REFRIGERATOR USER MANUAL
EN
2
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have
created it to give you impeccable performance for many
years, with innovative technologies that help make life
simpler – features you might not find on ordinary
appliances. Please spend a few minutes reading to get the
very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to
keep all your AEG appliances looking spotless and
working perfectly. Along with a wide range of accessories
designed and built to the high quality standards you
would expect, from specialist cookware to cutlery baskets,
from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg.com/shop
CONTENTS
4 Safety information
6 Control panel
10 First use
11 Daily use
13 Helpful hints and tips
14 Care and cleaning
16 What to do if…
18 Technical data
18 Installation
24 Environmental concerns
Contents
3
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
4 Safety information
SAFETY INFORMATION
In the interest of your safety and to ensure the correct use, before installing and first using
the appliance, read this user manual carefully, including its hints and warnings. To avoid
unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. Save these instructions and make sure that they remain with the appliance if it is moved or sold, so that everyone using it through its life will be properly informed on appliance use and safety.
For the safety of life and property keep the precautions of these user's instructions as the
manufacturer is not responsible for damages caused by omission.
Children and vulnerable people safety
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Keep all packaging well away from children. There is risk of suffocation.
• If you are discarding the appliance pull the plug out of the socket, cut the connection
cable (as close to the appliance as you can) and remove the door to prevent playing children to suffer electric shock or to close themselves into it.
• If this appliance featuring magnetic door seals is to replace an older appliance having a
spring lock (latch) on the door or lid, be sure to make that spring lock unusable before
you discard the old appliance. This will prevent it from becoming a death trap for a child.
General safety
CAUTION!
Keep ventilation openings clear of obstruction.
• The appliance is intended for keeping foodstuff and/or beverages in a normal household
as explained in this instruction booklet.
• Do not use a mechanical device or any artificial means to speed up the thawing process.
• Do not use other electrical appliances (such as ice cream makers) inside of refrigerating
appliances, unless they are approved for this purpose by the manufacturer.
• Do not damage the refrigerant circuit.
• The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable.
During transportation and installation of the appliance, be certain that none of the components of the refrigerant circuit become damaged.
If the refrigerant circuit should become damaged:
– avoid open flames and sources of ignition
– thoroughly ventilate the room in which the appliance is situated
Safety information 5
• It is dangerous to alter the specifications or modify this product in any way. Any damage
to the cord may cause a short-circuit, fire and/or electric shock.
WARNING!
Any electrical component (power cord, plug, compressor) must be replaced by a certified
service agent or qualified service personnel to avoid hazard.
1. Power cord must not be lengthened.
2. Make sure that the power plug is not squashed or damaged by the back of the appli-
ance. A squashed or damaged power plug may overheat and cause a fire.
3. Make sure that you can come to the mains plug of the appliance.
4. Do not pull the mains cable.
5. If the power plug socket is loose, do not insert the power plug. There is a risk of elec-
tric shock or fire.
6.
You must not operate the appliance without the lamp cover
1)
of interior lighting.
• This appliance is heavy. Care should be taken when moving it.
• Do not remove nor touch items from the freezer compartment if your hands are damp/
wet, as this could cause skin abrasions or frost/freezer burns.
• Avoid prolonged exposure of the appliance to direct sunlight.
•
Bulb lamps
2)
used in this appliance are special purpose lamps selected for household ap-
pliances use only. They are not suitable for household room illumination.
Daily use
• Do not put hot pot on the plastic parts in the appliance.
• Do not store flammable gas and liquid in the appliance, because they may explode.
• Appliance's manufacturers storage recommendations should be strictly adhered to. Refer
to relevant instructions.
Care and cleaning
• Before maintenance, switch off the appliance and disconnect the mains plug from the
mains socket.
• Do not clean the appliance with metal objects.
• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean
the drain. If the drain is blocked, water will collect in the bottom of the appliance.
Installation
For electrical connection carefully follow the instructions given in specific paragraphs.
• Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it.
In that case retain packing.
• It is advisable to wait at least four hours before connecting the appliance to allow the oil
to flow back in the compressor.
1) If the lamp cover is foreseen.
2) If the lamp is foreseen.
6 Control panel
• Adequate air circulation should be around the appliance, lacking this leads to overheating. To achieve sufficient ventilation follow the instructions relevant to installation.
