Reference Guide

HP 8753ES Option 011

Network Analyzer

HP Part Number 08753-90480

Printed in USA

August 1999

Hewlett-Packard Company

Notice

The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including

but not limited to, the implied warranties of merchantability and ﬁtness for a particular purpose. Hewlett-Packardshallnot be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

Certiﬁcation

Hewlett-Packard Company certiﬁes that this product met its published speciﬁcations at the time of shipment from the factory. Hewlett-Packard further certiﬁes that its calibration measurements are traceable to the United States National Institute of Standards and Technology, to the extent allowed by the Institute's calibration facility, and to the calibration facilities of other International Standards Organization members.

Regulatory and Warranty Information

The regulatory and warranty information is located in the user’s guide.

Assistance

Product maintenance agreements and other customer assistance agreements are available for Hewlett-Packard products. For any assistance, contact your nearest Hewlett-Packard sales or service ofﬁce. See the user’s guide for the nearest ofﬁce.

Safety Notes

The following safety notes are used throughout this manual. Familiarize yourself with each of the notes and its meaning before operating this instrument. All pertinent safety notes for using this product are located in the user’s guide.

WARNING Warning denotes a hazard. It calls attention to a procedure which, if

not correctly performed or adhered to, could result in injury or loss of life. Do not proceed beyond a warning note until the indicated conditions are fully understood and met.

CAUTION Caution denotes a hazard. It calls attention to a procedure that, if not

correctly performed or adhered to, would result in damage to or destruction of the instrument. Do not proceed beyond a caution sign until the indicated conditions are fully understood and met.

iii

How to Use This Guide

SOFTKEY

This guide uses the following conventions:

Front-Panel Key

Screen Text This represents text displayed on the instrument’s screen.

This represents a key physically located on the instrument.

This represents a “softkey,” a key whose label is determined by the instrument’s ﬁrmware.

Documentation Map

The Installation and Quick Start Guide provides procedures for installing, conﬁguring, and verifying the operation of the analyzer. It also will help you familiarize yourself with the basic operation of the analyzer.

The User’s Guide shows how to make measurements, explains commonly-used features, and tells you how to get the most performance from your analyzer.

The Reference Guide provides reference information, such as speciﬁcations, menu maps, and key deﬁnitions.

The Programmer’s Guide provides general HP-IB programming information, a command reference, and example programs. The Programmer’s Guide contains a CD-ROM with example programs.

The CD-ROM provides the Installation and Quick Start Guide, the User’s Guide, the Reference Guide, and the Programmer’s Guide in PDF format for viewing or printing from a PC.

The Service Guide provides information on calibrating, troubleshooting,and servicing your analyzer. The Service Guide is not part of a standard shipment and is available only as Option 0BW, or by ordering HP part number 08753-90485. A CD-ROM with the Service Guide in PDF format is included for viewing or printing from a PC.

Contents

1. HP 8753ES Option 011 Speciﬁcations and Characteristics

Deﬁnitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Corrected System Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Instrument Speciﬁcations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4

Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

General Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13

Speed Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18

Power Meter Calibration Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21

2. Front/Rear Panel

Front Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Analyzer Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Rear Panel Features and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9

3. Menu Maps

Menu Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

4. Hardkey/Softkey Reference

Key Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

Where to Look for More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Guide Terms and Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Analyzer Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

5. Error Messages

Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Error Messages in Alphabetical Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Error Messages in Numerical Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-23

6. Options and Accessories

Using This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2

Analyzer Options Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Option 1D5, High Stability Frequency Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Option 002, Harmonic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Option 006, 6 GHz Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Option 010, Time Domain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Option 075, 75 W Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Option 1CM, Rack Mount Flange Kit Without Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Option 1CP, Rack Mount Flange Kit With Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Service and Support Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Accessories Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Measurement Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Test-Port Cables: Type-N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Calibration Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

RF electronic calibration modules and PC software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6

Veriﬁcation Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

Test sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

Minimum Loss Pads and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8

Test Conﬁguration Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

RF Limiter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9

Ampliﬁer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

vii

Contents

Power Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9

Power Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

Keyboard Template . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10

7. Preset State and Memory Allocation

Preset State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2

Memory Allocation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12

Types of Memory and Data Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12

Volatile Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12

Non-Volatile Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12

Determining Memory Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14

Storing Data to Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16

Conserving Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18

Using Saved Calibration Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18

8. Understanding the CITIﬁle Data Format

Using This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2

The CITIﬁle Data Format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-3

Description and Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

Data Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

File and Operating System Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-3

Deﬁnition of CITIﬁle Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

A CITIﬁle Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

The CITIﬁle Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

An Array of Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

CITIﬁle Keyword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

CITIﬁle Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6

Example 2, An 8510 Display Memory File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6

Example 3, 8510 Data ﬁle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Example 4, 8510 3-Term Frequency List Cal Set File . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8

CITIﬁle Keywords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10

Useful Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13

Computing Frequency Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13

Expressing CITIﬁle Data in Other Data Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

Example Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15

9. Determining System Measurement Uncertainties

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

Sources of Measurement Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

Sources of Systematic Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-3

Sources of Random Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4

Determining Expected System Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5

Determining Cable Stability Terms (CR1, CR2, C

TM1

, C

TM2

, C

TP1

, C

) . . . . . . . . . . . . . . . 9-6

TP2

Measurement Uncertainty Equations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8

Forward Reﬂection Uncertainty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8

Forward Transmission Uncertainty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-9

Reverse Reﬂection Uncertainty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10

Reverse Transmission Uncertainty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11

viii

1 HP 8753ES Option 011

Speciﬁcations and Characteristics

1-1

HP 8753ES Option 011 Speciﬁcations and Characteristics

Deﬁnitions

All speciﬁcations and characteristics apply over a 25 °C ±5 °C range (unless otherwise stated) and 1/2 hour after the instrument has been turned on.

Speciﬁcation (spec.): Warranted performance. Speciﬁcations include guardbands to

account for the expected statistical performance distribution, measurement uncertainties, and changes in performance due to environmental conditions.

Characteristic (char.): A performance parameter that the product is expected to meet

before it leaves the factory, but that is not veriﬁed in the ﬁeld and is not covered by the product warranty. A characteristic includes the same guardbands as a speciﬁcation.

Typical (typ.): Expected performance of an average unit which does not include

guardbands. It is not covered by the product warranty.

Nominal (nom.): A general, descriptive term that does not imply a level of performance. It

is not covered by the product warranty.

Calibration: The process of measuring known standards from a calibration kit to

characterize a network analyzer’s systematic (repeatable) errors.

Corrected (residual) Performance: Indicates performance after error correction

(calibration). It is determined by the quality of calibration standards and how well “known” they are, plus system repeatability, stability, and noise.

Uncorrected (raw) Performance: Indicates instrument performance without error

correction. The uncorrected performance affects the stability of a calibration.

Option 011: This includes all options available with Option 011 unless noted otherwise.

1-2

HP 8753ES Option 011 Speciﬁcations and Characteristics

Corrected System Performance

The speciﬁcations in this section apply for measurements made using 10 Hz IF bandwidth, no averaging, and at an environmental temperature of 25 ±5 °C, with less than 1°C deviation from the calibration temperature. Assumes that an isolation calibration was performed with an averaging factor of 16.

Table 1-1 System Dynamic Range, All Device Connector Types

HP 8753ES Option 011, All Options, All Cal Kits, All Cables, 10 Hz IF BW Description Speciﬁcation Supplemental

Information

System Transmission Dynamic Range

Channels A and B

300 kHz to 16 MHz 100 dB 16 MHz to 3 GHz 110 dB 3 GHz to 6 GHz (Option 006 only) 105 dB

Channel R

300 kHz to 3 GHz 35 dB 3 GHz to 6 GHz (Option 006 only) 30 dB

a. The System Transmission Dynamic Range is calculated as the difference

between the receiver noise ﬂoor and the lesser of either: the source maximum output or the receiver maximum input.

1-3

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Source

Table 1-2 Source

HP 8753ES Option 011 Source Description Speciﬁcation Supplemental Information

Frequency

Range

Option 011 300 kHz to 3.0 GHz 300 kHz to 3 GHz, typ.

Option 011 with Option 006 30 kHz to 6.0 GHz 10 kHz to 6 GHz, typ. Resolution 1 Hz Stability

Option 011 ±7.5 ppm, 0˚ to 55˚C, typ.

±3 ppm/year

Option 011 with Option 1D5 ±0.05 ppm, 0˚ to 55˚C, typ.

±0.5 ppm/year

CW Accuracy ±10 ppm at 25˚C ±5˚C

Output Power (above 300 kHz)

Level Accuracy Maximum Leveled Power

Option 011 +20 dBm, char.

Option 011 and 006 +18 dBm, char. Power Range

Option 011 −5 to +20 dBm

Option 011 and 006 −5 to +18 dBm Power Sweep Range

Option 011 25 dB 33 dB, typ.

Option 011 and 006 23 dB 31 dB, typ.

±1.0 dB at +10 dBm output level

a. Absolute power accuracy at a given power level. Includes absolute accuracy and relative

flatness across frequency.

b. At any given frequency, the achievable power while remaining leveled. Applies to CW

mode only.

c. Power to which the source can be set and phase lock is assured.

1-4

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-3 Source

HP 8753ES Option 011 Source Description Speciﬁcation Supplemental Information

Output Power (above 300 kHz)

Power Resolution 0.01 dB Linearity

−5 to +15 dBm ±0.25 dB relative to +10 dBm output level +15 to +20 dBm ±0.5 dB relative to +10 dBm output level Option 011 and 006

−5 to +13 dBm ±0.25 dB relative to +10 dBm output level +13 to +18 dBm ±0.5 dB relative to +10 dBm output level

Impedance

Standard 50 Ω, nom.

Return Loss

300 kHz to 3 GHz > 16 dB, typ. 3 GHz to 6 GHz > 14 dB, typ.

Signal Purity

2nd Harmonic 16 MHz to 1.5 GHz (source freq.)

at maximum output power power

at +0 dBm output power < −40 dBc, typ. at −10 dBm output power < −50 dBc, typ.

3rd Harmonic 16 MHz to 1 GHz (source freq.)

at maximum output power power

at +0 dBm output power < −40 dBc, typ.

at −10 dBm output power < −50 dBc, typ. Non-harmonic Spurious Mixer Related

at +10 dBm output power < −30 dBc, typ.

at −10 dBm output power < −55 dBc, typ.

16 MHz to 3 GHz (Option 006, source freq.)

< −25 dBc (Option 002

< −25 dBc, char. (non-Option 002)

only)

16 MHz to 2GHz (Option 006, source freq.)

< −25 dBc (Option 002

< −25 dBc, char. (non-Option 002)

only)

a. Change in source output power for a given change in source power setting at any given

frequency.

1-5

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Receiver

Table 1-4 Receiver

HP 8753ES Option 011 Receiver Description Speciﬁcation Supplemental Information

Frequency Range

Option 011 300 kHz to 3.0 GHz 300 kHz to 3 GHz, typ. Option 011 and 006 30 kHz to 6.0 GHz 10 kHz to 6 GHz, typ.

Frequency Response

300 kHz to 3 GHz ±1 dB at −10 dBm 3 GHz to 6 GHz ±2 dB at −10 dBm

Frequency Response (Ratio)

Amplitude

300 kHz to 3 GHz ±0.5 dB, typ. 3 GHz to 6 GHz ±2.0 dB, typ.

Phase

300 kHz to 3 GHz ±3°−10 dBm, all inputs 3 GHz to 6 GHz ±10°−10 dBm, all inputs

Stability (Ratio Measurement)

Magnitude

300 kHz to 3 GHz 0.02 dB/°C, typ. 3 GHz to 6 GHz 0.04 dB/°C, typ

Phase

300 kHz to 3 GHz 0.05 deg/°C, typ 3 GHz to 6 GHz 0.20 deg/°C, typ

Impedance

Option 011 50 Ω, nominal.

30 kHz to 300 kHz 7 dB, typ. 300 kHz to 2 MHz 20 dB 2 MHz to 1.3 GHz 24 dB

1.3 GHz to 3 GHz 19 dB 3 GHz to 6 GHz 15 dB

Maximum Input Level

Option 011 0 dBm Compression See dynamic accuracy chart

Damage Level

Option 011 > +20 dBm or > 25 Vdc, typ.

1-6

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-4 Receiver (Continued)

HP 8753ES Option 011 Receiver Description Speciﬁcation Supplemental Information Noise Floor

Option 011

300 kHz to 3 GHz

3 kHz IF Bandwidth ≤−90 dBm 10 Hz IF Bandwidth ≤−110 dBm ≤−120 dBm, typ.

3 GHz to 6 GHz

3 kHz IF Bandwidth ≤−85 dBm 10 Hz IF Bandwidth ≤−105 dBm ≤−115 dBm, typ.

a. RMS value of a linear magnitude trace expressed in dBm.

1-7

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-5 Receiver

HP 8753ES Option 011 Receiver Description Speciﬁcation Supplemental Information

Internally Generated Harmonics (Option 002 Only)

2nd Harmonic 16 MHz to 3 GHz

at +0 dBm input level < −15 dBc at −10 dBm input level < −30 dBc, typ. at −30 dBm input level < −45 dBc, typ.

3rd Harmonic 16 MHz to 2 GHz

at +0 dBm input level < −30 dBc at −10 dBm input level < −50 dBc, typ. at −30 dBm input level < −50 dBc, typ.

Harmonic Measurement Accuracy

300 kHz to 3 GHz ±1.5 dB 3 GHz to 6 GHz ±3 dB

Harmonic Measurement Dynamic Range

Standard −40 dBc, typ.

output at −10 dBm and input at < −15 dBm

Minimum R Level

300 kHz to 3 GHz −35 dBm 3 GHz to 6 GHz −30 dBm

Input Crosstalk

300 kHz to 1 GHz −100 dB 1 GHz to 3 GHz −90 dB 3 GHz to 4.5 GHz −82 dB

4.5 GHz to 6 GHz −75 dB

1-8

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-6 Receiver

HP 8753ES Option 011 Receiver Description Speciﬁcation Supplemental Information Frequency Offset Operation

Frequency Range

Option 011 300 kHz to 3 GHz

Option 011 and Option 006 300 kHz to 6 GHz R Channel Input Requirements

300 kHz to 3 GHz 0 to −35 dBm

3 GHz to 6 GHz 0 to −30 dBm LO Spectral Purity and

Accuracy

Maximum Spurious Input < −25 dBc, typ.

Residual FM < 20 kHz, typ.

Frequency Accuracy −1 to +1 MHz of nominal

External Source Mode

Frequency Range at − 25 dBm R channel power

Option 011 300 kHz to 3 GHz

Option 011 and Option 006 300 kHz to 6 GHz R Input Requirements Power Level 0 to −25 dBm, typ. R Input Spectral Purity

Requirement

Maximum Spurious Input < −30 dBc, typ.

Residual FM < 20 kHz, typ. Settling Time

Auto 500 ms, typ.

Manual 50 ms, typ. Frequency Readout Accuracy 0.1%, auto, typ. Input Frequency Accuracy

Requirement Manual −0.5 to 5 MHz, typ.

frequency, typ.

level

a. The RF source characteristics in this mode are dependent on the stability of the external

LO source. The RF source tracks the LO to maintain a stable IF signal at the R channel receiver input.

b. Measurement accuracy is dependent on the stability of the input signal.

1-9

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-7 Receiver

HP 8753ES Option 011 Receiver Description Speciﬁcation

System Bandwidths

3000 Hz 10 Hz

Trace Noise

Magnitude

300 kHz to 3 GHz < 0.006 dB rms < 0.001 dB rms 3 GHz to 6 GHz < 0.010 dB rms < 0.002 dB rms

Phase

300 kHz to 3 GHz < 0.038° rms < 0.006° rms 3 GHz to 6 GHz < 0.070° rms < 0.012° rms

a. Trace noise is deﬁned for a channel/R ratio measurement with 20 dB of

padding and a 6 dB power splitter on the source with equal length/loss cables to the channel and R receivers, and a power of −10 dBm into the receivers.

Table 1-8 Receiver

HP 8753ES Option 011 Receiver Description Speciﬁcation Supplemental

Information

Reference Level

Magnitude

Range ±500 dB Resolution 0.001 dB

Phase

Range ±500° Resolution 0.01°

1-10

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-9 Receiver

HP 8753ES Option 011 Receiver (A and B Channel) Dynamic Accuracy (Speciﬁcation)

For inputs A and B, accuracy of the test port input power reading relative to the reference input power level.

• Inputs: test port A and B

• For test port powers > −50 dBm and < 0 dBm, magnitude dynamic accuracy is

0.02 dB + 0.001 dB/dB from the reference power, phase dynamic accuracy is

0.132 deg + 0.0066 deg/dB from the reference power.

1-11

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-10 Test Port Input

HP 8753ES Option 011 R-Channel Input Dynamic Accuracy (Typical)

Accuracy of the R-channel power reading relative to the R-channel reference power level. These curves apply when the calibrated power level and the measurement power level are not the

same.

• Inputs: R-channel

• For Option 075 and 014, for test port powers up to the maximum source power.

