Agilent 86100C Wide-Bandwidth Oscilloscope

Technical Specifications

• Automated jitter decomposition

• Internally generated pattern trigger

• Modular platform for testing waveforms to 40 Gb/s and beyond

• Broadest coverage of data rates with optical reference receivers and for clock recovery

• Compatible with Agilent 86100A/B-series, 83480A-series,and 54750-series modules

• < 200 fs intrinsic jitter

• Open operating system – Windows

XP Pro

Four instruments in one

A digital communications analyzer, a full featured wide-bandwidth oscilloscope, a time-domain reflectometer, and a jitter analyzer

DCA-J

Table of Contents

Overview

Features 3

Measurements 5

Additional capabilities 6

Specifications

Mainframe & triggering

(includes precision time base module) 10

Computer system & storage 12

Modules

Overview 13 Module selection table 14 Specifications

Multimode/single-mode 15 Single-mode 19 Dual electrical 20 TDR 21 Clock recovery 21

Ordering Information 24

Windows is a U.S. registered trademark of Microsoft Corporation.

Features

Four Instruments in One

The 86100C Infiniium DCA-J can be viewed as four high-powered instruments in one:

• A general-purpose wide-bandwidth sampling oscilloscope; the new PatternLock triggering significantly enhances the usability as a general purpose scope

• A digital communications analyzer; the new Eyeline Mode feature adds a powerful new tool to eye diagram analysis

• A time domain ref lectometer

• A jitter analyzer

Just select the desired instrument mode and start making measurements.

Configurable to meet your needs

The 86100C supports a wide range of modules for testing both optical and electrical signals. Select modules to get the specific bandwidth, filtering, and sensitivity you need.

PatternLock Triggering

The Enhanced Trigger Option (Option 001) on the 86100C provides a fundamental capability never available before in an equivalent time sampling oscilloscope. This new triggering mechanism enables the DCA-J to generate a trigger at the repetition of the input data pattern – a pattern trigger. Historically, this capability required the pattern source to provide this type of trigger output to the scope. PatternLock automatically detects the pattern length, data rate and clock rate making the complex triggering mechanism transparent to the user.

PatternLock enables the 86100C to behave more like a real-time oscilloscope in terms of user experience. Investigation of specific bits within the data pattern is greatly simplified. Users that are familiar with real-time oscilloscopes, but perhaps less so with equivalent time sampling scopes will be able to ramp up quickly.

PatternLock adds another new dimension to pattern triggering by enabling the mainframe software to take samples at specific locations in the data pattern with outstanding timebase accuracy. This capability is a building block for many of the new capabilities available in the 86100C described later.

Jitter Analysis

The “J” in DCA-J represents jitter analysis. The 86100C is a Digital Communications Analyzer with Jitter analysis capability. The 86100C adds a fourth mode of operation – Jitter Mode. Extremely wide bandwidth, low intrinsic jitter, and advanced analysis algorithms yield the highest accuracy in jitter measurements.

As data rates increase in both electrical and optical applications, jitter is an ever increasing measurement challenge. Decomposition of jitter into its constituent components is becoming more critical. It provides critical insight for jitter budgeting and performance optimization in device and system designs. Many emerging standards require jitter decomposition for compliance. Traditionally, techniques for separation of jitter have been complex and often difficult to configure, and availability of instruments for separation of jitter becomes very limited as data rates increase.

The DCA-J provides simple, one button setup and execution of advanced waveform analysis. Jitter Mode decomposes jitter into its constituent components and presents jitter data in various insightful displays. Jitter Mode operates at all data rates the 86100C supports, removing the traditional data rate limitations from complex jitter analysis. The 86100C brings several key attributes to jitter analysis:

• Very low intrinsic jitter (both random and deterministic) translates to a very low jitter noise floor which provides unmatched jitter measurement sensitivity.

• Wide bandwidth measurement channels deliver very low intrinsic data dependent jitter and allow analysis of jitter on all data rates to 40 Gb/s and beyond.

• PatternLock triggering technology provides sampling efficiency that makes jitter measurements very fast.

Jitter analysis functionality is segmented into two software package options. Option 200 is the enhanced jitter analysis software, and Option 201 is the advanced waveform analysis software. Option 200 includes:

• Decomposition of jitter into Total Jitter (TJ), Random Jitter (RJ), Deterministic Jitter (DJ), Periodic Jitter (PJ), Data Dependent Jitter (DDJ), Duty Cycle Distortion (DCD), and Jitter induced by Intersymbol Interference (ISI).

• Various graphical and tabular displays of jitter data

• Export of jitter data to convenient delimited text format

• Save / recall of jitter database

• Jitter frequency spectrum

• Isolation and analysis of Sub-Rate Jitter (SRJ), that is, periodic jitter that is at an integer sub-rate of the bitrate.

• Bathtub curve display

• Adjustable total jitter probability

Overview of infiniium DCA-J

As bit rates increase, channel effects cause significant eye closure. Many new devices and systems are employing equalization and pre/de-emphasis to compensate for channel effects. Option 201 Advanced Waveform Analysis will provide key tools to enable design and test of devices and systems that must deal with difficult channel effects:

• Capture of long single valued waveforms. PatternLock triggering and the waveform append capability of Option 201 enable very accurate pulse train data sets up to 256 megasamples long.

• Equalization. The DCA-J can take a long single valued waveform and route it through a linear equalizer algorithm (default or user defined) and display the resultant equalized waveform in real time. The user can simultaneously view the input (distorted) and output (equalized) waveforms.

• Interface to MATLAB® analysis capability.

Digital communications analysis

Accurate eye-diagram analysis is essential for characterizing the quality of transmitters used from 100 Mb/s to 40 Gb/s. The 86100C is designed specifically for the complex task of analyzing digital communications waveforms. Compliance mask and parametric testing no longer require a complicated sequence of setups and configurations. If you can press a button, you can perform a complete compliance test. The important measurements you need are right at your fingertips, including:

• industry standard mask testing with built-in margin analysis

• extinction ratio measurements with accuracy and repeatability

• eye measurements: crossing %, eye height and width, ‘1’ and ‘0’ levels, jitter, rise or fall times and more

The key to accurate measurements of lightwave communications waveforms is the optical receiver. The 86100C has a broad range of precision receivers integrated within the instrument.

• Built-in photodiodes, with flat frequency responses, yield the highest waveform fidelity. This provides high accuracy for extinction ratio measurements.

• Standards-based transmitter compliance measurements require filtered responses. The 86100C has a broad range of filter combinations. Filters can be automatically and repeatably switched in or out of the measurement channel remotely over GPIB or with a front panel button. The frequency response of the entire measurement path is calibrated, and will maintain its performance over long-term usage.

• The integrated optical receiver provides a calibrated optical channel. With the accurate optical receiver built into the module, optical signals are accurately measured and displayed in optical power units.

Switches or couplers are not required for an average power measurement. Signal routing is simplified and signal strength is maintained.

Eye diagram mask testing

The 86100C provides efficient, high-throughput waveform compliance testing with a suite of standards based eye-diagram masks. The test process has been streamlined into a minimum number of keystrokes for testing at industry standard data rates.

Standard formats

Rate (Mb/s)

1X Gigabit Ethernet 1250 2X Gigabit Ethernet 2500 10 Gigabit Ethernet 9953.28 10 Gigabit Ethernet 10312.5 10 Gigabit Ethernet FEC 11095.7 10 Gigabit Ethernet LX4 3125 Fibre Channel 1062.5 2X Fibre Channel 2125 4X Fibre Channel 4250 8x Fibre Channel 8500 10X Fibre Channel 10518.75 10X Fibre Channel FEC 11317 Infiniband 2500 STM0/OC1 51.84 STM1/OC3 155.52 STM4/OC12 622.08 STM16/OC48 2488.3 STM16/OC48 FEC 2666 STM64/OC192 9953.28 STM64/OC192 FEC 10664.2 STM64/OC192 FEC 10709 STM64/OC192 Super FEC 12500 STM256/OC768 39813 STS1 EYE 51.84 STS3 EYE 155.52

Other eye-diagram masks are easily created through scaling those listed at left. In addition, mask editing allows for new masks either by editing existing masks, or creating new masks from scratch. A new mask can also be created or modified on an external PC using a text editor such as Notepad, then can be transferred to the instrument’s hard drive using LAN or Flash drive.

Perform these mask conformance tests with convenient user-definable measurement conditions, such as mask margins for guardband testing, number of waveforms tested, and stop/limit actions.

Eyeline Mode

Eyeline Mode is a new feature only available in the 86100C that provides insight into the effects of specific bit transitions within a data pattern. The unique view assists diagnosis of device or system failures do to specific transitions or sets of transitions within a pattern. When combined with mask limit tests, Eyeline Mode can quickly isolate the specific bit that caused a mask violation.

Traditional triggering methods on an equivalent time sampling scope are quite effective at generating eye diagrams. However, these eye diagrams are made up of samples whose timing relationship to the data pattern is effectively random, so a given eye will be made up of samples from many different bits in the pattern taken with no specific timing order. The result is that amplitude versus time trajectories of specific bits in the pattern are not visible. Also, averaging of the eye diagram is not valid, as the randomly related samples will effectively average to zero.

