AEG-Electrolux S63800KMW0 User Manual

S63800KMW0
REFRIGERATOR USER MANUAL 2
EN
FRIGORIFERO ISTRUZIONI PER L’USO 21
IT
2
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG appliances looking spotless and working perfectly. Along with a wide range of accessories designed and built to the high quality standards you would expect, from specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…
Visit the webshop at: www.aeg-electrolux.com/shop
CONTENTS
Contents
4 Safety information
6 Control panel 10 First use 10 Daily use 12 Helpful hints and tips 13 Care and Cleaning 14 What to do if… 16 Technical data 17 Installation 20 Environmental concerns
3
The following symbols are used in this user manual:
Important information concerning your personal safety and information on how to avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
Safety information
4
SAFETY INFORMATION
In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. Save these instructions and make sure that they remain with the appliance if it is moved or sold, so that everyone using it through its life will be properly informed on appliance use and safety. For the safety of life and property keep the precautions of these user's instructions as the manufacturer is not responsible for damages caused by omission.
Children and vulnerable people safety
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Keep all packaging well away from children. There is risk of suffocation.
• If you are discarding the appliance pull the plug out of the socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent playing children to suffer electric shock or to close themselves into it.
• If this appliance featuring magnetic door seals is to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make that spring lock unusable be­fore you discard the old appliance. This will prevent it from becoming a death trap for a child.
General safety
CAUTION!
Keep ventilation openings clear of obstruction.
• The appliance is intended for keeping foodstuff and/or beverages in a normal house­hold as explained in this instruction booklet.
• Do not use a mechanical device or any artificial means to speed up the thawing process.
• Do not use other electrical appliances (such as ice cream makers) inside of refrigerat­ing appliances, unless they are approved for this purpose by the manufacturer.
• Do not damage the refrigerant circuit.
• The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the ap­pliance, a natural gas with a high level of environmental compatibility, which is never­theless flammable.
During transportation and installation of the appliance, be certain that none of the components of the refrigerant circuit become damaged.
If the refrigerant circuit should become damaged: – avoid open flames and sources of ignition – thoroughly ventilate the room in which the appliance is situated
Safety information
• It is dangerous to alter the specifications or modify this product in any way. Any dam­age to the cord may cause a short-circuit, fire and/or electric shock.
WARNING!
Any electrical component (power cord, plug, compressor) must be replaced by a certified service agent or qualified service personnel.
1. Power cord must not be lengthened.
2. Make sure that the power plug is not squashed or damaged by the back of the
appliance. A squashed or damaged power plug may overheat and cause a fire.
3. Make sure that you can come to the mains plug of the appliance.
4. Do not pull the mains cable.
5. If the power plug socket is loose, do not insert the power plug. There is a risk of
electric shock or fire.
6.
You must not operate the appliance without the lamp cover
1)
of interior lighting.
• This appliance is heavy. Care should be taken when moving it.
• Do not remove nor touch items from the freezer compartment if your hands are damp/ wet, as this could cause skin abrasions or frost/freezer burns.
• Avoid prolonged exposure of the appliance to direct sunlight.
Bulb lamps
2)
used in this appliance are special purpose lamps selected for household
appliances use only. They are not suitable for household room illumination.
Daily use
• Do not put hot pot on the plastic parts in the appliance.
• Do not store flammable gas and liquid in the appliance, because they may explode.
• Appliance's manufacturers storage recommendations should be strictly adhered to. Re­fer to relevant instructions.
5
Care and cleaning
• Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket.
• Do not clean the appliance with metal objects.
• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean the drain. If the drain is blocked, water will collect in the bottom of the appliance.
Installation
For electrical connection carefully follow the instructions given in specific paragraphs.
• Unpack the appliance and check if there are damages on it. Do not connect the appli­ance if it is damaged. Report possible damages immediately to the place you bought it. In that case retain packing.
• It is advisable to wait at least four hours before connecting the appliance to allow the oil to flow back in the compressor.
1) If the lamp cover is foreseen.
2) If the lamp is foreseen.
Control panel
6
• Adequate air circulation should be around the appliance, lacking this leads to overheat­ing. To achieve sufficient ventilation follow the instructions relevant to installation.
• Wherever possible the back of the product should be against a wall to avoid touching or catching warm parts (compressor, condenser) to prevent possible burn.
• The appliance must not be located close to radiators or cookers.
• Make sure that the mains plug is accessible after the installation of the appliance.
Connect to potable water supply only.
3)
Service
• Any electrical work required to do the servicing of the appliance should be carried out by a qualified electrician or competent person.
• This product must be serviced by an authorized Service Centre, and only genuine spare parts must be used.
Environment Protection
This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. The insulation foam contains flammable gases: the appliance shall be disposed according to the applicable regulations to obtain from your local authorities. Avoid damaging the cooling unit, especially at the rear near the heat exchanger. The materials used on this appliance marked by the symbol
are recyclable.
CONTROL PANEL
1 2 3 4 5 6
1 ON/OFF button 2 Mode button 3 OK button 4 Temperature colder button 5 Temperature warmer button
6 Display
It is possible to change predefined sound of buttons to a loudly one by pressing together Mode button and Temperature colder button for some seconds. Change is reversible.