300 KHz to 3 GHz 3 to 6 GHz

Magnitude Dynamic Accuracy for Test Port Powers

> −35 dBm and < −10 dBm .02 dB + .001 dB/dB

from the reference power

> 0 dBm and < 100 dBm .02 dB + .02 dB/dB

above 0 dBm

Phase Dynamic Accuracy for Test Port Powers

> −35 dBm and < −10 dBm .132 deg + .0066 deg/dB

from the reference power

> −10 dBm and < 0 dBm .132 deg + .132 deg/dB

above 0 dBm

.02 dB + .001 dB/dB from the reference power

.02 dB + .03 dB/dB above 0 dBm

.132 deg + .0066 deg/dB from the reference power

.132 deg + .198 deg/dB above 0 dBm

1-12

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

General Information

Table 1-11 General Information

HP 8753ES Option 011 General Information Description Speciﬁcation Supplemental Information

Display Range

Magnitude ±200 dB (at 20 dB/div), max Phase ±180°, max Polar 10 pico units, min

1000 units, max

Display Resolution

Magnitude 0.001 dB/div, min Phase 0.01°/div, min

Reference Value Range

Magnitude ±500 dB, max Phase ±360 °, max

Reference Level Resolution

Magnitude 0.001 dB, min Phase

Marker Resolution

Magnitude 0.001 dB, min Phase

Polar 0.01 mUnit, min; 0.01, min

0.01°, min

1-13

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-12 General Information

HP 8753ES Option 011 General Information Description Supplemental Information

System Bandwidths

IF bandwidth settings 6000 Hz, nom.

3700 Hz, nom. 3000 Hz, nom. 1000 Hz nom. 300 Hz, nom. 100 Hz, nom. 30 Hz, nom. 10 Hz, nom.

Rear Panel

External Auxiliary Input

Connector Female BNC Range ±10 V, typ.

External Trigger Triggers on a positive or negative TTL transition or contact

closure to ground. Damage Level < −0.2 V; > +5.2 V, typ. Limit Test Output Female BNC. Damage Level < −0.2 V; > +5.2 V, typ. Test Sequence Output Outputs a TTL signal which can be set to a TTL high pulse

(default) or low pulse at end of sweep; or a ﬁxed TTL high or

low. If limit test is on, the end of sweep pulse occurs after the

limit test is valid. This is useful when used in conjunction with

test sequencing. Test Set Interconnect 25-pin-D-sub (DB-25) female; use for external special test sets

(K36, K39, etc.) Measure Restart Floating closure to restart measurement. External AM Input ±1 volt into a 5 kΩ resistor, 1 kHz maximum, resulting in

approximately 8 dB/volt amplitude modulation. High Stability Frequency

Reference Output (10 MHz) (Option 1D5)

Frequency 10.0000 MHz, char. Frequency Stability

(0 °C to 55 °C) Daily aging rate (after 30 days)

Yearly aging rate ±0.5 ppm/year, char. Ouput ≥0 dBm, char. Output Impedance 50 Ω, nom.

±0.05 ppm, char.

< 3 x 10−9/day, char.

1-14

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-13 General Information

HP 8753ES Option 011 General Information Description Speciﬁcation Supplemental Information

Rear Panel

External Reference In

Input Frequency 1, 2, 5, and 10 MHz ±200 Hz at 10 MHz Input Power −10 dBm to +20 dBm, typ. Input Impedance 50 Ω, nom.

VGA Video Output 15-pin mini D-Sub; female. Drives

VGA compatible monitors.

HPIB Type-57, 24-pin; Microribbon

female

Parallel Port 25-pin D-Sub (DB-25); female;

may be used as printer port or

general purpose I.O. port RS232 9-pin D-Sub (DB-9); male Mini-DIN Keyboard/Barcode Reader 6-pin mini DIN (PS/2); female Line Power A third-wire ground is required.

Frequency 47 Hz to 66 Hz Voltage at 115 V setting 90 V to 132 V 115 V, nom. Voltage at 220 V setting 198 V to 265 V 230 V, nom. VA Maximum 350 VA max

Front Panel

RF Connectors Type-N Probe Power 3-pin connector; male

Positive Supply 400 mA, max +15 V ±2%, char.

the maximum combined load for

both probe connectors, char.

Negative Supply 300 mA, max −12.6 V ±5%, char.

the maximum combined load for

both probe connectors, char.

1-15

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-14 General Information

HP 8753ES Option 011 General Information Description Speciﬁcation

Front Panel

Display Pixel Integrity

Red, Green, or Blue Pixels Red, green, or blue "stuck on" pixels may

appear against a black background. In a properly working display, the following will not occur:

• complete rows or columns of stuck pixels

• more than 5 stuck pixels (not to exceed a maximum of 2 red or blue, and 3 green)

• 2 or more consecutive stuck pixels

• stuck pixels less than 6.5 mm apart

Dark Pixels Dark "stuck on" pixels may appear against a

white background. In a properly working display, the following will not occur:

• more than 12 stuck pixels (not to exceed a maximum of 7 red, green, or blue)

• more than one occurrence of 2 consecutive stuck pixels

• stuck pixels less than 6.5 mm apart

1-16

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-15 General Information

HP 8753ES Option 011 General Information Description Speciﬁcation Supplemental Information

General Environmental

RFI/EMI Susceptibility Deﬁned by CISPR Pub. 11 and

FCC Class B standards.

ESD Minimize using static-safe

work procedures and an antistatic bench mat (HP part number 9300-0797).

Dust Minimize for optimum

reliability.

Operating Environment

Temperature 0 °C to +55 °C Instrument powers up, phase

locks, and displays no error messages within this temperature range.

Error-corrected temperature range

Humidity 5% to 95% at +40 °C

(non-condensing)

Altitude 0 to 4.5 km (15,000 ft)

Storage Conditions

Temperature −40 °C to +70 °C Humidity 0% to 95% RH at +65 °C

(non-condensing)

Altitude 0 to 15.24 km (50,000 ft)

Cabinet Dimensions

Height x Width x Depth 222 x 425 x 457 mm, nom.

Weight

Shipping 32 kg (77 lb), nom. Net 24 kg (53lb), nom.

Internal Memory - Data Retention Time with 3 V, 1.2 Ah Battery

70 °C 250 days (0.68 year), typ. 40 °C 1244 days (3.4 years), typ. 25 °C 10 years, typ.

see system speciﬁcations

(8.75 x 16.75 x 18 in, nom.) Cabinet dimensions exclude front and rear protrusions.

a. Analyzer power is switched off.

1-17

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Speed Parameters Table 1-16 HP 8753ES Option 011 Measurement and Data Transfer Speed

Performance

Typical Time for Completion (ms)

Description Number of Points

51 201 401 1601

Typical Time for Completion (in ms), Start 1 GHz, Span 10 MHz, IFWB=6000

Uncorrected 32 70 121 423 1-port and Enhanced Response cal 2-port cal

Typical Time for Completion (in ms), Start 30 kHz, Stop 3 GHz, IFWB=6000

Uncorrected 202 270 304 615 1-port and Enhanced Response cal 2-port cal

Typical Time for Completion (in ms), Start 30 kHz, Stop 6 GHz, IFWB=6000

Uncorrected 310 380 415 658 1-port and Enhanced Response cal 2-port cal

35 71 127 440 62 139 240 848

202 270 304 615 402 540 607 1237

310 380 415 658 618 757 829 1315

Time Domainc (increase over uncorrected sweep time)

Conversions 12 42 86 378 Gating (Frequency Domain) 14 40 80 349

HP-IB Data Transferd:

Binary (Internal) 10 16 21 58 IEEE754 ﬂoating point format

32 bit 11 19 28 83 64 bit 13 26 42 141 ASCII 35 112 214 831

a. S11 1-port calibration, with a 6 kHz IF bandwidth. Includes system retrace time, but

does not include bandswitch time. Time domain gating is assumed off.

b. S21 measurement with full 2-port calibration, using a 6 kHz IF bandwidth. Includes

system retrace time and RF switching time, but does not include bandswitch time. Time

domain gating is assumed off. c. Option 010 only, gating off. d. Measured with HP Omnibook 7100 Pentium computer.

1-18

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-17 HP 8753ES Option 011 Recall and Sweep Speed Performance

Total Time,

typical (secs)

Raw

Operations Channel Points Error Correction

Recall and Sweep Single Chan. 201 On 0.389 0.260 0.250 0.126 Recall and Sweep Single Chan. 201 Off 0.340 0.210 0.201 0.077 Sweep only (no Recall) Single Chan. 201 N/A 0.139 0.134 N/A N/A Recall and Sweep Single Chan. 1601 On 1.480 1.347 0.632 0.506 Recall and Sweep Single Chan. 1601 Off 1.102 0.969 0.254 0.128 Sweep only (no Recall) Single Chan. 1601 N/A 0.848 0.841 N/A N/A Recall and Sweep Dual Chan. 201 On 0.539 0.389 0.357 0.215 Recall and Sweep Dual Chan. 201 Off 0.489 0.328 0.308 0.154 Sweep only (no Recall) Dual Chan. 201 N/A 0.182 0.174 N/A N/A Recall and Sweep Dual Chan. 1601 On 2.386 2.219 1.208 1.049 Recall and Sweep Dual Chan. 1601 Off 2.007 1.839 0.829 0.669 Sweep only (no Recall) Dual Chan. 1601 N/A 1.178 1.170 N/A N/A

Error Correction OFF

Recall and Sweep Single Chan. 201 On 0.240 0.147 0.170 0.082 Recall and Sweep Single Chan. 201 Off 0.227 0.134 0.157 0.069 Sweep only (no Recall) Single Chan. 201 N/A 0.070 0.065 N/A N/A Recall and Sweep Single Chan. 1601 On 0.675 0.587 0.252 0.168 Recall and Sweep Single Chan. 1601 Off 0.581 0.491 0.157 0.073 Sweep only (no Recall) Single Chan. 1601 N/A 0.423 0.419 N/A N/A Recall and Sweep Dual Chan. 201 On 0.306 0.170 0.235 0.104 Recall and Sweep Dual Chan. 201 Off 0.281 0.145 0.211 0.080 Sweep only (no Recall) Dual Chan. 201 N/A 0.071 0.066 N/A N/A Recall and Sweep Dual Chan. 1601 On 0.802 0.692 0.377 0.273 Recall and Sweep Dual Chan. 1601 Off 0.613 0.503 0.188 0.084 Sweep only (no Recall) Dual Chan. 1601 N/A 0.424 0.419 N/A N/A Instrument State: CF = 1 GHz, Span = 2 MHz, IF BW = 6 kHz. HP-IB commands sent for timing

are Recall;OPC?;SING; or, for sweep only, OPC?;SING;.

Offset

Blank Off

BlankOnBlank

Recall-Only

Time, typical

(secs)

Blank

Off

1-19

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Table 1-18 Sweep Time vs. IF Bandwidth

IF Bandwidth

Typical Sweep Time (seconds)

6000 0.070 3700 0.095 3000 0.121 1000 0.248 300 0.704 100 2.022 30 6.987 10 21.365

a. Preset condition, CF = 1 GHz, Span = 100 MHz; includes retrace time, 201 points.

Table 1-19 Sweep Time vs. Number of Points

Number of Points

Typical Sweep Time (seconds)

51 0.039 101 0.057 201 0.095 401 0.171 801 0.323 1601 0.625

a. Preset condition, CF = 1 GHz, Span = 100 MHz, Correction off; includes retrace time.

Measurement speed can be improved by selecting the widest IF bandwidth setting of 6000 Hz.

1-20

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

Power Meter Calibration Accuracy

Table 1-20 Power Meter Calibration Sweep Speed and Accuracy

Power Desired at

Test Port

+5 dBm

−15 dBm

−30 dBm

a. Sweep speed applies to every sweep in continuous correction mode, and to the ﬁrst

sweep in sample-and-sweep mode. Subsequent sweeps in sample-and-sweep mode will be much faster.

b. The accuracy values were derived by combining the accuracy of the power meter and

linearity of the analyzer's internal source, as well as the mismatch uncertainty associated with the power sensor.

Number of

Readings

1 2 3

Sweep Time

Setting (seconds)

33 64 95

48 92

123 194

360 447

Characteristic

Accuracy (dB)

±0.7 ±0.2 ±0.1

1-21

HP 8753ES Option 011 Speciﬁcations and Characteristics

Instrument Speciﬁcations

1-22

2 Front/Rear Panel

2-1

Front/Rear Panel

Front Panel Features

CAUTION Do not mistake the line switch for the disk eject button. See the following

illustration. If the line switch is mistakenly pushed, the instrument will be turned off, losing all settings and data that have not been saved.

Figure 2-1 HP 8753ES Option 011 Front Panel

The location of the following front panel features and key function blocks is shown in

Figure 2-1. These features are described in more detail later in this chapter, and in Chapter 4 , “Hardkey/Softkey Reference.”

1. LINE switch. This switch controls ac power to the analyzer. 1 is on, 0 is off.

2. Display. This shows the measurement data traces, measurement annotation, and softkey labels. The display is divided into speciﬁc information areas, illustrated in Figure 2-2.

3. Disk drive. This 3.5 inch ﬂoppy-disk drive allows you to store and recall instrument states and measurement results for later analysis.

4. Disk eject button.

5. Softkeys. These keys provide access to menus that are shown on the

display.

2-2

Front/Rear Panel

Front Panel Features

6. STIMULUS function block. The keys in this block allow you to control the analyzer source's frequency, power, and other stimulus functions.

7. RESPONSE function block. The keys in this block allow you to control the measurement and display functions of the active display channel.

8. ACTIVE CHANNEL keys. The analyzer has two independent primary channels and two auxiliary channels. These keys allow you to select the active channel. Any function you enter applies to the selected channel.

9. The ENTRY block. This block includes the knob, the step keys, the number pad, and the backspace key. These allow you to enter numerical data and control the markers.

You can use the numeric keypad to select digits, decimal points, and a minus sign for numerical entries. You must also select a units terminator to complete value inputs.

The backspace key has two independent functions: it modiﬁes entries, and it turns off the softkey menu so that marker information can be moved off of the grids and into the softkey menu area. For more details, refer to the “Making Measurements” chapter in the user’s guide.

10. INSTRUMENT STATE function block. These keys allow you to control channel-independent system functions such as the following:

• copying, save/recall, and HP-IB controller mode

• limit testing

• external source mode

• tuned receiver mode

• test sequence function

• harmonic measurements (Option 002)

• time domain transform (Option 010) HP-IB STATUS indicators are also included in this block.

11. key. This key returns the instrument to either a known factory

Preset

preset state, or a user preset state that can be deﬁned. Refer to Chapter 7 ,

“Preset State and Memory Allocation” for a complete listing of the

instrument preset condition.

12. PROBE POWER connectors. These connector (fused inside the instrument) supply power to an active probe for in-circuit measurements of ac circuits.

13. R, A, and B connectors. These connectors allow you to apply input signals when creating your own test setup. In addition, these connectors allow you to use the HP 85046A/B, HP 85044A/B test sets to simplify measurement setup.

14. RF OUT connector. This connects the RF output signal from the analyzer to a test set or power splitter.

2-3

Front/Rear Panel

Analyzer Display

Figure 2-2 Analyzer Display (Single Channel, Cartesian Format)

The analyzer display shows various measurement information:

• The grid where the analyzer plots the measurement data.

• The currently selected measurement parameters.

• The measurement data traces.

Figure 2-2 illustrates the locations of the different information labels described below.

In addition to the full-screen display shown in the illustration above, multi-graticule and multi-channel displays are available, as described in the “Using Instrument Functions” chapter of the user’s guide.

Several display formats are available for different measurements, as described under " " in Chapter 4 , “Hardkey/Softkey Reference.”

Format

1. Stimulus Start Value. This value could be any one of the following:

• The start frequency of the source in frequency domain measurements.

• The start time in CW mode (0 seconds) or time domain measurements.

• The lower power value in power sweep. When the stimulus is in center/span mode, the center stimulus value is

shown in this space. The color of the stimulus display reﬂects the current active channel.

2-4

Front/Rear Panel

FREQUENCY BLANK

Analyzer Display

2. Stimulus Stop Value. This value could be any one of the following:

• The stop frequency of the source in frequency domain measurements.

• The stop time in time domain measurements or CW sweeps.

• The upper limit of a power sweep. When the stimulus is in center/span mode, the span is shown in this space.

The stimulus values can be blanked, as described under the

softkey in Chapter 4 , “Hardkey/Softkey

Reference.”

(For CW time and power sweep measurements, the CW frequency is displayed centered between the start and stop times or power values.)

3. Status Notations. This area shows the current status of various functions for the active channel.

The following notations are used: Avg Sweep-to-sweep averaging is on. The averaging count is

shown immediately below. (See the key in Chapter

Avg

4 , “Hardkey/Softkey Reference.”)

Cor Error correction is on. (For error-correction procedures,

refer to the "Calibrating for Increased Measurement Accuracy" chapter in the user’s guide. For error correction theory, refer to the “Operating Concepts” chapter of the user’s guide.

C∆ Stimulus parameters have changed from the

error-correctedstate, or interpolated error correction is on. (For error-correction procedures, refer to the "Calibrating for Increased Measurement Accuracy" chapter in the user’s guide. For error correction theory, refer to the “Operating Concepts” chapter of the user’s guide.