• Wherever possible the back of the product should be against a wall to avoid touching or
catching warm parts (compressor, condenser) to prevent possible burn.
• The appliance must not be located close to radiators or cookers.
• Make sure that the mains plug is accessible after the installation of the appliance.
•
Connect to potable water supply only.
3)
Service
• Any electrical work required to do the servicing of the appliance should be carried out by
a qualified electrician or competent person.
• This product must be serviced by an authorized Service Centre, and only genuine spare
parts must be used.
Environment Protection
This appliance does not contain gasses which could damage the ozone layer, in either its
refrigerant circuit or insulation materials. The appliance shall not be discarded together
with the urban refuse and rubbish. The insulation foam contains flammable gases: the appliance shall be disposed according to the applicable regulations to obtain from your local
authorities. Avoid damaging the cooling unit, especially at the rear near the heat exchanger. The materials used on this appliance marked by the symbol
are recyclable.
CONTROL PANEL
1 2 3 4 5 6
1 ON/OFF button
2 Mode button
3 OK button
4 Temperature colder button
5 Temperature warmer button
6 Display
It is possible to change predefined sound of buttons to a loudly one by pressing together
Mode button and Temperature colder button for some seconds. Change is reversible.
3) If a water connection is foreseen.
Control panel
Display/Indicator
4321
78 56
1 Timer indicator
2 COOLMATIC function
3 Holiday function
4 Temperature indicator
5 Alarm indicator
6 Child Lock function
7 Minute Minder function
8 Humidity function
Switching on
To switch on the appliance do these steps:
1. Connect the mains plug to the power socket.
2. Press the ON/OFF button if the display is off.
3. The temperature indicators show the set default temperature.
To select a different set temperature refer to "Temperature regulation".
WARNING!
If the door remains open for some minutes, the light will turn off automatically. The light is
reset by closing and opening the door itself.
7
Switching off
To switch off the appliance do these steps:
1. Press the ON/OFF button for few seconds.
2. The display switches off.
3. To disconnect the appliance from the power disconnect the mains plug from the power
socket.
Temperature regulation
The set temperature of the fridge may be adjusted by pressing the temperature button.
Set default temperature:
• +5°C for the fridge
The temperature indicator shows the set temperature.
The set temperature will be reached within 24 hours.
After a power failure the set temperature remains stored.
8 Control panel
Minute Minder function
The Minute Minder function is to be used to set an acoustic alarm at the preferred time,
useful for example when a recipe requires to cool down a mixture for a certain lenght of
time.
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
The Minute Minder indicator flashes.
The Timer shows the set value (30 minutes) for a few seconds.
2. Press the Temperature colder or the Temperature warmer button to change the Timer
set value from 1 to 90 minutes.
3. Press the OK button to confirm.
The Minute Minder indicator is shown.
The Timer start to flash (min).
At the end of the countdown the Minute Minder indicator flashes and an audible alarm
sounds:
1. Press OK button to switch off the sound and terminate the function.
It is possible to deactivate the function at any time during the countdown:
1. Press the Mode button until the Minute Minder indicator flashes.
2. Press the OK button to confirm.
3. The Minute Minder indicator goes off.
It is possible to change the time during the countdown by pressing the Temperature colder
button and the Temperature warmer button.
Child Lock function
To lock the buttons from unintentional operation select the Child Lock function.
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
2. The Child Lock indicator flashes.
3. Press the OK button to confirm.
The Child Lock indicator is shown.
To switch off the function:
1. Press the Mode button until the Child Lock indicator flashes.
2. Press the OK button to confirm.
3. The Child Lock indicator goes off.
COOLMATIC function
If you need to insert a large amount of warm food, for example after doing the grocery
shopping, we suggest activating the COOLMATIC function to chill the products more rapidly
and to avoid warming the other food which is already in the refrigerator.
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
The COOLMATIC indicator flashes.
Control panel
2. Press the OK button to confirm.
The COOLMATIC indicator is shown.
The COOLMATIC function shuts off automatically after approximately 6 hours.
To switch off the function before its automatic end:
1. Press the Mode button until the COOLMATIC indicator flashes.
2. Press the OK button to confirm.
3. The COOLMATIC indicator goes off.
The function switches off by selecting a different fridge set temperature.
