user manual
Built-In Electric Oven
EON31000
We were thinking of you
when we made this product
Welcome to the world of Electrolux
Thank you for choosing a first class
product from Electrolux, which hopefully
will provide you with lots of pleasure in
the future. The Electrolux ambition is to
offer a wide variety of quality products
that make your life more comfortable.
You will find some examples on the cover in this manual. Please take a few minutes to study this manual so that you
can take advantage of the benefits of
your new machine. We promise that it
will provide a superior User Experience
delivering Ease-of-Mind. Good luck!
electrolux 3
4 electrolux contents
T
1
Contents
Safety instructions 5
Description of the Appliance 7
Before Using for the first time 9
Using the Rings 10
Using the Oven 13
Uses, Tables and Tips 16
Cleaning and Care 29
What to do if … 40
Installation Instructions 41
Disposal 45
Service 46
he following symbols are used in this user manual:
Important information concerning your personal safety and information on
how to avoid damaging the appliance.
3 General information and tips
2 Environmental information
Safety instructions
5
This appliance conforms with the
following EU Directives:
– 73/23/EEC dated 19.02.1973 Low
Voltage Directive
– 89/336/EEC dated 03.05.1989 EMC
Directive inclusive of Amending Directive 92/31/EEC
– 93/68/EEC dated 22.07.1993 CE
Marking Directive
Electrical safety
• This appliance must be only con-
nected by a registered electrician.
• In the event of a fault or damage to
the appliance: Take the fuses out or
switch off.
• Repairs to the appliance must only
be carried out by qualified service
engineers. Considerable danger
may result from improper repairs. If
repairs become necessary, please
contact our Customer Services or
your dealer.
Child Safety
• Never leave children unsupervised
when the appliance is in use.
Safety whilst Using
• This appliance is intended to be
used for cooking, roasting and baking food in the home.
• Take care when connecting electric
appliances to sockets nearby. Do
not allow connecting leads to come
into contact with or to catch beneath
the hot oven door.
safety instructions electrolux 5
• Warning: Risk of burns! The interi-
or of the oven becomes hot during
use.
• Using ingredients containing alcohol
in the oven may create an alcohol-air
mixture that is easily ignited. In this
case, open the door carefully. Do not
have embers, sparks or naked
flames in the vicinity when opening
the door.
Information on acrylamides
According to the latest scientific
knowledge, intensive browning of
food, especially in products containing starch, can constitute a
health risk due to acrylamides.
Therefore we recommend cooking
at the lowest possible temperatures
and not browning foods too much.
6 electrolux safety instructions
How to avoid damage to the
appliance
• Do not line the oven with aluminium
foil and do not place baking trays,
pots, etc. on the oven floor, as the
heat that builds up will damage the
oven enamel.
• Fruit juices dripping from the baking
tray will leave stains, which you will
not be able to remove. For very moist
cakes, use a deep tray.
• Do not put any strain on the oven
door when open.
• Never pour water directly into the
oven when it is hot. This could cause
damage to or discoloration of the
enamel.
• Rough handling, especially around
the edges of the front panel, can
cause the glass to break.
• Do not store any flammable materials inside the oven. These could ignite when the oven is switched on.
• Do not store any moist foods inside
the oven. This could damage the
oven enamel.
• After switching off the cooling fan, do
not keep uncovered dishes in the oven. Moisture may condense in the
oven interior or on the glass doors
and may get into the units.
Note on enamel coating
Changes in the colour of the oven’s
enamel coating as a result of use do not
affect the appliance’s suitability for normal and correct use. They therefore do
not constitute a defect in the sense of
the warranty law.
Description of the Appliance
General Overview
Control panel
description of the appliance electrolux 7
Door
handle
Full glass door
Control Panel
Hob Cooking Zone Control
Oven Power Indicator
Minute timer
Oven Functions Temperature selector
Temperature Pilot Light
Hob Cooking Zone Control
8 electrolux description of the appliance
Oven Features
Top heat and heating elements
Shelf positions
Oven shelf runners,
Oven accessories
Oven shelf
For cookware, cake tins, roasts and
grilled foods.
Baking tray
For cakes and biscuits.
Oven lighting
Fan
Bottom Heat
removable
Roasting Pan
For baking and roasting or as a pan for
collecting fat.
Before Using for the first time
Initial Cleaning
Before using the oven for the first time
you should clean it thoroughly.