Eyeline Mode uses PatternLock triggering to build up an eye diagram from samples taken sequentially through the data pattern. This maintains a specific timing relationship between samples and allows Eyeline Mode to draw the eye based on specific bit trajectories. Effects of specific bit transitions can be investigated, and averaging can be used with the eye diagram.

Measurement speed

Measurement speed has been increased with both fast hardware and a user-friendly instrument. In the lab, don’t waste time trying to figure out how to make a measurement. With the simple-to-use 86100C, you don’t have to relearn how to make a measurement each time you use it.

Manufacturers are continually forced to reduce the cost per test. Solution: Fast PC-based processors, resulting in high measurement throughput and reduced test time.

Measurements

The following measurements are available from the tool bar, as well as the pull down menus. The available measurements depend on the DCA-J operating mode.

Oscilloscope mode

Time

Rise Time, Fall Time, Jitter RMS, Jitter p-p, Period, Frequency, + Pulse Width, - Pulse Width, Duty Cycle, Delta Time, [T

max

, T

min

, T

edge

—remote commands only]

Amplitude

Overshoot, Average Power, V amptd, V p-p, V rms, V top, V base, V max, V min, V avg

Eye/mask mode

NRZ eye measurements

Extinction Ratio, Jitter RMS, Jitter p-p, Average Power, Crossing Percentage, Rise Time, Fall Time, One Level, Zero Level, Eye Height, Eye Width, Signal to Noise (Q-Factor), Duty Cycle Distortion, Bit Rate, Eye Amplitude

RZ Eye Measurements

Extinction Ratio, Jitter RMS, Jitter p-p, Average Power, Rise Time, Fall Time, One Level, Zero Level, Eye Height, Eye Amplitude, Opening Factor, Eye Width, Pulse Width, Signal to Noise (Q-Factor), Duty Cycle, Bit Rate, Contrast Ratio

Mask Test

Open Mask, Start Mask Test, Exit Mask Test, Filter, Mask Test Margins, Mask Test Scaling, Create NRZ Mask

Jitter Mode

Jitter Mode requires Option 001 Enhanced Trigger hardware.

There are two analysis software packages for the DCA-J. Option 200 is the enhanced jitter analysis software, and Option 201 is the advanced waveform analysis software.

Measurements (Option 200 Jitter Analysis)

Total Jitter (TJ), Random Jitter (RJ), Deterministic Jitter (DJ), Periodic Jitter (PJ), Data Dependent Jitter (DDJ), Duty Cycle Distortion (DCD), Intersymbol Interference (ISI), Sub-Rate Jitter (SRJ)

Data Displays (Option 200 Jitter Analysis)

TJ histogram, RJ/PJ histogram, DDJ histogram, Composite histogram, DDJ versus Bit position, Bathtub curve, SRJ analysis

Measurements (Option 201 Advanced Waveform Analysis)

Pattern waveform

Data Displays (Option 201 Advanced Waveform Analysis)

Equalized waveform

TDR/TDT Mode (requires TDR module)

Quick TDR, TDR/TDT Setup, Normalize, Response, Rise Time, Fall Time, ∆ Time, Minimum Impedance, Maximum Impedance, Average Impedance, Single-ended and Mixed-mode S-parameters.

Standard Functions

Standard functions are available through pull down menus and soft keys, and some functions are also accessible through the front panel knobs.

Markers

Two vertical and two horizontal (user selectable)

TDR Markers

Horizontal — seconds or meter Vertical — volts, ohms or Percent Reflection Propagation — Dielectric Constant or Velocity

Limit tests

Acquisition limits

Limit Test Run Until Conditions — Off, # of Waveforms, # of Samples

Report Action on Completion — Save waveform to memory or disk, Save screen image to disk

Measurement limit test

Specify Number of Failures to Stop Limit Test When to Fail Selected Measurement — Inside Limits, Outside Limits, Always Fail, Never Fail Report Action on Failure - Save waveform to memory or disk, Save screen image to disk, Save summary to disk

Mask limit test

Specify Number of Failed Mask Test Samples Report Action on Failure — Save waveform to memory or disk, Save screen image to disk, Save summary to disk

Configure measurements

Thresholds

10%, 50%, 90% or 20%, 50%, 80% or Custom

Eye Boundaries

Define boundaries for eye measurments Define boundaries for alignment

Format Units for

Duty Cycle Distortion — Time or Percentage Extinction/Contrast Ratio — Ratio, Decibel

or Percentage Eye Height — Amplitude or Decibel (dB) Eye Width — Time or Ratio Average Power — Watts or Decibels (dB)

Top Base Definition

Automatic or Custom

∆ Time Definition

First Edge Number, Edge Direction, Threshold Second Edge Number, Edge Direction, Threshold

Jitter Mode

Units (time or unit interval) Signal type (data or clock) Measure based on edges (all, rising only, falling only) Graph layout ( single, split, quad)

Quick Measure Configuration

4 User Selectable Measurements for Each Mode

Default Settings (Eye/Mask Mode)

Extinction Ratio, Jitter RMS, Average Power, Crossing Percentage

Default Settings (Oscilloscope Mode)

Rise Time, Fall Time, Period, V amptd

Histograms

Configure

Histogram scale (1 to 8 divisions) Histogram axis (vertical or horizontal) Histogram window (adjustable Window via marker knobs)

Math measurements

4 User definable functions Operator — magnify, invert, subtract, versus, min, max

Source — channel, function, memory, constant, response (TDR)

Calibrate

All calibrations

Module (amplitude) Horizontal (time base) Extinction ratio Probe Optical channel

Front panel calibration output level

User selectable –2V to 2V

Utilities

Set time and date

Remote interface

Set GPIB interface

Touch screen configuration/calibration

Calibration Disable/enable touch screen

Upgrade software

Upgrade mainframe Upgrade module

Additional Capabilities

Built-in information system

The 86100C has a contextsensitive on-line manual providing immediate answers to your questions about using the instrument. Link s on the measurement screen take you directly to the information you need including algorithms for all of the measurements. The on-line manual includes technical specifications of the mainframe and plug-in modules. It also provides useful information such as the mainframe serial number, module serial numbers, firmware revision and date, and hard disk free space. There is no need for a large paper manual consuming your shelf space.

File sharing and storage

Use the internal 40 GB hard drive to store instrument setups, waveforms, or screen images. A 64MB USB memory stick is included with the mainframe. Combined with the USB port on the front panel this provides for quick and easy file transfer. Images can be stored in formats easily imported into various programs for documentation and further analysis. LAN interface is also available for network file management and printing. An external USB CD-RW drive is included with the mainframe. This enables easy installation of software applications as well as storage of large amounts of data.

Powerful display modes

Use gray scale and color graded trace displays to gain insight into device behavior. Waveform densities are mapped to color or easy-to-interpret gray shades. These are infinite persistence modes where shading differentiates the number of times data in any individual screen pixel has been acquired.

Direct triggering through clock recovery

Typically an external timing reference is used to synchronize the oscilloscope to the test signal. In cases where a trigger signal is not available, clock recovery modules are available to derive a timing reference directly from the waveform to be measured. The Agilent 8349XA series of clock recovery modules are available for electrical, multimode optical, and single-mode optical input signals. All 8349XA modules have excellent jitter performance to ensure accurate measurements. Each clock recovery module is designed to synchronize to a variety of common transmission rates. The 83496A can derive triggering from optical and electrical signals at any rate from 50 Mb/s to 13.5 Gb/s.

Clock recovery loop bandwidth

The Agilent clock recovery modules have adjustable loop bandwidth settings. Loop bandwidth is very important in determining the accuracy of your waveform when measuring jitter, as well as testing for compliance. When using recovered clocks for triggering, the amount of jitter observed will depend on the loop bandwidth. As the loop bandwidth increases, more jitter is “tracked out” by the clock recovery resulting in less observed jitter.

• Narrow loop bandwidth provides a “jitter free” system clock to observe all the jitter

• Wide loop bandwidth in some applications is specified in the standards for compliance testing. Wide loop bandwidth settings mimic the performance of communications system receivers

The 83496A has a continuously adjustable loop bandwidth from as low as 30 kHz to as high as 10 MHz, and can be configured as a golden PLL for standards compliance testing.

S-parameters and time domain reflectometery/time domain transmission (TDR/TDT)

High-speed design starts with the physical structure. The transmission and reflection properties of electrical channels and components must be characterized to ensure sufficient signal integrity, so reflections and signal distortions must be kept at a minimum. Use TDR and TDT to optimize microstrip lines, backplanes, PC board traces, SMA edge launchers and coaxial cables.

Analyze return loss, attenuation, crosstalk, and other S-parameters with one button push using the 86100C Option 202 Enhanced Impedance and S-parameter software, either in single-ended or mixed-mode signals.

Calibration techniques, unique to the 86100C, provide highest precision by removing cabling and fixturing effects from the measurement results. Translation of TDR data to complete single-ended, differential, and mixed mode S-parameters are available through the N1930A Physical Layer Test System software. Higher two-event resolution and ultra high-speed impedance measurements are facilitated through TDR pulse enhancers from Picosecond Pulse Labs

Waveform autoscaling

Autoscaling provides quick horizontal and vertical scaling of both pulse and eye-diagram (RZ and NRZ) waveforms.

Gated triggering

Trigger gating port allows easy external control of data acquisition for circulating loop or burst-data experiments. Use TTL-compatible signals to control when the instrument does and does not acquire data.

