description

Gated Power Measurement Behavior

Gated Power measurem ents can not be made concurrently with any other measurement, and no other measurement can be made while a gated power measurement is in progress.

The pass/fail result indicates whether or not the trace conformed to the mask. To make the test run faster, reduce the number of averages (multi-measurement count). The default is 100. Most failures occur during the rising or falling portions of the burst. Gated power measurements are exp ressed in dB, relative to the average of the power lev els across th e number

of 1.25 mS burst specified in the multi-measurement count.

Measurement Requirements

Setup:

The following settings are required for the gated power measurement:

• Operating Mode must be Active Cell

• System Type must be IS-95 or IS-2000 with Radio Config set to (Fwd1, Rvs1) or (Fwd2, Rvs2)

• FCH Service Option Setup must be set to SO2 or SO9 (loopback service opt ion)

• Traffic Data Rate must be set to Eighth.

Input Signal:

The gated power measurement meets or exceeds specifications when the following input signal requirements are met:

• The frequency of the signal being measured must be within the range of 411 MHz to 484 MHz, 804 MHz to 934 MHz, 1.75 GHz to 1.78 GHz, or 1.85 GHz to 1.98 GHz,and be within 100 kHz of the expected frequency.

• The average power level of the signal at the RF IN/OUT connector must be between -20 dBm to +30 dBm. The test set can autorange to a signal that is bet we en +8 dBm to -20 dBm of the exp ected level (see

“RFANalyzer:AUTO:POWer[:SELected]?” ).

Handoff Waveform Quality Measurement Description

How is a Handoff Waveform Quality measurement made?

Handoff waveform quality measurements test a transmitter’s modulation accuracy during transmission of a single code channel, the reverse Pilot Channel. The handoff invol ves changing the current pn (pseudo-noise) offset to force the mobile station to transmit a preamble on the Pilot Channel only. Reverse link power control is changed to alternating up/down bits and waveform quality is measured. After the measurement, the pn offset is returned to the original setting and the power control is returned to the original setting.

Each handoff waveform quali ty measurement returns a number of measurements which include rho, the percentage of signal energy that correlates with a perfect IS-2000 signal after time offset and frequency error have been removed.

This measurement is designed to analyze signals that are made up of multiple code ch annels, as in the case of radio configurations three and above.

Waveform quality measurements are made by sampling the down-converted input signal, then applyi ng DSP (Digital Signal Processing) techniques to determine the original data input to the mobile station transmitter’s Walsh spreading function for each channel. The DSP then genera tes a representation of what the “ideal” signal would be given the coding and data in use at the time of transmission. The ideal wavefor m is then compared with the waveform being measured to determine the waveform quality.

Table 5. lists the Handoff W a veform Quality measurements:

Table 5. Handoff Waveform Qu al i t y m ea s urement re s ults

Handoff Waveform Quality

Rho Frequency Error Timing Error Carrier Feedthrough Phase Error Magnitude Error

Measurement Behavior

The handoff waveform quality measure ment does not provide the Multi-Measurement Count feature in the setup menu.

Handoff waveform quality measurements are always triggered singly (press the START SINGLE key to initiate a measurement from the front panel).

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_hwq_desc.fm

Handoff Waveform Quality Measurement Description

Measurement Requirements

Setup:

The following settings are required for the handoff w aveform quality measurement:

• Operating Mode must be Active Cell

• System Type must be IS-2000 with Radio Config set to (Fwd3, Rvs3) or (Fwd4, Rvs3)

• A call must be connected

Input Signal:

The handoff waveform quality measurement meets or exceeds specifications when the following input signal requirem en ts are met:

• The frequency of the signal being measured must be in the range of 412 MHz to 483 MHz, 800 MHz to 960 MHz, or 1.7 GHz to 2.0 GHz, and within 100 kHz of the expected frequency.

SINAD Measurement Description

How is a SINAD measurement made?

SINAD is a receiver audio quality measur ement for mobiles on a n analog voice c hannel (AVC). It is the ratio of Signal+Noise+Distortion divided by Noise+Distortion, expressed in dB . SINAD is measured using the test set’s Audio Analyzer. SINAD can be measured in the range of 100 Hz to 10 kHz. For information on using the Audio Analyzer, see “Audio Analyzer Measurement Description” on page 40.

The SINAD measurement is used to determine receiver RF sensitivity. SINAD is usually measured either of two ways:

• Reduce the Cell Po we r from the test set until 12 dB SINAD is displayed (re-t rig gering for each measurement), or

• Set the Cell Power from the test set to a specified low level and verify a

See IS-137A, section 2.3.1.1, for more info rmation.

Difference in Agilent 8960 Series 10 and 8920B Test Set SINAD Measurements

If you have previously used the Agilent 8920B RF Communications Test Set to measure SINAD, you may notice that the Agilent 896 0 Series 10 test set’s SINAD value may be lower by up to 0.8 dB when measuring 12 dB SINAD. This is due to the more prec ise digital notc h filter us ed by the 8960, caus ing a more accurate noi se measurement to be made. The 8920B uses an analog filter that does not ha ve as tight a filter notch as the

8960.

≥12 dB SINAD reading.

Considerations When Making Manual SINAD Measurements

Swept Audio Measurements Description

Swept Audio Measurements Description Description

How are swept audio measurements made?

Swept audio measurements synchronize the frequencies of the test set’s audio generator and audio analyzer instruments to automatically make measurements at up to 60 frequency points. Audio level, SINAD, and distortion measurements can be performed at each measurement point in the sweep.

This measurement only generates and analyzes audio signals; no modulation of the RF generator , or demodulation by the receiver, is performed. A representation of this operation is shown below.

Figure 5. Swept Audio Measurements Block Diagram

Audio Generator

Instrument

Level

Shared Controls

(These contro ls affect both instruments when making swept audio measurements.)

Start Frequency

Stop Frequency

Audio Analyzer Instrument

SINAD Measurement Distortion Measurement

Detector Type

Peak RMS

Filter Type

Audio Level Measurement

Number of Points

Device Settling Time

Coupling

Expected Peak Voltage

Audio

AUDIO

OUT

(DC)(AC)

High Low

Device Under

Test

The audio generator’s signal is output through the front panel AUDI O OUT port to the device under test. The audio signal from the device under test is sent to the audio analyzer through the AUDIO IN ports.