3) If a water connection is foreseen.
Display
7
5 64321
1 Timer function
2 COOLMATIC function
3 Minute Minder function
4 Child Lock function
5 Alarm indicator
6 Temperature indicator
7 Holiday function
Switching on
To switch on the appliance do these steps:
1. Connect the mains plug to the power socket.
2. Press the ON/OFF button if the display is off.
3. The alarm buzzer could operate after few seconds.
To reset the alarm refer to "High temperature alarm".
4. The temperature indicators show the set default temperature. To select a different set temperature refer to "Temperature regulation".
Control panel
7
Switching off
To switch off the appliance do these steps:
1. Press the ON/OFF button for 5 seconds.
2. The display switches off.
3. To disconnect the appliance from the power disconnect the mains plug from the pow-
er socket.
Temperature regulation
The set temperature of the fridge may be adjusted by pressing the temperature button. Set default temperature:
• +5°C for the fridge The temperature indicator shows the set temperature. The set temperature will be reached within 24 hours.
After a power failure the set temperature remains stored.
Minute Minder function
The Minute Minder function is to be used to set an acoustic alarm at the preferred time, useful for example when a recipe requires to cool down a mixture for a certain lenght of time.
Control panel
8
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
The Minute Minder indicator flashes. The Timer shows the set value (30 minutes) for a few seconds.
2. Press the Timer regulator button to change the Timer set value from 1 to 90 minutes.
3. Press the OK button to confirm.
The Minute Minder indicator is shown.
The Timer start to flash (min). At the end of the countdown the Minute Minder indicator flashes and an audible alarm sounds:
1. Switch off the function. To switch off the function:
1. Press the Mode button until the Minute Minder indicator flashes.
2. Press the OK button to confirm.
3. The Minute Minder indicator goes off. It is possible to deactivate the function at any time. It is possible to change the time at any time and before the end by pressing the Tempera­ture colder button and the Temperature warmer button.
Child Lock function
To lock the buttons from unintentional operation select the Child Lock function. To switch on the function:
1. Press the Mode button until the corresponding icon appears.
2. The Child Lock indicator flashes.
3. Press the OK button to confirm.
The Child Lock indicator is shown. To switch off the function:
1. Press the Mode button until the Child Lock indicator flashes.
2. Press the OK button to confirm.
3. The Child Lock indicator goes off.
COOLMATIC function
If you need to insert a large amount of warm food, for example after doing the grocery shopping, we suggest activating the COOLMATIC function to chill the products more rap­idly and to avoid warming the other food which is already in the refrigerator. To switch on the function:
1. Press the Mode button until the corresponding icon appears.
The COOLMATIC indicator flashes.
The fridge temperature indicator shows the set temperature of +2°C .
2. Press the OK button to confirm.
The COOLMATIC indicator is shown. The COOLMATIC function shuts off automatically after approximately 6 hours. To switch off the function before its automatic end:
1. Press the Mode button until the COOLMATIC indicator flashes.
2. Press the OK button to confirm.
3. The COOLMATIC indicator goes off. The function switches off by selecting a different fridge set temperature.
Quick Chill function
The Quick Chill function provide rapid cooling of cans and bottles through cold airstream.
1. Put the cans/bottles on the Quick Chill bottle
holder.
2. Open the air lever (1) towards maximum.
3. Activate COOLMATIC function.
4. The Quick Chill function stops automatically
after approximately 6 hours.
5. When the cooling is finished return the air
lever (1) towards minimum. To cancel the function at any time, press COOL-
MATIC button.
The Quick Chill bottle holder can be removed if not used.
Control panel
9
1
Holiday function
This function allows you to keep the refrigerator closed and empty during a long holiday period without the formation of a bad smell.
The fridge compartment must be empty with holiday function on.
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
The Holiday indicator flashes.
The fridge temperature indicator shows the set temperature.
2. Press the OK button to confirm.
The Holiday indicator is shown. To switch off the function:
1. Press the Mode button until the Holiday indicator flashes.
2. Press the OK button to confirm.
3. The Holiday indicator goes off. The function switches off by selecting a different fridge set temperature.
First use
10
Door open alarm
An acoustic alarm will sound if the door is left open for a few minutes. The door open alarm conditions are indicated by:
• flashing Alarm indicator
• acoustic buzzer When normal conditions are restored (door closed), the alarm will stop. During the alarm, the buzzer can be switched off by pressing any button.
FIRST USE
Cleaning the interior
Before using the appliance for the first time, wash the interior and all internal accesso­ries with lukewarm water and some neutral soap so as to remove the typical smell of a brand-new product, then dry thoroughly.
Do not use detergents or abrasive powders, as these will damage the finish.
DAILY USE
this appliance is sold in France. In accordance with regulations valid in this country it must be provided with a special device (see figure) placed in the lower compartment of the fridge to indicate the coldest zone of it.
