HP 37717C Communications Performance Analyzer
Self Test Error Codes
Copyright Hewlett­Packard Ltd.1998
Documentation Warranty
All rights reserved. Reproduction, adaption, or translation without prior written permission is prohibited, except as allowed under the copyright laws.
HP Part No. 37717-90412
First edition, 01/98 Printed in U.K.
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties or merchantability and fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
Hewlett-Packard Limited Telecommunications Networks Test Division South Queensferry West Lothian, Scotland EH30 9TG
1 Self Test Error Codes
Provides a list of self test fail numbers and a brief description of each fault.

Self Test Error Codes

Self Test Error Codes
Self Test Error Codes
When self test is run fail numbers may be displayed. The fail numbers and a description are listed in the following pages in numerical order.
4
Self Test Error Codes
Self Test Error Codes
711 STM-1 Signal Loss 721 STM-1 Pattern Sync Loss 724 STM-1 Bit Errors 741 STM-1 Signal Loss 751 STM-1 Signal Loss 753 STM-1 No offset - Frequency low 754 STM-1 No offset - Frequency high 761 STM-1 Signal Loss 763 STM-1 +100 ppm - Offset low 764 STM-1 +100 ppm - Offset high 771 STM-1 Signal Loss 773 STM-1 -100 ppm - Offset low 774 STM-1 -100 ppm - Offset high 781 STM-1 Clock Loss 791 STM-1 Ref Clk div ratio=193 but NO Clock Loss 821 STM-1 Signal Loss 831 STM-1 Pattern Sync Loss 834 STM-1 Bit Errors 841 STM-1 Signal Loss 843 STM-1 No offset - Frequency low 844 STM-1 No offset - Frequency high 851 STM-1 Signal Loss 853 STM-1 +100 ppm - Offset low 854 STM-1 +100 ppm - Offset high 861 STM-1 Signal Loss 863 STM-1 -100 ppm - Offset low 864 STM-1 -100 ppm - Offset high 871 STM-1 Frame or Pointer Sync Loss 884 STM-1 B1 BIP Errors 894 STM-1 B2 BIP Errors 911 STM-1 Optical Signal Loss 921 STM-1 Optical alarms present 931 STM-1 Optical Pattern Sync Loss 934 STM-1 Optical Bit Errors 941 STM-1 Optical Pattern Sync Loss 943 STM-1 Optical Bit Error Rate low 944 STM-1 Optical Bit Error Rate high 951 STM-1 Optical No Signal Loss 1010 FEPROM sum-check error 1020 SRAM error 1021 SRAM error 1022 SRAM error 1023 SRAM error 1024 SRAM address error 1040 RS232 DCD stuck low or high
5
Self Test Error Codes
Self Test Error Codes
1041 RS232 RI stuck low or high 1042 RS232 DSR stuck low or high 1043 RS232 CTS stuck low or high 1044 RS232 Rx too many bytes 1045 RS232 Tx time out 1046 RS232 Rx too few bytes 1047 RS232 Tx/Rx data failure 1052 HPIB driver chip fails 1060 RTC set incorrectly 1061 RTC not ticking correctly 1070 Parallel Port failed to send data 1080 Internal printer fails 1081 Keybd proc internal RAM fails 1082 Keybd proc external RAM fails 1083 Keybd proc ROM fails 1084 Front panel no response 1085 Front panel command not ok 1086 Front panel returned an invalid error number 1087 Front panel cpu or UART error 1088 Cannot detect front panel printer 1090 VRAM data error 1100 DISK : no disk in drive 1101 DISK : disk is full 1102 DISK : disk write failure 1103 DISK : disk read failure 1104 DISK : disk verify read/write failure 1110 LAN failed 'power on' test 1111 LAN test returned an invalid error number 1112 No LAN hardware found 1113 LAN fitted, no test result available 1120 Front panel no response 1121 Front panel command not ok 1122 Front panel returned an invalid error number 1123 Dual Port SRAM data error 1124 Dual Port SRAM address error 1130 Front panel no response 1131 Front panel command not ok 1132 Front panel returned an invalid error number 1133 Front panel FEPROM sum-check error 1140 Front panel no response 1141 Front panel command not ok 1142 Front panel returned an invalid error number 1143 Front panel SRAM data error 1144 Front panel SRAM address error 1145 Front panel : requested address range not valid 1150 Front panel no response
6
Self Test Error Codes
Self Test Error Codes
1151 Front panel command not ok 1152 Front panel returned an invalid error number 1153 Front panel VRAM data error 1154 Front panel stored fonts are corrupted 1155 Front panel : requested address range not valid 1156 Front panel VGA controller error 1160 Front panel no response 1161 Front panel command not ok 1162 Front panel returned an invalid error number 1163 Front panel UART Tx/Rx error (internal loop-back) 1164 Front panel failed to reset internal loop-back 1165 Front panel : operator indicated lid-printer power failure 1166 Front panel UART Tx/Rx error (external loop-back) 1411 JITTER GEN 140Mb/s PRBS23 10UI 2KHz - PDH errors 1419 JITTER GEN 140Mb/s - VCO not settled 1421 JITTER GEN 140Mb/s PRBS23 10UI 5KHz - PDH errors 1431 JITTER GEN 34Mb/s PRBS23 10UI 2KHz - PDH errors 1439 JITTER GEN 34Mb/s - VCO not settled 1441 JITTER GEN 34Mb/s PRBS23 10UI 5KHz - PDH errors 1452 JITTER GEN 34Mb/s PRBS23 10UI 100KHz - no PDH errors 1461 JITTER GEN 8Mb/s PRBS23 10UI 2KHz - PDH errors 1469 JITTER GEN 8Mb/s - VCO not settled 1471 JITTER GEN 8Mb/s PRBS23 10UI 5KHz - PDH errors 1482 JITTER GEN 8Mb/s PRBS23 10UI 50KHz - no PDH errors 1491 JITTER GEN 2Mb/s PRBS23 10UI 2KHz - PDH errors 1499 JITTER GEN 2Mb/s - VCO not settled 2010 UPDH (Unbalanced) Signal Loss 2011 UPDH 139 Mb/s PRBS(23) Pattern loss 2014 UPDH 139 Mb/s PRBS(23) Errors present 2020 UPDH (Unbalanced) Signal Loss 2021 UPDH 34 Mb/s PRBS(23) Pattern loss 2024 UPDH 34 Mb/s PRBS(23) Errors present 2030 UPDH (Unbalanced) Signal Loss 2031 UPDH 8 Mb/s PRBS(15) Pattern loss 2034 UPDH 8 Mb/s PRBS(15) Errors present 2040 UPDH (Unbalanced) Signal Loss 2041 UPDH 2 Mb/s PRBS(15) HDB3 Pattern loss 2044 UPDH 2 Mb/s PRBS(15) HBD3 Errors present 2050 UPDH (Unbalanced) Signal Loss 2051 UPDH 2 Mb/s PRBS(15) AMI Pattern loss 2054 UPDH 2 Mb/s PRBS(15) AMI Errors present 2060 UPDH (Unbalanced) Signal Loss 2061 UPDH 704 kb/s PRBS(15) HDB3 Pattern loss 2064 UPDH 704 kb/s PRBS(15) HBD3 Errors present 2070 UPDH (Unbalanced) Signal Loss 2071 UPDH 704 kb/s PRBS(15) AMI Pattern loss
7
Self Test Error Codes
Self Test Error Codes
2074 UPDH 704 kb/s PRBS(15) AMI Errors present 2080 UPDH (Unbalanced) Signal Loss 2081 UPDH 139 Mb/s WORD_2 Pattern loss 2084 UPDH 139 Mb/s WORD_2 Errors present 2090 UPDH (Unbalanced) Signal Loss 2091 UPDH 139 Mb/s WORD_1 Pattern loss 2094 UPDH 139 Mb/s WORD_1 Errors present 2100 UPDH (Unbalanced) Signal Loss 2101 UPDH 704 kb/s WORD_2 AMI Pattern loss 2104 UPDH 704 kb/s WORD_2 AMI Errors present 2110 UPDH (Balanced) Signal Loss 2111 UPDH 2 Mb/s PRBS(15) (Bal) HDB3 Pattern loss 2114 UPDH 2 Mb/s PRBS(15) (Bal) HBD3 Errors present 2120 UPDH (Balanced) Signal Loss 2121 UPDH 704 kb/s WORD_2 (Bal) AMI Pattern loss 2124 UPDH 704 kb/s WORD_2 (Bal) AMI Errors present 2130 UPDH (Unbalanced) Signal Loss 2133 UPDH 704 kb/s - Offset = 0 ppm Result low 2134 UPDH 704 kb/s - Offset = 0 ppm Result high 2140 UPDH (Unbalanced) Signal Loss 2143 UPDH 2 Mb/s - Offset = 0 ppm Result low 2144 UPDH 2 Mb/s - Offset = 0 ppm Result high 2150 UPDH (Unbalanced) Signal Loss 2153 UPDH 8 Mb/s - Offset = 0 ppm Result low 2154 UPDH 8 Mb/s - Offset = 0 ppm Result high 2160 UPDH (Unbalanced) Signal Loss 2163 UPDH 8 Mb/s - Offset = -100 ppm Result low 2164 UPDH 8 Mb/s - Offset = -100 ppm Result high 2170 UPDH (Unbalanced) Signal Loss 2173 UPDH 8 Mb/s - Offset = +100 ppm Result low 2174 UPDH 8 Mb/s - Offset = +100 ppm Result high 2180 UPDH (Unbalanced) Signal Loss 2183 UPDH 34 Mb/s - Offset = 0 ppm Result low 2184 UPDH 34 Mb/s - Offset = 0 ppm Result high 2190 UPDH (Unbalanced) Signal Loss 2193 UPDH 34 Mb/s - Offset = -100 ppm Result low 2194 UPDH 34 Mb/s - Offset = -100 ppm Result high 2200 UPDH (Unbalanced) Signal Loss 2203 UPDH 34 Mb/s - Offset = +100 ppm Result low 2204 UPDH 34 Mb/s - Offset = +100 ppm Result high 2210 UPDH (Unbalanced) Signal Loss 2213 UPDH 140 Mb/s - Offset = 0 ppm Result low 2214 UPDH 140 Mb/s - Offset = 0 ppm Result high 2220 UPDH (Unbalanced) Signal Loss 2223 UPDH 140 Mb/s - Offset = -100 ppm Result low 2224 UPDH 140 Mb/s - Offset = -100 ppm Result high
8
Self Test Error Codes
Self Test Error Codes
2230 UPDH (Unbalanced) Signal Loss 2233 UPDH 140 Mb/s - Offset = +100 ppm Result low 2234 UPDH 140 Mb/s - Offset = +100 ppm Result high 2240 UPDH (Unbalanced) Signal Loss 2243 UPDH 140 Mb/s - Error Add = Off Result low 2244 UPDH 140 Mb/s - Error Add = Off Result high 2250 UPDH (Unbalanced) Signal Loss 2253 UPDH 140 Mb/s - Error Add = Single Result low 2254 UPDH 140 Mb/s - Error Add = Single Result high 2260 UPDH (Unbalanced) Signal Loss 2263 UPDH 140 Mb/s - Error Add = On Result low 2264 UPDH 140 Mb/s - Error Add = On Result high 2273 UPDH 704 kb/s - Clock Recovery Result low 2274 UPDH 704 kb/s - Clock Recovery Result high 2283 UPDH 2 Mb/s - Clock Recovery Result low 2284 UPDH 2 Mb/s - Clock Recovery Result high 2293 UPDH 8 Mb/s - Clock Recovery Result low 2294 UPDH 8 Mb/s - Clock Recovery Result high 2303 UPDH 34 Mb/s - Clock Recovery Result low 2304 UPDH 34 Mb/s - Clock Recovery Result high 2313 UPDH 140 Mb/s - Clock Recovery Result low 2314 UPDH 140 Mb/s - Clock Recovery Result high 2320 UPDH FAS register write error 2330 UPDH FAS - No signal 2335 UPDH FAS - LCA not locked 2340 UPDH FAS 8 Mb/s - No signal 2341 UPDH FAS 8 Mb/s - Not locked (1) 2344 UPDH FAS 8 Mb/s - Errors present 2345 UPDH FAS 8 Mb/s - Not locked (2) 2350 UPDH FAS 34 Mb/s - No signal 2351 UPDH FAS 34 Mb/s - Not locked (1) 2354 UPDH FAS 34 Mb/s - Errors present 2355 UPDH FAS 34 Mb/s - Not locked (2) 2360 UPDH FAS 140 Mb/s - No signal 2361 UPDH FAS 140 Mb/s - Not locked (1) 2364 UPDH FAS 140 Mb/s - Errors present 2365 UPDH FAS 140 Mb/s - Not locked (2) 2370 UPDH BIN ECL 140 Mb/s Signal Loss 2373 UPDH BIN ECL 140 Mb/s Result low 2374 UPDH BIN ECL 140 Mb/s Result high 2380 UPDH BIN ECL 140 Mb/s Signal Loss 2384 UPDH BIN ECL 140 Mb/s Result high 2390 UPDH BIN TTL 34 Mb/s Signal Loss 2393 UPDH BIN TTL 34 Mb/s Result low 2394 UPDH BIN TTL 34 Mb/s Result high 2400 UPDH BIN TTL 34 Mb/s Signal Loss
9
Self Test Error Codes
Self Test Error Codes
2404 UPDH BIN TTL 34 Mb/s Result high 2410 UPDH BIN TTL 8 Mb/s Signal Loss 2413 UPDH BIN TTL 8 Mb/s Result low 2414 UPDH BIN TTL 8 Mb/s Result high 2420 UPDH BIN TTL 8 Mb/s Signal Loss 2424 UPDH BIN TTL 8 Mb/s Result high 2430 UPDH BIN TTL 2 Mb/s Signal Loss 2433 UPDH BIN TTL 2 Mb/s Result low 2434 UPDH BIN TTL 2 Mb/s Result high 2440 UPDH BIN TTL 2 Mb/s Signal Loss 2444 UPDH BIN TTL 2 Mb/s Result high 2450 UPDH BIN TTL 704 kb/s Signal Loss 2453 UPDH BIN TTL 704 kb/s Result low 2454 UPDH BIN TTL 704 kb/s Result high 2460 UPDH BIN TTL 704 kb/s Signal Loss 2464 UPDH BIN TTL 704 kb/s Result high 2470 UPDH BIN ECL 140 Mb/s Signal Loss 2474 UPDH BIN ECL 140 Mb/s User Pattern Result high 2480 UPDH BIN TTL 704 kb/s User Pattern Signal Loss 2484 UPDH BIN TTL 704 kb/s User Pattern Result high 2490 UPDH BIN TTL 34 Mb/s User Pattern Signal Loss 2494 UPDH BIN TTL 34 Mb/s User Pattern Result high 3010 SPDH (Unbalanced) Signal Loss 3011 SPDH 140 Mb/s PRBS(23) Pattern loss 3014 SPDH 140 Mb/s PRBS(23) Errors present 3020 SPDH (Unbalanced) Signal Loss 3021 SPDH 140 Mb/s WORD1 Pattern loss 3024 SPDH 140 Mb/s WORD1 Errors present 3030 SPDH (Unbalanced) Signal Loss 3031 SPDH 140 Mb/s WORD2 Pattern loss 3034 SPDH 140 Mb/s WORD2 Errors present 3040 SPDH (Unbalanced) Signal Loss 3041 SPDH 34 Mb/s PRBS(23) HDB3 Pattern loss 3044 SPDH 34 Mb/s PRBS(23) HBD3 Errors present 3050 SPDH (Unbalanced) Signal Loss 3051 SPDH 8 Mb/s PRBS(15) HDB3 Pattern loss 3054 SPDH 8 Mb/s PRBS(15) HDB3 Errors present 3060 SPDH (Unbalanced) Signal Loss 3061 SPDH 2 Mb/S PRBS(15) HDB3 Pattern loss 3064 SPDH 2 Mb/S PRBS(15) HBD3 Errors present 3070 SPDH (Unbalanced) Signal Loss 3071 SPDH 2 Mb/s PRBS(15) AMI Pattern loss 3074 SPDH 2 Mb/s PRBS(15) AMI Errors present 3080 SPDH (Balanced) Signal Loss 3081 SPDH 2 Mb/s PRBS(15) (Bal) HDB3 Pattern loss 3084 SPDH 2 Mb/s PRBS(15) (Bal) HBD3 Errors present
10
Self Test Error Codes
Self Test Error Codes
3090 SPDH (Balanced) Signal Loss 3091 SPDH 2 Mb/s PRBS(15) (Bal) AMI Pattern loss 3094 SPDH 2 Mb/s PRBS(15) (Bal) AMI Errors present 3100 SPDH (Unbalanced) Signal Loss 3102 SPDH 140 Mb/s - Offset = 0 ppm VCXO Not Settled 3103 SPDH 140 Mb/s - Offset = 0 ppm Result low 3104 SPDH 140 Mb/s - Offset = 0 ppm Result high 3110 SPDH (Unbalanced) Signal Loss 3112 SPDH 140 Mb/s - Offset = +100 ppm VCXO Not Settled 3113 SPDH 140 Mb/s - Offset = +100 ppm Result low 3114 SPDH 140 Mb/s - Offset = +100 ppm Result high 3120 SPDH (Unbalanced) Signal Loss 3122 SPDH 140 Mb/s - Offset = -100 ppm VCXO Not Settled 3123 SPDH 140 Mb/s - Offset = -100 ppm Result low 3124 SPDH 140 Mb/s - Offset = -100 ppm Result high 3130 SPDH (Unbalanced) Signal Loss 3132 SPDH 34 Mb/s - Offset = 0 ppm VCXO Not Settled 3133 SPDH 34 Mb/s - Offset = 0 ppm Result low 3134 SPDH 34 Mb/s - Offset = 0 ppm Result high 3140 SPDH (Unbalanced) Signal Loss 3142 SPDH 34 Mb/s - Offset = +100 ppm VCXO Not Settled 3143 SPDH 34 Mb/s - Offset = +100 ppm Result low 3144 SPDH 34 Mb/s - Offset = +100 ppm Result high 3150 SPDH (Unbalanced) Signal Loss 3152 SPDH 34 Mb/s - Offset = -100 ppm VCXO Not Settled 3153 SPDH 34 Mb/s - Offset = -100 ppm Result low 3154 SPDH 34 Mb/s - Offset = -100 ppm Result high 3160 SPDH (Unbalanced) Signal Loss 3162 SPDH 8 Mb/s - Offset = 0 ppm VCXO Not Settled 3163 SPDH 8 Mb/s - Offset = 0 ppm Result low 3164 SPDH 8 Mb/s - Offset = 0 ppm Result high 3170 SPDH (Unbalanced) Signal Loss 3172 SPDH 8 Mb/s - Offset = +100 ppm VCXO Not Settled 3173 SPDH 8 Mb/s - Offset = +100 ppm Result low 3174 SPDH 8 Mb/s - Offset = +100 ppm Result high 3180 SPDH (Unbalanced) Signal Loss 3182 SPDH 8 Mb/s - Offset = -100 ppm VCXO Not Settled 3183 SPDH 8 Mb/s - Offset = -100 ppm Result low 3184 SPDH 8 Mb/s - Offset = -100 ppm Result high 3190 SPDH (Unbalanced) Signal Loss 3192 SPDH 2 Mb/s - Offset = 0 ppm VCXO Not Settled 3193 SPDH 2 Mb/s - Offset = 0 ppm Result low 3194 SPDH 2 Mb/s - Offset = 0 ppm Result high 3200 SPDH (Unbalanced) Signal Loss 3202 SPDH 2 Mb/s - Offset = +100 ppm VCXO Not Settled 3203 SPDH 2 Mb/s - Offset = +100 ppm Result low
11
Self Test Error Codes
Self Test Error Codes
3204 SPDH 2 Mb/s - Offset = +100 ppm Result high 3210 SPDH (Unbalanced) Signal Loss 3212 SPDH 2 Mb/s - Offset = -100 ppm VCXO Not Settled 3213 SPDH 2 Mb/s - Offset = -100 ppm Result low 3214 SPDH 2 Mb/s - Offset = -100 ppm Result high 3223 SPDH 34 Mb/s - CODE error add = OFF Result low 3224 SPDH 34 Mb/s - CODE error add = OFF Result high 3226 SPDH 34 Mb/s - CODE error add = OFF Result Invalid 3233 SPDH 34 Mb/s - CODE error add = SINGLE Result low 3234 SPDH 34 Mb/s - CODE error add = SINGLE Result high 3236 SPDH 34 Mb/s - CODE error add = SINGLE Result Invalid 3243 SPDH 34 Mb/s - CODE error add = 1.0E-3 Result low 3244 SPDH 34 Mb/s - CODE error add = 1.0E-3 Result high 3246 SPDH 34 Mb/s - CODE error add = 1.0E-3 Result Invalid 3253 SPDH 34 Mb/s - FAS error add = OFF Result low 3254 SPDH 34 Mb/s - FAS error add = OFF Result high 3256 SPDH 34 Mb/s - FAS error add = OFF Result Invalid 3263 SPDH 34 Mb/s - FAS error add = SINGLE Result low 3264 SPDH 34 Mb/s - FAS error add = SINGLE Result high 3266 SPDH 34 Mb/s - FAS error add = SINGLE Result Invalid 3273 SPDH 34 Mb/s - FAS error add = 1.0E-3 Result low 3274 SPDH 34 Mb/s - FAS error add = 1.0E-3 Result high 3276 SPDH 34 Mb/s - FAS error add = 1.0E-3 Result Invalid 3283 SPDH 34 Mb/s - BIT error add = OFF Result low 3284 SPDH 34 Mb/s - BIT error add = OFF Result high 3286 SPDH 34 Mb/s - BIT error add = OFF Result Invalid 3293 SPDH 34 Mb/s - BIT error add = SINGLE Result low 3294 SPDH 34 Mb/s - BIT error add = SINGLE Result high 3296 SPDH 34 Mb/s - BIT error add = SINGLE Result Invalid 3303 SPDH 34 Mb/s - BIT error add = 1.0E-3 Result low 3304 SPDH 34 Mb/s - BIT error add = 1.0E-3 Result high 3306 SPDH 34 Mb/s - BIT error add = 1.0E-3 Result Invalid 3313 SPDH 2 Mb/s - FAS error add = OFF Result low 3314 SPDH 2 Mb/s - FAS error add = OFF Result high 3316 SPDH 2 Mb/s - FAS error add = OFF Result Invalid 3323 SPDH 2 Mb/s - FAS error add = SINGLE Result low 3324 SPDH 2 Mb/s - FAS error add = SINGLE Result high 3326 SPDH 2 Mb/s - FAS error add = SINGLE Result Invalid 3333 SPDH 2 Mb/s - FAS error add = 1.0E-3 Result low 3334 SPDH 2 Mb/s - FAS error add = 1.0E-3 Result high 3336 SPDH 2 Mb/s - FAS error add = 1.0E-3 Result Invalid 3343 SPDH 2 Mb/s - BIT error add = OFF Result low 3344 SPDH 2 Mb/s - BIT error add = OFF Result high 3346 SPDH 2 Mb/s - BIT error add = OFF Result Invalid 3353 SPDH 2 Mb/s - BIT error add = SINGLE Result low 3354 SPDH 2 Mb/s - BIT error add = SINGLE Result high
