AGFA ACTIONCAM User Guide

ACTIONCAM

Owner’s Guide

Trademarks

ACTIONCAM, FotoTune and FotoFlavor are trademarks of Agfa­Gevaert, NV.

Adobe is a trademark of Adobe Systems Inc., registered in the US.
Adobe Photoshop and Adobe Acrobat are trademarks of Adobe
Systems Inc.

Apple and Macintosh are registered trademarks of Apple Computer
Inc., registered in the US and other countries.

IBM is a registered trademarks of International Business Machines
Corporation.

Ulead, Ulead PhotoImpact and Ulead ImagePals are trademarks of
Ulead Systems Inc.

Microsoft, MS, MS-DOS, Windows and Windows 95 are either
registered trademarks or trademarks of Microsoft Corporation.

Adaptec, AHA, AVA and EZ-SCSI are trademarks of Adaptec, Inc.
which may be registered in some jurisdictions.

Color It! is a trademark of Microfrontier, Inc.
Other product or company names are trademarks or registered

trademarks of their respective holders.

Copyright © 1996
Agfa-Gevaert N.V.
Septestraat 27
B-2640 Mortsel

All rights reserved.

All software and hardware described in this document are subject to
change without any notice.

Safety regulations

IMPORTANT SAFETY INSTRUCTIONS

When using this digital camera and/or its accessories, basic safety
precautions should always be followed, including:

■ Read and understand all instructions.

■ Supervise closely when any digital camera or accessory is

used by or near children. Do not leave units unattended while
in use, or within the reach of children.

■ Do not connect power sources other than those specified in

the manual.

■ Do not operate the digital camera and or accessories if

dropped, damaged, or with a damaged cord, until examined
by an authorised Agfa Dealer.

■ To avoid electic shocks, do not immerse flash and/or

accessories in water or other liquids.

■ To reduce the risk of electric shocks, do not disassemble the

digital camera and/or accessories. Take them to an authorised
Agfa Dealer whenever service or repair is required. Incorrect
reassembly can cause electric shocks the next time the unit is
used.

SAVE THESE INSTRUCTIONS

CAUTION

Danger of explosion if battery is incorrectly installed.
Replace only with the same, or equivalent type, battery recommended

by AGFA.
Dispose of used batteries according to the instructions on the battery.

CE Marking (Declaration of
Conformity)

We declare under sole responsibility that the Camera and options to
which this declaration relates is in conformity with the below
specifications.

This declaration is valid for the area European Union (EU) only.

Product Type: Digital Camera
Product Name: ActionCam
Options: Flash 5400HS, Objectiv AF24-85, AC Power

Adaptor AC-M515

EMC: EN 55022 (Class B) / 1987

(Limits and method for measurement of radio
distubence characteristics of informatiotechnology
equipment (ITE)
EN 61000-3-2 (Limits for harmonic current
emissions)
EN 61000-3-2 (Limits vor voltage fluctuations)
EN 55082-1 / 1992
(Electromagnetic compability - Generic immunity
standard Part 1: Residential, commercial and light
industry)
IEC 801-2 / 1991 (Electrostatic discharge
requirement)
IEC 801-3 / 1984 (Radiated electromagnetic field
requirement)
IEC 801-4 / 1994 (Electrical fast transient / burst
requirement)

Safety: EN 60950 / 1992 and Amendment 1 / 1993

(Safety of information technology equipment,
including electrical business equipment)

EC Directives

EMC: 89 / 336 / EEC and 93 / 68 EEC art. 5
Safety: 73 / 23 / EEC and 93 / 68 EEC art. 13

This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

■ Reorient or relocate the receiving antenna.

■ Increase the distance between the equipment and the receiver.

■ Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

■ Consult the dealer or an experienced radio/TV technician for help.

This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus as set out in the Interference­causing equipment standard entitled “Digital Apparatus”, ICES-003 of
the Department of Communications.

Preface

Thank you for purchasing the AGFA ACTIONCAM Digital Camera.
Please take the time to read through this owner's guide, for it contains
information that is important for the proper and safe use and care of
your camera. Enjoy!

