AEG-Electrolux SG254N11 User Manual

user manual

notice d'utilisation

benutzerinformation

istruzioni per l’uso

Freezer

Congélateur

Gefriergerät

Congelatore

SG254N11

2 electrolux

Electrolux. Thinking of you.

Share more of our thinking at www.electrolux.com

Contents

Safety information 2
Control panel 4
First use 6
Daily Use 6
Helpful Hints and Tips 7

Safety information

In the interest of your safety and to ensure
the correct use, before installing and first us­ing the appliance, read this user manual
carefully, including its hints and warnings. To
avoid unnecessary mistakes and accidents,
it is important to ensure that all people using
the appliance are thoroughly familiar with its
operation and safety features. Save these in­structions and make sure that they remain
with the appliance if it is moved or sold, so
that everyone using it through its life will be
properly informed on appliance use and safe­ty.
For the safety of life and property keep the
precautions of these user's instructions as
the manufacturer is not responsible for dam­ages caused by omission.

Children and vulnerable people safety

• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or in­struction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.

• Keep all packaging well away from chil­dren. There is risk of suffocation.

• If you are discarding the appliance pull the
plug out of the socket, cut the connection
cable (as close to the appliance as you
can) and remove the door to prevent play­ing children to suffer electric shock or to
close themselves into it.

• If this appliance featuring magnetic door
seals is to replace an older appliance hav­ing a spring lock (latch) on the door or lid,
be sure to make that spring lock unusable

Care and cleaning 7
What to do if… 8
Technical data 10
Installation 10
Environmental concerns 12

Subject to change without notice

before you discard the old appliance. This
will prevent it from becoming a death trap
for a child.

General safety

Caution! Keep ventilation openings

clear of obstruction.

• The appliance is intended for keeping
foodstuff and/or beverages in a normal
household as explained in this instruction
booklet.

• Do not use a mechanical device or any ar­tificial means to speed up the thawing
process.

• Do not use other electrical appliances
(such as ice cream makers) inside of re­frigerating appliances, unless they are ap­proved for this purpose by the manufac­turer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is con­tained within the refrigerant circuit of the
appliance, a natural gas with a high level of
environmental compatibility, which is nev­ertheless flammable.
During transportation and installation of
the appliance, be certain that none of the
components of the refrigerant circuit be­come damaged.
If the refrigerant circuit should become
damaged:
– avoid open flames and sources of igni-

tion

– thoroughly ventilate the room in which

the appliance is situated

• It is dangerous to alter the specifications or
modify this product in any way. Any dam­age to the cord may cause a short-circuit,
fire and/or electric shock.

electrolux 3

Warning! Any electrical component
(power cord, plug, compressor) must be
replaced by a certified service agent or
qualified service personnel.

1. Power cord must not be lengthened.

2. Make sure that the power plug is not
squashed or damaged by the back of
the appliance. A squashed or dam­aged power plug may overheat and
cause a fire.

3. Make sure that you can come to the
mains plug of the appliance.

4. Do not pull the mains cable.

5. If the power plug socket is loose, do
not insert the power plug. There is a
risk of electric shock or fire.

6. You must not operate the appliance
without the lamp cover

1)

of interior

lighting.

• This appliance is heavy. Care should be
taken when moving it.

• Do not remove nor touch items from the
freezer compartment if your hands are
damp/wet, as this could cause skin abra­sions or frost/freezer burns.

• Avoid prolonged exposure of the appli­ance to direct sunlight.

Daily Use

• Do not put hot pot on the plastic parts in
the appliance.

• Do not store flammable gas and liquid in
the appliance, because they may explode.

• Do not place food products directly
against the air outlet on the rear wall.

2)

• Frozen food must not be re-frozen once it
has been thawed out.

• Store pre-packed frozen food in accord­ance with the frozen food manufacturer's
instructions.

• Appliance's manufacturers storage rec­ommendations should be strictly adhered
to. Refer to relevant instructions.

• Do not place carbonated or fizzy drinks in
the freezer compartment as it creates
pressure on the container, which may
cause it to explode, resulting in damage to
the appliance.

• Ice lollies can cause frost burns if con­sumed straight from the appliance.

1) If the lamp cover is foreseen

2) If the appliance is Frost Free

3) If a water connection is foreseen

Care and cleaning

• Before maintenance, switch off the appli­ance and disconnect the mains plug from
the mains socket.

• Do not clean the appliance with metal ob­jects.