12
Self Test Error Codes
Self Test Error Codes
3356 SPDH 2 Mb/s - BIT error add = SINGLE Result Invalid 3363 SPDH 2 Mb/s - BIT error add = 1.0E-3 Result low 3364 SPDH 2 Mb/s - BIT error add = 1.0E-3 Result high 3366 SPDH 2 Mb/s - BIT error add = 1.0E-3 Result Invalid 3377 SPDH 140 Mb/s Unframed - Loss Of Frame Detected 3386 SPDH 140 Mb/s Framed - Loss Of Frame Not Detected 3387 SPDH 140 Mb/s Framed - Loss Of Frame Detected 3396 SPDH 2 Mb/s Unframed - Loss Of Frame Not Detected 3397 SPDH 2 Mb/s Unframed - Loss Of Frame Detected 3406 SPDH 2 Mb/s PCM30 - Loss Of Frame Not Detected 3407 SPDH 2 Mb/s PCM30 - Loss Of Frame Detected 3408 SPDH 2 Mb/s PCM30 - Loss Of Multiframe Not Detected 3409 SPDH 2 Mb/s PCM30 - Loss Of Multiframe Detected 3416 SPDH 2 Mb/s PCM31 - Loss Of Frame Not Detected 3417 SPDH 2 Mb/s PCM31 - Loss Of Frame Detected 3426 SPDH 2 Mb/s PCM30CRC - Loss Of Frame Not Detected 3427 SPDH 2 Mb/s PCM30CRC - Loss Of Frame Detected 3428 SPDH 2 Mb/s PCM30CRC - Loss Of Multiframe Not Detected 3429 SPDH 2 Mb/s PCM30CRC - Loss Of Multiframe Detected 3436 SPDH 2 Mb/s PCM31CRC - Loss Of Frame Not Detected 3437 SPDH 2 Mb/s PCM31CRC - Loss Of Frame Detected 3446 SPDH 2 Mb/s Drop - Loss Of Frame Not Detected 3447 SPDH 2 Mb/s Drop - Loss Of Frame Detected 3448 SPDH 2 Mb/s Drop - Loss Of Multiframe Not Detected 3449 SPDH 2 Mb/s Drop - Loss Of Multiframe Detected 3451 SPDH 140 Mb/s struct 34 Mb/s - Pattern Loss 3454 SPDH 140 Mb/s struct 34 Mb/s - Pattern Errors Present 3461 SPDH 140 Mb/s struct 8 Mb/s - Pattern Loss 3464 SPDH 140 Mb/s struct 8 Mb/s - Pattern Errors Present 3471 SPDH 140 Mb/s struct 2 Mb/s - Pattern Loss 3474 SPDH 140 Mb/s struct 2 Mb/s - Pattern Errors Present 3481 SPDH 140 Mb/s struct 64 kb/s - Pattern Loss 3484 SPDH 140 Mb/s struct 64 kb/s - Pattern Errors Present 3491 SPDH 140 Mb/s struct Nx64 kb/s (odd channels) - Pattern Loss 3494 SPDH 140 Mb/s struct Nx64 kb/s (odd channels) - Pattern Errors Present 3501 SPDH 140 Mb/s struct Nx64 kb/s (even channels) - Pattern Loss 3504 SPDH 140 Mb/s struct Nx64 kb/s (even channels) - Pattern Errors Present 3511 SPDH 34 Mb/s struct 8 Mb/s - Pattern Loss 3514 SPDH 34 Mb/s struct 8 Mb/s - Pattern Errors Present 3521 SPDH 34 Mb/s struct 2 Mb/s - Pattern Loss 3524 SPDH 34 Mb/s struct 2 Mb/s - Pattern Errors Present 3531 SPDH 8 Mb/s struct 2 Mb/s - Pattern Loss 3534 SPDH 8 Mb/s struct 2 Mb/s - Pattern Errors Present 3541 SPDH 140 Mb/s Unframed - PRBS(9) INV Pattern Loss 3544 SPDH 140 Mb/s Unframed - PRBS(9) INV Pattern Errors Present 3551 SPDH 140 Mb/s Unframed - PRBS(11) NON-INV Pattern Loss
13
Self Test Error Codes
Self Test Error Codes
3554 SPDH 140 Mb/s Unframed - PRBS(11) NON-INV Pattern Errors Present 3561 SPDH 140 Mb/s Unframed - PRBS(15) INV Pattern Loss 3564 SPDH 140 Mb/s Unframed - PRBS(15) INV Pattern Errors Present 3571 SPDH 140 Mb/s Unframed - PRBS(23) NON-INV Pattern Loss 3574 SPDH 140 Mb/s Unframed - PRBS(23) NON-INV Pattern Errors Present 3581 SPDH 140 Mb/s Unframed - User Word Pattern Loss 3584 SPDH 140 Mb/s Unframed - User Word Pattern Errors Present 3591 SPDH 2 Mb/s Unframed - PRBS(9) NON-INV Pattern Loss 3594 SPDH 2 Mb/s Unframed - PRBS(9) NON-INV Pattern Errors Present 3601 SPDH 2 Mb/s Unframed - PRBS(11) INV Pattern Loss 3604 SPDH 2 Mb/s Unframed - PRBS(11) INV Pattern Errors Present 3611 SPDH 2 Mb/s Unframed - PRBS(15) NON-INV Pattern Loss 3614 SPDH 2 Mb/s Unframed - PRBS(15) NON-INV Pattern Errors Present 3621 SPDH 2 Mb/s Unframed - PRBS(23) INV Pattern Loss 3624 SPDH 2 Mb/s Unframed - PRBS(23) INV Pattern Errors Present 3631 SPDH 2 Mb/s Unframed - User Word Pattern Loss 3634 SPDH 2 Mb/s Unframed - User Word Pattern Errors Present 3641 SPDH 8 Mb/s struct 2 Mb/s insert/drop - Insert Port Not Settled 3644 SPDH 8 Mb/s struct 2 Mb/s insert/drop - Drop Port Not Settled 3651 SPDH 140 Mb/s struct 64 kb/s delay = 0s - Result Invalid 3652 SPDH 140 Mb/s struct 64 kb/s delay = 0s - Timeout 3653 SPDH 140 Mb/s struct 64 kb/s delay = 0s - Result low 3654 SPDH 140 Mb/s struct 64 kb/s delay = 0s - Result high 3661 SPDH 140 Mb/s struct 64 kb/s delay = 2s - Result Invalid 3662 SPDH 140 Mb/s struct 64 kb/s delay = 2s - Timeout 3663 SPDH 140 Mb/s struct 64 kb/s delay = 2s - Result low 3664 SPDH 140 Mb/s struct 64 kb/s delay = 2s - Result high 3671 SPDH 34 Mb/s struct 64 kb/s delay = 0s - Result Invalid 3672 SPDH 34 Mb/s struct 64 kb/s delay = 0s - Timeout 3673 SPDH 34 Mb/s struct 64 kb/s delay = 0s - Result low 3674 SPDH 34 Mb/s struct 64 kb/s delay = 0s - Result high 3681 SPDH 34 Mb/s struct 64 kb/s delay = 2s - Result Invalid 3682 SPDH 34 Mb/s struct 64 kb/s delay = 2s - Timeout 3683 SPDH 34 Mb/s struct 64 kb/s delay = 2s - Result low 3684 SPDH 34 Mb/s struct 64 kb/s delay = 2s - Result high 3691 SPDH 8 Mb/s struct 64 kb/s delay = 0s - Result Invalid 3692 SPDH 8 Mb/s struct 64 kb/s delay = 0s - Timeout 3693 SPDH 8 Mb/s struct 64 kb/s delay = 0s - Result low 3694 SPDH 8 Mb/s struct 64 kb/s delay = 0s - Result high 3701 SPDH 8 Mb/s struct 64 kb/s delay = 2s - Result Invalid 3702 SPDH 8 Mb/s struct 64 kb/s delay = 2s - Timeout 3703 SPDH 8 Mb/s struct 64 kb/s delay = 2s - Result low 3704 SPDH 8 Mb/s struct 64 kb/s delay = 2s - Result high 3711 SPDH 2 Mb/s struct 64 kb/s delay = 0s - Result Invalid 3712 SPDH 2 Mb/s struct 64 kb/s delay = 0s - Timeout 3713 SPDH 2 Mb/s struct 64 kb/s delay = 0s - Result low
14
Self Test Error Codes
Self Test Error Codes
3714 SPDH 2 Mb/s struct 64 kb/s delay = 0s - Result high 3721 SPDH 2 Mb/s struct 64 kb/s delay = 2s - Result Invalid 3722 SPDH 2 Mb/s struct 64 kb/s delay = 2s - Timeout 3723 SPDH 2 Mb/s struct 64 kb/s delay = 2s - Result low 3724 SPDH 2 Mb/s struct 64 kb/s delay = 2s - Result high 3730 SPDH BIN ECL 140 Mb/s Signal Loss 3731 SPDH BIN ECL 140 Mb/s Pattern Loss 3733 SPDH BIN ECL 140 Mb/s Result low 3734 SPDH BIN ECL 140 Mb/s Result high 3740 SPDH BIN ECL 140 Mb/s Signal Loss 3741 SPDH BIN ECL 140 Mb/s Pattern Loss 3744 SPDH BIN ECL 140 Mb/s Result high 3750 SPDH BIN TTL 34 Mb/s Signal Loss 3751 SPDH BIN TTL 34 Mb/s Pattern Loss 3753 SPDH BIN TTL 34 Mb/s Result low 3754 SPDH BIN TTL 34 Mb/s Result high 3760 SPDH BIN TTL 34 Mb/s Signal Loss 3761 SPDH BIN TTL 34 Mb/s Pattern Loss 3764 SPDH BIN TTL 34 Mb/s Result high 3770 SPDH BIN TTL 8 Mb/s Signal Loss 3771 SPDH BIN TTL 8 Mb/s Pattern Loss 3773 SPDH BIN TTL 8 Mb/s Result low 3774 SPDH BIN TTL 8 Mb/s Result high 3780 SPDH BIN TTL 8 Mb/s Signal Loss 3781 SPDH BIN TTL 8 Mb/s Pattern Loss 3784 SPDH BIN TTL 8 Mb/s Result high 3790 SPDH BIN TTL 2 Mb/s Signal Loss 3791 SPDH BIN TTL 2 Mb/s Pattern Loss 3793 SPDH BIN TTL 2 Mb/s Result low 3794 SPDH BIN TTL 2 Mb/s Result high 3800 SPDH BIN TTL 2 Mb/s Signal Loss 3801 SPDH BIN TTL 2 Mb/s Pattern Loss 3804 SPDH BIN TTL 2 Mb/s Result high 3810 SPDH BIN ECL 140 Mb/s Signal Loss 3811 SPDH BIN ECL 140 Mb/s Pattern Loss 3814 SPDH BIN ECL 140 Mb/s User Pattern Result high 3820 SPDH BIN TTL 34 Mb/s User Pattern Signal Loss 3821 SPDH BIN TTL 34 Mb/s User Pattern Pattern Loss 3824 SPDH BIN TTL 34 Mb/s User Pattern Result high 3830 SPDH (Unbalanced) Signal Loss 3831 SPDH DS3 PRBS(23) Pattern Loss 3834 SPDH DS3 PRBS(23) Errors present 3840 SPDH (Unbalanced) Signal Loss 3841 SPDH DS3 WORD1 Pattern Loss 3844 SPDH DS3 WORD1 Errors present 3850 SPDH (Unbalanced) Signal Loss
15
Self Test Error Codes
Self Test Error Codes
3851 SPDH DS3 WORD2 Pattern Loss 3854 SPDH DS3 WORD2 Errors present 3860 SPDH (Unbalanced) Signal Loss 3861 SPDH DS1 PRBS(20) Pattern Loss 3864 SPDH DS1 PRBS(20) Errors present 3870 SPDH (Balanced) Signal Loss 3871 SPDH DS1 PRBS(15) (Bal) B8ZS Pattern Loss 3874 SPDH DS1 PRBS(15) (Bal) B8ZS Errors Present 3880 SPDH (Balanced) Signal Loss 3881 SPDH DS1 QRSS (Bal) AMI Pattern Loss 3884 SPDH DS1 QRSS (Bal) AMI Errors Present 3890 SPDH (Unbalanced) Signal Loss 3891 SPDH DS3 - Offset = 0 ppm VCXO Not Settled 3893 SPDH DS3 - Offset = 0 ppm Result low 3894 SPDH DS3 - Offset = 0 ppm Result high 3900 SPDH (Unbalanced) Signal Loss 3901 SPDH DS3 - Offset = +100 ppm VCXO Not Settled 3903 SPDH DS3 - Offset = +100 ppm Result low 3904 SPDH DS3 - Offset = +100 ppm Result high 3910 SPDH (Unbalanced) Signal Loss 3911 SPDH DS3 - Offset = -100 ppm VCXO Not Settled 3913 SPDH DS3 - Offset = -100 ppm Result low 3914 SPDH DS3 - Offset = -100 ppm Result high 3920 SPDH (Unbalanced) Signal Loss 3921 SPDH DS1 - Offset = 0 ppm VCXO Not Settled 3923 SPDH DS1 - Offset = 0 ppm Result low 3924 SPDH DS1 - Offset = 0 ppm Result high 3930 SPDH (Unbalanced) Signal Loss 3931 SPDH DS1 - Offset = +100 ppm VCXO Not Settled 3933 SPDH DS1 - Offset = +100 ppm Result low 3934 SPDH DS1 - Offset = +100 ppm Result high 3940 SPDH (Unbalanced) Signal Loss 3941 SPDH DS1 - Offset = -100 ppm VCXO Not Settled 3943 SPDH DS1 - Offset = -100 ppm Result low 3944 SPDH DS1 - Offset = -100 ppm Result high 3953 SPDH DS3 - CODE error add = OFF Result low 3954 SPDH DS3 - CODE error add = OFF Result high 3956 SPDH DS3 - CODE error add = OFF Result Invalid 3963 SPDH DS3 - CODE error add = SINGLE Result low 3964 SPDH DS3 - CODE error add = SINGLE Result high 3966 SPDH DS3 - CODE error add = SINGLE Result Invalid 3973 SPDH DS3 - CODE error add = 1.0E-3 Result low 3974 SPDH DS3 - CODE error add = 1.0E-3 Result high 3976 SPDH DS3 - CODE error add = 1.0E-3 Result Invalid 3983 SPDH DS3 - FAS error add = OFF Result low 3984 SPDH DS3 - FAS error add = OFF Result high
16
Self Test Error Codes
Self Test Error Codes
3986 SPDH DS3 - FAS error add = OFF Result Invalid 3993 SPDH DS3 - FAS error add = SINGLE Result low 3994 SPDH DS3 - FAS error add = SINGLE Result high 3996 SPDH DS3 - FAS error add = SINGLE Result Invalid 7101 ODL not running 7102 STM-1 POH Test Failed 7104 STM-1 SOH Test Failed 7111 STM-1 VC-4 POH message failure 7121 STM-1 Frame or Pointer Sync Loss 7123 STM-1 B1 BIP Errors low 7124 STM-1 B1 BIP Errors high 7131 STM-1 Frame or Pointer Sync Loss 7133 STM-1 B2 BIP Errors low 7134 STM-1 B2 BIP Errors high 7141 STM-1 Frame or Pointer Sync Loss 7143 STM-1 B3 BIP Errors low 7144 STM-1 B3 BIP Errors high 7151 STM-1 Frame or Pointer Sync Loss 7153 STM-1 (M1) MS-REI Errors low 7154 STM-1 (M1) MS-REI Errors high 7161 STM-1 Frame or Pointer Sync Loss 7163 STM-1 (Z5) AU-4 HP-IEC Errors low 7164 STM-1 (Z5) AU-4 HP-IEC Errors high 7171 STM-1 Frame A1A2 errors OFF, LOF 7172 STM-1 Frame A1A2 1 in 4 errors, LOF 7173 STM-1 Frame A1A2 2 in 4 errors, LOF 7174 STM-1 Frame A1A2 3 in 4 errors, LOF 7175 STM-1 Frame A1A2 4 in 4 errors, NO LOF 7176 STM-1 Frame A1A2 3 in 4 errors, NO LOF 7177 STM-1 Frame A1A2 2 in 4 errors, LOF 7178 STM-1 Frame A1A2 1 in 4 errors, LOF 7179 STM-1 Frame A1A2 errors OFF, LOF 7181 STM-1 140M Pattern Sync loss 7183 STM-1 140M Bit Errors low 7184 STM-1 140M Bit Errors high 7191 STM-1 140M +100ppm Pattern Sync loss 7193 STM-1 140M +100ppm Bit Errors low 7194 STM-1 140M +100ppm Bit Errors high 7201 STM-1 140M -100ppm Pattern Sync loss 7203 STM-1 140M -100ppm Bit Errors low 7204 STM-1 140M -100ppm Bit Errors high 7211 STM-1 VC-3 POH message failure 7221 STM-1 Frame or Pointer Sync Loss 7223 STM-1 VC-3 B3 BIP Errors low 7224 STM-1 VC-3 B3 BIP Errors high 7231 STM-1 Frame or Pointer Sync Loss
17
Self Test Error Codes
Self Test Error Codes
7233 STM-1 VC-3 LP-REI Errors low 7234 STM-1 VC-3 LP-REI Errors high 7241 STM-1 TU3 Pattern Sync loss 7243 STM-1 TU3 Bit Errors low 7244 STM-1 TU3 Bit Errors high 7251 STM-1 TU3 TUG[2] Pattern Sync loss 7261 STM-1 TU3 TUG[1] 01010110 Pattern Sync loss 7262 STM-1 TU3 TUG[3] 00001110 Pattern Sync loss 7271 STM-1 TU12 Async, Frame or Pointer Sync Loss 7284 STM-1 TU12 Async, B1 BIP Errors 7294 STM-1 TU12 Async, B2 BIP Errors 7304 STM-1 TU12 Async, B3 BIP Errors 7314 STM-1 TU12 Async, HP-REI Errors 7324 STM-1 TU12 Async, VC-12 V5 BIP Errors 7334 STM-1 TU12 Async, VC-12 V5 LP-REI Errors 7341 STM-1 TU12 Fl Byte sync, Frame or Pointer Sync Loss 7354 STM-1 TU12 Fl Byte sync, B1 BIP Errors 7364 STM-1 TU12 Fl Byte sync, B2 BIP Errors 7374 STM-1 TU12 Fl Byte sync, B3 BIP Errors 7384 STM-1 TU12 Fl Byte sync, HP-REI Errors 7394 STM-1 TU12 Fl Byte sync, VC-12 V5 BIP Errors 7404 STM-1 TU12 Fl Byte sync, VC-12 V5 LP-REI Errors 7411 STM-1 Frame or Pointer Sync Loss 7413 STM-1 VC-12 V5 BIP Error Rate low 7414 STM-1 VC-12 V5 BIP Error Rate high 7421 STM-1 Frame or Pointer Sync Loss 7423 STM-1 VC-12 V5 LP-REI Error Rate low 7424 STM-1 VC-12 V5 LP-REI Error Rate high 7431 STM-1 TU12 Async, Pattern Sync loss 7433 STM-1 TU12 Async, Bit Errors low 7434 STM-1 TU12 Async, Bit Errors high 7441 STM-1 TU12 Fl Byte sync, Pattern Sync loss 7443 STM-1 TU12 Fl Byte sync, Bit Errors low 7444 STM-1 TU12 Fl Byte sync, Bit Errors high 7451 STM-1 140M PRBS 23 Pattern Sync Loss 7453 STM-1 140M PRBS 23 Bit Errors low 7454 STM-1 140M PRBS 23 Bit Errors high 7461 STM-1 TU3 PRBS 15 Pattern Sync Loss 7463 STM-1 TU3 PRBS 15 Bit Errors low 7464 STM-1 TU3 PRBS 15 Bit Errors high 7471 STM-1 TU12 1100010011110110 Pattern Sync Loss 7473 STM-1 TU12 1100010011110110 Bit Errors low 7474 STM-1 TU12 1100010011110110 Bit Errors high 7481 STM-1 TU2 PRBS 9 Pattern Sync Loss 7483 STM-1 TU2 PRBS 9 Bit Errors low 7484 STM-1 TU2 PRBS 9 Bit Errors high
18
Self Test Error Codes
Self Test Error Codes
7491 STM-1 TU12 Background Pattern same as Test Pattern 7501 STM-1 TU12 Background Pattern failure 7511 STM-1 TU2 Pattern Sync loss 7513 STM-1 TU2 Bit Errors low 7514 STM-1 TU2 Bit Errors high 7521 STM-1 140M Freq Off Ptr Mvts: Frame Sync Loss 7531 STM-1 140M Freq Off Ptr Mvts: Pointer Sync Loss 7544 STM-1 140M Freq Off Ptr Mvts: B1 BIP Errors 7554 STM-1 140M Freq Off Ptr Mvts: B2 BIP Errors 7564 STM-1 140M Freq Off Ptr Mvts: B3 BIP Errors 7573 STM-1 140M Freq Off Ptr Mvts: +100ppm, Imp VC Offset low 7574 STM-1 140M Freq Off Ptr Mvts: +100ppm, Imp VC Offset high 7583 STM-1 140M Freq Off Ptr Mvts: -100ppm, Imp VC Offset low 7584 STM-1 140M Freq Off Ptr Mvts: -100ppm, Imp VC Offset high 7591 STM-1 TU3 Freq Off Ptr Mvts: Frame Sync Loss 7601 STM-1 TU3 Freq Off Ptr Mvts: Pointer Sync Loss 7614 STM-1 TU3 Freq Off Ptr Mvts: B1 BIP Errors 7624 STM-1 TU3 Freq Off Ptr Mvts: B2 BIP Errors 7634 STM-1 TU3 Freq Off Ptr Mvts: B3 BIP Errors 7644 STM-1 TU3 Freq Off Ptr Mvts: TU BIP Errors 7653 STM-1 TU3 Freq Off Ptr Mvts: +100ppm, Imp VC Offset low 7654 STM-1 TU3 Freq Off Ptr Mvts: +100ppm, Imp VC Offset high 7663 STM-1 TU3 Freq Off Ptr Mvts: -100ppm, Imp VC Offset low 7664 STM-1 TU3 Freq Off Ptr Mvts: -100ppm, Imp VC Offset high 7671 STM-1 TU12 Freq Off Ptr Mvts: Frame Sync Loss 7681 STM-1 TU12 Freq Off Ptr Mvts: Pointer Sync Loss 7694 STM-1 TU12 Freq Off Ptr Mvts: B1 BIP Errors 7704 STM-1 TU12 Freq Off Ptr Mvts: B2 BIP Errors 7714 STM-1 TU12 Freq Off Ptr Mvts: B3 BIP Errors 7724 STM-1 TU12 Freq Off Ptr Mvts: TU BIP Errors 7733 STM-1 TU12 Freq Off Ptr Mvts: +100ppm, Imp VC Offset low 7734 STM-1 TU12 Freq Off Ptr Mvts: +100ppm, Imp VC Offset high 7743 STM-1 TU12 Freq Off Ptr Mvts: -100ppm, Imp VC Offset low 7744 STM-1 TU12 Freq Off Ptr Mvts: -100ppm, Imp VC Offset high 7751 STM-1 Thru Mode - No H4 Frame Alignment 7761 STM-1 RSOH DCC Test Failure 7771 STM-1 MSOH DCC Test Failure 7781 STM-1 AU-4 Bulk TX, AU-4 Unfrm RX : Fail to get PSL 7782 STM-1 AU-4 Bulk: Pattern Sync Loss 7791 STM-1 TU-3 Bulk TX, AU-4 Unfrm RX : Fail to get PSL 7792 STM-1 TU-3 Bulk: Pattern Sync Loss 7801 STM-1 TU-12 Bulk TX, AU-4 Unfrm RX : Fail to get PSL 7802 STM-1 TU-12 Bulk: Pattern Sync Loss 7811 STM-1 DS-3 Unfrm TX, AU-4 Unfrm RX : Fail to get PSL 7812 STM-1 DS-3 Unfrm: Pattern Sync Loss 7821 STM-1 DS-3 M13 TX, AU-4 Unfrm RX : Fail to get PSL
19
Self Test Error Codes
Self Test Error Codes
