FACTORY PARTS CATALOG
REFRIGERATOR
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT22RGJB2 FRT22RGJ 134A black 115
FRT22RGJD2 FRT22RGJ 134A almond 115
FRT22RGJQ2 FRT22RGJ 134A bisque 115
FRT22RGJW2 FRT22RGJ 134A white 115
MARKET
North America
WIRING DIAGRAM - #218663500
OWNER’S GUIDE - # 218971800
SERVICE DATA SHEET - # 218901900
REFRIGERATOR
Model No.
101 Masters Blvd.
Anderson, SC 29624
Publication No.
5995342325
000814
-EN/SERVICE /DJH
357
©2000 White Consolidated Industries, Inc.
All rights reserved
FRT22RGJ
Publication No. FRT22RGJ
5995342325
DOOR
08/00 2
A = FRT22RGJ (FRT22RGJB2)
B = FRT22RGJ (FRT22RGJD2)
C = FRT22RGJ (FRT22RGJQ2)
D = FRT22RGJ (FRT22RGJW2)
POS. NO PART NO DESCRIPTION
1 # 215608925 A - - - Gasket-frzr door,black ,magnetic
1 # 215608915 - B C D Gasket-frzr door,white ,magnetic
2 # 218730616 A - - - Gasket-refr door,black ,magnetic
2 # 218730614 - B C D Gasket-refr door,white ,magnetic
3 218979001 A B C D Door-Refr interior,panel
4 218763647 A B C D Rack-door,24.57" x 2.04"
4A 218763648 A B C D Rack-door,23.57" x 2.04"
4B 218763649 A B C D Rack-door,23.91" x 2.04"
5 218809701 A B C D Support-door rack,LH
5A 218809801 A B C D Support-door rack,RH
7 5303304569 A B C D Door-dairy,12.96" wide ,clear, no graphics
8 218763641 A B C D Rack-door,23.29" x 2.04"
9 215278301 A B C D Panel-inner door,frzr
10 5303299154 A - - - Plug-button,black ,hinge brg hole
10 5303292414 - B - - Plug-button,almond ,hinge brg hole
10 5304416926 - - C - Plug-button,bisque ,hinge brg hole
10 5303292413 ---D Plug-button,white ,hinge brg hole
10A 218696503 A - - - Plug-button,black ,lg closer hole
10A 218696502 - B - - Plug-button,almond ,lg closer hole
10A 218696504 - - C - Plug-button,bisque ,lg closer hole
10A 218696501 ---D Plug-button,white ,lg closer hole
11 5303918080 A - - - Panel-frzr door,black ,w/foam insulatn
11 5303918025 - B - - Panel-frzr door,almond ,w/foam insulatn
11 5303918171 - - C - Panel-frzr door,bisque ,w/foam insulatn
11 5303918024 ---D Panel-frzr door,white ,w/foam insulatn
12 218156540 A - - - Nameplate Assy,black ,with magnet
12 218156539 - B - - Nameplate Assy,almond ,with magnet
12 218156542 - - C - Nameplate Assy,bisque ,with magnet
12 218156538 ---D Nameplate Assy,white ,with magnet
12* 215008615 A - - - Label-nameplate,black
12* 215008614 - B - - Label-nameplate,almond
12* 215008628 - - C - Label-nameplate,bisque
12* 215008613 ---D Label-nameplate,white
12* 218364003 A - - - Frame-nameplate,black
12* 218364002 - B - - Frame-nameplate,almond
12* 218364007 - - C - Frame-nameplate,bisque ,12*
12* 218364001 ---D Frame-nameplate,white
12* 215518000 A B C D Magnet-nameplate
13 5303289522 A B C D Door Stop
13A 215030018 A - - - Door Stop,black ,frzr
13A 215030011 - B - - Door Stop,almond ,frzr
13A 215030019 - - C - Door Stop,bisque ,frzr
13A 215030001 ---D Door Stop,white ,frzr
14 218915703 A - - - Plug-button,black
14 218915702 - B - - Plug-button,almond
14 218915704 - - C - Plug-button,bisque
14 218915701 ---D Plug-button,white
14C 218696603 A - - - Plug-button,black ,sm closer hole
14C 218696602 - B - - Plug-button,almond ,sm closer hole
14C 218696604 - - C - Plug-button,bisque ,sm closer hole
14C 218696601 ---D Plug-button,white ,sm closer hole
15 5303918081 A - - - Panel-refr door,black ,w/foam insulatn
15 5303918023 - B - - Panel-refr door,almond ,w/foam insulatn
15 5303918172 - - C - Panel-refr door,bisque ,w/foam insulatn
15 5303918022 ---D Panel-refr door,white ,w/foam insulatn
18 218668003 A - - - Handle-door,black
18 218668002 - B - - Handle-door,almond
18 218668004 - - C - Handle-door,bisque
18 218668001 ---D Handle-door,white
21A 218578600 A B C D Screw-door stop mtg,phl truss hd ,10-16 x 3/4
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 5303289320 A B C D Bearing-hinge
37 218811638 A - - - Trim-handle,1.74" ,black ,upper
37 218811637 - B - - Trim-handle,almond ,upper ,w/gold band
37 218811639 - - C - Trim-handle,1.74" ,bisque ,upper
37 218811636 ---D Trim-handle,1.74" ,white ,upper
37* 218676003 A B C D Band-decorative,gold
37* 218906701 A B C D Lock-handle trim,stick-on
58 218781100 A B C D Screw,pan head ,8-18 x 0.625
* 5303917276 A B C D Insulation-door,fiberglass ,(bulk)
FRT22RGJ Publication No.
