FAVORIT 43470 I
Dishwasher
User information
PERFEKT IN FORM UND FUNKTION
Dear customer,
Please read this User Information carefully and keep it to refer to at a
later date.
Pass it on to any subsequent owner of the appliance.
The following symbols are used in the text:
Safety instructions
Warning! Notes that concern your personal safety.
Attention! Notes that show how to avoid damage to the appliance.
Useful tips and hints
Environmental information
Your dishwasher has the new washing system ”IMPULSE WASHING”.
With this dishwashing system the motor speed and spray pressure
are varied during the wash cycle to achieve better cleaning of the
dishes. It is for this reason that the noise level varies during the
dishwashing cycle.
2
Contents
CONTENTS
Operating instructions 4
Safety 4
Appliance features 5
Control panel 6
Prior to using for the first time 7
Setting the water softener 7
Adding special salt 9
Adding rinse aid 10
Activating/deactivating the inflow of rinse aid 11
In daily use 12
Loading cutlery and dishes 12
Adjusting the height of the upper basket 15
Adding detergent 16
Using 3 in 1 detergent tablets 17
Selecting the programme (Programme Table) 18
Starting a programme 19
Switching off the dishwasher 20
Care and cleaning 21
What to do when... 22
Technical data 25
Notes for Test Institutes 26
Installation and connection instructions 27
Safety information for the installation 27
Installing the dishwasher 28
Connecting the dishwasher 29
Electrical connection 31
Service 32
3
Operating instructions
OPERATING INSTRUCTIONS
Safety
Prior to using for the first time
•Follow the ”Instructions for installation and connection”.
Correct use
•The dishwasher is only meant for washing domestic dishes.
•Additions or modifications to the dishwasher are not permitted.
•Use only special salt, detergent and rinse aid suitable for domestic
dishwashers.
•Do not put any solvents in the dishwasher. This could cause an
explosion.
Child safety
•Keep packaging away from children. There is a risk of suffocation.
•Children often do not recognise the hazards associated with
electrical appliances. Don’t allow children to use the dishwasher
unsupervised.
•Make sure that children and pets don’t climb into the dishwasher.
Could endanger life!
•Dishwasher detergents can cause chemical burns to the eyes, mouth
and throat. Could endanger life! Comply with the safety instructions of
the dishwasher detergent manufacturer.
•The water in the dishwater is not for drinking. There is a risk of
chemical burns.
General safety
•Repairs to the dishwasher are only to be carried out by qualified
service engineers.
•When the dishwasher is not being used, switch it off and close the
water tap.
•Never unplug the appliance by pulling on the cable. Always pull the
plug.
•Never sit or stand on the open door.
• If the dishwasher is located in a room where there may be a frost,
remove the connection hose from the tap after each use of the
dishwasher.
4
Appliance features
Water hardness switch
Container for
special salt
Operating instructions
Upper spray arm
Lower spray arm
Filters
Dispenser for
detergent
Dispenser for
rinse aid
Rating plate
5
Operating instructions
Control panel
Programme
sequence indicators
Control
indicators
Select 3 in 1
function
ON / OFF
button
Programme
buttons
1 2 3
Function
buttons
The ON/OFF button is used to turn the dishwasher on and off.
The Programme buttons are used to select the desired dishwashing
cycle.
Function buttons: In addition to the dishwashing cycle and/or start
delay selected, the following functions can also be set with the help of
these buttons:
Function button 1
Set the water softener
Function button 2
Function button 3
Activate/deactivate rinse aid inflow
- not programmed -
The programme Sequence Indicators always indicates the current part
of the sequence.
The Control Indicators have the following meanings:
1
SALZ
KLARSPÜLER
1
Refill with special salt
Refill with rinse aid
1)The indicators are never illuminated while a dishwashing cycle is
running.
6
Prior to using for the first time
1. Set the water softener
2. Fill up with special salt for water softener
3. Fill up with rinse aid
If you use 3 in 1 detergent, do the following:
– Switch on the dishwasher, press the 3 in 1 button. The indicator
lamp illuminates, the 3 in 1 function is selected. As a result
– there is no need to fill up with special salt or rinse aid.