Easier calibrations

Calibrating your instrument has been simplified by placing all the performance level indicators and calibration procedures in a single high-level location. This provides greater confidence in the measurements made and saves time in maintaining equipment.

Stimulus response testing Using the Agilent N490XA Serial BERT

Error performance analysis represents an essential part of digital transmission test. The Agilent 86100C and N490XA Serial BERT have similar user interfaces and together create a powerful test solution.

Transitioning from the Agilent 83480A and 86100A/B to the 86100C

While the 86100C has powerful new functionality that its predecessors don’t have, it has been designed to maintain compatibility with the Agilent 86100A, 86100B and Agilent 83480A digital communications analyzers and Agilent 54750A wide-bandwidth oscilloscope. All modules used in the Agilent 86100A/B, 83480A and 54750A can also be used in the 86100C. The remote programming command set for the 86100C has been designed so that code written for the 86100A or 86100B will work directly. Some code modifications are required when transitioning from the 83480A and 54750A, but the command set is designed to minimize the level of effort required.

IVI-COM capability

Interchangeable Virtual Instruments (IVI) is a group of new instrument device software specifications created by the IVI Foundation to simplify interchangeability, increase application performance, and reduce the cost of test program development and maintenance through design code reuse. The 86100C IVI-COM drivers are available for download from the Agilent website.

Picosecond Pulse Labs (www.picosecond.com)

Lowest intrinsic jitter

The patented 86107A precision timebase reference module represents one of the most significant improvements in wide-bandwidth sampling oscilloscopes in over a decade. Jitter performance has been reduced by almost an order of magnitude to < 200 fs RMS. Oscilloscope jitter is virtually eliminated! The reduced jitter of the 86107A precision timebase module allows you to measure the true jitter of your signal. When using the 86107A, the minimum timebase resolution for oscilloscope and eye/mask displays is 500 fs/division, rather than 2 ps/div with the standard timebase.

The same 40 GHz sinewave

captured using current DCA (top)

and now with 86107A precision

timebase module (bottom).

The standard timebase of the 86100C has very low intrinsic jitter compared to other advanced waveform analysis solutions. However, for users who need the most accurate sensitivity for their jitter measurements, the 86107A provides the ultimate timebase performance. Using the 86107A with Jitter Mode requires the Option 200 Enhanced Jitter software package. Jitter measurements with the 86107A are targeted at users who are trying to accurately measure very low levels of jitter and need to minimize the jitter contribution of the scope.

The 86107A requires an electrical reference clock that is synchronous with the signal under test. For specific requirements of the clock signal, see the 86107A specifications on page 11.

Accurate views of your 40 Gb/s waveforms

When developing 40 Gb/s devices, even a small amount of inherent scope jitter can become significant since 40 Gb/s waveforms only have a bit period of 25 ps. Scope jitter of 1ps RMS can result in 6 to 9 ps of peak-to-peak jitter, causing eye closure even if your signal is jitter-free. The Agilent 86107A reduces the intrinsic jitter of 86100 family mainframes to the levels necessary to make quality waveform measurements on 40 Gb/s signals.

Meeting your growing need for more bandwidth

Today’s communication signals have significant frequency content well beyond an oscilloscope’s 3-dB bandwidth. A high-bandwidth scope does not alone guarantee an accurate representation of your waveform. Careful design of the scope’s frequency response (both amplitude and phase) minimizes distortion such as overshoot and ringing.

The Agilent 86116A and 86116B are plug-in modules that include an integrated optical receiver designed to provide the optimum in bandwidth, sensitivity, and waveform fidelity. The 86116B extends the bandwidth of the 86100C infiniium DCA-J to 80 GHz electrical, 65 GHz optical in the 1550 nm wavelength band. The 86116A covers the 1300 nm and 1550 nm wavelength bands with 63 GHz of electrical bandwidth and 53 GHz of optical bandwidth. The 86117A and 86118A modules provide electrical bandwidth to 50 GHz and 70 gHz respectively. You can build the premier solution for 40 Gb/s waveform analysis around the 86100 mainframe that you already own.

Performing return-to-zero (RZ) waveform measurements

An extensive set of automatic RZ measurements are built-in for the complete characterization of return-to-zero (RZ) signals at the push of a button.

Temperature

Operating 10 °C to +40 °C (50 °F to +104 °F) Non-operating –40 °C to +65 °C (–40 °F to +158 °F)

Humidity

Operating Up to 90% humidity (non-condensing) at +40 °C (+104 °F) Non-operating Up to 95% relative humidity at +65 °C (+149 °F)

Altitude

Operating Up to 4,600 meters (15,000 ft) Non-operating Up to 15,300 meters (50,000 ft)

Vibration

Operating Random vibration 5 to 500 Hz, 10 minutes per axis, 0.21 g (rms) Non-operating Random vibration 5 to 500 Hz, 10 minutes per axis, 0.3 g (rms); Resonant search, 5 to 500 Hz

swept sine, 1 octave/min sweep rate, 0.5 g, 5 minute resonant dwell at 4 resonances/axis

Power requirements

Voltage 90 to 132 or 198 to 264 Vac, 48 to 66 Hz Power (including modules) 604 VA; 391 W

Weight

Mainframe without modules 15.5 kg (34 lb) Typical module 1.2 kg (2.6 lb)

Mainframe dimensions (excluding handle)

Without front connectors and rear feet 215.1 mm H x 425.5 mm W x 566 mm D (8.47 in x 16.75 in x 22.2 in) With front connectors and rear feet 215.1 mm H x 425.5 mm W x 629 mm D (8.47 in x 16.75 in x 24.8 in)

Specifications

Mainframe specifications

HORIZONTAL SYSTEM (time base) PATTERN LOCK Scale factor (full scale is ten divisions)

Minimum 2 ps/div (with 86107A: 500 fs/div) Maximum 1 s/div 250 ns/div

Delay

Minimum 24 ns 40.1 ns Maximum 1000 screen diameters or 10 s, 1000 screen diameters or 25.401 µs,

whichever is smaller whichever is smaller

Time interval accuracy

1 ps + 1.0% of ∆ time reading

8 ps + 0.1% of ∆ time reading

Time interval accuracy – jitter mode operation

1 ps

Time interval accuracy – with 86107A < 200 fs

precision timebase

Time interval resolution ≤ (screen diameter)/(record length) or 62.5 fs,

whichever is larger

Display units Bits or time (TDR mode–meters)

VERTICAL SYSTEM (channels) Number of channels 4 (simultaneous acquisition) Vertical resolution 14 bit A/D converter (up to 15 bits with averaging) Full resolution channel scales Adjusts in a 1-2-5-10 sequence for coarse adjustment or fine adjustment resolution

from the front panel knob

Adjustments Scale, offset, activate filter, sampler bandwidth, attenuation factor, transducer conversion factors Record length 16 to 4096 samples – increments of 1

Specifications describe warranted performance over the temperature range of +10 °C to +40 °C (unless otherwise noted). The specifications are applicable for the temperature after the instrument is turned on for one (1) hour, and while self-calibration is valid. Many performance parameters are enhanced through frequent, simple user calibrations. Characteristics provide useful, non-warranted information about the functions and

performance of the instrument. Characteristics are printed in italic typeface.

Factory Calibration Cycle -For optimum performance, the instrument should have a complete verification of specifications once every twelve (12) months.

General specifications

This instrument meets Agilent Technologies’ environmental specifications (section 750) for class B-1 products with exception as described for temperature and condensation. Contact your local field engineer for complete details. Product specifications and descriptions in this document subject to change without notice.

Time offset relative to the front panel trigger input on the instrument mainframe.

Dual marker measurement performed at a temperature within ±5 °C of horizontal calibration temperature.

Delay settings: ∆ time is in the range (26 + N*4 ns) ±1.9 ns, where N = 0, 1, 2, ... 17.

Characteristic performance. Test configuration: PRBS of length 27– 1 bits, Data and Clock 10 Gb/s.

Mainframe specifications (continued)

Standard (direct trigger) Option 001 (enhanced trigger)

Trigger Modes

Internal trigger

Free run

External direct trigger

Limited bandwidth

DC to 100 MHz

Full bandwidth DC to 3.2 GHz External Divided Trigger N/A 3 GHz to 13 GHz (3 GHz to 15 GHz) PatternLock N/A 50 MHz to 13 GHz (50 MHz to 15 GHz)

Jitter

Characteristic < 1.0 ps RMS + 5*10E-5 of delay setting

1.2 ps RMS for time delays less than 100 ns

Maximum 1.5 ps RMS + 5*10E-5 of delay setting

1.7 ps RMS for time delays less than 100 ns

Trigger sensitivity 200 m Vpp (sinusoidal input or 200 m Vpp sinusoidal input: 50 MHz to 8 GHz

200 ps minimum pulse width) 400 m Vpp sinusoidal input: 8 GHz to 13 GHz

600 m Vpp sinusoidal input: 13 GHz to 15 GHz

Trigger configuration

Trigger level adjustment –1 V to + 1 V AC coupled Edge select Positive or negative N/A Hysteresis

Normal or high sensitivity N/A

Trigger gating

Gating input levels Disable: 0 to 0.6 V (TTL compatible) Enable: 3.5 to 5 V

Pulse width > 500 ns, period > 1 µs

Gating delay Disable: 27 ns + trigger period +

Max time displayed Enable: 100 ns

Trigger impedance

Nominal impedance 50 Ω Reflection 10% for 100 ps rise time Connector type 3.5 mm (male) Maximum trigger signal 2 V peak-to-peak

Precision time base 86107A

86107A Option 010 86107A Option 020 86107A Option 040

Trigger bandwidth 2.4 to 15.0 GHz 2.4 to 25.0 GHz 2.4 to 48.0 GHz Typical jitter (RMS) 2.4 to 4.0 GHz trigger: < 280 fs 2.4 to 4.0 GHz < 200 fs 2.4 to 4.0 GHz < 200 fs

4.0 to 15.0 GHz trigger: < 200 fs 4.0 to 25.0 GHz < 200 fs 4.0 to 48.0 GHz < 200 fs

Time base linearity error < 200 fs Input signal type Synchronous clock

Input signal level 0.5 to 1.0 Vpp

0.2 to 1.5 Vpp (Typical functional performance)

DC offset range ±200 mV

Required trigger signal-to-noise ratio ≥ 200 : 1 Trigger gating Disable: 0 to 0.6 V Gating input levels (TTL compatible) Enable: 3.5 to 5 V

Pulse width > 500 ns, period > 1 µs

Trigger impedance (nominal) 50 Ω Connector type 3.5 mm (male) 3.5 mm (male)

2.4 mm (male)

Requires 86100 software revision 4.1 or above.