7822 STM-1 DS-3 M13: Pattern Sync Loss 7831 STM-1 DS-3 C-Bit TX, AU-4 Unfrm RX : Fail to get PSL 7832 STM-1 DS-3 C-Bit: Pattern Sync Loss 7841 STM-1 DS-1 Unfrm TX, AU-4 Unfrm RX : Fail to get PSL 7842 STM-1 DS-1 Unfrm: Pattern Sync Loss 7851 STM-1 DS-1 D4 TX, AU-4 Unfrm RX : Fail to get PSL 7852 STM-1 DS-1 D4: Pattern Sync Loss 7861 STM-1 DS-1 ESF TX, AU-4 Unfrm RX : Fail to get PSL 7862 STM-1 DS-1 ESF: Pattern Sync Loss 7871 STM-1 DS-1 SLC-96 TX, AU-4 Unfrm RX : Fail to get PSL 7872 STM-1 DS-1 SLC-96: Pattern Sync Loss 7881 STM-1 AU-4 J0 message failure 7891 STM-1 AU-4 Bulk PRBS 11 Pattern Sync Loss 7893 STM-1 AU-4 Bulk PRBS 11 Bit Errors low 7894 STM-1 AU-4 Bulk PRBS 11 Bit Errors high 7901 STM-1 TU-3 Bulk PRBS 9 Pattern Sync Loss 7903 STM-1 TU-3 Bulk PRBS 9 Bit Errors low 7904 STM-1 TU-3 Bulk PRBS 9 Bit Errors high 7911 STM-1 TU-12 Bulk 1100010011110110 Pattern Sync Loss 7913 STM-1 TU-12 Bulk 1100010011110110 Bit Errors low 7914 STM-1 TU-12 Bulk 1100010011110110 Bit Errors high 7921 STM-1 DS-3 Unfrm PRBS 20 Pattern Sync Loss 7923 STM-1 DS-3 Unfrm PRBS 20 Bit Errors low 7924 STM-1 DS-3 Unfrm PRBS 20 Bit Errors high 7931 STM-1 DS-1 Unfrm QRSS Pattern Sync Loss 7933 STM-1 DS-1 Unfrm QRSS Bit Errors low 7934 STM-1 DS-1 Unfrm QRSS Bit Errors high 7941 STM-1 TU-3 Mixed Payl: TUG3#2 TU-12 mapping shows PSL 7945 STM-1 TU-3 Mixed Payl: TUG3#2 TU-12 mapping shows TU-AIS" 7946 STM-1 TU-3 Mixed Payl: TUG3#2 TU-12 mapping shows LP-RDI 7947 STM-1 TU-3 Mixed Payl: TUG3#2 TU-12 mapping shows TU-LOP" 7951 STM-1 TU-3 Mixed Payl: TUG3#1 TU-3 mapping shows PSL 7961 STM-1 TU-3 Mixed Payl: TUG3#3 TU-3 mapping shows PSL 7971 STM-1 TU-12 Mixed Payl: TUG3#1 TU-3 mapping shows PSL 7975 STM-1 TU-12 Mixed Payl: TUG3#1 TU-3 mapping shows TU-AIS" 7976 STM-1 TU-12 Mixed Payl: TUG3#1 TU-3 mapping shows LP-RDI 7977 STM-1 TU-12 Mixed Payl: TUG3#1 TU-3 mapping shows TU-LOP" 7981 STM-1 TU-12 Mixed Payl: TUG3#2 TU-12 mapping shows PSL 7991 STM-1 TU-12 Mixed Payl: TUG3#3 TU-12 mapping shows PSL 8104 STM-1 B3 BIP Errors 8114 STM-1 HP-REI Errors 8121 STM-1 VC-4 POH message failure 8131 STM-1 Frame or Pointer Sync Loss 8133 STM-1 B1 BIP Errors low 8134 STM-1 B1 BIP Errors high 8141 STM-1 Frame or Pointer Sync Loss
20
Self Test Error Codes
Self Test Error Codes
8143 STM-1 B2 BIP Errors low 8144 STM-1 B2 BIP Errors high 8151 STM-1 Frame or Pointer Sync Loss 8153 STM-1 B3 BIP Errors low 8161 STM-1 140M Pattern Sync loss 8163 STM-1 140M Bit Errors low 8164 STM-1 140M Bit Errors high 8171 STM-1 Frame or Pointer Sync Loss 8184 STM-1 B1 BIP Errors 8194 STM-1 B2 BIP Errors 8204 STM-1 VC-3 B3 BIP Errors 8214 STM-1 VC-3 LP-REI Errors 8221 STM-1 VC-3 POH message failure 8231 STM-1 Frame or Pointer Sync Loss 8233 STM-1 VC-3 LP-REI Error Rate low 8234 STM-1 VC-3 LP-REI Error Rate high 8241 STM-1 34M Pattern Sync loss 8243 STM-1 34M Bit Error Rate low 8244 STM-1 34M Bit Error Rate high 8251 STM-1 Frame or Pointer Sync Loss 8264 STM-1 B1 BIP Errors 8274 STM-1 B2 BIP Errors 8284 STM-1 B3 BIP Errors 8294 STM-1 HP-REI Errors 8304 STM-1 VC-12 V5 BIP Errors 8314 STM-1 VC-12 V5 LP-REI Errors 8321 STM-1 Frame or Pointer Sync Loss 8323 STM-1 VC-12 V5 BIP Error Rate low 8324 STM-1 VC-12 V5 BIP Error Rate high 8331 STM-1 Frame or Pointer Sync Loss 8333 STM-1 VC-12 V5 LP-REI Error Rate low 8334 STM-1 VC-12 V5 LP-REI Error Rate high 8341 STM-1 2M Pattern Sync loss 8343 STM-1 2M Bit Error Rate low 8344 STM-1 2M Bit Error Rate high 8351 STM-1 140M PRBS 23 Pattern Sync Loss 8354 STM-1 140M PRBS 23 Bit Errors 8361 STM-1 34M PRBS 23 Pattern Sync Loss 8364 STM-1 34M PRBS 23 Bit Errors 8371 STM-1 2M PRBS 23 Pattern Sync Loss 8374 STM-1 2M PRBS 23 Bit Errors 8381 STM-1 2M PRBS 15 Pattern Sync Loss 8384 STM-1 2M PRBS 15 Bit Errors 8391 STM-1 34M PRBS 15 Pattern Sync Loss 8394 STM-1 34M PRBS 15 Bit Errors 8401 STM-1 140M PRBS 15 Pattern Sync Loss
21
Self Test Error Codes
Self Test Error Codes
8404 STM-1 140M PRBS 15 Bit Errors 8411 STM-1 2M All Ones Pattern Sync Loss 8414 STM-1 2M All Ones Bit Errors 8421 STM-1 34M All Zeros Pattern Sync Loss 8424 STM-1 34M All Zeros Bit Errors 8431 STM-1 140M All Ones Pattern Sync Loss 8434 STM-1 140M All Ones Bit Errors 8441 STM-1 140M 1010 Pattern Sync Loss 8444 STM-1 140M 1010 Bit Errors 8451 STM-1 140M 1100010011110110 Pattern Sync Loss 8454 STM-1 140M 1100010011110110 Bit Errors 8461 STM-1 34M 1111111111111110 Pattern Sync Loss 8464 STM-1 34M 1111111111111110 Bit Errors 8471 STM-1 2M 1100010011110110 Pattern Sync Loss 8474 STM-1 2M 1100010011110110 Bit Errors 8481 STM-1 2M Background Pattern same as Test Pattern 8491 STM-1 2M Background Pattern failure 8511 STM-1 Out of Frame 8512 STM-1 Frame Loss 8521 STM-1 No Out of Frame history 8522 STM-1 Frame Loss history 8531 STM-1 Out of Frame not cancelled 8532 STM-1 Frame Loss 8541 STM-1 Pattern Sync Loss 8553 STM-1 No MS-AIS alarm 8564 STM-1 MS-AIS alarm not cancelled 8571 STM-1 Pattern Sync Loss 8583 STM-1 No MS-RDI alarm 8594 STM-1 MS-RDI alarm not cancelled 8601 STM-1 Pattern Sync Loss 8613 STM-1 No AU-AIS alarm 8624 STM-1 AU-AIS alarm not cancelled 8661 STM-1 Pattern Sync Loss 8673 STM-1 No TU3 TU-AIS alarm 8684 STM-1 TU3 TU-AIS alarm not cancelled 8691 STM-1 Pattern Sync Loss 8703 STM-1 No TU3 LP-RDI alarm 8714 STM-1 TU3 LP-RDI alarm not cancelled 8721 STM-1 Pattern Sync Loss 8733 STM-1 No TU12 TU-AIS alarm 8744 STM-1 TU12 TU-AIS alarm not cancelled 8751 STM-1 Pattern Sync Loss 8763 STM-1 No TU12 LP-RDI alarm 8774 STM-1 TU12 LP-RDI alarm not cancelled 8781 STM-1 Clock Loss 8791 STM-1 No Clock Loss
22
Self Test Error Codes
Self Test Error Codes
8801 STM-1 Frame or Pointer Sync Loss 8803 STM-1 VC-3 B3 BIP Error Rate low 8804 STM-1 VC-3 B3 BIP Error Rate high 8811 STM-1 K1 byte not equal to 00000000 8812 STM-1 K2 byte not equal to 00000000 8821 STM-1 K1 byte not equal to 11101111 8822 STM-1 K2 byte not equal to 11111101 8831 STM-1 S1 bits not equal to 0000 8841 STM-1 S1 bits not equal to 1111 8851 STM-1 AU-LOP not detected 8852 STM-1 AU-LOP detected 8861 STM-1 TU-LOP not detected 8862 STM-1 TU-LOP detected 8871 STM-1 LOF not detected 8872 STM-1 LOF detected 8883 STM-1 2 Mb/s TU BIP Error Rate low 8884 STM-1 2 Mb/s TU BIP Error Rate high 8893 STM-1 2 Mb/s LP-REI Error Rate low 8894 STM-1 2 Mb/s LP-REI Error Rate high 8901 STM-1 A1A2 OFF - LOF detected 8902 STM-1 A1A2 1 in 4 - LOF detected 8903 STM-1 A1A2 2 in 4 - LOF detected 8904 STM-1 A1A2 3 in 4 - LOF detected 8905 STM-1 A1A2 4 in 4 - LOF not detected 8906 STM-1 A1A2 3 in 4 - LOF not detected 8907 STM-1 A1A2 2 in 4 - LOF detected 8908 STM-1 A1A2 1 in 4 - LOF detected 8909 STM-1 A1A2 OFF - LOF detected 8911 STM-1 140 Mb/s struct 64 kb/s delay = 0s - Pattern Loss 8912 STM-1 140 Mb/s struct 64 kb/s delay = 0s - Timeout 8913 STM-1 140 Mb/s struct 64 kb/s delay = 0s - Result low 8914 STM-1 140 Mb/s struct 64 kb/s delay = 0s - Result high 8921 STM-1 140 Mb/s struct 64 kb/s delay = 2s - Pattern Loss 8922 STM-1 140 Mb/s struct 64 kb/s delay = 2s - Timeout 8923 STM-1 140 Mb/s struct 64 kb/s delay = 2s - Result low 8924 STM-1 140 Mb/s struct 64 kb/s delay = 2s - Result high 8931 STM-1 34 Mb/s struct 64 kb/s delay = 0s - Pattern Loss 8932 STM-1 34 Mb/s struct 64 kb/s delay = 0s - Timeout 8933 STM-1 34 Mb/s struct 64 kb/s delay = 0s - Result low 8934 STM-1 34 Mb/s struct 64 kb/s delay = 0s - Result high 8941 STM-1 34 Mb/s struct 64 kb/s delay = 2s - Pattern Loss 8942 STM-1 34 Mb/s struct 64 kb/s delay = 2s - Timeout 8943 STM-1 34 Mb/s struct 64 kb/s delay = 2s - Result low 8944 STM-1 34 Mb/s struct 64 kb/s delay = 2s - Result high 8951 STM-1 2 Mb/s struct 64 kb/s delay = 0s - Pattern Loss 8952 STM-1 2 Mb/s struct 64 kb/s delay = 0s - Timeout
23
Self Test Error Codes
Self Test Error Codes
8953 STM-1 2 Mb/s struct 64 kb/s delay = 0s - Result low 8954 STM-1 2 Mb/s struct 64 kb/s delay = 0s - Result high 8961 STM-1 2 Mb/s struct 64 kb/s delay = 2s - Pattern Loss 8962 STM-1 2 Mb/s struct 64 kb/s delay = 2s - Timeout 8963 STM-1 2 Mb/s struct 64 kb/s delay = 2s - Result low 8964 STM-1 2 Mb/s struct 64 kb/s delay = 2s - Result high 9101 STM-1 Optical Signal Loss 9111 STM-1 Optical alarms present 9121 STM-1 Optical Pattern Sync Loss 9124 STM-1 Optical Bit Errors 9131 STM-1 Optical Pattern Sync Loss 9133 STM-1 Optical Bit Error Rate low 9134 STM-1 Optical Bit Error Rate high 9141 STM-1 Optical No Signal Loss 9151 STM-4 Optical STM-1 #1 Signal Loss 9161 STM-4 Optical STM-1 #1 alarms present 9171 STM-4 Optical STM-1 #1 Pattern Sync Loss 9174 STM-4 Optical STM-1 #1 Bit Errors 9181 STM-4 Optical STM-1 #1 Pattern Sync Loss 9183 STM-4 Optical STM-1 #1 Bit Error Rate low 9184 STM-4 Optical STM-1 #1 Bit Error Rate high 9191 STM-4 Optical STM-1 #1 No Signal Loss 9201 STM-4 Optical STM-1 #2 Signal Loss 9211 STM-4 Optical STM-1 #2 alarms present 9221 STM-4 Optical STM-1 #2 Pattern Sync Loss 9224 STM-4 Optical STM-1 #2 Bit Errors 9231 STM-4 Optical STM-1 #2 Pattern Sync Loss 9233 STM-4 Optical STM-1 #2 Bit Error Rate low 9234 STM-4 Optical STM-1 #2 Bit Error Rate high 9241 STM-4 Optical STM-1 #2 No Signal Loss 9251 STM-4 Optical STM-1 #3 Signal Loss 9261 STM-4 Optical STM-1 #3 alarms present 9271 STM-4 Optical STM-1 #3 Pattern Sync Loss 9274 STM-4 Optical STM-1 #3 Bit Errors 9281 STM-4 Optical STM-1 #3 Pattern Sync Loss 9283 STM-4 Optical STM-1 #3 Bit Error Rate low 9284 STM-4 Optical STM-1 #3 Bit Error Rate high 9291 STM-4 Optical STM-1 #3 No Signal Loss 9301 STM-4 Optical STM-1 #4 Signal Loss 9311 STM-4 Optical STM-1 #4 alarms present 9321 STM-4 Optical STM-1 #4 Pattern Sync Loss 9324 STM-4 Optical STM-1 #4 Bit Errors 9331 STM-4 Optical STM-1 #4 Pattern Sync Loss 9333 STM-4 Optical STM-1 #4 Bit Error Rate low 9334 STM-4 Optical STM-1 #4 Bit Error Rate high 9341 STM-4 Optical STM-1 #4 No Signal Loss
24
Self Test Error Codes
Self Test Error Codes
9351 STM-4 Optical Frame or Pointer Sync Loss 9364 STM-4 Optical B1 BIP Errors 9374 STM-4 Optical B2 BIP Errors 9382 STM-4 Tx#1 Rx#2 Pattern Loss Not Detected 9383 STM-4 Tx#1 Rx#3 Pattern Loss Not Detected 9384 STM-4 Tx#1 Rx#4 Pattern Loss Not Detected 9391 STM-4 Tx#2 Rx#1 Pattern Loss Not Detected 9393 STM-4 Tx#2 Rx#3 Pattern Loss Not Detected 9394 STM-4 Tx#2 Rx#4 Pattern Loss Not Detected 9401 STM-4 Tx#3 Rx#1 Pattern Loss Not Detected 9402 STM-4 Tx#3 Rx#2 Pattern Loss Not Detected 9404 STM-4 Tx#3 Rx#4 Pattern Loss Not Detected 9411 STM-4 Tx#4 Rx#1 Pattern Loss Not Detected 9412 STM-4 Tx#4 Rx#2 Pattern Loss Not Detected 9413 STM-4 Tx#4 Rx#3 Pattern Loss Not Detected 9421 STM-4 Optical Pattern Sync Loss 9422 STM-4 Optical No MS-AIS alarm 9423 STM-4 Optical MS-AIS alarm not cancelled 9431 STM-4 Optical Pattern Sync Loss 9432 STM-4 Optical No MS-RDI alarm 9433 STM-4 Optical MS-RDI alarm not cancelled 10011 STM-1 Pattern Sync Loss 10012 STM-1 Signal Loss 10015 STM-1 Pattern Sync Loss 10016 STM-1 Signal Loss 10021 STM-1 LOF,OOF or LOP 10022 STM-1 LOF,OOF or LOP 10025 STM-1 LOF,OOF or LOP 10026 STM-1 LOF,OOF or LOP 10031 STM-1 Pattern Sync Loss 10033 STM-1 Payload bit error rate low 10034 STM-1 Payload bit error rate high 10035 STM-1 Pattern Sync Loss 10037 STM-1 Payload bit error rate low 10038 STM-1 Payload bit error rate high 10041 STM-1 No LOF,OOF or LOP 10042 STM-1 No signal Loss 10045 STM-1 No LOF,OOF or LOP 10046 STM-1 No signal Loss 10051 STM-1 Stress test LOF or OOF 10055 STM-1 Stress test LOF or OOF 10061 STM-1 Stress test OOF detected 10065 STM-1 Stress test OOF detected 10071 STM-4,STM-1#1 LOF,OOF or LOP 10072 STM-4,STM-1#1 Signal Loss 10075 STM-4,STM-1#1 LOF,OOF or LOP
25
Self Test Error Codes
Self Test Error Codes
10076 STM-4,STM-1#1 Signal Loss 10081 STM-4,STM-1#1 Pattern Sync Loss 10083 STM-4,STM-1#1 Payload bit error rate low 10084 STM-4,STN-1#1 Payload bit error rate high 10085 STM-4,STM-1#1 Pattern Sync Loss 10087 STM-4,STM-1#1 Payload bit error rate low 10088 STM-4,STM-1#1 Payload bit error rate high 10091 STM-4,STM-1#1 No LOF,OOF or LOP 10092 STM-4,STM-1#1 No signal Loss 10095 STM-4,STM-1#1 No LOF,OOF or LOP 10096 STM-4,STM-1#1 No signal Loss 10101 STM-4,STM-1#2 LOF,OOF or LOP 10102 STM-4,STM-1#2 Signal Loss 10105 STM-4,STM-1#2 LOF,OOF or LOP 10106 STM-4,STM-1#2 Signal Loss 10111 STM-4,STM-1#2 Pattern Sync Loss 10113 STM-4,STM-1#2 Payload bit error rate low 10114 STM-4,STM-1#2 Payload bit error rate high 10115 STM-4,STM-1#2 Pattern Sync Loss 10117 STM-4,STM-1#2 Payload bit error rate low 10118 STM-4,STM-1#2 Payload bit error rate high 10121 STM-4,STM-1#2 No LOF,OOF or LOP 10122 STM-4,STM-1#2 No signal Loss 10125 STM-4,STM-1#2 No LOF,OOF or LOP 10126 STM-4,STM-1#2 No signal Loss 10131 STM-4,STM-1#3 LOF,OOF or LOP 10132 STM-4,STM-1#3 Signal Loss 10135 STM-4,STM-1#3 LOF,OOF or LOP 10136 STM-4,STM-1#3 Signal Loss 10141 STM-4,STM-1#3 Pattern Sync Loss 10143 STM-4,STM-1#3 Payload bit error rate low 10144 STM-4,STM-1#3 Payload bit error rate high 10145 STM-4,STM-1#3 Pattern Sync Loss 10147 STM-4,STM-1#3 Payload bit error rate low 10148 STM-4,STM-1#3 Payload bit error rate high 10151 STM-4,STM-1#3 No LOF,OOF or LOP 10152 STM-4,STM-1#3 No signal Loss 10155 STM-4,STM-1#3 No LOF,OOF or LOP 10156 STM-4,STM-1#3 No signal Loss 10161 STM-4,STM-1#4 LOF,OOF or LOP 10162 STM-4,STM-1#4 Signal Loss 10165 STM-4,STM-1#4 LOF,OOF or LOP 10166 STM-4,STM-1#4 Signal Loss 10171 STM-4,STM-1#4 Pattern Sync Loss 10173 STM-4,STM-1#4 Payload bit error rate low 10174 STM-4,STM-1#4 Payload bit error rate high
26
Self Test Error Codes
Self Test Error Codes
10175 STM-4,STM-1#4 Pattern Sync Loss 10177 STM-4,STM-1#4 Payload bit error rate low 10178 STM-4,STM-1#4 Payload bit error rate high 10181 STM-4,STM-1#4 No LOF,OOF or LOP 10182 STM-4,STM-1#4 No signal Loss 10185 STM-4,STM-1#4 No LOF,OOF or LOP 10186 STM-4,STM-1#4 No signal Loss 10191 STM-4,STM-1#1 LOF,OOF or LOP 10192 STM-4,STM-1#1 RS B1 BIP Errors >0 10195 STM-4,STM-1#1 LOF,OOF or LOP 10196 STM-4,STM-1#1 RS B1 BIP Errors >0 10202 STM-4,STM-1#1 MS B2 BIP Errors >0 10206 STM-4,STM-1#1 MS B2 BIP Errors >0 10211 STM-4,STM-1#1 LOF or OOF 10213 STM-4,STM-1#1 MS B2 BIP Errors low 10214 STM-4,STM-1#1 MS B2 BIP Errors high 10215 STM-4,STM-1#1 LOF or OOF 10217 STM-4,STM-1#1 MS B2 BIP Errors low 10218 STM-4,STM-1#1 MS B2 BIP Errors high 10221 STM-4,STM-1#1 LOF,OOF or LOP 10222 STM-4,STM-1#1 Signal Loss 10225 STM-4,STM-1#1 LOF,OOF or LOP 10226 STM-4,STM-1#1 Signal Loss 10231 STM-4,Clock Recovery LOF,OOF or LOP 10235 STM-4,Clock Recovery LOF,OOF or LOP 10241 STM-4,Clock Recovery LOF,OOF or LOP 10245 STM-4,Clock Recovery LOF,OOF or LOP 10251 STM-4,Clock Recovery LOF,OOF or LOP 10255 STM-4,Clock Recovery LOF,OOF or LOP 10261 STM-4 SOH test sync loss 10262 STM-4 MUX4-SOH col147 'a5' error 10265 STM-4 SOH test sync loss 10266 STM-4 MUX4-SOH col147 'a5' error 10271 STM-4 SOH test sync loss 10272 STM-4 MUX4-SOH col147 '5a' error 10275 STM-4 SOH test sync loss 10276 STM-4 MUX4-SOH col147 '5a' error 10281 STM-4 SOH test sync loss 10282 STM-4 MUX4-SOH col147 'a5' error 10285 STM-4 SOH test sync loss 10286 STM-4 MUX4-SOH col147 'a5' error 10291 STM-4 SOH test sync loss 10292 STM-4 MUX4-SOH col258 'a5' error 10295 STM-4 SOH test sync loss 10296 STM-4 MUX4-SOH col258 'a5' error 10301 STM-4 SOH test sync loss
27
Self Test Error Codes
Self Test Error Codes
10302 STM-4 MUX4-SOH col369 'a5' error 10305 STM-4 SOH test sync loss 10306 STM-4 MUX4-SOH col369 'a5' error 10311 STM-4 SOH test sync loss 10312 STM-4 MUX4-SOH col147 '5a' error 10315 STM-4 SOH test sync loss 10316 STM-4 MUX4-SOH col147 '5a' error 10321 STM-4 SOH test sync loss 10322 STM-4 MUX4-SOH col258 '5a' error 10325 STM-4 SOH test sync loss 10326 STM-4 MUX4-SOH col258 '5a' error 10331 STM-4 SOH test sync loss 10332 STM-4 MUX4-SOH col369 '5a' error 10335 STM-4 SOH test sync loss 10336 STM-4 MUX4-SOH col369 '5a' error 10341 STM-4 SOH test sync loss 10342 STM-4#RAM1 SOH col147 pattern error 10345 STM-4 SOH test sync loss 10346 STM-4#RAM1 SOH col147 pattern error 10351 STM-4 SOH test sync loss 10352 STM-4#RAM1 SOH col258 pattern error 10355 STM-4 SOH test sync loss 10356 STM-4#RAM1 SOH col258 pattern error 10361 STM-4 SOH test sync loss 10362 STM-4#RAM1 SOH col369 pattern error 10365 STM-4 SOH test sync loss 10366 STM-4#RAM1 SOH col369 pattern error 10371 STM-4 SOH test sync loss 10372 STM-4#RAM2 SOH col147 pattern error 10375 STM-4 SOH test sync loss 10376 STM-4#RAM2 SOH col147 pattern error 10381 STM-4 SOH test sync loss 10382 STM-4#RAM2 SOH col258 pattern error 10385 STM-4 SOH test sync loss 10386 STM-4#RAM2 SOH col258 pattern error 10391 STM-4 SOH test sync loss 10392 STM-4#RAM2 SOH col369 pattern error 10395 STM-4 SOH test sync loss 10396 STM-4#RAM2 SOH col369 pattern error 10401 STM-4 SOH test sync loss 10402 STM-4#RAM3 SOH col147 pattern error 10405 STM-4 SOH test sync loss 10406 STM-4#RAM3 SOH col147 pattern error 10411 STM-4 SOH test sync loss 10412 STM-4#RAM3 SOH col258 pattern error 10415 STM-4 SOH test sync loss
