Agilent 71612B Data Sheet

12 Gb/s error performance analyzer

Accurately
characterize
your Gbit
systems and
devices

71612B

HP

Design and manufacture reliable
Gbit transmission modules and
system hardware

Fast transition time and low jitter of the data
output eye diagram at 12 Gb/s.

Use the HP 71600 Series of Gbit
testers to measure bit error
ratio (BER) and to verify the
performance and quality of your
components and system
hardware.

• Lightwave submarine cable

systems

• SONET/SDH synchronous

network transmitters and
receivers

• Gbit datacom serial links

• Lasers and photodetectors

• High-speed logic devices

• Optical amplifiers and

modulators

• Decision circuits

• Multiplexers and output drivers.

For high-performance pattern
generation and error analysis
across the entire 100 Mb/s to
12 Gb/s range, use an HP 71612B
error performance analyzer with
optional low-rate clock.

See captured errored bit on an oscilloscope. 8 Mbit programmable memory allows creation

Thoroughly test and verify
device performance

When looking at pulse shapes,
eye diagrams and waveform
distortions, use the pattern
generator with a high-speed
oscilloscope from the HP 83480
Series for characterizing
components up to 12 Gb/s.

Both pattern generator and error
analyzer provide a wide range of
PRBS and user-defined patterns,
with versatile triggering facilities.
And to help you identify the
address of the errored bits use
optional error location analysis.
Once the position of an errored
bit is identified, the flexible
triggering features can be used
to view the errored pattern on an
oscilloscope for further
diagnosis.

of complete, structured SONET and SDH frames
on the HP 71612B analyzer’s display.

• Exceptional waveform

performance (even with
reflective or poor
terminations)

• Display maybe totally

dedicated to pattern editing

• Error location analysis identifies

individual errored bits in custom
patterns; measure bit, block or
total pattern BER

• Flexible pattern trigger allows

oscilloscope to be triggered on
any bit in custom pattern,
allowing errored bits to be
displayed on oscilloscope

• Cost effective addition of

12 Gb/s jitter analysis with the
HP 71501C jitter analyzer

• Eye line display with HP 83480A

communications analyzer

• Q measurement and eye-contour

analysis with HP E4543A
application software.

The HP 71600 Series of

Gbit testers help you be more

competitive in today’s

rapidly developing global

communications marketplace

2

Design better lightwave
and Gbit devices

Optional, powerful eye analysis features are enabled when the HP 83480A is used with an HP 71600 Series pattern generator.
HP Eye line mode allows recovery of low level eye diagrams from the noise, and display of the eye diagram as continous traces
instead of dots. (Above example shows unfiltered laser output.)

Create powerful, practical
test patterns

Perform real-time editing of your
longest test patterns, too. Use
the efficient, on-screen pattern
editor to copy, cut, and paste at
the touch of a key, then save
patterns to the non-volatile
memory or to the integral
flexible disk. The large CRT
displays in binary or hex, as
you wish.

Thoroughly stress test
components and sub-systems

Use your own patterns that
accurately represent the type of
signal carried by a transmission
system.

Simulate multiple SONET/SDH
frames, and check out alarms
and frame alignment circuits.
The error performance analyzer
has over 8 Mbit of user-program­mable memory. This is large
enough for your most complex,
structured test patterns and
ideal for up to six OC-192/
STM-64 frames.

Efficiently edit and transfer
patterns off-line

To help you start testing, we’ve
included a disk with sample
SONET/SDH frames and with
clock-recovery stress patterns.
In addition, use HP E4544A
STM-64/OC-192 functional test
application software with a
personal computer off-line to
create, edit, and store your own
SONET/SDH test patterns. This
way, it’s also easy to exchange
test patterns among your other
test stations.

Easily investigate pattern­dependent errors

It’s often important to know how
devices and systems such as line
terminals and multiplexers
respond to sudden changes of
pattern. So, use the “hitless”
pattern switch to change
error-free between two patterns.
Each may be up to 4 Mbit long.

Improve productivity
– set up and measure fast

The auto-decision error
detector threshold setting, and
auto-phase alignment simplify
measurements for you.

They quickly and automatically
locate the optimum decision
point in the eye, clearly
displaying eye width and height
for user-defined error ratio
thresholds.

View only the measurements of
interest to you by building a
display from any of the set of
standard measurements.

Improve device performance
specifications

When making accurate
measurements on critical
devices you need the very fast
transition times and low jitter
capability typical of an
HP 71612B error performance
analyzer.