• Do not use sharp objects to remove frost
from the appliance. Use a plastic scraper.

• Never use a hair drier or other heating ap­pliances to speed up defrosting. Excessive
heat may damage the plastic interior, and
humidity could enter the electric system
making it live.

Installation
Important! For electrical connection

carefully follow the instructions given in
specific paragraphs.

• Unpack the appliance and check if there
are damages on it. Do not connect the ap­pliance if it is damaged. Report possible
damages immediately to the place you
bought it. In that case retain packing.

• It is advisable to wait at least four hours
before connecting the appliance to allow
the oil to flow back in the compressor.

• Adequate air circulation should be around
the appliance, lacking this leads to over­heating. To achieve sufficient ventilation
follow the instructions relevant to installa­tion.

• Wherever possible the back of the product
should be against a wall to avoid touching
or catching warm parts (compressor, con­denser) to prevent possible burn.

• The appliance must not be located close
to radiators or cookers.

• Make sure that the mains plug is accessi­ble after the installation of the appliance.

•

Connect to potable water supply only.

3)

Service

• Any electrical work required to do the serv­icing of the appliance should be carried out
by a qualified electrician or competent per­son.

• This product must be serviced by an au­thorized Service Centre, and only genuine
spare parts must be used.

4 electrolux

Environment Protection

This appliance does not contain gasses
which could damage the ozone layer, in
either its refrigerant circuit or insulation
materials. The appliance shall not be dis­carded together with the urban refuse
and rubbish. The insulation foam con­tains flammable gases: the appliance

shall be disposed according to the ap­plicable regulations to obtain from your
local authorities. Avoid damaging the
cooling unit, especially at the rear near
the heat exchanger. The materials used
on this appliance marked by the symbol

are recyclable.

Control panel

AC

BDE

A - Appliance button ON/OFF D - Function button
B - Temperature regulation button E - Confirmation button
C - Temperature and function indicator

Display

Temperature alarm Function timer is activated
Negative Temperature sign Drinks Chill is activated
Temperature Action Freeze is activated
Child Lock is activated Eco Mode is activated

Switching on

Insert the plug into the power outlet. If the
display is not illuminated, press button (A), to
start the appliance.
For optimal food storage select the Eco
Mode and the temperature is set to -18°C in
the freezer.

• Wait until the temperature reach -18°C,
before loading food into the freezer com­partment.

• To select a different temperature see
"Temperature regulation".

Switching off

The appliance is shut off by pressing button
(A) until a countdown from -3 -2 -1 is com­pleted.

Temperature regulation

The temperature may be changed by press­ing the button (B).
The current temperature setting flashes and
by pressing button (B) again the set temper­ature is possible to change in steps of one
degree.

electrolux 5

After some seconds the storage temperature
is shown again.
The selected-temperature will be reached
within 24 hours.

Important! At start up the displayed tem­perature don’t correspond with the set tem­perature until stabilized (within 24 hours).

Functions Menu

By activating the key (D) the functions menu
is operating. Each function could be con­firmed by pressing button (E). If there is no
confirmation after some seconds the display
will go out from the menu and return in nor­mal condition. The following functions are in­dicated:

Child Lock function
Eco Mode function
Action Freeze function
Drinks Chill function

Child Lock Function

The Child Lock function is activated by
pressing key (D) (several times if necessary)

until the corresponding icon appears

.
You must confirm the choice by pressing key
(E) within few seconds. You will hear the buz­zer and the icon remains lighted. In this con­dition any possible operation through the
keys does not cause any change as long as
this function is activated.
It is possible to de-activate the function at
any time by pressing key (D) until the corre­sponding icon will flash and then key (E).

Eco Mode Function

The Eco Mode function is activated by press­ing key D (several times if necessary) until the
corresponding icon appears

(or setting
the temperature at -18°C).
You must confirm the choice by pressing key
E within few seconds. You will hear the buz­zer and the icon remains lighted.
In this condition the chosen temperatures are
automatically set (-18°C), in the best condi­tions for storing food.
It is possible to de-activate the function at
any time by changing the selected tempera­ture in the compartment.

Action Freeze Function

To freeze fresh foods, press button (D) re­peatedly to access the Action Freeze func-

tion.
Confirm the selection by pressing button (E),
and you will hear the buzzer and the display
will show rotating lines.
To achieve maximum freezing capacity, allow
a pre-cooling period of 24 hours, before
placing the fresh food in the FAST FREEZE
compartment .
The freezing process takes 24 hours. During
this period do not put other foods in the
freezer.
This function stops automatically after 52
hours.
It is possible to deactivate the function at any
time by pressing button (D) until the corre­sponding icon will flash and then button (E).