Filtering provided for Option 010 bands 2.4 to 4.0 GHz and 9.0 to 12.6 GHz, for Option 020 9.0 to 12.6 GHz and 18 to 25.0 GHz, for Option 40 9.0 to 12.6 GHz, 18.0 to 25.0 GHz, and 39.0 to

48.0 GHz. Within the filtered bands, a synchronous clock signal should be provided (clock, sinusoid, BERT trigger, etc.). Outside these bands, filtering is required to minimize harmonics and sub harmonics and provide a sinusoid to the 86107 input.

For the 86107A with Option 020, the Agilent 11742A (DC Block) is recommended if the DC offset magnitude is greater than 200 mV.

The freerun trigger mode internally generates an asynchronous trigger that allows viewing the sampled signal amplitude without an external trigger signal but provides no timing information. Freerun is useful in

troubleshooting external trigger problems.

The sampled input signal timing is recreated by using an externally supplied trigger signal that is synchronous with the sampled signal input.

The DC to 100 MHz mode is used to minimize the effect of high frequency signals or noise on a low frequency trigger signal.

Measured at 2.5 GHz with the triggering level adjusted for optimum trigger.

High Sensitivity Hysteresis Mode improves the high frequency trigger sensitivity but is not recommended when using noisy, low frequency signals that may result in false triggers without normal hysteresis enabled.

Slew rate ≥ 2V/ns

Computer system and storage

CPU 1 GHz microprocessor Mass storage 40 GByte internal hard drive

External USB CD-RW drive 64 MB USB pen memory

Operating System Microsoft Windows

XP Pro

DISPLAY

Display area 170.9 mm x 128.2 mm (8.4 inch diagonal color active matrix LCD module incorporating amorphous

silicon TFTs)

Active display area 171mm x 128 mm (21,888 square mm) 6.73 in x 5.04 in (33.92 square inches) Waveform viewing area 103 mm x 159 mm (4.06 in x 6.25 in) Entire display resolution 640 pixels horizontally x 480 pixels vertically Graticule display resolution 451 pixels horizontally x 256 pixels vertically Waveform colors Select from 100 hues, 0 to 100% saturation and 0 to 100% luminosity Persistence modes Gray scale, color grade, variable, infinite Waveform overlap When two waveforms overlap, a third color distinguishes the overlap area Connect-the-dots On/Off selectable Persistence Minimum, variable (100 ms to 40 s), infinite Graticule On/Off Grid intensity 0 to 100% Backlight saver 2 to 8 hrs, enable option Dialog boxes Opaque or transparent

FRONT PANEL INPUTS AND OUTPUTS Cal output BNC (female) and test clip, banana plug Trigger input APC 3.5 mm, 50 Ω, 2 Vpp base max USB

REAR PANEL INPUTS AND OUTPUTS Gated trigger input TTL compatible Video output VGA, full color, 15 pin D-sub (female) 10 GPIB Fully programmable, complies with IEEE 488.2 RS-232 Serial printer, 9 pin D-sub (male) Centronics Parallel printer port, 25 pin D-sub (female) LAN USB

(2)

Supports external display. Supports multiple display configurations via Windows®XP Pro display utility.

USB Keyboard and mouse included with mainframe. Keyboard has intergrated, 2-port USB hub.

MS-DOS and Windows XP Pro are U.S. registered trademarks of Microsoft Corporation.

Optical/electrical modules

750-1650 nm

The 86105C has the widest coverage of data rates with optical bandwidth of 9 GHz and electrical bandwidth of 20 GHz. The outstanding sensitivity up to –21 dBm makes the 86105C ideal for a wide range of design and manufacturing applications. Available filters cover all common data rates from 155 Mb/s through 11.3 Gb/s.

750-860 nm

The 86101A and 86102U modules support waveform compliance testing of short wavelength signals with up to 15 GHz of optical bandwidth and 20 GHz of electrical bandwidth.

1000–1600 nm

< 20 GHz Optical and Electrical Channels:

The 86103A and 86105B modules are optimized for testing long wavelength signals with up to 15 GHz of optical bandwidth. Each module also has an electrical channel with 20 GHz of bandwidth.

The 86105B provides the high pulse fidelity and sensitivity, and flexible data rates. It is the recommended module for 10 Gb/s compliance applications. The 86103A is recommended when sensitivity is the dominant requirement, as its amplified O/E converter provides the best sensitivity.

20 to 40 GHz Optical and Electrical Channels:

The 86106B has 28 GHz of optical bandwidth with multiple 10Gb/s compliance filters, and has an electrical channel with 40 GHz of bandwidth.

40 GHz and Greater Optical and Electrical Channels:

The 86116A is optimized for testing 40 Gb/s signals. The 86116A has more than 50 GHz of optical bandwidth and 60 GHz of electrical bandwidth. The 86116B is the widest bandwidth optical module with more than 65 GHz optical (1550nm band only) and 80 GHz electrical bandwidth.

Dual electrical modules

86112A has two low-noise electrical channels with 20 GHz of bandwidth.

86117A has two electrical channels with up to 50 GHz of bandwidth ideal for testing signals up to 10 Gb/s.

86118A has two electrical channels, each housed in a compact remote sampling head, attached to the module with separate light weight cables. With over 70 GHz of bandwidth, this module is intended for high bit rate applications where signal fidelity is crucial.

Clock recovery modules

Unlike realtime oscilloscopes, equivalent time sampling oscilloscopes like the 86100 require a timing reference or trigger that is separate from the signal being observed. This is often achieved with a clock signal that is synchronous to the signal under test. Another approach is to derive a clock from the test signal with a clock recovery module.

The 83496A provides the highest performance/flexibility as it is capable of operation at any data rate from 50 Mb/s to 13.5 Gb/s, on single-ended and differential electrical signals, single-mode (1250 to 1620 nm) and multimode (780 to 1330 nm) optical signals, with extremely low residual jitter. PLL loop bandwidth is adjustable to provide optimal jitter filtering according to industry test standards.

The 83495A works for optical and electrical signals and has either multimode (750 to 860 nm) or single mode (1000 to 1600 nm) inputs. It operates over a continuous range of rates from 9.95 Gb/s to 11.3 Gb/s and has both low and high loop BW settings.

Time domain reflectometry (TDR)

The infiniium DCA-J may also be used as a powerful, high accuracy TDR, using the 54754A differential TDR module.

Module overview

Filtered data rates

86100 family plug-in module matrix

Module

Option

No. of optical channels

No. of electrical channels

Wavelength range (nm)

Unfiltered optical bandwidth (GHz)

Electrical bandwidth (GHz)

Fiber input (µm)

Mask test sensitivity (dBm)

155 Mb/s

622 Mb/s

1063 Mb/s

1250 Mb/s

2125 Mb/s

2488/2500 Mb/s

2.666 Gb/s

2.72 Gb/s

3.125 Gb/s

3.1875 Gb/s

3.32 Gb/s

4.25 Gb/s

9.953 Gb/s

8.500 Gb/s

10.3125 Gb/s

10.51875 Gb/s

10.664 Gb/s

10.709 Gb/s

11.095 Gb/s

11.317 Gb/s

The 86100 has a large family of plug-in modules designed for a broad range of data rates for optical and electrical waveforms. The 86100 can hold up to 2 modules for a total of 4 measurement channels.