3

A host of powerful additonal
capabilities

Perform Q measurements using HP E4543A application software.

Simulate long-distance
testing

Make reliable fiber cable tests
by simulating long runs using a
short fiber loop on the bench.
The fast PRBS synchronization
algorithm allows you to make
reliable BER tests using burst
gating. Now there’s no need for
you to make up bulky and
expensive cable drums for your
fiber testing.

Fully evaluate system
performance

You’ll find there is comprehen­sive bit error analysis to
characterize performance fully.
The simultaneous analysis of
both errored ones and errored
zeros is especially useful for
locating sources of errors.

Quickly find out what effect
those small circuit adjustments
have on error ratio. The error-bar
display with audio output
provides an easy way for you to
adjust devices for minimum
errors without the need to
interpret figures. And, continu­ously updated delta error count
and delta error ratio
measurements conveniently
track each minor adjustment
you make.

Create a frequency agile jitter analysis system
that can work at any rate up to 12 Gb/s.

Flexible gating

Increase the value of long-term,
unattended trials on prototype
systems by defining total
measurement period by time,
number of bits received or
number of errors measured.
Print your choice of informative
results summaries at regular
intervals on an external printer.

Application software

Enhance the flexible gating
capability with the HP E4543A
application software to perform
Q-factor measurements, or
generate eye-contour diagrams

-20

to 10

to reveal even the
smallest degradations in the
signal, quickly and efficiently.

Find out how to improve your

products and reach

tomorrow’s marketplace today

4

Use HP E4543A application software to derive eye contours to 10
BER from Q measurement.

Error location anlaysis has identified bit 57 of a long,
repetitive pattern to be in error. The preceding 28
bits and three following bits are also displayed. The

-20

separate analysis of 1→0 and 0→1 errors helps you

locate sources of errors. If you need to view more of
the pattern that may have caused the error, the
pattern editor is on hand to let you view all of the
pattern.

Go even further

Finally, extend your ability to
evaluate system performance by
adding the HP 71501C jitter
analyzer to create a frequency
agile jitter analysis system that
can work at any rate up to
12 Gb/s.

For more information refer to
related products section on rear
cover.

Make Gbit test interfacing
easy

When measuring device
distortion, or testing different­ially driven components, you
will value the independent
control you have of the pattern
generator’s dc-coupled
complementary clock and
data outputs – indispensable
for accurate characterization of
optical devices.

To avoid damage when changing
sensitive devices in test fixtures,
use the data output on/off
control to remove the data
signal.

If you’re responsible for the

research, development or

manufacturing test

of Gbit lightwave and digital

semiconductor components,

devices and sub-systems,

give HP a call – today.

Error location analysis

Makes it easier for you to find the
source of systematic errors — Vital
when you’re under continuous
pressure to develop more reliable
high-speed components and
subsystems.

• Bit BER

Locate the cause of systematic errors
causing a specific bit to change value.
Just specify any bit in a user-defined
pattern and perform bit error
measurements upon it.

• Block BER

Essential when trying to locate the
cause of systematic errors which affect
longer runs of bits, for example a
corrupt header in a SONET or SDH
frame. Perform bit error rate
measurements on a range of bits within
a user-defined pattern.

• Error-location capture

Helps you discriminate between random
and systematic errors. In a user-defined
pattern, automatically highlight the
position of each errored bit in turn –
displaying the address of the errored bit
– and show the surrounding bit pattern.
Then automatically measure BER of
each errored bit. If the error rate of a
captured bit remains significant over a
period, there is probably a pattern­dependent, systematic error.

5

HP 71612B error performance
analyzer specifications

Items marked “typical” or “nominal” are supplemental characteristics
intended to provide information useful in applying the instrument by
giving typical but non-warranted, performance parameters.

Test patterns

27 − 1.

31

− 1, 223 − 1, 215 − 1, 210 − 1,

• PRBS: 2

• User-defined pattern: Up to 8 Mbit.

• Zero substitution: Extends the

longest run of zeros up to pattern
length less one bit on patterns 2
210, 27.

13

, 211,

• Variable mark density ratio: 1/8 to

7/8 in 1/8 steps on patterns 213, 211, 210, 27.

• STM-64 and OC-192 patterns :

Samples supplied on disk along with
other stress patterns.

In the pattern generator, any pattern may
be split into two equal-length patterns, with
hitless switching between them. The user­defined patterns may be loaded from, or
saved to, a 3-½ inch, MS-DOS® format
floppy disk.