28
Self Test Error Codes
Self Test Error Codes
10416 STM-4#RAM3 SOH col258 pattern error 10421 STM-4 SOH test sync loss 10422 STM-4#RAM3 SOH col369 pattern error 10425 STM-4 SOH test sync loss 10426 STM-4#RAM3 SOH col369 pattern error 10431 STM-4 SOH test sync loss 10432 STM-4#RAM4 SOH col147 pattern error 10435 STM-4 SOH test sync loss 10436 STM-4#RAM4 SOH col147 pattern error 10441 STM-4 SOH test sync loss 10442 STM-4#RAM4 SOH col258 pattern error 10445 STM-4 SOH test sync loss 10446 STM-4#RAM4 SOH col258 pattern error 10451 STM-4 SOH test sync loss 10452 STM-4#RAM4 SOH col369 pattern error 10455 STM-4 SOH test sync loss 10456 STM-4#RAM4 SOH col369 pattern error 10461 STM-4 SOH test sync loss 10462 STM-4#RAM1 SOH col147 pattern error 10465 STM-4 SOH test sync loss 10466 STM-4#RAM1 SOH col147 pattern error 10471 STM-4 SOH test sync loss 10472 STM-4#RAM1 SOH col258 pattern error 10475 STM-4 SOH test sync loss 10476 STM-4#RAM1 SOH col258 pattern error 10481 STM-4 SOH test sync loss 10482 STM-4#RAM1 SOH col369 pattern error 10485 STM-4 SOH test sync loss 10486 STM-4#RAM1 SOH col369 pattern error 10491 STM-4 SOH test sync loss 10492 STM-4#RAM2 SOH col147 pattern error 10495 STM-4 SOH test sync loss 10496 STM-4#RAM2 SOH col147 pattern error 10501 STM-4 SOH test sync loss 10502 STM-4#RAM2 SOH col258 pattern error 10505 STM-4 SOH test sync loss 10506 STM-4#RAM2 SOH col258 pattern error 10511 STM-4 SOH test sync loss 10512 STM-4#RAM2 SOH col369 pattern error 10515 STM-4 SOH test sync loss 10516 STM-4#RAM2 SOH col369 pattern error 10521 STM-4 SOH test sync loss 10522 STM-4#RAM3 SOH col147 pattern error 10525 STM-4 SOH test sync loss 10526 STM-4#RAM3 SOH col147 pattern error 10531 STM-4 SOH test sync loss
29
Self Test Error Codes
Self Test Error Codes
10532 STM-4#RAM3 SOH col258 pattern error 10535 STM-4 SOH test sync loss 10536 STM-4#RAM3 SOH col258 pattern error 10541 STM-4 SOH test sync loss 10542 STM-4#RAM3 SOH col369 pattern error 10545 STM-4 SOH test sync loss 10546 STM-4#RAM3 SOH col369 pattern error 10551 STM-4 SOH test sync loss 10552 STM-4#RAM4 SOH col147 pattern error 10555 STM-4 SOH test sync loss 10556 STM-4#RAM4 SOH col147 pattern error 10561 STM-4 SOH test sync loss 10562 STM-4#RAM4 SOH col258 pattern error 10565 STM-4 SOH test sync loss 10566 STM-4#RAM4 SOH col258 pattern error 10571 STM-4 SOH test sync loss 10572 STM-4#RAM4 SOH col369 pattern error 10575 STM-4 SOH test sync loss 10576 STM-4#RAM4 SOH col369 pattern error 10591 STM-4 OOF 10592 STM-4 LOF 10595 STM-4 OOF 10596 STM-4 LOF 10601 STM-4 3 in 4 Frame errors,History OOF 10602 STM-4 3 in 4 Frame errors,History LOF 10605 STM-4 3 in 4 Frame errors,History OOF 10606 STM-4 3 in 4 Frame errors,History LOF 10611 Pattern Sync Loss 10615 Pattern Sync Loss 10622 STM-4 No MS AIS alarm detected 10626 STM-4 No MS AIS alarm detected 10632 STM-4 MS AIS alarm detected 10636 STM-4 MS AIS alarm detected 10641 Pattern Sync Loss 10645 Pattern Sync Loss 10652 STM-4 No MS-RDI alarm detected 10656 STM-4 No MS-RDI alarm detected 10662 STM-4 MS-RDI alarm detected 10666 STM-4 MS-RDI alarm detected 10671 STM-0 Pattern Sync Loss 10672 STM-0 Signal Loss 10675 STM-0 Pattern Sync Loss 10676 STM-0 Signal Loss 10681 STM-0 LOF,OOF or LOP 10682 STM-0 LOF,OOF or LOP 10685 STM-0 LOF,OOF or LOP
30
Self Test Error Codes
Self Test Error Codes
10686 STM-0 LOF,OOF or LOP 10691 STM-0 Pattern Sync Loss 10693 STM-0 Payload bit error rate low 10694 STM-0 Payload bit error rate high 10695 STM-0 Pattern Sync Loss 10697 STM-0 Payload bit error rate low 10698 STM-0 Payload bit error rate high 10701 Pattern Sync Loss 10702 STM-1 Signal Loss 10705 Pattern Sync Loss 10706 STM-1 Signal Loss 10712 STM-1 LOF,OOF or LOP 10716 STM-1 LOF,OOF or LOP 10721 STM-1 Pattern Sync Loss 10723 STM-1 Payload bit error rate low 10724 STM-1 Payload bit error rate high 10725 STM-1 Pattern Sync Loss 10727 STM-1 Payload bit error rate low 10728 STM-1 Payload bit error rate high 10751 STM-4 LOF,OOF or LOP 10752 STM-4 Signal Loss 10755 STM-4 LOF,OOF or LOP 10756 STM-4 Signal Loss 10761 STM-4 Pattern Sync Loss 10763 STM-4,STM-1#1 Payload bit error rate low 10764 STM-4,STM-1#1 Payload bit error rate high 10765 STM-4 Pattern Sync Loss 10767 STM-4,STM-1#1 Payload bit error rate low 10768 STM-4,STM-1#1 Payload bit error rate high 10771 STM-4,STM-1#1 No LOF,OOF or LOP 10772 STM-4,STM-1#1 No signal Loss 10775 STM-4,STM-1#1 No LOF,OOF or LOP 10776 STM-4,STM-1#1 No signal Loss 10781 STM-4 LOF,OOF or LOP 10782 STM-4,STM-4 B1 BIP errors detected 10792 STM-4,STM-4 B2 BIP errors detected 10801 STM-1 LOF,OOF or LOP 10803 STM-1 Power level low [1310] 10804 STM-1 Power level high [1310] 10805 STM-1 LOF,OOF or LOP 10807 STM-1 Power level low [1550] 10808 STM-1 Power level high [1550] 10811 STM-4 LOF,OOF or LOP 10813 STM-4 Power level low [1310] 10814 STM-4 Power level high [1310] 10815 STM-4 LOF,OOF or LOP
31
Self Test Error Codes
Self Test Error Codes
10817 STM-4 Power level low [1550] 10818 STM-4 Power level high [1550] 10821 STM-1 Signal Loss 10823 STM-1 Frequency low 10824 STM-1 Frequency high 10825 STM-1 Signal Loss 10827 STM-1 Frequency low 10828 STM-1 Frequency high 10831 STM-4 Signal Loss 10833 STM-4 Frequency low 10834 STM-4 Frequency high 10835 STM-4 Signal Loss 10837 STM-4 Frequency low 10838 STM-4 Frequency high 10841 STM-4 LOF 10843 STM-4 MS B2 BIP Errors low 10844 STM-4 MS B2 BIP Errors high 10845 STM-4 LOF 10847 STM-4 MS B2 BIP Errors low 10848 STM-4 MS B2 BIP Errors high 10853 STM-4 A1A2 Errors low 10854 STM-4 A1A2 Errors high 10855 STM-4 RS B1 Errors low 10856 STM-4 RS B1 Errors high 10857 STM-4 MS-REI Errors low 10858 STM-4 MS-REI Errors high 10861 STM-4 LOF 10862 STM-4 OOF 10865 STM-4 LOF 10866 STM-4 OOF 10871 STM-4 LOF 10872 STM-4 No Loss of Signal 10873 STM-4 Loss of Signal 10876 STM-4 No Loss of Signal 10877 STM-4 Loss of Signal 10881 STM-4 LOF 10882 STM-4 No Loss of Signal 10883 STM-4 Loss of Signal 10886 STM-4 No Loss of Signal 10887 STM-4 Loss of Signal 10891 STM-4c POH J1 incorrect 10895 STM-4c POH J1 incorrect 10901 STM-4c 2^23 Pattern Loss 10903 STM-4c 2^23 Bit Errors low 10904 STM-4c 2^23 Bit Errors high 10905 STM-4c 2^23 Pattern Loss
32
Self Test Error Codes
Self Test Error Codes
10907 STM-4c 2^23 Bit Errors low 10908 STM-4c 2^23 Bit Errors high 10911 STM-4c 2^15 Pattern Loss 10913 STM-4c 2^15 Bit Errors low 10914 STM-4c 2^15 Bit Errors high 10915 STM-4c 2^15 Pattern Loss 10917 STM-4c 2^15 Bit Errors low 10918 STM-4c 2^15 Bit Errors high 10921 STM-4c Word Pattern Loss 10923 STM-4c Word Bit Errors low 10924 STM-4c Word Bit Errors high 10925 STM-4c Word Pattern Loss 10927 STM-4c Word Bit Errors low 10928 STM-4c Word Bit Errors high 10931 STM-4c 2^9 Pattern Loss 10933 STM-4c 2^9 Bit Errors low 10934 STM-4c 2^9 Bit Errors high 10935 STM-4c 2^9 Pattern Loss 10937 STM-4c 2^9 Bit Errors low 10938 STM-4c 2^9 Bit Errors high 10941 STM-4c LOF Detected 10942 STM-4c LOP Detected 10943 STM-4c B1 BIP Errors Detected 10944 STM-4c B2 BIP Errors Detected 10945 STM-4c B3 BIP Errors Detected 10953 STM-4c +100ppm VC Offset - low 10954 STM-4c +100ppm VC Offset - high 10955 STM-4c -100ppm VC Offset - low 10956 STM-4c -100ppm VC Offset - high 10961 STM-4 STM#3 Pattern Sync Loss 10962 STM-4 STM#3 Bit Errors Detected 10965 STM-4 STM#3 Pattern Sync Loss 10966 STM-4 STM#3 Bit Errors Detected 10971 STM-4 STM#1 Pattern Sync Loss" 10972 STM-4 STM#1 Bit Errors <> 1 10973 STM-4 STM#2 Pattern Sync Loss" 10974 STM-4 STM#2 Bit Errors <> 1 10975 STM-4 STM#4 Pattern Sync Loss" 10976 STM-4 STM#4 Bit Errors <> 1 14102 JITTER GEN 2Mb/s PRBS23 10UI 5KHz - no PDH errors 14111 JITTER GEN SDH 10UI 2KHz - SDH errors 14121 JITTER GEN SDH 10UI 5KHz - SDH errors 14133 JITTER Rx 140Mb/s PRBS23 - Peak-to-peak too low 14134 JITTER Rx 140Mb/s PRBS23 - Peak-to-peak too high 14138 JITTER Rx 140Mb/s - jitter not locked 14139 JITTER Rx 140Mb/s - VCO not settled
33
Self Test Error Codes
Self Test Error Codes
14143 JITTER Rx 140Mb/s All-zeroes - Peak-to-peak too low 14144 JITTER Rx 140Mb/s All-zeroes - Peak-to-peak too high 14145 JITTER Rx 140Mb/s All-zeroes - RMS too low 14146 JITTER Rx 140Mb/s All-zeroes - RMS too high 14148 JITTER Rx 140Mb/s - jitter not locked 14153 JITTER Rx 140Mb/s 1000 - Peak-to-peak too low 14154 JITTER Rx 140Mb/s 1000 - Peak-to-peak too high 14158 JITTER Rx 140Mb/s - jitter not locked 14163 JITTER Rx 140Mb/s All-ones - Peak-to-peak too low 14164 JITTER Rx 140Mb/s All-ones - Peak-to-peak too high 14168 JITTER Rx 140Mb/s - jitter not locked 14173 JITTER Rx 34Mb/s PRBS23 - Peak-to-peak too low 14174 JITTER Rx 34Mb/s PRBS23 - Peak-to-peak too high 14178 JITTER Rx 34Mb/s - jitter not locked 14179 JITTER Rx 34Mb/s - VCO not settled 14183 JITTER Rx 34Mb/s All-zeroes - Peak-to-peak too low 14184 JITTER Rx 34Mb/s All-zeroes - Peak-to-peak too high 14185 JITTER Rx 34Mb/s All-zeroes - RMS too low 14186 JITTER Rx 34Mb/s All-zeroes - RMS too high 14188 JITTER Rx 34Mb/s - jitter not locked 14193 JITTER Rx 34Mb/s 1000 - Peak-to-peak too low 14194 JITTER Rx 34Mb/s 1000 - Peak-to-peak too high 14198 JITTER Rx 34Mb/s - jitter not locked 14203 JITTER Rx 34Mb/s All-ones - Peak-to-peak too low 14204 JITTER Rx 34Mb/s All-ones - Peak-to-peak too high 14208 JITTER Rx 34Mb/s - jitter not locked 14213 JITTER Rx 8Mb/s PRBS23 - Peak-to-peak too low 14214 JITTER Rx 8Mb/s PRBS23 - Peak-to-peak too high 14218 JITTER Rx 8Mb/s - jitter not locked 14219 JITTER Rx 8Mb/s - VCO not settled 14223 JITTER Rx 8Mb/s All-zeroes - Peak-to-peak too low 14224 JITTER Rx 8Mb/s All-zeroes - Peak-to-peak too high 14225 JITTER Rx 8Mb/s All-zeroes - RMS too low 14226 JITTER Rx 8Mb/s All-zeroes - RMS too high 14233 JITTER Rx 8Mb/s 1000 - Peak-to-peak too low 14234 JITTER Rx 8Mb/s 1000 - Peak-to-peak too high 14243 JITTER Rx 8Mb/s All-ones - Peak-to-peak too low 14244 JITTER Rx 8Mb/s All-ones - Peak-to-peak too high 14253 JITTER Rx 2Mb/s PRBS23 - Peak-to-peak too low 14254 JITTER Rx 2Mb/s PRBS23 - Peak-to-peak too high 14258 JITTER Rx 2Mb/s - jitter not locked 14259 JITTER Rx 2Mb/s - VCO not settled 14263 JITTER Rx 2Mb/s All-zeroes - Peak-to-peak too low 14264 JITTER Rx 2Mb/s All-zeroes - Peak-to-peak too high 14265 JITTER Rx 2Mb/s All-zeroes - RMS too low 14266 JITTER Rx 2Mb/s All-zeroes - RMS too high
34
Self Test Error Codes
Self Test Error Codes
14268 JITTER Rx 140Mb/s - jitter not locked 14273 JITTER Rx 2Mb/s 1000 - Peak-to-peak too low 14274 JITTER Rx 2Mb/s 1000 - Peak-to-peak too high 14278 JITTER Rx 140Mb/s - jitter not locked 14283 JITTER Rx 2Mb/s All-ones - Peak-to-peak too low 14284 JITTER Rx 2Mb/s All-ones - Peak-to-peak too high 14288 JITTER Rx 140Mb/s - jitter not locked 14293 JITTER GEN+Rx 140Mb/s All-0's Jit Off - Result too low 14294 JITTER GEN+Rx 140Mb/s All-0's Jit Off - Result too high 14298 JITTER Gen+Rx 140Mb/s - jitter not locked 14299 JITTER Gen+Rx 140Mb/s - VCO not settled 14303 JITTER GEN+Rx 140Mb/s All-0's 10UI 100Hz - Result too low 14304 JITTER GEN+Rx 140Mb/s All-0's 10UI 100Hz - Result too high 14308 JITTER Gen+Rx 140Mb/s - jitter not locked 14313 JITTER GEN+Rx 140Mb/s All-0's 1UI 10KHz - Result too low 14314 JITTER GEN+Rx 140Mb/s All-0's 1UI 10KHz - Result too high 14315 JITTER GEN+Rx 140Mb/s All-0's 1UI 10KHz - RMS too low 14316 JITTER GEN+Rx 140Mb/s All-0's 1UI 10KHz - RMS too high 14318 JITTER Gen+Rx 140Mb/s - jitter not locked 14323 JITTER GEN+Rx 140Mb/s All-0's 0.6UI 3MHz - Result too low 14324 JITTER GEN+Rx 140Mb/s All-0's 0.6UI 3MHz - Result too high 14328 JITTER Gen+Rx 140Mb/s - jitter not locked 14333 JITTER GEN+Rx 34Mb/s All-1's Jit Off - Result too low 14334 JITTER GEN+Rx 34Mb/s All-1's Jit Off - Result too high 14338 JITTER Gen+Rx 34Mb/s - jitter not locked 14339 JITTER Gen+Rx 34Mb/s - VCO not settled 14343 JITTER GEN+Rx 34Mb/s All-1's 10UI 100Hz - Result too low 14344 JITTER GEN+Rx 34Mb/s All-1's 10UI 100Hz - Result too high 14348 JITTER Gen+Rx 34Mb/s - jitter not locked 14353 JITTER GEN+Rx 34Mb/s All-1's 1UI 200KHz - Result too low 14354 JITTER GEN+Rx 34Mb/s All-1's 1UI 200KHz - Result too high 14355 JITTER GEN+Rx 34Mb/s All-1's 1UI 200KHz - RMS too low 14356 JITTER GEN+Rx 34Mb/s All-1's 1UI 200KHz - RMS too high 14358 JITTER Gen+Rx 34Mb/s - jitter not locked 14363 JITTER GEN+Rx 34Mb/s All-1's 0.6UI 500KHz - Result too low 14364 JITTER GEN+Rx 34Mb/s All-1's 0.6UI 500KHz - Result too high 14368 JITTER Gen+Rx 34Mb/s - jitter not locked 14373 JITTER GEN+Rx 8Mb/s All-1's jit-off - Result too low 14374 JITTER GEN+Rx 8Mb/s All-1's jit-off - Result too high 14378 JITTER Gen+Rx 8Mb/s - jitter not locked 14379 JITTER Gen+Rx 8Mb/s - VCO not settled 14383 JITTER GEN+Rx 8Mb/s All-1's 10UI 100Hz - Result too low 14384 JITTER GEN+Rx 8Mb/s All-1's 10UI 100Hz - Result too high 14388 JITTER Gen+Rx 8Mb/s - jitter not locked 14393 JITTER GEN+Rx 8Mb/s All-1's 1UI 100KHz - Result too low 14394 JITTER GEN+Rx 8Mb/s All-1's 1UI 100KHz - Result too high
35
Self Test Error Codes
Self Test Error Codes
14395 JITTER GEN+Rx 8Mb/s All-1's 1UI 100KHz - RMS too low 14396 JITTER GEN+Rx 8Mb/s All-1's 1UI 100KHz - RMS too high 14398 JITTER Gen+Rx 8Mb/s - jitter not locked 14403 JITTER GEN+Rx 8Mb/s All-1's 0.6UI 300KHz - Result too low 14404 JITTER GEN+Rx 8Mb/s All-1's 0.6UI 300KHz - Result too high 14408 JITTER Gen+Rx 8Mb/s - jitter not locked 14413 JITTER GEN+Rx 2Mb/s All-1's jit-off - Result too low 14414 JITTER GEN+Rx 2Mb/s All-1's jit-off - Result too high 14418 JITTER Gen+Rx 2Mb/s - jitter not locked 14419 JITTER Gen+Rx 2Mb/s - VCO not settled 14423 JITTER GEN+Rx 2Mb/s All-1's 10UI 100Hz - Result too low 14424 JITTER GEN+Rx 2Mb/s All-1's 10UI 100Hz - Result too high 14428 JITTER Gen+Rx 2Mb/s - jitter not locked 14433 JITTER GEN+Rx 2Mb/s All-1's 1UI 25KHz - Result too low 14434 JITTER GEN+Rx 2Mb/s All-1's 1UI 25KHz - Result too high 14435 JITTER GEN+Rx 2Mb/s All-1's 1UI 25KHz - RMS too low 14436 JITTER GEN+Rx 2Mb/s All-1's 1UI 25KHz - RMS too high 14438 JITTER Gen+Rx 2Mb/s - jitter not locked 14443 JITTER GEN+Rx 2Mb/s All-1's 0.6UI 80KHz - Result too low 14444 JITTER GEN+Rx 2Mb/s All-1's 0.6UI 80KHz - Result too high 14448 JITTER Gen+Rx 2Mb/s - jitter not locked 14453 JITTER GEN+RX 2Mb/s All-1's 1.0UI 1KHz - Result too low 14454 JITTER GEN+RX 2Mb/s All-1's 1.0UI 1KHz - Result too high 14458 JITTER GEN+RX 2Mb/s - jitter not locked 14463 JITTER GEN+RX 8Mb/s All-1's 1.0UI 1KHz - Result too low 14464 JITTER GEN+RX 8Mb/s All-1's 1.0UI 1KHz - Result too high 14468 JITTER GEN+RX 8Mb/s - jitter not locked 14473 JITTER GEN+RX 34Mb/s All-1's 1.0UI 1KHz - Result too low 14474 JITTER GEN+RX 34Mb/s All-1's 1.0UI 1KHz - Result too high 14478 JITTER GEN+RX 34Mb/s - jitter not locked 14483 JITTER GEN+RX 140Mb/s All-1's 1.0UI 1KHz - Result too low 14484 JITTER GEN+RX 140Mb/s All-1's 1.0UI 1KHz - Result too high 14488 JITTER GEN+RX 140Mb/s - jitter not locked 14493 JITTER STM-1E RX 1.6 UI PRBS23 - Result too low 14494 JITTER STM-1E RX 1.6 UI PRBS23 - Result too high 14495 JITTER STM-1E RX 1.6 UI PRBS23 - RMS too low 14496 JITTER STM-1E RX 1.6 UI PRBS23 - RMS too high 14497 JITTER STM-1E RX 1.6 UI PRBS23 - STM LOS 14498 JITTER STM-1E RX 1.6 UI PRBS23 - Jitter not locked 14499 JITTER STM-1E RX 1.6 UI PRBS23 - VCO not settled 14503 JITTER STM-1E RX 1.6 UI All-0's - Result too low 14504 JITTER STM-1E RX 1.6 UI All 0's - Result too high 14507 JITTER STM-1E RX 1.6 UI All 0's - STM LOS 14508 JITTER STM-1E RX 1.6 UI All 0's - Jitter not locked 14513 JITTER STM-1E RX 1.6 UI All-1's - Result too low 14514 JITTER STM-1E RX 1.6 UI All 1's - Result too high
36
Self Test Error Codes
Self Test Error Codes