Drinks Chill Function

The Drinks Chill function is to be used as a
safety warning when placing bottles in the
freezer compartment. It is activated by
pressing key (D) (several times if necessary)

until the corresponding icon appears

.
You must confirm the choice by pressing key
(E) within few seconds. You will hear the buz­zer and the icon remains lighted.
In this condition it operates a timer with a de­fault value of 30 min. and it could change
from 1 to 90 min., by pressing key (B) you
select the minutes needed.
At the end of the selected time there are the
following indications:

•

on the indicator

•

the icon

•

the icon

flashing

the symbol flashing

flashing

• sounding of an acoustic alarm until key (E)

is pressed
At this point bear in mind to remove the
drinks contained in the freezer compartment.
It is possible to deactivate the function at any
time by pressing key (D) until the correspond­ing icon will flash and then key (E).

Temperature alarm

Temperature increase in the freezer com­partment (for example due to an power fail­ure or door is open) is indicated by:

• flashing temperature

•

flashing icon

6 electrolux

• acoustic buzzer
When normal conditions are restored:

• the acoustic alarm will stop

• the temperature value continues to flash

• the Alarm icon continues to flash
When you press button (E) to deactivate the
alarm, the highest temperature reached in

First use

Cleaning the interior

Before using the appliance for the first time,
wash the interior and all internal accessories
with lukewarm water and some neutral soap
so as to remove the typical smell of a brand­new product, then dry thoroughly.

Daily Use

Use of the freezer compartment

The symbol
freezer is suitable for freezing fresh food and
for long term storage. The temperature may
be regulated between -15°C and -24°C. We
suggest setting the temperature to -18°C,
which is optimal for energy consumption and
frozen food storage.

Important! At start-up the displayed
temperature don't correspond with the set
temperature until stabilised (within 24 hours).

Difference between the temperature dis­played and temperature setting is normal.
Especially when:

• a new setting has recently been selected

• the door has been left open for a long time

• warm food has been placed in the com­partment.

Difference until 5°C inside the compartment
are quite normal.
During normal functioning the indicator
shows the warmest temperature inside the
compartment.

Storage of frozen food

When first starting-up or after a period out of
use, before putting the products in the com­partment let the appliance run at least 2
hours on the higher settings.
If large quantities of food are to be stored,
remove all drawers and baskets from appli-

means that the

the compartment appears on indicator
for some seconds.
Then it returns on the normal operation
showing the temperature of the selected
compartment.
During the alarm phase, the buzzer can be
switched off by pressing button (E).

Important! Do not use detergents or abra­sive powders, as these will damage the fin­ish.

ance and place food on cooling shelves to
obtain the best performance.

Warning! Make sure that foods do not
exceed the load limit stated on the side
of the upper section (where applicable)

Important! In the event of accidental
defrosting, for example due to a power
failure, if the power has been off for longer
that the value shown in the technical
characteristics chart under "rising time", the
defrosted food must be consumed quickly or
cooked immediately and then re-frozen (after
cooling).

Thawing

Deep-frozen or frozen food, prior to being
used, can be thawed in the refrigerator com­partment or at room temperature, depending
on the time available for this operation.
Small pieces may even be cooked still frozen,
directly from the freezer: in this case, cooking
will take longer.

Cold accumulators

The freezer contains at least one cold accu­mulator which increases storage time in the
event of a power cut or breakdown.

Helpful Hints and Tips

Hints for freezing

To help you make the most of the freezing
process, here are some important hints:

• the maximum quantity of food which can
be frozen in 24 hrs. is shown on the rating
plate;

• the freezing process takes 24 hours. No
further food to be frozen should be added
during this period;

• only freeze top quality, fresh and thorough­ly cleaned, foodstuffs;

• prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible subsequently to thaw only
the quantity required;

• wrap up the food in aluminium foil or pol­ythene and make sure that the packages
are airtight;

• do not allow fresh, unfrozen food to touch
food which is already frozen, thus avoiding
a rise in temperature of the latter;

• lean foods store better and longer than
fatty ones; salt reduces the storage life of
food;

electrolux 7

• water ices, if consumed immediately after
removal from the freezer compartment,
can possibly cause the skin to be freeze
burnt;

• it is advisable to show the freezing in date
on each individual pack to enable you to
keep tab of the storage time.

