User’s Quick Start Guide
Publication number 54810-97066
February 2001
For Safety information, Warranties, and Regulatory information, see the pages
at the end of this manual.
© Copyright Agilent Technologies 1997-2001
All Rights Reserved
Infiniium Oscilloscopes
In This Book
This book gives you the information you need to begin using the Infiniium
Oscilloscopes. It contains four chapters:
Setting up the Oscilloscope Chapter 1 contains inspection, power
requirements, air flow, and setup information.
Working in Comfort Chapter 2 contains recommendations for working
comfortably and safely while operating the Infiniium Oscilloscope.
Using the Oscilloscope Chapter 3 gives an overview of the front panel and
th e gr a p h i c a l us er interfa c e, and tells you how to pe rfo r m basi c ope ra t io n s wi t h
the oscilloscope.
Using the Built-In Information System Chapter 4 describes the built-in
information system contents and navigation. The built-in information system
contains all of the information that is generally found in a User’s Guide.
• For detailed information on how the oscilloscope makes measurements and
how to use the oscilloscope, see the built-in information system in the
oscilloscope.
• For information on programming the oscilloscope using a computer with a
GPIB interface card, see the Infiniium Oscilloscopes Programmer’s
Reference.
• For information on testing and servicing the oscilloscope, see either the
Infiniium Service Guide for Models 54810A/15A/20A/25A Oscilloscopes
or the Infiniium Service Guide for Models 54835A/45A/46A
Oscilloscopes.
CAUTION The Infiniium Oscilloscope uses a specially designed Windows 98 application
program. While it is possible to access some standard Windows 98 application
programs, it is not recommended. All Infiniium Oscilloscope functionality is
directly available from within the Infiniium Oscilloscope application. Other
application software may or may not function correctly. Windows 98
configuration changes made outside of the Infiniium Oscilloscope application
may not work correctly and could cause improper operation of the instrument.
Contents
1 Setting Up the Oscilloscope
To inspect package contents 1-3
To inspect options and accessories 1-5
To connect power 1-8
To connect the mouse or other pointing device 1-11
To attach the optional trackball 1-12
To connect the keyboard 1-17
To connect to the LAN card 1-18
!
To connect oscilloscope probes 1-19
To connect a printer 1-22
To connect an external monitor 1-24
To connect an GPIB cable 1-25
To tilt the oscilloscope upward for easier viewing 1-26
To turn on the oscilloscope 1-28
To turn off the oscilloscope 1-29
To verify basic oscilloscope operation 1-30
To clean the oscilloscope 1-32
2 Working in Comfort
About Repetitive Strain Injury 2-3
Mice and Other Input Devices 2-4
3 Using the Oscilloscope
To set the oscilloscope to a known starting condition 3-7
To start and stop waveform acquisition 3-8
To clear the waveform display 3-9
To turn a channel on or off 3-10
To change input impedance and input coupling 3-11
To adjust vertical scale and offset 3-12
To adjust sweep speed and horizontal position 3-13
To magnify a part of the waveform using delayed sweep 3-14
To set the oscilloscope to trigger on an edge 3-15
To use the markers 3-16
To use the quick measurements 3-17
To reinitialize the oscilloscope 3-18
To switch between the graphical interface and full-screen mode 3-30
To perform basic user interface operations 3-31
To select a command from the menu bar 3-33
To select a command from a context-sensitive menu 3-34
To change the mouse settings 3-36
To start and stop waveform acquisition 3-37
To clear the waveform display 3-38
Contents-1
Contents
To print the screen 3-39
To turn a channel on or off 3-40
To adjust the vertical offset 3-41
To adjust vertical scaling 3-43
To access the channel setup 3-44
To set the horizontal reference point 3-45
To adjust sweep speed 3-46
To adjust horizontal position 3-47
To access the horizontal setup 3-48
To zoom on a section of the waveform 3-49
To move the markers using the graphical interface 3-51
To make a measurement on a waveform 3-52
To access the trigger setup 3-54
To set an edge trigger 3-55
To enable 8.0 GSa/s sampling mode on the 54845A/46A 3-56
To enable 4.0 GSa/s sampling mode on the 54835A 3-57
To set dialog box preferences 3-58
To install the printer software 3-61
To set up the network 3-69
To recover your Infiniium hard disk 3-70
4 Using the Built-In Information System
To access the information system 4-4
To select the built-in information system language 4-10
To navigate through the information system 4-11
To access context-sensitive information 4-12
Contents-2
1
Setting Up the Oscilloscope
Setting Up the Oscilloscope
This chapter shows you how to set up your Infiniium oscilloscope,
connect power and accessories, and verify general operation.