DOOR
5995342325
# = Fast-moving Parts 3 08/00
* = Non-Illustrated Parts
Publication No. FRT22RGJ
5995342325
CABINET
08/00 4
A = FRT22RGJ (FRT22RGJB2)
B = FRT22RGJ (FRT22RGJD2)
C = FRT22RGJ (FRT22RGJQ2)
D = FRT22RGJ (FRT22RGJW2)
POS. NO PART NO DESCRIPTION
1 215937600 A B C D Shroud-evap fan mtg
5 # 5303292398 A B C D Fan Blade
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303292396 A B C D Bracket-motor mtg,front
10 5304416552 A B C D Cover-evap coil
11 5303208309 A B C D Plug-hole,factory test
12 5303292393 A B C D Plug-decorative,ice maker holes
13 # 218661700 A B C D Motor-evap fan
13* 215474201 A B C D Washer,"slinger" ,nylon ,evap fan shaft
14 5303292397 A B C D Bracket-motor mtg,rear
17 5304415955 A B C D Trough-drain
18 218980401 A B C D Support-evap cover,(2)
22 215774918 A - - - Plug-button,black ,upr hinge holes
22 215774911 - B - - Plug-button,almond ,upr hinge holes
22 215774919 - - C - Plug-button,bisque ,upr hinge holes
22 215774901 ---D Plug-button,white ,upr hinge holes
23 215266301 A B C D Tube-drain,w/seal ring
24 5303207353 A B C D Seal Ring,drain tube
25 5303292412 A B C D Spout-drain tube
29 215314301 A B C D Washer,.40 x .75 x .06 ,nylon
29* 218875801 A B C D Washer,nylon ,0.245 ID w/nibs
30 5303289060 A B C D Bracket-lower hinge,RH/LH ,w/hinge pin
30* 218979601 A B C D Tapping Plate,lower hinge
30* 218979701 A B C D Tapping Plate,lower hinge
34 218737000 A B C D Washer-ctr hnge pin
35 218220103 A - - - Bracket-ctr hinge,black
35 218220102 - B - - Bracket-ctr hinge,almond
35 218220104 - - C - Bracket-ctr hinge,bisque
35 218220101 ---D Bracket-ctr hinge,light gray
36 218971101 A B C D Pin-center hinge
37 5303321083 A - - - Trim-cabinet corner,black
37 5303321082 - B - - Trim-cabinet corner,almond
37 5304413167 - - C - Trim-cabinet corner,bisque
37 5303321081 ---D Trim-cabinet corner,white
38 218215244 A - - - Bracket-upper hinge,with closer ,black ,LH
38 218215251 - B - - Bracket-upper hinge,with closer ,almond
38 218215243 - - C D Bracket-upper hinge,with closer ,white ,LH
39 215848000 A B C D Spacer-air channel
40 5303323268 A - - - Cover-upper hinge,black
40 5303318774 - B - - Cover-upper hinge,almond
40 5304414819 - - C - Cover-upper hinge,bisque
40 5303318773 ---D Cover-upper hinge,white
41 5308000039 A B C D Screw,hex washer hd ,8-32CA x 0.500(7),serrat hd
43 218615300 A B C D Roller Assy,front ,(2)
43* 5308017044 A B C D Screw-roller mtg,spcl ind hex hd 5/16-18(23)x7/8
44 218738300 A B C D Roller Assy,rear ,(2)
45 5303001343 A B C D Screw,hex washer head ,8-15A x 0.500
47 218233300 A B C D Channel-shelf mtg,side ,(2)
48 5303292395 A B C D Channel-shelf mtg,center
52 215454600 A B C D Tube-water,ice mold fill ,elbow
52* 215058000 A B C D Plug-wtr inlet tube
58 5308002748 A B C D Screw,hex wshr hd ,8-15A x 0.500 special
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625 ,hng/mullion,thrd forming
60 218362500 A B C D Screw,hex washer head ,8-18AB x 1.250
72 218359612 A - - - Grille/Kickplate,black
72 218359608 - B - - Grille/Kickplate,almond
72 218359617 - - C - Grille/Kickplate,bisque
72 218359604 ---D Grille/Kickplate,white
81 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625,low profile
83 5308000107 A B C D Bracket-connector
89 5303288947 A B C D Cover-machine compt
FRT22RGJ Publication No.