Hints for storage of frozen food

To obtain the best performance from this ap­pliance, you should:

• make sure that the commercially frozen
foodstuffs were adequately stored by the
retailer;

• be sure that frozen foodstuffs are transfer­red from the foodstore to the freezer in the
shortest possible time;

• not open the door frequently or leave it
open longer than absolutely necessary.

• Once defrosted, food deteriorates rapidly
and cannot be refrozen.

• Do not exceed the storage period indica­ted by the food manufacturer.

Care and cleaning

Caution! Unplug the appliance before
carrying out any maintenance operation.

This appliance contains hydrocarbons in
its cooling unit; maintenance and re­charging must therefore only be carried
out by authorized technicians.

Periodic cleaning

The equipment has to be cleaned regularly:

• clean the inside and accessories with luke­warm water and some neutral soap.

• regularly check the door seals and wipe
clean to ensure they are clean and free
from debris.

• rinse and dry thoroughly.

Important! Do no t p ull , m ov e or da ma ge a ny
pipes and/or cables inside the cabinet.
Never use detergents, abrasive powders,
highly perfumed cleaning products or wax
polishes to clean the interior as this will dam­age the surface and leave a strong odour.

Clean the condenser (black grill) and the
compressor at the back of the appliance with

a brush or a vacuum cleaner. This operation
will improve the performance of the appli­ance and save electricity consumption.

Important! Take care of not to damage the
cooling system.

Many proprietary kitchen surface cleaners
contain chemicals that can attack/damage
the plastics used in this appliance. For this
reason it is recommended that the outer cas­ing of this appliance is only cleaned with
warm water with a little washing-up liquid
added.
After cleaning, reconnect the equipment to
the mains supply.

Defrosting of the freezer

The freezer compartment of this model, on
the other hand, is a "no frost" type. This
means that there is no buildup of frost when
it is in operation, neither on the internal walls
nor on the foods.
The absence of frost is due to the continuous
circulation of cold air inside the compart-

8 electrolux

ment, driven by an automatically controlled
fan.

Periods of non-operation

When the appliance is not in use for long pe­riods, take the following precautions:

• disconnect the appliance from elec-

tricity supply

•

• leave the door/doors ajar to prevent un-

If the cabinet will be kept on, ask somebody
to check it once in a while to prevent the food
inside from spoiling in case of a power failure.

4)

defrost

and clean the appliance and all

accessories

pleasant smells.

• remove all food

What to do if…

During operation of the appliance some
smaller but annoying trouble can often occur,
which does not require calling a technician
out. In the following chart information is given
about them to avoid unnecessary charges on
service.

Important! The operation of the appliance
goes with certain sounds (compressor and

Problem Possible cause Solution

The appliance is noisy. The appliance is not supported

The cushion spacers located be-

The buzzer sounds. The
Alarm icon flashing.

is displayed in the tem-

perature display

The compressor operates
continually.

The door is not closed correctly. Refer to "Closing the door".
The door has been opened too

The food temperature is too high. Let the food temperature decrease

The room temperature is too

There is too much frost
and ice.

The door is not closed correctly. Refer to "Closing the door".
The door gasket is deformed or

properly.

tween the back of the cabinet and
the pipes come loose.

The temperature in the freezer is
too high.

An error has occurred in measur­ing the temperature.

The Temperature regulator may
be set incorrectly.

frequently.

high.
Food are not wrapped properly. Wrap the food better.

dirty.

circulating sound). This not means a trouble,
but a normal operation.

Important! The appliance operates
discontinuously, so the stopping of
compressor does not mean being no
current. That is why you must not touch the
electrical parts of the appliance before
breaking the circuit.

Check if the appliance stands sta­ble (all feet and wheels should be
on the floor). Refer to "Levelling".

Put them back in place again.

Refer to "High Temperature
Alarm".

Call your service representative
(the cooling system will continue to
keep food products cold, but tem­perature adjustment will not be
possible).

Set a warmer temperature.

Do not keep the door open longer
than necessary.

to room temperature before stor­age.

Decrease the room temperature.

Refer to "Closing the door".

4) If foreseen.

electrolux 9

Problem Possible cause Solution

The temperature in the
appliance is too low.

The temperature in the
appliance is too high.

The door is not closed correctly. Refer to "Closing the door".
The food temperature is too high. Let the food temperature decrease

The temperature in the
freezer is too high.