Caution: Do not use any caustic,
abrasive cleaners! The surface
could be damaged.
To clean metal fronts use commercially available cleaning agents.
1. Turn the oven function switch to
oven lighting .
2. Remove all accessories and the shelf
support rails and wash them with
warm water and washing up liquid.
3. Then wash out the oven with warm
water and washing-up liquid, and
dry.
4. Wipe the front of the appliance with
a damp cloth.
before using for the first time electrolux 9
10 electrolux using the rings
Using the Rings
Switch the cooking zone off approx.
5-10 minutes before cooking is fin-
Also refer to the operating instructions for your built-in hob. It contains important information on
ovenware, operation, cleaning and
care.
Heat settings
• Heat settings can be set from 1-9.
• Intermediate positions are possible
for settings 2-7.
1 = lowest output
9 = highest output
= double ring switching
front left rear left rear right front right
ished to make use of the residual
heat. This saves electricity.
Hob Cooking Zone Control Knobs
Cooking with the Rings
1. For heating up/browning, select a
high heat setting.
2. As soon as steam starts to form or
the oil is hot, turn back to the heat
setting necessary for further
cooking.
3. To stop cooking, turn back to the
zero position.
using the rings electrolux 11
The power indicator light is lit as
long as a ring is on.
12 electrolux using the rings
Switching on the dual fry/cook area
The control for the dual fry/cook
area is switched on by turning to the
right, and cannot be turned past the
stop!
1. Turn the dual fry/cook control to the
right. Continue turning to Position 9,
and onto the symbol (you will feel
a slight resistance). The stop position
will then be clearly detectable.
2. Finally, turn back to the desired setting.
3. After cooking, turn back to the OFF
position.
To use the dual fry/cook area again
afterwards, the larger ring must be
switched back on.
Using the Oven
Switching the Oven On and Off
using the oven electrolux 13
Oven Power Indicator
Oven Functions
1. Turn the oven functions dial to the
desired function.
2. Turn the temperature selector to the
desired temperature.
The power indicator is lit as long as the
oven is in operation.
The temperature pilot light is lit as long
as the oven is heating up.
3. To turn the oven off, turn the oven
functions dial and the temperature
selector to the Off position.
Temperature Pilot Light
Temperature selector
Cooling fan
The fan switches on automatically
in order to keep the appliance’s surfaces cool. When the oven is
switched off, the fan continues to
run to cool the appliance down, then
switches itself off automatically.
14 electrolux using the oven
Oven Functions
The oven has the following functions:
Oven function Application
Light
Using this function you can
Convection
Conventional
Bottom heat
Dual grill
Convection grilling
For
the oven interior, e.g. for cleaning.
For
baking
els.
Set the oven temperatures 20-40 °C
lower than when using Conventional.
For
baking
oven level
For
baking
crusty bases
grilling
quantities
For
poultry on one level.
The function is also suitable for
nating
and for
roasting
and
Timer
To set a time. A signal is sounded when
the time has elapsed.
This function has no effect on oven operation.
light up
on up to
and
.
cakes with
flat foodstuffs in
browning
two oven lev-
roasting
.
larger joints of meat or
on
crispy or
toasting
.
one
large
.
grati-
Heating element/
fan
---
Top heat, bottomheat,
fan
Top heat, bottomheat
Bottom heat
Grill, top heat
Grill, top heat, fan
Set the timer knob to 60 minutes, then
turn it to the desired length of time. (60
minutes maximum).
A signal is sounded when the time has
elapsed.
To change your setting, just turn the
knob to the desired value.
To stop the timer before the set time has
elapsed, turn the knob to OFF.
Inserting the Oven Shelf, Baking
Tray and Roasting Pan
Shelf runner safety and anti-tip device
As a shelf runner safety device, all
insertable components have a small
curved indentation at the bottom on
the right and left-hand edge.
Always insert insertable components so that this indentation is at
the back of the oven interior. This indentation is also important for preventing the insertable components
from tipping.
Inserting the baking tray or roasting
pan
Push the baking tray or roasting pan between the guide bars of the selected
oven level.
using the oven electrolux 15
Inserting the oven shelf:
Insert the oven shelf so that the feet
point downwards.
Push the oven shelf between the guide
bars of the selected oven level.
The high rim around the oven shelf
is an additional device to prevent
cookware from slipping.