Optical/

electrical

Dual

electrical

86101A 201 1 1 750-860 2.85 20 62.5 –17 ■■

202 1 1 750-860 2.85 20 62.5 –17 ■■

86102U 201 1 1 750-860 15 20 62.5 –7.5 ■■

202 1 1 750-860 15 20 62.5 –7.5 ■■ 203 1 1 750-860 15 20 62.5 –7.5 ■■

86103A 201 1 1 1000-1600 2.85 20 62.5 –20 ■■

202 1 1 1000-1600 2.85 20 62.5 –20 ■■

86105B 101 1 1 1000-1600 15 20 9 –12 ■■■■■

102 1 1 1000-1600 15 20 9 –12 ■■ ■ ■ ■■■■■ 103 1 1 1000-1600 15 20 9 –12 ■■■■ ■■■■■

86105C 100* 1 1 750-1650 8.5 20 62.5 –20 ■■■■■■■ ■ ■■

200 1 1 750-1650 8.5 20 62.5 –16 ■■■■■■■

300* 1 1 750-1650 8.5 20 62.5 –16 ■■■■■■■ ■ ■■■■■■■■■

86106B 1 1 1000-1600 28 40 9 –7 ■■ ■

410 1 1 1000-1600 28 40 9 –7 ■■■■■ 86116A 1 1 1000-1600 53 63 9 N/A 86116B 1 1 1480-1620 65 80 9 N/A

54754A 0 2 N/A 18 86112A 0 2 N/A 20 86117A 0 2 N/A 50 86118A 0 2 N/A 70

*Pick any 4 rates (155 Mb/s to 4.25 Gb/s)

Multimode and single-mode 86101A 86102U

OPTICAL CHANNEL SPECIFICATIONS Optical channel unfiltered bandwidth 2.85 GHz (3 GHz typical) 15 GHz Wavelength range 750 to 860 nm Calibrated wavelengths 850 nm Optical sensitivity

–17 dBm –7.5 dBm

Transition time (10% to 90% calculated from TR = 0.48/BW optical) Unfiltered 160 ps 32 ps

RMS noise

Characteristic 1.5 µW 14 µW Maximum 2.5 µW 20 µW Scale factor (per division) Minimum 5 µW 20 µW Maximum 100 µW 500 µW CW accuracy (single marker, referenced to ±6 µW ±0.4% of full scale ±25 µW ±2% of (reading-channel offset), 15 GHz average power monitor, <50 µW/division) ±3% of (reading-channel offset) CW offset range (referenced two divisions from screen bottom) +0.2 mW to –0.6 mW +1 mW to –3 mW

Average power monitor

(specified operating range) –30 dBm to –2.2 dBm –27 dBm to +3 dBm

Factory calibrated accuracy ±5% ±100 nW ±connector uncertainty, 20 °C to 30 °C User calibrated accuracy ±2% ±100 nW ±power meter uncertainty, < 5 °C change Maximum input power

Maximum non-destruct average 0.4 mW (–4 dBm) 2 mW (+3 dBm) Maximum non-destruct peak 10 mW (+10 dBm)

Fiber input 62.5/125 µm, user selectable connector Input return loss

(HMS-10 connector fully filled fiber) 20 dB

ELECTRICAL CHANNEL SPECIFICATIONS Electrical channel bandwidth 12.4 and 20 GHz Transition time 28.2 ps (12.4 GHz)

(10% to 90%, calculated from TR = 0.35/BW) 17.5 ps (20 GHz)

RMS noise 0.25 mV (12.4 GHz)

Characteristic 0.5 mV (20 GHz) Maximum 0.5 mv (12.4 GHz)

1 mV (20 GHZ)

Scale factor

Minimum 1 mV/division Maximum 100 mV/division DC accuracy (single marker) ±0.4% of full scale ± 2 mV ±1.5% of (reading-channel offset), 12.4 GHz

±0.4% of full scale ± 2 mV ±3% of (reading-channel offset), 20 GHz

DC offset range (referenced to center of screen) ±500 mV Input dynamic range (relative to channel offset) ±400 mV Maximum input signal ±2 V (+16 dBm) Nominal impedance 50 Ω Reflections (for 30 ps rise time) 5% Electrical input 3.5 mm (male)

Module specifications: single-mode & multimode optical/electrical

Smallest average optical power required for mask test. Values represent typical sensitivity of NRZ eye diagrams. Assumes mask test with complicance filter switched in.

Multimode and single-mode Optical/electrical modules 86103A OPTICAL CHANNEL SPECIFICATIONS Optical channel unfiltered bandwidth 2.85 GHz Wavelength range 1000 to 1600 nm Calibrated wavelengths 1310 nm/1550 nm Optical sensitivity

–20 dBm Opt 201 –18 dBm Opt 202

Transition time (10% to 90% calculated from TR = 0.48/BW optical) 160 ps

RMS noise

Characteristic 0.75 µW Opt 201

1.0 µW Opt 202

Maximum 1.5 µW Opt 201

2.5 µW Opt 202 Scale factor (per division) Minimum 5 µW Maximum 100 µW CW accuracy (single marker, ±6 µW ±0.4% of full scale referenced to average power monitor) ±3% of (reading-channel offset) CW offset range (referenced two divisions from screen bottom) +0.2 mW to –0.6 mW

Average power monitor

(specified operating range) –30 dBm to 0 dBm

Factory calibrated accuracy

Single mode

±5% ±100 nW ±connector uncertainty

(20 °C to 30 °C)

Multi mode

±10% ±100 nW ±connector uncertainty

(20 °C to 30 °C)

User calibrated accuracy ±2% ±100 nW ±power meter uncertainty, < 5 °C change Maximum input power

Maximum non-destruct average 0.4 mW (–4 dBm) Maximum non-destruct peak 10 mW (+10 dBm)

Fiber input 62.5/125 µm, user selectable connector Input return loss

(HMS-10 connector fully filled fiber) 20 dB

ELECTRICAL CHANNEL SPECIFICATIONS Electrical channel bandwidth 12.4 and 20 GHz Transition time 28.2 ps (12.4 GHz)

(10% to 90%, calculated from TR = 0.35/BW) 17.5 ps (20 GHz)

RMS noise

Characteristic 0.25 mV (12.4 GHz)

0.5 mV (20 GHz)

Maximum 0.5 mv (12.4 GHz)

1 mV (20 GHz)

Scale factor

Minimum 1 mV/division Maximum 100 mV/division DC accuracy (single marker) ±0.4% of full scale ±2 mV ±1.5% of (reading-channel offset), 12.4 GHz

±0.4% of full scale ±2 mV ±3% of (reading-channel offset), 20 GHz DC offset range (referenced to center of screen) ±500 mV

Input dynamic range

(relative to channel offset) ±400 mV

Maximum input signal ±2 V (+16 dBm) Nominal impedance 50 Ω Reflections (for 30 ps rise time) 5% Electrical input 3.5 mm (male)

Module specifications: single-mode & multimode optical/electrical

(continued)

Smallest average optical power required for mask test. Values represent typical sensitivity

of NRZ eye diagrams. Assumes mask test with complicance filter switched in.

Multimode and single-mode Optical/electrical modules 86105B 86105C OPTICAL CHANNEL SPECIFICATIONS Optical channel unfiltered bandwidth 15 GHz 8.5 GHz (9 GHz) Wavelength range 1000 to 1600 nm 750 to 1650 nm Calibrated wavelengths 1310 nm/1550 nm 850 nm/1310 nm/1550 nm (±20 nm) Optical sensitivity

–12 dBm 850 nm

≤ 2.666 Gb/s, –20 dBm > 2.666 Gb/s to ≤ 4.25 Gb/s, –19 dBm > 4.25 Gb/s to 11.3 Gb/s, –16 dBm

1310 nm/1550 nm

≤ 2.666 Gb/s, –21 dBm > 2.666 Gb/s to ≤ 4.25 Gb/s, –20 dBm > 4.25 Gb/s to 11.3 Gb/s, –17 dBm

Transition time (10% to 90% calculated from TR = 0.48/BW optical) 32 ps 56 ps

RMS noise

Characteristic 5 µW, (10 GHz) 850 nm

12 µW, (15 GHz) ≤ 2.666 Gb/s, 1.3 µW

> 2.666 Gb/s to ≤ 4.25 Gb/s, 1.5 µW > 4.25 Gb/s to 11.3 Gb/s, 2.5 µW

1310 nm/1550 nm

≤ 2.666 Gb/s, 0.8 µW > 2.666 Gb/s to ≤ 4.25 Gb/s, 1.0 µW > 4.25 Gb/s to 11.3 Gb/s, 1.4 µW

Maximum 8 µW, (10 GHz) 850 nm

15 µW (15 GHz) ≤ 2.666 Gb/s, 2.0 µW

> 2.666 Gb/s to ≤ 4.25 Gb/s, 2.5 µW > 4.25 Gb/s to 11.3 Gb/s, 4.0 µW

1310 nm/1550 nm

≤ 2.666 Gb/s, 1.3 µW > 2.666 Gb/s to ≤ 4.25 Gb/s, 1.5 µW

> 4.25 Gb/s to 11.3 Gb/s, 2.5 µW Scale factor (per division) Minimum 20 µW 2 µW Maximum 500 µW 100 µW CW accuracy (single marker,

±25 µW ±2% (10 GHz) ±25 µW ±3%

referenced to average power monitor) ±25 µW ±4%

(

15 GHz) ±25 µW ±10%

CW offset range (referenced two divisions from screen bottom) +1 µW to –3 µW +0.2 µW to –0.6 µW

Average power monitor

(specified operating range) –30 dBm to +3 dBm –30 dBm to 0 dBm

Average power monitor accuracy

Single mode

±5% ±100 nW ±connector uncertainty

(20 °C to 30 °C)

±5% ±200 nW ±connector uncertainty

Multi mode (characteristic)

N/A

±10% ±200 nW ±connector uncertainty

User calibrated accuracy

Single mode ±2% ±100 nW ±power meter uncertainty, ±3% ±200 nW ±power meter uncertainty,

< 5 °C change < 5 °C change

Multi mode (characteristic)

N/A

±10% ±200 nW ±power meter uncertainty, < 5 °C change

Maximum input power

Maximum non-destruct average 2 mW (+3 dBm) 0.5 mW (–3 dBm) Maximum non-destruct peak 10 mW (+10 dBm) 5 mW (+7 dBm)

Fiber input 9/125 µm user selectable connector 62.5/125 µm Input return loss

(HMS-10 connector fully filled fiber) 33 dB 850 nm

> 13 dB ,

1310 nm/1550 nm

>24 dB

Module specifications: single-mode & multimode optical/electrical

(continued)

Smallest average optical power required for mask test. Values represent typical sensitivity of NRZ eye diagrams. Assumes mask test with complicance filter switched in.