Large quantities of food to be fro-

The appliance does not
operate.

The mains plug is not connected

The appliance has no power.

The door has been open to long. Close the door.

A large quantity of drops
ice covers the top com­partment inside the appli­ance. .

The Temperature regulator may
be set incorrectly.

The Temperature regulator may
be set incorrectly.

Food is too near to each other. Store food so that there is cold air

zen were put in at the same time.
The appliance is switched off. Switch on the appliance.

to the mains socket correctly.

There is no voltage in the mains
socket.

There is too much frost and ice on
the evaporator of the appliance,
the door was open for too long
time.

Set a higher temperature.

Set a lower temperature.

to room temperature before stor­age.

circulation.
Insert smaller quantities of food to

be frozen at the same time.

Connect the mains plug to the
mains socket correctly.

Connect another electrical appli­ance to the mains socket. Check
fuse. Contact a qualified electri­cian.

Refer to "Cleaning the evaporator".

As much as the advice does not lead to result, call the nearest brand-mark service.

Closing the door

1. Clean the door gaskets.

2. If necessary, adjust the door. Refer to "In-

stallation".

3. If necessary, replace the defective door

gaskets. Contact the Service Center.

Cleaning the evaporator

1. Switch off the appliance.

2. Disconnect the mains plug from the

mains socket.

3. Remove all foods from the freezer and

put them in a fresh place.

4. Move the appliance far from the wall.

5. Leave the door open.

6. After approximately 20 minutes the drain

hose at the rear of the cabinet starts to
discharge water into the drip tray.

7. To prevent the water overflowing from

the drip tray dry with a sponge.

8. The defrosting process ends when the
water stops dripping. It may take several
hours if the problem started long before.

9. Move the appliance to the original posi­tion.

10 electrolux

10. Clean and dry the inside of the appli­ance.

11. Connect the mains plug into the mains
socket.

12. Switch on the appliance.

Technical data

Dimension
Height 1800 mm
Width 600 mm
Depth 650 mm
Rising Time 20 h

The technical information are situated in the
rating plate on the internal left side of the ap­pliance and in the energy label.

Installation

Read the "Safety Information" carefully
for your safety and correct operation of
the appliance before installing the
appliance.

Location

The appliance should be installed well away
from sources of heat such as radiators, boil­ers, direct sunlight etc. Ensure that air can
circulate freely around the back of the cabi­net. To ensure best performance, if the ap­pliance is positioned below an overhanging
wall unit, the minimum distance between the
top of the cabinet and the wall unit must be
at least 100 mm . Ideally, however, the ap­pliance should not be positioned below over­hanging wall units. Accurate levelling is en­sured by one or more adjustable feet at the
base of the cabinet.
If the cabinet is placed in a corner and the
side with the hinges facing the wall, the dis­tance between the wall and the cabinet must
be at least 10 mm to allow the door to open
enough so that the shelves can be removed.

Warning! It must be possible to
disconnect the appliance from the mains
power supply; the plug must therefore
be easily accessible after installation.

10mm 100mm

Electrical connection

Before plugging in, ensure that the voltage
and frequency shown on the rating plate cor­respond to your domestic power supply.
The appliance must be earthed. The power
supply cable plug is provided with a contact
for this purpose. If the domestic power sup­ply socket is not earthed, connect the appli­ance to a separate earth in compliance with
current regulations, consulting a qualified
electrician.
The manufacturer declines all responsibility if
the above safety precautions are not ob­served.
This appliance complies with the E.E.C. Di­rectives.

10mm

Rear spacers
Inside the appliance you find two

spacers which must be fitted as shown
in the figure.

Slacken the screws and insert the spacer
under the screw head, then retighten the
screws.

electrolux 11

d

d

• Remove the screw of the hinge cover plug
(a) .

• Unscrew the upper hinge and remove it
(b).

• Unscrew the screw and remove the door
stopper (c).

b

Door reversibility

Before carrying out any operations, remove
the plug from the power socket. To change
the opening direction of the door, proceed as
follows:

• To carry out the following operations, we
suggest that this be made with another
person that will keep a firm hold on the
doors of the appliance during the opera­tions.

• Open the door with the appliance in the
upright position. Unscrew the screws and
remove the upper door plastic trim.

• Remove the little plastic cover from the
door plastic trim and refit on the opposite
side (d).

• Lay down the appliance back side down.

c

a

• Remove the door.