– there is no need to set the water softener.
– there is no need to activate/deactivate the rinse aid inflow.
– Before the start of the dishwashing cycle put 3 in 1 detergent in
the detergent dispenser.
– Read the section “Using 3 in 1 detergent”.
Setting the water softener
To avoid scale deposits on the dishes and in the dishwasher, the
dishes must be washed with soft water, i.e. water with a low lime
content. The water softener must be set according to the table to
the water hardness in the area where you live. Your local water
company will be able to give you information about the water
hardness in your area.
The dishwasher must be switched off. The water softener must be
set manually and electronically:
Setting manually:
1.Open the dishwasher door.
2.Remove the lower basket from
the dishwasher.
3.Turn the hardness range switch to 1
or 2 (see table).
Operating instructions
AA07
7
Operating instructions
Setting electronically:
1. Press the ON/OFF button.
If indicators other than the ON/OFF button are lit, a programme
has been selected. The programme must be cancelled:
Press function buttons 2 and 3 simultaneously for approx. 2 seconds.
All other indicators will go out.
2. Press function buttons 2 and 3 simultaneously and keep them
pressed. The LED indicators for function buttons 1 to 3 will flash.
3. Press function button 1 again.
The LED indicator for function button 1 will flash, at the same time
the indicator light ENDE starts to flash.
The current level is indicated by the number of flashes of the
indicator light ENDE.
4. Pressing function button 1 increases the hardness setting by 1.
(Exception: hardness setting 1 follows hardness setting 10).
5. When the hardness setting is correct, press the ON/OFF button.
The hardness setting is now saved.
If the water softener is set electronically to “1”, this switches off the
control indicator for special salt.
Water hardness
1
in °d
51 - 70
43 - 50
37 - 42
29 - 36
23 - 28
19 - 22
15 - 18
11 - 14 1,9 - 2,5 II
4 - 10 0,7 - 1,8 I/II
unter 4 unter 0,7 I
1) (°d) German degree, measure of water hardness
2) (mmol/l) millimol per litre, international unit for water hardness
*) factory setting
in mmol/l
9,0 - 12,5
7,6 - 8,9
6,5 - 7,5
5,1 - 6,4
4,0 - 5,0
3,3 - 3,9
2,6 - 3,2
2
Range
Adjusting the hardness
Manual
IV
III
*2
1
setting
Electronic
10
9
8
7
6
5
4*
3
2
1
no salt
necessary
Number of
flashes
10
9
8
7
6
5
4
3
2
1
8
Operating instructions
Adding special salt
Only use special salt suitable for domestic dishwashers.
If you don’t use 3 in 1 detergent add special salt:
-Before using the dishwasher for the first time.
-When the indicator for special salt is illuminated on the control panel.
1. Open the door and remove the lower
basket.
2. Screw open the lid on the salt
dispenser by turning it anticlockwise.
3. Only when using the dishwasher
for the first time:
Fill the salt dispenser with water.
4. Place the funnel (supplied) over the
dispenser opening.
SR14
Fill the dispenser with special salt;
the capacity of the dispenser is
approx. 1.0-1.5 kg, depending on the size of the grains. Do not
overfill the dispenser.
If water overflows when filling up with special salt, this is completely
harmless.
SALE
ZO
SALT
UT
SALZ
SEL
5. Clean away any salt remnants from the dispenser opening.
6. Screw the lid back on in a clockwise direction.
7. Run a dishwashing cycle after filling the salt dispenser with
special salt. This will wash away salt water and any salt crystals that
have been spilt.
Depending on the size of the salt grains, it can take several hours
for the salt to dissolve in the water and for the SALT indicator to go
out.
9
Operating instructions
Adding rinse aid
With rinse aid the rinsing water drains away better and so you get
smear-free, gleaming dishes and clear glasses.
Only use special rinse aid for dishwashers and no other liquid
detergents.
If you don’t use 3 in 1 detergent add rinse aid:
-Before using the dishwasher for the first time.