The start and stop frequencies for the sweep define the frequency range. The user specifies the number of measurement points, which are evenly spaced through the specified frequency range.

Measureme n t se ttling time can be se t to specify how lon g th e au dio signal is gen e ra ted at each freq u ency before a measurement is made by the audio analyzer. This is used to account for settling time in the device being tested and any signal delay through the device. Increasing the settling time increases the sweep time.

If the 100 Hz BW bandpass filter is selected, the center frequency of the filter is synchronized to the audio generator and audio analyzer frequencies.

Typical applications include measuring the audio distortion of a mobil e station across several frequencies and measuring the frequency response of an audio filter or amplifi er.

This is not a measurement procedure specified in the EIA/TIA standar ds.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_saudio_desc.fm

Swept Audio Measurements Description

Operating Considerations Front Panel Access Swept Audio measurements are accessed manually by pressing the front-panel

Instrument selection key.

Mutli-measurement Use When multi-measurements are used with the swept audio measurement, the AF analyzer makes the number of measurements specified at each point in the sweep. F or example, if five measurement points are specified, and the multi-measurement count is set to 20, a total of 100 measurements are performe d du r i n g th e sw ee p.

Interactions with the Audio Analyzer and Audio Generator Instruments The Swept Audio measurement and the Audio Analyzer instrument cannot be used at the same time to make audio measurements. If you enable either funct i on while the other function is already enabled, the first function is turned off and a message is displayed that informs you of this situation.

The amplitude of the Audio Generator instrument can be changed while the Swep t Au dio measurement is enabled. However, trying to change the Audio Generator instrument’s frequency while using swept audio measurements is not allowed, and causes an error message to be displayed.

Specifying a Specific Measurement Frequency Point Within a Sweep If you need to make sure that a measurement is performed at a specific frequency within the sweep, you can use the following algorithms to calculate the values to enter:

To find which point in the sweep (n) corresponds to the frequency you want the sweep to make a measurement at (F), use the following algorithm -

FS–()P 1–()

n 1 INT

S = sweep start frequency, P = number of measurement p oints t o ma ke i n the sweep, F = specific frequency to make a measurement at during the sweep, n = measurement point corresponding to F,

Emin = minimum upper sweep frequency INT= the largest integer value that is less than or equal to the expression in parenthesis. For example, if

the value of the expression is 3.65037, the integer value is 3.0; the value of n would therefore be 4.

To determine the actual stop frequency (E) to enter, use the following algorithm -

For example if you wanted to make a measurement at 1004 Hz (F) during a sweep of 15 points (P) that begins at 300 Hz (S) and ends after 3 kHz (Emin), the first alg orithm te lls you that 10 04 Hz occurs at the fou rth point in the sweep (n). Use the second algorithm to calculate the actual stop frequency (E) you would enter for that sweep (3585.333 Hz).



----------------------------------- -



Emin S–

FS–()P 1–()

----------------------------------- - S+=

n 1–()

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_saudio_desc.fm

TDSO Frame Error Rate Measurement Description

What is a TDSO (Test Data Service Option) FER (Frame Error Rate) measurement?

TDSO FER measurements are used to test the performance of a mobile station receiver while a supplemental (high speed da ta) channel is co n n ected and TDSO (Service Option 32) is sel ected.

This measurement provides a report fro m the mobile station indicating the status of traffic frames received during high speed data transfer on the F-SCH (forward supplemental channel).

NOTE At firmware revision B.03 a new TDSO service option was introduced. When a call is made with

this service option, SO32 (+ SCH), the supp lem ental channel is transmitted on both the forward and reverse links. TDSO FER measurements, however, are made only on the forward supplemental channel.

Since the measurement values displayed are obtained from the mobile station, there are no multi-measurement results availabl e, such as measurement averaging.

How is a TDSO FER Measurement Made?

The test set attempts a TDSO FER measurement when a call is connected using Service Options SO32 (+F-SCH) or SO32 (+ SCH). See “CALL[:CELL]:SOPTION” .

See “CALL[:CELL]:SOPTION” . To establish a call with Service Option 32 you must select Radio Config (Fwd3, Rvs3) or Radio Config (Fwd4, Rvs3). A mobile station originated call can be made or you can pre ss the Originate Call (F3) key. A TDSO FER display is shown below in Figure 6. with 512 frames selected.

Figure 6. TDSO FER Display

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_tdso_desc.fm

TDSO Frame Error Rate Measurement Description

The time period required for TDSO FER measurements depends on the timing of the call connection. All traffic channels, including the F-SCH, are subdivided into segments of 10.24 seconds each. Testing begins

when the first frame (called a sync frame) of the first full segment is received by the mobile station. For example, Figure 7. shows two full F-SCH segments. In this example, the SO 32 call is connected half way through the first segment. Appro ximately 5.12 s later the mo bile station receives the first sync frame from the test set and computes the PRBS data patte rn the test set is about to send.

The time period between the successful negotiation of a SO32 connection and the start of the FER Count Period is bas ed on the current long code state, and will range from 0 seconds to 10.24 seconds.

The mobile station also resets its frame counters upon receiving the first sync frame.

Figure 7. TDSO FER With Frame Count Set to 512 Frames

10.24 s

512 20 ms Frames

5.12 s

10.24 s

512 20 ms Frames

FER Count Period

SO 32 Selected

First sync frame-

mobile station begins

counting frames

Second sync frame-

mobile station returns

frame counter data

During the second sync frame interval, the mobile station keeps a running co unt of:

• Good Fram es Received

• Bad Frames Received

• Blank Frames Received

• Bad Frames Instead of Blank Frames Received

• Tot al Bad Frames Received

Also during the second frame interval, the test set keeps a running count of:

• Good Frames Transmitted

• Blank Frames Transmitted

At the end of the second frame interval, the tes t set retrieves frame count data from the mobile station and

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_tdso_desc.fm

TDSO Frame Error Rate Measurement Description

calculates percent FER based on the following formula:

FER 1

TotalGoodFramesReceived

-------------------------------------------------------------------------–=

TotalTransmittedFrames

Possible Setup Issues

A call must be setup using SO32 (+ F-SCH) or SO32 (+ SCH) and that call must be currently connec ted to make TDSO FER measurements.