• Remove using a tool the cover (e), unscrew
the lower hinge pivot (f) and place it on the
opposite side.

• Re-insert the cover (e) on the opposite
side.

• Re-insert the door .

• Pay attention that the front board of the
doors are parallel to the front board of the
top.

• Fix the door stopper on the opposite side.

• Position and fix the upper hinge (that can
be found in the instruction for use bag) on
the opposite side .

12 electrolux

• Fix the screw of the new cover hinge (that
can be found in the instruction for use
bag).

e

2

1

5

f

4

3

• Lift up the appliance to vertical position.

• Open the door and reposition the upper
door plastic trim with screws.

• Fix the handle on the opposite side, insert
the plastic plugs into the holes left open
that can be found in the instruction for use
bag.

Warning! Reposition, level the
appliance, wait for at least four hours
and then connect it to the power socket.

In case you do not want to carry out the
above mentioned operations, contact the
nearest After Sales Service Force. The After
Sales Service specialist will carry out the re­versibility of the doors at your cost.

Warning! After having reversed the
opening direction of the doors check
that all the screws are properly tightened
and that the magnetic seal adheres to
the cabinet.
If the ambient temperature is cold (i.e. in
Winter), the gasket may not fit perfectly
to the cabinet. In that case, wait for the
natural fitting of the gasket. Lay down
the appliance back side down.

Environmental concerns

The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for

the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local council,
your household waste disposal service or the
shop where you purchased the product.

Electrolux. Thinking of you.

Partagez notre imagination sur www.electrolux.com

Sommaire

Consignes de sécurité 13
Bandeau de commande 15
Première utilisation 18
Utilisation quotidienne 18
Conseils 18
Entretien et nettoyage 19

Consignes de sécurité

Pour votre sécurité et garantir une utilisation
correcte de l'appareil, lisez attentivement
cette notice, y compris les conseils et aver­tissements, avant d'installer et d'utiliser l'ap­pareil pour la première fois. Pour éviter toute
erreur ou accident, veillez à ce que toute per­sonne qui utilise l'appareil connaisse bien
son fonctionnement et ses fonctions de sé­curité. Conservez cette notice avec l'appa­reil. Si l'appareil doit être vendu ou cédé à
une autre personne, veillez à remettre cette
notice au nouveau propriétaire, afin qu'il
puisse se familiariser avec son fonctionne­ment et sa sécurité.
Pour la sécurité des personnes et des biens,
conservez et respectez les consignes de sé­curité figurant dans cette notice. Le fabricant
décline toute responsabilité en cas de dom­mages dus au non-respect de ces instruc­tions.

Sécurité des enfants et des personnes
vulnérables

• Cet appareil n'est pas destiné à être utilisé
par des enfants ou des personnes dont les
capacités physiques, sensorielles ou men­tales, ou le manque d'expérience et de
connaissance les empêchent d'utiliser
l'appareil sans risque lorsqu'ils sont sans
surveillance ou en l'absence d'instruction
d'une personne responsable qui puisse
leur assurer une utilisation de l'appareil
sans danger.
Empêchez les enfants de jouer avec l'ap­pareil.

electrolux 13

En cas d'anomalie de fonctionnement

20
Caractéristiques techniques 22
Installation 22
En matière de sauvegarde de
l'environnement 25

Sous réserve de modifications

• Ne laissez pas les différents emballages à

portée des enfants. Ils pourraient s'asphy­xier.

• Si l'appareil doit être mis au rebut, veillez à

couper le câble d'alimentation électrique
au ras de l'appareil pour éviter les risques
d'électrocution. Démontez la porte pour
éviter que des enfants ne restent enfermés
à l'intérieur.

• Cet appareil est muni de fermetures ma-

gnétiques. S'il remplace un appareil équi­pé d'une fermeture à ressort, nous vous
conseillons de rendre celle-ci inutilisable
avant de vous en débarrasser. Ceci afin
d'éviter aux enfants de s'enfermer dans
l'appareil et de mettre ainsi leur vie en dan­ger.

Sécurité générale

Attention Veillez à ce que les orifices de

ventilation ne soient pas obstrués.

• Cet appareil est destiné uniquement à la

conservation d'aliments et/ou de boissons
dans le cadre d'un usage domestique nor­mal, tel que celui décrit dans la présente
notice.

• N'utilisez pas de dispositifs mécaniques

ou autres moyens artificiels pour accélérer
le dégivrage de l'appareil.