The AGFA ACTIONCAM is a compact digital camera with the
following features:

• The ACTIONCAM digital camera uses three CCD imaging arrays and
a unique signal processing technique that allow it to photograph
extremely high resolution images, up to 1.75 million pixels per image.

• The design of the ACTIONCAM digital camera is based on the
Minolta MAXUM400si SUPER (VS) or the DYNAX 500 (Europe), and
uses the same high performance autofocus and exposure systems. The
ACTIONCAM can also use lenses, flashes, and other accessories
designed for use with MAXUM 400si SUPER (DYNAX 500).

• The ACTIONCAM digital camera is equipped with a SCSI-2
interface, and can be connected directly to your MACINTOSH, IBM PC,
or IBM PC compatible personal computer.

• The ACTIONCAM digital camera is packaged with the ACTIONCAM
SA driver, and the Adobe Photoshop™ plug-in software for MAC and
ActionCam Twain interface for PC that allow you to display your
images on your personal computer.

July 1996
Agfa-Gevaert N.V.
Septestraat 27
B-2640 Mortsel

Introduction

Welcome

For proper and Safe use

STANDARD SYMBOLS
Various symbols are used throughout this owner's guide, and the

product itself, for the proper and safe use of this product and to
prevent personal injury, injury to others, and property damage. An
explanation of the symbols follows. Read and understand each
caution thoroughly before reading the main text of this owner's guide.

Disregarding this warning may result in injury or death.

WARNING

Disregarding this caution may result in injury or
property damage.

CAUTION

EXAMPLES

The outer triangle is for warning. The symbol inside
illustrates what is being warned against. The example at
left means beware of electric shock.

The circle with a diagonal slash is for prohibition (don’t
do). The symbol inside illustrates what act is prohibited.
The example at left means do not disassemble.

The black circle indicates something you must do. The
circle inside illustrates how it should be done. The
example at left means you must hold the plug when
removing it from the outlet.

for proper and save use

Safety cautions for use of the
ACTIONCAM digital camera

Do not touch the flashtube during operation - it may
become hot when the flash fires.

Do not look directly at the sun through the lens

WARNING

CAUTION

or viewfinder.

Do not subject the camera to direct sunlight. Fire
may occur if the sunlight focuses at one point.

Do not fire the flash near the eyes of people or animals,
especially infants and young children. Maintain a distance
of one meter (three feet ) or greater.

If the camera is dropped or subjected to an impact in
which the interior is exposed, immediately remove
the batteries and discontinue use.

Do not disassemble. Call an AGFA dealer when
repairs are required.

Electric shock may occur if a high voltage circuit
inside the camera is touched.

Introduction

Don’t walk while looking through the lens or viewfinder,
you may trip and fall causing injury.

Read and follow all warnings supplied with the batteries.
Batteries may explode due to improper use.

Do not install batteries upside down (± reversed).
Do not use batteries with visible damage.

CAUTION

WARNING

CAUTION

Do not subject batteries to fire or high
temperatures.

Do not attempt to recharge, short, or disassemble.

Carefully observe the following warnings when using this product
near young children or persons who may have a difficulty percieving
the potential danger associated with these products.

Use caution. Always keep out of reach when not in use.
If caution is not used, the following accidents, and others,

may occur:

■ Flash fired near the eye.

■ Fingers caught in a running motor.

■ Strap wound around the neck.

YOUNG CHILDREN MAY SWALLOW SMALL OBJECTS
Keep small accessories, or things that could be swallowed,

away from young children.
Contact a doctor immediately if an object is swallowed.

BATTERY

CAUTION

YOUNG CHILDREN MAY SWALLOW BATTERIES
Keep batteries away from young children.

SAFETY CAUTIONS FOR USE OF THE AC POWER ADAPTER AC­M515

WARNING

Use only the indicated voltage.

Do not place a container of water or other liquid on the
product. If water or other liquid gets inside the product, it
may cause a short resulting in fire or electric shock.
Immediately unplug, discontinue use, and contact an
AGFA dealer.

Keep plug clean of dust and dirt. Insert plug
completely into the electrical outlet.

Do not use extension cords, or multiple cord
adapters. Insert plug directly into wall outlet.

Do not misuse the power cord. Damage to the cord may
result in fire or electric shock.