IMPORTANT PRBS data must be selected on the forward sup plemental channel if you are making any type of

code domain measurement on the reverse supplemental channel.

The F-SCH Parameters menu allows for the selection of PRBS or Fixed Pattern in the Data Source field. This choice is also applied to the reverse supplemental channel (see “Configuring the R-SCH (Reverse

Supplemental Channel)” . T o c orrectly det ect reverse sup plemental code c hannel parameters , PRBS is the only

data source supported. If PRBS data is not selected, the code domain power results (see “Waveform

Quality/Code Domain Measurement Description” ) will not display distinct code channels with the expected

spreading factors. When PRBS is se l e ct e d in th e D a ta So u rce field, code domain power re su l ts will not be cor r ec t until after th e

first sync frame occurs ( see “How is a TDSO FER Measurement Made?” ). The measurement setup menu allows for specifying the FER confidence requirement. The FER confidence

requirement establishes a target FER rate. To meet standard minimum specifications, a specified FER percentage must be attained with a confidence leve l of 95%. The TDSO FER measurement returns the confidence level based on the actual average FER result obtained over the fixed frame count length. If the confidence level is less than 95% for the specified FER confidence requirement, the test has not passed minimum standards.

The supplemental channel information menu provides channel setup parameters including the supplemental channel data rate, enco der type, and power level. Standards specify data rates and Eb/Nt. Eb/N t can be set by adjusting F-SCH and AWGN level.

If trigger arm is set to Single, the first TDSO FER measurement will be displayed and then the test set will wait until it is t riggered by a GPIB command or the START SINGLE key before the next sync frame is staged.

If “No F-SCH” is displayed in the bottom right po rtion of the display, the supplemental channel is not connected. If “No Sync” is displayed, the sync channel has not been sent to the mobile stati on yet.

Interim results are displayed when the frame count is greater than 512 and the test set is able to retrieve mobile station counter values after intermediate sync frames.

Integrity indicators (see “Integrity Indicator” ) do not apply to this measurement.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_tdso_desc.fm

Tx Spurious Emissions Measurement Description

How is a Tx Spurious Emissions measurement made?

For cellular frequency bands, and NMT 450, the Tx spurious emission s me asurement analyzes the signal energy at the following frequency offsets relative to the channel’s center frequency:

• ±885 kHz (lower and upper adjacent channels)

• ±1.98 MHz (lower and upper alternate channels)

For PCS frequency bands the Tx spurious emissions measurement analyzes the signal energy at the following frequency offsets relative to the channel’s center frequency:

• ±1.25 MHz (lower and upper adjacent channels)

• ±1.98 MHz (lower and upper alternate channels)

The relative signal energy (dBc) is measured within a 30 kHz bandwidth. A graphical view or a numeric view can be displayed. Tx Spurious Emissions measurements are triggered by a 20 ms clock derived from signaling protocol.

Tx Spurious Emissions measurement characteristics

Tx Spurious Emissions measurements are usuall y made with t he mobil e statio n transmit ting at its fu ll powe r (traffic channel and fundamental channel control is available in the measurement setup menu).

Limit lines are shown on the graphical dis pla y. These lines are set based on the cur rent Cell Band se lection. If the signal energy exceeds a limit line the word Fail appears on the display.

The x-axis on the graphical display is fixed to -2.5 MHz to 2.5 MHz The y-axis on the graphical display is fixed to 0 dBc/30 kHz to -70 dBc/30 kHz. A marker is provided to display measurement levels at each offset frequency. An overall pass/fail indicator is available via GPIB commands (see “FETCh:CTXSpurious[:ALL]?” )

Input Signal Requirements

The Tx Spurious Emissions measurement meets or exceeds specifications when the following requirements are met:

• The frequency of the signal being measured must be in the range of 411 MHz to 484 MHz, 804 MHz to 934 MHz, 1.75 GHz to 1.78 GHz, or 1.85 GHz to 1.98 GHz, and be within 100 kHz of the expected frequency.

• The signal level into the test set’s RF IN/OUT connector must be in the range of 0 dBm to +30 dBm, and within 9 dBm of the expected input power (see “RFANalyzer:AUTO:POWer[:SELected]?” ) to meet specifications.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_tx_spurious_desc.fm

Waveform Quality/Code Domain Measurement Description

Waveform Quality/Code Domai n Measurement Description

How is a Waveform Quality/Code Domain Power measurement made?

Each waveform waveform quality measurement returns a number of measurements whi ch includes:

• Rho, the percentage of signal energy that correlates with a perfect IS-2000 signal after time offset and frequency error have been removed

• Code domain power, the power levels of each code channel tran smitted by the mobile station.

• Code domain p o w e r a n d n oi se, the total of po wer and noise of ea ch code channel tr a n smitted by the m o bile

station.

This measurement is designed to analyze signals that may be made up of multiple code channels. Multiple code channels are used in calls setup usi ng radio configurations three (Fwd3, Rvs3) and above . Any time a call is connected, wavefor m qualit y measurements can be made. Any combination of service option, radio configuration, or data rate can be measured.

Table 6. “Waveform Quality/Code Domain Power Measurement Results” lists the Waveform Quality/Code

Domain Power measurements:

Table 6. Waveform Quality/Code Domain Power Measurement Results

Waveform Quality Code Domain Power

Rho Code Domain Power (I-Channel) Frequency Error Code Domain Power (Q-Channel) Timing Error Code Domain Po wer + Noise (I-Channel) Carrier Feedthrough Code Domain Power + Noise (Q-Channel) Phase Error Magnitude Error Error Vector Magnitude (EVM)

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_wquality_desc.fm

Waveform Quality/Code Domain Measurement Description

Code Domain Power Graphical Display

The Code Domain Power measurement displays up to 16 I-channel and up to 16 Q-channel bins1. Each bin represents one active code channel. The IS-2000 system achieves high data rates by combining multiple code channels. To facilitate the display of high data rate channels in contiguous blocks, the Walsh code sequence along the graph’s x-axis is displayed in “bit reversed” order. See Table 7. “Walsh Numbering on Code Domain

Power Graphs”