• N'utilisez pas d'autres appareils électri-

ques (par exemple, sorbetières) à l'inté­rieur d'appareils réfrigérants sauf s'ils sont
homologués pour cet usage par leur fabri­cant.

• N'endommagez pas le circuit de refroidis-

sement.

14 electrolux

• Le circuit de refroidissement de l'appareil
contient de l'isobutane (R600a), un gaz
naturel offrant un haut niveau de compati­bilité avec l'environnement mais qui est
néanmoins inflammable.
Pendant le transport et l'installation de
l'appareil, assurez-vous qu'aucune pièce
du circuit de refroidissement n'est endom­magée.
Si tel est le cas :
– évitez les flammes vives et les sources

d'ignition

– aérez soigneusement la pièce où se

trouve l'appareil

• Il est dangereux de modifier les caracté­ristiques de l'appareil ou l'appareil. Un cor­don d'alimentation endommagé peut être
la cause de courts-circuits, d'incendies et/
ou de décharges électriques.

Avertissement Les composants élec­triques (cordon d'alimentation, prise,
compresseur) doivent être remplacés
par un technicien d'entretien agréé ou
par un électricien spécialisé.

1. Ne branchez pas le cordon d'alimen-

tation à une rallonge.

2. Assurez-vous que la prise n'est pas

écrasée ou endommagée par l'arrière
de l'appareil. Une prise de courant en­dommagée peut s'échauffer et provo­quer un incendie.

3. Assurez-vous de pouvoir accéder à la

prise secteur de l'appareil.

4. Ne tirez pas sur le cordon d'alimenta-

tion.

5. Si la fiche du cordon d'alimentation est

desserrée, ne la branchez pas sur la
prise murale. Risque d'électrocution
ou d'incendie.

6. N'utilisez pas l'appareil si le diffuseur

de l'ampoule d'éclairage n'est pas pré-

5)

sent

pour l'éclairage intérieur.

• Cet appareil est lourd. Faites attention lors
de son déplacement.

• Ne touchez pas les produits congelés sor­tant du congélateur avec les mains humi­des car ceci peut provoquer des abrasions
ou des brûlures cutanées.

• Évitez les expositions prolongées de l'ap­pareil aux rayons solaires.

5) Si le diffuseur est prévu

6) Si l'appareil est sans givre

Utilisation quotidienne

• Ne posez pas d'éléments chauds sur les
parties en plastique de l'appareil.

• Ne stockez pas de gaz ou de liquides in­flammables dans l'appareil (risque d'ex­plosion).

• Ne placez pas d'aliments directement
contre la sortie d'air sur la paroi arrière de

l'appareil.

6)

• Un produit décongelé ne doit jamais être
recongelé.

• Conservez les aliments emballés confor­mément aux instructions de leur fabricant.

• Respectez scrupuleusement les conseils
de conservation donnés par le fabricant de
l'appareil. Consultez les instructions res­pectives.

• Ne mettez pas de bouteilles ni de boîtes
de boissons gazeuses dans le comparti­ment congélateur, car la pression se for­mant à l'intérieur du contenant pourrait le
faire éclater et endommager ainsi l'appa­reil.

• Ne consommez pas certains produits tels
que les bâtonnets glacés dès leur sortie de
l'appareil, car ils peuvent provoquer des
brûlures.

Entretien et nettoyage

• Avant toute opération d'entretien, mettez
l'appareil à l'arrêt et débranchez-le.

• N'utilisez pas d'objets métalliques pour
nettoyer l'appareil.

• N'utilisez pas d'objet tranchant pour grat­ter la couche de givre. Utilisez une spatule
en plastique.

• N'utilisez pas d'appareils électriques ou
agents chimiques pour dégivrer l'appareil.
La chaleur excessive pourrait endomma­ger le revêtement plastique interne et l'hu­midité pourrait s'introduire dans le systè­me électrique.

Installation
Important Avant de procéder au

branchement électrique, respectez
scrupuleusement les instructions fournies
dans cette notice.

• Déballez l'appareil et vérifiez qu'il n'est pas
endommagé. Ne branchez pas l'appareil
s'il est endommagé. Signalez immédiate­ment au revendeur de l'appareil les dom-

electrolux 15

mages constatés. Dans ce cas, gardez
l'emballage.

• Il est conseillé d'attendre au moins quatre
heures avant de brancher l'appareil pour
que le circuit frigorifique soit stabilisé.