-When the indicator for rinse aid is illuminated on the control panel.
1. Open the door. The rinse aid
compartment is located on the
inside of the dishwasher door.
2. Press the r elease button on the rinse
aid compartment.
3. Open the cover.
4. Pour rinse aid in slowly right up
to the broken “max” line;
this corresponds to a volume of
approx. 140 ml when full.
5. Press the lid shut until it clicks
into place.
6. Wipe up any spilt rinse aid with a
cloth. Otherwise too much foam
will be formed when rinsing.
BR17
10
BR14
Setting the amount of rinse
aid required
Only change the amount dispensed, if smears, milky spots or dried on
water spots can be seen on glasses and dishes. (See section “If wash
results are not satisfactory”). The dosage can be set from 1-6. The
dosage is set to “4” in the factory.
Operating instructions
1. Open the door of the dishwasher.
2. Press the r elease button on the
rinse aid compartment.
3. Open the cover.
4. Set the dosage level.
5. Press the lid shut until it clicks
into place.
6. If rinse aid has leaked out, wipe it
away with a cloth.
BR09
Activating/deactivating the inflow of rinse aid
If you press 3 in 1 button, you don’t need to deactivate the inflow
of rinse aid.
When the inflow of rinse aid has been deactivated, the rinse aid
indicator light on the control panel is automatically deactivated.
1. Press the ON/OFF button. The ON/OFF indicator light illuminates.
If other push button indicator lights are on, this means that a wash
programme has been selected. The programme must be cancelled:
press simultaneously the function push buttons 2 and 3 for approx.
2 seconds. All other indicators will turn off.
2. Press simultaneously function push buttons 2 and 3 until the
indicator lights of the function push buttons 1 to 3 start flashing.
3. Press the function push button 2, the indicator lights of function
push buttons 1 and 3 turn off while the indicator light of the
function push button 2 goes on flashing, at the same time the
indicator light ENDE illuminates indicating that the inflow of rinse
aid is active.
4. To deactivate the inflow of rinse aid, press the function push button
2 again, the indicator light ENDE turns off, indicating that the
inflow of rinse aid has been deactivated.
5. To memorise the operation, switch off the dishwasher by pressing
the ON/OFF push button or wait about 60 seconds after which the
dishwasher will automatically return to setting mode.
To activate the inflow of rinse aid follow the above instructions
until the indicator light ENDE illuminates.
11
Operating instructions
In daily use
Loading cutlery and dishes
Sponges, cleaning cloths and any other objects that can absorb water
must not be washed in the dishwasher. Plastic and Teflon-coated dishes
tend to retain water droplets. These dishes therefore do not dry as well
as china and stainless steel.
For washing in the dishwasher, the following cutlery/dishes
are not suitable:
•Cutlery with wooden, horn,
china or mother-of-pearl handles
•Plastic items that are not heat
resistant
•Older cutlery with cement
that is sensitive to temperature
•Dishes or cutlery with glued parts
•Pewter or copper items
•Lead crystal glass
•Steel items that rust
•Wooden boards/platters
•Items made from synthetic materials
•Only wash stoneware in the dishwasher if it
is specifically marked by the manufacturer
as being dishwasher-safe.
•Glazed patterns may fade if washed very
frequently in the dishwasher.
•Silver and aluminium parts have a tendency
to discolour when washed. Food remains,
e.g. egg white, egg yolk and mustard often
cause discolouration and staining on silver.
Therefore always clean food residues from
silver immediately, if it is not to be washed
straight after use.
•Some types of glass can become dull after a
large number of washes.
are of limited suitability:
• Before loading the dishes, you should:
- Remove the worst of the food residues.
- Soak pans with burnt on food residues.
• When loading the dishes and cutlery, please note:
- Dishes and cutlery must not impede the rotation of the spray arms.
- Load hollow items such as cups, glasses, pans, etc. with the
opening downwards so that water cannot collect in them
- Dishes and items of cutlery must not lie inside one another or
cover one another
- To avoid damage to glasses, they must not touch one another
- Lay small objects in the cutlery basket
12
Operating instructions
Cutlery basket
Place knives, forks and spoons in the cutlery basket with their handles
pointing downwards.