To facilitate the display of measurement results in contiguous blocks the Walsh code sequence along the graph’s x-axis is displayed in “bit reversed” order. See Table 7. “Walsh Numbering on Code Domain Power

Graphs”

Table 7. Walsh Numbering on Code Domain Power Graphs

Bin Number0123456789101112131415 Walsh Code

Channel

0841221061419513311715

The power and power + noise graphs, because of the bit-reversed order, can display channels with a spreading factor of less than 16, such as the R-SCH (Reverse Supplemental CHannel), using one bin. For example,

Figure 8. sh o ws th e Q chann e l with :

• the R-FCH (Reverse Fundamental CHannel) in bin 1 on channel 4,

• the R-SCH in bin 2 on channel 1 (composed of channels 1, 9, 5, 13),

Figure 8. Code Domain Power Graph with R-SCH

An example of bit reversal is shown in Figure 9. Bin 13 has a binary coded decimal value of 1101. If you reverse that sequence, the result is 1011. When 1011 is converted back to a decimal value, the result is Walsh code 11.

1. Bins are the bars that appear on the graph. When high data rate channels such as the F-SCH channel are transmitted from the mobile station, wider bins are displayed. The wider bins represent code channels that occupy multiple orthogonal channels.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_wquality_desc.fm

Waveform Quality/Code Domain Measurement Description

Figure 9. Walsh Channel Bit Reversal

Input Signal Requirements

Bin 13

Walsh 11

The Waveform Quality measurement meets or exceeds specifications when the following requirements are met:

• The frequency of the signal being measured must be in the range of 412 MHz to 483 MHz, 800 MHz to 960 MHz, or 1.7 GHz to 2.0 GHz, and within 100 kHz of the expected frequency.

IMPORTANT PRBS data is required if you are making any of the code domain measurements on the reverse

supplemental channel

The F-SCH Parameters menu allows for the selection of PRBS or Fixed Pattern in the Data Source field. This choice is also applied to the reverse supplemental channel. See “Configuring the F-SCH (Forward

Supplemental Channel)” . T o c orrectly det ect reverse sup plemental code c hannel parameters , PRBS is the only

data source supported. If PRBS data is not selected, the code domain power results will not display distinct code channels with the expecte d spreading factors.

Test Adherence to Standards

Standards Table

This table lists the capabilit ies of the E1962B T est Applic ation. This tes t capability is e ffective with the rel ease of revision B.02.

Table 8. IS-98-D Standards

TIA/EIA-98-D E1962B

1.3 Fundamental Channel Test Mode 1 (F/R RC1) Yes, supports SO2 and SO55 on the Traffic Channel.

1.3 Fundamental Channel Test Mode 2 (F/R RC2) Yes, supports SO9 and SO55 on the Traffic Channel.

1.3 Fundamental Channel Test Mode 3 (F/R RC3) Yes, supports SO2 and SO55 on the Traffic Channel.

1.3 Supplemental Channel Test Mode 3 (Forward RC3) Yes, supports SO32 (TDSO) on F-SCH.

1.3 Supplemental Channel Test Mode 4 (F-RC4 & R-RC3)

1.3 Supplemental Channel Test Mode 4 (Forward RC4) Yes, supports SO32 (TDSO) on F-SCH.

1.3 Fundamental Channel Test Mode 5 (F-RC5 & R-RC4)

1.3 Supplemental Channel Test Mode 5 (Forward RC5) Yes, supports SO32 (TDSO) on F-SCH.

3.1 Frequency Requirements Supports Band Class 0, 1, 3, 4, 5, & 6

3.2.1.1 Idle Handoff in Non-slotted Mode (Test 1) No, requires two synchronized Base Station Emulators.

3.2.1.1 Idle Handoff in Non-slotted Mode (Test 2) No, requires two synchronized Base Station Emulators.

3.2.1.2 Idle Handoff in Slotted Mode on Paging Channel No, requires two synchronized Base Station Emulators.

3.2.1.3 Idle Handoff in Slotted Mode on Forward Common Control Channel

3.2.1.4 Idle Handoff to another frequency No, requires two synchroniz ed Base Station Emulators.

3.2.2.1 Neighbor Set Pilot Detection & Incorrect Detection in Soft Handoff

3.2.2.2 Candidate Set Pilot Detection & Incorrect Detection in Soft Handoff

Yes, supports SO2 and SO55 on F-FCH & R-FCH.

Yes, supports SO9 and SO55 on F-FCH & R-FCH.

No, requires two synchronized Base Station Emulators.

No, requires Soft Handoff capability and Pilot Measurement detection.

3.2.2.3 Active Set Pilot Loss Detection in Soft Handoff No, requires Soft Handoff capability and Pilot Measurement detection.

3.2.3.1 Access Probe Handoff No, requires two synchronized Base Station Emulators.

3.2.3.2 Access Handoff No, requires two synchronized Base Station Emulato rs.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_adherence_desc.fm

Test Adherence to Standards

Table 8. IS-98-D Standards

TIA/EIA-98-D E1962B

3.3.1 Demodulation of Non-S lotted P aging Channel with AWGN

No. The Test Set can set up the proper forward channel conditions. The Test Set cannot retrieve the mobile accumulated statistics parameters.

3.3.2 Demodulation of slotted Paging Channel wi th

No, the Test Set cannot send an Audit Order

AWGN

3.3.2.2.1 Spreading Rate 1 Paging Channel No. The Test Set supports only IS-2000 rev.0 channels. It does not support enhanced access, FCCCH, BCC,CPCCH.

3.3.2.2.2 Spreading Rate 3 Paging Channel No. Possible future enhancement.

3.3.3 Demodulation of Broadcast Control Channel in

No. Possible future enhancement.

AWGN.

3.3.3.2.1 Spreading Rate 1 BCC. No. Possible future enhancement.

3.3.3.2.2 Spreading Rate 3 BCC. No. Possible future enhancement.

3.3.4 Demodulation of Broadcast Control Channel in

No. Possible future enhancement.

Multipath Fading Channel.

3.3.4.2.1 Spreading Rate 1 BCC. No. Possible future enhancement.

3.3.4.2.2 Spreading Rate 3 BCC. No. Possible future enhancement.

3.3.5 Demodulation of forward Common Control

No. Possible future enhancement.