14517 JITTER STM-1E RX 1.6 UI All 1's - STM LOS 14518 JITTER STM-1E RX 1.6 UI All 1's - Jitter not locked 14523 JITTER STM-1E RX 16 UI PRBS23 - Result too low 14524 JITTER STM-1E RX 16 UI PRBS23 - Result too high 14527 JITTER STM-1E RX 16 UI PRBS23 - STM LOS 14528 JITTER STM-1E RX 16 UI PRBS23 - Jitter not locked 14533 JITTER STM-1E RX 16 UI All-0's - Result too low 14534 JITTER STM-1E RX 16 UI All 0's - Result too high 14537 JITTER STM-1E RX 16 UI All 0's - STM LOS 14538 JITTER STM-1E RX 16 UI All 0's - Jitter not locked 14543 JITTER STM-1E RX 16 UI All-1's - Result too low 14544 JITTER STM-1E RX 16 UI All 1's - Result too high 14547 JITTER STM-1E RX 16 UI All 1's - STM LOS 14548 JITTER STM-1E RX 16 UI All 1's - Jitter not locked 14553 JITTER TX & STM-1E RX TX: OFF - Result too low 14554 JITTER TX & STM-1E RX TX: OFF - Result too high 14557 JITTER TX & STM-1E RX TX: OFF - STM LOS 14558 JITTER TX & STM-1E RX TX: OFF - Jitter not locked 14563 JITTER TX & STM-1E RX 5 UI 100 Hz - Result too low 14564 JITTER TX & STM-1E RX 5 UI 100 Hz - Result too high 14567 JITTER TX & STM-1E RX 5 UI 100 Hz - STM LOS 14568 JITTER TX & STM-1E RX 5 UI 100 Hz - Jitter not locked 14573 JITTER TX & STM-1E RX 5 UI 1 kHz - Result too low 14574 JITTER TX & STM-1E RX 5 UI 1 kHz - Result too high 14577 JITTER TX & STM-1E RX 5 UI 1 kHz - STM LOS 14578 JITTER TX & STM-1E RX 5 UI 1 kHz - Jitter not locked 14583 JITTER TX & STM-1E RX 1 UI 10 kHz - Result too low 14584 JITTER TX & STM-1E RX 1 UI 10 kHz - Result too high 14587 JITTER TX & STM-1E RX 1 UI 10 kHz - STM LOS 14588 JITTER TX & STM-1E RX 1 UI 10 kHz - Jitter not locked 14593 JITTER TX & STM-1E RX 1 UI 100 kHz - Result too low 14594 JITTER TX & STM-1E RX 1 UI 100 kHz - Result too high 14595 JITTER TX & STM-1E RX 1 UI 100 kHz - RMS too low 14596 JITTER TX & STM-1E RX 1 UI 100 kHz - RMS too high 14597 JITTER TX & STM-1E RX 1 UI 100 kHz - STM LOS 14598 JITTER TX & STM-1E RX 1 UI 100 kHz - Jitter not locked 14603 JITTER TX & STM-1E RX 0.5 UI 1 MHz - Result too low 14604 JITTER TX & STM-1E RX 0.5 UI 1 MHz - Result too high 14607 JITTER TX & STM-1E RX 0.5 UI 1 MHz - STM LOS 14608 JITTER TX & STM-1E RX 0.5 UI 1 MHz - Jitter not locked 14613 JITTER TX & STM-1E RX Hits: 1.0 UI 1 kHz - Result too low 14614 JITTER TX & STM-1E RX Hits: 1.0 UI 1 kHz - Result too high 14617 JITTER TX & STM-1E RX Hits: 1.0 UI 1 kHz - STM LOS 14618 JITTER TX & STM-1E RX Hits: 1.0 UI 1 kHz - Jitter not locked 14623 JITTER STM-1O RX 1.6 UI PRBS23 - Result too low 14624 JITTER STM-1O RX 1.6 UI PRBS23 - Result too high
37
Self Test Error Codes
Self Test Error Codes
14625 JITTER STM-1O RX 1.6 UI PRBS23 - RMS too low 14626 JITTER STM-1O RX 1.6 UI PRBS23 - RMS too high 14627 JITTER STM-1O RX 1.6 UI PRBS23 - STM LOL 14628 JITTER STM-1O RX 1.6 UI PRBS23 - Jitter not locked 14629 JITTER STM-1O RX 1.6 UI PRBS23 - VCO not settled 14633 JITTER STM-1O RX 1.6 UI All-0's - Result too low 14634 JITTER STM-1O RX 1.6 UI All 0's - Result too high 14637 JITTER STM-1O RX 1.6 UI All 0's - STM LOL 14638 JITTER STM-1O RX 1.6 UI All 0's - Jitter not locked 14643 JITTER STM-1O RX 1.6 UI All-1's - Result too low 14644 JITTER STM-1O RX 1.6 UI All 1's - Result too high 14647 JITTER STM-1O RX 1.6 UI All 1's - STM LOL 14648 JITTER STM-1O RX 1.6 UI All 1's - Jitter not locked 14653 JITTER STM-1O RX 16 UI PRBS23 - Result too low 14654 JITTER STM-1O RX 16 UI PRBS23 - Result too high 14657 JITTER STM-1O RX 16 UI PRBS23 - STM LOL 14658 JITTER STM-1O RX 16 UI PRBS23 - Jitter not locked 14663 JITTER STM-1O RX 16 UI All-0's - Result too low 14664 JITTER STM-1O RX 16 UI All 0's - Result too high 14667 JITTER STM-1O RX 16 UI All 0's - STM LOL 14668 JITTER STM-1O RX 16 UI All 0's - Jitter not locked 14673 JITTER STM-1O RX 16 UI All-1's - Result too low 14674 JITTER STM-1O RX 16 UI All 1's - Result too high 14677 JITTER STM-1O RX 16 UI All 1's - STM LOL 14678 JITTER STM-1O RX 16 UI All 1's - Jitter not locked 14683 JITTER TX & STM-1O RX TX: OFF - Result too low 14684 JITTER TX & STM-1O RX TX: OFF - Result too high 14687 JITTER TX & STM-1O RX TX: OFF - STM LOL 14688 JITTER TX & STM-1O RX TX: OFF - Jitter not locked 14693 JITTER TX & STM-1O RX 5 UI 100 Hz - Result too low 14694 JITTER TX & STM-1O RX 5 UI 100 Hz - Result too high 14697 JITTER TX & STM-1O RX 5 UI 100 Hz - STM LOL 14698 JITTER TX & STM-1O RX 5 UI 100 Hz - Jitter not locked 14703 JITTER TX & STM-1O RX 5 UI 1 kHz - Result too low 14704 JITTER TX & STM-1O RX 5 UI 1 kHz - Result too high 14707 JITTER TX & STM-1O RX 5 UI 1 kHz - STM LOL 14708 JITTER TX & STM-1O RX 5 UI 1 kHz - Jitter not locked 14713 JITTER TX & STM-1O RX 1 UI 10 kHz - Result too low 14714 JITTER TX & STM-1O RX 1 UI 10 kHz - Result too high 14717 JITTER TX & STM-1O RX 1 UI 10 kHz - STM LOL 14718 JITTER TX & STM-1O RX 1 UI 10 kHz - Jitter not locked 14723 JITTER TX & STM-1O RX 1 UI 100 kHz - Result too low 14724 JITTER TX & STM-1O RX 1 UI 100 kHz - Result too high 14725 JITTER TX & STM-1O RX 1 UI 100 kHz - RMS too low 14726 JITTER TX & STM-1O RX 1 UI 100 kHz - RMS too high 14727 JITTER TX & STM-1O RX 1 UI 100 kHz - STM LOL
38
Self Test Error Codes
Self Test Error Codes
14728 JITTER TX & STM-1O RX 1 UI 100 kHz - Jitter not locked 14733 JITTER TX & STM-1O RX 0.5 UI 1 MHz - Result too low 14734 JITTER TX & STM-1O RX 0.5 UI 1 MHz - Result too high 14737 JITTER TX & STM-1O RX 0.5 UI 1 MHz - STM LOL 14738 JITTER TX & STM-1O RX 0.5 UI 1 MHz - Jitter not locked 14743 JITTER TX & STM-1O RX Hits: 1.0 UI 1 kHz - Result too low 14744 JITTER TX & STM-1O RX Hits: 1.0 UI 1 kHz - Result too high 14747 JITTER TX & STM-1O RX Hits: 1.0 UI 1 kHz - STM LOL 14748 JITTER TX & STM-1O RX Hits: 1.0 UI 1 kHz - Jitter not locked 14753 JITTER STM-4O RX 1.6 UI PRBS23 - Result too low 14754 JITTER STM-4O RX 1.6 UI PRBS23 - Result too high 14755 JITTER STM-4O RX 1.6 UI PRBS23 - RMS too low 14756 JITTER STM-4O RX 1.6 UI PRBS23 - RMS too high 14757 JITTER STM-4O RX 1.6 UI PRBS23 - STM LOL 14758 JITTER STM-4O RX 1.6 UI PRBS23 - Jitter not locked 14759 JITTER STM-4O RX 1.6 UI PRBS23 - VCO not settled 14763 JITTER STM-4O RX 1.6 UI All-0's - Result too low 14764 JITTER STM-4O RX 1.6 UI All 0's - Result too high 14767 JITTER STM-4O RX 1.6 UI All 0's - STM LOL 14768 JITTER STM-4O RX 1.6 UI All 0's - Jitter not locked 14773 JITTER STM-4O RX 1.6 UI All-1's - Result too low 14774 JITTER STM-4O RX 1.6 UI All 1's - Result too high 14777 JITTER STM-4O RX 1.6 UI All 1's - STM LOL 14778 JITTER STM-4O RX 1.6 UI All 1's - Jitter not locked 14783 JITTER STM-4O RX 16 UI PRBS23 - Result too low 14784 JITTER STM-4O RX 16 UI PRBS23 - Result too high 14787 JITTER STM-4O RX 16 UI PRBS23 - STM LOL 14788 JITTER STM-4O RX 16 UI PRBS23 - Jitter not locked 14793 JITTER STM-4O RX 16 UI All-0's - Result too low 14794 JITTER STM-4O RX 16 UI All 0's - Result too high 14797 JITTER STM-4O RX 16 UI All 0's - STM LOL 14798 JITTER STM-4O RX 16 UI All 0's - Jitter not locked 14803 JITTER STM-4O RX 16 UI All-1's - Result too low 14804 JITTER STM-4O RX 16 UI All 1's - Result too high 14807 JITTER STM-4O RX 16 UI All 1's - STM LOL 14808 JITTER STM-4O RX 16 UI All 1's - Jitter not locked 14813 JITTER TX & STM-4O RX TX: OFF - Result too low 14814 JITTER TX & STM-4O RX TX: OFF - Result too high 14817 JITTER TX & STM-4O RX TX: OFF - STM LOL 14818 JITTER TX & STM-4O RX TX: OFF - Jitter not locked 14823 JITTER TX & STM-4O RX 5 UI 100 Hz - Result too low 14824 JITTER TX & STM-4O RX 5 UI 100 Hz - Result too high 14827 JITTER TX & STM-4O RX 5 UI 100 Hz - STM LOL 14828 JITTER TX & STM-4O RX 5 UI 100 Hz - Jitter not locked 14833 JITTER TX & STM-4O RX 5 UI 1 kHz - Result too low 14834 JITTER TX & STM-4O RX 5 UI 1 kHz - Result too high
39
Self Test Error Codes
Self Test Error Codes
14837 JITTER TX & STM-4O RX 5 UI 1 kHz - STM LOL 14838 JITTER TX & STM-4O RX 5 UI 1 kHz - Jitter not locked 14843 JITTER TX & STM-4O RX 1 UI 10 kHz - Result too low 14844 JITTER TX & STM-4O RX 1 UI 10 kHz - Result too high 14847 JITTER TX & STM-4O RX 1 UI 10 kHz - STM LOL 14848 JITTER TX & STM-4O RX 1 UI 10 kHz - Jitter not locked 14853 JITTER TX & STM-4O RX 1 UI 100 kHz - Result too low 14854 JITTER TX & STM-4O RX 1 UI 100 kHz - Result too high 14855 JITTER TX & STM-4O RX 1 UI 100 kHz - RMS too low 14856 JITTER TX & STM-4O RX 1 UI 100 kHz - RMS too high 14857 JITTER TX & STM-4O RX 1 UI 100 kHz - STM LOL 14858 JITTER TX & STM-4O RX 1 UI 100 kHz - Jitter not locked 14863 JITTER TX & STM-4O RX 0.5 UI 1 MHz - Result too low 14864 JITTER TX & STM-4O RX 0.5 UI 1 MHz - Result too high 14867 JITTER TX & STM-4O RX 0.5 UI 1 MHz - STM LOL 14868 JITTER TX & STM-4O RX 0.5 UI 1 MHz - Jitter not locked 14873 JITTER TX & STM-4O RX Hits: 1.0 UI 1 kHz - Result too low 14874 JITTER TX & STM-4O RX Hits: 1.0 UI 1 kHz - Result too high 14877 JITTER TX & STM-4O RX Hits: 1.0 UI 1 kHz - STM LOL 14878 JITTER TX & STM-4O RX Hits: 1.0 UI 1 kHz - Jitter not locked 14881 JITTER GEN 2Mb/s PRBS23 80UI 100Hz - PDH errors 14889 JITTER GEN 2Mb/s - VCO not settled 14893 JITTER Gen+Rx 2Mb/s All-1's 13UI 100Hz - Result too low 14894 JITTER Gen+Rx 2Mb/s All-1's 13UI 100Hz - Result too high 14898 JITTER Gen+Rx 2Mb/s - jitter not locked 14899 JITTER Gen+Rx 2Mb/s - VCO not settled 14902 JITTER Gen+Rx 2Mb/s All-1's 20UI 100Hz - Over-range not generated 14908 JITTER Gen+Rx 2Mb/s - jitter not locked 14909 JITTER Gen+Rx 2Mb/s - VCO not settled 14911 JITTER GEN SDH 50UI 100Hz - SDH errors 14923 JITTER TX & STM-1E RX 13UI 100Hz - Result too low 14924 JITTER TX & STM-1E RX 13UI 100Hz - Result too high 14926 JITTER TX & STM-1E RX 13UI 100Hz - STM LOS 14928 JITTER TX & STM-1E RX 13UI 100Hz - Jitter not locked 14933 JITTER TX & STM-1O RX 13UI 100Hz - Result too low 14934 JITTER TX & STM-1O RX 13UI 100Hz - Result too high 14936 JITTER TX & STM-1O RX 13UI 100Hz - STM LOS 14938 JITTER TX & STM-1O RX 13UI 100Hz - Jitter not locked 14943 JITTER TX & STM-4O RX 12UI 100Hz - Result too low 14944 JITTER TX & STM-4O RX 12UI 100Hz - Result too high 14946 JITTER TX & STM-4O RX 12UI 100Hz - STM LOS 14948 JITTER TX & STM-4O RX 12UI 100Hz - Jitter not locked 15016 ATM 34Mb/s - Pattern Loss not detected 15017 ATM 34Mb/s - Pattern Loss detected 15026 ATM 34Mb/s - Cell Sync Loss not detected 15027 ATM 34Mb/s - Cell Sync Loss detected
40
Self Test Error Codes
Self Test Error Codes
15036 ATM 34Mb/s - Selected Cell Not Received not detected 15037 ATM 34Mb/s - Selected Cell Not Received detected 15046 ATM 34Mb/s - Congestion Experienced not detected 15047 ATM 34Mb/s - Congestion Experienced detected 15056 ATM 140Mb/s - VP-AIS not detected 15057 ATM 140Mb/s - VP-AIS detected 15066 ATM 140Mb/s - VP-RDI not detected 15067 ATM 140Mb/s - VP-RDI detected 15076 ATM 140Mb/s - VP-LOC not detected 15077 ATM 140Mb/s - VP-LOC detected 15086 ATM 140Mb/s - VC-AIS not detected 15087 ATM 140Mb/s - VC-AIS detected 15096 ATM 2Mb/s - VC-RDI not detected 15097 ATM 2Mb/s - VC-RDI detected 15106 ATM 2Mb/s - VC-LOC not detected 15107 ATM 2Mb/s - VC-LOC detected 15116 ATM 2Mb/s - Test Cell Loss not detected 15117 ATM 2Mb/s - Test Cell Loss detected 15124 ATM 2Mb/s - Loss of Frame not detected 15125 ATM 2Mb/s - Loss of Frame detected 15126 ATM 34Mb/s - Loss of Frame not detected 15127 ATM 34Mb/s - Loss of Frame detected 15128 ATM 140Mb/s - Loss of Frame not detected 15129 ATM 140Mb/s - Loss of Frame detected 15134 ATM 2Mb/s - RAI not detected 15135 ATM 2Mb/s - RAI detected 15136 ATM 34Mb/s - RDI not detected 15137 ATM 34Mb/s - RDI detected 15138 ATM 140Mb/s - RDI not detected 15139 ATM 140Mb/s - RDI detected 15144 ATM 2Mb/s - AIS not detected 15145 ATM 2Mb/s - AIS detected 15146 ATM 34Mb/s - AIS not detected 15147 ATM 34Mb/s - AIS detected 15148 ATM 140Mb/s - AIS not detected 15149 ATM 140Mb/s - AIS detected 15150 ATM 34Mb/s - F/G rate 80000Cell/sec - Signal Loss 15151 ATM 34Mb/s - F/G rate 80000Cell/sec - Loss of Cell Synchronisation 15152 ATM 34Mb/s - F/G rate 80000Cell/sec - Pattern Loss 15153 ATM 34Mb/s - F/G rate 80000Cell/sec - Received Cell Count = Result Low 15154 ATM 34Mb/s - F/G rate 80000Cell/sec - Received Cell Count = Result High 15155 ATM 34Mb/s - F/G rate 80000Cell/sec - Selected Cell Not Received detected 15156 ATM 34Mb/s - F/G rate 80000Cell/sec - Received Cell Count = Result Invalid 15160 ATM 34Mb/s - F/G rate 40000Cell/sec - Signal Loss 15161 ATM 34Mb/s - F/G rate 40000Cell/sec - Loss of Cell Synchronisation 15162 ATM 34Mb/s - F/G rate 40000Cell/sec - Pattern Loss
41
Self Test Error Codes
Self Test Error Codes
15163 ATM 34Mb/s - F/G rate 40000Cell/sec - Received Cell Count = Result Low 15164 ATM 34Mb/s - F/G rate 40000Cell/sec - Received Cell Count = Result High 15165 ATM 34Mb/s - F/G rate 40000Cell/sec - Selected Cell Not Received detected 15166 ATM 34Mb/s - F/G rate 40000Cell/sec - Received Cell Count = Result Invalid 15170 ATM 34Mb/s - F/G rate 100Cell/sec - Signal Loss 15171 ATM 34Mb/s - F/G rate 100Cell/sec - Loss of Cell Synchronisation 15172 ATM 34Mb/s - F/G rate 100Cell/sec - Pattern Loss 15173 ATM 34Mb/s - F/G rate 100Cell/sec - Received Cell Count = Result Low 15174 ATM 34Mb/s - F/G rate 100Cell/sec - Received Cell Count = Result High 15175 ATM 34Mb/s - F/G rate 100Cell/sec - Selected Cell Not Received detected 15176 ATM 34Mb/s - F/G rate 100Cell/sec - Received Cell Count = Result Invalid 15180 ATM 34Mb/s - F/G rate 24000Cell/sec - Signal Loss 15181 ATM 34Mb/s - F/G rate 24000Cell/sec - Loss of Cell Synchronisation 15182 ATM 34Mb/s - F/G rate 24000Cell/sec - Pattern Loss 15183 ATM 34Mb/s - F/G rate 24000Cell/sec - Received Cell Count = Result Low 15184 ATM 34Mb/s - F/G rate 24000Cell/sec - Received Cell Count = Result High 15185 ATM 34Mb/s - F/G rate 24000Cell/sec - Selected Cell Not Received detected 15186 ATM 34Mb/s - F/G rate 24000Cell/sec - Received Cell Count = Result Invalid 15190 ATM 34Mb/s - #1 B/G rate 70% - Signal Loss 15191 ATM 34Mb/s - #1 B/G rate 70% - Loss of Cell Synchronisation 15192 ATM 34Mb/s - #1 B/G rate 70% - Pattern Loss 15193 ATM 34Mb/s - #1 B/G rate 70% - Received Cell Count = Result Low 15194 ATM 34Mb/s - #1 B/G rate 70% - Received Cell Count = Result High 15195 ATM 34Mb/s - #1 B/G rate 70% - Selected Cell Not Received detected 15196 ATM 34Mb/s - #1 B/G rate 70% - Received Cell Count = Result Invalid 15200 ATM 34Mb/s - #1 B/G rate 25% - Signal Loss 15201 ATM 34Mb/s - #1 B/G rate 25% - Loss of Cell Synchronisation 15202 ATM 34Mb/s - #1 B/G rate 25% - Pattern Loss 15203 ATM 34Mb/s - #1 B/G rate 25% - Received Cell Count = Result Low 15204 ATM 34Mb/s - #1 B/G rate 25% - Received Cell Count = Result High 15205 ATM 34Mb/s - #1 B/G rate 25% - Selected Cell Not Received detected 15206 ATM 34Mb/s - #1 B/G rate 25% - Received Cell Count = Result Invalid 15210 ATM 34Mb/s - #2 B/G rate 45% - Signal Loss 15211 ATM 34Mb/s - #2 B/G rate 45% - Loss of Cell Synchronisation 15212 ATM 34Mb/s - #2 B/G rate 45% - Pattern Loss 15213 ATM 34Mb/s - #2 B/G rate 45% - Received Cell Count = Result Low 15214 ATM 34Mb/s - #2 B/G rate 45% - Received Cell Count = Result High 15215 ATM 34Mb/s - #2 B/G rate 45% - Selected Cell Not Received detected 15216 ATM 34Mb/s - #2 B/G rate 45% - Received Cell Count = Result Invalid 15220 ATM 34Mb/s - #2 B/G rate 20% - Signal Loss 15221 ATM 34Mb/s - #2 B/G rate 20% - Loss of Cell Synchronisation 15222 ATM 34Mb/s - #2 B/G rate 20% - Pattern Loss 15223 ATM 34Mb/s - #2 B/G rate 20% - Received Cell Count = Result Low 15224 ATM 34Mb/s - #2 B/G rate 20% - Received Cell Count = Result High 15225 ATM 34Mb/s - #2 B/G rate 20% - Selected Cell Not Received detected 15226 ATM 34Mb/s - #2 B/G rate 20% - Received Cell Count = Result Invalid
42
Self Test Error Codes
Self Test Error Codes