Arrange cutlery loosely and distribute it in all compartments so that
each individual article has good contact with washing water. Also do
not arrange spoons and forks with their dirty side in contact with each
other.
Important! Exceptionally long cutlery, such as soup ladles, kitchen
knives, or the like, may obstruct the upper spray arm. Such cutlery can
be placed in the upper basket.
To unload your dishwasher more easily, you can take the cutlery basket
out of the lower basket and unfold it. this makes it easier to remove
small pieces of cutlery.
Important note! To prevent the full cutlery basket from inadvertently
unfolding when being taken out, place your hand right round the twopiece handle and hold it firmly.
1. Place the cutlery basket on a firm support (table, worktop) and
unfold both handle parts.
2. After unloading, fold back both handle parts.
UI25
UI20
Long bladed knives stored in an upright position are a potential
hazard.
Long and/or sharp items of cutlery such as carving knives must be
positioned horizontally in the upper basket.
Take care when loading or unloading sharp items such as knives.
13
Operating instructions
The lower basket
Load larger and heavily soiled dishes in the lower basket.
UI12
UI51
The upper basket
The upper basket is designed for plates (dessert plates, saucers, dinner
plates up to 24 cm in diameter), salad bowls, cups and glasses; these
should be arranged as shown in the pictures.
Glasses with long stems can be placed upside-down in the raised cupracks.
The cup-rack on the left folds upwards to increase your loading
flexibility.
Arrange items on and underneath the fold-down cup racks so that
water can reach all surfaces.
Light items (plastic bowls etc.) must be loaded in the upper basket and
arranged so they do not move.
14
US75
US74
Operating instructions
Before closing the door, ensure that the spray arms can rotate
freely.
Adjusting the height of the upper basket
If washing very large plates you can load them in the lower basket
after moving the upper basket to the higher position.
Maximum height of the dishes in:
upper basket lower basket
With upper basket raised 20 cm 31 cm
With upper basket lowered 24 cm 27 cm
To move to the higher position proceed as follows:
1. Move the front runner stops (A) of the upper basket outwards and
slide the basket out.
2. Refit the basket in the higher position and replace the stops (A) in
their original position.
When the basket is in the heigher
position you will not be able to
use the cup rack(s).
RC01
After loading your machine always close the door, as an open door
can be a hazard.
15
Operating instructions
Adding detergent
The detergent must be added before the programme starts.
Only use dishwasher detergent.
Follow the manufacturer’s instructions with regard to dosing and
storage.
The detergent compartment is
located on the inside of the door.
1. If the lid is closed:
Press the release button.
The lid will spring open.
2. Place the detergent in the
detergent dispenser. The markings
indicate the dosing levels:
”20”/”30” corresponds to approx.
20/30 ml of detergent.
3. Close the lid and press until it
locks into place.
In the case of very heavily soiled
dishes, fill the adjoining
compartment (1) with additional
detergent. This detergent starts to
act with the pre-rinse.
DE24
Concentrated detergent
Based on their chemical composition, dishwasher detergents can be
split into two basic types:
- conventional, alkaline detergents with caustic components.
- low alkaline concentrated deter gents with natural enzymes.
The use of 50°C washing programmes in conjunction with
concentrated detergents reduces pollution and is good for your
dishes; these wash programmes are specially matched to the dirtdissolving properties of the enzymes in the concentrated detergent.
For this reason 50°C wash programmes in which concentrated
detergents are used can achieve the same results that can otherwise
only be achieved using 65°C programmes.
16
Detergent tablets
Detergent tablets of different brands dissolve at different speeds.
For this reason some detergent tablets cannot dissolve and develop
their full cleaning power during short programmes. Therefore please
use long programmes when using detergent tablets, to ensure the
complete removal of detergent residuals.
Using 3 in 1 detergent tablets
These products are detergents with a combined cleaning, rinsing
and salt function.