Channel

3.3.5.2.1 Spreading Rate 1 F-CCCH. No. Possible future enhancement.

3.3.5.2.2 Spreading Rate 3 F-CCCH. No. Possible future enhancement.

3.3.6 Reception of Common Power Control Channel and

No. Possible future enhancement.

Common Assignment Channel

3.3.6.2.1 Spreading Rate 1 Forward Common Power

No. Possible future enhancement.

Control Channel and Common Assignment Channel with Rate = 1/4

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_adherence_desc.fm

Table 8. IS-98-D Standards

TIA/EIA-98-D E1962B

Test Adherence to Standards

3.3.6.2.2 Spreading Rate 1 Forward Common Power Control Channel and Common Assignment Channel with Rate = 1/2

3.3.6.2.3 Spreading Rate 1 Forward Common Power Control Channel and Common Assignment Channel with Rate = 1/2

3.4.1 Demodulation of Forward Traffic Channel with AWGN

3.4.2 Demodulation of Forward Traffic Channel with Fading

3.4.3 Demodulation of Forward Traffic Channel During Soft Handoff

3.4.4 Decision of Power Control Bit for Channels Belonging to Different Power Control Sets During Soft Handoff - Test 1 and Test 2

3.4.5 Decision of Power Control Bit for Channels Belonging to the Same Power Control Set

No. Possible future enhancement.

Yes, For F-FCH , the test set uses loopback Service Options 002,

009, or 055 For F-SCH, the test set uses Test Data Service Option

(S032) Yes, requires an external fader and AWGN generator to

perform per the standards. F-SCH uses TDSO (Service Option 32)

No, requires soft handoff capability

3.4.6 Demodulation of Power Control Subchannel During Soft Handoff

3.4.7 Demodulation of Forward Traffic Channel in Multipath Fading Channel with Closed Loop Power Control (FPC_MODE=000)

3.4.8 Demodulation of Forward Traffic Channel During Soft Handoff with Closed Loop Power Control (FPC_MODE=000)

3.4.9 Demodulation of Forward Traffic Channel in Multipath Fading Channel with Closed Loop Power Control (FPC_MODE=000 or 100)

3.4.10 Demodulation of Forward Traffic Channel in Multipath Fading Channel with Closed Loop Power Control (FPC_MODE=000) and Transmit Diversity (OTD or STS)

3.4.12 Demodulation of Power Control Subchannel During Reverse Fundamental Channel Gating

No, requires soft handoff capability

No, possible future enhancement

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_adherence_desc.fm

Test Adherence to Standards

Table 8. IS-98-D Standards

TIA/EIA-98-D E1962B

3.4.13 Behavior of the Quality Indicator Bit of the

No, possible future enhancement

Forward Dedicated Control Channel

3.5.1 Receiver Sensitivity and Dynamic Range Yes

3.5.2 Single Tone Desensitization Tests 1 and 2 Yes, with external signal generator

3.5.3 Intermodulation Spurious Response Attenuation

Yes, with external signal generator

Tests 1 and 2

3.5.4 Adjacent Channel Selectivity Yes, with external CDMA generator

3.6.1 Conducted Spurious Emissions No, use the HP 859XE +HP 85725C CDMA Spectrum Analyzer

3.6.2 Radiated Spurious Emissions No, use the HP 859XE +HP 85725C CDMA Spectrum Analyzer

3.7.1 Supervision Paging Channel Partially, but the test set does not provide timing measurements

3.7.2 Sup ervision Forward Channel - Test 1 and Tes t 2 No

4.1 Transmit Frequency Accuracy Yes, uses the rho or EVM measurement method

4.2.1 CDMA to CDMA Hard Handoff Partially, performs F

to F2 Hard handoffs, but cannot

make the required timing measurement

4.2.2 Transmit Power after Hard Handoff No

4.2.3 Candidate Frequency Single Search No

4.3.1 Time Reference Yes, uses the rho or EVM measurement method.

Time Reference Slew Rate Partially, requires an external fader & external timing

measurement device. E1962A requires mobile test mode to set-up call

4.3.2 Reverse Pilot Channel to Code Channel Time

Yes

Tolerance

4.3.3 Reverse Pilot Channel to Code Channel Phase

Yes

Tolerance

4.3.4 Waveform Quality and Frequency Accuracy Yes, uses the rho or EVM measurement method. The test set also measures multi-coded waveform quality, a non-standard but more useful measurement.

4.3.5 Code Domain Power Yes

4.4.1 Range of Open Loop Output Power Yes, Uses access pro be power measurement. Enhanced Access Channel is not currently supported.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_adherence_desc.fm

Test Adherence to Standards

Table 8. IS-98-D Standards

TIA/EIA-98-D E1962B

4.4.2 Time Response of Open Loop Power Control No

4.4.3 Access Probe Output Power Yes, use call limit feature to prevent call from connecting. Support for SR1 and SR3 Enhanced Access Channel is a possible future enhancement.

4.4.4 Range of Closed Loop Power Control Yes, but does not make timing measurements. Test 2 not supported.

4.4.5 Maximum RF Output Power Yes. Spurious emissions requires an external spectrum analyzer.

4.4.6 Minimum Controlled Output Power Uses channel power measurement.

4.4.7 Standby Output Power and Gated Output Power Partially, the E1962B has graphical Gated Power measurements.

4.4.8 Power up Function Output Power No

4.4.9 Code Channel to Reverse Pilot Output Power

Accuracy

Yes, except Enhanced Access Channel Header, Enhanced Access Channel Data and Reverse Common Control Channel Data.

4.4.10 Reverse Pilot Channel Phase Discontinuity No. The test set provides call setup. HP859XE and HP 85725C are needed to make the measurement.

4.5.1 Conducted Spurious Emissions Yes.

4.5.2 Radiated Spurious Emissions Yes. Requires external spectrum analyzer.

4.5.3 Occupied Bandwidth (Band classes 3 & 6 only) Yes. Requires external spectrum analyzer.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_adherence_desc.fm

Test Adherence to Standards

Table 8. IS-98-D Standards

TIA/EIA-98-D E1962B

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_meas_adherence_desc.fm

Amplitude Offset

Description

Amplitude offsets compensate fo r los s or gain between the test set ’s RF IN/OUT front panel connector and the mobile station’s RF connector.