15230 ATM 34Mb/s - #3 B/G rate 25% - Signal Loss 15231 ATM 34Mb/s - #3 B/G rate 25% - Loss of Cell Synchronisation 15232 ATM 34Mb/s - #3 B/G rate 25% - Pattern Loss 15233 ATM 34Mb/s - #3 B/G rate 25% - Received Cell Count = Result Low 15234 ATM 34Mb/s - #3 B/G rate 25% - Received Cell Count = Result High 15235 ATM 34Mb/s - #3 B/G rate 25% - Selected Cell Not Received detected 15236 ATM 34Mb/s - #3 B/G rate 25% - Received Cell Count = Result Invalid 15240 ATM 34Mb/s - #3 B/G rate 15% - Signal Loss 15241 ATM 34Mb/s - #3 B/G rate 15% - Loss of Cell Synchronisation 15242 ATM 34Mb/s - #3 B/G rate 15% - Pattern Loss 15243 ATM 34Mb/s - #3 B/G rate 15% - Received Cell Count = Result Low 15244 ATM 34Mb/s - #3 B/G rate 15% - Received Cell Count = Result High 15245 ATM 34Mb/s - #3 B/G rate 15% - Selected Cell Not Received detected 15246 ATM 34Mb/s - #3 B/G rate 15% - Received Cell Count = Result Invalid 15250 ATM 34Mb/s - Fill (Idle) 10% - Signal Loss 15251 ATM 34Mb/s - Fill (Idle) 10% - Loss of Cell Synchronisation 15252 ATM 34Mb/s - Fill (Idle) 10% - Pattern Loss 15253 ATM 34Mb/s - Fill (Idle) 10% - Received Cell Count = Result Low 15254 ATM 34Mb/s - Fill (Idle) 10% - Received Cell Count = Result High 15255 ATM 34Mb/s - Fill (Idle) 10% - Selected Cell Not Received detected 15256 ATM 34Mb/s - Fill (Idle) 10% - Received Cell Count = Result Invalid 15260 ATM 34Mb/s - Periodic 2000Cell/sec - Signal Loss 15261 ATM 34Mb/s - Periodic 2000Cell/sec - Loss of Cell Synchronisation 15262 ATM 34Mb/s - Periodic 2000Cell/sec - Pattern Loss 15263 ATM 34Mb/s - Periodic 2000Cell/sec - Received Cell Count = Result Low 15264 ATM 34Mb/s - Periodic 2000Cell/sec - Received Cell Count = Result High 15265 ATM 34Mb/s - Periodic 2000Cell/sec - Selected Cell Not Received detected 15266 ATM 34Mb/s - Periodic 2000Cell/sec - Received Cell Count = Result Invalid 15270 ATM 34Mb/s - Burst 2000Cell/sec - Signal Loss 15271 ATM 34Mb/s - Burst 2000Cell/sec - Loss of Cell Synchronisation 15272 ATM 34Mb/s - Burst 2000Cell/sec - Pattern Loss 15273 ATM 34Mb/s - Burst 2000Cell/sec - Received Cell Count = Result Low 15274 ATM 34Mb/s - Burst 2000Cell/sec - Received Cell Count = Result High 15275 ATM 34Mb/s - Burst 2000Cell/sec - Selected Cell Not Received not detected 15276 ATM 34Mb/s - Burst 2000Cell/sec - Received Cell Count = Result Invalid 15280 ATM 34Mb/s - Periodic+Burst - Signal Loss 15281 ATM 34Mb/s - Periodic+Burst - Loss of Cell Synchronisation 15282 ATM 34Mb/s - Periodic+Burst - Pattern Loss 15283 ATM 34Mb/s - Periodic+Burst - Received Cell Count = Result Low 15284 ATM 34Mb/s - Periodic+Burst - Received Cell Count = Result High 15285 ATM 34Mb/s - Periodic+Burst - Selected Cell Not Received detected 15286 ATM 34Mb/s - Periodic+Burst - Received Cell Count = Result Invalid 15290 ATM 2Mb/s - CRC4 error add = Signal Loss 15291 ATM 2Mb/s - CRC4 error add = Loss of Cell Synchronisation 15292 ATM 2Mb/s - CRC4 error add = Pattern Loss
43
Self Test Error Codes
Self Test Error Codes
15293 ATM 2Mb/s - CRC4 error add = OFF Result Low 15294 ATM 2Mb/s - CRC4 error add = OFF Result High 15295 ATM 2Mb/s - CRC4 error add = Selected Cell Not Received detected 15296 ATM 2Mb/s - CRC4 error add = OFF Result Invalid 15297 ATM 2Mb/s - CRC4 error add = SINGLE Result Low 15298 ATM 2Mb/s - CRC4 error add = SINGLE Result High 15299 ATM 2Mb/s - CRC4 error add = SINGLE Result Invalid 15300 ATM 2Mb/s - REBE error add = Signal Loss 15301 ATM 2Mb/s - REBE error add = Loss of Cell Synchronisation 15302 ATM 2Mb/s - REBE error add = Pattern Loss 15303 ATM 2Mb/s - REBE error add = OFF Result Low 15304 ATM 2Mb/s - REBE error add = OFF Result High 15305 ATM 2Mb/s - REBE error add = Selected Cell Not Received detected 15306 ATM 2Mb/s - REBE error add = OFF Result Invalid 15307 ATM 2Mb/s - REBE error add = SINGLE Result Low 15308 ATM 2Mb/s - REBE error add = SINGLE Result High 15309 ATM 2Mb/s - REBE error add = SINGLE Result Invalid 15310 ATM 34Mb/s - EM BIP error add = Signal Loss 15311 ATM 34Mb/s - EM BIP error add = Loss of Cell Synchronisation 15312 ATM 34Mb/s - EM BIP error add = Pattern Loss 15313 ATM 34Mb/s - EM BIP error add = OFF Result Low 15314 ATM 34Mb/s - EM BIP error add = OFF Result High 15315 ATM 34Mb/s - EM BIP error add = Selected Cell Not Received detected 15316 ATM 34Mb/s - EM BIP error add = OFF Result Invalid 15317 ATM 34Mb/s - EM BIP error add = SINGLE Result Low 15318 ATM 34Mb/s - EM BIP error add = SINGLE Result High 15319 ATM 34Mb/s - EM BIP error add = SINGLE Result Invalid 15320 ATM 140Mb/s - EM BIP error add = Signal Loss 15321 ATM 140Mb/s - EM BIP error add = Loss of Cell Synchronisation 15322 ATM 140Mb/s - EM BIP error add = Pattern Loss 15323 ATM 140Mb/s - EM BIP error add = OFF Result Low 15324 ATM 140Mb/s - EM BIP error add = OFF Result High 15325 ATM 140Mb/s - EM BIP error add = Selected Cell Not Received detected 15326 ATM 140Mb/s - EM BIP error add = OFF Result Invalid 15327 ATM 140Mb/s - EM BIP error add = SINGLE Result Low 15328 ATM 140Mb/s - EM BIP error add = SINGLE Result High 15329 ATM 140Mb/s - EM BIP error add = SINGLE Result Invalid 15330 ATM 34Mb/s - REI error add = Signal Loss 15331 ATM 34Mb/s - REI error add = Loss of Cell Synchronisation 15332 ATM 34Mb/s - REI error add = Pattern Loss 15333 ATM 34Mb/s - REI error add = OFF Result Low 15334 ATM 34Mb/s - REI error add = OFF Result High 15335 ATM 34Mb/s - REI error add = Selected Cell Not Received detected 15336 ATM 34Mb/s - REI error add = OFF Result Invalid 15337 ATM 34Mb/s - REI error add = ON Result Low 15338 ATM 34Mb/s - REI error add = ON Result High
44
Self Test Error Codes
Self Test Error Codes
15339 ATM 34Mb/s - REI error add = ON Result Invalid 15340 ATM 140Mb/s - REI error add = Signal Loss 15341 ATM 140Mb/s - REI error add = Loss of Cell Synchronisation 15342 ATM 140Mb/s - REI error add = Pattern Loss 15343 ATM 140Mb/s - REI error add = OFF Result Low 15344 ATM 140Mb/s - REI error add = OFF Result High 15345 ATM 140Mb/s - REI error add = Selected Cell Not Received detected 15346 ATM 140Mb/s - REI error add = OFF Result Invalid 15347 ATM 140Mb/s - REI error add = ON Result Low 15348 ATM 140Mb/s - REI error add = ON Result High 15349 ATM 140Mb/s - REI error add = ON Result Invalid 15350 ATM 34Mb/s - SINGLE HEC error add = Signal Loss 15351 ATM 34Mb/s - SINGLE HEC error add = Loss of Cell Synchronisation 15352 ATM 34Mb/s - SINGLE HEC error add = Pattern Loss 15353 ATM 34Mb/s - SINGLE HEC error add = OFF Result Low 15354 ATM 34Mb/s - SINGLE HEC error add = OFF Result High 15355 ATM 34Mb/s - SINGLE HEC error add = Selected Cell Not Received detected 15356 ATM 34Mb/s - SINGLE HEC error add = OFF Result Invalid 15357 ATM 34Mb/s - SINGLE HEC error add = SINGLE Result Low 15358 ATM 34Mb/s - SINGLE HEC error add = SINGLE Result High 15359 ATM 34Mb/s - SINGLE HEC error add = SINGLE Result Invalid 15360 ATM 34Mb/s - SINGLE HEC error add = Signal Loss 15361 ATM 34Mb/s - SINGLE HEC error add = Loss of Cell Synchronisation 15362 ATM 34Mb/s - SINGLE HEC error add = Pattern Loss 15363 ATM 34Mb/s - SINGLE HEC error add = SINGLE (INV HEC) Result Low 15364 ATM 34Mb/s - SINGLE HEC error add = SINGLE (INV HEC) Result High 15365 ATM 34Mb/s - SINGLE HEC error add = Selected Cell Not Received detected 15366 ATM 34Mb/s - SINGLE HEC error add = SINGLE (INV HEC) Result Invalid 15367 ATM 34Mb/s - SINGLE HEC error add = 1..0E-3 Result Low 15368 ATM 34Mb/s - SINGLE HEC error add = 1..0E-3 Result High 15369 ATM 34Mb/s - SINGLE HEC error add = 1..0E-3 Result Invalid 15370 ATM 34Mb/s - SINGLE HEC error add = Signal Loss 15371 ATM 34Mb/s - SINGLE HEC error add = Loss of Cell Synchronisation 15372 ATM 34Mb/s - SINGLE HEC error add = Pattern Loss 15373 ATM 34Mb/s - SINGLE HEC error add = BURST (COR HEC) Result Low 15374 ATM 34Mb/s - SINGLE HEC error add = BURST (COR HEC) Result High 15375 ATM 34Mb/s - SINGLE HEC error add = Selected Cell Not Received detected 15376 ATM 34Mb/s - SINGLE HEC error add = BURST (COR HEC) Result Invalid 15377 ATM 34Mb/s - SINGLE HEC error add = BURST (INV HEC) Result Low 15378 ATM 34Mb/s - SINGLE HEC error add = BURST (INV HEC) Result High 15379 ATM 34Mb/s - SINGLE HEC error add = BURST (INV HEC) Result Invalid 15380 ATM 34Mb/s - DOUBLE HEC error add = Signal Loss 15381 ATM 34Mb/s - DOUBLE HEC error add = Loss of Cell Synchronisation 15382 ATM 34Mb/s - DOUBLE HEC error add = Pattern Loss 15383 ATM 34Mb/s - DOUBLE HEC error add = OFF Result Low 15384 ATM 34Mb/s - DOUBLE HEC error add = OFF Result High
45
Self Test Error Codes
Self Test Error Codes
15385 ATM 34Mb/s - DOUBLE HEC error add = Selected Cell Not Received detected 15386 ATM 34Mb/s - DOUBLE HEC error add = OFF Result Invalid 15387 ATM 34Mb/s - DOUBLE HEC error add = SINGLE Result Low 15388 ATM 34Mb/s - DOUBLE HEC error add = SINGLE Result High 15389 ATM 34Mb/s - DOUBLE HEC error add = SINGLE Result Invalid 15390 ATM 34Mb/s - DOUBLE HEC error add = Signal Loss 15391 ATM 34Mb/s - DOUBLE HEC error add = Loss of Cell Synchronisation 15392 ATM 34Mb/s - DOUBLE HEC error add = Pattern Loss 15393 ATM 34Mb/s - DOUBLE HEC error add = SINGLE (COR HEC) Result Low 15394 ATM 34Mb/s - DOUBLE HEC error add = SINGLE (COR HEC) Result High 15395 ATM 34Mb/s - DOUBLE HEC error add = Selected Cell Not Received detected 15396 ATM 34Mb/s - DOUBLE HEC error add = SINGLE (COR HEC) Result Invalid 15397 ATM 34Mb/s - DOUBLE HEC error add = 1..0E-3 Result Low 15398 ATM 34Mb/s - DOUBLE HEC error add = 1..0E-3 Result High 15399 ATM 34Mb/s - DOUBLE HEC error add = 1..0E-3 Result Invalid 15400 ATM 34Mb/s - DOUBLE HEC error add = Signal Loss 15401 ATM 34Mb/s - DOUBLE HEC error add = Loss of Cell Synchronisation 15402 ATM 34Mb/s - DOUBLE HEC error add = Pattern Loss 15403 ATM 34Mb/s - DOUBLE HEC error add = BURST (COR HEC) Result Low 15404 ATM 34Mb/s - DOUBLE HEC error add = BURST (COR HEC) Result High 15405 ATM 34Mb/s - DOUBLE HEC error add = Selected Cell Not Received detected 15406 ATM 34Mb/s - DOUBLE HEC error add = BURST (COR HEC) Result Invalid 15407 ATM 34Mb/s - DOUBLE HEC error add = BURST (INV HEC) Result Low 15408 ATM 34Mb/s - DOUBLE HEC error add = BURST (INV HEC) Result High 15409 ATM 34Mb/s - DOUBLE HEC error add = BURST (INV HEC) Result Invalid 15410 ATM 34Mb/s - BIT error add = Signal Loss 15411 ATM 34Mb/s - BIT error add = Loss of Cell Synchronisation 15412 ATM 34Mb/s - BIT error add = Pattern Loss 15413 ATM 34Mb/s - BIT error add = OFF Result Low 15414 ATM 34Mb/s - BIT error add = OFF Result High 15415 ATM 34Mb/s - BIT error add = Selected Cell Not Received detected 15416 ATM 34Mb/s - BIT error add = OFF Result Invalid 15417 ATM 34Mb/s - BIT error add = SINGLE Result Low 15418 ATM 34Mb/s - BIT error add = SINGLE Result High 15419 ATM 34Mb/s - BIT error add = SINGLE Result Invalid 15420 ATM 34Mb/s - BIT error add = Signal Loss 15421 ATM 34Mb/s - BIT error add = Loss of Cell Synchronisation 15422 ATM 34Mb/s - BIT error add = Pattern Loss 15423 ATM 34Mb/s - BIT error add = SINGLE (Err Cell Cnt) Result Low 15424 ATM 34Mb/s - BIT error add = SINGLE (Err Cell Cnt) Result High 15425 ATM 34Mb/s - BIT error add = Selected Cell Not Received detected 15426 ATM 34Mb/s - BIT error add = SINGLE (Err Cell Cnt) Result Invalid 15427 ATM 34Mb/s - BIT error add = 1..0E-3 Result Low 15428 ATM 34Mb/s - BIT error add = 1..0E-3 Result High 15429 ATM 34Mb/s - BIT error add = 1..0E-3 Result Invalid 15430 ATM 140Mb/s - F/G GFC = 10 - Signal Loss
46
Self Test Error Codes
Self Test Error Codes
15431 ATM 140Mb/s - F/G GFC = 10 - Loss of Cell Synchronisation 15433 ATM 140Mb/s - F/G GFC = 10 Received Cell Count = Result Low 15434 ATM 140Mb/s - F/G GFC = 10 Received Cell Count = Result High 15435 ATM 140Mb/s - F/G GFC = 10 - Selected Cell Not Received detected 15436 ATM 140Mb/s - F/G GFC = 10 Received Cell Count = Result Invalid 15440 ATM 140Mb/s - F/G VPI = 85 - Signal Loss 15441 ATM 140Mb/s - F/G VPI = 85 - Loss of Cell Synchronisation 15443 ATM 140Mb/s - F/G VPI = 85 Received Cell Count = Result Low 15444 ATM 140Mb/s - F/G VPI = 85 Received Cell Count = Result High 15445 ATM 140Mb/s - F/G VPI = 85 - Selected Cell Not Received detected 15446 ATM 140Mb/s - F/G VPI = 85 Received Cell Count = Result Invalid 15450 ATM 140Mb/s - F/G VPI = 2730 - Signal Loss 15451 ATM 140Mb/s - F/G VPI = 2730 - Loss of Cell Synchronisation 15453 ATM 140Mb/s - F/G VPI = 2730 Received Cell Count = Result Low 15454 ATM 140Mb/s - F/G VPI = 2730 Received Cell Count = Result High 15455 ATM 140Mb/s - F/G VPI = 2730 - Selected Cell Not Received detected 15456 ATM 140Mb/s - F/G VPI = 2730 Received Cell Count = Result Invalid 15460 ATM 140Mb/s - F/G VCI = 21845 - Signal Loss 15461 ATM 140Mb/s - F/G VCI = 21845 - Loss of Cell Synchronisation 15463 ATM 140Mb/s - F/G VCI = 21845 Received Cell Count = Result Low 15464 ATM 140Mb/s - F/G VCI = 21845 Received Cell Count = Result High 15465 ATM 140Mb/s - F/G VCI = 21845 - Selected Cell Not Received detected 15466 ATM 140Mb/s - F/G VCI = 21845 Received Cell Count = Result Invalid 15470 ATM 140Mb/s - F/G PTI = 000 - Signal Loss 15471 ATM 140Mb/s - F/G PTI = 000 - Loss of Cell Synchronisation 15473 ATM 140Mb/s - F/G PTI = 000 Received Cell Count = Result Low 15474 ATM 140Mb/s - F/G PTI = 000 Received Cell Count = Result High 15475 ATM 140Mb/s - F/G PTI = 000 - Selected Cell Not Received detected 15476 ATM 140Mb/s - F/G PTI = 000 Received Cell Count = Result Invalid 15480 ATM 140Mb/s - F/G PTI = 010 - Signal Loss 15481 ATM 140Mb/s - F/G PTI = 010 - Loss of Cell Synchronisation 15483 ATM 140Mb/s - F/G PTI = 010 Received Cell Count = Result Low 15484 ATM 140Mb/s - F/G PTI = 010 Received Cell Count = Result High 15485 ATM 140Mb/s - F/G PTI = 010 - Selected Cell Not Received detected 15486 ATM 140Mb/s - F/G PTI = 010 Received Cell Count = Result Invalid 15490 ATM 140Mb/s - F/G CLP = 0 - Signal Loss 15491 ATM 140Mb/s - F/G CLP = 0 - Loss of Cell Synchronisation 15493 ATM 140Mb/s - F/G CLP = 0 Received Cell Count = Result Low 15494 ATM 140Mb/s - F/G CLP = 0 Received Cell Count = Result High 15495 ATM 140Mb/s - F/G CLP = 0 - Selected Cell Not Received detected 15496 ATM 140Mb/s - F/G CLP = 0 Received Cell Count = Result Invalid 15500 ATM 140Mb/s - F/G CLP = 1 - Signal Loss 15501 ATM 140Mb/s - F/G CLP = 1 - Loss of Cell Synchronisation 15503 ATM 140Mb/s - F/G CLP = 1 Received Cell Count = Result Low 15504 ATM 140Mb/s - F/G CLP = 1 Received Cell Count = Result High 15505 ATM 140Mb/s - F/G CLP = 1 - Selected Cell Not Received detected
47
Self Test Error Codes
Self Test Error Codes
15506 ATM 140Mb/s - F/G CLP = 1 Received Cell Count = Result Invalid 15510 ATM 140Mb/s - RX GFC = X - Signal Loss 15511 ATM 140Mb/s - RX GFC = X - Loss of Cell Synchronisation 15513 ATM 140Mb/s - RX GFC = X Received Cell Count = Result Low 15514 ATM 140Mb/s - RX GFC = X Received Cell Count = Result High 15515 ATM 140Mb/s - RX GFC = X - Selected Cell Not Received detected 15516 ATM 140Mb/s - RX GFC = X Received Cell Count = Result Invalid 15520 ATM 140Mb/s - RX GFC = 2 - Signal Loss 15521 ATM 140Mb/s - RX GFC = 2 - Loss of Cell Synchronisation 15523 ATM 140Mb/s - RX GFC = 2 Received Cell Count = Result Low 15524 ATM 140Mb/s - RX GFC = 2 Received Cell Count = Result High 15525 ATM 140Mb/s - RX GFC = 2 - Selected Cell Not Received detected 15526 ATM 140Mb/s - RX GFC = 2 Received Cell Count = Result Invalid 15530 ATM 140Mb/s - RX VPI = X - Signal Loss 15531 ATM 140Mb/s - RX VPI = X - Loss of Cell Synchronisation 15533 ATM 140Mb/s - RX VPI = X Received Cell Count = Result Low 15534 ATM 140Mb/s - RX VPI = X Received Cell Count = Result High 15535 ATM 140Mb/s - RX VPI = X - Selected Cell Not Received detected 15536 ATM 140Mb/s - RX VPI = X Received Cell Count = Result Invalid 15540 ATM 140Mb/s - RX VPI = 0 - Signal Loss 15541 ATM 140Mb/s - RX VPI = 0 - Loss of Cell Synchronisation 15543 ATM 140Mb/s - RX VPI = 0 Received Cell Count = Result Low 15544 ATM 140Mb/s - RX VPI = 0 Received Cell Count = Result High 15545 ATM 140Mb/s - RX VPI = 0 - Selected Cell Not Received detected 15546 ATM 140Mb/s - RX VPI = 0 Received Cell Count = Result Invalid 15550 ATM 140Mb/s - RX VPI = 85 - Signal Loss 15551 ATM 140Mb/s - RX VPI = 85 - Loss of Cell Synchronisation 15553 ATM 140Mb/s - RX VPI = 85 Received Cell Count = Result Low 15554 ATM 140Mb/s - RX VPI = 85 Received Cell Count = Result High 15555 ATM 140Mb/s - RX VPI = 85 - Selected Cell Not Received detected 15556 ATM 140Mb/s - RX VPI = 85 Received Cell Count = Result Invalid 15560 ATM 140Mb/s - RX VCI = X - Signal Loss 15561 ATM 140Mb/s - RX VCI = X - Loss of Cell Synchronisation 15563 ATM 140Mb/s - RX VCI = X Received Cell Count = Result Low 15564 ATM 140Mb/s - RX VCI = X Received Cell Count = Result High 15565 ATM 140Mb/s - RX VCI = X - Selected Cell Not Received detected 15566 ATM 140Mb/s - RX VCI = X Received Cell Count = Result Invalid 15570 ATM 140Mb/s - RX VCI = 33 - Signal Loss 15571 ATM 140Mb/s - RX VCI = 33 - Loss of Cell Synchronisation 15573 ATM 140Mb/s - RX VCI = 33 Received Cell Count = Result Low 15574 ATM 140Mb/s - RX VCI = 33 Received Cell Count = Result High 15575 ATM 140Mb/s - RX VCI = 33 - Selected Cell Not Received detected 15576 ATM 140Mb/s - RX VCI = 33 Received Cell Count = Result Invalid 15580 ATM 140Mb/s - RX PTI = XXX - Signal Loss 15581 ATM 140Mb/s - RX PTI = XXX - Loss of Cell Synchronisation 15583 ATM 140Mb/s - RX PTI = XXX Received Cell Count = Result Low
48
