AEG-Electrolux Z350A User Manual

Enviro Steamer Hand Gun

Owner’s Guide

Household Type

350 Series

Part No. 70402

1999 Electrolux

(8/99) Printed in Italy

Cod. 5065101300

IMPORTANT

For any advice on your

cleaner, pleaser refer to your

local telephone directory for

your nearest Electrolux

Service Agent. If you reside

in the UK please contact the

Customer Care line

08706 055055

INDEX

Important Safeguards...................2

Service Information ...................... 4

Use & Assembly........................6-8

Maintaining...................................8

Problem Solving .........................10

Guarantee .................................. 11

IMPORTANT SAFEGUARDS

When using an electrical appliance, basic precautions should always be
followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS STEAM CLEANER .

Guarantee (for UK residents only)

This guarantee is in addition to your statutory and other legal rights.

This product is for household use only.

WARNING

To reduce the risk of fire, electric shock, or injury:

1 Do not use outdoors.

2 Do not leave steam cleaner when plugged in. Unplug the electrical cord when not

in use and before servicing.

3 Do not allow to be used as a toy. Close attention is necessary when used near

children, pets and plants.

4 Use only as described in this manual. Use only manufacturer’s recommended

accessories.

5 Do not use with damaged cord or plug. If steam cleaner is not working as it

should, has been dropped, damaged, left outdoors, or dropped into water, return it
to a service center before using.

6 Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull

cord around sharp edges or corners. Keep cord away from heated surfaces.
7 Do not use extension cords or outlets with inadequate current carrying capacity.
8 Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
9 Do not handle plug or steam cleaner with wet hands or operate without shoes.
10 Do not put any object into openings. Do not use with any opening blocked.
11 Store your steam cleaner indoors in a cool, dry area.
12 Keep your work area well lighted.
13

Never turn the appliance over or on its side when using steam. Never direct

steam towards people, animals, plants, and equipment with electrical

components, such as the interior of ovens.

14 Do not immerse the steam cleaner into water or other liquids. Always unplug the

power cord from the electrical socket when filling the steam cleaner.
15 Never put descaling, aromatic, alcoholic or detergent products into the

steam cleaner, as this may damage it or make it unsafe for use.
16 Do not operate without safety cap in place.

17 Before filling, proceed as follows: 1) unplug the power supply, 2) relieve

pressure by depressing steam delivery button, 3) allow steamer to cool down for

three minutes, 4) relieve any built up pressure again by depressing steam delivery

button, 5) slowly unscrew safety cap (see page 6, item 5) and wait 5 seconds

before removing.
18 Metal tips on nozzles will get hot during use. Do not touch hot surfaces.

Allow the attachments to cool down before replacing them while the appliance is

being used.
19 This appliance is intended for household use only.
20 Any repair work, including the replacement of the power cord must only be carried

out by an Authorized Electrolux Service technician because a special tool is

required. Call for nearest service location.

Electrolux products are carefully designed, manufactured, tested and inspected
and, in consequence, we undertake to replace or repair any part found to be defective
in material or workmanship, within one year of delivery to the original purchaser,
free of charge. You may be required to take the product to your nearest service
provider if the product requires attention during the first year.

There are certain conditions which may invalidate this guarantee:
a. It is dependent upon the appliance being correctly installed and used in

accordance with the Company’s instructions under normal domestic conditions
within the United Kingdom or the Republic of Ireland.

b. Service at all times must be carried out by an Electrolux Service Representative

or authorised agent.

c. The guarantee may be invalidated by unauthorised repair or modification of

the appliance.

d. You may be charged by Electrolux if you call for an engineer to resolve a problem

that we believe is covered in the instruction booklet.

The Company does not accept liability for defects arising from neglect, misuse or
accident.

Proof of the date of purchase will be required before service under guarantee is
provided. For further assistance call our customer care line on 08706 055055.

Important:

For future reference we suggest you record the following details here, and keep
the receipt with the handbook as proof of purchase.

Purchased from___________________________________________________

Date purchased_________________ Model no _________________________

2

SAVE THESE INSTRUCTIONS

BEFORE YOU START
CHECK THE VOLTAGE

First check the voltage shown on the data plate (see rear view) to make sure that the cleaner
is of the correct voltage for your electricity supply. If it is not, do not use the cleaner but refer
back to your dealer.

CONNECTING TO YOUR ELECTRICITY SUPPLY

Permanently connected to the cleaner is a mains supply (3-core) cable fitted with a non-rewirable plug
incorporating a 13A fuse. In the event of the fuse requiring replacement the fuse cover should be removed
using a small screwdriver. The old fuse MUST be replaced by a 13A ASTA approved BS1362 fuse or a
BSI approved fuse. The cover must be replaced before the plug is used again. In the event of loss of
the fuse cover, replacements can be obtained from your Electrolux dealer or Electrical Retailers and must
be of the same colour as indicated by the coloured insert on the base of the plug.
f difficulty is experienced in obtaining a replacement, contact Electrolux on 08706 055055.In no
circumstances must the plug be used without a correct fuse cover fitted.If the plug that is fitted
to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate plug
fitted.Remove the fuse from the cut off plug.
The cut off plug should then be disposed of to prevent the hazard of shocks in case it should be plugged
into a 13 amp socket in another part of your home.The wires in the mains cable of this appliance are
coloured in accordance with the following code: Blue: Neutral. Brown: Live. Green/Yellow: Earth.
As the colours of the wires in the mains cable of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must
be connected to the terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the
letter L orcoloured red.The wire which is coloured yellow and green must be connected to the terminal
which is marked with a letter E or coloured yellow and green.It is in your interest to ensure that the plug
is correctly attached to the mains cable. In case of doubt, have it done by a qualified electrician, as
Electrolux cannot regard the repair of faults on the plug connection as a service that can be given free
of charge under the terms of the guarantee.

(for UK residents only)

Yellow and

Fuse Cover

Green

13 Amp Fuse

Fuse

Blue

Brown

Cord Clamp

WARNING

If the mains supply cable becomes damaged during cleaning the following action should be
taken:

1. Switch off and remove the plug from the socket outlet.

2. Examine the mains supply cable for damage (only after removing the plug from the socket outlet).

3. If there is any sign of damage to the supply cable it MUST be renewed. The repair MUST be carried

out by Electrolux Service Staff or a similar qualified person.

4. NEVER use the machine with a damaged mains supply cable.
The wire which is coloured yellow and green must be connected to the terminal which is marked with

a letter E or coloured yellow and green.

Thermal Cut Off

This steam cleaner has a special thermostat that protects the cleaner in case of overheating. If
the cleaner suddenly shuts off, push the switch pedal once and unplug the cleaner. Check the
cleaner for a possible source of overheating such as no water in tank. If these conditions are
found, fix them and wait at least 30 minutes before attempting to use the cleaner. After the 30
minute period, plug the cleaner back in and turn on the switch. If the cleaner still does not heat
up, call Electrolux on 08706 055055 if you reside in the UK, otherwise contact your nearest
Service Agent.

3