Clean Air Control Filter
Your appliance is equipped with a carbon filter behind the air lever flap. The filter purifies the air from unwanted odours in the fridge compartment preserving food quality. On delivery the filter is in a plastic bag. Refer to "Installation of the Clean Air Control filter" for instructions.
Make sure that the air lever flap is closed to obtain proper function.
Movable shelves
The walls of the refrigerator are equipped with a series of runners so that the shelves can be posi­tioned as desired.
Positioning the door shelves
To permit storage of food packages of various sizes, the door shelves can be placed at different heights.
Bottle rack
Place the bottles (with the opening facing front) in the pre-positioned shelf.
If the shelf is positioned horizontally, place only closed bottles.
Daily use
11
This bottle holder shelf can be tilted in order to store previously opened bottles. To obtain this re­sult, pull the shelf up so it can rotate upwards and be placed on the next higher level.
Bottle and can holder
The side of the bottle and can holder is movea­ble to enable a more flexible placement of cans and bottles in front of the grid. To allow the holder to be moved easier when mov­ing sideways, press the shelf backwards.
Helpful hints and tips
12
The bottle support can be pulled out when chill­ing larger bottles.
Removing the bottle and can holder
1. Take out the Quick Chill Shelf with hold-
er from the cabinet
2. To loosen the holder from the shelf,
bend the hooks/brackets that surround
the backside of the shelf.
Quick Chill shelf
The Quick Chill shelf can be placed in one of the upper grooves. To maintain the best perform­ance the shelf should be placed in the second groove from the top.
HELPFUL HINTS AND TIPS
Hints for energy saving
• Do not open the door frequently or leave it open longer than absolutely necessary.
• If the ambient temperature is high and the Temperature Regulator is set to low tem-
perature and the appliance is fully loaded, the compressor may run continuously, caus­ing frost or ice on the evaporator. If this happens, set the Temperature Regulator to­ward warmer settings to allow automatic defrosting and so a saving in electricity con­sumption.
Hints for fresh food refrigeration
To obtain the best performance:
• do not store warm food or evaporating liquids in the refrigerator
• do cover or wrap the food, particularly if it has a strong flavour
• position food so that air can circulate freely around it
Care and Cleaning
Hints for refrigeration
Useful hints: Meat (all types) : wrap in polythene bags and place on the glass shelf above the vegeta­ble drawer. For safety, store in this way only one or two days at the most. Cooked foods, cold dishes, etc..: these should be covered and may be placed on any shelf. Fruit and vegetables: these should be thoroughly cleaned and placed in the special draw­er(s) provided. Butter and cheese: these should be placed in special airtight containers or wrapped in aluminium foil or polythene bags to exclude as much air as possible. Milk bottles: these should have a cap and should be stored in the bottle rack on the door. Bananas, potatoes, onions and garlic, if not packed, must not be kept in the refrigerator.
CARE AND CLEANING
CAUTION!
Unplug the appliance before carrying out any maintenance operation.
This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must therefore only be carried out by authorized technicians.
Replacing the Clean Air Control filter
To get the best performance replace the Clean Air Control filter once every year. New active filters can be purchased from your local dealer. Refer to "Installation of the Clean Air Control filter" for instructions.
13
Periodic cleaning
The equipment has to be cleaned regularly:
• clean the inside and accessories with lukewarm water and some neutral soap.
• regularly check the door seals and wipe clean to ensure they are clean and free from
debris.
• rinse and dry thoroughly. Do not pull, move or damage any pipes and/or cables inside the cabinet.
Never use detergents, abrasive powders, highly perfumed cleaning products or wax pol­ishes to clean the interior as this will damage the surface and leave a strong odour.
Clean the condenser (black grill) and the compressor at the back of the appliance with a brush or a vacuum cleaner. This operation will improve the performance of the appliance and save electricity consumption.
Take care of not to damage the cooling system.
Many proprietary kitchen surface cleaners contain chemicals that can attack/damage the plastics used in this appliance. For this reason it is recommended that the outer casing of this appliance is only cleaned with warm water with a little washing-up liquid added. After cleaning, reconnect the equipment to the mains supply.
What to do if…
14
Defrosting of the refrigerator
Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates. It is important to periodically clean the defrost water drain hole in the middle of the refrigera­tor compartment channel to prevent the water overflowing and dripping onto the food inside. Use the special cleaner provided, which you will find already inserted into the drain hole.
Periods of non-operation
When the appliance is not in use for long periods, take the following precautions:
disconnect the appliance from electricity supply
• remove all food
defrost
4)
and clean the appliance and all accessories
• leave the door/doors ajar to prevent unpleasant smells. If the cabinet will be kept on, ask somebody to check it once in a while to prevent the food inside from spoiling in case of a power failure.
WHAT TO DO IF…
WARNING!
Before troubleshooting, disconnect the mains plug from the mains socket. Only a qualified electrician or competent person must do the troubleshooting that is not in this manual.
There are some sounds during normal use (compressor, refrigerant circulation).
Problem Possible cause Solution
The appliance is noisy
4) If foreseen.
The appliance is not supported properly
Check if the appliance stands sta­ble (all the four feet should be on the floor)
Loading...
+ 30 hidden pages