Extra Humidity function
If you need to increase the humidity in the refrigerator, we suggest activating the Extra
Humidity function:
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
The Extra Humidity indicator flashes.
2. Press the OK button to confirm.
The Extra Humidity indicator is shown.
To switch off the function:
1. Press the Mode button until the Extra Humidity indicator flashes.
2. Press the OK button to confirm.
3. The Extra Humidity indicator goes off.
9
Holiday function
This function allows you to keep the refrigerator closed and empty during a long holiday
period without the formation of a bad smell.
The fridge compartment must be empty with holiday function on.
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
The Holiday indicator flashes.
The fridge temperature indicator shows the set temperature.
2. Press the OK button to confirm.
The Holiday indicator is shown.
To switch off the function:
1. Press the Mode button until the Holiday indicator flashes.
2. Press the OK button to confirm.
3. The Holiday indicator goes off.
The function switches off by selecting a different fridge set temperature.
10 First use
Door open alarm
An acoustic alarm will sound if the door is left open for a few minutes. The door open alarm
conditions are indicated by:
• flashing Alarm indicator
• acoustic buzzer
When normal conditions are restored (door closed), the alarm will stop.
During the alarm, the buzzer can be switched off by pressing any button.
FIRST USE
Cleaning the interior
Before using the appliance for the first time, wash the interior and all internal accessories
with lukewarm water and some neutral soap so as to remove the typical smell of a brandnew product, then dry thoroughly.
Do not use detergents or abrasive powders, as these will damage the finish.
Check that the drain hose at the rear of the cabinet discharges into the drip tray.
Daily use 11
DAILY USE
Movable shelves
The walls of the refrigerator are equipped with a
series of shelves support so that the shelves can
be positioned as desired.
Some shelves must be lifted up by the rear edge
to enable them to be removed.
Do not move the glass shelf above the vegetable
drawer to ensure correct air circulation.
Vegetable Drawer
The drawer is suitable for storing fruit and vegetables.
Some models have a separator inside the drawer that can be placed in different positions to
allow for the subdivision best suited to personal needs.
All parts inside the drawer can be removed for cleaning purposes.
Bottle rack
Place the bottles (with the opening facing front)
in the pre-positioned shelf.
If the shelf is positioned horizontally, place only
closed bottles.
12 Daily use
This bottle holder shelf can be tilted in order to
store previously opened bottles. To obtain this result, pull the shelf up so it can rotate upwards and
be placed on the next higher level.
Clean Air Control Filter
Your appliance is equipped with a carbon filter behind the air lever flap.
The filter purifies the air from unwanted odours in the fridge compartment preserving food
quality.
On delivery the filter is in a plastic bag. Refer to "Installation of the Clean Air Control filter"
for instructions.
Make sure that the air lever flap is closed to obtain proper function.
Positioning the door shelves
To permit storage of food packages of various sizes, the door shelves can be placed at different heights.
Helpful hints and tips 13
To make these adjustments proceed as follows:
Gradually pull the shelf in the direction of the arrows until it comes free, then reposition as required.
Do not move the big lower door shelf to ensure
correct air circulation.
HELPFUL HINTS AND TIPS
Hints for energy saving
• Do not open the door frequently or leave it open longer than absolutely necessary.
• If the ambient temperature is high and the Temperature Regulator is set to low tempera-
ture and the appliance is fully loaded, the compressor may run continuously, causing
frost or ice on the evaporator. If this happens, set the Temperature Regulator toward
warmer settings to allow automatic defrosting and so a saving in electricity consumption.
Hints for fresh food refrigeration
To obtain the best performance:
• do not store warm food or evaporating liquids in the refrigerator
• do cover or wrap the food, particularly if it has a strong flavour
• position food so that air can circulate freely around it
Hints for refrigeration
Useful hints:
Meat (all types) : wrap in polythene bags and place on the glass shelf above the vegetable
drawer.
For safety, store in this way only one or two days at the most.
Cooked foods, cold dishes, etc..: these should be covered and may be placed on any shelf.
Fruit and vegetables: these should be thoroughly cleaned and placed in the special drawer(s) provided.
Butter and cheese: these should be placed in special airtight containers or wrapped in aluminium foil or polythene bags to exclude as much air as possible.