1-2
Setting Up the Oscilloscope
To inspect package contents
To inspect package contents
❏ Inspect the shipping container for damage.
Keep a damaged shipping container or cushioning material until you have
insp ec t ed the contents of the sh ip m en t fo r co m pl et e n e ss an d have checked the
oscilloscope mechanically and electrically.
❏ Verify that you received the following items in the Infiniium Oscilloscope
packaging.
• Infiniium Oscilloscope (54810A, 15A, 20A, 25A, 35A, 45A, or 46A)
• PS/2 Mouse, P/N C3751-60201
• Mouse Pad, P/N 54810-85901
• (2) 1160A 10:1 10-MΩ passive probes (54810A, 54820A)
• (4) 1160A 10:1 10-MΩ passive probes (54815A, 54825A)
• (4) 1161A 10:1 10-MΩ passive probes (54835A, 54845A, 54846A)
• Accessory Pouch (P/N 54810-68701)
• Front Panel Cover
• Keyboard
•Power cord
• User’s Quick Start Guide
• Programmer’s Reference
• Programmer’s Quick Reference Guide
• Infiniium Service Guide for Models 54810A/15A/20A/25A Oscilloscopes
or Infiniium Service Guide for Models 54835A/45A/46A Oscilloscope
See figure 1-1. (See table 1-3 for the power cord.) If anything is missing, contact
your nearest Agilent Technologies Sales Office. If the shipment was damaged,
contact the carrier, then contact the nearest Agilent Technologies Sales Office.
❏ Inspect the oscilloscope.
• If there is mechanical damage or a defect, or if the oscilloscope does not
operate properly or does not pass performance tests, notify your Agilent
Technologies Sales Office.
• If the shipping container is damaged, or the cushioning materials show signs
of stress, notify the carrier and your Agilent Technologies Sales Office. Keep
the shipping materials for the carrier’s inspection. The Agilent Technologies
Sales Office will arrange for repair or replacement at Agilent’s option without
waiting for claim settlement.
1-3
Figure 1-1
Infiniium Oscilloscope
with Accessory Pouch
1160A or 1161A
Probe
Setting Up the Oscilloscope
To inspect package contents
Keyboard
PS/2 Mouse and
Mouse Pad
54810A/15A/20A/25A
Oscillo scopes Servic e Guide
or 54835A/45A/46A
Infiniium Oscilloscopes
Programmer’s Reference
Package Contents for the Infiniium Oscilloscopes
1-4
Infiniium Oscilloscopes
User’s Quick Start Guide
Infiniium Oscilloscopes
Programmer’s Quick Reference
Setting Up the Oscilloscope
To inspect options and accessories
To inspect options and accessories
❏ Verify that you received the options and accessories you ordered and that
none were damaged.
If anything is missing, contact your nearest Agilent Technologiess Sales Office.
If the ship m ent was damage d, or th e cushioning materials show signs of stress,
contact the carrier and your Agilent Technologies Sales Office.
Some of the options available for the Infiniium Oscilloscopes are listed in table
1-1. Contact your Agilent Technologies Sales Office for a complete list of
options, or look in the built-in information system under the Accessories List.
Table 1-1
Infiniium Oscilloscope Options
Option Description
001 Additional set of standard probes—(2) 1160A probes for the
54810A/15A/20A/25A, or (2) 1161A probes for the 54835A, 54845A, and 54846A
002 Add 1 1162A 1:1 passive probe
003 Add 1 1163A 10:1 500-
006 Add one 1152A 2.5 GHz, 0.6-pF active probe (for the 54835A, 54845A, and 54846A
only)
008 Add 1153A 200 MHz differential probe
009 Add 1154A 500 MHz differential probe
010 Add 1159A 1 GHz differential probe
090 Delete standard probes
100 Telecommunications Mask Template Kit
106 BenchLink Scope Software (34810B version 1.6 or later)
200 VoiceControl
1BP MIL-STD-45662A and ANSI/NCSL Z-540 calibration with test data
1CM Add 1 Rackmount kit (E2609A)
AB0 Taiwan User’s Quick Start Guide
AB1 Korea User’s Quick Start Guide
AB2 PRC User’s Quick Start Guide
ABD German User’s Quick Start Guide
ABE Spanish User’s Quick Start Guide
ABF French User’s Quick Start Guide
Ω, low-C passive probe
1-5
Setting Up the Oscilloscope
To inspect options and accessories
Option Description
ABJ Japanese User’s Quick Start Guide
ABZ Italian User’s Quick Start Guide
UL5 Add 1 Touchpad pointing device (E2612A)
UL6 Add 1 Clip-on trackball pointing device (E2611A)
W32 3 years calibration service
W34 3 years return standards comp calibration service
W50 5 years return repair service (additional 2 years)
W52 5 years return calibration service
W54 5 years return standards comp cal service
You can order multiple options with the oscilloscope. Also, all model numbers
shown in table 1-1 may also be ordered separately, using the model number.