Self Test Error Codes
Self Test Error Codes
15584 ATM 140Mb/s - RX PTI = XXX Received Cell Count = Result High 15585 ATM 140Mb/s - RX PTI = XXX - Selected Cell Not Received detected 15586 ATM 140Mb/s - RX PTI = XXX Received Cell Count = Result Invalid 15590 ATM 140Mb/s - RX PTI = 0XX - Signal Loss 15591 ATM 140Mb/s - RX PTI = 0XX - Loss of Cell Synchronisation 15593 ATM 140Mb/s - RX PTI = 0XX Received Cell Count = Result Low 15594 ATM 140Mb/s - RX PTI = 0XX Received Cell Count = Result High 15595 ATM 140Mb/s - RX PTI = 0XX - Selected Cell Not Received detected 15596 ATM 140Mb/s - RX PTI = 0XX Received Cell Count = Result Invalid 15600 ATM 140Mb/s - RX PTI = X1X - Signal Loss 15601 ATM 140Mb/s - RX PTI = X1X - Loss of Cell Synchronisation 15603 ATM 140Mb/s - RX PTI = X1X Received Cell Count = Result Low 15604 ATM 140Mb/s - RX PTI = X1X Received Cell Count = Result High 15605 ATM 140Mb/s - RX PTI = X1X - Selected Cell Not Received detected 15606 ATM 140Mb/s - RX PTI = X1X Received Cell Count = Result Invalid 15610 ATM 140Mb/s - RX PTI = XX0 - Signal Loss 15611 ATM 140Mb/s - RX PTI = XX0 - Loss of Cell Synchronisation 15613 ATM 140Mb/s - RX PTI = XX0 Received Cell Count = Result Low 15614 ATM 140Mb/s - RX PTI = XX0 Received Cell Count = Result High 15615 ATM 140Mb/s - RX PTI = XX0 - Selected Cell Not Received detected 15616 ATM 140Mb/s - RX PTI = XX0 Received Cell Count = Result Invalid 15620 ATM 140Mb/s - RX CLP = X - Signal Loss 15621 ATM 140Mb/s - RX CLP = X - Loss of Cell Synchronisation 15623 ATM 140Mb/s - RX CLP = X Received Cell Count = Result Low 15624 ATM 140Mb/s - RX CLP = X Received Cell Count = Result High 15625 ATM 140Mb/s - RX CLP = X - Selected Cell Not Received detected 15626 ATM 140Mb/s - RX CLP = X Received Cell Count = Result Invalid 15630 ATM 140Mb/s - RX CLP = 0 - Signal Loss 15631 ATM 140Mb/s - RX CLP = 0 - Loss of Cell Synchronisation 15633 ATM 140Mb/s - RX CLP = 0 Received Cell Count = Result Low 15634 ATM 140Mb/s - RX CLP = 0 Received Cell Count = Result High 15635 ATM 140Mb/s - RX CLP = 0 - Selected Cell Not Received detected 15636 ATM 140Mb/s - RX CLP = 0 Received Cell Count = Result Invalid 15640 ATM 140Mb/s - RX CLP = 1 - Signal Loss 15641 ATM 140Mb/s - RX CLP = 1 - Loss of Cell Synchronisation 15643 ATM 140Mb/s - RX CLP = 1 Received Cell Count = Result Low 15644 ATM 140Mb/s - RX CLP = 1 Received Cell Count = Result High 15645 ATM 140Mb/s - RX CLP = 1 - Selected Cell Not Received detected 15646 ATM 140Mb/s - RX CLP = 1 Received Cell Count = Result Invalid 15650 ATM 34Mb/s - Cross Cell 2^15-1 - Signal Loss 15651 ATM 34Mb/s - Cross Cell 2^15-1 - Loss of Cell Synchronisation 15652 ATM 34Mb/s - Cross Cell 2^15-1 - Pattern Loss 15654 ATM 34Mb/s - Cross Cell 2^15-1 - Pattern Errors Present 15655 ATM 34Mb/s - Cross Cell 2^15-1 - Selected Cell Not Received detected 15656 ATM 34Mb/s - Cross Cell 2^15-1 - Result Invalid 15660 ATM 34Mb/s - Cross Cell 2^23-1 - Signal Loss
49
Self Test Error Codes
Self Test Error Codes
15661 ATM 34Mb/s - Cross Cell 2^23-1 - Loss of Cell Synchronisation 15662 ATM 34Mb/s - Cross Cell 2^23-1 - Pattern Loss 15664 ATM 34Mb/s - Cross Cell 2^23-1 - Pattern Errors Present 15665 ATM 34Mb/s - Cross Cell 2^23-1 - Selected Cell Not Received detected 15666 ATM 34Mb/s - Cross Cell 2^23-1 - Result Invalid 15670 ATM 34Mb/s - Single Cell 2^9-1 - Signal Loss 15671 ATM 34Mb/s - Single Cell 2^9-1 - Loss of Cell Synchronisation 15672 ATM 34Mb/s - Single Cell 2^9-1 - Pattern Loss 15674 ATM 34Mb/s - Single Cell 2^9-1 - Pattern Errors Present 15675 ATM 34Mb/s - Single Cell 2^9-1 - Selected Cell Not Received detected 15676 ATM 34Mb/s - Single Cell 2^9-1 - Result Invalid 15680 ATM 140Mb/s - User Word 00000000 - Signal Loss 15681 ATM 140Mb/s - User Word 00000000 - Loss of Cell Synchronisation 15682 ATM 140Mb/s - User Word 00000000 - Pattern Loss 15684 ATM 140Mb/s - User Word 00000000 - Pattern Errors Present 15685 ATM 140Mb/s - User Word 00000000 - Selected Cell Not Received detected 15686 ATM 140Mb/s - User Word 00000000 - Result Invalid 15690 ATM 140Mb/s - User Word 11111111 - Signal Loss 15691 ATM 140Mb/s - User Word 11111111 - Loss of Cell Synchronisation 15692 ATM 140Mb/s - User Word 11111111 - Pattern Loss 15694 ATM 140Mb/s - User Word 11111111 - Pattern Errors Present 15695 ATM 140Mb/s - User Word 11111111 - Selected Cell Not Received detected 15696 ATM 140Mb/s - User Word 11111111 - Result Invalid 15700 ATM 2Mb/s - User Word 01010101 - Signal Loss 15701 ATM 2Mb/s - User Word 01010101 - Loss of Cell Synchronisation 15702 ATM 2Mb/s - User Word 01010101 - Pattern Loss 15704 ATM 2Mb/s - User Word 01010101 - Pattern Errors Present 15705 ATM 2Mb/s - User Word 01010101 - Selected Cell Not Received detected 15706 ATM 2Mb/s - User Word 01010101 - Result Invalid 15710 ATM 2Mb/s - Test Cell - Signal Loss 15711 ATM 2Mb/s - Test Cell - Loss of Cell Synchronisation 15712 ATM 2Mb/s - Test Cell - Pattern Loss 15714 ATM 2Mb/s - Test Cell - Pattern Errors Present 15715 ATM 2Mb/s - Test Cell - Selected Cell Not Received detected 15716 ATM 2Mb/s - Test Cell - Result Invalid 15720 ATM 34Mb/s - Single Header error add - Signal Loss 15721 ATM 34Mb/s - Single Header error add - Loss of Cell Synchronisation 15722 ATM 34Mb/s - Single Header error add - Pattern Loss 15723 ATM 34Mb/s - Single Header error add - Cell Loss Count = Result Low 15724 ATM 34Mb/s - Single Header error add - Cell Loss Count = Result High 15725 ATM 34Mb/s - Single Header error add - Selected Cell Not Received detected 15726 ATM 34Mb/s - Single Header error add - Cell Loss Count = Result Invalid 15730 ATM 34Mb/s - Double Header error add - Signal Loss 15731 ATM 34Mb/s - Double Header error add - Loss of Cell Synchronisation 15732 ATM 34Mb/s - Double Header error add - Pattern Loss 15733 ATM 34Mb/s - Double Header error add - Cell Loss Count = Result Low
50
Self Test Error Codes
Self Test Error Codes
15734 ATM 34Mb/s - Double Header error add - Cell Loss Count = Result High 15735 ATM 34Mb/s - Double Header error add - Selected Cell Not Received detected 15736 ATM 34Mb/s - Double Header error add - Cell Loss Count = Result Invalid 15740 ATM 34Mb/s - 100msec Double Header error add - Signal Loss 15741 ATM 34Mb/s - 100msec Double Header error add - Loss of Cell Synchronisation 15742 ATM 34Mb/s - 100msec Double Header error add - Pattern Loss 15743 ATM 34Mb/s - 100msec Double Header error add - Cell Loss Count = Result Low 15744 ATM 34Mb/s - 100msec Double Header error add -Cell Loss Count = Result High 15745 ATM 34Mb/s - 100msec Double Header error add - Selected Cell Not Received
detected
15746 ATM 34Mb/s - 100msec Double Header error add -Cell Loss Count = Result
Invalid 15750 ATM 34Mb/s - Type A - Signal Loss 15751 ATM 34Mb/s - Type A - Loss of Cell Synchronisation 15752 ATM 34Mb/s - Type A - Pattern Loss 15753 ATM 34Mb/s - Type A - Misinserted Cell Count = Result Low 15754 ATM 34Mb/s - Type A - Misinserted Cell Count = Result High 15755 ATM 34Mb/s - Type A - Selected Cell Not Received detected 15756 ATM 34Mb/s - Type A - Misinserted Cell Count = Result Invalid 15757 ATM 34Mb/s - Type A - Errored Cell Count = Result Low 15758 ATM 34Mb/s - Type A - Errored Cell Count = Result High 15759 ATM 34Mb/s - Type A - Errored Cell Count = Result Invalid 15760 ATM 34Mb/s - Type B - Signal Loss 15761 ATM 34Mb/s - Type B - Loss of Cell Synchronisation 15762 ATM 34Mb/s - Type B - Pattern Loss 15763 ATM 34Mb/s - Type B - Misinserted Cell Count = Result Low 15764 ATM 34Mb/s - Type B - Misinserted Cell Count = Result High 15765 ATM 34Mb/s - Type B - Selected Cell Not Received detected 15766 ATM 34Mb/s - Type B - Misinserted Cell Count = Result Invalid 15767 ATM 34Mb/s - Type B - Errored Cell Count = Result Low 15768 ATM 34Mb/s - Type B - Errored Cell Count = Result High 15769 ATM 34Mb/s - Type B - Errored Cell Count = Result Invalid 15770 ATM 34Mb/s - Type C - Signal Loss 15771 ATM 34Mb/s - Type C - Loss of Cell Synchronisation 15772 ATM 34Mb/s - Type C - Pattern Loss 15773 ATM 34Mb/s - Type C - Misinserted Cell Count = Result Low 15774 ATM 34Mb/s - Type C - Misinserted Cell Count = Result High 15775 ATM 34Mb/s - Type C - Selected Cell Not Received detected 15776 ATM 34Mb/s - Type C - Misinserted Cell Count = Result Invalid 15777 ATM 34Mb/s - Type C - Errored Cell Count = Result Low 15778 ATM 34Mb/s - Type C - Errored Cell Count = Result High 15779 ATM 34Mb/s - Type C - Errored Cell Count = Result Invalid 15780 ATM 34Mb/s - Mean Cell Transfer delay = Signal Loss 15781 ATM 34Mb/s - Mean Cell Transfer delay = Loss of Cell Synchronisation 15782 ATM 34Mb/s - Mean Cell Transfer delay = Pattern Loss 15783 ATM 34Mb/s - Mean Cell Transfer delay = 0 - Result Low
51
Self Test Error Codes
Self Test Error Codes
15784 ATM 34Mb/s - Mean Cell Transfer delay = 0 - Result High 15785 ATM 34Mb/s - Mean Cell Transfer delay = Selected Cell Not Received detected 15786 ATM 34Mb/s - Mean Cell Transfer delay = 0 - Result Invalid 15787 ATM 34Mb/s - Mean Cell Transfer delay = 307 - Result Low 15788 ATM 34Mb/s - Mean Cell Transfer delay = 307 - Result High 15789 ATM 34Mb/s - Mean Cell Transfer delay = 307 - Result Invalid 15790 ATM 34Mb/s - Gated Mean Cell Transfer delay = Signal Loss 15791 ATM 34Mb/s - Gated Mean Cell Transfer delay = Loss of Cell Synchronisation 15792 ATM 34Mb/s - Gated Mean Cell Transfer delay = Pattern Loss 15793 ATM 34Mb/s - Gated Mean Cell Transfer delay = 0 - Result Low 15794 ATM 34Mb/s - Gated Mean Cell Transfer delay = 0 - Result High 15795 ATM 34Mb/s -Gated Mean Cell Transfer delay =Selected Cell Not Received
detected 15796 ATM 34Mb/s - Gated Mean Cell Transfer delay = 0 - Result Invalid 15797 ATM 34Mb/s - Gated Mean Cell Transfer delay = 307 - Result Low 15798 ATM 34Mb/s - Gated Mean Cell Transfer delay = 307 - Result High 15799 ATM 34Mb/s - Gated Mean Cell Transfer delay = 307 - Result Invalid 15800 ATM 34Mb/s - Max Cell Transfer delay = Signal Loss 15801 ATM 34Mb/s - Max Cell Transfer delay = Loss of Cell Synchronisation 15802 ATM 34Mb/s - Max Cell Transfer delay = Pattern Loss 15803 ATM 34Mb/s - Max Cell Transfer delay = 0 - Result Low 15804 ATM 34Mb/s - Max Cell Transfer delay = 0 - Result High 15805 ATM 34Mb/s - Max Cell Transfer delay = Selected Cell Not Received detected 15806 ATM 34Mb/s - Max Cell Transfer delay = 0 - Result Invalid 15807 ATM 34Mb/s - Max Cell Transfer delay = 307 - Result Low 15808 ATM 34Mb/s - Max Cell Transfer delay = 307 - Result High 15809 ATM 34Mb/s - Max Cell Transfer delay = 307 - Result Invalid 15810 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = Signal Loss 15811 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = Loss of Cell Synchronisation 15812 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = Pattern Loss 15813 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = 0 - Result Low 15814 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = 0 - Result High 15815 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = Selected Cell Not Received
detected 15816 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = 0 - Result Invalid 15817 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = 625 - Result Low 15818 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = 625 - Result High 15819 ATM 34Mb/s - Pk-to-Pk Cell Transfer delay = 625 - Result Invalid 15820 ATM 34Mb/s - Bit Error Add = OFF (Err Cell)- Signal Loss 15821 ATM 34Mb/s - Bit Error Add = OFF (Err Cell)- Loss of Cell Synchronisation 15822 ATM 34Mb/s - Bit Error Add = OFF (Err Cell)- Pattern Loss 15823 ATM 34Mb/s - Bit Error Add = OFF (Err Cell)- Result Low 15824 ATM 34Mb/s - Bit Error Add = OFF (Err Cell)- Result High 15825 ATM 34Mb/s - Bit Error Add = OFF (Err Cell)- Selected Cell Not Received
detected 15826 ATM 34Mb/s - Bit Error Add = OFF (Err Cell)- Result Invalid
52
Self Test Error Codes
Self Test Error Codes
15830 ATM 34Mb/s - Bit Error Add = SINGLE (Err Cell)- Signal Loss 15831 ATM 34Mb/s - Bit Error Add = SINGLE (Err Cell)- Loss of Cell
Synchronisation 15832 ATM 34Mb/s - Bit Error Add = SINGLE (Err Cell)- Pattern Loss 15833 ATM 34Mb/s - Bit Error Add = SINGLE (Err Cell)- Result Low 15834 ATM 34Mb/s - Bit Error Add = SINGLE (Err Cell)- Result High 15835 ATM 34Mb/s - Bit Error Add = SINGLE (Err Cell)- Selected Cell Not Received
detected 15836 ATM 34Mb/s - Bit Error Add = SINGLE (Err Cell)- Result Invalid 15840 ATM 34Mb/s - Bit Error Add = 1.0E-3 (Err Cell)- Signal Loss 15841 ATM 34Mb/s - Bit Error Add = 1.0E-3 (Err Cell)- Loss of Cell
Synchronisation 15842 ATM 34Mb/s - Bit Error Add = 1.0E-3 (Err Cell)- Pattern Loss 15843 ATM 34Mb/s - Bit Error Add = 1.0E-3 (Err Cell)- Result Low 15844 ATM 34Mb/s - Bit Error Add = 1.0E-3 (Err Cell)- Result High 15845 ATM 34Mb/s - Bit Error Add = 1.0E-3 (Err Cell)- Selected Cell Not Received
detected 15846 ATM 34Mb/s - Bit Error Add = 1.0E-3 (Err Cell)- Result Invalid 15850 ATM 34Mb/s = NCCount - Type A - Signal Loss 15851 ATM 34Mb/s = NCCount - Type A - Loss of Cell Synchronisation 15852 ATM 34Mb/s = NCCount - Type A - Pattern Loss 15853 ATM 34Mb/s = NCCount - Type A - Result Low 15854 ATM 34Mb/s = NCCount - Type A - Result High 15855 ATM 34Mb/s = NCCount - Type A - Selected Cell Not Received detected 15856 ATM 34Mb/s = NCCount - Type A - Result Invalid 15860 ATM 34Mb/s = NCCount - Signal Loss 15861 ATM 34Mb/s = NCCount - Loss of Cell Synchronisation 15862 ATM 34Mb/s = NCCount - Pattern Loss 15863 ATM 34Mb/s = NCCount - Type B - Result Low 15864 ATM 34Mb/s = NCCount - Type B - Result High 15865 ATM 34Mb/s = NCCount - Selected Cell Not Received detected 15866 ATM 34Mb/s = NCCount - Type B - Result Invalid 15867 ATM 34Mb/s = NCCount - Type C - Result Low 15868 ATM 34Mb/s = NCCount - Type C - Result High 15869 ATM 34Mb/s = NCCount - Type C - Result Invalid 15870 ATM 34Mb/s - PCR 20000Cell/sec - Signal Loss 15871 ATM 34Mb/s - PCR 20000Cell/sec - Loss of Cell Synchronisation 15872 ATM 34Mb/s - PCR 20000Cell/sec - Pattern Loss 15873 ATM 34Mb/s - PCR 20000Cell/sec - Result Low 15874 ATM 34Mb/s - PCR 20000Cell/sec - Result High 15875 ATM 34Mb/s - PCR 20000Cell/sec - Selected Cell Not Received detected 15876 ATM 34Mb/s - PCR 20000Cell/sec - Result Invalid 15880 ATM 34Mb/s - PCR 60000Cell/sec - Signal Loss 15881 ATM 34Mb/s - PCR 60000Cell/sec - Loss of Cell Synchronisation 15882 ATM 34Mb/s - PCR 60000Cell/sec - Pattern Loss 15883 ATM 34Mb/s - PCR 60000Cell/sec - Result Low
53
Self Test Error Codes
Self Test Error Codes
15884 ATM 34Mb/s - PCR 60000Cell/sec - Result High 15885 ATM 34Mb/s - PCR 60000Cell/sec - Selected Cell Not Received detected 15886 ATM 34Mb/s - PCR 60000Cell/sec - Result Invalid 15890 ATM - Trail Trace - Signal Loss 15891 ATM - Trail Trace - Loss of Cell Synchronisation 15892 ATM - Trail Trace - Pattern Loss 15895 ATM - Trail Trace - Selected Cell Not Received detected 15896 ATM 34Mb/s - TEST Trail Trace - String not correct 15897 ATM 140Mb/s - TEST Trail Trace - String not correct 15898 ATM 34Mb/s - USER Trail Trace - String not correct 15899 ATM 140Mb/s - USER Trail Trace - String not correct 15906 ATM 34Mb/s - LPM - F4 Segment - Loss of Perf Management Not Detected 15907 ATM 34Mb/s - LPM - F4 Segment - Loss of Perf Management Detected 15916 ATM 34Mb/s - LPM - F4 End-to-End - Loss of Perf Management Not Detected 15917 ATM 34Mb/s - LPM - F4 End-to-End - Loss of Perf Management Detected 15926 ATM 34Mb/s - LPM - F5 Segment - Loss of Perf Management Not Detected 15927 ATM 34Mb/s - LPM - F5 Segment - Loss of Perf Management Detected 15936 ATM 34Mb/s - LPM - F5 End-to-End - Loss of Perf Management Not Detected 15937 ATM 34Mb/s - LPM - F5 End-to-End - Loss of Perf Management Detected 15940 ATM 34Mb/s - POAM F4 Seg BEDC errors - Signal Loss 15941 ATM 34Mb/s - POAM F4 Seg BEDC errors - Loss of Cell Synchronisation 15942 ATM 34Mb/s - POAM F4 Seg BEDC errors - Pattern Loss 15943 ATM 34Mb/s - POAM F4 Seg BEDC errors (0)- Received Cell Count = Result Low 15944 ATM 34Mb/s - POAM F4 Seg BEDC errors (0) - Received Cell Count = Result
High 15945 ATM 34Mb/s - POAM F4 Seg BEDC errors - Selected Cell Not Received detected 15946 ATM 34Mb/s - POAM F4 Seg BEDC errors (0) - Received Cell Count = Result
Invalid 15947 ATM 34Mb/s - POAM F4 Seg BEDC errors (3) - Received Cell Count = Result Low 15948 ATM 34Mb/s - POAM F4 Seg BEDC errors (3) - Received Cell Count = Result
