AEM GM Injector Adapter User Manual

GM Injector Adapter Harness

User Manual

30-3805-00

THIS PRODUCT IS LEGAL IN CALIFORNIA FOR RACING VEHICLES ONLY

AND SHOULD NEVER BE USED ON PUBLIC HIGHWAYS.

AEM Performance Electronics

AEM Performance Electronics, 2205 126th Street Unit A, Hawthorne, CA 90250

Phone: [phone] Fax: [phone]

http://www.aemelectronics.com

Instruction Part Number: 10-3805-00

Document Build 6/11/2014

AEM Infinity Harness Manuals2

1Introduction

Several universal wiring harness options are available for Infinity products. They range
in complexity from simple plug and pin kits to complete engine harness assemblies that
include power distribution centers. Custom wiring harness projects should only be
undertaken by experienced harness builders. If in doubt, please contact AEM for
recommendations.

30-3805 Universal V8 harness system for Infinity-8/10 systems

The Infinity Universal V8 Harness system consists of a universal core harness and
optional application specific extensions. It was designed with flexibility in mind. The
harness system includes many features and it can be used in many different
applications.

30-3807 Universal V8 harness system for Infinity-6/8h systems

The Infinity Universal V8 Harness system consists of a universal core harness and
optional application specific extensions. It was designed with flexibility in mind. The
harness system includes many features and it can be used in many different
applications.

30-3705 Universal Mini Harness for Infinity-6/8h systems

This harness is intended to be used as a starting point by experienced harness builders.
It saves time by including basic power distribution features that can be expanded to suit
many application requirements. It allows the harness builder to populate the ECU
connector with only the features needed by the application.

30-3702 Infinity-8/10/12 Mini-harness

This harness is intended to be used as a starting point by experienced harness builders.
It saves time by including basic power distribution features that can be expanded to suit
many application requirements. It allows the harness builder to populate the ECU
connector with only the features needed by the application. Includes 100 96" pre­terminated leads.

30-3703 Infinity-8/10/12 Mini-harness

This harness is intended to be used as a starting point by experienced harness builders.
It saves time by including basic power distribution features that can be expanded to suit
many application requirements. It allows the harness builder to populate the ECU
connector with only the features needed by the application.

30-3701 Infinity-8/10/12 Plug & Pin Kit

Bare necessities to begin a custom wire harness design. Includes 73 and 56 pin Molex
MX123 harness connectors, terminals and sealing plugs, main relay and relay socket.

30-3704 Infinity-6/8h Plug & Pin Kit

Bare necessities to begin a custom wire harness design. Includes 80 pin Molex MX123
harness connector, terminals and sealing plugs, main relay and relay socket.

This manual is focused primarily on the universal V8 harness system components but it

© 2014 AEM Performance Electronics

3

can be used as a reference for any custom harness build based on the Infinity ECU.

Please read the entire User Manual prior to beginning any installation.

2Optional Extension Harnesses for Modular Harness System

Optional extension harnesses compatible with the 3805 V8 harness system are
available.

30-3805-00 GM Injector Adapter Harness

Adapter harness that mates EV1 style injectors in standard GM cylinder order (odd
cylinders on one bank, even cylinders on other) to 30-3805 Core Harness.

30-3805-01 Ford Injector Adapter Harness

Adapter harness that mates EV1 style injectors in standard Ford cylinder order
(cylinders 1-4 on one bank, cylinders 5-8 on other) to 30-3805 Core Harness.

30-3805-02 Single Channel Ignition Adapter Harness

Adapter harness that mates AEM Single Channel Coil Driver (30-2841) to 30-3805
Core Harness. Coil driver takes 5v falling edge ignition trigger signal from Infinity and
outputs a 12v rising edge signal. 12v rising edge signal can either be used to trigger an
inductive coil directly or trigger a single channel CDI box (MSD 6A, etc).

30-3805-03 VR Crank & VR Cam Adapter Harness

Adapter harness that mates variable reluctance (VR) crank and cam sensors to 30­3805 Core Harness. Legs to each sensor are 48” long.

30-3805-04 VR Crank & Hall Cam Adapter Harness

Adapter harness that mates variable reluctance (VR) crank sensor and Hall Effect cam
sensor to 30-3805 Core Harness. Legs to each sensor are 48” long.