Do not perform any of the following acts to the cord:

• Scratch • Modify • Cut cord or replace plug

• Twist • Bend • Place a heavy object on

• Pull • Heat

Do not place unit in a dusty or humid area.

WARNING

If there is smoke, a strange smell, or any other unusual
conditions, immediately unplug unit, discontinue use, and
contact an AGFA dealer.

CAUTION

Grasp the plug when removing the cord from an
outlet. Pulling the cord may damage it resulting in
fire or electric shock.

Never pull the plug if your hands
are wet, or if you are standing in
water.

Do not attempt to disassemble this product; it contains
high-voltage circuits. For repairs, contact an AGFA
dealer.

Disconnect the AC adapter when
it is not in use.

SAFETY CAUTIONS FOR THE LITHIUM ION BATTERY

1 Use only the battery charger specified for this unit.
2 Never heat the battery or expose it to fire. Do not disassemble or

modify the battery. Do not intentionally or unintentionally short
circuit the battery terminals.

3 Do not leave the battery in hot places, such as inside a car, or in
direct sunlight. Exposure to temperatures over 60°C (140°F) may cause
damage.

4 Do not drop the battery or subject it to mechanical shocks.
5 Use the battery only in the specified apparatus.

1 Do not put the battery in a microwave oven or clothes dryer.
2 Stop using, or charging, battery if there is smoke, a strange

smell, or any change of color or shape.

If the battery leaks liquid, or there is a strange smell, keep battery away
from heat or open flame.

If liquid from inside the battery gets into the eyes, flush with water and
consult a physician immediately.

HANDLING CAUTIONS FOR THE ACTIONCAM

BATTERY CAUTIONS

• When photographing in cold weather, we recommend that you
keep
the camera and spare batteries inside your coat to keep them warm
when you are not shooting. Cold batteries will regain some of their
charge when they warm up.

• The low battery symbol may appear even with a fresh battery
depending on the storage conditions. To restore camera power, repeat
turning the camera on and off.

ENVIRONMENTAL REQUIREMENTS

• This digital camera is designed for use from 0° to 50°C (-4° to
122°F).

• Never leave the digital camera where it may be subjected to
extreme temperatures such as the glove compartment of a car.

• At colder temperatures, the data panel response time will be slow;
at higher temperatures, the display will temporarily darken, but will
restore when the temperature normalizes.

• Never subject the digital camera to extreme humidity.

• To prevent condensation from forming, place the digital camera in
a sealed plastic bag when bringing it from the cold exterior to a warm
building. Allow it to come to room temperature before removing it
from the bag.

HANDLING CARE

• This digital camera is not waterproof, dustproof, or sand proof.
Take care when using at the beach or near water - costly or
irreparable damage to the camera may occur.

• Do not touch the lithium-ion battery contacts on the digital camera.
The lithium-ion battery contacts can be seen when the lithium-ion
battery case is removed.

HANDLING INSTRUCTIONS FOR THE NP500H LITHIUM ION BATTERY
PROHIBITIONS FOR HANDLING OF LITHIUM ION BATTERIES

• Never heat the battery or expose it to fire.

• Do not disassemble or modify the battery.

• Do not leave the battery in hot places, such as inside a car or in
direct sunlight. Temperatures over 60° C (140° F) may cause damage.

• Do not allow necklaces, chains, or other metal items to come in
contact with the battery’s + and - terminals, as this could lead to
excessive heat, fire, or explosion of the battery.

• Do not allow the battery to come in contact with water. Never use
a wet battery.

• Do not drop the battery, or subject it to mechanical shocks.

• Do not directly solder the battery.
CHARGING

• Use only the battery charger specified.

• Be sure that the battery terminals are correctly aligned before
recharging.

• Perform the charging within the temperature range of 0°C to +
45°C (0°F to 113°F).

DISCHARGING

• Do not use the battery in devices not designed for its use.

• Avoid discharging the battery below 2.5V. Never discharge the
battery below 1.0V.

• Perform discharging within a temperature range of 0°C to 60°C.
STORAGE

• For long term storage, discharge the battery before storing.

• Store in a cool and dry place. In particular, avoid leaving the
battery in high temperature areas.