Some accessories that will enhance your work with the oscilloscope are listed
in table 1-2.
Table 1-2
Accessories for the Infiniium Oscilloscopes
Agilent Model
Number
01144-61604 1:2 Probe Power Fan-Out (for use with 1144A and 1145A)
10020A Resistive Divider Probe Kit
10024A 16-pin IC clip
10076A 4 KV Passive Probe
10211A 24-pin IC clip
10240B BNC Blocking Capacitor
10450A SMT Probe Accessory Kit
10833A GPIB cable, 1 m
10833B GPIB cable, 2 m
10833C GPIB cable, 4 m
10833D GPIB cable, 0.5 m
11094B 75
1142A Probe control and power module
1182A Testmobile
1250-2427 PC Board Mini-Probe Socket (horizontal mount)
Description
Ω Feedthrough Termination
1-6
Setting Up the Oscilloscope
To inspect options and accessories
Agilent Model
Number
1250-2428 PC Board Mini-Probe Socket (vertical mount)
34398A
34399A
54006A 6 GHz probe, 10:1 (500
54701A 2.5 GHz probe, 10:1, 100 k
C2950A Parallel printer cable, 2 m
C2951A Parallel printer cable, 3 m
1144A 800 MHz Active Probe
1145A 2-channel, 750 MHz SMT active probe
1146A AC/DC Current Probe
1152A 2.5 GHz Active Probe
1153A 200 MHz Differential Probe
1154A 500 MHz Differential Probe
1155A 750 MHz 2-Channel, Low-Mass Active Probe
1159A 1 GHz Differential Probe
1170A 500 MHz Low-Mass, Miniature 10:1 10 M
1171A 500 MHz Low-Mass, Miniature 10:1 10 M
1172A 500 MHz Low-Mass, Miniature 20:1 10 M
1173A 500 MHz Low-Mass, Miniature 20:1 10 M
1250-1454 BNC to Miniature Probe Adapter
E2621A 75
E2622A 100/110/120
E2625A Telecommunications Mask Template Kit
E2635A VoiceControl Retrofit Kit
Description
RS-232-C printer cable
RS-232-C Adapter kit
Ω) or 20:1 (1 kΩ), .25 pf
Ω, 0.6 pf Active Probe (need 1143A probe
power)
Requires 1142A power supply—1144-61604 probe power extender also
required when using more than two 1144A active probes
Requires 1142A power supply
Ω Passive Probe
Ω Passive Probe
Ω Passive Probe
Ω Passive Probe
Ω terminator
Ω differential terminator
1-7
Figure 1-2
Setting Up the Oscilloscope
To connect power
To connect power
1 Position the oscilloscope where it will have sufficient clearance for
airflow around the top, back, and sides.
Minimum 0 mm
Minimum 15.9 mm
Minimum 15.9 mm
both sides
Airflow requirements
54810A-25A 125 cfm
54835A-45A 250 cfm
Positioning the Infiniium Oscilloscope with Sufficient Clearance
Minimum 38.1 mm
1-8
Figure 1-3
Setting Up the Oscilloscope
To connect power
2 Connect the power cord to the rear of the oscilloscope, then to a
suitable ac voltage source (100-240 VAC ±10%, 47 to 440 Hz, max power
dissipation 390 W).
Infiniium Oscilloscope Power Cord Connection
The oscilloscope power supply automatically adjusts for line input voltages in
the range 100 to 240 VAC. Therefore, you do not need to adjust an input line
voltage setting. The line cord provided is matched by Agilent Technologies to
the country of origin of the order.
3 Ensure that you have the correct line cord. See table 1-3.
1-9
Setting Up the Oscilloscope
To connect power
Table 1-3
Power Cords
Plug Type Cable Part
No.