C2 (ES) Full two-port error-correction is on and the reverse sweep

is not updated each sweep Any one of the following causes the reverse sweep not to be

updated each sweep:

• the instrument uses a mechanical switch, for example Options 85 and 007.

• different channel power ranges (PORT POWER UNCOUPLED) which puts the test set switch in HOLD mode except Option 400 (dual step attenuators).

• the user manually puts the test set switch in HOLD mode (TESTSET SW 0 or >1).

2-5

Front/Rear Panel

HOLD

POWER

Analyzer Display

Del Electrical delay has been added or subtracted, or port

extensions are active. (See the “Operatiing Concepts” chapter of the user’s guide and the key in

Scale Ref

Chapter 4 , “Hardkey/Softkey Reference.”)

ext Waiting for an external trigger. Ofs Frequency offset mode is on. (See the “Making Mixer

Measurements” chapter in the user’s guide.)

Of? Frequency offset mode error, the IF frequency is not

within 10 MHz of expected frequency. LO inaccuracy is the most likely cause. (See the “Making Mixer Measurements” chapter in the user’s guide.)

Gat Gating is on (time domain Option 010 only). (For time

domain measurement procedures and theory, refer to the "Making Time Domain Measurements" chapter of the user’s guide.)

H=2 Harmonic mode is on, and the second harmonic is being

measured (harmonics Option 002 only). (See Chapter 6 ,

“Options and Accessories.”)

H=3 Harmonic mode is on, and the third harmonic is being

measured (harmonics Option 002 only). (See Chapter 6 ,

“Options and Accessories.”)

Hld Hold sweep. (See in Chapter 4 , “Hardkey/Softkey

Reference.”)

man Waiting for manual trigger. PC Power meter calibration is on. (For power meter

calibration procedures, refer to the "Calibrating for Increased Measurement Accuracy" chapter of the user’s guide.)

PC? The analyzer's source could not be set to the desired level,

following a power meter calibration. (For power meter calibration procedures, refer to the "Calibrating for Increased Measurement Accuracy" chapter in the user’s guide.)

P? Source power is unleveled at start or stop of sweep. (Refer

to the service guide for troubleshooting.)

P↓ Source power has been automatically set to minimum, due

to receiver overload. (See in Chapter 4 ,

“Hardkey/Softkey Reference.”)

2-6

Smo Trace smoothing is on. (See " " in Chapter 4 ,

Avg

“Hardkey/Softkey Reference.”)

tsH Indicates that the test set hold mode is engaged. That is, a

mode of operation is selected which would cause repeated

Front/Rear Panel

MEASURE RESTART

NUMBER OF GROUPS

Analyzer Display

switching of the step attenuator. This hold mode may be overridden. See or

in Chapter 4 , “Hardkey/Softkey

Reference.”

↑ Fast sweep indicator. This symbol is displayed in the

status notation block when sweep time is ≤1.0 second. When sweep time is ≥ 1.0 second, this symbol moves along the displayed trace.

* Source parameters changed: measured data in doubt until

a complete fresh sweep has been taken.

4. Active Entry Area. This displays the active function and its current value.

5. Message Area. This displays prompts or error messages.

6. Title. This is a descriptive alphanumeric string title that you deﬁne and

enter through an attached keyboard or as described the "Printing, Plotting, and Saving Measurement Results" chapter of the user’s guide.

7. Active Channel. This is the label for the number for the active channel, selected with the , , , and keys.

Chan 1 Chan 2 Chan 3 Chan 4

If multiple channels are overlaid, the labels will appear in this area. The active channel is denoted by a rectangle around the channel number.

For multiple-graticule displays, the channel information labels will be in the same relative position for each graticule.

NOTE The label of the active channel is enclosed in a rectangle to differentiate it

from inactive channels.

8. Measured Input(s). This shows the parameter, input, or ratio of inputs currently measured, as selected using the key. Also indicated in

Meas

this area is the current display memory status.

9. Format. This is the display format that you selected using the

Format

key.

10. Scale/Div. This is the scale that you selected using the key, in

Scale Ref

units appropriate to the current measurement.

11. Reference Level. This value is the reference line in Cartesian formats or the outer circle in polar formats, whichever you selected using the

Scale Ref

key. The reference level is also indicated by a small triangle adjacent to the graticule, at the left for channel 1 and at the right for channel 2 in Cartesian formats.

12. Marker Values. These are the values of the active marker, in units appropriate to the current measurement. (Refer to "Using Analyzer Display Markers" in the "Making Measurement" chapter of the user’s guide.)

2-7

Front/Rear Panel

Analyzer Display

13. Marker Stats, Bandwidth. These are statistical marker values that the analyzer calculates when you access the menus with the key.

Marker Fctn

(Refer to "Using Analyzer Display Markers" in the "Making Measurements" chapter of the user’s guide.)

This general area is also where information for additional markers is placed. Note that Stats and Bandwidth have priority.

14. Softkey Labels. These menu labels redeﬁne the function of the softkeys that are located to the right of the analyzer display.

15. Pass Fail. During limit testing, the result will be annunciated as PASS if the limits are not exceeded, and FAIL if any points exceed the limits.

2-8

Rear Panel Features and Connectors

Figure 2-3 HP 8753ES Option 011 Rear Panel

Front/Rear Panel

Rear Panel Features and Connectors

Figure 2-3 illustrates the features and connectors of the rear panel, described below.

Requirements for input signals to the rear panel connectors are provided in the speciﬁcations and characteristics chapter.

1. HP-IB connector. This allows you to connect the analyzer to an external controller, compatible peripherals, and other instruments for an automated system. Refer to Chapter 6 , “Options and Accessories” for HP-IB information, limitations, and conﬁgurations.

2. PARALLEL interface. This connector allows the analyzer to output to a peripheral with a parallel input. Also included, is a general purpose input/output (GPIO) bus that can control eight output bits and read ﬁve input bits through test sequencing. Refer to Chapter 6 , “Options and

Accessories” for information on conﬁguring a peripheral. Also refer to The

GPIO Mode” in “Operating Concepts” of the user’s guide.

3. RS-232 interface. This connector allows the analyzer to output to a peripheral with an RS-232 (serial) input.

4. KEYBOARD input (mini-DIN). This connector allows you to connect an external keyboard. This provides a more convenient means to enter a title for storage ﬁles, as well as substitute for the analyzer's front panel keyboard.

5. Power cord receptacle, with fuse. For information on replacing the fuse, refer to the installation and quick start guide.

2-9

Front/Rear Panel

MEASURE RESTART

Rear Panel Features and Connectors

6. Line voltage selector switch. For more information, refer to the installation and quick start guide.

7. Fan. This fan provides forced-air cooling for the analyzer.

8. 10 MHZ PRECISION REFERENCE OUTPUT. (Option 1D5)

9. 10 MHZ REFERENCE ADJUST. (Option 1D5)

10. EXTERNAL REFERENCE INPUT connector. This allows for a

frequency reference signal input that can phase lock the analyzer to an external frequency standard for increased frequency accuracy.

The analyzer automatically enables the external frequency reference feature when a signal is connected to this input. When the signal is removed, the analyzer automatically switches back to its internal frequency reference.

11. AUXILIARY INPUT connector. This allows for a dc or ac voltage input from an external signal source, such as a detector or function generator, which you can then measure, using the S-parameter menu. (You can also use this connector as an analog output in service routines, as described in the service guide.)

12. EXTERNAL AM connector. This allows for an external analog signal input that is applied to the ALC circuitry of the analyzer's source. This input analog signal amplitude modulates the RF output signal.

13. EXTERNAL TRIGGER connector. This allows connection of an external negative-going TTL-compatible signal that will trigger a measurement sweep. The trigger can be set to external through softkey functions.

14. TEST SEQUENCE. This outputs a TTL signal that can be programmed in a test sequence to be high or low, or pulse (10 µseconds) high or low at the end of a sweep for robotic part handler interface.

15. LIMIT TEST. This outputs a TTL signal of the limit test results as follows:

• Pass: TTL high

• Fail: TTL low

16. MEASURE RESTART. This allows the connection of an optional foot switch. Using the foot switch will duplicate the key sequence

Meas

17. TEST SET INTERCONNECT. This allows you to connect the analyzer to an HP 85046A/B or 85047A S-parameter test set using the interconnect cable supplied with the test set. The S-parameter test set is then fully controlled by the analyzer.

18. BIAS INPUTS AND FUSES. These connectors bias devices connected to

2-10

port 1 and port 2. The fuses (1 A, 125 V) protect the port 1 and port 2 bias lines.

Front/Rear Panel

Rear Panel Features and Connectors

19. Serial number plate. The serial number of the instrument is located on this plate.

19. EXTERNAL MONITOR: VGA. VGA output connector provides analog red, green, and blue video signals which can drive a VGA monitor.

2-11

Front/Rear Panel

Rear Panel Features and Connectors

2-12

3 Menu Maps

3-1

Menu Maps

This chapter contains menus maps for the hardkeys listed below. The ﬁgure number of these menu maps is listed next to the name of the hardkey. Fold Outs are located at the end of this chapter.

Table 3-1 Menu Map Locations

Menu Map Figure Number Menu Map Figure Number

Avg

Cal

Copy

Display

Format

Local

Marker, Marker Fctn, and Marker Search

Figure 3-1

Fold Out

Figure 3-2 Figure 3-3 Figure 3-4 Figure 3-5

Figure 3-6

Figure 3-1 Menu Map for

Avg

Meas

Power & Sweep Setup

Preset

Save/Recall

Scale Ref

Seq

System

Figure 3-7 Figure 3-8

Figure 3-9 Figure 3-10 Figure 3-11

Fold Out Fold Out

3-2

Figure 3-2 Menu Map for Copy

Menu Maps

3-3

Menu Maps

Figure 3-3 Menu Map for Display

3-4

Figure 3-4 Menu Map for Format

Menu Maps

3-5

Menu Maps

Figure 3-5 Menu Map for Local

3-6

Figure 3-6 Menu Map for Marker, Marker Fctn, and Marker Search

Menu Maps

3-7

Menu Maps

Figure 3-7 Menu Map for Meas

3-8

Figure 3-8 Menu Map for Power and Sweep Setup

Menu Maps

3-9

Menu Maps

Figure 3-9 Menu Map for Preset

3-10

Figure 3-10 Menu Map for Save/Recall

Menu Maps

3-11

Menu Maps

Figure 3-11 Menu Map for Scale Ref

3-12

Cal

Cal Kit

SELECT

CAL KIT

SAVE

USER KIT

MODIFY

[ ]

RETURN

Correction

CORRECTION

on OFF

INTERPOL

ON off

CALIBRATE

RESUME CAL

SEQUENCE

CAL KIT

[ ]

PWRMTR CAL

[OFF]

Select Cal Kit

7mm

HP 85031

3.5mmC

HP 85033C

3.5mmD

HP 85033D

N 50

HP 85032

N 75

HP 85036

USER KIT

RETURN

Power Meter

Cal. Main Menu

PWRMTR CAL

EACH SWEEP

ONE SWEEP

TAKE CAL

SWEEP

NUMBER of

READINGS

PWR LOSS

on OFF

LOSS/SENSR

RETURN

Select Cal Kit

More Menu

2.4mm

HP 85056

2.92 *

HP 85056K

2.92mm

other kits

TRL 3.5mm

HP 85052C

7-16

HP 85038

RETURN

OFF

LISTS

Pwr. Loss/Sens.

Lists Menu

USE SENSOR

CAL FACTOR

SENSOR A

CAL FACTOR

SENSOR B

Calibrate

More Menu

PORT

EXTENSIONS

VELOCITY

FACTOR

SET Z

ADAPTER

REMOVAL

TESTSET SW

CONTINUOUS

ALTERNATE

A and B

CHOP

A and B

RETURN

Segment

Modify Menu

A / B

POWER

LOSS

RETURN

Calibration Factor Softkey Path

Power Loss Softkey Path

Adapter

Removal Menu

HELP ADAPT

REMOVAL

RECALL CAL

STETS

ADAPTER

DELAY

ADAPTER:

COAX

WAVEGUIDE

REMOVE

ADAPTER

RETURN

SEGMENT

EDIT

DELETE

ADD

CLEAR

LIST

DONE

Recall Cal Sets

RECALL

CAL PORT 1

RECALL

CAL PORT 2

RETURN

Seg. Edit (Cal

Factor) Menu

FREQUENCY

CAL

FACTOR

DONE

Reference

Plane Menu

EXTENSIONS

on OFF

EXTENSION

INPUT A

EXTENSION

INPUT B

EXTENSION

PORT 1

EXTENSION

PORT 2

RETURN

Seg. Edit (Pwr.

Loss) Menu

FREQUENCY

LOSS

DONE

Modify Cal Kit

STANDARD

SPECIFY

TRL/LRM

KIT DONE

(MODIFIED)

DEFINE

CLASS

LABEL

CLASS

LABEL

KIT

OPTION

Clear List

CLEAR LIST

YES

Specify Class

S11A

S11B

S11C

S22A

S22B

S22C

SPECIFY

CLASS DONE

Specify Class

More Menu

FWD TRANS

REV TRANS

FWD MATCH

REV MATCH

RESPONSE

& ISOL'N

SPECIFY

CLASS DONE

Define Standard

STD TYPE:

OPEN

SHORT

LOAD

DELAY /

THRU

ARBITRARY

IMPEDANCE

MODIFY STD

DEFINITION

RETURN

Specify Class

More Menu

TRL THRU

OR MATCH

CLASS DONE

SPECIFY:

TRL

REFLECT

TRL LINE

SPECIFY

Def. Arbitrary Imped. Menu

TERMINAL

IMPEDANCE

FIXED

SLIDING

SPECIFY

OFFSET

LABEL

STD

STD DONE (DEFINED)

Calibrate

ENHANCED RESPONSE

RESPONSE

TRL /LRM

RECEIVER

& ISOL'N

S11

1-PORT

S22

1-PORT

FULL

2-PORT

CAL

Define Delay/

Thru Menu

SPECIFY

OFFSET

LABEL

STD

STD DONE (DEFINED)

Enhanced

Response Menu

ENH. RESP.

S11/S21

S22/S12

RETURN

Define Load

FIXED

SLIDING

OFFSET

SPECIFY

OFFSET

LABEL

STD

STD DONE (DEFINED)

Enh. Resp. Cal. Menu

REFLECT'N

TRANS-

MISSION

ISOLATION

DONE

***

ENH RESP

Define Short

SPECIFY

OFFSET

LABEL

STD

STD DONE (DEFINED)

Enh. Resp.

Refl. Menu

STANDARDS

***

OPENS

SHORTS

LOAD

DONE

Define Open

SPECIFY

OFFSET

LABEL

STD

STD DONE (DEFINED)

Enh. Resp.

Trans. Menu

STANDARDS

DO BOTH

THRUS

***

TRANS

***

MATCH

***

THRU

DONE

Specify Offset

OFFSET

DELAY

OFFSET

LOSS

OFFSET

MINIMUM

FREQUENCY

MAXIMUM

FREQUENCY

COAX

WAVEGUIDE

STD OFFSET

DONE

Enh. Resp.

Isolation Menu

ISOLATION

***

ISOLATION

ISOL'N

OMIT

DONE

Label Standard

SELECT LETTER

BACK

SPACE

ERASE

TITLE

DONE

Response

SHORT

OPEN

THRU

Represents "FWD" when calibrating

***

the forward path or "REV" when calibrating the reverse path.

Response &

Isolation Menu

RESPONSE

ISOL 'N STD

DONE RESP

ISOL 'N CAL

ka532e

TRL Option

CAL Z0: LINE Z0

SYSTEM Z0

SET REF:

THRU

REFLECT

RETURN

Label Class

S11A

S11B

S11C

S22A

S22B

S22C

LABEL

CLASS DONE

Class

Label

More Menu

FWD TRANS

REV TRANS

FWD MATCH

REV MATCH

RESPONSE

& ISOL'N

LABEL

CLASS DONE

Label Class More Menu

LABEL:

TRL THRU

TRL

REFLECT

TRL LINE

OR MATCH

LABEL

CLASS DONE

Label Select

SELECT LETTER

SPACE

BACK

SPACE

ERASE

TITLE

DONE

Rcvr Cal

TAKE RCVR

CAL SWEEP

RETURN

TRL*/LRW*

Cal Menu

THRU THRU

S11 REFL

OPEN

S22 REFL

OPEN

ISOLATION

LINE/MATCH

DONE

TRL/LRW

TRL*/LRW*

Isolation Menu

OMIT

ISOLATION

DO BOTH

FWD + REV

FWD ISOL 'N

ISOL 'N STD

REV ISOL 'N ISOL 'N STD

ISOLATION

DONE

Line / Match

DO BOTH

FWD + REV

LN/MATCH1

LOAD

LN/MATCH2

LOAD

DONE

LINE / MATCH

2-Port Trans.