To access the amplitude offset feature, press the SYSTEM CONFIG key, followed by the RF IN/OUT Amptd Offset key, F5.

Amplitude offset settings are preserved during power cycles or instrument preset.

Setting Up Amplitude Offsets and Frequency Points

Up to 20 frequency points can be assigned an amplitude offset. Negative amplitude offset values should be entered when there is a loss through the RF cabling and test fixtures and positive values should be entered when there is a gain.

The RF IN/OUT Amplitude Offset table displays the current (on/off) state of the amplitude offset feature. There are also 20 rows for entering frequencies and 20 rows for entering corresponding offset values. T o enter values in the table use the RF IN/OUT Amplitude Offset Setup menu.

To set up amplitude offsets remotely, one comma-separated string is sent to set up frequency points and another comma-separated string assigns the corresponding amplitudes.

GPIB Commands

MHZ,1879.8 MHZ” !sets the first 4 frequencies in the amplitude offset table.

OUTPUT 714;”SYSTEM:CORRECTION:SGAIN -2.55,-3.12,-3.68,-4.23” !sets the first 4 amplitude offsets in the amplitude offset table.

OUTPUT 714;”SYSTEM:CORRECTION:SFREQUENCY 1710.2 MHZ,1805.2 MHZ,1784.8

Turning amplitude offsets on/off

When the RF IN/OUT Amplitude Offset State is on, all offsets that are not individually turned off are applied and the word “Offset” appears in the Instrument Status Area of the test set’s display.

If the RF IN/OUT Amplitude Offset State is off, none of the amplitude offsets are applied.

GPIB Command

!Sets the RF IN/OUT Amplitude Offset State to On

OUTPUT 714;”SYSTEM:CORRECTION:STATE ON”

NOTE If the RF IN/OUT Amplitude Offset State is turned off , none of the amplitude offsets are on,

even if values are entered for the individual offsets.

Examples of Amplitude Offset Behavior

When the amplitude offset table entries accurately represent the loss in all components (cabling, connectors, and test fixturing) in the signal path between the test set and the mobile stati on, the test set will make the necessary adjustments in both receiver and transmitter measurements.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_conf_meas.fm

Amplitude Offset

Mobile Station Receiver Example

When you set a transmit power level, the test set uses the amplitude offset value to adjust the power so that the test set’s transmit power level refers to the power level received at the mobile station.

For example, with the test set’s transmit power set to level transmitted from the test set will be automatically off set to the mobile station will receive

−85 dBm, the actual setting.

−85 dBm and a −3 dB amplitude offset the actual power

−82 dBm. With a 3 dB loss in the signal path

Figure 10. Amplitude Offset Mobile Station Receiver Example

Agilent 8960

Transmit Power setting = –85 dBm Amplitude offset = –3 dB

–3 dB network

(bidirectional)

Power = –82 dBm Power = –85 dBm

Mobile Station Transmitter Example

When you measure power from the mobile station, the displayed and queried values are offset to show the level at the mobile station.

For example, with the mobile station transmitting 12 dBm and a

−3 dB amplitude offset is entered, the

measured power at the test set would be 9 dBm. The displayed power level is automatically adjusted to 12 dBm to show the level at the mobile station.

Mobile Station

If the expected power, which can be set manually or automatically is 12 dBm, the test set’s internal hardware adjusts itself to r eceive 9 dBm whic h is the actual power from the mobil e stati on after 3 dB loss in th e network.

Figure 11. Amplitude Offset Mobile Station Transmitter Example

Signal Flow

Agilent 8960

Expected Power setting = 12 dBm Amplitude offset = –3 dB

–3 dB network

(bidirectional)

Power = 9 dBm Power = 12 dBm

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_conf_meas.fm

Mobile Station

Amplitude Offset

Amplitude Offsets Between Frequency Settings

If mobile station testing is performed at frequencies that do not have amplitude offsets assigned to them, the test set will estimate an amplitude offset based on the nearest settings. For exampl e, the following screen shows five amplitude offsets for frequencies ranging from 890.2 MHz to 1710.2 MHz.

Figure 12. RF IN/OUT Amplitude Offset Setup

For test frequencies between the lowest (890.2 MHz) and highest (1710.2 MHz) frequency points that are not entered in the table, the test set will calculate offsets using piece-wise linear interpolation.

The graph shown in Figure 13. is a conceptual representation of the test set’s amplitude offset configuration using the settings from the RF IN/OUT Amplitude Offset table in Figure 12. “RF IN/OUT Amplitude Offset

Setup”. Each of the five points are shown on a non-scaled frequncy versus amplitude offset graph. At a test

frequency of 890.4 MHz, whic h is midway between point number one (-1 dB) and point number two (- 2 dB) th e test set applies an offset of -1.5 dB. Be aware that since amplitude offsets are in units of dB, this piece-wise linear interpolation does not pro duce a linear transition from point to point.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_conf_meas.fm

Amplitude Offset

Figure 13. Amplitude Offset Interpolation

Amplitude Offset Interpolation

800 890.2 890.6 891 914 1710 2000

-1

-2

-3

Offset (dB)

If testing is done outside the range of frequencie s bounded by the lowest and highest frequency entries, the test set simply uses the amplitude offset that is paired with the nearest frequency point.

Offset at 890.4 MHz would equal -1.5 dB

-4

-5

Freque ncy (MHz)

IMPORTANT It is highly recommended that amplitude offsets are set up for each test frequency. This

eliminates inaccuracies due to the mismatch between the test set’s linear interpolation and the actual frequency response of the RF path betwe en the test set and mobile station.

Call Processing

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\ch_call_processing.fm

Active Cell Operating Mode

Active cell mode is u sed to emul ate an IS-2000 ce ll interact ing with the mobil e s tation (MS) , and is the def ault operating mode.

Active Cell Features

The basic features provided by active cell operating mode are:

• Selection of radio configuration.

• Selection of service options (voice echo or data loopback).

• Call setup and disconnection, both mobile station originated and paging.

• Zone-based and timer-based registration controls.

• Hard handoffs between frequency bands and physical RF channels.

• Service option negotiation during access state or on traffic channels.