250V 8120-1351
8120-1703
Plug Description Length
Straight *BS1363A
90°
(in/cm)
90/228
90/228
Color Country
Gray
Mint Gray
United Kingdom,
Cyprus, Nigeria,
Zimbabwe, Singapore
250V 8120-1369
8120-0696
250V 8120-1689
8120-1692
8120-2857
125V 8120-1378
8120-1521
8120-1992
250V 8120-2104
8120-2296
220V 8120-2956
8120-2957
250V 8120-4211
8120-4600
100V 8120-4753
8120-4754
* Part number sh own for plug is the ind ustry ide ntifier for the plug on ly. Numb er shown fo r cable is t he Agilen t part nu mber for the complete
cable including the plug.
Straight *NZSS198/ASC
90°
Straight *CEE7-Y11
90°
Straight (Shielded)
Straight *NEMA5-15P
90°
Straight (Medical) UL544
Straight *SEV1011
1959-24507
Type 12 90°
Straight *DHCK107
90°
Straight SABS164
90°
Straight MITI
90°
79/200
87/221
79/200
79/200
79/200
90/228
90/228
96/244
79/200
79/200
79/200
79/200
79/200
79/200
90/230
90/230
Gray
Mint Gray
Mint Gray
Mint Gray
Coco Brown
Jade Gray
Jade Gray
Black
Mint Gray
Mint Gray
Mint Gray
Mint Gray
Jade Gray Republic of South
Dark Gray Japan
Australia, New
Zealand
East and West
Europe, Saudi Arabia,
So. Africa, India
(unpolarized in many
nations)
United States,
Canada, Mexico,
Philippines, Taiwan
Switzerland
Denmark
Africa
India
1-10
Figure 1-4
Setting Up the Oscilloscope
To connect the mouse or other pointing device
To connect the mouse or other pointing device
1 Plug the mouse into the matching connector on the back panel of the
oscilloscope.
Connecting the Mouse Cable
While you can operate many oscilloscope functions using only the front-panel
keys and knobs, you will need the mouse to access advanced oscilloscope
functions through the graphical interface, or to find out more about the
oscilloscope through the built-in information system.
The optional touchpad pointing device connects in exactly the same way as the
mo us e. T he supplied mousepad provides the correct surface for smooth mouse
operation.
2 To modify the mouse configuration, see “To change the mouse settings”
in Chapter 3.
1-11
Figure 1-5
Setting Up the Oscilloscope
To attach the optional trackball
To attach the optional trackball
1 Push in the latch on the trackball baseplate to extend the metal tabs.
Insert the tabs into the upper right of the slot on the side of the
oscilloscope. You can only install the trackball on the right side
of the oscilloscope.
Connecting the Trackball Baseplate
1-12
Figure 1-6
Setting Up the Oscilloscope
To attach the optional trackball
2 While holding the latch in, slide the metal tabs down and to the front of
the oscilloscope until they touch the ends of the slot.
Slide the Metal Tabs
1-13
Figure 1-7
Setting Up the Oscilloscope
To attach the optional trackball
3 Release the latch. The trackball baseplate should now be secure
against the side of the oscilloscope.
Trackball Baseplate Secured
1-14
Figure 1-8
Setting Up the Oscilloscope
To attach the optional trackball
4 Snap the trackball assembly onto the pins of the baseplate. The
trackball and buttons should face up and toward the front of the
oscilloscope.
Snap the Trackball Assembly Onto the Baseplate
1-15
Setting Up the Oscilloscope
To attach the optional trackball
5 Connect the 9-pin “D” connector on the trackball cable to the COM1
port on the back panel. Tighten the retaining screws.
Figure 1-9
Connecting the Trackball Cable to the COM1 Port
For information on changing the trackball settings, see “To change the mouse
settings” in Chapter 3.
1-16
Figure 1-10
Setting Up the Oscilloscope
To connect the keyboard
To connect the keyboard
1 Plug the keyboard cable into the matching connector on the back panel
of the oscilloscope.
Connecting the Keyboard
The keyboard simplifies some oscilloscope tasks, such as entering file names
when you store waveforms and setups to the disk.
2 If you need more desk space, place the keyboard on top of the
oscilloscope. Do not stack other objects on the keyboard; this will
cause self-test failures on power on.
1-17
Figure 1-11
Setting Up the Oscilloscope
To connect to the LAN card
To connect to the LAN card
1 Connect your LAN cable to the RJ-45 connector on the LAN card. Make
sure the connection is secure.