1. Check whether they are suitable for your water hardness.
Follow the manufacturer’s instructions.
2. Place just the detergent in the detergent dispenser.
If you want to stop using 3 in 1 products, please do the following:
• Fill up the dispensers for salt and rinse aid.
• Switch the water softener to the highest setting and perform up
to three normal cycles without loading any dishes.
• Then set the water softener to the water har dness in your ar ea.
Operating instructions
17
Operating instructions
Selecting the programme (Programme Table)
Final rinse
• •
Consumption
values
Drying
Length (minutes)
113
1,60
bis
bis
127
1,80
25
0,70
bis
bis
30
0,80
160
0,75
bis
bis
170
0,80
Programme
sequence
Cycle
INTENSIVE
CARE 70°
30 MIN. (65°)
ENERGIE
SPAREN
(50°)
(1) The consumption values were obtained under standardised conditions. They depend on how
(2) In the Intensiv wash programme an additional programme has been integrated which thoroughly
(3) Test programme for Test Institutes.
2
3
full the baskets for the dishes are. Variations are therefore possible in practice.
disinfects items such as baby bottles and jam jars. In order to achieve this, in the final wash cycle
the temperature is kept at 68°C for at least 10 minutes.
Suitable
for
Dinner service
and cookware
Dishes excluding
saucepans
Dinner service
and cookware
temperaturesensitive
crockery
Type of
soiling
heavily soiled,
dried on food remains,
in particular protein
and starch
just used, lightly to
normally soiled
normally soiled
Pre-rinse
Main wash
Intermediate
• •
•
2x
- • - • -
• • • • •
1
Energy (kWh)
Water (litres)
19
bis
21
7
bis
8
12
bis
13
18
Operating instructions
Starting a programme
1. Check that the dishes and cutlery are stacked in the dishwasher in
such a way that the spray arms are free to rotate.
2. Turn on the tap fully.
3. Close the door
4. Press the ON/OFF button.
5. Select the desired programme.
The programme indicator and the respective stages of the
programme sequence indicators will be illuminated.
The selected programme will begin after approximately 2 seconds.
The current stage of the programme is always shown by the
programme sequence indicators.
Interrupting or cancelling a programme
Only interrupt a programme that is in progress if it is
absolutely necessary.
Interrupting the wash programme by opening the dishwasher door
Hot steam may escape when the door is opened. There is a risk of
scalding.
1. Open the door carefully. The programme will stop.
2. Close the door. The programme will continue.
Cancelling the programme
1. Press function buttons 2 and 3 for approx. 2 seconds and keep them
pressed. The programme display for the current programme will flash
for several seconds and then go out.
2. Release the function buttons.
The programme has been cancelled.
3. Switch off the dishwasher by pressing the ON/OFF button.
19
Operating instructions
Switching off the dishwasher
Only switch the dishwasher off when the end of programme phase
indicator light (ENDE) will illuminate.
1. Press the ON/OFF button. All display indicators will go out.
2. Turn off the tap.
Carefully open the door. Hot steam may escape.
Hot dishes are sensitive to knocks. Therefore leave the dishes to cool
for about 15 minutes before removing them. Y ou also get a better
drying result.
Removing the dishes
It is normal for the inner door and the dispensers to be damp.
• Empty the lower basket first, then the upper basket. This way you
avoid dripping water in the upper basket onto dishes in the lower
basket.
20
Care and cleaning
Do not use furniture care products or aggressive cleaners.
• When necessary, clean the dishwasher’s controls with a soft cloth
and clean warm water only.
• Occasionally check the internal dispensers, door seal, and water
inlet for soiling, and clean them if necessary.
Cleaning the filters
The filters must be regularly checked
and cleaned. Dirty filters will spoil the
wash results.
1. Open the door and remove the lower
basket.
2. Turn the handle about 1/4 of a turn
anticlockwise(A) and remove the filter
system(B).
Operating instructions
3. Take hold of the coarse and fine
filters (1/2) by the handle and remove
them from the micro-filter (3).
4. Clean all filters thoroughly under
running water.
