AEG-Electrolux FRIGTTW309000856EN User Manual

OWNER’S GUIDE

READ AND SAVE THESE INSTRUCTIONS

THRU-THE-WALL

AIR CONDITIONER

ELECTRONIC CONTROL

P/N 309000856 (11/03)

ROOM AIR CONDITIONER WARRANTY

Your product is protected by this warranty

Your appliance is warranted by Electrolux. Electrolux has authorized Frigidaire Consumer Services and their authorized servicers to perform service under this warranty. Electrolux authorizes no one else to change or add to any of these obligations under this warranty. Any obligations for service and parts under this warranty must be performed by Frigidaire Consumer Services or an authorized Frigidaire servicer.

WARRANTY FRIGIDAIRE, THROUGH ITS AUTHORIZED THE CONSUMER WILL BE

PERIOD SERVICERS, WILL: RESPONSIBLE FOR:

FULL ONE-YEAR WARRANTY

One year from original purchase date.

Pay all costs for repairing or replacing parts of this appliance which prove to be defective in materials or workmanship.

Costs of service calls that are listed under NOR-

MAL RESPONSIBILITIES OF THE CONSUMER.*

LIMITED 2ND-5TH YEAR WARRANTY (Sealed System)

Second through fifth years from original purchase date.

Repair or replace any parts in the Sealed Refrigeration System (compressor, condenser, evaporator and tubing) proves to be defective in materials or workmanship.

Diagnostic costs and any removal, transportation and reinstallation costs which are required because of service. Costs for labor , parts and transportation other than with respect to the Sealed Refrigeration System.

LIMITED WARRANTY (Applicable to the State of Alaska)

Time periods listed above. All of the provisions of the full and limited warranties above

and the exclusions listed below apply.

Costs of the technician’s travel to the home and any costs for pick up and delivery of the appliance required because of service.

*NORMAL RESPONSIBILITIES OF THE CONSUMER

This warranty applies only to products in ordinary household use, and the consumer is responsible for the items listed below.

1. Proper use of the appliance in accordance with instructions provided with the product.

2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in accordance with all local plumbing, electrical and/or gas codes.

3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose connections or defects in house wiring.

4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are not a part of the appliance when it was shipped from the factory.

5. Damages to finish after installation.

6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).

EXCLUSIONS This warranty does not cover the following:

1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.

Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you.

2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in ordinary household use. The consumer shall pay for such service calls.

3. Damages caused by services performed by persons other than authorized Frigidaire servicers; use of parts other than Frigidaire Genuine Renewal Parts; obtained from persons other than such servicers; or external causes such as abuse, misuse, inadequate power supply or acts of God.

4. Products with original serial numbers that have been removed or altered and cannot be readily determined.

IF YOU NEED SERVICE Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the bill establishes the warranty period

should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This written warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under this warranty must be obtained by following these steps, in order:

1. Contact Frigidaire Consumer Services or an authorized Frigidaire servicer.

2. If there is a question as to where to obtain service, contact our Consumer Relations Department at:

Frigidaire Company P.O. Box 212378 Augusta, GA 30917

800-444-4944

Product features or specifications as described or illustrated are subject to change without notice. All warranties are made by Electrolux. This warranty applies only in the 50 states of the U.S.A., Puerto Rico and Canada.

Product Registration

Record Your Model and Serial Numbers

Record in the space provided below the model and serial numbers. On most models, the serial plate is located on the outside of the cabinet. On some models, remove the filter and look at the bottom edge of the air conditioner behind the front grille for the model and serial numbers. Reading these numbers may be easier by using a flashlight or by removing the cabinet front as instructed under “Care and Cleaning.”

Model No. ____________________________________________________________

Serial No. _____________________________________________________________

The self-addressed PRODUCT REGISTRATION CARD should be filled in completely, signed and returned to the Frigidaire Company.

Contents

2Warranty 3Product Registration 3Normal Sounds 4 Important Safety Instructions 4 Energy Saving Ideas 5 Using Air Conditioner 5-10 Air Conditioner Features 10 Care and Cleaning 11 Avoid Service Checklist

NOTE: This Owner’s Guide provides specific operating instructions for your model. Use the room air conditioner only as instructed in this Owner’s Guide. These instructions are not meant to cover every possible condition and situation that may occur. Common sense and caution must be practiced when installing, operating, and maintaining any appliance.

Normal Sounds

High Pitched Chatter

Today’s high efficient compressors may have a high pitched chatter during the cooling cycle.

Vibration

Unit may vibrate and make noise because of poor wall or window construction or incorrect installation.

Pinging or Swishing

Droplets of water hitting condenser during normal operation may cause “pinging or swishing” sounds.

Gurgle/Hiss

“Gurgling or hissing” noise may be heard due to refrigerant passing through evaporation during normal operation.

Sound of Rushing Air

At the front of the unit, you may hear the sound of rushing air being moved by the fan.

Important Safety Instructions

Read all instructions before using this air conditioner.

For Your Safety

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Read product labels for flammability and other warnings.

Prevent Accidents

To reduce the risk of fire, electrical shock, or injury to persons when using your air conditioner, follow basic precautions, including the following:

• Be sure the electrical service is adequate for the model you have chosen. This information can be found on the serial plate, which is located either on the side of the cabinet or behind the grille.

• If the air conditioner is to be installed in a window, you will probably want to clean both sides of the glass first. If the window is a triple-track type with a screen panel included, remove the screen completely before installation.

• Be sure the air conditioner has been securely and correctly installed according to the separate installation instructions provided with this manual. Save this manual and the installation instructions for possible future use in removing or reinstalling this unit.

• When handling the air conditioner , be car eful to avoid cuts fr om sharp metal fins on front and rear coils.

Electrical Information

The complete electrical rating of your new room air conditioner is stated on the serial plate. Refer to the rating when checking the electrical requirements.

• Be sure the air conditioner is properly grounded. To minimize shock and fire hazards, proper grounding is important. The power cord is equipped with a three-prong grounding plug for protection against shock hazards.

•Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you intend to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a qualified electrician install the proper receptacle.

• Do not run air conditioner with outside protective cover in place. This could result in mechanical damage within the air conditioner.

•Do not use an extension cord or an adapter plug.

Energy Saving Ideas

• Do not block air flow inside with blinds, curtains or furniture; or outside with shrubs, enclosures, or other buildings.

• The capacity of the room air conditioner must fit the room size for efficient and satisfactory operation.

• Install the room air conditioner on the shady side of your home. A window that faces north is best because it is shaded most of the day.

• Close the fireplace damper, floor and wall registers so cool air does not escape up the chimney and into the duct work.

• Keep blinds and drapes in other windows closed during the sunniest part of the day.

• Clean the air filter as recommended in the section “Care and Cleaning.”

•Proper insulation and weather stripping in your home will help keep warm air out and cool air in.

• External house shading with trees, plants or awnings will help reduce the air conditioner’s work load.

• Operate heat producing appliances such as ranges, washers, dryers and dishwashers during the coolest part of the day.

Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove any prong from the power cord.

Grounding type wall receptacle

Power supply cord with 3-prong grounding plug

Do not, under any circumstances, cut, remove, or bypass the grounding prong.