14 Care and cleaning
Milk bottles: these should have a cap and should be stored in the bottle rack on the door.
Bananas, potatoes, onions and garlic, if not packed, must not be kept in the refrigerator.
Hints for temperature inside the fridge
A suitable temperature inside the fridge is approx. +5° C. When the temperature regulator
is set to +5°C this represents the mean temperature in the fridge. It is normal with higher
temperature in the top of the fridge.
If the temperature regulator is set to a cold temperature, the ambient temperature is high or if
the fridge is fully loaded the compressor will run
for a longer time. It too cold, change to a higher
temperature setting.
Do not place food against or close to the temperature sensor. This can result in too cold temperatures.
If you want to check the temperature of food
stored in the refrigerator, place a glass of water
centrally in the cabinet, and put a proper thermometer with an accuracy of +/– 1 °C into it. After 6 hours the temperature can be monitored.
The measuring shall be performed under steadystated conditions (without changing the load).
A
CARE AND CLEANING
CAUTION!
Unplug the appliance before carrying out any maintenance operation.
This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must
therefore only be carried out by authorized technicians.
Periodic cleaning
The equipment has to be cleaned regularly:
• clean the inside and accessories with lukewarm water and some neutral soap.
Care and cleaning 15
• regularly check the door seals and wipe clean to ensure they are clean and free from
debris.
• rinse and dry thoroughly.
Do not pull, move or damage any pipes and/or cables inside the cabinet.
Never use detergents, abrasive powders, highly perfumed cleaning products or wax polishes
to clean the interior as this will damage the surface and leave a strong odour.
Clean the condenser (black grill) and the compressor at the back of the appliance with a
brush or a vacuum cleaner. This operation will improve the performance of the appliance
and save energy consumption.
Take care of not to damage the cooling system.
When moving the cabinet, lift it by the front edge to avoid scratching the floor.
Many proprietary kitchen surface cleaners contain chemicals that can attack/damage the
plastics used in this appliance. For this reason use a soft cloth rinsed in warm water and
neutral soap emulsion for cleaning external surfaces.
Do not use detergents or abrasive paste as these will damage the paint, or stainless steel
anti finger print coating.
After cleaning, reconnect the equipment to the mains supply.
Replacing the Clean Air Control filter
To get the best performance replace the Clean Air Control filter once every year.
New active filters can be purchased from your local dealer.
Refer to "Installation of the Clean Air Control filter" for instructions.
Cleaning the ventilation grille
The ventilation grille can be removed for washing.
Make sure the door is open and then:
1. Loosen the upper edge of the grille by
pulling outward/downward.
2. Pull the grille straight out to completely
remove it.
3. Vacuum clean under the cabinet.
16 What to do if…
Defrosting the refrigerator
Frost is automatically eliminated from the evaporator of the refrigerator compartment every time
the motor compressor stops, during normal use.
The defrost water drains out through a drain hole
into a special container at the back of the appliance, over the motor compressor, where it evaporates.
It is important to periodically clean the defrost
water drain hole in the middle of the refrigerator
compartment channel to prevent the water overflowing and dripping onto the food inside.
Periods of non-operation
When the appliance is not in use for long periods, take the following precautions:
1. disconnect the appliance from electricity supply
2. remove all food
3. defrost and clean the appliance and all accessories
4. leave the door/doors open to prevent unpleasant smells.
If the cabinet will be kept on, ask somebody to check it once in a while to prevent the food
inside from spoiling in case of a power failure.
WHAT TO DO IF…
During operation of the appliance some smaller but annoying trouble can often occur,
which does not require calling a technician out. In the following chart information is given
about them to avoid unnecessary charges on service.
The operation of the appliance goes with certain sounds (compressor and circulating
sound). This not means a trouble, but a normal operation.
The appliance operates discontinuously, so the stopping of compressor does not mean being no current. That is why you must not touch the electrical parts of the appliance before
breaking the circuit.
Problem Possible cause Solution
The appliance is noisy. The appliance is not supported
The buzzer sounds. The
Alarm icon flashing.
properly.
The door is not closed correctly. Refer to "Door open alarm".
Check if the appliance stands stable (all feet and wheels should be
on the floor). Refer to "Levelling".
What to do if… 17
Problem Possible cause Solution
upper or lower square
is shown in the temperature display.