5. Remove the flat filter (4) from the
base of the washing compartment
and clean both surfaces thoroughly.
6. Re-insert the flat filter.
7. Place the coarse and fine filters in the
micro-filter and press together.
8. Insert the filter system in place and
lock it by turning the handle
clockwise as far as it will go. Ensure
that the flat filter does not protrude
above the base of the washing
compartment.
Under no circumstances may the
dishwasher be used without its filters.
MA44
21
Operating instructions
What to do when...
Remedying minor faults.
If any of the indicators in the control panel, as listed in the table
below, are flashing or are illuminated, you can probably rectify the
foult yourself.
After remedying the error that is flashing in the first or second
rhythm in the programme progress display, press the button of the
selected programme. The programme will continue.
In the fault is displayed again, please contact your local Service Force
Centre and inform them of the fault code.
Malfunction
The indicator for the
selected programme is
flashing. In the
programme sequence
indicators ENDE is
flashing in the following
rhythm: one short flash
with approx. 5 seconds
pause in between.
There is no water
running into the
dishwasher.
Possible cause Remedy
The tap is blocked or
furred with lime-scale.
The tap is turned off.
The filter (where present) in
the threaded hose fitting at
the water inlet valve is
blocked
Filters in the base of the
washing compartment are
blocked.
The water inlet hose has not
been correctly laid.
Clean tap.
Turn the tap on.
Clean the filter in the
threaded hose fitting.
Press the button for the
selected programme;
then cancel the programme
by pressing RESET (see
chapter: Starting a
programme); Clean out the
filters. (See chapter:
Cleaning the filters).
Check hose installation.
22
Operating instructions
Malfunction
The indicator for the
selected programme is
flashing, in the
programme sequence
indicators ENDE is
flashing in the following
rhythm: two short
signals one after the
other.
In the programme
sequence indicators
ENDE is flashing in the
following rhythm: three
short flashes one after
the other.
The programme is not
starting.
Possible cause Remedy
The siphon is blocked. Clean out siphon.
The water drain hose
has not been correctly
laid.
The leak prevention system
has been triggered.
The door of the dishwasher
is not closed properly.
Mains plug is not plugged in.
House fuse in defective.
In the case of dishwasher
models with start delay
timer:
A start delay is selected.
Check hose installation.
Turn off the tap and contact
your local Service Force
Centre.
Shut the door.
Insert mains plug.
Replace fuse.
If dishes are to be washed
immediately cancel delay
start timer.
Rust spots are visible in
washing compartment.
There is a whistling
noise during washing.
Rust spots in the washing
compartment are from
particles from outside the
appliance (rust particles
from the water pipe, from
pans, cutlery, etc). Remove
such spots with a
commercially available
stainless steel cleaner.
The whistling is not a cause
for concern.
Only wash cutlery and dishes
that are suitable for dishwasher use.
Close the lid of the special
salt container securely.
Use a different brand of
detergent.
23
Operating instructions
....the wash result is not satisfactory.
The dishes are still dirty.
• The wrong programme was selected.
• The dishes were loaded is such a way that the wash water did not
reach all items. The baskets for the dishes must not be overloaded.
• The filters in the base of the washing compartment are dirty or
incorrectly positioned.
• Good quality detergent was not used, or too little was used.
• In the case of scale deposits on the dishes: The special salt dispenser
is empty or the water softener has been incorrectly adjusted.
• The drain hose is incorrectly laid.
The dishes do not dry and are not shiny.
• Poor quality rinse aid used.
• The rinse aid dispenser is empty.
There are smears, streaks, milky spots or a shiny bluish
coating on glasses and dishes.
• Lower rinse aid dosage.
There are dried water drops on the glasses and dishes.
• Increase rinse aid dosage.
• The detergent may be the cause. Contact the detergent
manufacturer's customer advice centre.
24
Glasses corroded
• Contact the detergent manufacturer's customer advice centre.
Operating instructions
Disposal
Packaging material
All the packaging materials used are harmless to the environment and
can be recycled. Plastics are marked, e. g. >PE<, >PS< etc. Use these
marking to dispose of the packaging material in the right containers at
your local recycling centre.