30-3805-05 Hall Crank & VR Cam Adapter Harness

Adapter harness that mates Hall Effect crank sensor and variable reluctance (VR) cam
sensor to 30-3805 Core Harness. Legs to each sensor are 48” long.

30-3805-06 Hall Crank & Hall Cam Adapter Harness

Adapter harness that mates Hall Effect crank and cam sensors to 30-3805 Core
Harness. Legs to each sensor are 48” long.

30-3805-07 GM Stepper Idle Control Adapter Harness

Adapter harness that mates GM stepper idle control valve to 30-3805 Core Harness.
IAC connector is flat and meant for use with later model style control valves.

30-3805-08 Universal PWM Idle Control Adapter Harness

Flying lead to mate universal PWM idle control valve to 30-3805 Core Harness.
Connector to connect to control valve must be provided by end user.

30-3600 O2 Sensor Extension Harness

© 2014 AEM Performance Electronics

AEM Infinity Harness Manuals4

Extension harness to connect AEM UEGO Wideband O2 sensor to 6 pin Deutsch DTM
in Infinity Mini Harnesses (30-3702/3703).

30-3601 IP67 Comms Cable

USB Mini-B comms cable; 39” long with right angled connector and bayonet style lock.

30-3602 IP67 Logging Cable

USB A-to-A extension cable: 39” long with right angled connector and bayonet style
lock.

33805-00 Kit Contents

GM Injector Adapter Harness
User Instructions

© 2014 AEM Performance Electronics

43805-00 GM Injector Adapter Pinout

Branch labels are identified by

BOLD TEXT in this column

36-3805-00 GM Injector Adapter

C1

DT Plug, 12 Way

Pin

Wire

Color

Gauge

Destination

1

C1-1

YEL20C2-B

C1-2

BLK20C3-B

C1-3

BRN20C4-B

C1-4

BLU20C5-B

C1-5

RED20S1

C1-6

RED20S3

C1-7

RED20S2

C1-8

RED20S4

C1-9

VIO20C6-B

C1-10

GRY20C7-B

C1-11

ORG20C8-B

C1-12

GRN20C9-B

C2

2-Way F Metri-Pack 280.1

Pin

Wire

Color

Gauge

Destination

INJ1

1ARED20S1 B

YEL20C1-1

C3

2-Way F Metri-Pack 280.1

Pin

Wire

Color

Gauge

Destination

INJ2

1ARED20S2 B

BLK20C1-2

C4

2-Way F Metri-Pack 280.1

Pin

Wire

Color

Gauge

Destination

INJ3

1

5

© 2014 AEM Performance Electronics

AEM Infinity Harness Manuals6

A

RED20S1 B

BRN20C1-3

C5

2-Way F Metri-Pack 280.1

Pin

Wire

Color

Gauge

Destination

INJ4

1ARED20S2 B

BLU20C1-4

C6

2-Way F Metri-Pack 280.1

Pin

Wire

Color

Gauge

Destination

INJ5

1ARED20S3 B

VIO20C1-9

C7

2-Way F Metri-Pack 280.1

Pin

Wire

Color

Gauge

Destination

INJ6

1ARED20S4 B

GRY

20

C1-10

C8

2-Way F Metri-Pack 280.1

Pin

Wire

Color

Gauge

Destination

INJ7

1ARED20S3 B

ORG

20

C1-11

C9

2-Way F Metri-Pack 280.1

Pin

Wire

Color

Gauge

Destination

INJ8

1ARED20S4 B

GRN

20

C1-12

S1

SPLICE

© 2014 AEM Performance Electronics

7

Pin

Wire

Color

Gauge

Destination

1INRED20C1-5

OUT

RED20C2-A

OUT

RED20C4-A

S2

SPLICE

Pin

Wire

Color

Gauge

Destination

1INRED20C1-7

OUT

RED20C3-A

OUT

RED20C5-A

S3

SPLICE

Pin

Wire

Color

Gauge

Destination

1INRED20C1-6

OUT

RED20C6-A

OUT

RED20C8-A

S4

SPLICE

Pin

Wire

Color

Gauge

Destination

1

IN

RED20C1-8

OUT

RED20C7-A

OUT

RED20C9-A

© 2014 AEM Performance Electronics

AEM Infinity Harness Manuals8