• Voice echoing through the mobile’s earpiece.

• Automatic frequency co n t ro l and power ran g i n g o f th e test set’s receiver.

• Mobile station reported information, such as mobile station parameters.

• Closed loop power control.

Setting the Test Set’s Operating Mode to Active Cell Mode

The active cell operating mode is set using the following test set command: OUTPUT 714;”CALL:OPERating:MODE CALL”

AVC Test Operating Mode

Analog Voice Channel (AVC) test mode provides a forward voice channel for operating AMPS mobiles in test mode. This allows you to get the mobile transmitti ng on an AVC and test many functions in the mobile without the need to register or page the mobile.

AVC Test Mode Operation

When the test set’s operating mode is AVC test mode:

• No over the air signaling is available.

• Changes to the test set’s AVC channel assignment occur immediately.

• When the test set’s AVC channel is changed, the base station emulator is automatically reconfigured to

receive the corresponding reverse AVC signal from the mobile. If needed, you can disable this operation by selecting manual receiver frequency control. See “Receiver Control” on page 213.

• Changes to the MS TX Level automatically set the ex pected analog input power. If needed, you can disable this operation by selecting manual receiver power control. See “Receiver Control” on page 213.

• SAT modulation of the tes t set’s forward A VC can be turned on or off , and can be set t o any of the three col or code frequencies.

• Internal FM of the forward AVC is available for various audio frequency tests.

• An external FM source can be used to provide addition fr equency modulation of the forward AVC.

Forward Channel FM Operation

Frequency modulation of the forw a rd c han nel in AVC test mode is a combination of the SAT, internal FM, and external FM settings. No wideband data is present.

To meet sp eci ficatio ns , the total peak FM deviation cannot exceed 20 kHz. Limitat ions for eac h FM source are as follows:

• SAT - can be turned on or off, and has three color code selections: SAT1 (5970 Hz), SAT2 (6000 Hz), SAT3 (6030 Hz). Peak devi ation is fixed at 2 kHz.

• Internal FM - can be turned on or off , has a rate range of 100 Hz to 20 kHz, and a peak deviation range of 0 Hz to 20 kHz.

• External FM - uses the test set’s rear-panel FM Mod In port to connect an external modulation source. The fixed peak deviation for a 100 Hz to 20 kHz tone is 20 kHz/Volt.

AVC Test Mode Operation Using Au tomated Re ceiver Control

The following procedure demonstrates the use of AVC test mode where the base station emulator’s RF generator frequency, measurement receiver frequency, and expected input power are automatically set by the call control settings used. This is the most common way to use test mode because it requires less individual configuration of call parameters.

This procedure provides general programmi ng steps, but is not written around any specific test require ments. Some of the settings shown are the default power up settings f or AVC Test mode.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_gen_bse_avctest.fm

AVC Test Operating Mode

Putting the mobile in analog test mode at the correct channel num ber and power setting is the responsibility of the user.

1. Select AVC Test mode.

OUTPUT 714;”CALL:OPERating:MODE AVCT”

2. Turn on the base station emulator’s RF Generator and set the output level to -50 dBm.

OUTPUT 714;”CALL:POWer -50”

3. Set the AVC channel number to 777.

OUTPUT 714;”CALL:SETup:AVC 777”

4. Set the MS TX Level to two (2). (This is the mobile’s power level setting, not the expected power in dBm.)

OUTPUT 714;”CALL:SETup:MS:ANALog:TXLevel:CELLular 2”

5. Turn the fo rward channel AVC SAT on.

OUTPUT 714;”CALL:AVCTest:AVC:SATone:STATe ON”

6. Set the SAT color code to SAT1 (5970 Hz).

OUTPUT 714;”CALL:SETup:AVC:SATone SAT1”

7. Turn on internal FM, and set the deviation to 8.0 kHz and the rate to 1004 Hz.

OUTPUT 714;”CALL:FM:INTernal 8 KHZ;INT:FREQuency 1004 HZ”

If you do not want internal FM on, use the FM State command to turn it off:

OUTPUT 714;”CALL:FM:INTernal:STATe OFF”

8. Turn external FM off.

OUTPUT 714;”CALL:FM:EXTernal:STATe OFF”

9. Connect the mobile’s antenna port to the test set’s RF IN/OUT port and p ut the mob ile i n anal og te st mode, transmitting at power level two on channel 777.

If your mobile’s audio is not muted, you should hear a 1004 Hz tone out of its speaker. If you have an acoustic or direct connection to the mobile’s audio output, you can make audio measurements through the test set’s AUDIO IN connections. See “Audio Analyzer Measur eme nt De scription” on page 40.

You can also make analog transmit power and frequency stability measurements on the mobile’s reverse channel carrier. If you modulate your mobile’s carrier, you can measure the frequency modulation characteristics. See “Analog Transmit Power Measurement Description” on page 39, “Frequency Stability

Measurement Description” on page 59, and “Frequency Modulation (FM) Measurement Description” on page

57.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_gen_bse_avctest.fm

AVC Test Operating Mode

AVC Test Mode Oper ation Using Manual Receiver Control

Note: Changing the operating mode affects manual receiver control parameters. See “Effects on Receiver

Control When Changing Operating Mode” on page 215.

The following procedure demonstrates the use of AVC test mode where the base station emulator’s RF generator frequency, measurement receiver frequency, and expected input power are manually configured. Manual control is not commonly used in prod uction testing, but is provided to allow the measurement rece iver and RF generator to be used to perform tests where automated control may not be used; such as when tuning the recevier to make measurements outside of the cellular band during AMPS testing.

This procedure provides general programmi ng steps, but is not written around any specific test require ments. Some of the settings shown are the default power up settings for AVC Test mode.

Putting the mobile in analog test mode at the correct channel num ber and power setting is the responsibility of the user.

1. Select AVC Test mode.

OUTPUT 714;”CALL:OPERating:MODE AVCT”

2. Turn on the base station emulator’s RF Generator and set the output level to -50 dBm.

OUTPUT 714;”CALL:POWer -50”

3. Set the base station emulator’s RF generato r to 893.310 MHz; the forward channel frequency for channel

777.