Old appliances
Dispose of your old appliance in accordance with the disposal
guidelines where you live.
Warning! When an appliance is finished with, remove the plug from
the socket. Cut off the cable and plug and dispose of them.
Break the door lock so that the door no longer shuts. This prevents
children from trapping themselves inside and endangering their lives.
Technical data
Capacity:
Permitted water
pressure:
Electrical connection:
Dimensions:
This appliance conforms with the following EU Directives:
- 73/23/EEC dated 19.02.1973 Low Voltage Directive
- 89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending
Directive 92/31/EEC.
- 93/68/EEC dated 22.07.1993 CE Marking Directive
9 place settings including serving dishes
min. 50 kPa (0.5 bar)
max. 800 kPa (8 bar)
Information on the electrical connection is given on the
rating plate located on the right inner edge of the
dishwasher door.
818 - 878 x 446 x 575 (H x W x D in mm)
25
Operating instructions
Notes for Test Institutes
Testing in accordance with EN 60704 must be carried out with the
appliance fully loaded and using the test cycle (see “Programme
Table”).
Tests in accordance with EN 50242 must be carried out when the salt
dispenser in the water softener and the rinse aid dispenser have been
filled with salt and rinse aid respectively, and using the test
programme (see“Programme Table”).
Full load:
Rinse aid setting:
Amount of detergent required:
Example loading arrangement :
Upper basket: without
smaller bowl and salad-bowl
9 place settings
Position 4 (Type III)
5 g + 20 g (Typ B)
Upper basket: with smaller
bowl and salad-bowl
26
Cutlery basket
Lower basket
Installation and connection instructions
INSTALLATION AND CONNECTION
INSTRUCTIONS
Safety information for the installation
• Only transport the dishwasher in an upright position, otherwise salt
water may run out.
• Before using the dishwasher for the first time, check for any damage
caused in transport. Do not under any circumstances connect an
appliance that is damaged. In the case of damage, please contact
your supplier.
• Never use the dishwasher if the mains cable, water inlet or drain
hose are damaged; or if the control panel, work top or plinth area
are damaged such that the inside of the appliance is freely
accessible.
• Always plug the mains plug into a correctly installed shockproof
socket.
• Permanent connection: a permanent connection must only be
installed by a trained electrician.
• Prior to using the appliance for the first time, ensure that the rated
voltage and type of supply on the rating plate match that of the
supply where the appliance is to be installed. The fuse rating is also
to be found on the rating plate.
• Multi-way plugs / connectors and extension cables must not be used.
This could constitute a fire hazard through overheating.
• The dishwasher’s cable must only be replaced by your local Service
Force Centre or a trained specialist technician.
• A water inlet hose with safety valve must only be replaced by your
local Service Force Centre.
• Do not use, for connection, old hoses which have been used in
another appliance.
27
Installation and connection instructions
Installing the dishwasher
• The dishwasher must be installed on a firm floor and adjusted to
ensure that it is stable and level.
• To compensate for unevenness in the floor and to match the height
of the appliance to that of surrounding units, extend the threaded
feet using a screwdriver:
• Adjust the rear feet of the appliance using a cordless screwdriver
from the front of the appliance.
• The drain hose, inlet hose and mains cable must be laid so that they
are able to move freely within the plinth area and so that they are
not kinked or crushed.
• The dishwasher must also be screwed tightly to the work surface or
to the adjoining units. This is essential to ensure the dishwasher does
not tip up.
Dishwashers that can be integrated
(see installation template supplied)
28
Installation and connection instructions
Connecting the dishwasher
Connecting to the water supply
• The dishwasher can be connected to cold and hot water supplies up
to max. 60°C.
• The dishwasher must not be connected to open hot water appliances
or instantaneous water heaters.
Permitted water pressure
Lowest permitted water pressure:
0,5 bar (=5 N/cm2 =50 kPa)
Highest permitted water pressure:
8 bar (=80 N/cm2 =0,8 MPa)
Consult your installer if the water
pressure is less than 0,5 bar.