The compressor runs continuously.
The door is not closed correctly. Refer to "Closing the door".
The door has been opened too
The food temperature is too
The room temperature is too
Water flows inside the refrigerator.
Food prevent that water flows
Water flows on the
ground.
The temperature in the
appliance is too cold.
The temperature in the
appliance is too warm.
The door is not closed correctly. Refer to "Closing the door".
The food temperature is too
The temperature in the refrigerator is too warm.
Large quantities of food to be
The appliance does not
operate.
The mains plug is not connected
An error has occurred in measuring the temperature
The Temperature regulator may
be set incorrectly.
frequently.
high.
high.
The water outlet is clogged. Clean the water outlet.
into the water collector.
The melting water outlet does
not flow in the evaporative tray
above the compressor.
The Temperature regulator may
be set incorrectly.
The Temperature regulator may
be set incorrectly.
high.
There is no cold air circulation in
the appliance.
cooled were put in at the same
time.
The appliance is switched off. Switch on the appliance.
to the mains socket correctly.
Call your service representative
(the cooling system will continue
to keep food products cold, but
temperature adjustment will not
be possible)
Set a warmer temperature.
Do not keep the door open longer
than necessary.
Let the food temperature decrease to room temperature before storage.
Decrease the room temperature.
Make sure that food do not touch
the rear plate.
Attach the melting water outlet
to the evaporative tray.
Set a warmer temperature.
Set a lower temperature.
Let the food temperature decrease to room temperature before storage.
Make sure that there is cold air
circulation in the appliance.
Insert smaller quantities of food
to be cooled at the same time.
Connect the mains plug to the
mains socket correctly.
18 Technical data
Problem Possible cause Solution
The appliance has no power.
The lamp does not work. The lamp is defective. Refer to "Replacing the lamp".
The door has been open to long. Close the door.
Door interferes with ventilation grill.
Misaligned door. The appliance is not levelled. Refer to "Levelling".
There is no voltage in the mains
socket.
The appliance is not levelled. Refer to "Levelling".
Connect a another electrical appliance to the mains socket.
Check fuse. Contact a qualified
electrician.
As much as the advice does not lead to result, call the nearest brand-mark service.
Replacing the lamp
The appliance is equipped with a longlife LED interior light.
Only service is allowed to replace the lighting device. Contact your Service Center .
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to "Installation".
3. If necessary, replace the defective door gaskets. Contact the Service Center.
TECHNICAL DATA
Dimension
Height 1800 mm
Width 595 mm
Depth 623 mm
Voltage 230 V
Frequency 50 Hz
The technical information are situated in the rating plate on the internal left side of the
appliance and in the energy label.
INSTALLATION
WARNING!
Read the "Safety Information" carefully for your safety and correct operation of the appliance before installing the appliance.
Installation 19
Positioning
Install this appliance at a location where the ambient temperature corresponds to the climate class indicated on the rating plate of the appliance:
Climate class Ambient temperature
SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C
Location
To ensure best performance, if the appliance is positioned below an overhanging wall unit,
the minimum distance between the top of the cabinet and the wall unit must be at least 40
mm . Ideally, however, the appliance should not be positioned below overhanging wall
units.
The ventilation space can be:
• directly above the appliance
• behind and above the top cupboard.
In this case, the space behind the top cupboard
must be at least 50 mm deep.
50mm
Electrical Connection
CAUTION!
Any electrical work required to install this appliance should be carried out by a qualified
electrician or competent person.
WARNING!
This appliance must be earthed.
The manufacturer declines any liability should these safety measures not be observed.
20 Installation
1 2
5
3
4
The wires in the mains lead are coloured in accordance with the following code:
Green and Yellow: Earth
1
Brown: Live
3
Blue: Neutral
5
As the colours of the wires in the mains lead of this appliance may not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows:
1. Connect the wire coloured green and yellow to the terminal marked either with the let-
ter “E“ or by the earth symbol
2. Connect the wire coloured blue to the terminal either marked with the letter “N“ or
coloured black.
3. Connect the wire coloured brown to the terminal either marked with the “L“ or col-
oured red.
4.
Check that no cut, or stray strands of wire is present and the cord clamp
over the outer sheath.