DO BOTH

FWD + REV

FWD TRANS

THRU

FWD MATCH

THRU

REV TRANS

THRU

REV MATCH

THRU

STANDARDS

DONE

2-Port Isolation

OMIT

ISOLATION

DO BOTH

FWD + REV

FWD ISOL 'N

ISOL 'N STD

REV ISOL 'N ISOL 'N STD

ISOLATION

DONE

Full 2-Port

REFLECTION

TRANS-

MISSION

ISOLATION

DONE

2-PORT CAL

2-Port Reflection

FORWARD:

OPEN

SHORT

LOAD

REVERSE:

OPEN

SHORT

LOAD

STANDARDS

DONE

S22 1-Port

REVERSE:

OPEN

SHORT

LOAD

DONE

I-PORT CAL

S11 1 Port

FORWARD:

OPEN

SHORT

LOAD

DONE

I-PORT CAL

Menu Map For Cal (HP8753ES Option 011)

Seq

Sequencing

CONTINUE

SEQUENCE

GOSUB

SEQUENCE

NEW SEQ/

MODIFY SEQ

DONE SEQ

MODIFY

TTL I/O

SPECIAL

FUNCTIONS

Select Seq

SEQUENCE X

SEQ X

PAUSE TO

SELECT

RETURN

New / Modify

Seq Menu

SEQUENCE 1

SEQ 1

SEQUENCE 2

SEQ 2

SEQUENCE 3

SEQ 3

SEQUENCE 4

SEQ 4

SEQUENCE 5

SEQ 5

SEQUENCE 6

SEQ 6

RETURN

TTL I/O

TTL OUT

PARALLEL

OUT ALL

SET BIT

CLEAR BIT

PARALL IN

BIT NUMBER

PARALL IN

IF BIT H

IF BIT L

RETURN

TTL Out

TTL OUT

HIGH

TTL OUT

LOW

END SWEEP HIGH PULSE

END SWEEP

LOW PULSE

TESTSET

I/O FWD

I/O REV

RETURN

Seq Spec

Func Menu

DECISION

MAKING

PERIPHERAL

HPIB ADDR

TITLE TO

PERIPHERAL

WAIT x

PAUSE

MARKER------

RETURN

Seq Dec

Making Menu

IF LIMIT

TEST PASS

IF LIMIT

TEST FAIL

LOOP

COUNTER

INCR LOOP

COUNTER

DECR LOOP

COUNTER

IF LOOP

COUNTER=0

IF LOOP

COUNTER<>0

RETURN

New / Modify

Seq Menu

SEQUENCE 1

SEQ 1

SEQUENCE 2

SEQ 2

SEQUENCE 3

SEQ 3

SEQUENCE 4

SEQ 4

SEQUENCE 5

SEQ 5

SEQUENCE 6

SEQ 6

RETURN

Spec Func More Menu

EMIT

BEEP

TITLE TO

PRNTR/HPIB

TITLE TO

P MTR/HPIB

SHOW

MENUS

ASSERT SRQ

P MTR/HPIB

TO TITLE

TITLE TO

MEMORY

RETURN

Sequencing More Menu

STORE SEQ

LOAD SEQ

FROM DISK

DUPLICATE SEQUENCE

SEQUENCE

Displays only the user-defined sequence (X), where X is the sequence number, when not modifying a sequence. When modifying a sequence all sequence labels are shown.

TO DISK

TITLE

CLEAR

RETURN

Select Seq

SEQUENCE X

SEQX

RETURN

Select Seq

Menu2

SEQUENCE 1

SEQ 1

SEQUENCE 2

SEQ 2

SEQUENCE 3

SEQ 3

SEQUENCE 4

SEQ 4

SEQUENCE 5

SEQ 5

SEQUENCE 6

SEQ 6

RETURN

Seq Load

LOAD SEQ

SEQ 1

LOAD SEQ

SEQ 2

LOAD SEQ

SEQ 3

LOAD SEQ

SEQ 4

LOAD SEQ

SEQ 5

LOAD SEQ

SEQ 6

READ SEQ FILE TITLS

GET SEQ

TITLES

Select Seq

SEQUENCE X

SEQX

RETURN

Select Seq

Menu2

SEQUENCE 1

SEQ 1

SEQUENCE 2

SEQ 2

SEQUENCE 3

SEQ 3

SEQUENCE 4

SEQ 4

SEQUENCE 5

SEQ 5

SEQUENCE 6

SEQ 6

RETURN

File Title

SELECT LETTER

SPACE

BACK

SPACE

ERASE

TITLE

DONE

Seq Store

STORE SEQ

SEQX

PURGE

SEQUENCES

RETURN

Purge Seq

PURGE SEQ

SEQ 1

PURGE SEQ

SEQ 2

PURGE SEQ

SEQ 3

PURGE SEQ

SEQ 4

PURGE SEQ

SEQ 5

PURGE SEQ

SEQ 6

READ SEQ FILE TITLS

GET SEQ

TITLES

Menu Map for Seq

ka521e

Set Clock

TIME STAMP

ON off

ROUND

SECONDS

SET

MINUTES

SET

HOUR

SET DAY

SET

MONTH

SET

YEAR

RETURN

User Settings

PRESET

SETTINGS

K36 MODE

on OFF

K39 MODE

on OFF

* * * * *

* * * * * *

Preset Settings

CAL INTERP

ON off

Limits

LIMIT LINE

on OFF

LIMIT TEST

on OFF

BEEP FAIL

on OFF

EDIT

LIMIT LINE

OFFSETS

RETURN

Edit Limits

SEGMENT

EDIT

DELETE

ADD

CLEAR

LIST

LIMIT TYPE

DONE

Edit Segment

STIMULUS

VALUE

MARKER

STIMULUS

UPPER

LIMIT

LOWER

LIMIT

DELTA

LIMITS

MIDDLE

VALUE

MARKER

MIDDLE

DONE

Only appears on instruments

equipped with Option 010.

Only appears on instruments

* *

equipped with Option 002.

Service menu key descriptions are

* * *

located in the HP 8753D Option 011

Network Analyzer Service Guide.

* * * *

* * * * *

* * * * * *

Loss appears thru the power loss path.

Only appears on instruments equipped with Option K36.

Only appears on instruments equipped with Option K39

Edit List

SEGMENT

EDIT

DELETE

CLEAR

DONE

ADD

LIST

Edit Sensor

FREQUENCY

CAL

FACTOR

DONE

* * * *

System

SET CLOCK

CONFIGURE

LIMIT

TRANSFORM

HARMONIC

MEAS

INSTRUMENT

MODE

SERVICE

* *

* * *

Configure

TESTSET SW

CONTINUOUS

RAW OFFSET

ON off

SPUR AVOID

ON off

USER

SETTINGS

RETURN

Instrument

Mode Menu

NETWORK

ANALYZER

EXT SOURCE

AUTO

EXT SOURCE

MANUAL

TUNED

RECEIVER

FREQ OFFS

RETURN

Offset Limits

STIMULUS

OFFSET

AMPLITUDE

OFFSET

MARKER AMP. OFS.

RETURN

Frequency

Offset Menu

FREQ OFFS

on OFF

DOWN

CONVERTER

RF > LO

RF < LO

VIEW

MEASURE

RETURN

Transform

TRANSFORM

on OFF

SET FREQ

LOW PASS

IMPULSE

LOW PASS

STEP

BANDPASS

WINDOW

SPECIFY

GATE

RETURN

FREQUENCY :

LO CONTROL

LO SOURCE

SWEEP

POWER :

FIXED

SWEEP

on OFF

ADDRESS

VIEW

MEASURE

RETURN

Specify Gate

GATE

on OFF

GATE:

START

STOP

CENTER

SPAN

GATE

SHAPE

RETURN

Harmonic

Mode Menu

HARMONIC

OFF

SECOND

THIRD

RETURN

Window

WINDOW:

MAXIMUM

NORMAL

MINIMUM

USE MEMORY

on OFF

DEMOD:

OFF

AMPLITUDE

PHASE

RETURN

Service

TESTS

TEST

OPTIONS

SELF

DIAGNOSIS

SERVICE

MODES

ANALOG BUS

on OFF

PEEK /

POKE

FIRMWARE

REVISION

RETURN

Gate Shape

GATE SHAPE

MAXIMUM

WIDE

NORMAL

MINIMUM

RETURN

Tests Menu

EXECUTE

TEST

INTERNAL

TESTS

EXTERNAL

TESTS

SYS VER

TESTS

ADJUSTMENT

TESTS

DISPLAY

TESTS

RETURN

Limit Type

SLOPING

LINE

FLAT

LINE

SINGLE

POINT

RETURN

Test Options

CONTINUE

TEST

REPEAT

on OFF

RECORD

on OFF

LIMITS

[ NORM ]

PWR LOSS

on OFF

LOSS / SENSR

LISTS

DUMP GRAPH

on OFF

RETURN

Offset Table

USE SENSOR

CAL FACTOR

Service Modes

FRACN TUNE

SOURCE PLL

A / B

SENSOR A

SENSOR B

POWER

LOSS

RETURN

on OFF

SRC ADJUST

ON off

PLL AUTO

ON off

PLL DIAG

on OFF

PLL PAUSE

[ CONT ]

RETURN

Source

Adjust Menu

SRC TUNE

on OFF

SRC TUNE

FREQ

ALC

ON off

PWR DAC

on OFF

SLOPE

DAC

SRC ADJUST

DACS

HB FLTR SW

on OFF

RETURN

Peek / Poke

PEEK / POKE

ADDRESS

PEEK

POKE

RESET

MEMORY

RETURN

Adjust DACS

SLOPE

OFFSET DAC

SQUARE LAW

LINEAR DAC

DETECTOR

OFFSET DAC

Serve Mode

More Menu

SAMPLE COR

STORE EEPR

LOG

WRITE

EEPROM

RETURN

ON off

IF GAIN

AUTO

IF GAIN

OFF

SPUR TEST

on OFF

SPUR AVOID

ON off

RETURN

ka522e

Menu Map For System (HP8753ES only)

4 Hardkey/Softkey Reference

4-1

Hardkey/Softkey Reference

SERVICE MENU

Key Reference

This chapter contains information on the following topics:

• softkey and front-panel functions in alphabetical order (includes a brief description of each function)

• cross reference of programming commands to key functions

• cross reference of softkeys to front-panel access keys

NOTE The keys are not included in this chapter. Information on

the keys can be found in the service guide.

4-2

Hardkey/Softkey Reference

TRANSMISSION

Where to Look for More Information

Additional information about many of the topics discussed in this chapter is located in the following areas:

• "Making Measurements" in the user’s guide contains step-by-step procedures for making measurements or using particular functions.

• "Printing, Plotting, and Saving Measurement Results" in the user’s guide contains instructions for saving to disk or the analyzer internal memory, and printing and plotting displayed measurements.

• "Optimizing Measurement Results" in the user’s guide describes techniques and functions for achieving the best measurement results.

• “Operating Concepts” chapter of the user’s guide contains explanatory-style information about many applications and analyzer operation.

• The programmer’s guide provides a complete description of all HP-IB mnemonics.

Guide Terms and Conventions

The eight keys along the right side of the analyzer display are called softkeys. Their labels are shown on the display. The softkeys appear in shaded boxes in this chapter (for

example, ). The labeled keys that are on the front panel of the analyzer are called front-panel keys or hardkeys. The front-panel keys appear in unshaded boxes in

this chapter (for example, ).

Start

4-3

Hardkey/Softkey Reference

A/R

Analyzer Functions

This section contains an alphabetical listing of softkey and front-panel functions, and a brief description of each function.

is used to add a decimal point to the number you are entering.

−

is used to add a minus sign to the number you are entering.

is used to step up the current value of the active function. The analyzer deﬁnes the step size for different functions. No units terminator is required. For editing a test sequence, this key can be used to scroll through and execute the displayed sequence one step at a time.

is used to step down the current value of the active function. The analyzer deﬁnes the step size for different functions. No units terminator is required. For editing a test sequence, this key can be used to scroll backwards through the displayed sequence without executing it.

has two independent functions:

• modiﬁes entries and test sequences

• moves marker information off of the graticules The backspace key will delete the last entry, or the last

digit entered from the numeric keypad. The backspace key can also be used in two ways for modifying a test sequence:

4-4

• deleting a single-key command that you may have pressed by mistake, (for example )

• deleting the last digit in a series of entered digits, as long as you haven't yet pressed a terminator, (for

example if you pressed but did not press

, etc.)

G/n

Start

The second function of this key is to move marker information off of the graticules so that the display traces are clearer. If there are two or more markers activated on

a channel on the right side of the display, pressing will turn off the softkey menu and move the marker

information into the softkey display area. Pressing , or any hardkey which brings up a menu, or a softkey, will restore the softkey menu and move the marker

information back onto the graticules.

MODE MENU

MODE OFF

REF = 1

MARKER∆ REF = 1

REF = 2

REF = 3

REF = 4

REF = 5

REF =∆ FIXED MKR

FIXED MKR POSITION

MKR ZERO

1/S

2X: [1&2]/[3&4]

Hardkey/Softkey Reference

Analyzer Functions

∆

goes to the delta marker menu, which is used to read the difference in values between the active marker and a reference marker.

∆

turns off the delta marker mode, so that the values displayed for the active marker are absolute values.

∆

establishes marker 1 as a reference. The active marker stimulus and response values are then shown relative to this delta reference. Once marker 1 has been selected as

the delta reference, the softkey label is

∆

underlined in this menu, and the marker menu is returned to the screen. In the marker menu, the ﬁrst key

is now labeled . The notation "∆REF=1" appears at the top right corner of the graticule.

∆

makes marker 2 the delta reference. Active marker stimulus and response values are then shown relative to this reference.

∆ ∆ ∆

makes marker 3 the delta reference. makes marker 4 the delta reference. makes marker 5 the delta reference.

∆

sets a user-speciﬁed ﬁxed reference marker. The stimulus and response values of the reference can be set arbitrarily, and can be anywhere in the display area. Unlike markers 1 to 5, the ﬁxed marker need not be on the trace. The ﬁxed marker is indicated by a small triangle ∆, and the active marker stimulus and response values are shown relative to this point. The notation "∆REF=∆" is displayed at the top right corner of the graticule.

Pressing this softkey turns on the ﬁxed marker. Its stimulus and response values can then be changed using the ﬁxed marker menu, which is accessed with the

softkey described below.

Alternatively, the ﬁxed marker can be set to the current active marker position, using the softkey in

the marker menu. expresses the data in inverse S-parameter values, for use

in ampliﬁer and oscillator design. sets up a two-graticule display with channel 1 and 2 on the

top graticule and channels 3 and 4 in the bottom graticule.

4-5

Hardkey/Softkey Reference

2X: [1&3]/[2&4]

2.4 mm HP 85056

2.92* HP 85056K

2.92 mm other kits

3.5 mm C HP 85033C

4X: [1] [2]/[3] [4]

4X: [1] [3]/[2] [4]

4 PARAM DISPLAYS

7-16 HP 85038

A/B

A/R

ACTIVE ENTRY

ACTIVE MAGNITUDE

ADAPTER: COAX

ADAPTER: WAVEGUIDE

ADAPTER DELAY

ADAPTER REMOVAL

ADD

SEGMENT

Analyzer Functions

sets up a two-graticule display with channel 1 and 3 in the top graticule and channels 2 and 4 in the bottom graticule.

selects the HP 85056A/D cal kit. selects the HP 85056K cal kit. selects the 2.92 mm cal kit model. selects the HP 85033C cal kit. sets up a four-graticule display with channel 2 in the

upper right quadrant and channel 3 in the lower left quadrant.

sets up a four-graticule display with channel 3 in the upper right quadrant and channel 2 in the lower left quadrant.

provides single-keystroke options to quickly set up multiple-channel displays, and information on multiple-channel displays.

selects the HP 85038A/F/M cal kit. measures the absolute power amplitude at input A. calculates and displays the complex ratio of input A to

input B. calculates and displays the complex ratio of the signal at

input A to the reference signal at input R. puts the name of the active entry in the display title. puts the active marker magnitude in the display title. selects coaxial as the type of adapter used in adapter

removal calibration. selects waveguide as the type of adapter used in adapter

removal calibration. is used to enter the value of electrical delay of the adapter

used in adapter removal calibration. provides access to the adapter removal menu. displays the edit segment menu and adds a new segment

to the end of the list. The new segment is initially a duplicate of the segment indicated by the pointer > and

selected with the softkey.

4-6

Hardkey/Softkey Reference

ADDRESS: 8753

ADDRESS: CONTROLLER

ADDRESS: DISK

ADDRESS: P MTR/HPIB

ADJUST DISPLAY

ADJUSTMENT TESTS

ALL SEGS SWEEP

ALTERNATE A and B

AMPLITUDE OFFSET

ANALOG IN Aux Input

ARBITRARY IMPEDANCE

ASSERT SRQ

AUTO FEED ON off

Analyzer Functions

sets the HP-IB address of the network analyzer, using the entry controls. There is no physical address switch to set in the analyzer. The default HP-IB address is 16.

sets the HP-IB address the analyzer will use to communicate with the external controller.

sets the HP-IB address the analyzer will use to communicate with an external HP-IB disk drive.

sets the HP-IB address the analyzer will use to communicate with the power meter used in service routines.

presents a menu for adjusting display intensity, colors, and accessing save and recall functions for modiﬁed LCD color sets.

leads to the beginning of the adjustment tests. These tests generate correction constants that are used by the analyzer.

retrieves the full frequency list sweep. measures only one input, A or B, per frequency sweep, in

order to reduce spurious signals. Thus, this mode optimizes the dynamic range for all four S-parameter measurements.

adds or subtracts an offset in amplitude value. This allows limits already deﬁned to be used for testing at a different response level. For example, if attenuation is added to or removed from a test setup, the limits can be offset an equal amount. Use the entry block controls to specify the offset.

displays a dc or low frequency ac auxiliary voltage on the vertical axis, using the real format. An external signal source such as a detector or function generator can be connected to the rear panel AUXILIARY INPUT connector.

deﬁnes the standard type to be a load, but with an arbitrary impedance (different from system Z0).

sets the sequence bit in the Event Status Register, which can be used to generate an SRQ (service request) to the system controller.

turns the plotter auto feed function on or off when in the deﬁne plot menu. It turns the printer auto feed on or off when in the deﬁne print menu.