OUTPUT 714;”CALL:RFGenerator:FREQuency 893.310 MHZ”

4. Enable manual receiver frequency control and tune the measurement receiver to 848.31 MHz (reverse channel 777).

OUTPUT 714;”RFANalyzer:MANual:MEASurement 848.310 MHZ”

5. Enable manual control of the receiver’s expected analog input level power setting.

OUTPUT 714;”RFANalyzer:CONTrol:POWer:AUTO OFF”

6. Set the expected input level value to correspond to mobile station power level two.

OUTPUT 714;”RFANalyzer:MANual:ANALog:POWer 28 DBM”

7. Turn the fo rward channel AVC SAT on.

OUTPUT 714;”CALL:AVCTest:AVC:SATone:STATe ON”

8. Set the SAT color code to SAT1 (5970 Hz).

OUTPUT 714;”CALL:SETup:AVC:SATone SAT1”

9. Turn on internal FM, and set the deviation to 8.0 kHz and the rate to 1004 Hz.

OUTPUT 714;”CALL:FM:INTernal 8 KHZ;INT:FREQuency 1004 HZ”

If you do not want internal FM on, use the FM State command to turn it off:

OUTPUT 714;”CALL:FM:INTernal:STATe OFF”

10.Turn external FM off.

OUTPUT 714;”CALL:FM:EXTernal:STATe OFF”

11.Connect the mobile’s antenna port to the test set’s RF IN/OUT port and put the mobile in analog test mode, transmitting at power level two and channel 777.

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_gen_bse_avctest.fm

AVC Test Operating Mode

If your mobile’s audio is not muted, you should hear a 1004 Hz tone out of the speaker. If you have an acoustic or direct connection to the mobile’s audio output, you can make audio measurements through the test set’s AUDIO IN connections. See “Audio Analyzer Measur eme nt De scription” on page 40.

Measurement Description” on page 59, and “Frequency Modulation (FM) Measurement Description” on page

57.

IS-2000 Test Operating Mode

When the test set is in IS-2000 test operating mode (as opposed to active cell operating mode) it is necessary for the mobile station under test to be capable of independantly performing operations that normally occur through over-t he-air signaling. This capability is referred to as test mode and is usually accomplished using commands which are sent to the mobile station from a system con troller (usually a personal computer) through a proprietary digital interface. See <test mode paper>.

To make measurements on the reverse channel in test mode, the mobile station must first synchronize to the test set’s forward pilot channel and demodulate the sync and paging channels. This is consistent with normal system acquisition procedures and results in the mobile st ation reaching the mobile station idle state. In active cell operating mode, the mobile station at this point would autonomously perform a power-up registration after entering the idle state. A call could then be initiated, using over-the-air call processing, and the fundamental channel would be established and maintained according to the applicable message protocol.

However, in test mode the test set and mobile station are directed to the same FCH (fundamental channel) by the system controller or through manual user interfaces without over-the-air call processing.

Forward CDMA channels available in test mode

In test mode, the test set can be configured to transmit a forward channel that emulates a base station operating in radio configuration (RC) 1, 2, 3, 4 or 5. See “Forward Channel Description” on page 784

CW Operating Mode

CW operating mode provides an unmodulated carrier of adjustable frequency and amplitude, manual adjustment of the measurement receiver and demodulation (uplink) receiver frequencies, and manual setting of the expected CW input power.

Note: Changing the operating mode affects manual receiver control parameters. See “Effects on Receiver

Control When Changing Operating Mode” on page 215.

CW Test Mode Operation

When the test set’s operating mode is set to CW:

• No over the air signaling is used.

• No demodulation or channel decoding is available.

• An unmodulated RF signal can be generated while analyzing another signal (at the same frequency or at a

different frequency). No interaction exists between these controls.

• Expected CW power, measurement receiver frequency, and uplink receiver frequency are available as manual settings only; no automatic control is provided.

CW Mode Operation

The following command examples show you how to control each function for CW operating mode:

1. Select CW operating mode: OUTPUT 714;”CALL:OPERating:MODE CW”

2. Set the cell power output level to be transmitted by the test set: OUTPUT 714;”CALL:POWer -45 DBM”

3. Set the RF generator frequency: OUTPUT 714;”CALL:RFGenerator:FREQuency 870 MHZ”

4. Set the expected CW power level to be received by the test set: OUTPUT 714;”RFANalyzer:CW:EXPected:POWer 23 DBM”

5. Set the measurement receiver frequency: OUTPUT 714;”RF ANalyzer:MANual:MEASurement 870.030 MHZ”

Selecting a Cellular System Type

To select a cellular system type using the test set’s front panel, see “How Do I Set Up a Call?” on page 683 The mobile station’s cellular sy stem type is selected using the “CALL[:CELL]:SYSTem[:TYPE]” call

processing subsystem commands.

Available System Types

The following system types are displayed under the System Type menu when the Operating Mode is set to Active Cell (see “Active Cell Operating Mode” ) or Cell Off.

• IS-2000 (CALL:SYSTem DIGital2000)

• IS-95 (CALL:SYSTem DIGital95)

• AMPS (CALL:SYSTem AMPS)

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_gen_bse_syst_type.fm

Selecting a Cellular System Type

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_gen_bse_syst_type.fm

Setting the Cell Band

The test set’s base station emulator provides a selection of cell bands. To set the cell band using the test set’s front panel, see “How Do I Set Up a Call?” on page 683.

Cell Bands

The following GPIB subsystem describes the cell bands:

“CALL:BAND” on page 296

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_gen_bse_cell_band.fm

Setting the Radio Configuration

The test set’s base station emulator provides five radio configuration selections. To set the the radio configuration using the test set’s front panel, see “How Do I Set Up a Call?” on page 683.

Radio Configuration

The following GPIB subsystem describes the rad io configuration settings:

“CALL[:CELL]:RCONfig”

To select a service optio n fo r t he se l ected radio co n f iguration, see “CALL[:CELL]:SOPTION”

100

S:\Hp8960\E1962B CDMA 2000\3.2 Release\Reference Guide\Chapters\cdma2000_gen_bse_radio_config.fm

Agilent 8960 Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Measurements

Instrument Configuration Measurement Matrix

Access Probe Power Measurement Description

How is an Access Probe Power measurement made?

Considerations when making Access Probe Power measurements

Input Signal Requirements