HANDLING CAUTIONS FOR THE CONVERTER AC-M515
ENVIRONMENTAL REQUIREMENTS

• This AC converter is designed for use from 0° to 40°C (32° to
104°F).

• Do not leave the AC converter where it may be subjected to
extreme temperatures, such as the glove compartment of a car.

• Do not subject the AC converter to extreme humidity.

• To prevent condensation from forming, place the AC converter in a
sealed plastic bag when bringing it from the cold exterior to a warm
building. Allow it to come to room temperature before removing it
from the bag.

HANDLING CARE

• The AC converter is not waterproof, dustproof, or sand proof; take
care when using at the beach or near water - costly or irreparable
damage to the camera may occur.

Before you begin

Before you begin, check the packing list . If some of the parts are
missing, contact the nearest AGFA dealer.

• Digital Camera ACTIONCAM body

• Minolta zoomlens

• AC power adapter AC-M515

• DC power cord

• Lithium ion battery NP-500H

• Lithium battery 2CR5

• AGFA ACTIONCAM DIGITAL FILM Card (PC Card)

• Holding Strap HS-700

• SCSI Cable

• Digital Camera ACTIONCAM CD

• Adobe Photoshop LE 3.0 CD package

• License Agreement document

• Quick Start Card MAC and PC

• Digital Camera ACTIONCAM Owner's Guide

• Digital Camera ACTIONCAM Software Guide

• Digital Camera ACTIONCAM Application Guide

• Fototune Cam manual + IT8 ColorTarget

• Warranty & Registration card

for MAC version only :

• CUMULUS Desktop CD package

for PC version only :

• ULEAD PhotoImpact CD package

• ADAPTEC AVA 1502P SCSI Host Adapter

Quick operation

1. Insert lithium battery into camera body
Insert one 6-volt 2CR5 lithium battery into the chamber as indicated

by the + and - marks on the inside of the battery cover.

2. Install lithium ion battery into digital back
Press the battery case release button and slide the battery case out.

Insert the NP-500H lithium ion battery as illustrated on the inside of
the battery case. Slide the battery case back into the camera until it
clicks.

3. Attach Lens
Align the red mounting index on the lens with the one on the camera.

Gently insert the lens into the mount and turn the lens clockwise until
it clicks into the locked position.

4. Insert AGFA ACTIONCAM Digital Film.
Open the slot/SCSI connector cover. Insert the PC card, as shown,

until the card stops.

5. Turn on power
Slide the main switch to ON. Wait until the frame counter displays

the number of remaining frames in the data panel.

6. Set Full-Auto mode
Press the program reset button to set the camera to fully automatic

mode.

7. Focus on subject
Align the subject within the focus frame and press the shutter-release

button partway down to activate the autofocus. The focus lock
indicator will glow when the subject is in focus.

8. Take the picture
Check that the standby lamp in the viewfinder is illuminated. Gently

press the shutter-release button all the way down to take the picture,
the way you want it.

Built-in Flash

Shutter-release button

Control dial

Lens contacts

Mirror

Names of parts -Camera body

Self-timer button

White balance window

Main switch
Mode button

Manual fill-
flash button

Exposure-
compensation button

Lens-release button

Slot/SCSI connector cover

PC terminalFocus mode button

Inside the slot/SCSI connector cover

Access lamp

PC card slot

Ejector lever
SCSI connector

Finder

WB/ASM mode switch

Accessory shoe

Flash node button

Program reset button

Data panel

Holding strap eyelet

Remote-control terminal

Battery case

Battery case release button

Aperture button

Bottom of the camera (after the Battery case has removed out)

Power input terminal

Clock battery chamber

Battery chamber

Tripod socket

Holding strap eyelet

Names of parts -Data panel

Shutter speed / SCSI ID number display

Wireless flash indicator

Red-eye reduction indicator

White balance indicators

SCSI mode indicatorTerminater power indicator

Exposure compensation indicator
Self timer indicator

Aperture display
Exposure mode indicators
Manual focus indicator

Battery condition indicators

Frame counter

Names of parts -Viewfinder Display

Focus frame Viewfinder frame

Standby lamp

Flash signal

Focus signal