4-7

Hardkey/Softkey Reference

AUTO SCALE

AUX CHAN on OFF

AUX OUT on OFF

AVERAGING FACTOR

AVERAGING on OFF

AVERAGING RESTART

Analyzer Functions

brings the trace data in view on the display with one keystroke. Stimulus values are not affected, only scale and reference values. The analyzer determines the smallest possible scale factor that will put all displayed data onto 80% of the vertical graticule. The reference value is chosen to put the trace in center screen, then rounded to an integer multiple of the scale factor.

enables and disables auxiliary channels 3 and 4. allows you to monitor the analog bus nodes (except nodes

1, 2, 3, 4, 9, 10, and 12) with external equipment. To do this, connect the equipment to the AUX INPUT BNC connector on the rear panel.

makes averaging factor the active function. Any value up to 999 can be used. The algorithm used for averaging is:

An() Sn() Sn 1–()... Sn F–1+()+++[]F⁄=

where A(n) = current average S(n) = current measurement F = average factor

turns the averaging function on or off for the active channel. "Avg" is displayed in the status notations area at the left of the display, together with the sweep count for the averaging factor, when averaging is on. The sweep count for averaging is reset to 1 whenever an instrument state change affecting the measured data is made.

At the start of the averaging or following

, averaging starts at 1 and averages each new sweep into the trace until it reaches the speciﬁed averaging factor. The sweep count is displayed in the status notations area below "Avg" and updated every sweep as it increments. When the speciﬁed averaging factor is reached, the trace data continues to be updated, weighted by that averaging factor.

averaging starts at 1 and averages each new sweep into the trace until it reaches the speciﬁed averaging factor. The sweep count is displayed in the status notations area below "Avg" and updated every sweep as it increments.

Avg

4-8

is used to access three different noise reduction techniques: sweep-to-sweep averaging, display smoothing, and variable IF bandwidth. Any or all of these can be used simultaneously. Averaging and smoothing can be set independently for each channel, and the IF bandwidth can

Hardkey/Softkey Reference

B/R

BACK SPACE

BACKGROUND INTENSITY

BANDPASS

BEEP DONE ON off

BEEP FAIL on OFF

BEEP WARN on OFF

BLANK DISPLAY

BRIGHTNESS

Analyzer Functions

be set independently if the stimulus is uncoupled. measures the absolute power amplitude at input B. calculates and displays the complex ratio of input B to

input R. deletes the last character entered. sets the background intensity of the LCD as a percent of

white. The factory-set default value is stored in non-volatile memory.

(Option 010 only) sets the time-domain bandpass mode. toggles an annunciator which sounds to indicate

completion of certain operations such as calibration or instrument state save.

turns the limit fail beeper on or off. When limit testing is on and the fail beeper is on, a beep is sounded each time a limit test is performed and a failure detected. The limit fail beeper is independent of the warning beeper and the operation complete beeper.

toggles the warning annunciator. When the annunciator is on it sounds a warning when a cautionary message is displayed.

switches off the analyzer's display. This feature may be helpful in prolonging the life of the LCD in applications where the analyzer is left unattended (such as in an automated test system). Pressing any front panel key will restore the default display operation.

adjusts the brightness of the color being modiﬁed. Refer to the section on adjusting the display color in the “Using Measurement Functions” chapter of the user’s guide for an explanation of using this softkey for color modiﬁcation of display attributes.

is used to enter the C0 term in the deﬁnition of an OPEN standard in a calibration kit, which is the constant term of

the cubic polynomial and is scaled by 10

−15

is used to enter the C1 term, expressed in F/Hz

−27

(Farads/Hz) and scaled by 10 is used to enter the C2 term, expressed in F/Hz

−36

scaled by 10

is used to enter the C3 term, expressed in F/Hz

−45

scaled by 10

and

4-9

Hardkey/Softkey Reference

CAL

CAL FACTOR

CAL FACTOR SENSOR A

CAL INTERP ON off

CAL FACTOR SENSOR B

CAL KIT [ ]

2.4 mm HP 85056

2.92* HP 85056K

2.92 mm other kits

3.5 mm C HP 85033C

7-16 HP 85038

N 75ΩHP 85036

TRL 3.5 mm HP 85052C

CAL ZO: LINE ZO

Analyzer Functions

Cal

key leads to a series of menus to perform measurement calibrations for vector error correction (accuracy enhancement), and for specifying the calibration

standards used. The key also leads to softkeys which activate interpolated error correction and power meter calibration.

accepts a power sensor calibration factor % for the segment.

brings up the segment modify menu and segment edit (calibration factor menu) which allows you to enter a power sensor's calibration factors. The calibration factor data entered in this menu will be stored for power sensor A.

sets the preset state of interpolated error-correction on or off.

indicates the currently selected cal kit and leads to the select cal kit menu, which is used to select one of the default calibration kits available for different connector types. This, in turn, leads to additional menus used to deﬁne calibration standards other than those in the default kits (refer to “Modifying Calibration Kits” in the “Operating Concepts” chapter of the user’s guide). When a calibration kit has been speciﬁed, its connector type is displayed in brackets in the softkey label. The cal kits available are listed below, refer to the softkey descriptions for these softkeys for more information.

— — — — — — —

4-10

this default selection establishes the TRL/LRM LINE/MATCH standard as the characteristic impedance.

Hardkey/Softkey Reference

CAL ZO: SYSTEM ZO

CALIBRATE MENU

CENTER

CH1 DATA [ ]

CH1 DATA LIMIT LN

CH1 MEM

CH1 MEM [ ]

CH2 DATA [ ]

CH2 DATA LIMIT LN

CH2 MEM

CH2 MEM [ ]

CH3 DATA [ ]

CH3 DATA LIMIT LN

CH3 MEM

CH3 MEM [ ]

Analyzer Functions

allows you to modify the characteristic impedance of the system for TRL/LRM calibration.

leads to the calibration menu, which provides several accuracy enhancement procedures ranging from a simple frequency response calibration to a full two-port calibration. At the completion of a calibration procedure, this menu is returned to the screen, correction is automatically turned on, and the notation Cor or C2 is displayed at the left of the screen.

Center Span

is used, along with the key, to deﬁne the frequency range of the stimulus. When the key is pressed,

its function becomes the active function. The value is displayed in the active entry area, and can be changed with the knob, step keys, or numeric keypad.

sets the center frequency of a subsweep in a list frequency sweep.

brings up the printer color selection menu. The channel 1 data trace default color is magenta for color prints.

selects channel 1 data trace and limit line for display color modiﬁcation.

selects channel 1 memory trace for display color modiﬁcation.

brings up the printer color selection menu. The channel 1 memory trace default color is green for color prints.

brings up the printer color selection menu. The channel 2 data trace default color is blue for color prints.

selects channel 2 data trace and limit line for display color modiﬁcation.

Center

selects channel 2 memory trace for display color modiﬁcation.

brings up the printer color selection menu. The channel 2 memory trace default color is red for color prints.

brings up the printer color selection menu. The channel 3 data trace default color is magenta for color prints.

selects channel 3 data trace and limit line for display color modiﬁcation.

selects channel 3 memory trace for display color. brings up the printer color selection menu. The channel 2

data trace default color is green for color prints.

4-11

Hardkey/Softkey Reference

CH4 DATA [ ]

CH4 DATA LIMIT LN

CH4 MEM

CH4 MEM [ ]

CHAN POWER [COUPLED]

CHAN POWER [UNCOUPLED

CHANNEL POSITION

CHOP A and B

Analyzer Functions

brings up the printer color selection menu. The channel 4 data trace default color is blue for color prints.

selects channel 4 data trace and limit line for display color modiﬁcation.

selects channel 4 memory trace for display color modiﬁcation.

brings up the printer color selection menu. The channel 2 memory trace default color is red for color prints.

Chan 1

Chan 2

Chan 3

Chan 4

allows you to select channel 1 as the active channel. The active channel is indicated by an amber LED adjacent to the corresponding channel key. All of the channel-speciﬁc functions you select, such as format or

scale, apply to the active channel. By default,

Chan 1

measures S11 in log mag format. allows you to select channel 2 as the active channel.

The active channel is indicated by an amber LED adjacent to the corresponding channel key. All of the channel-speciﬁc functions you select, such as format or

scale, apply to the active channel. By default,

Chan 2

measures S21 in log mag format. allows you to select channel 3 as the active channel.

The active channel is indicated by an amber LED adjacent to the corresponding channel key. All of the channel-speciﬁc functions you select, such as format or

scale, apply to the active channel. is the auxiliary channel of . By default, measures S12

Chan 1 Chan 3

Chan 3

in log mag format. allows you to select channel 4 as the active channel.

The active channel is indicated by an amber LED adjacent to the corresponding channel key. All of the channel-speciﬁc functions you select, such as format or

scale, apply to the active channel. is the auxiliary channel of . By default, measures S22

Chan 2 Chan 4

Chan 4

in log mag format.

4-12

is used to apply the same power levels to Chan 1/3 & 2/4.

is used to apply different power levels to Chan 1/3 & 2/4.

conﬁgures multiple-channel displays so that the auxiliary channels are adjacent to or beneath the primary channels.

measures A and B inputs simultaneously for faster measurements.

Hardkey/Softkey Reference

CLEAR BIT

CLEAR LIST

CLEAR SEQUENCE

COAX

COAXIAL DELAY

COLOR

CONFIGURE EXT DISK

CONFIGURE MENU

CONTINUE SEQUENCE

CONTINUOUS

CONVERSION [ ]

CONVERSION [OFF]

Analyzer Functions

when the parallel port is conﬁgured for GPIO, 8 output bits can be controlled with this key. When this key is pressed, "TTL OUT BIT NUMBER" becomes the active function. This active function must be entered through the

keypad number keys, followed by the key. The bit is cleared when the key is pressed. Entering numbers

larger than 7 will result in bit 7 being cleared, and entering numbers lower than 0 will result in bit 0 being cleared.

deletes all segments in the list. clears a sequence from memory. The titles of cleared

sequences will remain in load, store, and purge menus. This is done as a convenience for those who often reuse the same titles.

deﬁnes the standard (and the offset) as coaxial. This causes the analyzer to assume linear phase response in any offsets.

applies a linear phase compensation to the trace for use with electrical delay. That is, the effect is the same as if a corresponding length of perfect vacuum dielectric coaxial transmission line was added to the reference signal path.

adjusts the degree of whiteness of the color being modiﬁed. Refer to the section on adjusting the display color in the “Using Measurement Functions” chapter of the user’s guide for an explanation of using this softkey for color modiﬁcation of display attributes.

provides access to the conﬁgure ext disk menu. This menu contains softkeys used to the disk address, unit number, and volume number.

provides access to the conﬁgure menu. This menu contains softkeys used to control raw offsets, spur avoidance, the test set transfer switch, and user preset settings.

resumes a paused sequence. located under the key, is the standard

Sweep Setup

sweep mode of the analyzer, in which the sweep is triggered automatically and continuously and the trace is updated with each sweep.

brings up the conversion menu which converts the measured data to impedance (Z) or admittance (Y). When a conversion parameter has been deﬁned, it is shown in brackets under the softkey label. If no conversion has been

deﬁned, the softkey label reads .

4-13

Hardkey/Softkey Reference

CORRECTION on OFF

COUNTER: ANALOG BUS

COUNTER: DIV FRAC N

COUNTER: FRAC N

COUNTER: OFF

COUPLED CH ON off

COUPLED CH ON

CW FREQ

CW TIME

CW FREQ

D2/D1 to D2 on OFF

DATA and MEMORY

DATA ARRAY on OFF

DATA/MEM

Analyzer Functions

Copy

provides access to the menus used for controlling external plotters and printers and deﬁning the plot parameters.

turns error correction on or off. The analyzer uses the most recent calibration data for the displayed parameter. If the stimulus state has been changed since calibration, the original state is recalled, and the message "SOURCE PARAMETERS CHANGED" is displayed.

switches the counter to count the analog bus. switches the counter to count the A14 fractional-N VCO

frequency after it has been divided down to 100 kHz for phase-locking the VCO.

switches the counter to count the A14 fractional-N VCO frequency at the node shown on the overall block diagram.

switches the internal counter off and removes the counter display from the LCD.

toggles the channel coupling of stimulus values. With

(the preset condition), both channels have the same stimulus values (the inactive channel takes on the stimulus values of the active channel).

is used to set the frequency for power sweep and CW time sweep modes. If the instrument is not in either of these two modes, it is automatically switched into CW time mode.

turns on a sweep mode similar to an oscilloscope. The analyzer is set to a single frequency, and the data is displayed versus time. The frequency of the CW time

sweep is set with in the stimulus menu. this math function ratios channels 1 and 2, and puts the

results in the channel 2 data array. Both channels must be on and have the same number of points. Refer to the "Making Measurements" chapter in the user’s guide for information on how to use this function to make gain compression measurements.

displays both the current data and memory traces. speciﬁes whether or not to store the error-corrected data

on disk with the instrument state. divides the data by the memory, normalizing the data to

the memory, and displays the result. This is useful for ratio comparison of two traces, for instance in measurements of gain or attenuation.

4-14

Hardkey/Softkey Reference

DATA - MEM

DATA→ MEMORY

DATA ONLY on OFF

DECISION MAKING

DECR LOOP COUNTER

DEFAULT COLORS

DEFAULT PLOT SETUP

DEFAULT PRNT SETUP

DEFINE DISK-SAVE

DEFINE PLOT

DEFINE PRINT

Analyzer Functions

subtracts the memory from the data. The vector subtraction is performed on the complex data. This is appropriate for storing a measured vector error, for example directivity, and later subtracting it from the device measurement.

stores the current active measurement data in the memory of the active channel. It then becomes the memory trace, for use in subsequent math manipulations or display. If a parameter has just been changed and the * status notation is displayed at the left of the display, the data is not stored in memory until a clean sweep has been executed. The gating and smoothing status of the trace are stored with the measurement data.

stores only the measurement data of the device under test to a disk ﬁle. The instrument state and calibration are not stored. This is faster than storing with the instrument state, and uses less disk space. It is intended for use in archiving data that will later be used with an external controller, and data cannot be read back by the analyzer.

presents the sequencing decision making menu under the

menu.

Seq

decrements the value of the loop counter by 1. returns all the display color settings back to the

factory-set default values that are stored in non-volatile memory.

resets the plotting parameters to their default values. resets the printing parameters to their default values. leads to the deﬁne save menu. Use this menu to specify

the data to be stored on disk in addition to the instrument state.

leads to a sequence of three menus. The ﬁrst deﬁnes which elements are to be plotted and the auto feed state. The second deﬁnes which pen number is to be used with each of the elements (these are channel dependent). The third deﬁnes the line types (these are channel dependent), plot scale, and plot speed.

leads to the deﬁne print menu. This menu deﬁnes the printer mode (monochrome or color) and the auto-feed state.

4-15

Hardkey/Softkey Reference

DEFINE STANDARD

DELAY

DELAY/THRU

DELETE

DELETE ALL FILES

DELETE FILE

DELTA LIMITS

MIDDLE VALUE

MARKER→ MIDDLE

DEMOD: AMPLITUDE

DEMOD: OFF

DEMOD: PHASE

DIRECTORY SIZE

DISK UNIT NUMBER

Analyzer Functions

makes the standard number the active function, and brings up the deﬁne standard menus. The standard number (1 to 8) is an arbitrary reference number used to reference standards while specifying a class.

selects the group delay format, with marker values given in seconds.

deﬁnes the standard type as a transmission line of speciﬁed length, for calibrating transmission measurements.

deletes the segment indicated by the pointer. deletes all ﬁles. deletes a selected ﬁle. sets the limits an equal amount above and below a

speciﬁed middle value, instead of setting upper and lower limits separately. This is used in conjunction with

or , to set limits for testing a device that is speciﬁed at a particular value plus or minus an equal tolerance.

For example, a device may be speciﬁed at 0 dB ±3 dB. Enter the delta limits as 3 dB and the middle value as 0dB.

(Option 010 only) amplitude demodulation for CW time transform measurements.

(Option 010 only) turns time domain demodulation off. (Option 010 only) phase demodulation for CW TIME

transform measurements. lets you specify the number of directory ﬁles to be

initialized on a disk. This is particularly useful with a hard disk, where you may want a directory larger than the default 256 ﬁles, or with a ﬂoppy disk you may want to reduce the directory to allow extra space for data ﬁles. The number of directory ﬁles must be a multiple of 8. The minimum number is 8, and there is no practical maximum limit. Set the directory size before initializing a disk.

speciﬁes the number of the disk unit in the disk drive that is to be accessed in an external disk store or load routine. This is used in conjunction with the HP-IB address of the disk drive, and the volume number, to gain access to a speciﬁc area on a disk. The access hierarchy is HP-IB address, disk unit number, disk volume number.