Multimode and single-mode Optical/electrical modules 86105B 86105C ELECTRICAL CHANNEL SPECIFICATIONS Electrical channel bandwidth 12.4 and 20 GHz Transition time 28.2 ps (12.4 GHz)

(10% to 90%, calculated from TR = 0.35/BW) 17.5 ps (20 GHz)

RMS noise

Characteristic 0.25 mV (12.4 GHz)

0.5 mV (20 GHz)

Maximum 0.5 mv (12.4 GHz)

1 mV (20 GHz)

Scale factor

Minimum 1 mV/division Maximum 100 mV/division DC accuracy (single marker) ±0.4% of full scale ±2 mV ±1.5% of (reading-channel offset), 12.4 GHz

±0.4% of full scale ±2 mV ±3% of (reading-channel offset), 20 GHz DC offset range (referenced to center of screen) ±500 mV

Input dynamic range

(relative to channel offset) ±400 mV

Maximum input signal ±2 V (+16 dBm) Nominal impedance 50 Ω Reflections (for 30 ps rise time) 5% Electrical input 3.5 mm (male)

Module specifications: single-mode & multimode optical/electrical

(continued)

High bandwidth, single-mode Optical/electrical modules 86106B 86116A

86116B

OPTICAL CHANNEL SPECIFICATIONS Optical channel unfiltered bandwidth 28 GHz 53 GHz 65 GHz (best pulse fidelity) Wavelength range 1000 to 1600 nm 55 GHz (best sensitivity) Calibrated wavelengths 1310/1550 nm 1480 to 1620 nm Optical sensitivity

–7 dBm

Transition time (10% to 90%, calculated from TR = 0.48/BW optical) 18 ps 9.0 ps (FWHM)

7.4 ps (FWHM)

RMS noise

Characteristic 13 µW (Filtered) 60 µW (50 GHz) 50 µW (55 GHz)

23 µW (Unfiltered) 190 µW (53 GHz) 140 µW (65 GHz)

Maximum 15 µW (Filtered) 90 µW (50 GHz) 85 µW (55 GHz)

30 µW (Unfiltered) 260 µW (53 GHz) 250 µW (65 GHz)

Scale factor

Minimum 20 µW/division 200 µW/division Maximum 500 µW/division 2.5 mW/division 5 mW/division CW accuracy (single marker, ±50 µW ±4% of referenced to average power monitor) (reading-channel offset) ± 150 µW ± 4% of (reading-channel offset) CW offset range (referenced two divisions from screen bottom) +1 mW to –3 mW +5 mW to –15mW +8 to –12 mW

Average power monitor

(specified operating range) –27 dBm to +3 dBm –23 dBm to +9 dBm

Factory calibrated accuracy ±5% ±100 nW ±connector uncertainty, 20 °C to 30 °C User calibrated accuracy ±2% ±100 nW ±power meter uncertainty, < 5 °C change Maximum input power

Maximum non-destruct average 2 mW (+3 dBm) 10 mW (+10 dBm) Maximum non-destruct peak 10 mW (+10 dBm) 50 mW (+17 dBm)

Fiber input 9/125 µm, user selectable connector Input return loss

(HMS-10 connector fully filled fiber) 30 dB 20 dB

86116A and 86116B requires the 86100 software revision A.3.0 or above.

FWHM (Full Width Half Max) as measured from optical pulse with 700 fs FWHM, 5 MHz repetition rate and 10 mW peak power.

Smallest average optical power required for mask test. Values represent typical sensitivity of NRZ eye diagrams. Assumes mask test with compliance filter switched in.

ELECTRICAL CHANNEL SPECIFICATIONS Electrical channel bandwidth 18 and 40 GHz 43 and 63 GHz 80, 55 and 30 GHz Transition time (10% to 90%, 19.5 ps (18 GHz) 8.1 ps (43 GHz) 6.4 ps (55 GHz)

calculated from TR = 0.35/BW) 9 ps (40 GHz) 5.6 ps (63 GHz) 4.4 ps (80 GHz)

RMS noise

Characteristic 0.25 mV (18 GHz) 0.6 mV (43 GHz) 0.6 mV (55 GHz)

0.5 mV (40 GHz) 1.7 mV (63 GHz) 1.1 mV (80 GHz)

Maximum 0.5m V (18 GHz) 0.9 mV (43 GHz) 1.1 mV (55 GHz)

1.0 mV (40 GHz) 2.5 mV (63 GHz) 2.2 mV (80 GHz)

Scale factor

Minimum 1 mV/division 2 mV/division Maximum 100 mV/division 100 mV/division DC accuracy (single marker) ±0.4% of full scale ±0.8% of full scale ±0.4% of full scale

±2 mV ±1.5% of (reading- ±2 mV ±1.5% of (reading- ±3 mV ±2% of (readingchannel offset), 18 GHz channel offset), 43 GHz channel offset), ±2% of ±0.4% of full scale ±2.5% of full scale offset (all bandwidths) ±2 mV ±3% of (reading- ±2 mV ±2% of (reading-

channel offset), 40 GHz channel offset), 63 GHz DC offset range (referenced to center of screen) ±500 mV

Input dynamic range

(relative to channel offset) ±400 mV

Maximum input signal ±2 V (+16 dBm) Nominal impedance 50 Ω Reflections (for 20 ps rise time) 5% 10% (DC to 70 GHz)

20% (70 to 100 GHz)

Electrical input 2.4 mm (male) 1.85 mm (male)

Module specifications: single-mode optical/electrical

Dual electrical channel modules 86112A 54754A Electrical channel bandwidth 12.4 and 20 GHz 12.4 and 18 GHz Transition time (10% to 90%, 28.2 ps (12.4 GHz); 28.2 ps (12.4 GHz);

calculated from TR = 0.35/BW) 17.5 ps (20 GHz) 19.4 ps (18 GHz)

RMS noise

Characteristic 0.25 mV (12.4 GHz); 0.25 mV (12.4 GHz);

0.5 mV (20 GHz) 0.5 mV (18 GHz)

Maximum 0.5 mv (12.4 GHz); 0.5 mv (12.4 GHz);

1 mV (20 GHz) 1 mV (18 GHz)

Scale factor

Minimum 1 mV/division Maximum 100 mV/division DC accuracy (single marker) ±0.4% of full scale ±0.4% of full scale

±2 mV ±1.5% of (reading-channel offset), 12.4 GHz ±2mV ±0.6% of (reading-channel offset), 12.4 GHz ±0.4% of full scale ±0.4% of full scale or marker reading ±2 mV ±3% of (reading-channel offset), 20 GHz (whichever is greater)

±2 mV ±1.2% of (reading-channel offset), 18 GHz CW offset range (referenced from center of screen) ±500 mV Input dynamic range (relative to channel offset) ±400 mV

Maximum input signal ±2 V (+16 dBm) Nominal impedance 50 Ω Reflections (for 30 ps rise time) 5% Electrical input 3.5 mm (male)

Module specifications: dual electrical

Dual electrical channel modules 86117A 86118A Electrical channel bandwidth 30 and 50 GHz 50 and 70 GHz Transition time (10% to 90%, 11.7 ps (30 GHz)

calculated from TR = 0.35/BW) 7 ps (50 GHz)

RMS noise

Characteristic 0.4 mV (30 GHz) 0.7 mV (50 GHz)

0.6 mV (50 GHz) 1.3 mV (70 GHz)

Maximum 0.7 mv (30 GHz); 1.8 mV (50 GHz)

1.0 mV (50 GHz 2.5 mV (70 GHz)

Scale factor

Minimum 1 mV/division Maximum 100 mV/division DC accuracy (single marker) ±0.4% of full scale ±0.4% of full scale

±2 mV ±1.2% of (reading-channel offset) (30 GHz) ±2 mV ±2% of (reading-channel offset) (50 GHz) ±0.4% of full scale ±0.4% of full scale

±2 mV ±2% of (reading-channel offset) (50 GHz) ±2 mV ±4% of (reading-channel offset) (70 GHz) CW offset range (referenced from center of screen) ±500 mV Input dynamic range (relative to channel offset) ±400 mV

Maximum input signal ±2 V (+16 dBm) Nominal impedance 50 Ω Reflections (for 30 ps rise time) 5% 20% Electrical input 2.4 mm (male) 1.85 mm (female)

Clock recovery single mode, Multimode and electrical modules 83495A-100 83495A-101 Channel type Single mode optical and electrical Multimode optical and electrical Wavelenth range 1000 to 1600 nm 750 to 860 nm Clock recovery phase locked loop bandwidth