RJ-45
Connection
Connecting to the LAN Card
2 After you have connected to the LAN card, you must set up the network.
Each Infiniium Oscilloscope now ships with a LAN card installed. If you want
a LAN connection, but have an older Infiniium Oscilloscope model that does not
have a LAN card installed, contact your Agilent Technologies Sales and Service
Office. A LAN Card Installation Kit with instructions is available from Agilent
Technologies and describes how to add a LAN card to your Infiniium
Oscilloscope.
Go to “To set up the network” in chapter 3.
1-18
Figure 1-12
Setting Up the Oscilloscope
To connect oscilloscope probes
To connect oscilloscope probes
1 Attach the probe connector to the desired oscilloscope channel or
trigger input. Push it straight on until it latches into place.
Attaching the Probe Connector
1-19
Figure 1-13
Setting Up the Oscilloscope
To connect oscilloscope probes
2 Connect the probe to the circuit of interest using grabbers or other
probing aids.
Probing the Circuit
1-20
Figure 1-14
Setting Up the Oscilloscope
To connect oscilloscope probes
3 To disconnect the probe, push the small latch on top of the probe
connector to the left, then pull the connector body away from the front
panel of the oscilloscope without twisting it.
Disconnecting the Oscilloscope Probe
CAUTION Do not attempt to twist the snap-on probes on or off the oscilloscope’s BNC
connector. Twisting the probe connector body will damage it.
CAUTION Do not exceed the maximum input voltage rating! The maximum input voltage
!
for 50 Ω inputs is 5 Vrms, CAT I. Maximum voltage for the 54810A/15A/20A/
25A at 1 MΩ input impedance is ±250V (dc + ac) [ac < 10 kHz], CAT I; for the
54835A, 54845A, and 54846A it is ±100V (dc + ac) [ac < 10 kHz], CAT I.
1-21
Figure 1-15
Setting Up the Oscilloscope
To connect a printer
To connect a printer
If you have a parallel (Centronics) printer, you will need a parallel printer cable,
such as an C2950A (2 m) or C2951A (3 m) cable. Go to step 1.
If you have a serial printer, you will need a 9-pin to 25-pin serial printer cable,
such as an 34398A cable, plus the 34399A adapter kit. Some printers may
require other cable configurations, but the oscilloscope has a 9-pin serial
connector. Go to step 5.
1 Attach the 25-pin small “D” connector to the printer output connector
on the rear of the oscilloscope. Tighten the thumbscrews to secure the
cable.
Figure 1-16
Attaching the Small “D” Connector
2 Attach the larger 36-pin “D” connector to the printer. Latch the wire
bails into the tabs on each side of the connector.
Port on Printer
Attaching the Larger “D” Connector
1-22
Figure 1-17
Setting Up the Oscilloscope
To connect a printer
3 Set the printer configuration to use the “Centronics” or “Parallel”
interface, if necessary. See the documentation for your printer.
4 Go to “To install the printer software” in Chapter 3.
5 Connect the 9-pin “D” connector of the serial printer cable to the serial
output port on the rear panel of the oscilloscope. Tighten the
thumbscrews to secure the cable.
Figure 1-18
Attaching the 9-pin “D” Connector
6 Attach the 25-pin “D” connector to the serial input port of the printer.
Tighten the thumbscrews to secure the cable.
Port on Printer
Attaching the 25-pin “D” Connector
7 Set the printer configuration to use the serial interface. See the
documentation for your printer.
8 Go to “To install the printer software” in Chapter 3.
1-23
Figure 1-19
Setting Up the Oscilloscope
To connect an external monitor
To connect an external monitor
You can connect a VGA-compatible monitor to the Infiniium oscilloscope to
provide a larger viewing area.
1 Connect the monitor cable to the display board video connector at the
rear panel of the oscilloscope.
2 Tighten the retaining screws.
Connecting an External Monitor
1-24
Figure 1-20
Setting Up the Oscilloscope
To connect an GPIB cable
To connect an GPIB cable
1 Attach the GPIB connector to the GPIB interface card connector at the
rear of the oscilloscope.
2 Tighten the thumbscrews on the connector.
Attaching the GPIB Connector
1-25
Figure 1-21
Setting Up the Oscilloscope
To tilt the oscilloscope upward for easier viewing
To tilt the oscilloscope upward for easier viewing
1 If your oscilloscope has front feet with individual wire bails, lift up the
front of the oscilloscope, grasp one of the wire bails under the front
corner, and pull it down and forward until it latches into place. Repeat
for the other wire bail.
Tilting the Oscilloscope
1-26
Loading...