High 15949 ATM 34Mb/s - POAM F4 Seg BEDC errors (3) - Received Cell Count = Result
Invalid 15950 ATM 34Mb/s - POAM F4 End BEDC errors - Signal Loss 15951 ATM 34Mb/s - POAM F4 End BEDC errors - Loss of Cell Synchronisation 15952 ATM 34Mb/s - POAM F4 End BEDC errors - Pattern Loss 15953 ATM 34Mb/s - POAM F4 End BEDC errors (0) - Received Cell Count = Result Low 15954 ATM 34Mb/s - POAM F4 End BEDC errors (0) - Received Cell Count = Result
High 15955 ATM 34Mb/s - POAM F4 End BEDC errors - Selected Cell Not Received detected 15956 ATM 34Mb/s - POAM F4 End BEDC errors (0) - Received Cell Count = Result
Invalid 15957 ATM 34Mb/s - POAM F4 End BEDC errors (3) - Received Cell Count = Result Low 15958 ATM 34Mb/s - POAM F4 End BEDC errors (3) - Received Cell Count = Result
High
54
Self Test Error Codes
Self Test Error Codes
15959 ATM 34Mb/s - POAM F4 End BEDC errors (3) -Received Cell Count =Result
Invalid 15960 ATM 34Mb/s - POAM F5 Seg BEDC errors - Signal Loss 15961 ATM 34Mb/s - POAM F5 Seg BEDC errors - Loss of Cell Synchronisation 15962 ATM 34Mb/s - POAM F5 Seg BEDC errors - Pattern Loss 15963 ATM 34Mb/s - POAM F5 Seg BEDC errors (0) - Received Cell Count = Result Low 15964 ATM 34Mb/s - POAM F5 Seg BEDC errors (0) - Received Cell Count = Result
High 15965 ATM 34Mb/s - POAM F5 Seg BEDC errors - Selected Cell Not Received detected 15966 ATM 34Mb/s - POAM F5 Seg BEDC errors (0) - Received Cell Count = Result
Invalid 15967 ATM 34Mb/s - POAM F5 Seg BEDC errors (3) - Received Cell Count = Result Low 15968 ATM 34Mb/s - POAM F5 Seg BEDC errors (3) - Received Cell Count = Result
High 15969 ATM 34Mb/s - POAM F5 Seg BEDC errors (3) - Received Cell Count = Result
Invalid 15970 ATM 34Mb/s - POAM F5 End BEDC errors - Signal Loss 15971 ATM 34Mb/s - POAM F5 End BEDC errors - Loss of Cell Synchronisation 15972 ATM 34Mb/s - POAM F5 End BEDC errors - Pattern Loss 15973 ATM 34Mb/s - POAM F5 End BEDC errors (0) - Received Cell Count = Result Low 15974 ATM 34Mb/s - POAM F5 End BEDC errors (0) - Received Cell Count = Result
High 15975 ATM 34Mb/s - POAM F5 End BEDC errors - Selected Cell Not Received detected 15976 ATM 34Mb/s - POAM F5 End BEDC errors (0) - Received Cell Count = Result Invalid 15977 ATM 34Mb/s - POAM F5 End BEDC errors (3) - Received Cell Count = Result Low 15978 ATM 34Mb/s - POAM F5 End BEDC errors (3) - Received Cell Count = Result
High 15979 ATM 34Mb/s - POAM F5 End BEDC errors (3) - Received Cell Count = Result
Invalid 15980 ATM 34Mb/s - POAM Cell loss errors - Signal Loss 15981 ATM 34Mb/s - POAM Cell loss errors - Loss of Cell Synchronisation 15982 ATM 34Mb/s - POAM Cell loss errors - Pattern Loss 15983 ATM 34Mb/s - POAM Cell loss errors - Result Low 15984 ATM 34Mb/s - POAM Cell loss errors - Result High 15985 ATM 34Mb/s - POAM Cell loss errors - Selected Cell Not Received detected 15986 ATM 34Mb/s - POAM Cell loss errors - Result Invalid 15987 ATM 34Mb/s - BEDC errors - Result Low 15988 ATM 34Mb/s - BEDC errors - Result High 15989 ATM 34Mb/s - BEDC errors - Result Invalid 15990 ATM 34Mb/s - POAM Cell misinsertion errors - Signal Loss 15991 ATM 34Mb/s - POAM Cell misinsertion errors - Loss of Cell Synchronisation 15992 ATM 34Mb/s - POAM Cell misinsertion errors - Pattern Loss 15993 ATM 34Mb/s - POAM Cell misinsertion errors - Result Low 15994 ATM 34Mb/s - POAM Cell misinsertion errors - Result High 15995 ATM 34Mb/s - POAM Cell misinsertion errors - Selected Cell Not Received
55
Self Test Error Codes
Self Test Error Codes
detected 15996 ATM 34Mb/s - POAM Cell misinsertion errors - Result Invalid 15997 ATM 34Mb/s - BEDC errors - Result Low 15998 ATM 34Mb/s - BEDC errors - Result High 15999 ATM 34Mb/s - BEDC errors - Result Invalid 16200 Locked during jitter mask sweep and auto tolerance 18003 SPDH DS3 - FAS error add = 1.0E-3 Result low 18004 SPDH DS3 - FAS error add = 1.0E-3 Result high 18006 SPDH DS3 - FAS error add = 1.0E-3 Result Invalid 18013 SPDH DS3 - BIT error add = OFF Result low 18014 SPDH DS3 - BIT error add = OFF Result high 18016 SPDH DS3 - BIT error add = OFF Result Invalid 18023 SPDH DS3 - BIT error add = SINGLE Result low 18024 SPDH DS3 - BIT error add = SINGLE Result high 18026 SPDH DS3 - BIT error add = SINGLE Result Invalid 18033 SPDH DS3 - BIT error add = 1.0E-3 Result low 18034 SPDH DS3 - BIT error add = 1.0E-3 Result high 18036 SPDH DS3 - BIT error add = 1.0E-3 Result Invalid 18043 SPDH DS1 - FAS (D4) error add = OFF Result low 18044 SPDH DS1 - FAS (D4) error add = OFF Result high 18046 SPDH DS1 - FAS (D4) error add = OFF Result Invalid 18053 SPDH DS1 - FAS (D4) error add = SINGLE Result low 18054 SPDH DS1 - FAS (D4) error add = SINGLE Result high 18056 SPDH DS1 - FAS (D4) error add = SINGLE Result Invalid 18063 SPDH DS1 - FAS (D4) error add = 1.0E-3 Result low 18064 SPDH DS1 - FAS (D4) error add = 1.0E-3 Result high 18066 SPDH DS1 - FAS (D4) error add = 1.0E-3 Result Invalid 18073 SPDH DS1 - BIT error add = OFF Result low 18074 SPDH DS1 - BIT error add = OFF Result high 18076 SPDH DS1 - BIT error add = OFF Result Invalid 18083 SPDH DS1 - BIT error add = SINGLE Result low 18084 SPDH DS1 - BIT error add = SINGLE Result high 18086 SPDH DS1 - BIT error add = SINGLE Result Invalid 18093 SPDH DS1 - BIT error add = 1.0E-3 Result low 18094 SPDH DS1 - BIT error add = 1.0E-3 Result high 18096 SPDH DS1 - BIT error add = 1.0E-3 Result Invalid 18103 SPDH DS1 - FAS (SLC96) error add = OFF Result low 18104 SPDH DS1 - FAS (SLC96) error add = OFF Result high 18106 SPDH DS1 - FAS (SLC96) error add = OFF Result Invalid 18113 SPDH DS1 - FAS (SLC96) error add = SINGLE Result low 18114 SPDH DS1 - FAS (SLC96) error add = SINGLE Result high 18116 SPDH DS1 - FAS (SLC96) error add = SINGLE Result Invalid 18123 SPDH DS1 - FAS (SLC96) error add = 1.0E-3 Result low 18124 SPDH DS1 - FAS (SLC96) error add = 1.0E-3 Result high 18126 SPDH DS1 - FAS (SLC96) error add = 1.0E-3 Result Invalid 18137 SPDH DS3 Unframed - Loss Of Frame Detected
56
Self Test Error Codes
Self Test Error Codes
18146 SPDH DS3 M23 - Loss Of Frame Not Detected 18147 SPDH DS3 M23 - Loss Of Frame Detected 18156 SPDH DS3 C-BIT - Loss Of Frame Not Detected 18157 SPDH DS3 C-BIT - Loss Of Frame Detected 18167 SPDH DS1 Unframed - Loss Of Frame Detected 18176 SPDH DS1 D4 - Loss Of Frame Not Detected 18177 SPDH DS1 D4 - Loss Of Frame Detected 18186 SPDH DS1 ESF - Loss Of Frame Not Detected 18187 SPDH DS1 ESF - Loss Of Frame Detected 18196 SPDH DS1 SLC96 - Loss Of Frame Not Detected 18197 SPDH DS1 SLC96 - Loss Of Frame Detected 18206 SPDH DS1 DROP from DS3 - Loss Of Frame Not Detected 18207 SPDH DS1 DROP from DS3 - Loss Of Frame Detected 18211 SPDH DS3 struct 64 kb/s - Pattern Loss 18214 SPDH DS3 struct 64 kb/s - Pattern Errors Present 18221 SPDH DS3 struct Nx64 kb/s (odd channels) - Pattern Loss 18224 SPDH DS3 struct Nx64 kb/s (odd channels) - Pattern Errors Present 18231 SPDH DS3 struct DS1 - Pattern Loss 18234 SPDH DS3 struct DS1 - Pattern Errors Present 18241 SPDH DS3 struct 56 kb/s - Pattern Loss 18244 SPDH DS3 struct 56 kb/s - Pattern Errors Present 18251 SPDH DS3 struct Nx56 kb/s (odd channels) - Pattern Loss 18254 SPDH DS3 struct Nx56 kb/s (odd channels) - Pattern Errors Present 18261 SPDH DS3 struct Nx56 kb/s (even channels) - Pattern Loss 18264 SPDH DS3 struct Nx56 kb/s (even channels) - Pattern Errors Present 18271 SPDH DS1 struct 64 kb/s - Pattern Loss 18274 SPDH DS1 struct 64 kb/s - Pattern Errors Present 18281 SPDH DS1 struct Nx64 kb/s (odd channels) - Pattern Loss 18284 SPDH DS1 struct Nx64 kb/s (odd channels) - Pattern Errors Present 18291 SPDH DS1 struct 56 kb/s - Pattern Loss 18294 SPDH DS1 struct 56 kb/s - Pattern Errors Present 18301 SPDH DS1 struct Nx56 kb/s (even channels) - Pattern Loss 18304 SPDH DS1 struct Nx56 kb/s (even channels) - Pattern Errors Present 18311 SPDH DS3 Unframed - PRBS(9) INV Pattern Loss 18314 SPDH DS3 Unframed - PRBS(9) INV Pattern Errors Present 18321 SPDH DS3 Unframed - PRBS(20) NON-INV Pattern Loss 18324 SPDH DS3 Unframed - PRBS(20) NON-INV Pattern Errors Present 18331 SPDH DS3 Unframed - PRBS(15) INV Pattern Loss 18334 SPDH DS3 Unframed - PRBS(15) INV Pattern Errors Present 18341 SPDH DS3 Unframed - PRBS(23) NON-INV Pattern Loss 18344 SPDH DS3 Unframed - PRBS(23) NON-INV Pattern Errors Present 18351 SPDH DS3 Unframed - User Word Pattern Loss 18354 SPDH DS3 Unframed - User Word Pattern Errors Present 18361 SPDH DS1 Unframed - PRBS(9) NON-INV Pattern Loss 18364 SPDH DS1 Unframed - PRBS(9) NON-INV Pattern Errors Present 18371 SPDH DS1 Unframed - PRBS(11) INV Pattern Loss
57
Self Test Error Codes
Self Test Error Codes
18374 SPDH DS1 Unframed - PRBS(11) INV Pattern Errors Present 18381 SPDH DS1 Unframed - QRSS Pattern Loss 18384 SPDH DS1 Unframed - QRSS Pattern Errors Present 18391 SPDH DS1 Unframed - PRBS(23) INV Pattern Loss 18394 SPDH DS1 Unframed - PRBS(23) INV Pattern Errors Present 18401 SPDH DS1 Unframed - User Word Pattern Loss 18404 SPDH DS1 Unframed - User Word Pattern Errors Present 18411 SPDH DS3 struct DS1 insert/drop - Insert Port Not Settled 18414 SPDH DS3 struct DS1 insert/drop - Drop Port Not Settled 18421 SPDH DS3 struct 56 kb/s delay = 0s - Result Invalid 18422 SPDH DS3 struct 56 kb/s delay = 0s - Timeout 18423 SPDH DS3 struct 56 kb/s delay = 0s - Result low 18424 SPDH DS3 struct 56 kb/s delay = 0s - Result high 18431 SPDH DS3 struct 56 kb/s delay = 2s - Result Invalid 18432 SPDH DS3 struct 56 kb/s delay = 2s - Timeout 18433 SPDH DS3 struct 56 kb/s delay = 2s - Result low 18434 SPDH DS3 struct 56 kb/s delay = 2s - Result high 18441 SPDH DS1 struct 56 kb/s delay = 0s - Result Invalid 18442 SPDH DS1 struct 56 kb/s delay = 0s - Timeout 18443 SPDH DS1 struct 56 kb/s delay = 0s - Result low 18444 SPDH DS1 struct 56 kb/s delay = 0s - Result high 18451 SPDH DS1 struct 56 kb/s delay = 2s - Result Invalid 18452 SPDH DS1 struct 56 kb/s delay = 2s - Timeout 18453 SPDH DS1 struct 56 kb/s delay = 2s - Result low 18454 SPDH DS1 struct 56 kb/s delay = 2s - Result high 22001 "STM-1 TU-12 DS-1 F/G Patt: Unframed shows PSL 22002 "STM-1 TU-12 DS-1 B/G Patt: Expected D4 framing shows PSL 22011 "STM-1 TU-12 DS-1 F/G Patt: Expected ESF framing shows PSL 22012 "STM-1 TU-12 DS-1 B/G Patt: Expected D4 framing shows PSL 22021 "STM-1 AU-4 Pattern Sync Loss 22025 "STM-1 AU-4 Service Disruption : Short Burst <> 0 ms 22026 "STM-1 AU-4 Service Disruption : Long Burst <> 0 ms 22027 "STM-1 AU-4 Service Disruption : Last Burst <> 0 ms 22031 "STM-1 AU-4 Pattern Sync Loss 22035 "STM-1 AU-4 Service Disruption : Short Burst <> 0 ms 22036 "STM-1 AU-4 Service Disruption : Long Burst not OVERRANGE 22037 "STM-1 AU-4 Service Disruption : Last Burst not OVERRANGE 22041 "STM-1 AU-4 Pattern Sync Loss 22045 "STM-1 AU-4 Service Disruption : Short Burst <0ms or >2000ms 22046 "STM-1 AU-4 Service Disruption : Long Burst <> Short Burst 22047 "STM-1 AU-4 Service Disruption : Last Burst <> Short Burst 22051 "STM-0 Signal Loss 22061 "STM-0 Pattern Sync Loss 22064 "STM-0 Bit Errors 22071 "STM-0 Signal Loss 22081 "STM-0 AU-3 Pattern Sync loss (TX Pulse HI, RX HI)
58
Self Test Error Codes
Self Test Error Codes
22084 "STM-0 AU-3 Bit Errors (TX Pulse = HI, RX Pulse = HI) 22091 "STM-0 AU-3 Pattern Sync loss (TX Pulse LO, RX LO) 22094 "STM-0 AU-3 Bit Errors (TX Pulse = LO, RX Pulse = LO) 22101 "STM-0 AU-3 Pattern Sync loss (TX Pulse XCON, RX HI) 22104 "STM-0 AU-3 Bit Errors (TX Pulse = XCON, RX Pulse = HI) 22111 "STM-0 Signal Loss 22113 "STM-0 No offset - Frequency low 22114 "STM-0 No offset - Frequency high 22121 "STM-0 AU-3 Bulk TX, AU-3 Unfrm RX: Fail to get PSL 22122 "STM-0 AU-3 Bulk: Pattern Sync Loss 22131 "STM-0 TU-2 TX, AU-3 Unfrm RX : Fail to get PSL 22132 "STM-0 TU-2: Pattern Sync Loss 22141 "STM-0 DS-1 Unfrmd TX, AU-3 Unfrm RX: Fail to get PSL 22142 "STM-0 DS-1 Unfrmd: Pattern Sync Loss 22151 "STM-0 Frame or Pointer Sync Loss 22153 "STM-0 B1 BIP Errors low 22154 "STM-0 B1 BIP Errors high 22161 "STM-0 Frame or Pointer Sync Loss 22163 "STM-0 B2 BIP Errors low 22164 "STM-0 B2 BIP Errors high 22171 "STM-0 Frame or Pointer Sync Loss 22173 "STM-0 B3 BIP Errors low 22174 "STM-0 B3 BIP Errors high 22181 "STM-0 Frame or Pointer Sync Loss 22183 "STM-0 (M1) MS-REI Errors low 22184 "STM-0 (M1) MS-REI Errors high 22191 "STM-0 Frame or Pointer Sync Loss 22193 "STM-0 (Z5) AU-3 HP-IEC Errors low 22194 "STM-0 (Z5) AU-3 HP-IEC Errors high 22201 "STM-0 34M +100ppm Pattern Sync loss 22203 "STM-0 34M +100ppm Bit Errors low 22204 "STM-0 34M +100ppm Bit Errors high 22211 "STM-0 34M -100ppm Pattern Sync loss 22213 "STM-0 34M -100ppm Bit Errors low 22214 "STM-0 34M -100ppm Bit Errors high 22221 "STM-0 DS-3 +100ppm Pattern Sync loss 22223 "STM-0 DS-3 +100ppm Bit Errors low 22224 "STM-0 DS-3 +100ppm Bit Errors high 22231 "STM-0 C-3 Bulk -100ppm Pattern Sync loss 22233 "STM-0 C-3 Bulk -100ppm Bit Errors low 22234 "STM-0 C-3 Bulk -100ppm Bit Errors high 22251 STM-1 TU11 Async, Frame or Pointer Sync Loss 22264 STM-1 TU11 Async, B1 BIP Errors 22274 STM-1 TU11 Async, B2 BIP Errors 22284 STM-1 TU11 Async, B3 BIP Errors 22294 STM-1 TU11 Async, HP-REI Errors
59
Self Test Error Codes
Self Test Error Codes
22304 STM-1 TU11 Async, VC-11 V5 BIP Errors 22314 STM-1 TU11 Async, VC-11 V5 LP-REI Errors 22321 STM-1 Frame or Pointer Sync Loss 22323 STM-1 VC-11 V5 BIP Error Rate Low 22324 STM-1 VC-11 V5 BIP Error Rate High 22331 STM-1 Frame or Pointer Sync Loss 22333 STM-1 VC-11 V5 LP-REI Error Rate Low 22334 STM-1 VC-11 V5 LP-REI Error Rate High 22341 STM-1 TU11 Async, Pattern Sync Loss 22343 STM-1 TU11 Async, Bit Errors Low 22344 STM-1 TU11 Async, Bit Errors High 22351 STM-1 TU11 Background Pattern same as Test Pattern 22361 STM-1 TU11 Background Pattern Failure 22371 STM-1 TU11 Freq Off Ptr Mvts: Frame Sync Loss 22381 STM-1 TU11 Freq Off Ptr Mvts: Pointer Sync Loss 22394 STM-1 TU11 Freq Off Ptr Mvts: B1 BIP Errors 22404 STM-1 TU11 Freq Off Ptr Mvts: B2 BIP Errors 22414 STM-1 TU11 Freq Off Ptr Mvts: B3 BIP Errors 22424 STM-1 TU11 Freq Off Ptr Mvts: TU BIP Errors 22433 STM-1 TU11 Freq Off Ptr Mvts: +100ppm, Imp VC Offset Low 22434 STM-1 TU11 Freq Off Ptr Mvts: +100ppm, Imp VC Offset High 22443 STM-1 TU11 Freq Off Ptr Mvts: -100ppm, Imp VC Offset Low 22444 STM-1 TU11 Freq Off Ptr Mvts: -100ppm, Imp VC Offset High 22455 STM-1 Mixed TU3/TU11 TUG3#2 Background TU-11 shows TU-AIS 22456 STM-1 Mixed TU3/TU11 TUG3#2 Background TU-11 shows LP-RDI 22457 STM-1 Mixed TU3/TU11 TUG3#2 Background TU-11 shows TU-LOP 22461 STM-1 Mixed TU3/TU11 TUG3#1 Foreground TU-3 shows PSL 22471 STM-1 Mixed TU3/TU11 TUG3#3 Background TU-3 shows PSL 22485 STM-1 Mixed TU3/TU11 TUG3#1 Background TU-3 shows TU-AIS 22486 STM-1 Mixed TU3/TU11 TUG3#1 Background TU-3 shows LP-RDI 22487 STM-1 Mixed TU3/TU11 TUG3#1 Background TU-3 shows TU-LOP 22491 STM-1 Mixed TU3/TU11 TUG3#2 Foreground TU-11 shows PSL 22501 STM-1 Mixed TU3/TU11 TUG3#3 Background TU-11 shows PSL 22511 STM-1 TU-11 DS-1 F/G Patt: Unframed shows PSL 22512 STM-1 TU-11 DS-1 B/G Patt: Expected D4 framing shows PSL 22521 STM-1 TU-11 DS-1 F/G Patt: Expected ESF framing shows PSL 22522 STM-1 TU-11 DS-1 B/G Patt: Expected D4 framing shows PSL 22531 STM-1 AU-3 J1 message failure 22541 STM-1 TU-2 Pattern Sync loss 22543 STM-1 TU-2 Bit Errors low 22544 STM-1 TU-2 Bit Errors high 22551 STM-1 TU-12 Fl Byte Sync, Pattern Sync loss 22553 STM-1 TU-12 Fl Byte Sync, Bit Errors low 22554 STM-1 TU-12 Fl Byte Sync, Bit Errors high 22561 STM-1 TU-11 Pattern Sync loss 22563 STM-1 TU-11 Bit Errors low
60
Self Test Error Codes
Self Test Error Codes
22564 STM-1 TU-11 Bit Errors high 22571 STM-1 AU-3 34 Mb/s PRBS 23 Pattern Sync Loss 22573 STM-1 AU-3 34 Mb/s PRBS 23 Bit Errors Low 22574 STM-1 AU-3 34 Mb/s PRBS 23 Bit Errors High 22581 STM-1 AU-3 TU-2 Bulk PRBS 15 Pattern Sync Loss 22583 STM-1 AU-3 TU-2 Bulk PRBS 15 Bit Errors Low 22584 STM-1 AU-3 TU-2 Bulk PRBS 15 Bit Errors High 22591 STM-1 AU-3 TU-12 Fl Byte Word Pattern Sync Loss 22593 STM-1 AU-3 TU-12 Fl Byte Word Bit Errors Low 22594 STM-1 AU-3 TU-12 Fl Byte Word Bit Errors High 22601 STM-1 AU-3 TU-11 Async PRBS 9 Pattern Sync Loss 22603 STM-1 AU-3 TU-11 Async PRBS 9 Bit Errors Low 22604 STM-1 AU-3 TU-11 Async PRBS 9 Bit Errors High
61
Self Test Error Codes
Self Test Error Codes