5995342325
CABINET
# = Fast-moving Parts 5 08/00
* = Non-Illustrated Parts
Publication No. FRT22RGJ
5995342325
CABINET
08/00 6
A = FRT22RGJ (FRT22RGJB2)
B = FRT22RGJ (FRT22RGJD2)
C = FRT22RGJ (FRT22RGJQ2)
D = FRT22RGJ (FRT22RGJW2)
POS. NO PART NO DESCRIPTION
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875
93 218362603 A - - - Plug-grille,black
93 218362602 - B - - Plug-grille,almond
93 218362604 - - C - Plug-grille,bisque
93 218362601 ---D Plug-grille,white
94 5303319993 A B C D Cover-air duct
94* 218044800 A B C D Seal-air duct cover
95 218663101 A B C D Gasket-air duct cvr
96 215775900 A B C D Cover-fan access
96 215775901 A B C D Cover-fan access
97 5303289299 A B C D Bracket-IM plug
98 215099718 A - - - Plug-button,black
98 215099711 - B - - Plug-button,almond
98 215099719 - - C - Plug-button,bisque
98 215099701 ---D Plug-button,white
99 5303294246 A B C D Grommet-shelf mtg,1.25" long
99 5303294247 A B C D Grommet-shelf mtg,.69" long
100 5303288973 A B C D Support-pan cover
FRT22RGJ Publication No.
5995342325
CABINET
* 5303321321 A - - - Paint,touch-up ,black
* 5303305325 - B - - Paint,touch-up ,almond
* 5304414035 - - C - Paint,touch-up ,bisque
* 5303305324 ---D Paint,touch-up ,white
* 5308016571 A B C D Plug-button,cab liner holes
# = Fast-moving Parts 7 08/00
* = Non-Illustrated Parts
Publication No. FRT22RGJ
5995342325
SHELVES
08/00 8
A = FRT22RGJ (FRT22RGJB2)
B = FRT22RGJ (FRT22RGJD2)
C = FRT22RGJ (FRT22RGJQ2)
D = FRT22RGJ (FRT22RGJW2)
POS. NO PART NO DESCRIPTION
1 218652310 A - - - Mullion,black
5 # 218752300 A B C D Heater-mullion
6 218845601 A B C D Tapping Plate,mullion mtg ,(2)
7 218907501 A B C D Top Panel-refr,HASC
8 218909707 A B C D Divider,styrofoam ,w/foil tape
8* # 218965501 A B C D Harness-wiring,main
9 215058300 A B C D Bottom Panel-frzr
10 215667501 A B C D Tray-ice,plastic
11 5304409141 A B C D Shelf-freezer,w/trim
11* 5303299664 A B C D Spacer-shelf
12 218634902 A B C D Deflector-air,"paddle"
12* 215363801 A B C D Spacer-air deflectr
12* 215363901 A B C D Washer-air deflectr
13 218629900 A B C D Cover-air deflector
13* 215935700 A B C D Nut-anchor
14 # 5309918806 A B C D Switch-light/lamp
15 5303001179 A B C D Light Bulb/Lamp,40 W
16A 218906801 A B C D Socket-light/lamp
17 215932906 A B C D Control Box
17* 5308016567 A B C D Nut-anchor
18 5304414917 A B C D Knob-temp control,refr
18A 5304414918 A B C D Knob-temp control,(damper)
19 # 5303286905 A B C D Switch-energy saver,rocker type
21 # 5304402184 A B C D Control-temperature
21* 5303001260 A B C D Screw-control mtg,pan hd ,6-32 x 0.250
22 218660701 A B C D Tube,insulator ,plastic ,on temp sensor
23 # 215846606 A B C D Timer-defrost,60 Hz ,120 V ,10 hour/30 min
23* 215277000 A B C D Cover-defrost timer,top
23* 5303001259 A B C D Screw-timer mtg,pan hd ,6-20 x 0.438
23* 5303289058 A B C D Shield-defrost timr,btm
24 215406138 A B C D Shelf-"Spill-Safe",fixed ,(3)
25 215216654 A B C D Cover-crisper pan,with beam ,trim,humid cont
26 5303292386 A B C D Pan-crisper,(2)
28 215341200 A B C D End Cap-shelf,protector
31 5303292388 A B C D Pan-meat
34 5303212918 A B C D Container-ice
42 215002301 A B C D Hanger-pan/tray,LH
42* 215002401 A B C D Hanger-pan/tray,RH
45 5303001343 A B C D Screw,hex washer head ,8-15A x 0.500
46 5304405084 A B C D Front-crisper pan
47 218498180 A B C D Insert-pan cover
59 218188000 A B C D Screw,pan hd,10-32x.625hinge/mullion,thread forming
67 5304405086 A B C D Front-meat pan
77 5303001216 A B C D Washer-nylon,3/16 x 5/8 OD
81 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625 ,low profile
120 218019201 A B C D Seal-refr top
121 215364001 A B C D Cable-damper contrl
121* 215209400 A B C D Nut,push-on ,damper cable
122 218561201 A B C D Block-air deflector,RH
122 218561203 A B C D Block-air deflector,LH
123 215005100 A B C D Screw-roller/hanger,8-10 x 0.438
145 218660800 A B C D Clip,plastic ,temp sensor mtg ,snap-in
FRT22RGJ Publication No.