5. Make sure the electricity supply voltage is the same as that indicated on the appliance
rating plate.
6. Switch on the appliance.
The appliance is supplied with a 13 amp plug fitted
the fuse in the plug supplied, a 13 amp ASTA approved (BS 1362) fuse must be used.
WARNING!
A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard. Ensure that it
is disposed of safely.
or coloured green and yellow.
. In the event of having to change
2
is secure
4
Removing the transport support
Your appliance is equipped with transport support to secure the door during transportation.
To remove them do these steps:
1. Open the door.
2. Remove the transport support from the
door sides.
3. Remove the transport support from the
lower hinge (some models).
Some models are fitted with a silencing pad
under the cabinet. Do not remove this pad.
Removing the shelf holders
Your appliance is equipped with shelf retainers
that make it possible to secure the shelves during
transportation.
To remove them proceed as follows:
1. Move the shelf holders in the direction of the
arrow (A).
2. Lift up the shelves in the rear edge (B) and
push it forward until it is freed (C).
3. Remove the retainers.
Installation 21
3
2
C
A
B
Rear spacers
Install the spacers provided within the accessory bag as shown in the figure.
Install the spacers on the back side of the panel.
Fitting the door handles
(Example for right hinge performance)
The handles are supplied as a kit at delivery.
22 Installation
1. Screw the top handle bracket to the han-
dle rod.
2. Fit the bottom handle bracket on the low-
er left-hand side of the door.
3. Fit the top handle bracket on the top left-
hand side of the door.
4. Screw the handle rod to the bottom han-
dle bracket.
Do not use excessive force and overtighten
the screws (max. 2 Nm) as you may damage
the door handles.
12
Levelling
When placing the appliance ensure that it stands
level. If necessary adjust the feet using the adjustment spanner supplied.
Door alignment is dependent on proper levelling.
Installation of the Taste Guard Filter
The Taste Guard Filter is an active carbon filter which absorbs bad odours maintain the best
flavour and aroma for all foodstuffs without risk of odour cross contamination.
On delivery the carbon filter is in a plastic bag to preserve performance.
1. Open the air lever flap.
2. Take the filter out of the plastic bag.
43
3. Insert the filter in the slot found in the
back of the air lever flap.
4. Close the air lever flap.
The filter should be handled carefully so fragments do not loosen from the surface.
Make sure that the air lever flap is closed to
obtain proper function.
Door reversibility
To change the opening direction of the door, do these steps:
1. Remove the plug from the power.
2. Remove the ventilation grille. Remove the upper filling and install it on the opposite
side of the grille.
Remove the pedal hole cover and install the cover provided in the accessory bag on
the opposite side.
3. Lay down the appliance back side down on a wooden support.
4. Remove the handle:
Unscrew the handle from the top (A1)
and the bottom (A2) of the door.
Unscrew both of the handle brackets
from the handle rod and re-screw the
handle brackets provided in the handle
kit.
a1 a2
Installation 23
5. Unscrew the hinge (B1) and remove the
cover plate (B2) and the support (B3).
Remove the cover (B4) on the opposite
side and install the support (B3) the
cover plate (B2) and the hinge (B1). Install the cover (B4) on the opposite side.
B1
B2
B3 B4
24 Environmental concerns
6. Unscrew the lower hinge (C1). Move the
pin to the opposite side (C2). Unscrew
and move the pedal to the opposite side
(C3).
Screw on the lower hinge on the opposite side.
7. Tighten the pin with the adjustment
spanner supplied.
8. Install the handle on the opposite side.
9. Raise the appliance and install the ven-
tilation grille.
10. Put the cabinet in position.
WARNING!
Reposition, level the appliance, wait for at least four hours and then connect it to the power socket.
Do a final check to make sure that:
• All screws are tightened.
• The magnetic seal adheres to the cabinet.
• The door opens and closes correctly.
If the ambient temperature is cold (i.e. in Winter), the gasket may not fit perfectly to the
cabinet. In that case, wait for the natural fitting of the gasket.
C2
C3
C1
ENVIRONMENTAL CONCERNS
The symbol on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it should be taken to the appropriate collection point
for the recycling of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of this product,
please contact your local council, your household waste disposal service or the shop where
you purchased the product.
252627
www.aeg.com/shop 855813400-A-522010
Loading...