Internal path triggering

< 300 KHz or < 4 MHz (3.5 MHz1) user selectable

External output

< 300 KHz or < 4 MHz (3.5 MHz1) user selectable

Data rates (Gb/s) 9.953 to 11.32 Tracking range ±30 MHz Acquisition range Continuous within data rate range Internal splitter ratio 20/80 30/70

Clock output jitter

0.008 UI (0.006 UI) RMS

Input level for clock recovery

–12 dBm (–14 dBm) to +0 dBm optical –9 dBm (–11 dBm) to +0 dBm optical

0.20 to 2.0 Vp-p electrical 0.20 to 2.0 Vp-p electrical

Input/output connectors FC/PC, 9/125 µm & Type N FC/PC, 62.5/125 µm & Type N Auxiliary recovered clock and regenerated data outputs Type N with SMA adapters (no data output) Input return loss 28 dB maximum optical

DC to 2.5 GHz, 20 dB electrical

2.5 GHz to 11.32 GHz, 15 dB electrical

Input insertion loss 2.0 dB maximum optical 2.5 dB maximum optical

Clock recovery

TDR system Oscilloscope/TDR performance Normalized characteristics

(Mainframe with 54754A module) Rise time 40 ps nominal Adjustable from larger of 10 ps or 0.08 x time/div

< 25 ps normalized Maximum: 5 x time/div

TDR step flatness ≤ ±1% after 1 ns from edge ≤ 0.1%

≤ ±5%, –3% 1 ns from edge

Low level 0.00 V ±2 mV High level ±200 mV ±2 mV

TDR system

Achieved with input power ≥ –8 dBm for Option 100; ≥ –5 dBm for Option 101.

Loop BW transfer function is guaranteed to be less than a low pass

response with the specified corner frequency rolling off –20 dB/dec.

Measured with a PRBS 223-1 pattern. For total scope jitter, RSS clock output jitter with mainframe jitter.

For optical input power, source extinction ratio ≥ 8.2 dB when measured per TIA/EIA OFSTP-4A. For extinction

ratio equal to 8.2 dB, OMA is defined as (P

1–P0

) and is equal to average input power (dBm) + 1.68 dB.

Input is a fully filled multimode signal.

83496A-100 83496A-101

Single-mode or multi-mode optical,

Channel type Differential or single-ended electrical differential or single-ended electrical

(no internal electrical splitters)

Data rates Standard: 50 Mb/s to 7.1 Gb/s continuous tuning

Option 200: 50 Mb/s to 13.5 Gb/s continuous tuning)

single-mode (OMA

–11 dBm @ 50 Mb/s to 11.4 Gb/s –8 dBm @ > 11.4 G/bs –12 dBm @ 7.1 Gb/s to 13.5 Gb/s (w/Opt 200) –14 dBm @ 1 Gb/s to 7.1 Gb/s –15 dBm @ 50 Mb/s to 1 Gb/s

multi-mode 1310 nm (OMA

–10 dBm @ 50 Mb/s to 11.4 Gb/s –7 dBm @ > 11.4 G/bs

Minimum input level to aquire lock 75 m Vpp

–11 dBm @ 7.1 Gb/s to 13.5 Gb/s (w/Opt 200)

(voltage or OMA

)

–13 dBm @ 1 Gb/s to 7.1 Gb/s –14 dBm @ 50 Mb/s to 1 Gb/s

multi-mode 850 nm (OMA

–8 dBm @ 50 Mb/s to 11.4 Gb/s –7 dBm @ > 11.4 G/bs –9 dBm @ 7.1 Gb/s to 13.5 Gb/s (w/Opt 200) –11 dBm @ 1 Gb/s to 7.1 Gb/s –12 dBm @ 50 Mb/s to 1 Gb/s

electrical: 150 mVpp

Internal recovered clock trigger

< 500 fs 7.2 Gb/s to 11.4 Gb/s (300 fs @ 10 Gb/s) < 700 fs 4.2 Gb/s to 7.2 Gb/s, 11.4 GB/s to 13.5 Gb/s (400 fs @ 4.25 Gb/s, 500 fs @ 2.5 Gb/s)

Output random jitter (RMS)

< 3 mUI 50 Mb/s to 4.2 Gb/s (700 fs @ 1.25 Gb/s)

Front panel recovered clock

< 700 fs 7.2 Gb/s to 11.4 Gb/s (300 fs @ 10 Gb/s) < 900 fs 4.2 Gb/s to 7.2 Gb/s, 11.4 Gb/s to 13.5 Gb/s (400 fs @ 4.25 Gb/s, 500 fs @ 2.5 Gb/s) < 4 mUI 50 Mb/s to 4.2 Gb/s (700 fs @ 1.25 Gb/s)

Clock recovery adjustable loop Standard: 270 KHz or 1.5 MHz

;

bandwidth range (user selectable) Option 300: 15 kHz to 10 MHz

continuous tuning (fixed value or a constant rate/N ratio)

Option 300: ±25% for transition density = 0.5 and data rate 155 Mb/s to 11.4 Gb/s

Loop bandwidth accuracy (±30% for 0.25 ≤ transition density ≤1.0 and all data rates)

Standard: ±30%

Tracking range ±1000 ppm Acquisition range ±5000 ppm

20/80 single-mode

Internal splitter ratio 50/50

30/70 multi-mode Electrical signals have input only (no internal power dividers)

22 dB (DC to 12 GHz) electrical

20 dB single-mode, 16 dB multi-mode

Input return loss

16 dB (12 to 20 GHz) electrical

22 dB min (DC to 12 GHz) electrical 16 dB min (12 to 20 GHz) electrical

7.2 dB max (DC to 12 GHz) electrical

2.5 dB max single-mode optical,

Input insertion loss

7.8 dB max (12 to 20 GHz) electrical

3 dB max multi-mode optical (no electrical data output signal path)

See footnotes on page 23.

Specifications

Specifications (continued)

To convert from OMA to average power with an extinction ratio of 8.2 dB use: Pavg

dBm

= OMA

dBm

–1.68 dB.

Verified with PRBS7 pattern, electrical inputs > 150 mVp-p and optical inputs > 3 dB above specification for minimum input level to acquire lock. Output jitter verification results of the 83496A can be affected by jitter on the input test signal. The 83496A will track jitter frequencies inside the loop bandwidth, and the jitter will appear on the recovered clock output. Vertical noise (such as laser RIN) on the input signal will be converted to jitter by the limit amplifier stage on the input of the clock recovery. These effects can be reduced by lowering the Loop bandwidth setting.

At rates below 1 Gb/s, loop bandwidth is fixed at 30 KHz when Option 300 is not installed.

Without Option 200 loop bandwidth is adjustable from 15 KHz to 6 MHz. Available loop bandwidth settings also depend on the data rate of the input signal. For transition density from 0.25 to 1, the Loop Bandwidth vs Rate chart shows available loop bandwidth settings.

20*log(Vamp

out

/Vam

) measured with PRBS23 at 13.5 Gb/s.

Minimum frequency of divided front panel clock output is 25 MHz.

Other types of optical connectors are also available.

83496A-100 83496A-101

Electrical through-path digital

7.5 dB (no electrical data output signal path)

amplitude attenuation

Wavelength range

780 to 1330 nm multi-mode 1250 to 1620 nm single-mode

Front panel recovered clock output amplitude

±500 mV max; ±125 mV min

Consecutive identical digits (CID) 150 max Front panel recovered clock output N=1 to 16 @ data rates 50 Mb/s to 7.1 Gb/s divide ratio (user selectable)

N=2 to 16 @ data rates 7.1 Gb/s to 13.5 Gb/s

FC/PC

9/125 µm single-mode optical

Data input/output connectors 3.5 mm male FC/PC

62.5/125 µm multi-mode optical

3.5 mm male electrical (input only)

Front panel recovered clock output connector

SMA

Selectable Loop Bandwidth vs Rate

10.0E+6

for 0.25 ≤ Transition Density ≤ 1

1.0E+6

100.0E+3

Loop Bandwidth (Hz)

10.0E+3

10.0E+6 100.0E+6 1.0E+9 10.0E+9 100.0E+9

Input Data Rate (bits/s)

min max

Ordering Information

86100C infiniium DCA-J mainframe

86100C-001 Enhanced trigger 86100C-090 Removable hard drive 86100C-200 Jitter analysis software 86100C-201 Advanced waveform analysis software 86100C-202 Enhanced impedance and S-parameter software 86100C-AFP Accessory filler panel 86100C-AX4 Rack mount flange kit 86100C-AXE Rack mount flange kit with handles 86100C-UK6 Commercial cal certificate with test data

Optical/electrical modules 86101A 2.85 GHz optical channel; multimode, amplified

(750 to 860 nm) 20 GHz electrical channel 86101A-201 155, 622 Mb/s 86101A-202 1.063, 1.25 Gb/s

86102U 15 GHz optical channel; multimode, unamplified

(750 to 860 nm)

20 GHz electrical channel 86102U-201 1.25, 2.488 Gb/s 86102U-202 2.488, 3.125 Gb/s 86102U-203 3.125, 10.3125 Gb/s

86103A 2.85 GHz optical channel; multimode, amplified

(1000 to 1600 nm)

20 GHz electrical channel 86103A-201 155, 622 Mb/s 86103A-202 1.063, 1.25 Gb/s

86105B 15 GHz optical channel; single-mode, unamplified

(1000 to 1600 nm)