Pattern generator

There are inputs for an external clock,
external error inject, alternate-pattern
switch and data output on/off switch.
There are outputs for clock and inverted
clock, data and inverted data and pattern
trigger, sub-rate (quarter-rate) clock; also
four outputs for quarter-rate data.

Clock input
Frequency range: 100 MHz to 12 GHz.
Interface: 0.45 to 0.90 V p-p, dc coupled,

50 ohms. (≤ 10 GHz), 0.65 to 0.9 V p-p
(> 10 GHz).

Clock outputs – main
Frequency range: 100 MHz to 12 GHz.
Interface: Complementary, dc coupled,

50 ohms, reverse terminated. (Independent
control of outputs available).

Amplitude: 0.5 to 2 V p-p in 10 mV steps.
Range: +1.5 to −3.0 V in 10 mV steps.

Data outputs – main
Interface: Complementary, dc coupled,

50 ohms, reverse terminated NRZ, normal
or inverted. (Independent control of
outputs available).

Amplitude: 0.5 to 2 V p-p in 10 mV steps.
Transition times (10% to 90%):

< 30 ps (typical at 2 V p-p).

Jitter: < 20 ps p-p; < 15 ps p-p at 10 Gb/s.
Range: +1.5 to −3.0 V in 10 mV steps.
Clock/data delay: ±1 ns (100 MHz to

500 MHz), one clock period (500 MHz to
12 GHz).

Resolution: 1 ps.

Clock and data outputs – subrate
Frequency range: ¼ of main clock rate.
Interface: dc coupled, 50 ohms, reverse

terminated.

Amplitude: 0.5 to 1 V p-p in 10 mV steps.
Range: 0 to −2.0 V in 10 mV steps.

Trigger output: Pattern; clock/32; clock/8.

Error add
Internal: Single on command, or fixed

ratio 1 in 10n bits, where n = 3 to 9.

External: TTL levels (active low).

Error detector

The error detector has clock and data
inputs and an input which inhibits error
counting. There are outputs for errors and
pattern trigger. The error detector has both
manual and automatic setting of decision
threshold and clock/data phase alignment.

Clock input
Frequency range: 100 MHz to 12 GHz.
Interface: 0.45 to 0.90 V p-p dc coupled,

50 ohms to 0 V or −2 V.
Sensitivity: < 200 mV p-p (typical at
10 Gb/s).

Data input
Sensitivity: < 50 mV p-p (typical for 2

PRBS input at 10 Gb/s. 0 V high level).
Impedance: 50 ohms to 0 V or −2 V,
dc coupled.
Decision threshold range: +1 to −3 V in
1 mV steps.
Clock/data phase alignment: ±1 ns
(100 MHz to 500 MHz); 1 clock period
(500 MHz to 12 GHz).
Resolution: 1 ps.

23

− 1

Trigger output: Pattern or clock/8.
Error output: 0 to −0.4 V nominal.

Measurement modes: Manual, single

period, repetitive period.
Measurement period: 1 s to 100 days;
10, 100, 1000 errors; 107 to 10

Pattern synchronization: Automatic or
manual.

Selectable threshold: 10−1 to 10−8.

Audible output: Proportional to error

ratio.

Result logging: Time-stamped results to
an external printer.

15

bits.

Clock source

The standard integral clock source has a
clock output and an external reference
input. It provides a variable-frequency,
synthesized clock signal to the pattern
generator.

See HP 70340A signal generator data
sheet for full specifications

Frequency range: 1 to 20 GHz.
Resolution: 1 kHz.

Measurements

• Error count and ratio for:

errored ones
errored zeros
all logic errors

• Errored and error-free

intervals of:

seconds
deciseconds
centiseconds
milliseconds

• Clock frequency

• Error location analysis (optional)

Specific bit BER

Bit BER
Bit error count
Delta bit BER
Delta bit error count

Block BER
Error location capture

6

HP 71612B error performance analyzer
available with pattern generator, error
detector and integral 12 GHz clock source.

Ordering information

12 Gb/s BER measurement
and analysis systems

All provide mainframe, color display
with integral keypad, base unit, set of
operating and installation manuals.

HP 71612B option UHF: 1 to 12 Gb/s
error performance analyzer system with
pattern generator, error detector and
clock source.

HP 71612B option UHG: 1 to 12 Gb/s
system with pattern generator and clock
source (no error detector provided).