4-16

Hardkey/Softkey Reference

DISP MKRS ON off

MKR STATS

DISPLAY: DATA

DISPLAY TESTS

DO BOTH FWD + REV

DO BOTH FWD THRUS

DO BOTH REV THRUS

DO SEQUENCE

DONE 1-PORT CAL

DONE 2-PORT CAL

DONE FWD ENH RESP.

Analyzer Functions

displays response and stimulus values for all markers that are turned on. Available only if no marker functions are

on, for example .

Display

provides access to a series of menus for instrument and active channel display functions. The ﬁrst menu deﬁnes the displayed active channel trace in terms of the mathematical relationship between data and trace memory. Other functions include auxiliary channel enabling, dual channel display (overlaid or split), display intensity, color selection, active channel display title, and frequency blanking.

displays the current measurement data for the active channel.

leads to a series of service tests for the display. activates both forward and reverse measurements of

selected calibration standards. activates both forward measurements (reﬂection and

transmission) of the thru standard from the selective enhanced response calibration menus.

activates both reverse measurements of the thru standard S22/S12 from the S11/S21 selective enhanced response calibration menus.

has two functions:

• It shows the current sequences in memory. To run a sequence, press the softkey next to the desired sequence title.

• When entered into a sequence, this command performs a one-way jump to the sequence residing in the speciﬁed sequence position (SEQUENCE 1 through 6).

jumps to a softkey position, not to a speciﬁc sequence title. Whatever sequence is in the selected softkey position will run when the

command is executed. This command prompts the operator to select a destination sequence position.

ﬁnishes one-port calibration (after all standards are measured) and turns error correction on.

ﬁnishes two-port calibration (after all standards are measured) and turns error correction on .

ﬁnishes the transmission portion of the enhanced response calibration.

4-17

Hardkey/Softkey Reference

DONE LOADS

DONE OPENS

DONE SHORTS

DONE RESP ISOL'N CAL

DONE REV ENH RESP.

DONE SEQ MODIFY

DONE TRL/LRM

DOWN CONVERTER

DUAL CH on OFF

SPLIT DISP 1X 2X 4X

DUAL|QUAD SETUP

SPLIT DISP 1X

DUAL|QUAD SETUP

DUPLICATE SEQUENCE

EACH SWEEP

NUMBER OF READINGS

Analyzer Functions

ﬁnishes all the load standards when the cal kit deﬁnes more than one load standard.

ﬁnishes all the open standards when the cal kit deﬁnes more than one open standard.

ﬁnishes all the short standards when the cal kit deﬁnes more than one short standard.

ﬁnishes response and isolation calibration (after all standards are measured) and turns error correction on.

ﬁnishes the transmission portion of the enhanced response calibration.

terminates the sequencing edit mode. ﬁnishes TRL/LRM two-port calibration (after all

standards are measured) and turns error correction on. sets the analyzer's source higher than the analyzer's

receiver for making measurements in frequency offset mode.

toggles between the display of both measurement channels or the active channel only. This is used in conjunction with

in the display menu to display multiple

channels. With , the two traces are overlaid on a single graticule.

activates a sub-menu of , which allows you to

Display

enable the auxiliary channels and conﬁgure multiple-channel displays.

duplicates a sequence currently in memory into a different softkey position. Duplicating a sequence is straightforward. Follow the prompts on the analyzer screen. This command does not affect the original sequence.

Power meter calibration occurs on each sweep. Each measurement point is measured by the power meter, which provides the analyzer with the actual power reading. The analyzer corrects the power level at that point. The number of measurement/correction iterations performed on each point is determined by the

softkey. This measurement mode sweeps slowly, especially when the measured power is low. Low power levels require more time for the power meter to settle. The power meter correction table in memory is updated after each sweep. This table can be read or changed via HP-IB.

4-18

Hardkey/Softkey Reference

EDIT LIMIT LINE

EDIT LIST

LIST FREQ

ELECTRICAL DELAY

EMIT BEEP

END OF LABEL

END SWEEP HIGH PULSE

END SWEEP LOW PULSE

ENHANCED RESPONSE

ENTRY Off

ERASE TITLE

EXECUTE TEST

EXT SOURCE AUTO

EXT SOURCE MANUAL

EXT TRIG ON POINT

Analyzer Functions

displays a table of limit segments on the LCD, superimposed on the trace. The edit limits menu is presented so that limits can be deﬁned or changed. It is not necessary for limit lines or limit testing to be on while limits are deﬁned.

presents the edit list menu. This is used in conjunction with the edit subsweep menu to deﬁne or modify the frequency sweep list. The list frequency sweep mode is

selected with the softkey described below. adjusts the electrical delay to balance the phase of the

DUT. It simulates a variable length lossless transmission line, which can be added to or removed from a receiver input to compensate for interconnecting cables, etc. This function is similar to the mechanical or analog "line stretchers" of other network analyzers. Delay is annotated in units of time with secondary labeling in distance for the current velocity factor.

causes the instrument to beep once. terminates the HP-GL "LB" command. sets the TTL output on TEST SEQ BNC or the test set

interconnect to normally high with a 10 microseconds pulse high at the end of each sweep.

sets the TTL output on TEST SEQ BNC or the test set interconnect to normally low with a 10 µs pulse low at the end of each sweep.

provides access to the series of menus used to perform an enhanced response calibration.

turns the active entry off. This also removes error and warning messages.

deletes the entire title. runs the selected service test. selects the auto external source mode. selects the manual external source mode. is similar to the trigger on sweep, but triggers each data

point in a sweep.

4-19

Hardkey/Softkey Reference

EXT TRIG ON SWEEP

EXTENSION INPUT A

EXTENSION INPUT B

EXTENSION PORT 1

EXTENSION PORT 2

EXTENSIONS on OFF

EXTERNAL DISK

EXTERNAL TESTS

FILETITLE FILE0

FILE NAME

FILE UTILITIES

FIXED

FIXED MKR AUX VALUE

Analyzer Functions

is used when the sweep is triggered on an externally generated signal connected to the rear panel EXT TRIGGER input. The sweep is started with a high to low transition of a TTL signal. If this key is pressed when no external trigger signal is connected, the notation “Ext” is displayed at the left side of the display to indicate that the analyzer is waiting for a trigger. When a trigger signal is connected, the “Ext” notation is replaced by the sweep speed indicator either in the status notation area or on the trace. External trigger mode is allowed in every sweep mode.

Use this feature to add electrical delay (in seconds) to extend the reference plane at input A to the end of the cable. This is used for any input measurements including S-parameters.

adds electrical delay to the input B reference plane for any B input measurements including S-parameters.

extends the reference plane for measurements of S

and S extends the reference plane for measurements of S

and S

, S21,

, S12,

toggles the reference plane extension mode. When this function is on, all extensions deﬁned above are enabled; when off, none of the extensions are enabled.

selects an (optional) external disk drive for SAVE/RECALL.

leads to a series of service tests. appears during sequence modiﬁcation, when external disk

is selected. FILE0 is the default name. A new name can be entered when you save the state to disk.

supplies a name for the saved state and or data ﬁle. Brings up the TITLE FILE MENU.

provides access to the ﬁle utilities menu. deﬁnes the load in a calibration kit as a ﬁxed (not sliding)

load.

4-20

is used only with a polar or Smith format. It changes the auxiliary response value of the ﬁxed marker. This is the second part of a complex data pair, and applies to a magnitude/phase marker, a real/imaginary marker, an R+jX marker, or a G+jB marker. Fixed marker auxiliary response values are always uncoupled in the two channels.

Hardkey/Softkey Reference

MKR ZERO

FIXED MKR POSITION

FIXED MKR STIMULUS

MKR ZERO

FIXED MKR VALUE

MKR ZERO

FLAT LINE

FORM FEED

FORMAT ARY on OFF

FORMAT DISK

FORMAT: DOS

FORMAT: LIF

Analyzer Functions

To read absolute active marker auxiliary values following a operation, the auxiliary value can be reset

to zero. leads to the ﬁxed marker menu, where the stimulus and

response values for a ﬁxed reference marker can be set arbitrarily.

changes the stimulus value of the ﬁxed marker. Fixed marker stimulus values can be different for the two channels if the channel markers are uncoupled using the marker mode menu. To read absolute active marker

stimulus values following a operation, the stimulus value can be reset to zero.

changes the response value of the ﬁxed marker. In a Cartesian format this is the y-axis value. In a polar or Smith chart format with a magnitude/phase marker, a real/imaginary marker, an R+jX marker, or a G+jB marker, this applies to the ﬁrst part of the complex data pair. Fixed marker response values are always uncoupled in the two channels.

Format

To read absolute active marker response values following a operation, the response value can be reset

to zero. deﬁnes a ﬂat limit line segment whose value is constant

with frequency or other stimulus value. This line is continuous to the next stimulus value, but is not joined to a segment with a different limit value. If a ﬂat line segment is the ﬁnal segment, it terminates at the stop stimulus. A ﬂat line segment is indicated as FL on the table of limits.

puts a form feed command into the display title. presents a menu used to select the display format for the

data. Various rectangular and polar formats are available for display of magnitude, phase, impedance, group delay, real data, and SWR.

speciﬁes whether or not to store the formatted data on disk with the instrument state.

brings up a menu for formatting a LIF or DOS disk. causes subsequent disk initialization to use the DOS disk

format. causes subsequent disk initialization to use the LIF disk

format. is the default setting.

4-21

Hardkey/Softkey Reference

FORMAT EXT DISK

FORMAT INT DISK

FORMAT INT MEMORY

FREQ OFFS MENU

FREQ OFFS on OFF

FREQUENCY

FREQUENCY BLANK

FREQUENCY: CW

FREQUENCY: SWEEP

FULL 2-PORT

FWD ISOL'N

FWD MATCH

FWD MATCH THRU

FWD TRANS

FWD TRANS THRU

G+jB MKR

Analyzer Functions

initializes media in external drive, and formats the disk using the selected (DOS or LIF) format.

initializes media in internal drive, and formats the disk using the selected (DOS or LIF) format.

clears all internal save registers and associated cal data and memory traces.

leads to the frequency offset menu (Option 089 only). switches the frequency offset mode on and off. speciﬁes the frequency of a calibration factor or loss value

in the power meter cal loss/sensor lists. blanks the displayed frequency notation for security

purposes. Frequency labels cannot be restored except by instrument preset or turning the power off and then on.

sets the LO frequency to CW mode for frequency offset. sets the LO frequency to sweep mode for frequency offset. provides access to the series of menus used to perform a

complete calibration for measurement of all four S-parameters of a two-port device. This is the most accurate calibration for measurements of two-port devices.

measures the forward isolation of the calibration standard.

(Label Class) lets you enter a label for the forward match class. The

label appears during a calibration that uses this class.

(Specify Class) speciﬁes which standards are in the forward match class

in the calibration kit. measures the forward match using a thru standard.

(Label Class) lets you enter a label for the forward transmission class.

The label appears during a calibration that uses this class.

(Specify Class) speciﬁes which standards are in the forward transmission

class in the calibration kit. measures the forward transmission frequency response in

a two-port calibration.

4-22

displays the complex admittance values of the active marker in rectangular form. The active marker values are displayed in terms of conductance (in Siemens), susceptance, and equivalent capacitance or inductance. Siemens are the international units of admittance, and are equivalent to mhos (the inverse of Ωs). The Smith chart graticule is changed to admittance form.

Hardkey/Softkey Reference

GATE on OFF

GATE: CENTER

GATE: SPAN

GATE: START

GATE: STOP

GATE SHAPE

GATE SHAPE MAXIMUM

GATE SHAPE MINIMUM

GATE SHAPE NORMAL

GATE SHAPE WIDE

GET SEQ TITLES

GOSUB SEQUENCE

GRAPHICS on OFF

GRATICULE [ ]

GRATICULE

HARMONIC MEAS

HARMONIC OFF

HARMONIC SECOND

HARMONIC THIRD

Analyzer Functions

G/n

giga/nano (109 / 10-9). Used to terminate numeric entries. (Option 010 only) turns gating on or off in time domain

mode. (Option 010 only) allows you to specify the time at the

center of the gate. (Option 010 only) allows you to specify the gate periods. (Option 010 only) allows you to specify the starting time of

the gate. (Option 010 only) allows you to specify the stopping time of

the gate. (Option 010 only) leads to the gate shape menu. (Option 010 only) selects the widest time domain gate with

the smallest passband ripple. (Option 010 only) selects the narrowest time domain gate

with the largest passband ripple. (Option 010 only) selects an intermediate time domain

gate. (Option 010 only) selects an intermediate time domain

gate. copies the sequence titles currently in memory into the six

softkey positions. calls sub-routines in sequencing. speciﬁes whether or not to store display graphics on disk

with the instrument state. brings up the graticule print color deﬁnition menu. The

graticule default print color is cyan. selects the display graticule for color modiﬁcation. (Option 002 only) leads to the harmonics menu. Measured

harmonics cannot exceed the frequency range of the analyzer receiver.

||HARMONIC OFF|| (Option 002 only) turns off the harmonic

measurement mode. (Option 002 only) selects measurement of the second

harmonic. (Option 002 only) selects measurement of the third

harmonic.

4-23

Hardkey/Softkey Reference

HELP ADAPT REMOVAL

HOLD

SINGLE

HP-IB DIAG on off

IF BW [ ]

IF LIMIT TEST FAIL

IF LIMIT TEST PASS

IF LOOP COUNTER = 0

Analyzer Functions

provides an on-line quick reference guide to using the adapter removal technique.

freezes the data trace on the display, and the analyzer stops sweeping and taking data. The notation "Hld" is displayed at the left of the graticule. If the * indicator is on at the left side of the display, trigger a new sweep with

toggles the HP-IB diagnostic feature (debug mode). This mode should only be used the ﬁrst time a program is written: if a program has already been debugged, it is unnecessary.

When diagnostics are on, the analyzer scrolls a history of incoming HP-IB commands across the display in the title line. Nonprintable characters are represented as pi. If a syntax error is received, the commands halt and a pointer wedge indicates the misunderstood character. For information on clearing a syntax error, refer to the programmer's guide.

is used to select the bandwidth value for IF bandwidth reduction. Allowed values (in Hz) are 6000, 3700, 3000, 1000, 300, 100, 30, and 10. Any other value will default to the closest allowed value. A narrow bandwidth slows the sweep speed but provides better signal-to-noise ratio. The selected bandwidth value is shown in brackets in the softkey label.

jumps to one of the six sequence positions (SEQUENCE 1 through 6) if the limit test fails. This command executes any sequence residing in the selected position. Sequences may jump to themselves as well as to any of the other sequences in memory. When this softkey is pressed, the analyzer presents a softkey menu showing the six sequence positions and the titles of the sequences located in them. Choose the destination sequence to be called if the limit test fails.

jumps to one of the six sequence positions (SEQUENCE 1 through 6) if the limit test passes. This command executes any sequence residing in the selected position. Sequences may jump to themselves as well as to any of the other sequences in memory. When this softkey is pressed, the analyzer presents a softkey menu showing the six sequence positions, and the titles of the sequences located in them. Choose the sequence to be called if the limit test passes (destination sequence).

4-24

prompts the user to select a destination sequence position (SEQUENCE 1 through 6). When the value of the loop

Hardkey/Softkey Reference

IF LOOP < > COUNTER 0

IMAGINARY

INCR LOOP COUNTER

INPUT PORTS

INSTRUMENT MODE

INTENSITY

INTERNAL TESTS

INTERNAL DISK

INTERNAL MEMORY

INTERPOL on OFF

ISOLATION

ISOLATION DONE

ISOL'N STD

KIT DONE (MODIFIED)

SAVE USER KIT

Analyzer Functions

counter reaches zero, the sequence in the speciﬁed position will run.

prompts the user to select a destination sequence position (SEQUENCE 1 through 6). When the value of the loop counter is no longer zero, the sequence in the speciﬁed position will run.

displays only the imaginary (reactive) portion of the measured data on a Cartesian format. This format is similar to the real format except that reactance data is displayed on the trace instead of impedance data.

increments the value of the loop counter by 1. accesses a menu that allows you to measure the R, A, and

B channels and their ratios. presents the instrument mode menu. This provides access

to the primary modes of operation (analyzer modes). sets the LCD intensity as a percent of the brightest

setting. The factory-set default value is stored in non-volatile memory.

k/m

leads to a series of service tests. selects the analyzer internal disk for the storage device. selects internal non-volatile memory as the storage

medium for subsequent save and recall activity. turns interpolated error correction on or off. The

interpolated error correction feature allows the operator to calibrate the system, then select a subset of the frequency range or a different number of points. Interpolated error correction functions in linear frequency, power sweep and CW time modes. When using the analyzer in linear sweep, it is recommended that the original calibration be performed with at least 67 points per 1 GHz of frequency span.

leads to the isolation menu. returns to the two-port cal menu. measures the isolation of the device connected to the test

port.

kilo/milli (10

/ 10−3)

terminates the cal kit modiﬁcation process, after all standards are deﬁned and all classes are speciﬁed. Be sure

to save the kit with the softkey, if it is to be used later.

