AEG-Electrolux EOB31002X User Manual
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully
will provide you with lots of pleasure in the future. The Electrolux ambition is to offer
a wide variety of quality products that make your life more comfortable. You find
some examples on the cover in this manual. Please take a few minutes to study
this manual so that you can take advantage of the benefits of your new machine.
We promise that it will provide a superior User Experience delivering Ease-of-Mind.
Good luck!
electrolux 25
English
For your safety
It is most important that the instruction book should be retained with the appliance for future
reference. Should the appliance be sold or transferred to another owner, or should you move
house and leave the appliance, always ensure that the book is supplied with the appliance in
order that the new owner can be acquainted with the functioning of the appliance and the
relevant warnings. These warnings are provided in the interest of safety. You must read
them carefully before installing or using the appliance.
Installation
! Any installation work must be undertaken
by a qualified electrician or competent
person.
! Installation and initial adjustment of your
oven MUST be carried out by qualified
personnel in compliance with current
regulations. Specific installation
instructions for the installer are given in this
booklet.
During use
! This appliance has been designed for
cooking edible foodstuffs only, and must
not be used for any other purposes.
! Always stand back from the oven when
opening the oven door during cooking or
at the end of it to allow any build up of
steam or heat to release.
! It is dangerous to alter the specifications
or modify the product in any way.
! Appliances become very hot with use, and
retain their heat for a long period after use.
Care should be taken to avoid touching
heating elements inside the oven.
! Always ensure that the control knobs are
in the “off” position when not in use.
! For hygiene and safety reasons, this
appliance should be kept clean at all times.
A build-up of fats or foodstuffs could result
in a fire.
! Never line any part of the oven with
aluminium foil.
! Easy clean-liners (if provided) should never
be cleaned with any other than soapy water.
! Never use steam or steam machines to
clean the appliance.
! Do not use harsh abrasive cleaners or
sharp metal scraper to clean the oven door
glass since they can scratch the surface,
which may result in shattering of the glass.
! Before any maintenance or cleaning work
is carried out on the appliance, always turn
off the isolator switch at the cooker point,
and allow to cool.
! Ensure that the shelves are put in place in
the correct way.
! This oven (even if it is linked to an electrical
cooking table) is made to function at 230 V
monophase with neutral.
People safety
! This appliance is not intended for use by
children or other persons whose physical,
sensory or mental capabilities or lack of
experience and knowledge prevents them
from using the appliance safely without
supervision or instruction by a responsible
person to ensure that they can use the
appliance safely.
! This appliance is designed to be operated
by adults. Children should not be allowed
to tamper with the controls or play with the
product.
! Children should be supervised at all times
and should not be allowed to touch the hot
surfaces or be in the vicinity when in use or
until the appliance has cooled after use.
! During oven cooking and grilling, the
appliance door and the surrounding parts
are warmed up to a very high temperature.
Be careful and keep children away from
the appliance while you are using it. When
26 electrolux
you connect other appliances to a plug near
the oven, check carefully that the wire does
not touch warm parts of the oven and does
not get taken in the oven door.
Technical assistance
! This appliance should be serviced by an
authorized Network Service Centre, and
only genuine spare parts should be used.
! Under no circumstances should you
attempt to repair the appliance yourself.
Repairs carried out by inexperienced
persons may cause injury or serious
malfunctioning. Refer to your local Service
Centre. Always insist on genuine spare
parts.
Guide to Use the instructions
Safety Instructions
Step by step instructions for an
"
operation
Hints and Tips
The symbol
packaging indicates that this product may not
be treated as household waste. Instead it shall
be handed over to the applicable collection
point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed
of correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused
by inappropriate waste handling of this product.
For more detailed information about recycling
of this product, please contact your local city
office, your household waste disposal service
or the shop where you purchased the product.
on the product or on its
This appliance complies with the
following E.E.C. Directives:
- 2006/95 (Low Voltage Directive);
- 89/336 (Electromagnetical Compatibility
Directive);
- 93/68 (General Directives)
and subsequent modifications.
electrolux 27
Contents
For your safety 26
When the oven is first installed 28
Description of the appliance 29
Electric oven 30
Hints and tips for using the oven 32
Cooking tables 34
Cleaning and maintenance 36
What happens if something goes wrong 29
Technical data 40
Instructions for the Installer 41
Building-in 42
Service and spare parts 43
European guarantee 44
When the oven is first installed
Before using the appliance,
remove all packaging, both inside
and outside the appliance,
including the advertising labels
and any protective film.
Before cooking for the first time,
carefully wash the oven accessories.
Once the oven has been installed:
"
1. set the thermostat knob to 250;
2. switch the oven function control knob to
fan cooking function ;
3. allow the oven to run empty for
approximately 45 minutes;
4. open a window for ventilation.
During this time, an unpleasant odour may
be emitted. This is absolutely normal, and
is caused by residues of manufacturing.
Repeat this operation for the grill cooking
function for approximately 5-10 minutes.
