AER Amp Two Technical sheet

b a s s

solutions

amp two

advanced level

amp two is the second member of the Bottom Line com­bo bass amps. In line with Amp one, but with more de ned
speakersystem and more power. A 12“ neodymium louds­peaker for quick and full bass response combined with a 4“
mid-high loudspeaker for gentle trebles allows a wider ran­ge of sounds from funk to pop and rock to jazz.

• single channel bass combo

• 240 watts, dynamic control

• 12“ (300 mm) loudspeaker neodymium alloy mag­net plus

• 4“ (100 mm) mid-high loudspeaker

• compressor with adjustable ratio and threshold

• 23,50 kg (51.70 lbs)

Inputs

Input 6.3 mm (1/4”) input jack socket as high impedance

line input stage with pad (high/low attenution).

Tone Controls

equalizer three band EQ with parametric mids

colour ‘mid-cut-treble-boost’- lter

bass boost +10 dB / 55 Hz

tone balance the tone balance enables the bass- or treble emphasis

or a combination of both

e ect compressor with adjustable ratio and threshold

Power

power amp 240 W / 8 ohms, dynamic control

analog signal subsonic  lter, low distortion
processing RMS limiter

Two-Way-Speaker-System

12“ (300 mm) loudspeaker neodymium alloy magnet
4“ (100 mm) mid-high loudspeaker

Features

headphone output, line out pre/post master switcha
ble, sub out, footswitch (muting and e ect on/
o ), send, return, insert pre/post EQ, adjustable aux
in, tuner, adjustable hf level, adjustable pre/post EQ
DI-out, ground lift

Accessories

padded cover

Speci cations

cabinet 18 mm (0.70”)  nnish birch plywood

 nish waterbased acrylic, black spatter  nish

dimensions 500mm x 420 mm x 350 mm
(19.70“ x 16.50“ x 13.80“), HxWxD

weight 23,50 kg (51.70 lbs)