5995342325
SHELVES
* 215339100 A B C D Seal-divider throat
* 215359900 A B C D Seal-divider front
# = Fast-moving Parts 9 08/00
* = Non-Illustrated Parts
Publication No. FRT22RGJ
5995342325
SYSTEM
08/00 10
A = FRT22RGJ (FRT22RGJB2)
B = FRT22RGJ (FRT22RGJD2)
C = FRT22RGJ (FRT22RGJQ2)
D = FRT22RGJ (FRT22RGJW2)
POS. NO PART NO DESCRIPTION
1 218787700 A B C D Condenser
1* 5303208866 A B C D Spacer-cond tube,black
1* 5303289026 A B C D Spacer-tube
2 5303289029 A B C D Clip-cond mtg,(4)
4 # 218944001 A B C D Drier-filter,R134a System
5 # 218965501 A B C D Harness-wiring,main
6 # 218965901 A B C D Wiring Harness,compressor
7 215459201 A B C D Cord-electric power
8 218803400 A B C D Cover-wiring
13 # 218168602 A B C D Heat Exchanger,suction line
14 # 5317842502 A B C D Heater-defrost
15 # 218956001 A B C D Evaporator,bundy
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 5304415939 A B C D Insulator-evap,plastic
18 218979801 A B C D Block-evap coil,styrofoam insul ,RH
19 218631200 A B C D Tube,rubber
20 218979501 A B C D Block-evap coil,styrofoam insul ,LH
21 # 218969902 A B C D Thermostat-defrost
22 218811100 A B C D Base-compressor mtg,(drain pan)
23 218513300 A B C D Grommet-compr mtg,(4)
25 218773500 A B C D Screw-compr mtg,hex washer hd, 10Bx11/4
29 # 218374517 A B C D Compressor,R134a ,w/o electricals
30 # 218721101 A B C D Starter/Overload Assy
32 218740800 A B C D Clamp,elec cont mtg ,compressor
41 5308000039 A B C D Screw,hex wash hd,8-32CA x 0.5 ,(7),serrat hd
43 215174700 A B C D Clamp-service cord,strain relief ,galv steel
43* 5303001199 A B C D Clamp-wiring harness,strain relief, galv steel
43* 5308000133 A B C D Clamp,nylon ,.625 ID
45 5303001343 A B C D Screw,hex washer head ,8-15A x 0.500
54 5303289027 A B C D Rail-cabinet base,rear
54A 5303289311 A B C D Rail-compr support
54B 5303289292 A B C D Rail-cabinet base,front
55 # 218909901 A B C D Capacitor-run,220 VAC ,15 microfarad
55* 218897001 A B C D Screw,hex washer head ,8-32 x 1/4
56 218769300 A B C D Insert-compressor mtg
57 218247300 A B C D Clip-wiring harness
58 215004600 A B C D Screw-cond fan mtr,hx serr wshr hd, 8-36 x 7/16,(2)
59 5303289031 A B C D Shroud-cond fan mtr
59* 215226700 A B C D Seal-foam,cond fan shroud
60 # 215501901 A B C D Motor-condenser fan
61 5303289032 A B C D Blade-cond fan
61* 215004700 A B C D Nut,speed
61* 215004800 A B C D Grommet-silencer
FRT22RGJ Publication No.
5995342325
SYSTEM
* 5303917214 A B C D Hot Tube Repair Kit,Service
# = Fast-moving Parts 11 08/00
* = Non-Illustrated Parts
Publication No. FRT22RGJ
5995342325
WIRING SCHEMATIC
08/00 12
FRT22RGJ Publication No.
5995342325
WIRING DIAGRAM
# = Fast-moving Parts 13 08/00
* = Non-Illustrated Parts
Loading...