Once this operation is carried out, let the
oven cool down, then clean the oven cavity
with a soft cloth soaked in warm soapy
water.
28 electrolux
Fig. 1
To open the oven door, always
catch the handle in its central
part (Fig. 1).
Description of the appliance
362
4 5
1
9
7
8
1. Control panel
2. Oven thermostat control knob
3. Oven thermostat control light
4. End of cooking programmer
5. Operating control light
6. Oven function control knob
7. Grill
8. Oven lamp
9. Rating plate
electrolux 29
Electric oven
0
Oven Function (Fig. 2) and
Thermostat (Fig. 3) control knobs
They enable to select the most appropriate
type of heating for the different cooking
requirements by appropriately connecting
the heating elements and adjusting
temperature to the required level.
OFF position
0
Conventional cooking - The heat
comes from both the top and bottom
element, ensuring even heating
inside the oven.
Grill - The grill element will be on.
Bottom heating element - The heat
comes from the bottom of the oven
only.
Fan cooking - This allows you to roast
or roast and bake simoultaneously
using any shelf, without flavour
transference.
Fig. 2
Defrost setting - This setting is
intended to assist in thawing of frozen
food.
End of cooking programmer
This device (Fig. 4) allows you to make the
oven switch off automatically once the preset
time is over. An acousitic signal will be heard
when the cooking is completed.The cooking
duration can be set up to 90 minutes
maximum.
Place food in the oven and turn the oven
function control knob and the thermostat
control knob on the required settings. Turn
the timer knob to maximum time position
("90"), then turn it back to set the required
cooking time. When the cooking time is over,
30 electrolux
Fig. 3
Fig. 4
0
an acoustic alarm will sound and the oven
will switch off automatically.
Turn the timer knob on to set the oven on
manual operation.
Operating control light
It indicates that one or more of the heating
elements are turned on.
Oven thermostat control light
This light goes off when the oven heats up
to the temperature set and comes on again
every time the thermostat cuts in to stabilize
temperature.
Safety thermostat
In order to avoid excessive overheating due
to incorrect use of the appliance or else to a
faulty component, the oven is equipped with
a safety thermostat which cuts off the power
supply if necessary. Operation is restored
automatically when the oven temperature
decreases to normal values. Therefore, if the
thermostat cuts in because you have not
been using the appliance correctly, the oven
can be used again simply by waiting for the
appliance to cool down. If, instead, the
thermostat cuts in because of a faulty
component, you should call the Service
Department.
The cooling fan
The oven is provided with a cooling fan,
meant to keep the front panel, the knobs
and the oven door handle cool.
The fan switches on automatically when the
oven is activated. Warm air is blown out
through the aperture near the oven door
handle. The fan switches off when, after
cooking, the oven function control knob is
set to OFF position
.
0
electrolux 31
Hints and tips for using the oven
Always cook with the oven door
closed.
The oven is supplied with an exclusive system
which produces a natural circulation of air
and the constant recycling of steam.
This system makes it possible to cook in a
steamy environment and keep the dishes soft
inside and crusty outside. Moreover, the
cooking time and energy consumption are
reduced to a minimum. During cooking steam
may be produced which can be released when
opening the oven door. This is absolutely
normal.
However, always stand back from the
oven when opening the oven door during
cooking or at the end of it to allow any
build up of steam or heat to release.
Conventional cooking
Heat comes from the top and from the
bottom, therefore it is preferable to use the
central runners.
If cooking requires more heat from the top
or from the bottom use the top or the bottom
runners.
heights means that you can cook several
different dishes at the same time and up to
three tins of biscuits and mini pizzas to be
eaten immediately or subsequently deep
frozen.
Naturally the oven can also be used for
cooking on just one shelf. In this case you
should use the lowest set of runners so that
you can keep an eye on progress more
easily.
In addition, the oven is particularly
recommended for sterilizing preserves,
cooking home-made fruit in syrup, and for
drying mushrooms or fruit.
Grilling
When grilling meat or fish, spread a little oil
on them and always place them on the oven
grid. The shelf level depends on the
thinckness of the food.
Always place the dripping pan at the lowest
level, with some water in it, to avoid smoke
and unpleasant smells.
Some hints
Fan cooking
The food is cooked by means of preheated
air force blown evenly round the inside of
the oven by a fan set on the rear wall of the
oven itself.
Heat thus reaches all parts of the oven evenly
and fast and this means that you can
simultaneously cook different types of foods
positioned on the various oven shelves (Fig.
5). Fan cooking ensures rapid elimination
of moisture and the dryer oven environment
stops the different aromas and flavours from
being transmitted from one food to another.
The possibility of cooking on several shelf
32 electrolux
For baking cakes
Cakes require a moderate temperature
(normally between 150 °C and 200 °C). In
addition, the oven must be heated up
beforehand - for about 10 minutes.
Fan cooking
4
3
2
1
Fig. 5
Loading...