20 GHz electrical channel 86105B-101 9.953, 10.3125, 10.51875, 10.664, 10.709 Gb/s 86105B-102 155, 622 Mb/s

2.488, 2.5, 2.666, 9.953, 10.3125, 10.51875, 10.664,

10.709 Gb/s

86105B-103 1.063, 1.250, 2.125, 2.488, 2.5, 9.953, 10.3125,

10.51875, 10.664, 10.709 Gb/s

86105C 10 GHz optical channel; multimode, amplified

(750 to 1650 nm)

20 GHz electrical channel 86105C-100 155 Mb/s through 4.25 Gb/s (choose 4 data rates) 86105C-110 155 Mb/s 86105C-120 622 Mb/s 86105C-130 1.063 Gb/s 86105C-140 1.250 Gb/s 86105C-150 2.125 Gb/s 86105C-160 2.488, 2.500 Gb/s 86105C-170 2.666 Gb/s 86105C-180 3.125 Gb/s 86105C-190 4.250 Gb/s 86105C-H97 8.500 Gb/s 86105C-200 9.953, 10.3125, 10.519, 10.664, 10.709,

11.096,11.317 Gb/s

86105C-300 Combination of rates available in 86105C-100 and

86105C-200

86106B 28 GHz optical channel; single-mode, unamplified

(1000 to 1600 nm)

40 GHz electrical channel 86106B-410 9.953, 10.3125, 10.664, 10.709 Gb/s

86116A 53 GHz optical channel; single-mode, unamplified

(1000 to 1600 nm)

63 GHz electrical channel

86116B 65 GHz optical channel; single-mode, unamplified

(1480 to 1620 nm)

80 GHz electrical channel

All optical modules have FC/PC connectors installed on each optical port. Other connector adapters available as options are: Diamond HMS-10, DIN, ST and SC.

Dual electrical channel modules 86112A Dual 20 GHz electrical channels

86117A Dual 50 GHz electrical channels

86118A Dual 70 GHz electrical remote sampling channels

TDR/TDT modules

Included with each of these TDR modules is a TDR demo board, programmers guide, two 50 Ω terminations, APC-3.5 (m), and one short, APC-3.5 (m).

54754A Differential TDR module with dual 18 GHz TDR/electrical

channels

N1024A Calibration kit

Trigger module 86107A Precision timebase reference module

86107A-010 2.5 and 10 GHz clock input capability 86107A-020 10 and 20 GHz clock input capability 86107A-040 10, 20 and 40 GHz clock input capability

Clock recovery modules

The following modules provide a recovered clock from the data signal for triggering at indicated data rates:

83495A 10 Gb/s Clock recovery module 83495A-100 Single-mode signals (1000–1600 nm) and electrical 83495A-101 Multimode signals (750–860 nm) and electrical 83495A-200 Continuous data rates from 9.953 Gb/s to 11.32 Gb/s

83496A 50 Mb/s to 7.1 Gb/s Clock recovery module 83496A-100 Single-ended and differential electrical with integrated

signal taps

83496A-101 Single-mode (1250–1620 nm) and multimode

(780-1330 nm) optical. Integrated signal taps. Single-ended

or differential electrical inputs (no signal taps) 83496A-200 Increase operating range to 50 Mb/s to 13.5 Gb/s 83496A-300 Add tunable loop bandwidth “golden PLL” capability

Warranty options (for all products) R1280A Customer return repair service R1282A Customer return calibration service

Connector options (for all optical modules) 81000 AI Diamond HMS-10 connector 81000 FI FC/PC connector adapter 81000 SI DIN connector adapter 81000 VI ST connector adapter 81000 KI SC Connector Adapter Accessories 11667B Power splitter, DC to 26.5 GHz, APC 3.5 mm 11667C Power splitter, DC to 50 GHz, 2.4mm 11742A 45 MHz to 26.5 GHz DC blocking capacitor 11742A-K01 50 GHz DC blocking capacitor

83440B/C/D Optical-to-electrical converters (6/20/32 GHz) 8490D-020 2.4 mm 20dB attenuator

86101-60005 Filler panel 0960-2427 USB keyboard (included with 86100C) 1150-7799 USB mouse (included with 86100C) N1020A 6 GHz TDR probe kit

Probes 1169A 13 Ghz probe 1168A 10 Ghz probe N5380A InfiniiMax II 12 GHz differential SMA adapter N5381A InfiniiMax II 12 GHz solder-in probe head N5382A InfiniiMax II 12 GHz differential browser

1130 Series InfiniiMax probing systems

(Requires N1022A – see below)

1134A 7 GHz InfiniiMax probe amp – order one or both E266xA

connectivity kits per amp

1132A 5 GHz InfiniiMax probe amp – order one or both E266xA

connectivity kits per amp

1131A 3.5 GHz InfiniiMax probe amp – order one or both E266xA

connectivity kits per amp

Connectivity kits model E2669A InfiniiMax connectivity kit for differential measurements

E2668A InfiniiMax connectivity kit for single-ended measurements

Additional Components E2675A InfiniiMax differential browser probe head and accessories.

Includes 20 replaceable tips and ergonomic handle. Order E2658A for replacement accessories.

E2676A InfiniiMax single-ended browser probe head and accessories.

Includes 2 ground collar assemblies, 10 replaceable tips, a ground lead socket and ergonomic browser handle. Order E2663A for replacement accessories.

E2677A InfiniiMax differential solder-in probe head and accessories.

Includes 20 full bandwidth and 10 medium bandwidth damping resistors. Order E2670A for replacement accessories.

E2678A InfiniiMax single-ended/differential socketed probe head and

accessories. Includes 48 full bandwidth damping resistors, 6 damped wire accessories, 4 square pin sockets and socket heatshrink. Order E2671A for replacement accessories.

E2679A InfiniiMax single-ended solder-in probe head and accessories.

Includes 16 full bandwidth and 8 medium bandwidth damping resistors and 24 zero ohm ground resistors. Order E2672A for replacement accessories.

Adapters N1022A Adapts 113x/115x active probes to 86100 Infiniium DCA

Other compatible probes 54006A 6 GHz passive probe

Adapters for electrical channels 11900B 2.4mm (f-f) adapter 11901B 2.4mm (f) to 3.5mm (f) adapter 11901C 2.4mm (m) to 3.5mm (f) adapter 5061-5311 3.5mm (f-f) adapter 1250-1158 SMA (f-f) adapter 1810-0118 3.5mm termination

Firmware and software

Firmware and software upgrades are available through the Web or your local sales office. www.agilent.com/comms/dcaupgrade

Agilent Technologies’ Test and Measurement Support, Services, and Assistance

Agilent Technologies aims to maximize the value you receive, while minimizing your risk and problems. We strive to ensure that you get the test and measurement capabilities you paid for and obtain the support you need. Our extensive support resources and services can help you choose the right Agilent products for your applications and apply them successfully. Every instrument and system we sell has a global warranty. Two concepts underlie Agilent’s overall support policy: “Our Promise” and “Your Advantage.”

Our Promise

Our Promise means your Agilent test and measurement equipment will meet its advertised performance and functionality. When you are choosing new equipment, we will help you with product information, including realistic performance specifications and practical recommendations from experienced test engineers. When you receive your new Agilent equipment, we can help verify that it works properly and help with initial product operation.

Your Advantage

Your Advantage means that Agilent offers a wide range of additional expert test and measurement services, which you can purchase according to your unique technical and business needs. Solve problems efficiently and gain a competitive edge by contracting with us for calibration, extra-cost upgrades, out-of-warranty repairs, and onsite education and training, as well as design, system integration, project management, and other professional engineering services. Experienced Agilent engineers and technicians worldwide can help you maximize your productivity, optimize the return on investment of your Agilent instruments and systems, and obtain dependable measurement accuracy for the life of those products.

www.agilent.com/find/emailupdates

Get the latest information on the products and applications you select.

Agilent T&M Software and Connectivity

Agilent’s Test and Measurement software and connectivity products, solutions and developer network allows you to take time out of connecting your instruments to your computer with tools based on PC standards, so you can focus on your tasks, not on your connections. Visit

www.agilent.com/find/connectivity

for more information.

www.agilent.com

For more information on Agilent Technologies’ products, applications or services, please contact your local Agilent office. The complete list is available at:

www.agilent.com/find/contactus

Online assistance:

www.agilent.com/find/dca

Phone or Fax

United States:

(tel) 800 829 4444 (fax) 800 829 4433

Canada:

(tel) 877 894 4414 (fax) 800 746 4866

China:

(tel) 800 810 0189 (fax) 800 820 2816

Europe:

(tel) 31 20 547 2111

Japan:

(tel) (81) 426 56 7832 (fax) (81) 426 56 7840

Korea:

(tel) (080) 769 0800 (fax) (080)769 0900

Latin America:

(tel) (305) 269 7500

Taiwan: (tel) 0800 047 866 (fax) 0800 286 331

Other Asia Pacific Countries:

(tel) (65) 6375 8100 (fax) (65) 6755 0042 Email: tm_ap@agilent.com

Contacts revised: 05/27/05

Product specifications and descriptions in this document subject to change without notice.

Agilent Email Updates

Agilent 86100C Technical Specifications

Specifications and Main Features

Frequently Asked Questions

User Manual