• Veillez à ce que l'air circule librement au­tour de l'appareil pour éviter qu'il ne sur­chauffe. Pour assurer une ventilation suffi­sante, respectez les instructions de la no­tice (chapitre Installation).

• Placez l'appareil dos au mur pour éviter
tout contact avec le compresseur et le
condenseur (risque de brûlure).

• Placez de préférence votre appareil loin
d'une source de chaleur (chauffage, cuis­son ou rayons solaires trop intenses).

• Assurez-vous que la prise murale reste ac­cessible après l'installation de l'appareil.

• Branchez à l'alimentation en eau potable
uniquement.

Maintenance

• Les branchements électriques nécessai­res à l'entretien de l'appareil doivent être

7)

Bandeau de commande

réalisés par un électricien qualifié ou une
personne compétente.

• Cet appareil ne doit être entretenu et ré­paré que par un Service après-vente au­torisé, exclusivement avec des pièces
d'origine.

Protection de l'environnement

Le système frigorifique et l'isolation de
votre appareil ne contiennent pas de
C.F.C. contribuant ainsi à préserver l'en­vironnement. L'appareil ne doit pas être
mis au rebut avec les ordures ménagè­res et les déchets urbains. La mousse
d'isolation contient des gaz inflamma­bles : l'appareil sera mis au rebut con­formément aux règlements applicables
disponibles auprès des autorités loca­les. Veillez à ne pas détériorer les circuits
frigorifiques, notamment au niveau du
condenseur. Les matériaux utilisés dans
cet appareil identifiés par le symbole
sont recyclables.

AC

BDE

A - Touche Marche/Arrêt D - Touche Fonctions
B - Touche de réglage de la température E - Touche de confirmation
C - Affichage de la température et de la fonc-

tion

7) Si un branchement sur le réseau d'eau est prévu

16 electrolux

Afficheur

Alarme de température Activation de la fonction Minuteur
Signe négatif de la température Activation de la fonction Refroidisse-

ment des boissons

Température Activation de la fonction Congélation

rapide

Activation de la Sécurité enfants Activation du mode Eco

Mise en fonctionnement

Branchez correctement la fiche sur la prise
de courant. Si l'afficheur n'est pas allumé,
appuyez sur la touche (A) pour mettre l'ap­pareil en fonctionnement.
Pour une conservation optimale des ali­ments, sélectionnez le mode Eco, la tempé­rature est alors réglée sur -18°C dans le
compartiment congélateur.

• Avant d'introduire des aliments dans le
compartiment congélateur, attendez que
la température régnant à l'intérieur soit de

-18°C.

• Pour sélectionner une température diffé­rente, reportez-vous au paragraphe "Ré­glage de la température".

Mise à l'arrêt

Pour mettre l'appareil à l'arrêt, appuyez sur
la touche (A) jusqu'à ce que le décompte de

-3 -2 -1 soit terminé.

Réglage de la température

Pour modifier la température, appuyez sur la
touche (B).
Le réglage actuel de la température clignote
sur l'afficheur. Vous pouvez le modifier par
palier de un degré en appuyant de nouveau
sur la touche (B).
La température de conservation s'affiche de
nouveau au bout de quelques secondes.
La température de consigne sélectionnée
sera atteinte au bout de 24 heures.

Important Pendant la phase de stabilisation
de 24 heures, après la première mise en ser­vice, il est possible que la température affi­chée ne corresponde pas à la température
programmée.

Menu Fonctions

Pour activer le menu Fonctions, appuyez sur
la touche (D). Pour confirmer la fonction sé­lectionnée, appuyez sur la touche (E). Si vous
omettez de confirmer votre sélection, l'écran
quitte le menu Fonctions au bout de quel­ques secondes et retourne au mode de fonc­tionnement normal. Les fonctions affichées
sont les suivantes :

Fonction Sécurité enfants
Fonction Mode Eco
Fonction Congélation Rapide
Fonction Refroidissement des bois-

sons

Fonction Sécurité enfants

Pour activer la fonction Sécurité enfants, ap­puyez sur la touche (D) (plusieurs fois, si né­cessaire), jusqu'à ce que le symbole corres-

pondant apparaisse
Vous devez valider votre sélection en appuy­ant sur la touche (E) dans les secondes qui
suivent. Un signal sonore retentit et le sym­bole reste allumé. Dans ce cas, aucune mo­dification n'est possible en appuyant sur