If the water pressure is greater than 8
bar, a pressure reduction valve must be
used (available from your dealer).
Connecting the inlet hose
The water inlet hose must not be kinked, crushed or entangled when it
is being connected up.
Connect the threaded hose fitting (ISO 228-1:2000) on the water inlet
hose to a tap with an external thread (3/4 inch). The inlet hose is fitted
with either a plastic or a metal nut:
- Tighten the plastic nut hand tight only.
– You must tighten the metal nut using a tool.
Then do a visual check for water tightness (make sure that the tap is
not dripping).
• So that access to the tap in the kitchen is not limited by the use of
the dishwasher, we recommend installing an additional tap, or fitting
a T-branch to the existing tap.
29
Installation and connection instructions
Water outlet hose connection
The end of the drain hose can be connected in the following ways:
1. To the sink outlet spigot, securing it to the underside of the work
surface. This will prevent waste water from the sink running into the
machine.
2. To a stand pipe provided with vent-hole, minimum internal
diameter 4 cm.
The waste connection must be at a height of between 30 cm
(minimum) and 100 cm (maximum) from the bottom of the
dishwasher.
The drain hose can face either to the right or left of the dishwasher
Ensure the hose is not bent or squashed as this could prevent or slow
down the discharge of water.
The sink plug must not be in place when the machine is draining as
this could cause the water to siphon back into the machine.
If you use a drain hose extension it must be no longer than 2 metres
and its internal diameter must be no smaller than the diameter of the
hose provided.
30
CS18
Likewise the internal diameter of the couplings used for connections
to the waste outlet must be no smaller than the diameter of the hose
provided.
Attention!
Our appliances are supplied with a security device to protect against
the return of dirty water back into the machine.
If the spigot of your sink has a "no return valve" incorporated this can
prevent the correct draining of your dishwasher.
We advise you therefore to remove it.
Installation and connection instructions
Anti-flood system
For protection from water demage, the dishwasher is equipped with a
anti-flood sytem.
In the event of a fault, the safety valve in the water inlet hose
immediately interrupts the supply of water to the appliance.
Electrical connection
Details about the voltage, type of supply and the fuses required are to
be found on the rating plate. The rating plate is located on the right
inner edge of the dishwasher door.
To isolate the dishwasher from the mains, pull out the mains plug.
Important:
– The plug must still be accessible after the appliance has
been installed.
– Following installation, live parts and insulated wiring must not be
accessible with a probe in accordance with EN 60335/DIN.
Connections
The water inlet hose, drain hose and the mains cable must all be
connected to the side of the dishwasher as there is no space for them
behind the appliance.
31
Service
Service
If after all these checks, the problem persists, contact your local
consumer services department, quoting the model (Mod.), product
number (PNC) and serial number (S.N.).
This information can be found on the rating plate located on the right
hand side of the dishwasher door (see picture).
So that you always have these numbers at hand, we recommend you
to make a note of them here:
Mod. : . . . . . . . . . . . . . . . . . . . . . . . .
PNC : . . . . . . . . . . . . . . . . . . . . . . . . .
S.N. : . . . . . . . . . . . . . . . . . . . . . . . . . .
RA07
M
o
d
.
........
P
r
o
d
.
N
o
.
........
S
e
r
.
N
o
.
.........
32
Service and spare parts
This product should be serviced by an authorised service engineer, and
only genuine spare parts should be used.
Under no circumstances should you attempt to repair the machine
yourself.
Repairs carried out by inexperienced persons may cause injury or
serious malfunctioning. Contact your local consumer services
department.
Always insist on genuine spare parts.
333435
From the Electrolux Group. The world’s No.1 choice.
The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor
use. More than 55 million Electrolux Group products (such as refrigerators, cookers, vacuum cleaners, chain
saws and lawn mowers) are sold each year to a value of approx. 14 billion USD in more than 150 countries
around the world.
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
© Copyright by AEG
152 967 81/0
Subject to change without notice
Loading...