4-25

Hardkey/Softkey Reference

LABEL CLASS

LABEL CLASS DONE

LABEL KIT

LABEL STD

LEFT LOWER

LEFT UPPER

LIMIT LINE OFFSETS

LIMIT LINE on OFF

EDIT LIMIT LINE

LIMIT MENU

LIMIT TEST on OFF

Analyzer Functions

leads to the label class menu, to give the class a meaningful label for future reference during calibration.

ﬁnishes the label class function and returns to the modify cal kit menu.

leads to a menu for constructing a label for the user-modiﬁed cal kit. If a label is supplied, it will appear as one of the ﬁve softkey choices in the select cal kit menu. The approach is similar to deﬁning a display title, except that the kit label is limited to ten characters.

The function is similar to deﬁning a display title, except that the label is limited to ten characters.

draws a quarter-page plot in the lower left quadrant of the page.

draws a quarter-page plot in the upper left quadrant of the page.

leads to the offset limits menu, which is used to offset the complete limit set in either stimulus or amplitude value.

turns limit lines on or off. To deﬁne limits, use the

softkey described below. If limits have been deﬁned and limit lines are turned on, the limit lines are displayed on the LCD for visual comparison of the measured data in all Cartesian formats.

If limit lines are on, they are plotted with the data on a plot, and saved in memory with an instrument state. In a listing of values from the copy menu with limit lines on, the upper limit and lower limit are listed together with the pass or fail margin, as long as other listed data allows sufﬁcient space.

leads to a series of menus used to deﬁne limits or speciﬁcations with which to compare a test device. Refer to “Limit Line Operation” in the “Operating Concepts” chapter of the user’s guide and the limit line testing section of the “Making Measurements” chapter of the user’s guide.

turns limit testing on or off. When limit testing is on, the data is compared with the deﬁned limits at each measured point. Limit tests occur at the end of each sweep, whenever the data is updated, when formatted data is changed, and when limit testing is ﬁrst turned on.

4-26

Limit testing is available for both magnitude and phase values in Cartesian formats. In polar and Smith chart formats,the value tested depends on the marker mode and

Hardkey/Softkey Reference

LIMIT TEST RESULT

LIMIT TYPE

LIN FREQ

LIN MAG

LIN MKR

LINE/MATCH

LINE TYPE DATA

LINE TYPE MEMORY

LIST

Analyzer Functions

is the magnitude or the ﬁrst value in a complex pair. The message "NO LIMIT LINES DISPLAYED" is displayed in polar and Smith chart formats if limit lines are turned on.

Five indications of pass or fail status are provided when limit testing is on. A PASS or FAIL message is displayed at the right of the LCD. The trace vector leading to any measured point that is out of limits is set to red at the end of every limit test, both on a displayed plot and a hard copy plot. The limit fail beeper sounds if it is turned on. In a listing of values using the copy menu, an asterisk * is shown next to any measured point that is out of limits. A bit is set in the HP-IB status byte.

puts the result of a limit test into the display title. leads to the limit type menu, where one of three segment

types can be selected: sloping line, ﬂat line, or single point. activates a linear frequency sweep displayed on a

standard graticule with ten equal horizontal divisions. This is the default preset sweep type.

displays the linear magnitude format. This is a Cartesian format used for unitless measurements such as reﬂection coefﬁcient magnitude ρ or transmission coefﬁcient magnitude τ, and for linear measurement units. It is used for display of conversion parameters and time domain transform data.

displays a readout of the linear magnitude and the phase of the active marker. Marker magnitude values are expressed in units and phase is expressed in degrees.

provides access to the Line/Match Menu for TRL/LRM calibration.

selects the line type for the data trace plot. The default line type is 7, which is a solid unbroken line.

selects the line type for the memory trace plot. The default line type is 7.

provides a tabular listing of all the measured data points and their current values, together with limit information if it is turned on. At the same time, the screen menu is presented, to enable hard copy listings and access new pages of the table. 30 lines of data are listed on each page, and the number of pages is determined by the number of measurement points speciﬁed in the stimulus menu.

4-27

Hardkey/Softkey Reference

LIST FREQ [SWEPT]

[STEPPED]

LIST IF BW on OFF

LIST POWER on OFF

PWR RANGE

SEGMENT POWER

LIST TYPE [SWEPT]

LN/MATCH 1

LN/MATCH 2

LO CONTROL on OFF

LO MENU

LO SOURCE ADDRESS

Analyzer Functions

or provides two user-deﬁnable arbitrary frequency list

modes. This list is deﬁned and modiﬁed using the edit list menu and the edit subsweep menu. Up to 30 frequency subsweeps (called "segments") of several different types can be speciﬁed, for a maximum total of 1601 points. One list is common to both channels. Once a frequency list has been deﬁned and a measurement calibration performed on the full frequency list, one or all of the frequency segments can be measured and displayed without loss of calibration.

Formore information on the different list frequency sweep modes,refer to “Sweep Types” in the “Operating Concepts” chapter of the user’s guide.

enables or disables the ability to set independent IF bandwidths for each segment in a swept list measurement.

enables or disables the ability to set independent power levels for each segment in a swept list measurement.

When on, sets power range mode to manual to set a range for the power values. (The range can be chosen using the

key.) The power values can be entered

using the key.If ports are uncoupled, the power can be set independently for each port.

When off, the key will not function and the power column in the swept list table will display asterisks. In this case, the power is set by the normal test port power value.

selects either stepped or swept list mode. For in-depth information on swept list mode, refer to “Swept List Frequency Sweep (Hz)” in the “Operating Concepts” chapter of the user’s guide.

measures the TRL/LRM line or match standard for PORT 1.

measures the TRL/LRM line or match standard for PORT 2.

turns the LO control mode on and off for frequency offset. leads to the LO menu. Allows you to conﬁgure the external

source for frequency offset.

4-28

shows the HP-IB address of the LO source.

Hardkey/Softkey Reference

LOAD

LOAD NO OFFSET

LOAD OFFSET

LOAD SEQ FROM DISK

LOG FREQ

LOG MAG

LOG MKR

Analyzer Functions

deﬁnes the standard type as a load (termination). Loads are assigned a terminal impedance equal to the system characteristic impedance Z0, but delay and loss offsets may still be added. If the load impedance is not Z0, use the arbitrary impedance standard deﬁnition.

initiates measurement of a calibration standard load without offset.

initiates measurement of a calibration standard load with offset.

presents the load sequence from disk menu. Select the desired sequence and the analyzer will load it from disk.

Local

This key is used to return the analyzer to local (front panel) operation from remote (computer controlled) operation. This key will also abort a test sequence or hardcopy print/plot. In this local mode, with a controller still connected on HP-IB, the analyzer can be operated manually (locally) from the front panel. This is the only front panel key that is not disabled when the analyzer is remotely controlled over HP-IB by a computer. The exception to this is when local lockout is in effect: this is a

remote command that disables the key, making it

Local

difﬁcult to interfere with the analyzer while it is under computer control.

activates a logarithmic frequency sweep mode. The source is stepped in logarithmic increments and the data is displayed on a logarithmic graticule. This is slower than a continuous sweep with the same number of points, and the entered sweep time may therefore be changed automatically. For frequency spans of less than two octaves, the sweep type automatically reverts to linear sweep.

displays the log magnitude format. This is the standard Cartesian format used to display magnitude-only measurements of insertion loss, return loss, or absolute power in dB versus frequency.

displays the logarithmic magnitude value and the phase of the active marker in Polar or Smith chart format. Magnitude values are expressed in dB and phase in degrees. This is useful as a fast method of obtaining a reading of the log magnitude value without changing to log magnitude format.

4-29

Hardkey/Softkey Reference

LOOP COUNTER

LOSS

LOSS/SENSR LISTS

LOW PASS IMPULSE

LOW PASS STEP

LOWER LIMIT

M/µ

Analyzer Functions

displays the current value of the loop counter and allows you to change the value of the loop counter. Enter any

number from 0 to 32767 and terminate with the key. The default value of the counter is zero. This command should be placed in a sequence that is separate from the measurement sequence. For this reason: the measurement sequence containing a loop decision command must call

itself in order to function. The command must be in a separate sequence or the counter value would always be reset to the initial value.

(Sequence Filenaming) inserts the string "[LOOP]" into the ﬁle name.

accepts a power loss value for a segment in the power meter cal power loss list. This value, for example, could be the difference (in dB) between the coupled arm and through arm of a directional coupler.

presents the power loss/sensor lists menu. This menu performs two functions:

• Corrects coupled-arm power loss when a directional

coupler is used to sample the RF output.

• Allows calibration factor data to be entered for one or

two power sensors.

Each function provides up to 12 separate frequency points, called segments, at which the user may enter a different power loss or calibration factor. The instrument interpolates between the selected points. Two power sensor lists are provided because no single power sensor can cover the frequency range of the network analyzer.

(Option 010 only) sets the transform to low pass impulse mode, which simulates the time domain response to an impulse input.

(Option 010 only) sets the transform to low pass step mode, which simulates the time domain response to a step input.

sets the lower limit value for the start of the segment in a limit line list. If an upper limit is speciﬁed, a lower limit must also be deﬁned. If no lower limit is required for a particular measurement, force the lower limit value out of range (for example −500 dB).

mega/micro (10

/ 10−6)

4-30

Hardkey/Softkey Reference

MANUAL TRG ON POINT

MARKER→ AMP. OFS.

MARKER→ CENTER

MARKER→ CW

MARKER→ DELAY

Analyzer Functions

waits for a manual trigger for each point. Subsequent pressing of this softkey triggers each measurement. The annotation "man" will appear at the left side of the display when the instrument is waiting for the trigger to occur. This feature is useful in a test sequence when an external device or instrument requires changes at each point.

Marker

displays an active marker on the screen and provides access to a series of menus to control from one to ﬁve display markers for each channel. Markers provide numerical readout of measured values at any point of the trace.

The menus accessed from the key provide several

Marker

basic marker operations. These include special marker modes for different display formats, and a marker delta mode that displays marker values relative to a speciﬁed value or another marker.

uses the active marker to set the amplitude offset for the limit lines. Move the marker to the desired middle value of the limits and press this softkey. The limits are then moved so that they are centered an equal amount above and below the marker at that stimulus value.

changes the stimulus center value to the stimulus value of the active marker, and centers the new span about that value.

sets the CW frequency of the analyzer to the frequency of the active marker. This feature is useful in automated compression measurements. Test sequences allow the instrument to automatically ﬁnd a maximum or minimum

point on a response trace. The command sets the instrument to the CW frequency of the active marker. When power sweep in engaged, the CW frequency will already be selected.

adjusts the electrical delay to balance the phase of the DUT. This is performed automatically, regardless of the format and the measurement being made. Enough line length is added to or subtracted from the receiver input to compensate for the phase slope at the active marker position. This effectively ﬂattens the phase trace around the active marker, and can be used to measure electrical length or deviation from linear phase. Additional electrical delay adjustments are required on DUTs without constant group delay over the measured frequency span. Since this feature adds phase to a variation in phase versus frequency, it is applicable only for ratioed inputs.

4-31

Hardkey/Softkey Reference

MARKER→ MIDDLE

DELTA LIMITS

MARKER→ REFERENCE

MARKER→ SPAN

MARKER→ START

MARKER→ STIMULUS

MARKER→ STOP

MARKER 1

MARKER 2

MARKER 3

MARKER 4

MARKER 5

MARKER all OFF

Analyzer Functions

sets the midpoint for using the active marker to set the middle amplitude value of a limit segment. Move the marker to the desired value or device speciﬁcation, and press this key to make that value the midpoint of the delta limits. The limits are automatically set an equal amount above and below the marker.

makes the reference value equal to the active marker's response value, without changing the reference position. In a polar or Smith chart format, the full scale value at the outer circle is changed to the active marker response value. This softkey also appears in the scale reference menu.

changes the start and stop values of the stimulus span to the values of the active marker and the delta reference marker. If there is no reference marker, the message "NO MARKER DELTA − SPAN NOT SET" is displayed.

changes the stimulus start value to the stimulus value of the active marker.

sets the starting stimulus value of a limit line segment using the active marker. Move the marker to the desired starting stimulus value before pressing this key, and the marker stimulus value is entered as the segment start value.

changes the stimulus stop value to the stimulus value of the active marker.

turns on marker 1 and makes it the active marker. The active marker appears on the display as ∇. The active marker stimulus value is displayed in the active entry area, together with the marker number. If there is a marker turned on, and no other function is active, the stimulus value of the active marker can be controlled with the knob, the step keys, or the numeric keypad. The marker response and stimulus values are displayed in the upper right-hand corner of the screen.

turns on marker 2 and makes it the active marker. If another marker is present, that marker becomes inactive and is represented on the display as ∆.

turns on marker 3 and makes it the active marker.

4-32

turns on marker 4 and makes it the active marker. turns on marker 5 and makes it the active marker. turns off all the markers and the delta reference marker,

as well as the tracking and bandwidth functions that are

accessed with the key.

MKR FCTN

MARKER MODE MENU

MARKERS: CONTINUOUS

MARKERS: COUPLED

MARKERS: DISCRETE

MARKERS: UNCOUPLED

MAX

MAXIMUM FREQUENCY

MEASURE RESTART

Hardkey/Softkey Reference

Analyzer Functions

Marker Fctn

Marker Search

key activates a marker if one is not already active, and provides access to additional marker functions. These can be used to quickly change the measurement parameters, to search the trace for speciﬁed information, and to analyze the trace statistically.

provides access to the marker mode menu, where several marker modes can be selected including special markers for polar and Smith chart formats.

allows user to turn tracking on, off and search for the maximum, minimum, and target points on the trace.

located under the key, interpolates between

Marker

measured points to allow the markers to be placed at any point on the trace. Displayed marker values are also interpolated. This is the default marker mode.

couples the marker stimulus values for the two display channels. Even if the stimulus is uncoupled and two sets of stimulus values are shown, the markers track the same stimulus values on each channel as long as they are within the displayed stimulus range.

places markers only on measured trace points determined by the stimulus settings.

Meas

allows the marker stimulus values to be controlled independently on each channel.

moves the active marker to the maximum point on the trace.

is used to deﬁne the highest frequency at which a calibration kit standard can be used during measurement calibration. In waveguide,this is normally the upper cutoff frequency of the standard.

key provides access to a series of softkey menus for selecting the parameters or inputs to be measured.

aborts the sweep in progress, then restarts the measurement. This can be used to update a measurement following an adjustment of the device under test. When a full two-port calibration is in use, the

key will initiate another update of both forward and reverse S-parameter data. This softkey will also override the test set hold mode, which inhibits continuous switching of either the test port transfer switch or step attenuator. This softkey will override the test set hold mode for one measurement.

4-33

Hardkey/Softkey Reference

MEASURE RESTART

AVERAGING RESTART

HOLD

MEASURE RESTART

MEMORY

MIDDLE VALUE

DELTA LIMITS

MIN

MINIMUM FREQUENCY

OFFSET DELAY

MKR SEARCH [ ]

MKR STATS on OFF

MKR ZERO

Analyzer Functions

If the analyzer is taking a number of groups, the sweep counter is reset at 1. If averaging is on,

resets the sweep-to-sweep

averaging and is effectively the same as

. If the sweep trigger is in

mode, executes a single

sweep. displays the trace memory for the active channel. This is

the only memory display mode where the smoothing and gating of the memory trace can be changed. If no data has been stored in memory for this channel, a warning message is displayed.

sets the midpoint for . It uses the entry controls to set a speciﬁed amplitude value vertically centered between the limits.

moves the active marker to the minimum point on the trace.

is used to deﬁne the lowest frequency at which a calibration kit standard can be used during measurement calibration. In waveguide, this must be the lower cutoff frequency of the standard, so that the analyzer can calculate dispersive effects correctly (see

leads to the marker search menu, which is used to search the trace for a particular value or bandwidth.

calculates and displays the mean, standard deviation, and peak-to-peak values of the section of the displayed trace between the active marker and the delta reference marker. If there is no delta reference, the statistics are calculated for the entire trace. A convenient use of this feature is to ﬁnd the peak-to-peak value of passband ripple without searching separately for the maximum and minimum values.

The statistics are absolute values: the delta marker here serves to deﬁne the span. For polar and Smith chart formats, the statistics are calculated using the ﬁrst value of the complex pair (magnitude, real part, resistance, or conductance).