HP 71612B option UHH: 0.1 to 12 Gb/s
error detector (no pattern generator or
clock source).

Error location analysis
HP 71612B option UHJ: Adds enhanced

error detection to help identify sources of
systematic errors.
Do not order with option UHG.

No clock source
HP 71612B option UKC: Deletes clock

source.
Do not order with option UHH.

12 Gb/s BER measurement
and analysis system – without
display and clock source

All provide base unit, set of operating and
installation manuals.

If you have your own MMS display and
clock source, or you wish to build your
own test bays, order only the parts you
need for your 12 GHz applications.

HP 70843B option UHF: 0.1 to 12 Gb/s
error performance analyzer with pattern
generator and error detector (no clock
source provided).

HP 70843B option UHG: 0.1 to 12 Gb/s
system with pattern generator only (no
error detector or clock source provided).

HP 70843B option UHH: 0.1 to 12 Gb/s
system with error detector only (no pattern
generator or clock source provided).

Error location analysis.
HP 70843B option UHJ: Adds enhanced

error location analysis to help identify
sources of systematic errors.
Do not order with option UHG.

Accessories

HP 71612B option 806:

Replaces HP 70340A standard clock source
(1 to 12 Gb/s) with HP 83752A clock source
(0.1 to 12 Gb/s), extending the operation of
the system down to 100 Mb/s.

7

Available for both HP 71612B and
70843B analyzers.

Option 0B1: Extra set of manuals.
Option 1CM: Rack mount kit without

front handles fitted.
Option 1CP: Rack mount kit with front
handles fitted.
Option +W30: Two years additional
hardware support beyond the standard
one-year warranty.

Note: If you have already purchased
pattern generator-only or error detector­only units (options UHG or UHH) and
wish to upgrade these to full analysis
systems (option UHF), factory retrofits
are available. Please contact your HP
representative for further details.

Related literature

HP E4544A STM-64/OC-192 Profile 5965-6411E
functional test application
software

HP E4543A Q-factor and eye-contour Profile 5965-6412E
application software

Locating errors in Gigabit transmission Technique 5968-2811E
systems and components

Testing 10 Gb/s SONET/SDH Technique 5968-2812E
equipment and components

Methods for faster high-speed Brochure 5966-4258E
digital communications design

Frequency agile jitter measurement Application Note 5963-5353E
system 1267

HP 71501C jitter analysis system Product Overview 5965-0801E

HP 83480A Series digital Product Overview 5964-2238E
communications analyzer

For more information about Hewlett-Packard test &
measurement products, applications, services, and
for a current sales office listing, visit our web site,
http://www.hp.com/go/tmdir. You can also contact
one of the following centers and ask for a test and
measurement sales representative.

United States:

Hewlett-Packard Company
Test and Measurement Call Center
P.O. Box 4026
Englewood, CO 80155-4026
1 800 452 4844

Canada:

Hewlett-Packard Canada Ltd.
5150 Spectrum Way
Mississauga, Ontario
L4W 5G1
1 877 894 4414

Europe:

Hewlett-Packard
European Marketing Centre
P. O. Box 999
1180 AZ Amstelveen
The Netherlands
(31 20) 547 9999

Japan:

Hewlett-Packard Japan Ltd.
Measurement Assistance Center
9-1, Takakura-Cho, Hachioji-Shi
Tokyo 192-8510, Japan
Tel: [phone]
Fax: [phone]

Latin America:

Hewlett-Packard
Latin American Region Headquarters
5200 Blue Lagoon Drive, 9th Floor
Miami, Florida 33126
USA
[phone]/4220
Fax: [phone]

Australia/New Zealand:

Hewlett-Packard Australia Ltd.
31-41 Joseph Street
Blackburn, Victoria 3130
Australia
Tel: [phone] (Australia)
Tel: [phone] (New Zealand)
Fax: [phone]

Asia Pacific:

Hewlett-Packard Asia Pacific Ltd.
17-21/F Shell Tower, Times Square
1 Matheson Street, Causeway Bay
Hong Kong
Tel: [phone]
Fax: [phone]

Hewlett-Packard manufactures the HP 71612B/70843B analyzers under a quality
system approved to the international standard ISO 9002 plus TickIT (BSI Registration
Certificate No FM 10987).

MS-DOS is a US registered trademark of Microsoft Corporation.

© Hewlett-Packard Limited 1999
Printed in USA

Data subject to change
5968-2810E (02/99)