4-34

puts a ﬁxed reference marker at the present active marker position, and makes the ﬁxed marker stimulus and response values at that position equal to zero. All subsequent stimulus and response values of the active marker are then read out relative to the ﬁxed marker. The ﬁxed marker is shown on the display as a small triangle ∆

Hardkey/Softkey Reference

MKR ZERO

MKR ZERO∆REF =

ALL OFF

MODIFY [ ]

MODIFY COLORS

N 75ΩHP 85036

NETWORK ANALYZER

NEW SEQ/MODIFY SEQ

NEWLINE

NUMBER OF GROUPS

NUMBER of POINTS

Analyzer Functions

(delta), smaller than the inactive marker triangles. The softkey label changes from to

∆

and the notation "∆REF = ∆" is displayed at the top right corner of the graticule. Marker zero is canceled by turning delta mode off in the delta marker menu or turning all the markers off with the

softkey.

leads to the modify cal kit menu, where a default cal kit can be user-modiﬁed.

present a menu for color modiﬁcation of display elements. Refer to the section on adjusting the display color in the “Using Measurement Functions” chapter of the user’s guide for information on modifying display elements.

selects the HP 85036B/E cal kit. sets the analyzer to network analyzer mode. activates the sequence edit mode and presents the

new/modify sequence menu with a list of sequences that can be created or modiﬁed.

puts a new line command into the display title. steps forward through a tabular list of data page-by-page. triggers a user-speciﬁed number of sweeps, and returns to

the hold mode. This function can be used to override the test set hold mode (indicated by the notation “tsH” at the left of the screen). In this mode, the electro-mechanical transfer switch (Option 007) and attenuator are not protected against unwanted continuous switching. This occurs in a full two-port calibration, in a measurement of two different parameters that require power out from both ports, or when the channels are uncoupled and a different power level is set for each channel.

If averaging is on, the number of groups should be at least equal to the averaging factor selected to allow measurement of a fully averaged trace.Entering a number of groups resets the averaging counter to 1.

is used to select the number of data points per sweep to be measured and displayed. Using fewer points allows a faster sweep time but the displayed trace shows less horizontal detail. Using more points gives greater data density and improved trace resolution, but slows the sweep and requires more memory for error correction or saving instrument states.

The possible values that can be entered for number of

4-35

Hardkey/Softkey Reference

NUMBER OF READINGS

OFFSET

OFFSET DELAY

OFFSET LOADS DONE

OFFSET LOSS

OFFSET Z0

OMIT ISOLATION

ONE-PATH 2-PORT

Analyzer Functions

points are 3, 11, 26, 51, 101, 201, 401,801, and 1601. The number of points can be different for the two channels if the stimulus values are uncoupled.

In list frequency sweep, the number of points displayed is the total number of frequency points for the deﬁned list (see “Sweep Types” in the “Operating Concepts” chapter of the user’s guide).

determines the number of measurement/correction iterations performed on each point in a power meter calibration. This feature helps eliminate residual power errors after the initial correction. The amount of residual error is directly proportional to the magnitude of the initial correction. The user should initially set the source power so that it is approximately correct at the device under test. If power uncertainty at the device under test is expected to be greater than a few dB, it is recommended that the number of readings be greater than 1.

selects the calibration standard load as being offset. is used to specify the one-way electrical delay from the

measurement (reference) plane to the standard, in seconds (s). (In a transmission standard, offset delay is the delay from plane to plane.) Delay can be calculated from the precise physical length of the offset, the permittivity constant of the medium, and the speed of light.

completes the selection in the Offset Load Menu. is used to specify energy loss, due to skin effect, along a

one-way length of coax offset. The value of loss is entered as Ωs/nanosecond (or Giga Ωs/second) at 1 GHz. (Such losses are negligible in waveguide, so enter 0 as the loss offset.)

is used to specify the characteristic impedance of the coax offset. (Note: This is not the impedance of the standard itself.)(For waveguide,the offset impedance should always be assigned a value equal to the system Z0.)

is used to omit the isolation portion of the calibration. leads to the series of menus used to perform a

high-accuracy two-port calibration without an S-parameter test set. This calibration procedure effectively removes directivity, source match, load match, isolation, reﬂection tracking, and transmission tracking errors in one direction only. Isolation correction can be omitted for measurements of devices with limited dynamic range. (The device under test must be manually reversed between sweeps to accomplish measurement of both input

4-36

Hardkey/Softkey Reference

ONE SWEEP

OP PARMS (MKRS etc)

OPEN

OPEN (F)

OPEN (M)

P MTR/HPIB TO TITLE

PARALL IN BIT NUMBER

PARALL IN IF BIT H

PARALL IN IF BIT L

PARALLEL

PARALLEL [COPY/GPIO]

Analyzer Functions

and output responses.) The required standards are a short, an open, a thru, and an impedance-matched load.

This mode does not measure each sweep, but corrects each point with the data currently in the power meter correction table.

provides a tabular listing on the analyzer display of the key parameters for both channels. The screen menu is presented to allow hard copy listings and access new pages of the table. Four pages of information are supplied. These pages list operating parameters, marker parameters, and system parameters that relate to control of peripheral devices rather than selection of measurement parameters.

deﬁnes the standard type as an open, used for calibrating reﬂection measurements. Opens are assigned a terminal impedance of inﬁnite Ωs, but delay and loss offsets may still be added.

for cal kits with different models for male and female test port standards, this selects the open model for a female test port. Note that the sex of a calibration standard always refers to the test port.

for cal kits with different models for male and female test port standards, this selects the open model for a male test port. Note that the sex of a calibration standard always refers to the test port.

gets data from an HP-IB device set to the address at which the analyzer expects to ﬁnd a power meter. The data is stored in a title string. The analyzer must be in system controller or pass control mode.

while creating a sequence, this softkey will insert a command that selects the single bit (0 to 4) that a sequence will be looking for from the GPIO bus.

while creating a sequence, this softkey inserts a command to jump to another sequence if the single input selected is in a high state.

while creating a sequence, this softkey inserts a command to jump to another sequence if the single input selected is in a low state.

sets the printer or plotter port to parallel. toggles the parallel output port between the copy and

GPIO output modes.

4-37

Hardkey/Softkey Reference

PARALLEL OUT ALL

PAUSE

CONTINUE SEQUENCE

PAUSE TO SELECT

DO SEQUENCE

PEN NUM DATA

PEN NUM GRATICULE

PEN NUM MARKER

PEN NUM MEMORY

PEN NUM TEXT

PHASE OFFSET

MARKER→ DELAY

ELECTRICAL DELAY

PHASE

PLOT

Analyzer Functions

allows you to input a number (0 to 255) in base 10, and outputs it to the bus as binary, when the parallel port is in GPIO mode.

pauses the sequence so the operator can perform a needed task, such as changing the DUT, changing the calibration standard, or other similar task. Press

when ready.

when editing a sequence, appears when you press . When placed in a

sequence, it presents the menu of up to 6 available sequences (softkeys containing non-empty sequences). If the operator selects one of the sequences, that sequence is executed. Any other key can be used to exit this mode. This function is not executed if used during modify mode and does nothing when operated manually. This softkey is not visible on the display, and the function is not available, unless programmed into analyzer memory.

selects the number of the pen to plot the data trace. The default pen for channel 1 is pen number 2, and for channel 2 is pen number 3.

selects the number of the pen to plot the graticule. The default pen for channel 1 is pen number 1, and for channel 2 is pen number 1.

selects the number of the pen to plot both the markers and the marker values. The default pen for channel 1 is pen number 7, and for channel 2 is pen number 7.

selects the number of the pen to plot the memory trace. The default pen for channel 1 is pen number 5, and for channel 2 is pen number 6.

selects the number of the pen to plot the text. The default pen for channel 1 is pen number 7, and for channel 2 is pen number 7.

adds or subtracts a phase offset that is constant with frequency (rather than linear). This is independent of

and .

(Option 010 only) displays a Cartesian format of the phase portion of the data, measured in degrees. This format displays the phase shift versus frequency.

4-38

makes a hard copy plot of one page of the tabular listing on the display, using a compatible HP plotter connected to the analyzer through HP-IB. This method is appropriate when speed of output is not a critical factor.

Hardkey/Softkey Reference

PLOT DATA ON off

PLOT GRAT ON off

PLOT GRAT ON

PLOT GRAT OFF

PLOT MEM ON off

PLOT MKR ON off

PLOT NAME PLOTFILE

PLOT SPEED [ ]

PLOT TEXT ON off

PLOTTER BAUD RATE

PLOTTER FORM FEED

PLOTTER PORT

PLTR PORT: DISK

PLTR PORT HPIB

PLTR PORT PARALLEL

PLTR PORT SERIAL

PLTR TYPE [PLOTTER]

PLTR TYPE [HPGL PRT]

Analyzer Functions

speciﬁes whether the data trace is to be drawn (on) or not drawn (off) on the plot.

speciﬁes whether the graticule and the reference line are to be drawn (on) or not drawn (off) on the plot. Turning

and all other elements off is a convenient way to make preplotted grid forms. However, when data is to be plotted on a preplotted form,

should be selected.

speciﬁes whether the memory trace is to be drawn (on) or not drawn (off) on the plot. Memory can only be plotted if it is displayed (refer to the “Making Measurements” chapter in the user’s guide).

speciﬁes whether the markers and marker values are to be drawn (on) or not drawn (off) on the plot.

supplies a name for the plot ﬁle generated by a PLOT to disk. Brings up the TITLE FILE MENU.

toggles between fast and slow speeds. selects plotting of all displayed text except the marker

values, softkey labels, and display listings such as the frequency list table or limit table. (Softkey labels can be plotted under the control of an external controller. Refer to the programmer’s guide.)

sets the serial port data transmission speed for plots. sends a page eject command to the plotter. conﬁgures the port analyzer will use to communicate with

the plotter. directs plots to the selected disk (internal or external). directs plots to the HP-IB port and sets the HP-IB address

the analyzer will use to communicate with the plotter. conﬁgures the analyzer for a plotter that has a parallel

(centronics) interface. conﬁgures the analyzer for a plotter that has a serial

(RS-232) interface. selects a pen plotter such as the HP 7440A, HP 7470A,

HP 7475A, or HP 7550B as the plotter type. selects a PCL5 compatible printer, which supports

HP-GL/2, such as the LaserJet III or LaserJet 4 for a monochrome plotter type, or the DeskJet 1200C for a color plotter type.

4-39

Hardkey/Softkey Reference

POLAR

POLAR MKR MENU

PORT EXTENSIONS

PORT POWER [COUPLED]

PORT POWER [UNCOUPLED]

POWER: FIXED

POWER RANGES

POWER: SWEEP

POWER LOSS

POWER MTR

436A

438A/437

Analyzer Functions

displays a polar format. Each point on the polar format corresponds to a particular value of both magnitude and phase. Quantities are read vectorally: the magnitude at any point is determined by its displacement from the center (which has zero value), and the phase by the angle counterclockwise from the positive x-axis. Magnitude is scaled in a linear fashion, with the value of the outer circle usually set to a ratio value of 1. Since there is no frequency axis, frequency information is read from the markers.

leads to a menu of special markers for use with a polar format.

goes to the reference plane menu, which is used to extend the apparent location of the measurement reference plane or input.

is used to set the same power levels at each port.

allows you to set different power levels at each port.

Power

makes power level the active function and sets the RF output power level of the analyzer's internal source. The analyzer will detect an input power overload at any of the three receiver inputs. This is indicated with the message "OVERLOAD ON INPUT (R, A, B)." If power meter cal is on, cal power is the active entry.

sets the external LO ﬁxed power. leads to the power ranges menu which allows the user to

select among 12 power ranges from −75 to −5 dBm. sets the external LO power sweep. brings up the segment modify menu and segment edit

(power loss) menu explained in the following pages. This softkey is intended for use when the power output is being sampled by a directional coupler or power splitter. In the case of the directional coupler, enter the power loss caused by the coupled arm.

This feature may be used to compensate for attenuation non-linearities in either a directional coupler or a power splitter. Up to 12 segments may be entered, each with a different frequency and power loss value.

4-40

toggles between or . These power meters are HP-IB compatible with the analyzer. The model number in the softkey label must match the power meter to be used.

Hardkey/Softkey Reference

POWER SWEEP

CW FREQ

PRESET: FACTORY

PRESET: USER

PRESET SETTINGS

PRINT ALL COLOR

PRINT ALL MONOCHROME

Analyzer Functions

turns on a power sweep mode that is used to characterize power-sensitive circuits. In this mode, power is swept at a single frequency, from a start power value to a stop power

value, selected using the and keys and the

Start Stop

entry block. This feature is convenient for such measurements as gain compression or AGC (automatic gain control) slope. To set the frequency of the power

sweep, use in the stimulus menu. Refer to the user's guide for an example of a gain compression measurement.

Note that power range switching is not allowed in power sweep mode.

In power sweep, the entered sweep time may be automatically changed if it is less than the minimum required for the current conﬁguration (number of points, IF bandwidth, averaging, etc.).

Preset

presents a menu to select a factory or user deﬁned preset state.

is used to select the preset conditions deﬁned by the factory.

is used to select a preset condition deﬁned by the user. This is done by saving a state in a register under

Save/Recall

and naming the register UPRESET. When

is underlined, the key will

Preset

bring up the state of the UPRESET register. selects a menu to set the preset states of some items, such

as calibration interpolation and step sweep mode. steps backward through a tabular list of data

page-by-page. when displaying list values, prints the entire list in color.

When displaying operating parameters, prints all but the last page in color. The data is sent to the printer as ASCII text rather than as raster graphics, which causes the printout to be faster.

when displaying list values, prints the entire list in monochrome. When displaying operating parameters, prints all but the last page in monochrome. The data is sent to the printer as ASCII text rather than as raster graphics, which causes the printout to be faster.

4-41

Hardkey/Softkey Reference

PRINT: COLOR

PRINT COLOR

PRINT COLORS

PRINT: MONOCHROME

PRINT MONOCHROME

PRINT SEQUENCE

PRINTER BAUD RATE

PRINTER FORM FEED

PRINTER PORT

PRNTR PORT HPIB

PRNTR PORT PARALLEL

PRNTR PORT SERIAL

PRNTR TYPE [DESKJET]

PRNTR TYPE [EPSON-P2]

PRNTR TYPE [LASERJET]

PRNTR TYPE [PAINTJET]

PRNTR TYPE [THINKJET]

PWR LOSS on OFF

LOSS/SENSR LISTS

PWR RANGE AUTO man

Analyzer Functions

sets the print command to default to a color printer. The printer output is always in the analyzer default color values. This command does not work with a black and white printer.

prints the displayed measurement results in color. is used to select the print colors menu. sets the print command to default to a black and white

printer. prints the displayed measurement results in black and

white. prints any sequence currently in memory to a compatible

printer. sets the serial port data transmission speed for prints. sends a conditional form feed to the printer. conﬁgures the port the analyzer will use to communicate

with the printer. directs prints to the HP-IB port and sets the HP-IB

address the analyzer will use to communicate with the printer.

conﬁgures the analyzer for a printer that has a parallel (centronics) interface.

conﬁgures the analyzer for a printer that has a serial (RS-232) interface.

sets the printer type to the DeskJet series. sets the printer type to Epson compatible printers, which

support the Epson ESC/P2 printer control language. sets the printer type to the LaserJet series. sets the printer type to the PaintJet. sets the printer type to the ThinkJet or QuietJet. turns on or off power loss correction. Power loss correction

should be used when the power output is measured by a directional coupler. Enter the power loss caused by the

coupled arm with the softkey submenus described below.

4-42

toggles the power range mode between auto and manual. Auto mode selects the power range based on the power selected. Manual mode limits power entry to within the ±6to−12 dB selected range.

Hardkey/Softkey Reference

PWRMTR CAL [ ]

PWRMTR CAL [OFF]

R+jX MKR

RANGE 0 [ ]

RANGE 1 [ ]

RANGE 2 [ ]

RANGE 3 [ ]

RANGE 4 [ ]

RANGE 5 [ ]

RANGE 6 [ ]

RANGE 7 [ ]

RANGE 8 [ ]

RANGE 9 [ ]

RANGE 10 [ ]

RANGE 11 [ ]

RAW ARRAY on OFF

RAW OFFSET On Off

Analyzer Functions

leads to the power meter calibration menu which provides two types of power meter calibration, continuous (each sweep) and single-sample (one sweep).

turns off power meter calibration, terminate a power meter calibration sweep.

measures the absolute power amplitude at input R. converts the active marker values into rectangular form.

The complex impedance values of the active marker are displayed in terms of resistance, reactance, and equivalent capacitance or inductance. This is the default Smith chart marker.

NOTE Each of the range softkeys will have different ranges dependent on the

analyzer model and options installed.

selects power range 0 when in manual power range. selects power range 1 when in manual power range. selects power range 2 when in manual power range. selects power range 3 when in manual power range. selects power range 4 when in manual power range. selects power range 5 when in manual power range. selects power range 6 when in manual power range. selects power range 7 when in manual power range. selects power range 8 when in manual power range. selects power range 9 when in manual power range. selects power range 10 when in manual power range. selects power range 11 when in manual power range. speciﬁes whether or not to store the raw data (ratioed and

averaged) on disk with the instrument state. selects whether sampler and attenuator offsets are ON or

OFF. By selecting raw offsets OFF, a full two port error correction can be performed without including the effects of the offsets. It also saves substantial time at recalls and during frequency changes. Raw offsets follow the channel coupling. This softkey is used with "Take4" mode. Refer to the examples in the programmer’s guide.

4-43

Agilent 8753ES Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Documentation Map

Corrected System Performance

Source

Receiver

General Information

2 Front/Rear Panel

Front Panel Features

Analyzer Display

Rear Panel Features and Connectors

3 Menu Maps

Menu Maps

4 Hardkey/Softkey Reference

Key Reference

Where to Look for More Information

Guide Terms and Conventions

Analyzer Functions
